BBC Bircher CR3 User manual

1
2
1
3 4 5 6
7
9
10
8
Min.
Max.
1 m 0.5 m 0 m 0.5 m 1 m
0.5
m
1 m
1.5
m
2 m
2.5
m
M3 x 10
48
Max. 7
M3 x 40
36
63
36
Max. 4
10 16
36
CR3
2Assembly
1Safety instructions
4Field size adjustment
Translation of the original instructions
General
Top cover
 Screw
 Sealing
Radar module
PCB module
Screw
Rubber grommet
Cable
 Rubber plug
 Cover back
Mounting of the detector
1. Position drill template
2. Drill the holes, remove drill template
3. Mount detector
Microwave motion detector
ENGLISH
366237D
05/18
Electrical connections
3
1. Open the lower hole
from the gap,don’t
open the upper hole.
2. Adjust the
potentiometer.
3. Mount the rubber plug
correctly.
Only trained, qualied personnel may mount and start up the detector.
The unit may only be opened and repaired by the manufacturer.
The unit may only be operated from a safety extra-low voltage (SELV) system with safe electrical
separation.
Always consider the safety functions of your application as a whole, never just in relation to one
individual section of the system.
The installer is responsible for carrying out a risk assessment and installing the detector and the
system correctly. Avoid touching any electronic components.
The rubber plug must be mounted correctly after adjusting potentiometer. Otherwise it will affect
protection effect (IP65).
12~28 V AC
12~36 V DC
48 V AC/DC
30 W / 60 VA
grey
yellow
green
brown
white

2
Made in China / Designed in Switzerland
BBC Bircher Smart Access, BBC Bircher AG, Wiesengasse 20, CH-8222 Beringen, www.bircher.com
Technology Microwave Doppler Radar
Frequency 24.125 GHz
Transmitter radiated power (EIRP) < 20 dBm
Max. detection distance 2.5 m
Detection mode Motion
Min. detection speed 3 cm/s (measured in sensor axis)
Supply voltage 12~28 V AC ± 10%
12~36 V DC + 30%/– 10%
Max. power consumption 1.2 W
Output
Relay with switch-over contact
Rated load: 0.5 A at 125 VAC; 1 A at 24 VDC
Rated carry current: 2 A
Max. switching voltage: 125 VAC, 60 VDC
Max. switching current: 1 A
Output hold time 1 s
Temperature range –20 to +60 ˚C
Protection class IP65
Dimension (mm) 63 x 48 x 36 mm (L x W x H)
Materials ABS
5Technical data
6EU Declaration of Conformity
9Contact
7WEEE
8FCC approval
This device meets the requirements of Part 15 of the FCC regulations and the RSS-210 standard of Industry Canada.
Warning: Changes or modications made to this device may void the FCC authorisation to operate this device.
See attachment
Devices with this symbol must be treated separately during disposal. This must be done in accordance with the laws of
the respective countries for environmentally sound disposal, processing and recycling of electrical and electronic equipment.
