Beko 19LM250DS/B User manual

BEKO - IB COVER
SIZE: 148 X 210 MM
INSTRUCTION MANUAL
19”
LCD/DVD
COMBI
MODEL 19LM250DS/B

2
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. DO
NOT PLACE OBJECTS FILLED WITH LIQUIDS ON OR NEAR THIS UNIT.
CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED. REPLACE ONLY WITH THE SAME
OR EQUIVALENT TYPE.
PLACEMENT INFORMATION
• Do not use this unit in places which are extremely hot, cold, dusty, or humid.
• Place the unit on a flat and even surface.
• Do not restrict the air flow of this unit by placing it somewhere with poor air flow, by covering
it with a cloth, or by placing it on bedding or carpeting.
SAFETY INFORMATION
• When connecting or disconnecting the cord, grip the plug and not the AC cord itself. Pulling
the cord may damage it and create a hazard.
• When you are not going to use the unit for a long period of time, disconnect the AC cord.
• The mains plug is used as the disconnecting device. It shall remain readily operable and should
not be obstructed during intended use. To be completely disconnected from the supply mains,
the mains plug of the apparatus should be disconnected from the mains socket outlet completely.
• When the signal lamp LED is off, it indicates that the apparatus is completely disconnected
from the mains.
• The apparatus should not be exposed to dripping or splashing and that no objects filled with
liquids, such as vases, should be placed on apparatus.
• Leave a minimum distance 100mm around the apparatus for sufficient ventilation;
• The ventilation openings should not be impeded by covering with items such as newspaper,
table-cloths, curtains etc.
• No naked flame sources such as lighted candles should be placed on the apparatus;
• Attention should be drawn to the environmental aspects of battery disposal;
• The use of apparatus in moderate climates.
CONDENSATION INFORMATION
• When left in a heated room where it is warm and damp, water droplets or condensation may form
inside the unit. When there is condensation inside the unit, the unit may not function normally.
Let the unit stand for 1-2 hours before turning the power on, or gradually heat the room and let
the unit dry before use.
RATING PLATE LOCATION
• The rating plate is on the back of product.
The symbol for Class II
(Double lnsulation)
CAUTION
INVISIBLE LASER RADIATION WHEN OPEN
AND INTERLOCKS DEFEATED.
AVOID EXPOSURE TO BEAM
WARNING: Should any problems occur, disconnect the AC cord and refer servicing to a qualified technician.
SAFETY PRECAUTIONS
This product
contains a low
power laser device.
This symbol means that
the unit complies with
European safely and
electrical interference
directives.
CLASS 1 LASER PRODUCT
The exclamation point within a triangle alerts
you to the presence of important operating,
maintenance and servicing instructions in
this user’s manual.
The lightning flash with an arrowhead within
a triangle alerts you to uninsulated
dangerous voltage within the product's
enclosure that could cause an electric shock.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED PERSONNEL.
PVS31190_IB_P2-13_DVI.pmd 16/08/2006, 14:232

3
IMPORTANT SAFETY INSTRUCTIONS
MAINS PLUG
UNITS SUPPLIED WITH MOULDED MAINS PLUG
1. If the mains plug fitted to the AC cord supplied is not suitable for your mains outlet it may be necessary to cut it off.
Carefully dispose of the severed plug. Under no circumstances must it be
inserted into a mains socket, otherwise a dangerous electric shock could result.
2. If the fuse in the fitted mains plug should fail, replace it with a BS1362 approved
fuse rated at 3A Never use the plug without the fuse cover fitted.
WIRING A MAINS PLUG
As the wires in the mains lead may not correspond with the coloured markings
identifying the terminals in your plug proceed as follows:
• The wire which is coloured blue must be connected to the terminal which is
marked with the letter Nor coloured black.
• The wire which is coloured brown must be connected to the terminalwhich is
marked with the letter L or coloured red.
•No connection is to be made to the earth terminal of the plug which is marked
with the letter Eor coloured green or green and
yellow or marked by the safety earth symbol.
The standard (BS1363) mains plug must be fitted with a 3 Amp fuse
approved to BS1362. If any other plug or connection is used a 3 Amp
fuse must be fitted in the plug or adaptor or in the distribution board.
Caution: Moisture Condensation
If the equipment is moved from a cold place to a warm one, water in the air will condense on some parts and may cause
damage or malfunction if the equipment is operated.
Allow at least two hours for the equipment to acclimatise before switching it on.
This unit is designed to operate from a 230V-240V AC ~ 50Hz mains supply.
Please note that when the STANDBY/ON switch is in the standby position this does not completely disconnect the unit from
the mains supply. If the equipment is not to be used for a day or more, disconnect it at the wall outlet.
This symbol means that the unit is double insulated.No connection to earth is necessary.
SAFE USE OF YOUR EQUIPMENT
This equipment has been designed and manufactured to meet UK safety standards but like any electrical equipment care
must be taken to obtain the best results from the equipment and assure your own safety. Here are a few tips to help you
do this:
READ this instruction manual before you attempt to use the equipment.
NEVER fit makeshift stands or legs with woodscrews. Use only approved supports and fasteners specially designed for
the equipment.
NEVER let anyone, especially children, push objects into holes, ventilation slots or any other opening; this could result in
fatal electric shock!
ALWAYS disconnect the AC power cord when you are not going to use the unit for a long period of time.
ENSURE adequate ventilation of the equipment is not obstructed, for example by curtains above or soft furnishings
underneath it.
ENSURE that all electrical connections (including the mains plug, extension leads and interconnections between pieces
of equipment) are properly made in accordance with the instructions given. Switch off the main supply when making or
changing connections.
CONSULT your dealer if you are ever in doubt about the installation, operation or safety of your equipment.
DON'T continue to operate the equipment if it is damaged in any way or if it does not function normally.
Withdraw the mains plug and consult your dealer.
DON'T leave equipment switched on when it is unattended unless it is part of it's normal function to operate in your
absence, for example a video cassette recorder with timed recording facility.
LISTEN to headphones at moderate volume levels; high volume levels can permanently damage your hearing.
The wires in this mains lead are
coloured in accordance with the
following code.
BLUE-NEUTRAL
BROWN-LIVE
PVS31190_IB_P2-13_DVI.pmd 16/08/2006, 14:233

4
TABLE OF CONTENTS
SAFETY PRECAUTIONS ................... 2
IMPORTANT SAFETY INSTRUCTIONS
.......................................................... 3
DISC FORMATS ................................ 5
INSTALLATION ................................. 6
Removing the base stand ............... 6
Mounting on the wall ...................... 6
REMOTE CONTROL ......................... 7
REMOTE CONTROL REFERENCE
GUIDE ........................................ 8 – 9
UNIT REFERENCE GUIDE ...... 10 – 11
CONNECTING A TV ANTENNA ...... 12
CONNECTING A POWER CORD ... 12
DISPLAY ........................................... 13
TV SETUP ................................. 14 – 17
Setup menu .................................... 14
Tuning menu .................................. 15
Program menu ............................... 15
Picture menu ................................ 16
Sound menu ................................... 17
TELETEXT ................................. 18 – 19
CONNECTIONS ....................... 20 – 24
Connecting to A/V devices (VCR,
Camcorder, Game System, etc.)
.............................................. 20 – 21
Connecting to sources with component
video output (DVD - only 480i, 480p,
720p & 1080i are supported) ......... 22
Connecting to sources with scart
...................................................... 22
Connecting an audio amplifier ...... 23
Connecting a PC ............................ 23
Connecting to sources with DVI output
(DVD - only 576i, 576p, 720p & 1080i
are supported) ............................... 24
USING HEADPHONES .................... 25
UNIT OPERATION ......................... 25
SOUND SYSTEM ........................... 25
CD/DVD OPERATION ............. 26 - 27
Playing a disc ................................ 26
Pausing playback (still mode) ....... 26
To skip to a different track ............ 26
Fast forward/fast reverse ............... 26
Skip (Forward/Reverse) ................. 27
Audio selection (DVD) .................. 27
Subtitle selection (DVD) ............... 27
Angle Selection (DVD) .................. 27
SPECIAL FUNCTIONS ...................... 28
Display function (DVD) ................ 28
Locating a specific title (DVD) ..... 28
Locating a specific chapter/track .. 28
Locating a specific time ............... 28
CD/DVD PROGRAMMABLE MEMORY
........................................................ 29
Programmable memory ................. 29
Title/chapter programmed playback
(DVD) ........................................... 29
Track programmed playback (CD)... 29
REPEAT PLAYBACK ................... 29 - 30
Repeating a chapter/title (DVD) ... 29
Repeating a single track/whole disc
(CD) ............................................. 29
Repeating a specific section (DVD)
(CD) .............................................. 30
PLAYING A PICTURE FILE DISC ..... 30
CUSTOMIZING THE FUNCTION
SETTINGS ................................ 31 – 32
Language setup ............................ 31
Video setup .................................... 31
System setup ................................ 31
TV type .......................................... 32
Password ..................................... 32
Rating ......................................... 32
Default .......................................... 32
LANGUAGE CODE LIST .................. 33
MAINTENANCE ................................ 34
TROUBLESHOOTING GUIDE .... 35 – 36
GUARANTEE GUIDE .................... 37 – 38
PVS31190_IB_P2-13_DVI.pmd 16/08/2006, 14:234

5
This unit can playback:
TITLE, CHAPTER AND TRACKS
• DVDs are divided into “titles” and
“chapters”. If the disc has more than one
movie on it, each movie would be a separate
“title”. “Chapters” are sections of titles.
• Audio CDs are divided into “tracks”. A
“track” is usually one song on an Audio CD.
ICONS USED ON DVDS
Sample lcons Language selections for audio
Language selections for subtitles
Screen aspect ratio
Multiple camera angles
Region code indicator
Notes:
• When playing back a CD-G (Graphics) or CD EXTRA disc, the audio portion will be played,
but the graphic images will not be shown.
DISC FORMATS
DVDS
[8CM/12CM DISC]
AUDIO CDS
[8CM/12CM DISC]
CD-R/CD-RW
Compatible
REGION MANAGEMENT INFORMATION
Region Management Information: This unit is designed and manufactured to respond to the Region
Management Information that is encoded on DVD discs. If the Region number printed on the DVD
disc does not correspond to the Region number of this unit, this unit cannot play that disc.
The region number of this unit is .
Note:
• Numbers identify each title, chapter, and track on a disc. Most discs have these numbers
recorded on them, but some do not.
Notes on Unauthorized Discs
You may not be able to play back some DVD discs on this unit if they were purchased from outside
your geographic area or made for business purposes.
JPG-CD
picture viewer
DISC FUNCTION OR OPERATION THAT IS NOT AVAILABLE
When the symbol appears on the screen, it indicates that the function or operation attempted
is not available at that time. This occurs because the DVD disc manufacturer determines the
specific functions. Certain functions may not be available on some discs. Be sure to read the
documentation provided with the DVD.
PVS31190_IB_P2-13_DVI.pmd 16/08/2006, 14:235

6
INSTALLATION
MOUNTING ON THE WALL
This unit is VESA-compliant, and is designed to be wall-mounted with a VESA-compliant 100mm
x 100mm mounting kit designed for flat-panel TVs (sold separately). Mount this unit according
to the directions included with the mounting kit.
REMOVINGTHE BASE STAND
WARNING: The LCD Display is very fragile, and must be protected at all times when removing
the base stand. Be sure that no hard or sharp, or anything that could scratch or damage the LCD
display, come in contact with it. Do NOT put pressure on the front of the unit at any time
because the screen could crack.
1. Disconnect any cables or cords connected to the unit.
2. Lay the unit down on a flat surface, so the back side is facing up, making sure to place a
soft cushioned material (such as a pillow or thick piece of foam) beneath the screen.
3. Remove the four screws and then remove the BASE STAND from the TV.
PVS31190_IB_P2-13_DVI.pmd 16/08/2006, 14:236

7
REMOTE CONTROL
USING THE REMOTE CONTROL
• Point the remote control at the REMOTE SENSOR located on the unit.
• When using this unit in a very brightly lit area, the infrared REMOTE CONTROL SENSOR may
not work properly.
• The recommended effective distance for using the remote control is about 16 feet (5 metres).
TO CHANGE THE REMOTE CONTROL BATTERY
1. Open the battery door. 2. Insert two “AA” batteries.
BATTERY REPLACEMENT
When the batteries become weak, the operating distance of the remote control will be greatly
reduced and you will need to replace the batteries.
Note:
• If the Remote Control is not going to be used for a long time, remove the batteries to avoid
damage caused by battery leakage corrosion.
• Do not mix old and new batteries. Do not mix ALKALINE, standard (CARBON-ZINC) or
rechargeable (NICKEL-CADMIUM) batteries.
WARNING: Do not dispose of batteries in a fire or they may leak and/or explode.
Waste electrical and electronic products must not be disposed of with
household waste. Please refer to the retailer from whom you purchased
this item for disposal instructions.
PVS31190_IB_P2-13_DVI.pmd 16/08/2006, 14:237

8
REMOTE CONTROL REFERENCE GUIDE
1) STANDBY/ON button
Press to turn ON the unit or put it in
STANDBY (OFF) mode.
2) RETURN button
Return to normal operation after using
the SETUP menu of a DVD.
3) Number (0 – 9) buttons
Use to change the TV channels.
4) TV button
Press to switch to TV mode.
5) DVD button
Press to select DVD mode.
6) button
Directly select Mono/Stereo - Dual I/II.
7) TEXT button
Directly selects Teletext mode.
8) SLEEP button
Sets the SLEEP timer. The unit will remain
ON for the time that is set, and will
automatically shut off afterwards.
9) TV MENU button
Press to display the on-screen TV menu.
10) + VOLUME – button
Press to adjust the volume level.
11) DVD MENU button
Press to enter the main menu of the disc
you are watching.
12) LAST CH button
Press to switch repeatedly between the
last two channels displayed.
13) STOP button
Stop playing a disc.
PLAY button
Press to start and resume playback of a
disc.
PAUSE button
Pause playback and single frame
advance.
14) HOLD button
Press to stop the automatic page change
from Teletext.
PREV button
Select previous chapters or tracks on a
disc.
15) ANGLE button
Switch the camera angle of the video
presentation when scenes with multiple
camera angles are recorded on a DVD.
SIZE button
Press to set the letters size of teletext on
the screen.
16) SUBTITLE button
Select one of the subtitle languages
programmed on a DVD.
17) MEMORY button
In stop mode, enter the number of a
selected chapter or track.
18) CLEAR button
Clear input selections and cancel certain
playback functions.
19) REPEAT A-B button
Perform point-to-point repeat playback on
a DVD or CD.
REPEAT DISC button
Repeat chapter of a DVD.
Repeat single track or whole CD.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
PVS31190_IB_P2-13_DVI.pmd 16/08/2006, 14:238

9
REMOTE CONTROL REFERENCE GUIDE
20) FUNCTION button
Toggle between TV / DVD / AV IN / YUV
IN / DVI IN / PC.
21) MUTE button
Press to turn off the sound.
22) GOTO button
Skip directly to a specific location on a
DVD/CD.
23) LCD MODE button
Press to Set the LCD display.
24) YUV IN button
Directly selects YUV (Component Video)
mode.
25) AV IN button
Directly selects AV1 / AV2 mode.
26) SOUND button
Select from preset sound settings (Personal,
Voice, Music, Theatre) to match the type
of show you are watching.
27) DISPLAY button
Change disc status information displayed
on the screen.
28) PICTURE button
Select from preset screen display settings to
match the type of show you are watching
(Standard, Personal, Movie, Dynamic, & Soft).
29) EXIT button
Press to exit the menu and return directly
to normal viewing.
30) SETUP button
Enter and exit the SETUP menu of the
DVD player.
31) Cursor ( ,, , ) buttons
Press to highlight selections on a menu
screen and make adjust certain settings.
CH + & CH – button
Move up or down through the TV channels
and forward or backward the page of
Teletext screen.
ENTER button
Confirm selections on a menu screen.
32) AUDIO button
Select audio sound tracks of a DVD or
change the output mode of a CD.
33) TIME button
Press to display the current time
information from Teletext.
MIX button
Press to select Teletext with a TV
programme.
/buttons
: Fast reverse playback.
: Fast forward playback.
34) INDEX button
Press to select the page number of the
index from Teletext.
NEXT button
Select next title, chapter or track on a
disc.
35) CANCEL button
Press to cancel the Teletext menu.
36) REVEAL button
Press to reveal answers on a quiz or game
pages from Teletext.
37) RED/GREEN/YELLOW/BLUE button
Press to select the relevant page quickly
from Teletext.
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
PVS31190_IB_P2-13_DVI.pmd 16/08/2006, 14:239

10
1) STANDBY/ON button
Turns the unit on and off.
2) MENU button
Enter the Setup menu.
3) FUNCTION button
Select TV, AV IN, YUV IN, DVI IN or PC.
4) – VOL + controls
Adjusts the volume level and highlights
selections (Left & Right) on the menu screen.
5) /buttons
Select a TV channel and highlight selections
(Up & Down) on the menu screen.
6) PLAY button
Press to start or resume playback a disc.
7) STOP button
Stops playing a disc.
8) PAUSE button
Pauses playback and frame advance.
UNIT REFERENCE GUIDE
9) PREV button
Press PREV button to go back to previous
chapters/tracks.
Press and hold to fast reverse playback.
10) NEXT button
Press NEXT button to advance chapters/
tracks.
Press and hold to fast forward playback.
11) OPEN/CLOSE button
Push to open the disc door.
12) Colour LCD Screen
13) Disc Door
14) STANDBY indicator
Indicates whether the unit is ON or in
STANDBY (OFF) mode.
Light On: The unit is in STANDBY.
Light Off: The unit is turned ON.
Remote Control Sensor
Do not block this sensor or the remote
control will not work.
15) Removeable Stand
TOP, FRONT & SIDE VIEW
12
13
14
15
1
3
2
5
4
6
7
8
9
10
11
PVS31190_IB_P2-13_DVI.pmd 16/08/2006, 14:2310

11
16) Power Cord
17) DVI Input
18) AV IN 1 S-Video Input
19) AV IN 1 Video Input Jack
20) AV IN 1 Audio Input Jacks (Left / Right)
21) Audio Output Jacks (Left/Right)
22) TV Antenna Cable terminal - Coaxial TV
antenna input
BACK & BOTTOM VIEW
UNIT REFERENCE GUIDE
23) Headphone Jack
24) PC IN Audio Jack
25) PC IN Monitor/VGA Jack
26) AV IN 2 Scart Input
27) YUV IN Component Video Inputs (Y/PB/PR)
28) YUV IN Audio Input Jacks (Left/Right)
16 17
23 24 25 26 27 28
18 19 20 21 22
PVS31190_IB_P2-13_DVI.pmd 16/08/2006, 14:2311

12
CONNECTING A TV ANTENNA
CONNECTING A TV ANTENNA/CABLE/SATELLITE
To view television channels correctly, a signal must be received from one of the following
sources:
- An indoor or outdoor aerial antenna
- A cable system
- A satellite system
Note:
For receiving over-the-air TV broadcasts,
we recommend that you use an external
fixed antenna. Should you require the
use of a temporary antenna, please ensure
that you purchase an antenna with
sufficient ability to receive in weak signal
areas. Only when you are in close
proximity to a transmitter will a temporary
antenna reproduce a signal as strongly
as a fixed antenna.
Satellite, Cable, or
TV antenna cable to
TV ANTENNA
CABLE Terminal
(cable not included)
CONNECT THE POWER CORD
• Connect the AC power cord into a wall outlet.
• Press the STANDBY/ON button on the unit or
remote control to turn on the unit.
Note:
• Be sure the AC power cord is disconnected and the
TV is switched off before making connections.
• Make sure that all the components are connected
correctly.
• When you are not going to use the unit for a long
period of time, disconnect the power cord.
• The apparatus should not be exposed to dripping
or splashing and that no objects filled with
liquids, such as vases, should be placed on
apparatus.
• The mains plug is used as the disconnecting
device. It should remain readily accessible and
should not be obstructed during use. To be
completely disconected from the supply mains,
the mains plug of the apparatus should be
disconnected from the mains socket outlet
completely.
CONNECTING A POWER CORD
To AC outlet
PVS31190_IB_P2-13_DVI.pmd 16/08/2006, 14:2412

13
DISPLAY
DISPLAY INFORMATION
The display information shown below on the TV screen depending on the operation status.
Nicam mode
Stereo mode
Mono mode
Mute mode
TV Display
PICTURE menu
SOUND menu
SETUP menu
TUNING menu
PROGRAM menu
Symbol TV Display
Symbol
PVS31190_IB_P2-13_DVI.pmd 16/08/2006, 14:2413

14
TV SETUP
SETUP MENU
1. Press the TV MENU button.
2. Use or button to select the Setup menu, then press button to enter the setting.
3. Use or button to select the options (OSD Size, Background, Language, Country,
Timers, Teletext lang., Teletext E/W, Auto adjust, Light, Restore setting) and adjust them
using the or buttons.
4. Repeat step 3 to adjust other settings.
5. To exit the MAIN MENU and return to the normal screen, press the EXIT button on remote
control.
In TV mode
•OSD Size : Select the menu size you prefer.
•Background : Select the menu from translucent/opaque
on screen.
•Language : Select the language your prefer.
•Country : Select the country your prefer.
•Timers : Select the Sleep timer / Reminder timer mode.
Sleep timer / Reminder timer : Off -> 5 - -
- - -> 115 -> 120.
•Teletext lang. : Select the teletext language from Pan
European/Cyrillic/Greek.
•Teletext E/W : Select the teletext from West/East.
•Light : Select “ON” to turn on the blue disc tray
light. Select “OFF” to turn off the blue
disc tray light.
•Restore setting : Reset the TV mode to the factory settings.
In PC mode
•OSD Size : Select the menu size you prefer.
•Background : Select the menu from translucent/opaque
on screen.
•Language : Select the language you prefer.
•Timers : Select the Sleep timer / Reminder timer mode.
Sleep timer / Reminder timer : Off -> 5 - -
- - -> 115 -> 120.
•Auto Adjust : Adjusts when characters have low contrast
or when the image flickers automatically.
•Light : Select “ON” to turn on the blue disc tray
light. Select “OFF” to turn off the blue
disc tray light.
•Restore setting : Reset the PC mode to the factory settings.
In AV / YUV / DVI mode
•OSD Size : Select the menu size you prefer.
•Background : Select the menu from translucent/opaque
on screen.
•Language : Select the language you prefer.
•Timers : Select the Sleep timer / Reminder timer mode.
Sleep timer / Reminder timer : Off -> 5 - -
- - -> 115 -> 120.
•Light : Select “ON” to turn on the blue disc tray
light. Select “OFF” to turn off the blue
disc tray light.
•Restore setting : Reset the AV / YUV/DVI mode to the factory
settings.
PC MODE
AV / YUV / DVI MODE
TV MODE
PVS31190_IB_P14-17.pmd 16/08/2006, 14:2614

15
TV SETUP
TUNING MENU
1. Press the TV MENU button.
2. Use or button to select the Tuning menu, then press button to enter the setting.
3. Use or button to select the options (Program no., Program name, Colour, Sound, Auto
tune, Manual tune, AFC, Skip) and adjust them using the or buttons.
4. Repeat step 3 to adjust other settings.
5. To exit the MAIN MENU and return to the normal screen, press the EXIT button on remote
control.
Note : This option is available in TV mode only.
Porgram no. : To store 1-99 TV channel.
Programe name : To set the name of TV channel.
Use or cursor to select the characters
to represent the station name. Use or
to next position of character.
Colour System : Select from Auto/PAL.
Sound System : Select from Auto, BG, I, DK, BG NICAM,
I NICAM, DK NICAM.
Auto tune : Searches for usable stations and stores
them in memory.
Manual tune : If the reception is not satisfactory, adjust
using or keys.
AFC : Auto frequency control.
Skip :ON - Skip weak channels.
OFF - No channel skip.
TV MODE
PROGRAM MENU
1. Press the TV MENU button.
2. Use or button to select the Program menu, then
press button to enter the setting.
3. To exit the MAIN MENU and return to the normal screen,
press the EXIT button on remote control.
Note : This option is available in TV mode only.
Remarks:
Move : Use , , or cursor to select the
Channel no. and press GREEN button, then
select the Channel no. you want to swap
it with, press GREEN button to swap.
Delete : Use , , or cursor to select the
channel no. you want to delete, press
RED button twice to delete.
TV MODE
PVS31190_IB_P14-17.pmd 16/08/2006, 14:2615

16
TV SETUP
PICTURE MENU
1. Press the TV MENU button.
2. Use or button to select the Tuning menu, then press button to enter the setting.
3. Use or button to select the options (Brightness, Contrast, Colour, Sharpness, Tint,
Colour Temp, Preset) and adjust them using the or buttons. (The screen will change to
your desired setting).
4. Repeat step 3 to adjust other options.
5. To exit the MAIN MENU and return to the normal
screen, press the EXIT button on remote control.
In TV / AV / YUV / DVI mode
•Brightness : Adjust to brighten the darkest parts of the
picture.
•Contrast : Adjust to sharpen the picture quality. The
black portions of the picture become
richer in darkness and the white become
brighter.
•Colour : Adjust the colour of the picture.
•Sharpness : Adjust the sharpness level to improve
detail in the picture.
•Tint : Adjust the tint of the picture. (Toward
purple / Toward green)
•ColourTemp : Adjust the three colour temperature of
the picture. Select Normal (balanced) /
Cold (blue white) / Warm (red white) mode.
•Preset : Select from preset screen display settings
to match the type of show you are
watching (Standard, Personal, Movie,
Dynamic, & Soft).
Note :
You can also select simply by pressing the PICTURE button.
In PC mode
Use or button to select the options (Brightness,
Contrast, Frequency, Phase, H offset, V offset, Colour Temp,
Preset) and adjust them using the or buttons. (The screen
will change to your desired setting).
- Resolution : 1366 x 768 max
- Refresh Frequency : 60Hz max.
•Brightness : Adjust to brighten the darkest parts of the
picture.
•Contrast : Adjust to sharpen the picture quality. The
black portions of the picture become
richer in darkness and the white become
brighter.
•Frequency : Adjust the frequency of the picture.
•Phase : Adjust when characters have low contrast
or when the image flickers.
•H offset : Centre the image by moving it left or
right.
•V offset : Centre the image by moving it up or down.
•ColourTemp : Adjust the three colour temperature of
the picture. Select Normal (balanced) /
Cold (blue white) / Warm (red white) mode.
•Preset : Select from preset screen display settings
to match the type of show you are
watching (Standard, Personal, Movie,
Dynamic, & Soft).
TV / AV MODE
YUV / DVI MODE
PC MODE
PVS31190_IB_P14-17.pmd 16/08/2006, 14:2616

17
TV SETUP
SOUND MENU
1. Press the TV MENU button.
2. Use or button to select the Sound menu, then press button to enter the setting.
3. Use or button to select the options (Balance, Bass, Treble, Preset) and adjust them
using the or buttons.
4. Repeat step 3 to adjust other settings.
5. To exit the MAIN MENU and return to the normal screen, press the EXIT button on remote
control.
Experiment with different sound settings until you find the
settings you prefer.
•Bass : Adjust the bass range.
•Treble : Adjust the treble range.
•Balance : Adjust the balance level toward the left or
right speakers.
•Preset : Select from preset sound settings (Personal,
Voice, Music, Theatre) to match the type of
show you are watching.
Note :
You can also select simply by pressing the SOUND button.
TV MODE
PC / AV / YUV / DVI MODE
PVS31190_IB_P14-17.pmd 16/08/2006, 14:2617

18
TELETEXT
Teletext is an information system that displays text on your TV screen. Using the Teletext control
buttons you can view pages of information that are listed in the teletext index.
Please Note
No on screen display is available in text mode. The contrast, brightness and colour cannot be
changed but the volume control is still available.
TO ENTER TEXT MODE
Please Note
Make sure the TV channel you are watching transmits teletext. If not NO TEXT sign will be shown
on the screen.
Press the TEXT button. The text page will appear, normally the index page.
TO EXIT TEXT MODE
Press the TEXT button, The TV will return to the channel you were watching.
TO SELECT A PAGE OF TEXT
Find the number of the page in the index and enter it using the Numeric buttons. The number of
the page will appear in the top left hand corner of the screen.
The page counter will search for your page. When it finds it, the page will be displayed.
To move to the next page of text, press the CH + button.
To move to the previous page, press the CH - button.
To return to the index page, enter the “100” by using the Numeric buttons.
TIME/MIX
To view a page of the text whilst watching a TV programme press the MIX button. The text will be
superimposed over the TV programme.
Press the MIX button again to return to the text page.
PAGE SEARCH WHILST WATCHING TV
In Text mode press the CANCEL button. The TV will return to TV mode with “ CAN ” in the top left
hand corner of the screen.
Enter the page number you want using the Numeric buttons.
The top line of the text page will appear whilst the text searches for your page. When the page
is found the number will remain in the top left hand corner of the screen.
Press the CANCEL button to view your selected page of text.
PVS31190_IB_P18-19.pmd 16/08/2006, 14:2718

19
TELETEXT
DOUBLE HEIGHT TEXT
If you have difficulty reading the text on the TV you can double the height of the text.
Press the SIZE button. The top half of the page will be displayed in double height text.
Press the SIZE button again. The bottom half of the page will be displayed in double height text.
Press the SIZE button again to return to the full page.
PAGE STOP
If the page of text you have selected contains sub pages, these sub pages will automatically be
displayed in order with a delay to allow you to read the page.
To stop the move to the next sub page, press the HOLD button. “HOLD” will appear in the top left
hand corner.
To continue moving through the sub pages, press the HOLD button again.
TO SELECT A SUB PAGE
To select a sub page press the SUBTITLE button. The screen will show “ S _ _ _ _ “, then press the
page by using the Numeric buttons.
TO REVEAL INFORMATION
Press the REVEAL button to reveal concealed information (quiz answers etc.).
Press the REVEAL button again to conceal the information again.
FASTEXT
At the bottom of the teletext screen is a row of subject headings in red, green, yellow and blue.
The remote control has a row of colour buttons corresponding to the row of coloured subjects on
the screen.
Pressing one of the colour buttons will take you directly to the page corresponding to the subject
heading.
PVS31190_IB_P18-19.pmd 16/08/2006, 14:2719

20
CONNECTING TO A/V DEVICES (VCR, Camcorder, Game System, etc.)
Connecting to Devices with an S-Video Output
To connect to A/V devices such as a VCR or camcorder:
- Connect to a VCR
Connect the right (red) and left (white) audio output
from the VCR to the right (red) and left (white)
input on this unit (Audio cable not included).
Connect the S-VIDEO output from the VCR to the
S-VIDEO input on this unit (S-VIDEO cable not
included).
Make sure you connect both audio and video from
the same VCR to the same input (AV1).
To operate the connected device and play the
VCR, first press the FUNCTION button or AV IN
button to select the AV1 mode.
Note:
Please refer to the user manual for the VCR for
more information.
CONNECTIONS
- Connect to a camcorder
Connect the right (red) and left (white) audio output
from the camcorder to the right (red) and left (white)
input on this unit (Audio cable not included).
Connect the S-VIDEO output from the camcorder
to the S-VIDEO input on this unit (S-VIDEO cable
not included).
Make sure you connect both audio and video from
the same camcorder to the same input (AV1).
To operate the connected device and play the
camcorder, first press the FUNCTION button or AV
IN button to select the AV1 mode.
Note:
Please refer to the user manual for the camcorder
for more information.
PVS31190_IB_P20-25_DVI.pmd 16/08/2006, 14:2920
