Refrigerator
User Manual


Please read this manual first!
Dear Customer,
We hope that your product, which has been produced in modern plants and checked
under the most meticulous quality control procedures, will provide you an effective service.
For this, we recommend you to carefully read the entire manual of your product before
using it and keep it at hand for future references.
This manual
• Will help you use your appliance in a fast and safe way.
• Read the manual before installing and operating your product.
• Follow the instructions, especially those for safety.
• Keep the manual in an easily accessible place as you may need it later.
• Besides, read also the other documents provided with your product.
Please note that this manual may be valid for other models as well.
Symbols and their descriptions
This instruction manual contains the following symbols:
CImportant information or useful usage tips.
A Warning against dangerous conditions for life and property.
B Warning against electric voltage.

EN
2
CONTENTS
1 The refrigerator 3
2 Important Safety
Warnings 4
Intended use .....................................4
General safety ..................................4
For products with a ..........................7
water dispenser;................................7
Child safety........................................7
Compliance with WEEE Directive and
Disposing of the Waste Product: .......7
Package information..........................7
HC warning .......................................8
Things to be done for energy saving ..8
Reccomendations for freshfood
compartment.....................................8
3 Installation 9
Points to be considered when re-
transporting your refrigerator .............9
Before operating your refrigerator ......9
Changing the illumination lamp .........9
Adjusting the legs ............................10
Electric connection ..........................10
Disposing of the packaging .............10
Disposing of your old refrigerator .....10
Placing and Installation ....................10
4 Preparation 11
5 Using your refrigerator 12
Indicator Panel.................................12
Door Open Warning.........................15
Freezing fresh food ..........................16
Recommendations for preservation of
frozen food ......................................17
Placing the food ..............................17
Deep-freeze information ..................18
Moisture controlled vegetable bin ...18
Description and cleaning of odor
filter: ................................................19
Egg holder.......................................19
Water Dispenser ..............................20
Rotary storage container .................22
Blue light .........................................23
Auto Icematic .................................23
Icematic and ice storage container ..24
6 Maintenance and
cleaning 25
Protection of plastic surfaces ..........25
7.
Troubleshooting 26

EN
3
1The refrigerator
1. Freezer compartment shelf
2. Auto Icematic
3. Ice storage container
4. Auto Icematic water tank
5. Temperature setting indicator
6. Adjustable glass shelves
7. Odor filter
8. Illumination lens
9. Bottle shelf
10. Chiller Compartment
11. Crisper cover
12. Crisper
C Figures that take place in this instruction manual are schematic and may not correspond
exactly with your product. If the subject parts are not included in the product you have
purchased, then it is valid for other models.
1
3*
5*
4*
6
9*
7
8
*10
12
11
13
14
16*
15
17*
18
*19
*20
*20
21
22
2*
13. Adjustable legs
14. Freezer compartment door racks
15. Egg holder
16. Water dispenser filling container
17. Water dispenser tank
18. Fridge compartment door shelves
19. Sliding and rotary storage containers
20. Key
21. Freezer compartment
22. Fridge compartment
*OPTIONAL

EN
4
2Important Safety Warnings
Please review the following
information. Failure to observe
this information may cause
injuries or material damage.
Otherwise, all warranty and
reliability commitments will
become invalid.
Original spare parts will be
provided for 10 years, following
the product purchasing date.
Intended use
This product is intended to be
used
• indoors and in closed areas
such as homes;
• in closed working environments
such as stores and offices;
• in closed accommodation
areas such as farm houses,
hotels, pensions.
• It should not be used outdoors.
General safety
• When you want to dispose/
scrap the product, we
recommend you to consult the
authorized service in order to
learn the required information
and authorized bodies.
• Consult your authorized
service for all your questions
and problems related to the
refrigerator. Do not intervene or
let someone intervene to the
refrigerator without notifying the
authorised services.
• For products with a freezer
compartment; Do not eat
cone ice cream and ice cubes
immediately after you take them
out of the freezer compartment!
(This may cause frostbite in
your mouth.)
• For products with a freezer
compartment; Do not put
bottled and canned liquid
beverages in the freezer
compartment. Otherwise, these
may burst.
• Do not touch frozen food by
hand; they may stick to your
hand.
• Unplug your refrigerator before
cleaning or defrosting.
• Vapor and vaporized cleaning
materials should never be
used in cleaning and defrosting
processes of your refrigerator.
In such cases, the vapor may
get in contact with the electrical
parts and cause short circuit or
electric shock.
• Never use the parts on your
refrigerator such as the door as
a means of support or step.
• Do not use electrical devices
inside the refrigerator.
• Do not damage the parts,
where the refrigerant is
circulating, with drilling or
cutting tools. The refrigerant
that might blow out when the
gas channels of the evaporator,
pipe extensions or surface
coatings are punctured causes
skin irritations and eye injuries.
• Do not cover or block the
ventilation holes on your
refrigerator with any material.

EN
5
• Electrical devices must be
repaired by only authorised
persons. Repairs performed by
incompetent persons create a risk
for the user.
• In case of any failure or during
a maintenance or repair work,
disconnect your refrigerator’s
mains supply by either turning off
the relevant fuse or unplugging
your appliance.
• Do not pull by the cable when
pulling off the plug.
• Ensure highly alcoholic beverages
are stored securely with the lid
fastened and placed upright.
• Never store spray cans containing
flammable and explosive
substances in the refrigerator.
• Do not use mechanical devices
or other means to accelerate the
defrosting process, other than
those recommended by the
manufacturer.
• This product is not intended to be
used by persons with physical,
sensory or mental disorders
or unlearned or inexperienced
people (including children) unless
they are attended by a person
who will be responsible for their
safety or who will instruct them
accordingly for use of the product
• Do not operate a damaged
refrigerator. Consult with the
service agent if you have any
concerns.
• Electrical safety of your refrigerator
shall be guaranteed only if the
earth system in your house
complies with standards.
• Exposing the product to
rain, snow, sun and wind is
dangerous with respect to
electrical safety.
• Contact authorized service when
there is a power cable damage
to avoid danger.
• Never plug the refrigerator into
the wall outlet during installation.
Otherwise, risk of death or
serious injury may arise.
• This refrigerator is intended
for only storing food items. It
must not be used for any other
purpose.
• Label of technical specifications
is located on the left wall inside
the refrigerator.
• Never connect your refrigerator
to electricity-saving systems;
they may damage the
refrigerator.
• If there is a blue light on the
refrigerator, do not look at the
blue light with optical tools.
• For manually controlled
refrigerators, wait for at least 5
minutes to start the refrigerator
after power failure.
• This operation manual should be
handed in to the new owner of
the product when it is given to
others.
• Avoid causing damage on
power cable when transporting
the refrigerator. Bending cable
may cause fire. Never place
heavy objects on power cable.
Do not touch the plug with
wet hands when plugging the
product

EN
6
• In-corporated ice-makers
installed only by the
manufacturer or its service
agent.
• Appliances desinged for
incorporating ice-makers, the
types of ice-makers.
• For ice-makers not intended
to be connected to the water
supply.
• Do not plug the refrigerator if
the wall outlet is loose.
• Water should not be sprayed
on inner or outer parts of the
product for safety purposes.
• Do not spray substances
containing inflammable gases
such as propane gas near the
refrigerator to avoid fire and
explosion risk.
• Never place containers filled
with water on top of the
refrigerator; in the event of
spillages, this may cause
electric shock or fire.
• Do not overload the refrigerator
with food. If overloaded, the
food items may fall down
and hurt you and damage
refrigerator when you open the
door.
• Never place objects on top
of the refrigerator; otherwise,
these objects may fall down
when you open or close the
refrigerator’s door.
• As they require a precise
temperature, vaccines, heat-
sensitive medicine and scientific
materials and etc. should not be
kept in the refrigerator.
• If not to be used for a long
time, refrigerator should be
unplugged. A possible problem
in power cable may cause fire.
• The plug’s tip should be cleaned
regularly with a dry cloth;
otherwise, it may cause fire.
• Refrigerator may move if
adjustable legs are not properly
secured on the floor. Properly
securing adjustable legs on the
floor can prevent the refrigerator
to move.
• When carrying the refrigerator,
do not hold it from door handle.
Otherwise, it may be snapped.
• When you have to place
your product next to another
refrigerator or freezer, the
distance between devices
should be at least 8cm.
Otherwise, adjacent side walls
may be humidified.
• The product shall never be used
while the compartment which
is located at the top or back
of your product and in which
electronic boards are available
(electronic board box cover) (1) is
open.

EN
7
1
1
For products with a
water dispenser;
• Pressure for cold water inlet shall
be maximum 90 psi (6.2 bar).
If your water pressure exceeds
80 psi (5.5 bar), use a pressure
limiting valve in your mains
system. If you do not know how
to check your water pressure,
ask for the help of a professional
plumber.
• If there is risk of water hammer
effect in your installation,
always use a water hammer
prevention equipment in
your installation. Consult
Professional plumbers is you
are not sure that there is no
water hammer effect in your
installation.
• Do not install on the hot water
inlet. Take precautions against
of the risk of freezing of the
hoses. Water temperature
operating interval shall be 33°F
(0.6°C) minimum and 100°F
(38°C) maximum.
• Use only potable water.
Child safety
• If the door has a lock, the key
should be kept away from reach
of children.
• Children must be supervised to
prevent them from tampering
with the product.
Compliance with WEEE
Directive and Disposing of the
Waste Product:
This product complies with EU
WEEE Directive (2012/19/EU).
This product bears a classification
symbol for waste electrical and
electronic equipment (WEEE).
This product has been
manufactured with high quality
parts and materials which can be reused and
are suitable for recycling. Therefore, do not
dispose the product with normal domestic
waste at the end of its service life. Take it to
a collection point for the recycling of electrical
and electronic equipment. Please consult your
local authorities to learn the nearest collection
point. Help protect the environment and
natural resources by recycling used products.
For children’s safety, cut the power cable and
break the locking mechanism of the door, if
any, so that it will be non-functional before
disposing of the product.
Package information
Packaging materials of the product are
manufactured from recyclable materials in
accordance with our National Environment
Regulations. Do not dispose of the packaging
materials together with the domestic or other
wastes. Take them to the packaging material
collection points designated by the local
authorities.
Do not forget...

EN
8
Reccomendations for
freshfood compartment

• Please do not let any foodstuff to come
to contact with the temperature sensor in
freshfood compartment.In order to maintain
freshfood compartment at ideal storage
temperature, the sensor must not be
blocked by fodstuffs.
• Do not place hot foodstuff in your
appliance.
temperature
sensor
oo
MILK
juice
etc.
temperature
sensor
temperature
sensor
oo
MILK
juice
etc.
temperature
sensor
Any recycled substance is an indispensable
matter for nature and our national asset
wealth.
If you want to contribute to the re-
evaluation of the packaging materials,
you can consult to your environmentalist
organizations or the municipalities where
you are located.
HC warning
If your product's cooling system
contains R600a:
This gas is flammable. Therefore, pay
attention to not damaging the cooling
system and piping during usage and
transportation. In the event of damage,
keep your product away from potential fire
sources that can cause the product catch a
fire and ventilate the room in which the unit
is placed.
Ignore this warning if your product's
cooling system contains R134a.
Type of gas used in the product is stated in
the type label which is on the left wall inside
the refrigerator.
Never throw the product in fire for disposal.
Things to be done for energy
saving
• Do not leave the doors of your refrigerator
open for a long time.
• Do not put hot food or drinks in your
refrigerator.
• Do not overload your refrigerator so
that the air circulation inside of it is not
prevented.
• Do not install your refrigerator under direct
sunlight or near heat emitting appliances
such as ovens, dishwashers or radiators.
Keep your refrigerator at least 30cm away
from heat emitting sources and at least
5cm from electrical ovens.
• Pay attention to keep your food in closed
containers.
• For products with a freezer compartment;
You can store maximum amount of
food items in the freezer when you
remove the shelf or drawer of the freezer.
Energy consumption value stated for
your refrigerator has been determined
by removing freezer shelf or drawer and
under maximum load. There is no harm
to use a shelf or drawer according to the
shapes and size of food to be frozen.
• Thawing frozen food in fridge
compartment will both provide energy
saving and preserve the food quality.

EN
9
3Installation
BPlease remember that the manufacturer
shall not be held liable if the information
given in the instruction manual is not
observed.
Points to be considered
when re-transporting your
refrigerator
1. Your refrigerator must be emptied and
cleaned prior to any transportation.
2. Shelves, accessories, crisper and etc. in
your refrigerator must be fastened securely
by adhesive tape against any jolt before
repackaging.
3. Packaging must be tied with thick
tapes and strong ropes and the rules of
transportation printed on the package
must be followed.
Please do not forget…
Every recycled material is an indispensable
source for the nature and for our national
resources.
If you wish to contribute to recycling the
packaging materials, you can get further
information from the environmental bodies
or local authorities.
Before operating your
refrigerator
Before starting to use your refrigerator
check the following:
1. Is the interior of the refrigerator dry and
can the air circulate freely in the rear of it?
2. Please install the 2 plastic wedges as
illustrated in the figure. Plastic wedges will
provide the required distance between
your refrigerator and the wall in order to
allow the air circulation. (The illustrated
figure is only an example and does not
match exactly with your product.)
3. Clean the interior of the refrigerator as
recommended in the “Maintenance and
cleaning” section.
4. Plug the refrigerator into the wall outlet.
When the fridge door is open, the fridge
compartment interior light will come on.
5. You will hear a noise as the compressor
starts up. The liquid and gases sealed
within the refrigeration system may also
give rise to noise, even if the compressor
is not running and this is quite normal.
6. Front edges of the refrigerator may
feel warm. This is normal. These areas
are designed to be warm to avoid
condensation.
Changing the illumination
lamp
To change the Bulb/LED used for
illumination of your refrigerator, call your
AuthorisedService.
The lamp(s) used in this appliance is not
suitable for household room illumination.
The intended purpose of this lamp is to
assist the user to place foodstuffs in the
refrigerator/freezer in a safe and comfortable
way.The lamps used in this appliance have
to withstand extreme physical conditions
such as temperatures below -20 °C.
(only chest and upright freezer)
