Beko LXSP1545DS User manual

EWWERQWEW
LSG1545DS
LSG1545DW
LXSP1545DS
LXSG1545DS
EN
Refrigerator
User manual

EN
1
Please read this user manual first!
Dear Customer,
We hope that your product, which has been produced in modern plants and
checked under the most meticulous quality control procedures, will provide
effective service.
Therefore, read this entire user manual carefully before using the product and
keep it as a reference. If you handover the product to someone else, give the
user manual as well.
The user manual will help you use the product in a fast and safe way.
• Read the manual before installing and operating the product.
• Make sure you read the safety instructions.
• Keep the manual in an easily accessible place as you may need it later.
• Read the other documents given with the product.
Remember that this user manual is also applicable for several other models.
Differences between models will be identified in the manual.
Explanation of symbols
Throughout this user manual the following symbols are used:
CImportant information or useful tips.
AWarning against dangerous conditions for life and property.
BWarning against electric voltage.

EN
2
CONTENTS
1 Your appliance 3
2 Warnings 4
Electrical requirements...........................6
Warning! This appliance must be
earthed..........................................................6
Energy saving tips..................................... 7
Compliance with WEEE Directive and
Disposing of the Waste Product: .......8
Compliance with rohs directive: .........8
Package information................................8
3 Installation 9
Points to be paid attention to when
the relocation of the appliance ...........9
Before you start the appliance,...........9
Electrical connection .............................10
Disposing of the packaging.................10
Disposing of your old appliance .......10
Placing and Installation......................... 11
4 Preparation 12
Reversing the doors...............................13
5 Using your appliance 14
Temperature Control And
Adjustment................................................14
Thermostat setting button.................14
Defrost.........................................................15
Using the water dispenser..................16
Filling the water dispenser's tank ....17
Cleaning the water tank .....................18
Drip tray......................................................19
6 Maintenance and
cleaning 20
Protection of plastic surfaces .......... 20
7 Troubleshooting 21
8 How To Obtain Service 25
9 Guarantee Details 26

EN
3
C Figures that take place in this instruction manual are schematic and may not
correspond exactly with your product. If the subject parts are not included in the
product you have purchased, then it is valid for other models.
1Your appliance
1. Temperature setting knob
2. Movable shelves
3. Defrost water collection channel -
Drain tube
4. Crisper cover
5. Crisper
6. Adjustable front feet
7. Dairy compartment
8. Water dispenser filling tank
9. Egg section
10. Water dispenser reservoir
11. Adjustable door shelves
12. Bottle shelf
Congratulations on your choice a Beko quality Appliance which has been
designed to give you service for many years.
1
*2
5
6
4
3
*7
*11
*12
10
*8
9
*May not be available in all models

EN
4
2Warnings
• Do not connect your
appliance to the
electricity supply until
all packing and transit
protectors have been
removed.
• If transported
horizontally leave to
stand upright for at
least 4 hours before
switching on to allow
compressor oil to settle
• If you are discarding an
old refrigerator with a
lock or latch fitted to the
door, disable the lock/
latch, ensure that it is
left in a safe condition to
prevent the entrapment
of young children.
• This fridge/freezer
must only be used for its
intended purpose i.e the
storing and freezing of
edible foodstuff.
• Do not dispose of the
appliance on a fire.
At Beko, the care
and protection of our
environment is an
ongoing commitment.
This appliance which is
among the latest range
introduced is particularly
environment friendly.
Your appliance
contains non CFC / HFC
natural substances
in the cooling system
(Called R600a) and
in the insulation
(Called cyclopentane)
which are potentially
flammable if exposed
to fire. Therefore, take
care not to damage,
the cooling circuit /
pipes of the appliance
in transportation
and in use. In case of
damage do not expose
the appliance to fire
or potential ignition
source and immediately
ventilate the room
where the appliance is
situated.
• We suggest you contact
your local authority for
disposal information
and facilities available.
• To obtain the best
possible performance
and trouble free
operation from your
2

EN
5
appliance it is very
important to carefully
read these instructions.
• On delivery, check to
make sure that the
product is not damaged
and that all the parts
and accessories are in
perfect condition.
• Ensure that the
plug remains readily
accessible. Do not use
multiple adapter or
extension cable.
• Failure to observe
these instructions may
invalidate your right to
free service during the
guarantee period.
• Keep ventilation
openings, in the
appliance enclosure or
in the built-in structure,
clear of obstruction.
• Do not damage the
refrigerant circuit.
• Do not use electrical
appliances inside
the food storage
compartments of
the appliance, unless
they are of the type
recommended by the
manufacturer.
• We suggest you keep
these instructions in
a safe place for easy
reference.
• This appliance can
be used by children
aged from 8 years and
above and persons
with reduced physical,
sensory or mental
capabilities or lack
of experience and
knowledge if they have
been given supervision
or instruction
concerning use of the
appliance in a safe
way and understand
the hazards involved.
Children shall not play
with the appliance.
Cleaning and user
maintenance shall not
be made by children
without supervision.
• Children should be
supervised to ensure
that they do not play
with the appliance.

EN
6
Electrical
requirements
Before you insert
the plug into the wall
socket make sure that
the voltage and the
frequency shown on the
rating plate inside the
appliance corresponds to
your electricity supply.
Rating label is on the left
hand side of fridge inner
liner.
We recommend that this
appliance be connected
to the mains supply
via a suitable switched
and fused socket. The
appliance must be
positioned so that the
plug is accessible.
WARNING:
When positioning the
appliance ensure the
supply cord is not trapped
or damaged.
Should the mains lead
of the appliance become
damaged or should it
need replacing at any
time, it must be replaced
by a special purpose
made mains lead which
can only be obtained
from a Beko authorised
service agent.
Warning! This
appliance must be
earthed
If the fitted moulded
plug is not suitable for
your socket, then the
plug should be cut off
and an appropriate plug
fitted. Destroy the old
plug which is cut off as
a plug with bared cord
could cause a shock
hazard if inserted into a
socket elsewhere in the
house.
Themouldedplugonthis
appliance incorporates
a 13 A fuse. Should the
fuse need to be replaced
an ASTABEAB approved
BS 1362 fuse of the same
rating must be used. Do
not forget to refit the
fuse cover. In the event of
losing the fuse cover the
plug must not be used
until a replacement fuse
cover has been fitted.
Colour of the
replacement fuse cover
must be the same colour
as that visible on the pin
face of the plug. Fuse
covers are available from
any good electrical store.

EN
7
Important! Fitting A
Different Plug
1. As the colours of the wires in the
mains lead of this appliance may
not correspond with the coloured
markings identifying the terminals
in your plug proceed as follows: (See
diagram).
2. Connect the green-yellow or green
(Earth) wire to the terminal in the
plug marked ‘E’ or with the symbol
or coloured green and yellow or
green.
3. Connect the blue (Neutral) wire to
the terminal in the plug marked ‘N’ or
coloured black.
4. Connect the brown (Live) wire to
the terminal in the plug marked ‘L’ or
coloured red.
5. With alternative plugs a 13 A fuse
must be fitted either in the plug or
adaptor or in the main fuse box. If in
doubt contact a qualified electrician.
Energy saving tips
1. Ensure your appliance is installed in
a well ventilated area.
2. Ensure the time between buying
chilled/frozen food and placing
them in your appliance is kept at
minimum, particularly in summer.
We recommend you use a cool bag
or a special carrier bag to carry
perishable food.
3. Do not leave the door (s) of your
appliance open longer than
necessary and ensure they are
closed properly after each opening.
4. Defrost frozen food in the fridge
compartment, so that frozen food
acts as an ice pack to assist cooling
in the fridge.
5. Energy consumption of this
appliance is measured while freezer
compartment is loaded without
use of top shelf lid and the drawers
except the bottom drawer. It is
advised that freezer compartment
is loaded without use of drawers
except the bottom drawer in order to
achieve maximum loading capacity.
FITTED WITH
BS 1362 13A FUSE ALWAYS
FIT BS 1362 REPLACEMENT
CARTRIDGE FUSE
GREEN &
YELLOW
OR
GREEN
N
BLUE
OR
BLACK
L
BROWN
OR
RED
22mm.
6mm.
6mm.
6mm. 32mm.
12mm.
FUSE
CORD GRIP

EN
8
Compliance with
WEEE Directive and
Disposing of the
Waste Product:
This product complies
with EU WEEE Directive
(2012/19/EU). This
product bears a
classification symbol for
waste electrical and
electronic equipment (WEEE).This
product has been manufactured with
high quality parts and materials which
can be reused and are suitable for
recycling. Do not dispose of the waste
product with normal domestic and
other wastes at the end of its service
life. Take it to the collection center for
the recycling of electrical and
electronic equipment. Please consult
your local authorities to learn about
these collection centers.
Compliance with rohs
directive:
The product you have purchased
complies with EU RoHS Directive
(2011/65/EU). It does not contain
harmful and prohibited materials
specified in the Directive.
Package information
Packaging materials of the product
are manufactured from recyclable
materials in accordance with our
National Environment Regulations. Do
not dispose of the packaging materials
together with the domestic or other
wastes. Take them to the packaging
material collection points designated
by the local authorities.

EN
9
3Installation
BThe manufacturer will not be liable
for any event caused by disregarding
the information supplied in this user
manual.
Points to be paid attention
to when the relocation of
the appliance
1. Your appliance should be unplugged.
Before transportation of your
appliance, it should be emptied and
cleaned.
2. Before it is re-packaged, shelves,
accessories, crisper, etc. inside
your appliance should be fixed
with adhesive tape and secured
against impacts. Packaging should
be adequate and the transportation
rules on the package should be
strictly observed.
3. Original packaging and foam
materials should be kept for future
transportations or moving.
Before you start the
appliance,
Check the following before you start
to use your appliance:
1. Clean the interior of the appliance as
recommended in the “Maintenance
and cleaning” section.
2. Connect the plug of the appliance
to the wall socket. When the fridge
door is opened, fridge internal lamp
will turn on.
3. When the compressor starts to
operate, a sound will be heard. The
liquid and gases sealed within the
refrigeration system may also give
rise to noise, even if the compressor
is not running and this is quite
normal.
4. Front edges of the appliance may
feel warm. This is normal. These
areas are designed to be warm to
avoid condensation.

EN
10
Electrical connection
Connect your product to a grounded
socket which is being protected by a
fuse with the appropriate capacity.
Important:
The connection must be in
compliance with national regulations.
• The power plug must be easily
accessible after installation.
• Electrical safety of your appliance
shall be guaranteed only if the earth
system in your house complies with
standards.
• The voltage stated on the label
located at left inner side of your
product should be equal to your
network voltage.
• Extension cables and multi plugs
must not be used for connection.
BA damaged power cable must be
replaced by a qualified electrician.
BProduct must not be operated
before it is repaired! There is the risk
of electric shock!
Disposing of the packaging
The packing materials may be
dangerous for children. Keep the
packing materials out of the reach
of children or dispose of them by
classifying them in accordance with
the waste instructions stated by your
local authorities. Do not throw away
with regular house waste, throw away
on packaging pick up spots designated
by the local authorities.
The packing of your appliance is
produced from recyclable materials.
Disposing of your old
appliance
Disposeofyouroldappliancewithout
giving any harm to the environment.
• You may consult your authorized
dealer or waste collection center of
your municipality about the disposal
of your appliance.
Before disposing of your appliance,
cut out the electric plug and, if there
are any locks on the door, make them
inoperable in order to protect children
against any danger.
The condenser of your appliance is located on the back as shown below. In
order to achieve better energy efficiency with lower energy consumption,
please pull the condenser towards yourself as illustrated in picture below.
*may not be available in all models
better energy
efficiency
2-b
initial position
PULL
PULL

EN
11
Placing and Installation
AIf the entrance door of the room
where the appliance will be installed is
not wide enough for the appliance to
pass through, then carefully remove
the doors of your appliance and pass
it sideways through the door.
1. Install your appliance to a place that
allows ease of use.
2. Keep your appliance away from heat
sources, humid places and direct
sunlight.
3. There must be appropriate air
ventilation around your appliance
in order to achieve an efficient
operation. If the appliance is to be
placed in a recess in the wall, there
must be at least 5 cm distance with
the ceiling and at least 5 cm with the
wall. Do not place your product on
the materials such as rug or carpet.
4. Place your appliance on an even
floor surface to prevent jolts.

EN
12
4Preparation
• Your appliance should be installed at
least 30 cm away from heat sources
such as hobs, ovens, central heater
and stoves and at least 5 cm away
from electrical ovens and should not
be located under direct sunlight.
• The ambient temperature of
the room where you install your
appliance should at least be
10°C. Operating your appliance
under cooler conditions is not
recommended with regard to its
efficiency.
• Please make sure that the interior of
your appliance is cleaned thoroughly.
• If two appliances are to be installed
side by side, there should be at least
2 cm distance between them.
• When you operate your appliance
for the first time, please observe the
following instructions during the
initial six hours.
• The door should not be opened
frequently.
• It must be operated empty without
any food in it.
• Do not unplug your appliance. If a
power failure occurs out of your
control, please see the warnings in
the “Recommended solutions for
the problems” section.
• Original packaging and foam
materials should be kept for future
transportations or moving.
• Due to temperature change as
a result of opening/closing the
product door during operation,
condensation on the door/body
shelves and the glass containers is
normal.

EN
13
Reversing the doors
3
2
7
8
9
10
11
13
14
17
15
16
1
4
5
6
12

EN
14
Warm Cold
1 2 3 4 5
(Or) Min. Max.
5Using your appliance
Temperature Control And Adjustment
The operating temperature is regu
lated by the temperature control.
Warm Cold
1 2 3 4 5
(Or) Min. Max.
1=Lowest cooling setting
(Warmest setting).
5=Highest cooling setting (Coldest
setting).
The average temperature inside the
fridge should be around +5°C.
Please choose the setting according
to the desired temperature.
Please note that there will be
different temperatures in the cooling
area.
The coldest region is immediately
above the vegetable compartment.
The interior temperature also
depends on ambient temperature,
the frequency with which the door is
opened and the amount of foods kept
inside.
Frequently opening the door causes
the interior temperature to rise.
For this reason, it is recommended
to close the door again as soon as
possible after use.
Thermostat setting button
The interior temperature of your
refrigerator changes for the following
reasons;
• Seasonal temperatures,
• Frequent opening of the door and
leaving the door open for long
periods,
• Food put into the refrigerator
without cooling down to the room
temperature,
• The location of the refrigerator in
the room (e.g. exposing to sunlight).
• You may adjust the varying interior
temperature due to such reasons
by using the thermostat. Numbers
around the thermostat button
indicates the cooling degrees.
• If the ambient temperature is higher
than 25°C, turn the thermostat
button to maximum position.
• If the ambient temperature is lower
than 25°C, turn the thermostat
button to minimum position.

EN
15
Defrost
The frdge compartment defrosts
automatcally. The thawng water
flows through the dran channel nto a
collecton contaner at the rear of the
devce.
Durng defrostng, water droplets
form at the back of the frdge due to
the evaporator.
If not all of the drops run down, they
may freeze agan after defrostng but
wll be thawed durng the next defrost
cycle.
Check the flow of the thawed water
from tme to tme.It may become
blocked occasonally.

EN
16
Using the water dispenser
*optional
CIt is normal for the first
few glasses of water taken
from the dispenser to be
warm.
CIf the water dispenser is
not used for a long period
of time, dispose of first few
glasses of water to obtain
fresh water.
1. Push in the lever of the water
dispenser with your glass. If you are
using a soft plastic cup, pushing the
lever with your hand will be easier.
2. After filling the cup up to the
level you want, release the lever.
CPlease note, how much
water flows from the
dispenser depends on
how far you depress the
lever. As the level of water
in your cup / glass rises,
gently reduce the amount
of pressure on the lever
to avoid overflow. If you
slightly press the arm, the
water will drip; this is quite
normal and not a failure.

EN
17
Filling the water
dispenser's tank
Water tank filling reservoir is located
inside the door rack.
1. Open the cover of the tank.
2. Fill the tank with fresh drinking
water.
3. Close the cover.
CDo not fill the water
tank with any other liquid
except for water such as
fruit juices, carbonated
beverages or alcoholic
drinks which are not
suitable to use in the water
dispenser. Water dispenser
will be irreparably damaged
if these kinds of liquids are
used. Warranty does not
cover such usages. Some
chemical substances and
additives contained in these
kinds of drinks/liquids may
damage the water tank.
CUse clean drinking water
only.

EN
18
CCapacity of the water tank
is 3 litres; do not overfill.
Cleaning the water tank
1. Remove the water filling
reservoir inside the door rack.
2. Remove the door rack by
holding from both sides.
3. Grab the water tank from both
sides and remove it with an angle of
45°C.
4. Remove the cover of the water
tank and clean the tank.
CComponents of the water
tank and water dispenser
should not be washed in
dishwasher.

EN
19
Drip tray
Water that dripped while using the
water dispenser accumulates in the
spillage tray.
Remove the plastic filter as shown in
the figure.
With a clean and dry cloth, remove the
water that has accumulated.
