Beko METPOINT CID User manual

EN
METPOINT®CID
10-402
Original installation and operation manual

Table of contents
1. Safety instructions...........................................................................................................................4
1.1 About this document ...................................................................................................................................4
1.1.1 General safety instructions ............................................................................................................4
1.1.2 Using Class 2 lasers ..........................................................................................................................4
2. Servicing and maintenance .............................................................................................................5
3. Environmental protection ...............................................................................................................5
4. Intended use.....................................................................................................................................6
5. Technical data ..................................................................................................................................6
6. Marking ............................................................................................................................................7
6.1 Type plate........................................................................................................................................................7
6.2 Laser warning label.......................................................................................................................................7
6.3 Label locations...............................................................................................................................................7
6.3.1 The METPOINT®CID (standard and laser distance module) ................................................. 7
6.3.2 Parabolic mirror.................................................................................................................................7
7. Device components and controls....................................................................................................8
8. Overview of sensor types and description of their use..................................................................9
8.1 Assembly with horn....................................................................................................................................11
8.2 Assembly with focus tube.........................................................................................................................11
8.3 Assembly with gooseneck.........................................................................................................................12
8.4 Assembly with parabolic mirror...............................................................................................................12
9. Commissioning / use..................................................................................................................... 13
9.1 Switching on the device ............................................................................................................................13
9.2 Headphone volume up / down ................................................................................................................13
9.3 Sensitivity level............................................................................................................................................14
9.4 Laser ON / OFF............................................................................................................................................14
10. Automatic distance measurement............................................................................................. 15
11. Pinpointing leaks ........................................................................................................................ 17
11.1 Leak pinpointing process........................................................................................................................17
11.2 Possible causes of leaks ..........................................................................................................................18
11.3 Leak pinpointing procedure...................................................................................................................18
11.4 Supercial leak detection .......................................................................................................................19
12. How to use .................................................................................................................................. 20
12.1 Initialization...............................................................................................................................................20
12.2 Display.........................................................................................................................................................21
METPOINT® CID Original installation and operation manual
2 | 56

12.3 Home screen..............................................................................................................................................22
12.3.1 Conguration.................................................................................................................................23
12.3.1.1 Selecting a sensor type (measuring tool)...............................................................26
12.3.1.1.1 Intelligent tools.........................................................................................................26
12.3.1.1.2 Selecting the sensor type manually .....................................................................26
12.3.1.2 Saving a measurement ...............................................................................................27
12.3.1.3 Parameters for measurement (check).....................................................................27
12.3.1.4 Fault description ..........................................................................................................28
12.3.1.5 Storing a measurement on the internal SD card..................................................29
12.3.2 Export / Import..............................................................................................................................29
12.3.2.1 Export .............................................................................................................................30
12.3.2.1.1 Export Leakage data ................................................................................................30
12.3.2.1.2 Exporting system settings......................................................................................31
12.3.2.2 Import.............................................................................................................................32
12.3.2.2.1 Importing system settings......................................................................................32
12.3.2.2.2 Importing a new measuring tool...........................................................................33
12.3.2.3 Exporting / importing company databases ...........................................................34
12.3.3 Viewing bitmaps ...........................................................................................................................35
12.3.4 Device settings..............................................................................................................................36
12.3.4.1 Setting a password ......................................................................................................36
12.3.4.2 Device settings.............................................................................................................37
12.3.4.2.1 Language ....................................................................................................................37
12.3.4.2.2 Date and time............................................................................................................38
12.3.4.2.3 SD card........................................................................................................................38
12.3.4.2.4 Updating the system ...............................................................................................39
12.3.4.2.5 Checking for updates...............................................................................................40
12.3.4.2.6 Updating channels ...................................................................................................40
12.3.4.2.7 Resetting to factory settings .................................................................................41
12.3.4.2.8 Unique USB ID ..........................................................................................................41
12.3.4.2.9 Calibrating the touch panel ...................................................................................42
12.3.4.2.10 Display brightness..................................................................................................42
12.3.4.2.11 Cleaning....................................................................................................................43
12.3.4.2.12 System overview ....................................................................................................44
12.3.4.2.13 About METPOINT®CID........................................................................................44
12.4 Using the BEKO Leak Management software....................................................................................44
13. Charging the battery .................................................................................................................. 45
14. Scope of delivery......................................................................................................................... 46
15. Appendix ..................................................................................................................................... 47
16. Notes ........................................................................................................................................... 54
Original installation and operation manual METPOINT® CID
3 | 56

1. Safety instructions
1.1 About this document
Carefully read this documentation and familiarize yourself with the product before using it. Observe all safety
instructions and warnings in particular so as to prevent injury and damage to the product. Keep this documentation
within reach so that you will be able to consult it if necessary.
Pass on this documentation to later users of the product.
1.1.1 General safety instructions
• Use the product properly and exclusively as intended and within the parameters specied in
the technical data. Do not use force.
• Do not, under any circumstance, use the device to measure on or close to live parts! When
detecting leaks on electrical systems, please make sure to maintain a safe distance so as to
avoid dangerous electric shock!
• Avoid direct contact with hot rotating parts.
• Always switch the device on before connecting the headphones! The volume can be high when
the signal levels are high (headphone bars in red range). You can use the sensitivity setting to
reduce the volume.
• Observe the specied storage and operating temperatures.
• Using the device improperly or trying to use force on it will void the warranty.
• Tampering of any kind that is not in conformity with the intended and described processes will
void the warranty and exclude all liability.
• The device is intended exclusively for the purpose described.
1.1.2 Using Class 2 lasers
• Do not, under any circumstance, point the integrated laser directly at people!
• Do not, under any circumstance, hit a person’s or animal’s eyes with the laser beam!
• If a Class 2 laser beam hits your eyes, close your eyes and immediately move your head out of
the beam’s path.
• Do not look into the direct or reected beam.
• Horn and parabolic mirror laser exit points:
Laser exit point
Laser exit point
METPOINT® CID Original installation and operation manual
4 | 56

2. Servicing and maintenance
Servicing and maintenance work must be performed exclusively by authorized personnel.
3. Environmental protection
• Dispose of faulty rechargeable batteries and dead batteries in compliance with all applicable
regulations.
• After this product reaches the end of its service life, dispose of it as e-waste (in compliance
with all local regulations) or return the product to BEKO TECHNOLOGIES for disposal.
This electrical device contains the following rechargeable battery:
Battery type Chemical system
Rechargeable battery Li-ion 2S1P
How to safely remove the battery
• Warning: Make sure that the battery is completely discharged.
• Remove the rechargeable battery as shown below:
Remove the battery lid Unplug the connector Carefully pull out the battery
• Carefully remove the rechargeable battery. You can now dispose of the rechargeable battery and the device
together.
Original installation and operation manual METPOINT® CID
5 | 56

4. Intended use
The METPOINT®CID is a leak detection device used to quickly and reliably detect leaks in compressed air systems.
The METPOINT®CID leak detection device analyses the ultrasonic waves produced by a leak as a function of distance
and pressure.
It is designed exclusively for the intended purpose described here and may only be used accordingly.
The operator must check whether the device is suitable for the use chosen.
The technical data listed on the data sheet are binding. Inappropriate handling and operation outside the technical
specications is not permitted.
Claims of any kind due to non-intended use are excluded.
5. Technical data
Handheld housing dimensions 263 x 96 x 280 mm (11.55 x 3.78 x 11.02 in) with preamplier and horn
Weight 0.55 kg (1.21 lb) with preamplier and horn.
Approx. 3.0 kg (6.61 lb) for the complete kit in its case
Operating frequency 40 kHz (+/-2 kHz)
Power supply, internal 7.2 V Internal lithium-ion battery
Power supply, external 12 VDC 1 A External power supply unit (included)
Operating time > 9 h (continuous operation)
Charging time Max. 4 h
Laser 645 – 660 nm wavelength, output power < 1 mW (Class 2 laser)
Connections 3.5 mm headphone jack for headphones.
Power supply connector for connecting an external charger.
USB port
Colour display Transmissive TFT 3.5” touch panel
Interface USB for importing / exporting data, SW updates, etc.
Data logger 16 GB memory card (Class 4 microSD)
Intended area for use Indoors
Operating temperature -5 °C … +50 °C (+23 … +122 °F)
Storage temperature -20 °C … +60 °C (-4 … +140 °F)
Altitude Up to 4000 m (13,123 ft) above sea level
Max. air humidity < 95% RH, non-condensing
Permissible pollution degree 2
Degree of protection IP20
METPOINT® CID Original installation and operation manual
6 | 56

6. Marking
6.1 Type plate
METPOINT
®
CID
Lithium-Ion-battery: 7,2 V
Power Supply: 12V DC / 1A
Degree of Protection: IP 20
Operating Temperature: -5 … +50°C / +23 ... +122°F
P/N: 4055748
S/N: 42227631
www.beko-technologies.com
6.2 Laser warning label
6.3 Label locations
6.3.1 The METPOINT®CID (standard and laser distance module)
6.3.2 Parabolic mirror
METPOINT®CID
Parabolspiegel / Parabolic mirror
www.beko-technologies.com
P/N: 0530.0106
S/N:
BEKO TECHNOLOGIES GmbH
Im Taubental 7, D - 41468 Neuss
Original installation and operation manual METPOINT® CID
7 | 56

7. Device components and controls
7
1
2
8
10
9
5
6
11
3
4
Position number Description / Explanation
[1] Release button for preamplier module
[2] 3.5” TFT colour display with touch panel
[3] Membrane keypad (four keys)
[4] ON / OFF button
[5] Volume (+/-)
[6] “Save” key
[7] Connector for power supply unit (battery charging connector)
[8] USB port
[9] Preamplier module
[10] Camera
[11] Horn
3.5 mm jack
for headphones
METPOINT® CID Original installation and operation manual
8 | 56

8. Overview of sensor types and description of their use
Horn (standard attachment) Focus tube
The horn bundles incident ultrasonic waves together,
increasing the device’s range this way. This makes it ideal
for medium distances. Leaks can be heard across long
distances, but the user needs to get closer to the leak and
always follow the “loudest” point to pinpoint it accurately.
The user must then scan the individual compressed air
components to pinpoint exact locations.
Quantication distance: 1 … 6 m (3 … 20 ft)
When to use the horn:
• Medium distance from line / component of 0.2 … 6 mm
(0.66 … 20 ft)
• Low noise
• Freely accessible leak
• Use at distances of up to six meters if there is no
parabolic mirror
The tip of the focus tube only lets very few ultrasonic
waves through in the direction of the ultrasonic
transducer, making it possible to pinpoint leaks very
exactly.
Accordingly, it is recommended to use the focus tube
at short distances in order to accurately pinpoint the
corresponding leak.
Quantication distance: 0 … 0.2 m (0 … 0.66 ft)
When to use the focus tube:
• Short distance from line / component of
0.05 m (0.16 ft)
• Freely accessible line / component
• The lines and components being inspected are very
close to each other
• Use if there is no gooseneck available
Original installation and operation manual METPOINT® CID
9 | 56

Gooseneck Parabolic mirror
The gooseneck should be used when the lines and
components being inspected are physically very close
to each other. In addition, the gooseneck’s shape can
be adjusted as necessary in order to make it possible
to comfortably inspect lines and components that are
dicult to access.
The gooseneck’s sensitivity has been reduced in order to
attenuate noise.
Accordingly, it is exceptionally well-suited to inspecting
compressed air components in a targeted and local
manner when there is high noise, such as is the case inside
compressed air distributor cabinets and with systems that
use pneumatic cylinders.
Quantication distance: 0 … 0.05 m (0 … 0.16 ft)
When to use the gooseneck:
• Short distance from line / component of
0.05 m (0.16 ft)
• Freely accessible line / component
• The lines and components being inspected are
physically very close to each other
• Medium to high noise
The parabolic mirror bundles horizontally incident
ultrasonic waves together at its focal point, where
the ultrasonic transducer is located. This results in
the measured ultrasound being signicantly amplied
(long range), as well as in very precise directional
characteristics, as any ultrasound that is not horizontally
incident is simply reected by the reector.
The combination of these two properties means that the
parabolic mirror can be used to accurately pinpoint leaks
across long distances.
Quantication distance: 3 … 12 m (9.84 … 39.38 ft)
When to use the parabolic mirror:
• Long distance from line / component of
3 … 12 m (9.84 … 39.38 ft)
• Noise
• Leak not freely accessible
• Leaks physically close to each other (overlapping)
METPOINT® CID Original installation and operation manual
10 | 56

8.1 Assembly with horn
By bundling sound waves together, the horn makes acoustic amplication possible and helps pinpoint leaks accurately.
Its special design ensures that the integrated laser pointer will continue to be usable. The camera is integrated into the
underside of the horn and is connected electrically to the preamplier module with the jack.
Assemble the device by joining the individual components until you hear them lightly lock into place (insert them all the
way).
To disassemble the device, remove the components in the opposite order. You will additionally need to press the release
button in order to release the preamplier module.
8.2 Assembly with focus tube
The focus tube with a tip is used to detect very small leaks and pinpoint them exactly. Just like the horn, the focus tube
can be installed on the preamplier with an ultrasonic receiver.
The camera cannot be used in this case.
To disassemble the device, remove the components in the opposite order. You will additionally need to press the release
button in order to release the preamplier module.
Original installation and operation manual METPOINT® CID
11 | 56

8.3 Assembly with gooseneck
Due to its exibility, the gooseneck tool is used for localized measurements in areas that are dicult to access. it is
connected to the METPOINT®CID with the included coiled cord.
The camera cannot be used in this case.
To remove the component, disconnect the connection cable. To do this, press the release button on both sides and pull
o the cable.
8.4 Assembly with parabolic mirror
The parabolic mirror is used for measurements at long distances and for strict requirements regarding selectivity and
leak location pinpointing.
It is connected to the METPOINT®CID with the included coiled cord.
To remove the component, disconnect the connection cable. To do this, press the release button on both sides and pull
o the cable.
Note:
In order to use the parabolic mirror and gooseneck, these components must be enabled on the METPOINT®CID during
the initial commissioning process in order to save the corresponding component-specic calibration parameters. If this
has not been done at the factory already, the corresponding data will be included on a USB drive. For instructions on
how to enable the components (importing parameters), see section “12.3.2 Export / Import“.
Parabolic mirror 2.0 and gooseneck 2.0 will be automatically detected by an intelligent METPOINT®CID. In this case,
you will not need to import the corresponding parameters.
METPOINT® CID Original installation and operation manual
12 | 56

9. Commissioning / use
Please observe the safety instructions in section 1 rst
Operating the METPOINT® CID with an external plug-in power supply unit is only permitted in
ambient temperatures ranging from -5 °C (+14 °F) to +40 °C (+104 °F).
9.1 Switching on the device
Press the ON / OFF button and hold it down for about 1 second. The device will switch on and a startup sequence will be
shown on the display. Pressing the button again will switch o the device.
See “Device components and controls“ for the ON / OFF button
9.2 Headphone volume up / down
You can raise and lower the headphone volume in 16 steps with the volume up / down buttons. Holding the button
down will automatically raise / lower the value.
See “Device components and controls“ for volume up / down buttons
Please make sure that the headphone volume is lower than 50% before putting the headphones
on.
Original installation and operation manual METPOINT® CID
13 | 56

9.3 Sensitivity level
Ultrasonic levels can be viewed as a kind of leak “volume.”
You can use the “sensitivity adjustment button” to adjust the sensitivity of the METPOINT®CID to the corresponding
surroundings. This will heavily aect the device’s acoustic behaviour and increase or reduce the valid value range.
Reducing sensitivity will reduce the range of the leak measurement. However, the “relevant area” illustrated with a circle
on the display will also be smaller, making exact pinpointing much easier.
Sensitivity levels
0 … 60 dB The device’s maximum sensitivity level (intended for when there are small leaks and no
noise); can be selected with the “HiSn button” or “sensitivity level button”
10 … 70 dB Leaks and noise will become “quieter” and the range will decrease
20 … 80 dB Leaks and noise will become “quieter” and the range will decrease
30 … 90 dB Leaks and noise will become “quieter” and the range will decrease
40 … 100 dB Least sensitive level (large leaks, a lot of noise for a heavy-duty application)
50 … 110 dB Leaks and noise will become “quieter” and the range will decrease
60 … 120 dB Least sensitive level (large leaks, a lot of noise for a heavy-duty application)
Whether the 50 … 110 dB and 60 … 120 dB levels are available will depend on whether the METPOINT®CID and the
sensor are intelligent. The METPOINT®CID will have its auto function enabled by default and will switch between levels
(10 – 70 dB to 40 – 100 dB) by itself.
9.4 Laser ON / OFF
The laser pointer can only be switched on and o with the laser ON / OFF button on the display (not with the membrane
keypad). When switched on, the display will show a laser warning symbol.
Laser “ON” icon
Please observe all warnings regarding laser
operation! Do not, under any circumstance,
hit a person’s or animal’s eyes directly or
indirectly (reection) with the laser beam!
METPOINT® CID Original installation and operation manual
14 | 56

10. Automatic distance measurement
The new intelligent horn features an integrated distance measuring module.
Prerequisites for rmware and hardware:
In order to be able to use this functionality, the following prerequisites must rst be met:
• The main board must be “intelligent” so that the main body of the METPOINT®CID and the tool will be able to
communicate with each other.
• The rmware version on the METPOINT®CID must be V3.02 or higher. The latest rmware can be downloaded from
the “Downloads” section of the corresponding homepage.
If these prerequisites are met, the METPOINT®CID will automatically detect that an intelligent tool with automatic
distance measuring is connected.
Description of functionality:
1. The laser must be started in order to activate the distance measurement, just
like with all other tools.
2.
The METPOINT®CID will then show the measured distance on the display. In
this case, the distance is 3.49 meters o 137 inches depending on the selected
unit system.
3.
In order to automatically use the measured distance to calculate costs, you will
need to enable the “Distance by Laser” option under “Parameter.”
Important: The laser must be switched on before you enable “Distance by
Laser.” Otherwise, the icon will ash yellow and red and say “Laser?”.
Note: For the horn, the valid distance range is 1 … 6 meters (40 … 236 inches).
4.
The METPOINT®CID will now update the distance automatically. The currently
measured distance will be shown in the grey “Dist:” bar. Meanwhile, the distance
used for cost calculations will be shown in the small bar at the bottom left next
to the pressure.
Original installation and operation manual METPOINT® CID
15 | 56

State Current distance
measurement
Distance parameter
used internally
Likelihood that the
distance is being
measured correctly
Best case white green high
Assess how plausible the
measurement is yellow yellow medium
Move to the valid distance
range white yellow high, but distance outside of valid range
Move to a dierent surface
close to the leak until the
“best case” occurs and the
measurement is robust
red empty low
Important: The distance measurement can be challenging on black surfaces or in very bright environments, which is
why distances can still be entered manually. To be able to enter manual distances, disable the “Distance by Laser” option.
States:
Best case:
“Dist:” is green, the distance module measurement is robust and the
distance used falls within the valid range
Outside of range:
Distance measurement = robust, but out of range!
Move to the valid distance range
METPOINT® CID Original installation and operation manual
16 | 56

11. Pinpointing leaks
This section goes over how to optimally use the device in real-life scenarios.
11.1 Leak pinpointing process
The following process should be carried out cyclically at the company in order to keep leakage rates as low as possible.
The goal should be to have a continuous leakage rate of 5 … 10%, as searching for leaks and xing them one time only
will not reduce the leakage rate permanently and new leaks will occur later on.
Real-life tip:
To identify the ideal time, it is recommended to use a volumetric ow sensor in the main line behind the tank. At least
one week (Monday to Sunday) is recommended as the period for the measurement. When production is stopped, the
volumetric ow prole will show the leakage rate. This means that if the limit is exceeded, a leak search can be ordered.
In addition, the volumetric ow measurement can be used to validate the result from the leak search and x, as the latter
should reduce the volumetric ow rate when production is stopped.
5
1
4
3
2
Position number Description / Explanation
[1] Pinpointing leaks
[2] Quantifying leaks
[3] Documenting leaks
[4] Reporting leaks
[5] Fixing leaks
Original installation and operation manual METPOINT® CID
17 | 56

11.2 Possible causes of leaks
When dealing with compressed air systems, leaks can be usually found at connecting elements.
• Leaky couplings and hose clamps
• Leaky gaskets
• Porous / faulty hoses
• Porous / faulty seals on tools and machines
• Faulty condensate drains
• Leaky or incorrectly installed dryers, lters, service units
• etc.
11.3 Leak pinpointing procedure
The specic approach recommended for pinpointing leaks depends on the specic ambient conditions in question.
Option 1 – from which direction can you hear a leak?
When using this method, you should point in all directions until you nd the loudest point. After this, you should move
in the direction of the loudest point in order to be able to accurately pinpoint the leak.
This option works well when there is little noise.
Option 2 – Walking along the compressed air system.
Alternatively, if there is more noise, you can make it easier to pinpoint the leak by “moving along and listening to the
compressed air system bit by bit.” That is, from the compressor room all the way to the end points. If there is noise, it
is recommended to manually reduce the device’s sensitivity and use either the gooseneck for short distances or the
parabolic mirror for long distances.
In addition, the following generally applies when using this method: The shorter the distance from line, the easier it
will be to pinpoint the leak.
Option 3 – Searching for leaks while production is stopped
Production processes can result in ultrasonic noise in certain cases. If, for example, a pneumatic system blows o air
on a regular basis, the METPOINT®CID will detect the corresponding noise.
If noise makes pinpointing leaks signicantly harder, it is recommended to use option 1 or option 2 if the lines are
pressurized but the corresponding production processes are stopped. This is the easiest and fastest way to nd leaks.
METPOINT® CID Original installation and operation manual
18 | 56

11.4 Supercial leak detection
After the device starts, it will be in the leak detection view. The following gure describes the various corresponding
functions and indicators.
14
1
2
4
6
5
7
8
9
10
11
12
13
3
Position number Description / Explanation
[1] Signal level in dB
[2] Leakage rate
[3] Leakage costs per year
[4] LeakTag number
[5] Camera image
[6] Home screen
[7] High sensitivity
[8] Saves the measurement
[9] Settings
[10] Laser ON / OFF button
[11] Date / time and battery charge (alternating display)
[12] Laser “ON” icon
[13] Signal level bars
[14] Sensitivity adjustment button
Original installation and operation manual METPOINT® CID
19 | 56

12. How to use
This device is controlled using the various screens on the touch panel. To select a screen option, simply “tap” it quickly
with a nger or stylus.
Important:
Please do not use pens or other objects with sharp edges!
Doing so may damage the touch panel lm!
You can enter information into or make changes to all elds with a white background.
12.1 Initialization
After the METPOINT®CID is switched on, it will be initialized and then
switch to the leakage screen
METPOINT® CID Original installation and operation manual
20 | 56
