Beko RDNE455E30DZXPN User manual

RDNE455E30DSN-RDNE455E30DBN-RDNE455E30DZXPN
EN/İT
58 4745 0000/AE-EN-İT 1/2
Refrigerator
User Manual
Frigorifero
Manuale utente
Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Beko RDNE455E30DBN
o cerca il tuo prodotto tra le migliori offerte di Frigoriferi e Congelatori

Please read this user manual first!
Dear Customer,
We hope that your product, which has been produced in modern plants and checked
under the most meticulous quality control procedures, will provide you an effective
service.
Therefore, read this entire user manual carefully before using the product and keep
it as a reference. If you handover the product to someone else, give the user manual
as well.
The user manual will help you use the product in a fast and safe way.
Read the manual before installing and operating the product.
Make sure you read the safety instructions.
Keep the manual in an easily accessible place as you may need it later.
Read the other documents given with the product.
Remember that this user manual is also applicable for several other models.
Differences between models will be identified in the manual.
Explanation of symbols
Throughout this user manual the following symbols are used:
CImportant information or
useful hints.
ARisk of injury and damage to
the property.
BRisk of electric shock.
Packaging materials of
the product are manufac-
tured from recyclable ma-
terials in accordance with
our National Environment
Regulations.
A
A
A
C
SUPPLIER’S NAME MODEL IDENTIFIER (*)
INFORMATION
C
.The model information as stored in the product data base
can be reached by entering following website and searching
for your model identifier (*) found on energy label.
https://eprel.ec.europa.eu/

2 /39 EN Refrigerator / User Manual
1. Safety and environment
instructions 3
1.1. General safety . . . . . . . . . . . . . . . . . . . 3
1.1.1 HC warning . . . . . . . . . . . . . . . . . . . . . . 5
1.1.2 For models with water dispenser5
1.2. Intended use. . . . . . . . . . . . . . . . . . . . . 5
1.3. Child safety . . . . . . . . . . . . . . . . . . . . . . 5
1.4. Compliance with the WEEE Directive
and Disposing of the Waste
Product: . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.5. Compliance with RoHS Directive 6
1.6. Package information . . . . . . . . . . . . 6
2Your appliance 7
3Installation 8
3.1. Appropriate installation location8
3.2. Installing the plastic wedges. . . . 8
3.3. Adjusting the feet . . . . . . . . . . . . . . . 9
3.4. Electrical connection . . . . . . . . . . . . 9
3.5. Reversing the doors . . . . . . . . . . . .10
3.6. Reversing the doors . . . . . . . . . . . . 11
4 Preparation 12
4.1. Things to be done for energy
saving. . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.2. Initial use . . . . . . . . . . . . . . . . . . . . . . . 12
5Operating the product 13
5.1. Temperature setting button . . . 13
5.2. Fast freeze . . . . . . . . . . . . . . . . . . . . . 13
5.3. Vacation function . . . . . . . . . . . . . . 14
5.4. Indicator panel. . . . . . . . . . . . . . . . . . 15
5.5. Indicator panel. . . . . . . . . . . . . . . . . .18
5.6. Twist Ice – matic . . . . . . . . . . . . . . .23
5.7. Ice container. . . . . . . . . . . . . . . . . . . .24
5.8. Egg holder . . . . . . . . . . . . . . . . . . . . . .24
5.9. Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
5.10 Crisper. . . . . . . . . . . . . . . . . . . . . . . . . .24
5.11.Chiller compartment. . . . . . . . . . . .24
5.12.Moving door shelf . . . . . . . . . . . . . .25
5.13.Sliding storage container . . . . . .25
5.14.Humidity controlled crisper . . . .26
5.15.Auto Icematic . . . . . . . . . . . . . . . . . .26
5.16Description and cleaning of odor
filter. . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
5.17.HerbBox/HerbFresh. . . . . . . . . . . .27
5.18.Using the water dispenser . . . . .28
5.19.Using the water dispenser. . . . .28
5.20.Filling the water dispenser's tank2 9
5.21. Cleaning the water tank . . . . . . .30
5.22.Drip tray . . . . . . . . . . . . . . . . . . . . . . . . 31
5.23.Blue light/HarvestFresh . . . . . . .31
5.24.Freezing fresh food . . . . . . . . . . . .32
5.25.Recommendations for preserving
the frozen food . . . . . . . . . . . . . . . . .33
5.26.Deep-freeze information . . . . . .33
5.27.Placing the food . . . . . . . . . . . . . . . .33
5.28.Door open warning . . . . . . . . . . . .34
5.29.Changing the door opening
direction . . . . . . . . . . . . . . . . . . . . . . . .34
5.30.Illumination lamp. . . . . . . . . . . . . . .34
6Maintenance and cleaning 35
6.1. Avoiding bad odors . . . . . . . . . . . . .35
6.2. Protecting the plastic surfaces 35
6.3. Door Glasses . . . . . . . . . . . . . . . . . . .35
6Maintenance and cleaning36
7. Troubleshooting 37
Contents

3/39 EN
Refrigerator / User Manual
This section provides the safety
instructions necessary to prevent
the risk of injury and material
damage. Failure to observe these
instructions will invalidate all types
of product warranty.
Intended use
A
WARNING:
Keep ventilation
openings, in the appliance
enclosure or in the built-
instructure, clear of
obstruction.
A
WARNING:
Do not use mechanical
devices or other means
to accelerate the
defrosting process,
other than those
recommended by the
manufacturer.
AWARNING:
Do not damage the
refrigerant circuit.
A
WARNING:
Do not use electrical
appliances inside
the food storage
compartments of
the appliance, unless
they are of the type
recommended by the
manufacturer.
This appliance is intended to be
used in household and similar
applications such as
– staff kitchen areas in shops,
offices and other working
environments;
– farm houses and by clients
in hotels, motels and other
residential type environments;
– bed and breakfast type
environments;
– catering and similar non-retail
applications.
1.1.General safety
 This product should not be
used by persons with physical,
sensory and mental disabilities,
without sufficient knowledge
and experience or by children.
The device can only be used by
such persons under supervision
and instruction of a person
responsible for their safety.
Children should not be allowed
to play with this device.
 In case of malfunction, unplug
the device.
 After unplugging, wait at least
5 minutes before plugging in
again.
 Unplug the product when not
in use.
 Do not touch the plug with wet
hands! Do not pull the cable to
plug off, always hold the plug.
 Do not plug in the refrigerator if
the socket is loose.
 Unplug the product during
installation, maintenance,
cleaning and repair.
 If the product will not be used
for a while, unplug the product
and remove any food inside.
 Do not use the product when
the compartment with circuit
cards located on the upper back
part of the product (electrical
card box cover) (1) is open.
1. Safety and environment instructions

Instructions for safety and environment
4 / 39 EN Refrigerator / User Manual
1
1
 Do not use steam or steamed
cleaning materials for
cleaning the refrigerator and
melting the ice inside. Steam
may contact the electrified
areas and cause short circuit
or electric shock!
 Do not wash the product by
spraying or pouring water on
it! Danger of electric shock!
 In case of malfunction, do
not use the product, as it may
cause electric shock. Contact
the authorised service before
doing anything.
 Plug the product into an
earthed socket. Earthing
must be done by a qualified
electrician.
 If the product has LED
type lighting, contact the
authorised service for
replacing or in case of any
problem.
 Do not touch frozen food with
wet hands! It may adhere to
your hands!
 Do not place liquids in bottles
and cans into the freezer
compartment. They may
explode.
 Place liquids in upright
position after tightly closing
the lid.
 Do not spray flammable
substances near the product,
as it may burn or explode.
 Do not keep flammable
materials and products with
flammable gas (sprays, etc.)
in the refrigerator.
 Do not place containers
holding liquids on top of the
product. Splashing water on
an electrified part may cause
electric shock and risk of fire.
 Exposing the product to rain,
snow, sunlight and wind
will cause electrical danger.
When relocating the product,
do not pull by holding the
door handle. The handle may
come off.
 Take care to avoid trapping
any part of your hands or
body in any of the moving
parts inside the product.
 Do not step or lean on the
door, drawers and similar
parts of the refrigerator. This
will cause the product to fall
down and cause damage to
the parts.
 Take care not to trap the
power cable.

Instructions for safety and environment
5/39 EN
Refrigerator / User Manual
1.1.1 HC warning
If the product comprises a
cooling system using R600a
gas, take care to avoid
damaging the cooling system
and its pipe while using and
moving the product. This gas
is flammable. If the cooling
system is damaged, keep the
product away from sources
of fire and ventilate the room
immediately.
CThe label on the inner left
side indicates the type of
gas used in the product.
1.1.2 For models with
water dispenser
 Pressure for cold water inlet
shall be maximum 90 psi(6.2
bar). If your water pressure
exceeds 80 psi(5.5 bar), use
a pressure limiting valve in
your mains system. If you
do not know how to check
your water pressure, ask for
the help of a professional
plumber.
 If there is risk of water
hammer effect in your
installation, always
use a water hammer
prevention equipment in
your installation. Consult
Professional plumbers if you
are not sure that there is no
water hammer effect in your
installation.
 Do not install on the hot
water inlet. Take precautions
against of the risk of
freezing of the hoses. Water
temperature operating
interval shall be 33°F (0.6°C)
minimum and 100°F (38°C)
maximum.
 Use drinking water only.
1.2.Intended use
 This product is designed for
home use. It is not intended
for commercial use.
 The product should be used
to store food and beverages
only.
 Do not keep sensitive
products requiring controlled
temperatures (vaccines,
heat sensitive medication,
medical supplies, etc.) in the
refrigerator.
 The manufacturer assumes
no responsibility for any
damage due to misuse or
mishandling.
 Original spare parts will
be provided for 10 years,
following the product
purchasing date.
1.3.Child safety
 Keep packaging materials
out of children’s reach.
 Do not allow the children to
play with the product.
 If the product’s door
comprises a lock, keep the
key out of children’s reach.

Instructions for safety and environment
6 / 39 EN Refrigerator / User Manual
1.4. Compliance with
the WEEE Directive
and Disposing of the
Waste Product:
This product complies with EU WEEE Directive
(2012/19/EU). This product bears a classifica-
tion symbol for waste electrical and electronic
equipment (WEEE).
This symbol indicates that this prod-
uct shall not be disposed with other
household wastes at the end of its
service life. Used device must be re-
turned to offical collection point for
recycling of electrical and electronic devices. To
find these collection systems please contact to
your local authorities or retailer where the prod-
uct was puchased. Each household performs
important role in recovering and recycling of old
appliance. Appropriate disposal of used appli-
ance helps prevent potential negative conse-
quences for the environment and human
health.
1.5.Compliance with
RoHS Directive
The product you have purchased complies with
EU RoHS Directive (2011/65/EU). It does not
contain harmful and prohibited materials speci-
fied in the Directive.
1.6.Package
information
Packaging materials of the product
are manufactured from recyclable
materials in accordance with our
National Environment Regulations.
Do not dispose of the packaging materials to-
gether with the domestic or other wastes. Take
them to the packaging material collection points
designated by the local authorities.

7/39 EN
Refrigerator / User Manual
1. Fridge - compartment door shelf
2. Temperature setting button
3. Water dispenser filling tank
4. Egg section
5. Water dispenser reservoir
6. Storage container under the door shelf
7. Moving door shelf
8. Adjustable feet
9. Crisper
10. Chiller compartment
11. Lock and key
12. Bottle shelf
13. Fridge - compartment glass shelf
14. Fan
15. Freezer compartment shelf
16. Icebox / Ice-making compartment
17. Freezer compartment
18. Fridge compartment
2Your appliance
C*optional:Figures in this user manual are given as an example and may not
match the product exactly. If the relevant parts are not available in the product you
purchased, the figure applies to other models.
*1
*3
*5
*4
*6
*2
*7
8
*9
*10
*11
*12
*13
14
14
17
18
*15
*16
*16
8

8 /39 EN Refrigerator / User Manual
3Installation
3.1.Appropriate
installation location
Contact an Authorized Service for the
installation of the product. In order to
prepare the product for use, refer the
information in the user manual and
ensure that electrical installation and
water installation are appropriate. If not,
call a qualified electrician and technician
to have any necessary arrangements
carried out.
BWARNING: Manufacturer shall
not be held liable for damages that
may arise from procedures carried
out by unauthorized persons.
BWARNING: Product must not
be plugged in during installation.
Otherwise, there is the risk of
death or serious injury!
A
WARNING: If the door clearance
of the room where the product
shall be place is so tight to prevent
passing of the product, remove
the door of the room and pass
the product through the door by
turning it to its side; if this does
not work, contact the authorized
service.

surface to prevent jolts.

away from heat sources such as hobs,
heater cores and stoves and at least 5
cm away from electrical ovens.

direct sun light and kept in humid
places.

circulation to function efficiently. If
the product will be placed in an alcove,
remember to leave at least 5 cm
clearance between the product and
the ceiling, rear wall and the side walls.

alcove, remember to leave at least 5
cm clearance between the product
and the ceiling, rear wall and the side
walls. Check if the rear wall clearance
protection component is present at its
location (if provided with the product).
If the component is not available, or if
it is lost or fallen, position the product
so that at least 5 cm clearance shall be
left between the rear surface of the
product and the wall of the room. The
clearance at the rear is important for
efficient operation of the product.

where the temperature falls below
-5°C.
3.2.Adjusting the feet
If the product stands unbalanced after
installation, adjust the feet on the front
by rotating them to the right or left.

Installation
9 /39 EN
Refrigerator / User Manual
3.3.Electrical
connection
AWARNING:Do not make
connections via extension
cables or multi-plugs.
BWARNING: Damaged power
cable must be replaced by the
Authorized Service Agent.
CIf two coolers are to be
installed side by side, there
should be at least 4 cm
distance between them.
 Our company shall not be liable
for any damages that will arise
when the product is used
without grounding and electrical
connection in accordance with the
national regulations.
 Power cable plug must be within
easy reach after installation.
 Do not extension cords or cordless
multiple outlets between your
product and the wall outlet.
C
Hot Surface Warning!
Side walls of your product is
equipped with refrigerant
pipes to improve the cooling
system. Refrigerant with
high temperatures may flow
through these areas, resulting
in hot surfaces on the side
walls. This is normal and does
not need any servicing. Please
pay attention while touching
these areas.

Installation
10 / 39 EN Refrigerator / User Manual
3.4. Reversing the doors
Proceed in numerical order .
4
1
5
10 11
3
6
78
12
19
18
14
13
21
21
9
45 °
2
17
16
20
15

Installation
11 /39 EN
Refrigerator / User Manual
3.5.Reversing the doors
Proceed in numerical order .
1
5
10 11
3
6
78
19
18
14
13
9
45 °
2
17
16
12
4
15
20

12 /39 EN Refrigerator / User Manual
4.1. Things to be done
for energy saving
AConnecting the product to electric
energy saving systems is risky
as it may cause damage on the
product.
 For a freestanding appliance; ‘this
refrigerating appliance is not intended
to be used as a built-in appliance.
 Do not leave the doors of your
refrigerator open for a long time.
 Do not put hot food or drinks in your
refrigerator.
 Do not overload the refrigerator,
cooling capacity will fall when the air
circulation inside is hindered.
 In order to store maximum amount
of food in the freezer compartment,
the icematic, available in the freezer
compartment and easily removable by
hand, shall be taken out. Net volume
and energy consumption values
declared on the power data plate of
your refrigerator are measured and
tested by removing the icematic. Do
not remove the shelves inside the
freezer compartment and on the door
of freezer compartment shall not be
removed and they shall always be used
they provide ease of use and efficiency
in energy consumption.
 Airflow should not be blocked by
placing foods on the sides of the
freezer compartment fan. A minimum
distance of 3 cm shall be provided on
the sides of protective fan cover.
 The baskets/drawers that are
provided with the chill compartment
must always be in use for low energy
consumption and for better storage
conditions.
 Since hot and humid air will not directly
penetrate into your product when the
doors are not opened, your product
will optimize itself in conditions
sufficient to protect your food. In this
energy saving function, functions and
components such as compressor, fan,
heater, defrost, lighting, display and so
on will operate according to the needs
to consume minimum energy while
4Preparation
maintaining the freshness of your
foodstuff.
 Food contact with the temperature
sensor in the freezer compartment may
increase energy consumption of the
appliance. Thus any contact with the
sensor(s) must be avoided.
 Depending on the features of your
product, thawing frozen food in fridge
compartment will both provide energy
saving and preserve the food quality.
 Do not allow contact of the food with
the fridge compartment temperature
sensor shown in the figure below.
4.2. Initial use
Before starting to use your refrigerator,
ensure that all preparations are made
in accordance with the instructions in
sections "Instructions for safety and
environment" and "Installation".
 Run the product without putting any
food for 6 hours and do not open its
door unless certainly required.
C
compressor starts up. The liquids
and gases sealed within the
refrigeration system may also
give rise to noise, even if the
compressor is not running and this
is quite normal.
CFront edges of the product may
feel warm. This is normal. These
areas are designed to be warm to
avoid condensation.
CIn some models, the instrument
panel automatically turns off
5 minutes after the door has
closed. It will be reactivated
when the door has opened or
pressed on any key.

13/39 EN
Refrigerator / User Manual
5Operating the product
5.1.Temperature
setting button
The interior temperature of your
refrigerator changes for the following
reasons;
Seasonal temperatures,
Frequent opening of the door and
leaving the door open for long periods,
Food put into the refrigerator
without cooling down to the room
temperature,
The location of the refrigerator in the
room (e.g. exposing to sunlight).

temperature due to such reasons by
using the setting button.
The numbers around the control knob
indicate the temperature values in “°C”.
If the ambient temperature is 25°C,
we recommend you to use the
temperature control knob of your
refrigerator at 4°C. This value may be
increased or decreased as required in
other ambient temperatures.
5.2.Fast freeze
If large amounts of fresh food are going
to be frozen, adjust the temperature
control knob to ( ) max. 24 hours
before putting the fresh food in the fast
freeze compartment.
It is strongly recommended to keep the
knob at this position at least 24 hours
to freeze maximum amount of fresh
food declared as freezing capacity. Take
special care not to mix frozen food and
fresh food.

Operating the product
14 / 39 EN Refrigerator / User Manual
Remember to turn the temperature
control knob back to its previous
position once food has frozen.
5.3.Vacation function
If the doors of the product are
not opened for 12 hours after the
temperature control knob is switched
to the hottest position, then the
vacation function will be activated
automatically.
To cancel the function, change the
knob setting.
It is not recommended to store food
in cooler compartment when the
vacation function is active.
When the setting operation is
completed, you may press the
temperature control knob and have
it hidden.

Operating the product
15/39EN
Refrigerator / User Manual
This indicator illuminated when a
sensor failure occurs, too. When
this indicator is illuminated, “E”
and figures such as “1,2,3...” are
displayed alternatively on the
temperature indicator. These figures
on the indicator inform the service
personnel about the error.
2. Energy saving function (display
off):
If the product doors are kept closed
for a long time energy saving
function is automatically activated
and energy saving symbol is
illuminated. ( )
When energy saving function is
activated, all symbols on the display
other than energy saving symbol will
turn off. When the Energy Saving
C*Optional: Figures in this user manual are schematic and may not match
the product exactly. If the subject parts are not included in the product you
have purchased, then those parts are valid for other models.
5.4. Indicator panel
Indicator panel allows you to set the temperature and control the other
functions related to the product without opening the door of the product. Just
press the inscriptions on relevant buttons for function settings.
1
3
45
6
789
11
2
*10
*12
1. Power Failure / High temperature
/ Error status indicator
This indicator ( ) illuminates in case of
power failure, high temperature and
error warnings.
When the temperature of the freezer
compartment is heated up to a
critical level for the frozen food, the
maximum value reached by the freezer
compartment temperature flashes on
the digital indicator.
Check the food in the freezer
compartment.
This is not a malfunction. The warning
may be deleted by pressing any
button or on high temperature alarm
off button. (Cancelling by pressing
any button is not applicable for every
model.)

Operating the product
16 / 39 EN Refrigerator / User Manual
function is activated, if any button is
pressed or the door is opened, energy
saving function will be canceled and
the symbols on display will return to
normal.
Energy saving function is activated
during delivery from factory and
cannot be canceled.
3.Quick fridge function
The button has two functions. To
activate or deactivate the quick cool
function press it briefly. Quick Cool
indicator will turn off and the product
will return to its normal settings.
( )
CUse quick cooling function
when you want to quickly cool
the food placed in the fridge
compartment. If you want to
cool large amounts of fresh
food, activate this function
before putting the food into
the product.
CIf you do not cancel it, quick
cooling will cancel itself
automatically after 8 hours or
when the fridge compartment
reaches to the required
temperature.
CIf you press the quick cooling
button repeatedly with short
intervals, the electronic circuit
protection will be activated
and the compressor will not
start up immediately.
CThis function is not recalled
when power restores after a
power failure.
4. Fridge compartment
temperature setting button
Press this button to set the
temperature of the fridge
compartment to 8, 7,6, 5,4,3, 2, 8...
respectively. Press this button to set
the fridge compartment temperature
to the desired value. ( )
5.Vacation Function
In order to activate vacation function,
press the this button ( ) for 3
seconds, and the vacation mode
indicator ( ) will be activated. When
the vacation function is activated,
“- -” is displayed on the fridge
compartment temperature indicator
and no active cooling is performed
on the fridge compartment. It is not
suitable to keep the food in the fridge
compartment when this function is
activated. Other compartments shall
be continued to be cooled as per their
set temperature.
To cancel this function press Vacation
function button again.
6. Termination of the High
Temperature Warning
In case of power failure/high
temperature warning, you may
delete the warning ( ) by pressing
any button on the indicator or high
temperature alarm off button for 1
second after checking the food inside
the freezer compartment.
Note: Cancelling by pressing any
button is not applicable for every
model.
7. Key lock
Press key lock button ( )
simultaneously for 3 seconds. Key
lock symbol ( ) will light up and key
lock mode will be activated. Buttons
will not function if the Key lock
mode is active. Press key lock button

Operating the product
17/39EN
Refrigerator / User Manual
simultaneously for 3 seconds again.
Key lock symbol will turn off and the
key lock mode will be exited.
Press the key lock button if you
want to prevent changing of
the temperature setting of the
refrigerator ( ).
8. Eco fuzzy
Press and hold eco fuzzy button
for 1 seconds to activate eco fuzzy
function. Refrigerator will start
operating in the most economic
mode at least 6 hours later and the
economic usage indicator will turn
on when the function is active (
). Press and hold eco fuzzy function
button for 3 seconds to deactivate
eco fuzzy function.
This indicator is illuminated after 6
hours when eco fuzzy is activated.
9. Freezer compartment
temperature setting button
Press this button to set the
temperature of the freezer
compartment to -18,-19,-20,-21,
-22, -23,-24, -18... respectively.
Press this button to set the freezer
compartment temperature to the
desired value.( )
10. Icematic off indicator
Indicates whether the icematic is on
or off. ( )If On, then the icematic
is not operating. To operate the
icematic again press and hold the On-
Off button for 3 seconds.
CWater flow from water tank
will stop when this function is
selected. However, ice made
previously can be taken from
the icematic.
11. Quick freeze function button/
icematic on-off button
Press this button to activate or
deactivate the quick freezing
function. When you activate the
function, the freezer compartment
will be cooled to a temperature lower
than the set value. ( )
To turn on and off the icematic press
and hold it for 3 seconds.
CUse the quick freeze function
when you want to quickly
freeze the food placed in fridge
compartment. If you want to
freeze large amounts of fresh
food, activate this function
before putting the food into
the product.
CIf you do not cancel it, Quick
Freeze will cancel itself
automatically after 4 hours or
when the fridge compartment
reaches to the required
temperature.
CThis function is not recalled
when power restores after a
power failure.
12. Economic usage indicator
Indicates that the product is running
in energy-efficient mode.This
indicator will be active if the Freezer
Compartment temperature is set to
-18 or the energy efficient cooling
is being performed due to Eco-Extra
function.
CEconomic usage indicator is
turned off when quick cooling
or quick freeze functions are
selected.

Operating the product
18 / 39 EN Refrigerator / User Manual
5.5.Indicator panel
Indicator panels may vary according to the product model.
Audio – visual functions on the indicator panel helps you in using your product.
45
76
*8
9
123
1. Fridge Compartment Indicator
2. Error status indicator
3. Temperature indicator
4. Vacation function button
5. Temperature setting button
6. Compartment selection button
7. Freezer compartment indicator
8. Economy mode indicator
9. Vacation function indicator
*optional
C*Optional: Figures in this user manual are schematic and may not match
the product exactly. If the subject parts are not included in the product you
have purchased, then those parts are valid for other models.

Operating the product
19/39EN
Refrigerator / User Manual
1. Fridge compartment indicator
Fridge compartment light is
illuminated while the fridge
compartment temperature is set.
2. Error status indicator
If your refrigerator does not perform
enough cooling or in case of a sensor
fault, this indicator is activated.
When this indicator is activated,
“E” is displayed on the freezer
compartment temperature indicator,
and numbers such as “1,2,3...” are
displayed on the fridge compartment
temperature indicator. These
numbers on the indicator inform
service personnel about the error.
3. Temperature indicator
Indicates freezer, fridge compartment
temperature.
4. Vacation function button
Press on Vacation Button for 3
seconds to activate this function.
When the vacation function is
activated, “- -” is displayed on the
fridge compartment temperature
indicator and no active cooling
is performed on the fridge
compartment. It is not suitable
to keep the food in the fridge
compartment when this function is
activated. Other compartments shall
be continued to be cooled as per their
set temperature.
To cancel this function press Vacation
button again.
5. Temperature setting button
Changes the temperature of the
relevant compartment between
-24°C... -18°C and 8°C...1°C.
6. Compartment selection button
Selection button: Press compartment
selection button to switch between
fridge and freezer compartments.
7. Freezer compartment indicator
Fridge compartment light is
illuminated while the freezer
compartment temperature is set.
8. Economy mode indicator
Indicates that the refrigerator
operates in energy saving mode.
This display shall be activated if the
freezer compartment temperature is
set to -18°C.
9. Vacation function indicator
Indicates that vacation is activated.
