Beko RDNE600K20DX User manual

DN170223DX -DN170123X-DN170223X-RDNE710E21ZP
RDNE600K20DX
EN/AR
57 4572 0000/AO -EN-AR
Refrigerator
User Manual


EN
1
Please read this user manual first!
Dear Customer,
We hope that your product, which has been produced in modern plants and checked
under the most meticulous quality control procedures, will provide you an effective service.
Therefore, read this entire user manual carefully before using the product and keep it as
a reference. If you handover the product to someone else, give the user manual as well.
The user manual will help you use the product in a fast and safe way.
 Read the manual before installing and operating the product.
 Make sure you read the safety instructions.
 Keep the manual in an easily accessible place as you may need it later.
 Read the other documents given with the product.
Remember that this user manual is also applicable for several other models. Differences
between models will be identified in the manual.
Explanation of symbols
Throughout this user manual the following symbols are used:
CImportant information or useful tips.
AWarning against dangerous conditions for life and property.
BWarning against electric voltage.
Warning Risk of fire/ flammable materials.

EN
2
1 Your Refrigerator 3
2 Safety and Environment
Instructions 4
General Safety...................................4
Intended Use.....................................6
Child Safety .......................................7
Compliance with WEEE Directive and
Disposing of the Waste Product.........7
Compliance with RoHS Directive .......7
Package Information..........................7
Recommendations for the fresh food
compartment.....................................8
3 Installation 9
Points to be paid attention to when the
relocation of the refrigerator ...............9
Electrical connection..........................9
Disposing of the packaging .............10
Disposing of your old refrigerator .....10
Placing and Installation ....................10
Adjusting the legs ............................11
Changing the illumination lamp .......11
Door Open Warning.........................11
4 Preparation 12
5 Using your refrigerator 13
Indicator Panel.................................13
Temperature setting button..............24
Setting the temperature of your
refrigerator.......................................24
Dual cooling system ........................24
Recommendations for preservation of
frozen food ......................................25
Defrosting........................................25
Placing the food ..............................26
Deep-freeze information ..................26
Egg section .....................................26
Description and cleaning of odor
filter ................................................27
Water Dispenser ..............................28
Blue light .........................................30
Sliding storage container .................30
Rotary storage container .................31
Auto Icematic .................................32
Icematic and ice storage container ..33
Making ice.......................................34
Humidity-controlled crisper (Ever
Fresh) ..............................................34
Ice-cream machine..........................35
6 Maintenance and
cleaning 37
Protection of plastic surfaces ..........37
7 Troubleshooting 38

EN
3
1Your Refrigerator
1. Door shelves of the freezer compartment
2. Temp e r a ture sett i n g i ndic a t o r
3. Egg section
4. Water dispenser filling tank
5. Water dispenser reservoir
6. Door shelves of fridge compartment
7. Sliding and rotary storage containers
8. Blue light
9. Adjustable legs
10. Crisper
11. Crisper cover
12. Breakfast compartment
13. Key
14. Bottle shelf
C*optional:Figures in this user manual are schematic and may not correspond exactly to
you product. If the subject parts are not included in the product you have purchased, then it
is valid for other models.
15. Odor filter
16. Glass shelves of fridge compartment
17. Illumination glass
18. Impeller
19. Automatic Icematic water tank
20. Icebox
21. Ice storage container
22. Freezer compartment glass shelf
23. Ice-cream making machine / Quick Freeze
compartment
24. Freezer compartment
25. Fridge compartment
*optional
1
4*
3
17
*16
18
2*
16
5*
*6
*6
*6
*8
*7
9
*10
*12
11
*14
*13
*13
*15
*19
*20
*21
*23
22
24
25
*

EN
4
2Safety and Environment Instructions
This section provides the
safety instructions necessary
to prevent the risk of injury and
material damage. Failure to
observe these instructions will
invalidate all types of product
warranty.
Intended use
A
WARNING:
Keep ventilation
openings, in the
appliance enclosure or
in the built-instructure,
clear of obstruction.
A
WARNING:
Do not use mechanical
devices or other
means to accelerate
the defrostingprocess,
other than those
recommended by the
manufacturer.
AWARNING:
Do not damage the
refrigerant circuit.
A
WARNING:
Do not use electrical
appliances inside
the food storage
compartments of the
appliance, unless
they are of the type
recommended by the
manufacturer.
A
WARNING:
Do not store explosive
substances such as
aerosol cans with a
flammable propellant in
this appliance.
This appliance is intended to be
used in household and similar
applications such as
– staff kitchen areas in shops,
offices and other working
environments;
– farm houses and by clients
in hotels, motels and other
residential type environments;
– bed and breakfast type
environments;
– catering and similar non-retail
applications.
General Safety
 This product should not be used by
persons with physical, sensory and mental
disabilities, without sufficient knowledge
and experience or by children. The device
can only be used by such persons under
supervision and instruction of a person
responsible for their safety. Children should
not be allowed to play with this device.
 In case of malfunction, unplug the device.
 After unplugging, wait at least 5 minutes
before plugging in again.
 Unplug the product when not in use.
 Do not touch the plug with wet hands! Do
not pull the cable to plug off, always hold
the plug.

EN
5
 Do not plug in the refrigerator if the socket
is loose.
 Unplug the product during installation,
maintenance, cleaning and repair.
 If the product will not be used for a while,
unplug the product and remove any food
inside.
 Do not use the product when the
compartment with circuit cards located
on the upper back part of the product
(electrical card box cover) (1) is open.
1
1
 Do not use steam or steamed cleaning
materials for cleaning the refrigerator and
melting the ice inside. Steam may contact
the electrified areas and cause short circuit
or electric shock!
 Do not wash the product by spraying or
pouring water on it! Danger of electric
shock!
 In case of malfunction, do not use the
product, as it may cause electric shock.
Contact the authorized service before
doing anything.
 Plug the product into an earthed socket.
Earthing must be done by a qualified
electrician.
 If the product has LED type lighting,
contact the authorized service for
replacing or in case of any problem.
 Do not touch frozen food with wet hands!
It may adhere to your hands!
 Do not place liquids in bottles and cans
into the freezer compartment. They may
burst out!
 Place liquids in upright position after tightly
closing the lid.
 Do not spray flammable substances near
the product, as it may burn or explode.
 Do not keep flammable materials and
products with flammable gas (sprays, etc.)
in the refrigerator.
 Do not place containers holding liquids on
top of the product. Splashing water on an
electrified part may cause electric shock
and risk of fire.
 Exposing the product to rain, snow,
sunlight and wind will cause electrical
danger. When relocating the product, do
not pull by holding the door handle. The
handle may come off.
 Take care to avoid trapping any part of
your hands or body in any of the moving
parts inside the product.
 Do not step or lean on the door, drawers
and similar parts of the refrigerator. This
will cause the product to fall down and
cause damage to the parts.
 Take care not to trap the power cable.
 In-corporated ice-makers installed only by
the manufacturer or its service agent.

EN
6
 Appliances desinged for incorporating ice-
makers, the types of ice-makers.
 For ice-makers not intended to be
connected to the water supply.
 When positioning the appliance, ensure
the supply cord is not trapped or
damaged.
 Do not locate multiple portable socket-
outlets or portable power supplies at the
rear of the appliance.
 To avoid contamination of food, please
respect the following instructions:
 – Opening the door for long periods
can cause a significant increase of the
temperature in the compartments of the
appliance.
 – Clean regularly surfaces that can come
in contact with food and accessible
drainage systems.
 – Clean water tanks if they have not been
used for 48 h; flush the water system
connected to a water supply if water has
not been drawn for 5 days.
 – Store raw meat and fish in suitable
containers in the refrigerator, so that it is
not in contact with or drip onto other food.
 – Two-star frozen-food compartments
are suitable for storing pre-frozen food,
storing or making icecream and making
ice cubes.
 – One-, two- and three-star
compartments are not suitable for the
freezing of fresh food.
 – If the refrigerating appliance is left empty
for long periods, switch off, defrost, clean,
dry, and leave the door open to prevent
mould developing within the appliance.
1.1.1 HC Warning
If the product comprises a
cooling system using R600a
gas, take care to avoid
damaging the cooling system
and its pipe while using and
moving the product. This gas is
flammable. If the cooling system
is damaged, keep the product
away from sources of fire and
ventilate the room immediately.
C
The label on the inner left side
indicates the type of gas used in
the product.
1.1.2 For Models with
Water Dispenser
 Pressure for cold water inlet shall be
maximum 90 psi (6.2 bar). If your water
pressure exceeds 80 psi (5.5 bar), use
a pressure limiting valve in your mains
system. If you do not know how to check
your water pressure, ask for the help of a
professional plumber.
 If there is risk of water hammer effect
in your installation, always use a water
hammer prevention equipment in your
installation. Consult Professional plumbers
if you are not sure that there is no water
hammer effect in your installation.
 Do not install on the hot water inlet. Take
precautions against of the risk of freezing
of the hoses. Water temperature operating
interval shall be 33°F (0.6°C) minimum and
100°F (38°C) maximum.
 Use drinking water only.
Intended Use
 This product is designed for home use. It
is not intended for commercial use.

EN
7
 The product should be used to store food
and beverages only.
 Do not keep sensitive products requiring
controlled temperatures (vaccines, heat
sensitive medication, medical supplies,
etc.) in the refrigerator.
 The manufacturer assumes no
responsibility for any damage due to
misuse or mishandling.
 Original spare parts will be provided for 10
years, following the product purchasing
date.
Child Safety
 Keep packaging materials out of children’s
reach.
 Do not allow the children to play with the
product.
 If the product’s door comprises a lock,
keep the key out of children’s reach.
Compliance with WEEE
Directive and Disposing of
the Waste Product
This product complies with EU WEEE
Directive (2012/19/EU). This product bears a
classification symbol for waste electrical and
electronic equipment (WEEE).
This product has been
manufactured with high quality
parts and materials which can be
reused and are suitable for
recycling. Do not dispose of the
waste product with normal
domestic and other wastes at the
end of its service life. Take it to the
collection center for the recycling of electrical
and electronic equipment. Please consult your
local authorities to learn about these collection
centers.
Compliance with RoHS
Directive
 This product complies with EU
WEEE Directive (2011/65/EU). It
does not contain harmful and pro-
hibited materials specified in the
Directive.
Package Information
Packaging materials of the product are
manufactured from recyclable materials in
accordance with our National Environment
Regulations. Do not dispose of the packaging
materials together with the domestic or other
wastes. Take them to the packaging material
collection points designated by the local
authorities.

EN
8
Recommendations for the
fresh food compartment
*May not be available in all models
Do not allow the food to touch the
temperature sensor in fresh food
compartment. To allow the fresh food
compartment keep its ideal storage
temperature, sensor must not be hindered
by food.
Do not place hot foods in the product.

EN
9
3Installation
BIn case the information which are given
in the user manual are not taken into
account, manufacturer will not assume
any liability for this.
Points to be paid attention
to when the relocation of the
refrigerator
1. Your refrigerator should be
unplugged.Before transportation of your
refrigerator, it should be emptied and
cleaned.
2. Before it is re-packaged, shelves,
accessories, crisper, etc. inside your
refrigerator should be fixed with adhesive
tape and secured against impacts.
Package should be bound with a thick
tape or sound ropes and the transportation
rules on the package should be strictly
observed.
3. Original packaging and foam
materials should be kept for future
transportations or moving.
Before you start the refrigerator,
Check the following before you start to
use your refrigerator:
1. Attach 2 plastic wedges as
illustrated below. Plastic wedges are
intended to keep the distance which will
ensure the air circulation between your
refrigerator and the wall. (The picture is
drawn up as a representation and it is not
identical with your product.)
2. Clean the interior of the refrigerator
as recommended in the “Maintenance and
cleaning” section.
3. Connect the plug of the refrigerator
to the wall socket. When the fridge door is
opened, fridge internal lamp will turn on.
4. When the compressor starts to
operate, a sound will be heard. The liquid
and gases sealed within the refrigeration
system may also give rise to noise, even if
the compressor is not running and this is
quite normal.
5. Front edges of the refrigerator
may feel warm. This is normal. These
areas are designed to be warm to avoid
condensation.
Electrical connection
Connect your product to a grounded
socket which is being protected by a fuse
with the appropriate capacity.
Important:
The connection must be in compliance
with national regulations.
 The power plug must be easily accessible
after installation.
 Electrical safety of your refrigerator shall be
guaranteed only if the earth system in your
house complies with standards.
 The voltage stated on the label located at
left inner side of your product should be
equal to your network voltage.

EN
10
 Extension cables and multi plugs must not
be used for connection.
BA damaged power cable must be
replaced by a qualified electrician.
BProduct must not be operated before it is
repaired! There is the risk of electric shock!
Disposing of the packaging
The packing materials may be dangerous
for children. Keep the packing materials out
of the reach of children or dispose of them
by classifying them in accordance with
the waste instructions stated by your local
authorities. Do not throw away with regular
house waste, throw away on packaging
pick up spots designated by the local
authorities.
The packing of your refrigerator is
produced from recyclable materials.
Disposing of your old
refrigerator
Dispose of your old refrigerator without
giving any harm to the environment.
 You may cons ult your authorized dealer
or waste collection center of your
municipality about the disposal of your
refrigerator.
Before disposing of your refrigerator, cut
out the electric plug and, if there are any
locks on the door, make them inoperable in
order to protect children against any danger.
Placing and Installation
AIf the entrance door of the room where
the refrigerator will be installed is not wide
enough for the refrigerator to pass through,
then call the authorized service to have
them remove the doors of your refrigerator
and pass it sideways through the door.
1. Install your refrigerator to a place
that allows ease of use.
2. Keep your refrigerator away from
heat sources, humid places and direct
sunlight.
3. There must be appropriate air
ventilation around your refrigerator in
order to achieve an efficient operation. If
the refrigerator is to be placed in a recess
in the wall, there must be at least 5 cm
distance with the ceiling and at least 5 cm
with the wall. Do not place your product on
the materials such as rug or carpet.
4. Place your refrigerator on an even
floor surface to prevent jolts.

EN
11
Adjusting the legs
If your refrigerator is unbalanced;
You can balance your refrigerator by
turning its front legs as illustrated in the
figure. The corner where the leg exists is
lowered when you turn in the direction of
black arrow and raised when you turn in
the opposite direction. Taking help from
someone to slightly lift the refrigerator will
facilitate this process.
Changing the illumination
lamp
To change the Bulb/LED used for
illumination of your refrigerator, call your
AuthorisedService.
The lamp(s) used in this appliance is not
suitable for household room illumination.
The intended purpose of this lamp is to
assist the user to place foodstuffs in the
refrigerator/freezer in a safe and comfortable
way.The lamps used in this appliance have
to withstand extreme physical conditions
such as temperatures below -20 °C.
(only chest and upright freezer)
Door Open Warning
*May not be available in all models
An audio warning signal will be given when
the door of your product is left open for at
least 1 minute. This warning will be muted
when the door is closed or any of the display
buttons (if any) are pressed.

EN
12
4Preparation
 Your cooler/freezer should be installed at
least 30 cm away from heat sources such
as hobs, ovens, central heater and stoves
and at least 5 cm away from electrical
ovens and should not be located under
direct sunlight.
 Please make sure that the interior of your
cooler/freezer is cleaned thoroughly.
 If two coolers are to be installed side
by side, there should be at least 2 cm
distance between them.
 When you operate your cooler/freezer for
the first time, please observe the following
instructions during the initial six hours.
 Its door should not be opened frequently.
 It must be operated empty without placing
any food in it.
 Do not unplug your cooler/freezer.
If a power failure occurs out of your
control, please see the warnings in
the “Recommended solutions for the
problems” section.
 The baskets/drawers that are provided
with the chill compartment must always
be in use for low energy consumption and
for better storage conditions.
 Food contact with the temperature sensor
in the freezer compartment may increase
energy consumption of the appliance.
Thus any contact with the sensor(s) must
be avoided.
 This product has been designed to
function at ambient temperatures up to
43 °C (90 SDgrF). Even if the ambient
temperature falls to -15 °C, frozen food
in the freezer does not thaw thanks to its
Advanced Electronic Temperature Control
System. For the first installation, the
product should NOT be placed under low
ambient temperatures. This is because
the freezer cannot go down to standard
operation temperature. When reaching
continuous operation, the product can be
moved to another place. Thus, later you
can place your product in the garage or
an unheated room without the concern
of causing frozen food to get rotten.
However, it is likely that above mentioned
low temperatures may cause the freezing
of the food in the fridge compartment;
thus, please consume the food items in
the fridge in a controlled way as needed.
When ambient temperature goes back to
normal, you may change button setting
according to your need.
 If the ambient temperature is below 0°C,
the food in fridge compartment will freeze.
Therefore, we recommend not using the
fridge compartment in such low ambient
temperatures. You may continue to use
the freezer compartment as usual.
 In some models, the instrument panel
automatically turns off 5 minutes after
the door has closed. It will be reactivated
when the door has opened or pressed on
any key.
 Due to temperature change as a result of
opening/closing the product door during
operation, condensation on the door/
body shelves and the glass containers is
normal.

EN
13
Indicator Panel
Indicator panels may vary depending on your product's model.
The Indicator panel aids in using your refrigerator with its audio and visual functions.
(in some models)
5Using your refrigerator
1 7 3
45*62
1. Freezer Compartment Temperature
Setting Indicator
2. Freezer Compartment Temperature
Setting Button
3. Fridge Compartment Temperature
Setting Indicator
4. Fridge Compartment Temperature
Setting Button
5. Economy Mode Indicator
6. Ionizer Indicator
7. Error Status Indicator
*optional
CFigures in this user manual are schematic and may not correspond exactly to you
product. If the subject parts are not included in the product you have purchased, then
it is valid for other models.

EN
14
1. Freezer Compartment Temperature
Setting Indicator
Indicates the temperature set for freezer
compartment.
2. Freezer Compartment Temperature
Setting Button
Press this button to set the temperature of
the freezer compartment to -18, -20, -22,
-24, -18... respectively. Press this button to
set the desired temperature for the freezer
compartment.
3. Fridge Compartment Temperature
Setting Indicator
Indicates the temperature set for Fridge
compartment.
4. Fridge Compartment Temperature
Setting Button
Press this button to set the temperature
of the fridge compartment to 8, 6, 4, 2,
8... respectively. Press this button to set
the desired temperature for the fridge
compartment.
5. Economy Mode Indicator
Indicates that the refrigerator is running in
energy-efficient mode.
6- Ionizer Indicator
Indicator light lights up continuously.
This light indicates that your refrigerator is
protected against the bacteria.
7. Error Status Indicator
If your refrigerator does not cool
adequately or if there is a sensor failure,
this indicator will be activated. When this
indicator is active, Freezer Compartment
Temperature indicator will display "e" and
Fridge Compartment Temperature Indicator
will display numbers such as "1,2,3…".
These numbers on the indicator provide
information about the error to the service
personnel.

EN
15
Indicator panels may vary depending on the model of your product.
Audial and visual functions of the indicator panel will assist in using the product.
45
76
*8
9
123
1. Cooler compartment indicator
2. Error status indicator
3. Temp e r a ture indi c a t or
4. Vacation function button
5. Temp e r a ture adju s t m ent bu t t o n
6. Compartment selection button
7. Cooler compartment indicator
8. Economy mode indicator
9. Vacation function indicator
*optional
CFigures in this user manual are schematic and may not correspond exactly to you
product. If the subject parts are not included in the product you have purchased, then
it is valid for other models.

EN
16
1. Cooler compartment indicator
The freezer compartment light will turn on
when adjusting the cooler compartment
temperature.
2. Error status indicator
This sensor will activate if the refrigerator is
not cooling adequately or in case of sensor
fault. When this indicator is active, the
freezer compartment temperature indicator
will display "E" and the cooler compartment
temperature indicator will display "1, 2, 3..."
etc. numbers.
The numbers on the indicator serve to
inform the service personnel about the fault.
( )
3. Temperature indicator
Indicates the temperature of the freezer
and cooler compartments.
4.Vacation function button
To activate this function, press and hold
the Vacation button for 3 seconds. When
the Vacation function is active, the cooler
compartment temperature indicator displays
the inscription "- -" and no cooling process
will be active in the cooling compartment.
This function is not suitable to keep
food in the cooler compartment. Other
compartments will remain cooled with
the respective temperature set for each
compartment.
Push the vacation function button again to
cancel this function. ( )
5. Temperature adjustment button
Respective compartment's temperature
varies in -24°C..... -18°C and 8°C...1°C
ranges.( )
6. Compartment selection button
Use the refrigerator compartment selection
button to toggle between the cooler and
freezer compartments.( )
7. Cooler compartment indicator
The cooler compartment light will turn on
when adjusting the cooler compartment
temperature.
8. Economy mode indicator
Indicates the refrigerator is running on
energy-saving mode. This indicator will be
active when the temperature in the freezer
compartment is set to -18°C. ( )
9.Vacation function indicator
Indicates the vacation function is active.(
)

EN
17
1. Freezer Compartment Temperature
Setting Button
2. Fridge Compartment Temperature Setting
Button
3. Error Status Indicator
4. Key Lock indicator
5. Eco Extra Function Indicator
6. Eco Extra / Vacation Button
7. Vacation Function Indicator
8. Energy saving function (display off)
9. Icematic Off Indicator (*in some models)
10. Economic Usage Indicator
11. Quick Fridge Function Indicator
12. Quick Fridge Function Button
13. Fridge Compartment Temperature Setting
Indicator
14. Quick Freeze Function Button Icematic
On-Off Button (3")
15. Freezer Compartment Temperature
Setting Indicator
16. Quick Freeze Function Indicator
CFigures in this user manual are schematic and may not correspond exactly to you product. If
the subject parts are not included in the product you have purchased, then it is valid for other
models.
*optional
15
14
1
2
3
4
5
13
12
11
10
9
8*
*
7
6

EN
18
1. Freezer Compartment Temperature
Setting Button
This function allows you to set the
temperature of freezer compartment. Press
this button to set the temperature of the
freezer compartment to -18, -19, -20, -21
-22, -23 and -24, respectively.
2. Fridge Compartment Temperature
Setting Button
function allows you to set the fridge
compartment’s temperature. Press this
button to set the temperature of the fridge
compartment to 8, 7, 6, 5, 4, 3, 2 degrees,
respectively.
3. Error Status Indicator
If your refrigerator does not cool
adequately or if there is a sensor failure,
this indicator will be activated. When this
indicator is active, Freezer Compartment
Temperature indicator will display "E" and
Fridge Compartment Temperature Indicator
will display numbers such as "1,2,3…".
These numbers on the indicator provide
information about the error to the service
personnel.
When you place hot food into the freezer
compartment or if you leave the door open
for a long time, exclamation mark can
illuminate for some time. This is not a failure;
this warning will disappear when the food
cools down.
4. Key Lock Indicator
Use this function if you do not want your
refrigerator temperature setting changed.
Press Fridge compartment temperature
setting button and Freezer compartment
temperature setting button simultaneously
for a long time (3 sec) to activate this
function.
5. Eco Extra Function Indicator
It indicates that the Eco-Extra function is
active.
If this function is active, your refrigerator
will automatically detect the least usage
periods and energy-efficient cooling will be
performed during those times. Economy
indicator will be active while energy-efficient
cooling is performed.
Press the relevant button again to
deactivate this function.
6. Eco Extra/Vacation Button
Press this button briefly to activate the Eco
Extra function. Press and hold this button
for 3 sec. to activate the Vacation function.
Press this button again to deactivate the
selected function.
7. Vacation Function Indicator
Indicates that the vacation function is
active. If this function is active, "- -" appears
on the indicator of the fridge compartment
and no cooling is performed in the fridge
compartment. Other compartments will
continue to be cooled in accordance with
the temperature set for them.
Press the relevant button again to
deactivate this function.
8. Energy saving function (display off)
If the product doors are kept closed
for a long time energy saving function is
automatically activated and energy saving
symbol is illuminated.When energy saving
function is activated, all symbols on the
display other than energy saving symbol will
turn off. When the Energy Saving function
is activated, if any button is pressed or the
door is opened, energy saving function will
be canceled and the symbols on display will
return to normal.
Energy saving function is activated
during delivery from factory and cannot be
canceled.
9. Icematic Off Indicator
Icematic will not run when the indicator of
this function is active.
To activate the ice off function, you need
to press and hold the quick freeze button
for 3 seconds.
10. Economic Usage Indicator
Indicates that the refrigerator is running
in energy-efficient mode. This indicator
will be active if the Freezer Compartment
temperature is set to -18 or the energy
efficient cooling is being performed due to
Eco-Extra function.

EN
19
11. Quick Fridge Function Indicator
This symbol flashes in an animated style
when the Quick Fridge function is active.
12. Quick Fridge Function Button
When you press the Quick Fridge button,
the temperature of the compartment will be
colder than the adjusted values.
This function can be used for food placed
in the fridge compartment and required to
be cooled down rapidly.
If you want to cool large amounts of fresh
food, it is recommended to activate this
feature before putting the food into the
fridge.
Quick Fridge indicator turns on when the
Quick Fridge function is on. To cancel this
function, press Quick Fridge button again.
If you do not cancel it, Quick Fridge will
cancel itself automatically after 4 hours or
when the fridge compartment reaches to
the required temperature.
This function is not recalled when power
restores after a power failure.
13. Fridge Compartment Temperature
Setting Indicator
Indicates the temperature set for the
Fridge Compartment.
14. Quick Freeze Function Button
Icematic On-Off Button (3")
Indicates the temperature set for the
Freezer Compartment.
To stop ice formation, press Icematic on-
off button for 3 seconds. Water flow from
water tank will stop when this function is
selected. However, ice made previously can
be taken from the Icematic. To restart ice
formation, press Icematic on-off button for
3 seconds.
15. Freezer Compartment Temperature
Setting Indicator
Fast Freeze indicator turns on when the
Fast Freeze function is active. To cancel
this function, press Fast Freeze button
again. Quick Freeze indicator will turn off
and return to its normal settings. If you
do not cancel it, Fast Freeze will cancel
itself automatically after 8 hours or when
the freezer compartment reaches to the
required temperature.
If you want to freeze large amounts of
fresh food, press the Fast Freeze button
before putting the food into the freezer
compartment.
If you press the Fast Freeze button
repeatedly with short intervals, the electronic
circuit protection will be activated and the
compressor will not start up immediately.
This function is not recalled when power
restores after a power failure.
16. Quick Freeze Function Indicator
This symbol flashes in an animated style
when the Fast Freeze function is active.
