Beko 2012 CXY User manual

Washing Machine
User’s Manual
2012 CXY

Please read this manual first!
Dear Customer,
We hope that your product which has been manufactured in modern facilities and
passed through a strict quality control procedure will give you the best results.
Therefore, we advise you to read through this manual carefully before using your
product and keep it for future reference.
This operation manual will…
…help you use your machine in a fast and safe way.
 •PleasereadtheOperationManualbeforeinstallingandstartingyourmachine.
 •Particularlyfollowtheinstructionsrelatedtosafety.
 •KeepthisOperatingManualwithineasyreach.Youmayneeditinthefuture.
 •Pleasereadalladditionaldocumentssuppliedwiththismachine.
PleasenotethatthisOperatingManualmaybeapplicableforseveralothermodels.
Differences between models will be identified in the manual.
Explanation of symbols
ThroughoutthisOperationManualthefollowingsymbolsareused:
CImportant information or useful hints about usage.
AWarning for hazardous situations with regard to life and property.
BWarning for supply voltage.
2820521249_EN/071010.1324
This appliance’s packaging material is recyclable. Help recycle it and protect
the environment by dropping it off in the municipal receptacles provided for this
purpose.Yourappliancealsocontainsagreatamountofrecyclablematerial.Itis
marked with this label to indicate the used appliances that should not be mixed
with other waste. This way, the appliance recycling organised by your manufac-
turer will be done under the best possible conditions, in compliance with European
Directive 2002/96/EC on Waste Electrical and Electronic Equipment. Contact your
town hall or your retailer for the used appliance collection points closest to your
home. We thank you doing your part to protect the environment.

EN
3
TABLE OF CONTENTS
1 Your Washing Machine 4
Overview . . . . . . . . . . . . . . . . . . . . . . .4
Specifications . . . . . . . . . . . . . . . . . . .5
3 Installation 8
Removing packaging reinforcement. . .8
Openingthetransportationlocks. . . . .8
Appropriate installation location . . . . . .8
Adjusting the feet. . . . . . . . . . . . . . . . .8
Connecting to the water supply. . . . . .8
Connecting to the drain . . . . . . . . . . . .9
Electrical connection . . . . . . . . . . . . .10
Destroying the packaging material. . .10
Disposing of the old machine. . . . . . .10
4 Initial preparations for
washing 11
Sorting the laundry . . . . . . . . . . . . . .11
Preparingclothesforwashing . . . . . .11
Correct load capacity . . . . . . . . . . . .12
Loading door. . . . . . . . . . . . . . . . . . .12
Detergents and softeners . . . . . . . . .12
5 Selecting a Program and
Operating Your Machine 14
Control panel. . . . . . . . . . . . . . . . . . .14
Turning the machine on . . . . . . . . . . .15
Programselection . . . . . . . . . . . . . . .15
Spin Speed selection. . . . . . . . . . . . .16
Programselectionandconsumption
table . . . . . . . . . . . . . . . . . . . . . . . . .17
Auxiliary functions . . . . . . . . . . . . . . .18
StartingtheProgram . . . . . . . . . . . . .18
Progressingaprogram . . . . . . . . . . .18
Changing the program after the program
has started . . . . . . . . . . . . . . . . . . . .19
Child-proof lock. . . . . . . . . . . . . . . . .20
Ending the program through
canceling. . . . . . . . . . . . . . . . . . . . . .20
EndofProgram . . . . . . . . . . . . . . . . .20
6 Quick instructions for daily
use 21
7 Cleaning and care 23
Detergent drawer. . . . . . . . . . . . . . . .23
The door and the drum . . . . . . . . . . .23
Outercabinetandcontrolpanel. . . . .23
Inlet water filters. . . . . . . . . . . . . . . . .23
Draining any remaining water and
cleaning the pump filter . . . . . . . . . . .24
8 Solution suggestions for
problems 26

EN
4
1 - Detergent Drawer
2 - Door
3 - Top Lid
4-ControlPanel
5 - Filter Cap
6 - Height-adjustable feet
Overview
1Your Washing Machine
4
5
6
3
1
2

EN
5
Specifications
Specifications of this appliance may change without notice to improve the quality of
the product. Figures in this manual are schematic and may not match your product
exactly.
Values stated on the machine labels or in the documentation accompanying it are
obtained in laboratory in accordance with the relevant standards. Depending on
operational and environmental conditions of the appliance, values may vary.
Models
Maximumdrylaundrycapacity(kg)
Height(cm)
Width(cm)
Depth(cm)
NetWeight(±4kg)
Electricity(V/Hz.)
TotalCurrent(A)
TotalPower(W)
Spinningcycle(rpmmax.)
2012CXY
5
84
60
45
60
220-240 V / 50Hz
10
2000-2350
600

EN
6
Pleasereadthefollowinginformation.
Otherwise,theremaybetheriskof
personal injury or material damage.
Moreover,anywarrantyandreliability
commitment will become void.
General Safety
• Neverplaceyourmachineona
carpetcoveredfloor.Otherwise,
lack of airflow from below of your
machine may cause electrical
parts to overheat. This may cause
problems with your washing
machine.
• Ifthepowercableormainsplugis
damaged you must call Authorized
Service for repair.
• Checkwaterhosesforwear.Do
not use old/used water inlet hoses.
These may cause stains on your
laundry.
• Fitthedrainhoseintothedischarge
housing securely to prevent any
water leakage and to allow machine
to take in and discharge water as
required. It is very important that the
water intake and drain hoses are not
folded, squeezed, or broken when
the appliance is pushed into place
after it is installed or cleaned.
• Yourwashingmachineisdesigned
to continue operating in the event
ofapowerinterruption.Youcannot
cancel any program by pressing the
“On/Offbutton.”Yourmachinewill
not resume its program when the
powerrestores.Pressthe“Start/
Pause/Cancel”buttonfor3seconds
tocanceltheprogram(See,
CancellingaProgram)
• Theremaybesomewaterinyour
machine when you receive it. This is
from the quality control process and
is normal. It is not harmful to your
machine.
• Someproblemsyoumayencounter
may be caused by the software.
Press“Start/Pause/Cancel”button
for 3 seconds to cancel the program
set in your machine before calling
the authorized service.
First Use
• Toprepareyourmachinefor
washing, carry out your first washing
process without loading your
machine and with detergent under
“Cottons90°C”program.
• Ensurethatthecoldandhotwater
connections has been made
correctly when installing your
machine.Otherwise,yourlaundry
may come out hot at the end of the
washing process and may wear out.
• Ifthecurrentfuseorcircuitbreaker
is less than 16 Amperes, please
have a qualified electrician install a
16 Ampere fuse or circuit breaker.
• Whileusingwithorwithouta
transformer, do not neglect to have
the grounding installation laid by a
qualifiedelectrician.Ourcompany
shall not be liable for any damages
that may arise when the machine is
used on a line without grounding.
• Tomakeyourmachinereadyfor
use, please be sure that the tap
water supply and water drainage
systems are appropriate before
calling the authorized service. If they
2 Warnings

EN
7
are not, call a qualified plumber to
have any necessary arrangements
carried out.
Intended use
• Thisproducthasbeendesignedfor
home use.
• Theappliancemayonlybeusedfor
washing and rinsing of textiles that
are marked accordingly.
• Onlydetergents,softenersand
supplements suitable for washing
machines may be used.
• Observethecareinstructionslabelled
on textile products and any other
instructions given by companies that
produce detergents for your machine.
• Thisapplianceisnotintendedforuse
bypersons(includingchildren)with
reduced physical, sensory or mental
capabilities, or lack of experience
and knowledge, unless they have
been given supervision or instruction
concerning use of the appliance by a
person responsible for their safety.
Safety instructions
• Thisappliancemustbeconnectedto
an earthed outlet protected by a fuse
of suitable capacity.
• Thesupplyanddraininghosesmust
always be securely fastened and
remain in an undamaged state.
• Fitthedraininghosetoawashbasin
or bathtub securely before starting up
your machine. There may be a risk of
being scalded due to high washing
temperatures!
• Neveropenthedoororremovethe
filter while there is still water in the
drum.Otherwise,theremaybethe
risk of flooding and possible injury
due to the hot water.
• Neverforceopenthelockeddoor!
The door will be ready to open just a
few minutes after the washing cycle
comes to an end.
• Unplugthemachinewhenitisnotin
use.
• Neverwashdowntheappliance
with a water hose! There is the risk
of electric shock! Always disconnect
from the mains by unplugging before
cleaning.
• Nevertouchtheplugwithwethands.
Never unplug by pulling on the cable,
always pull out from the plug only. Do
not operate the machine if the power
cord or plug is damaged.
• Neverattempttorepairthemachine
yourself.Otherwise,youmaybe
putting yours and other’s lives in
danger.
• Formalfunctionsthatcannotbe
solved by information in the operating
manual:
Turn off the machine, unplug it, turn
off the water tap and contact an
authorized service agent.
If there are children
in your house...
• Electricalappliancesmaybe
dangerousforthechildren.Keep
children away from the machine
when it is operating. Do not let them
tamper with the machine.
• Closethedoorwhenyouleavethe
area where the machine is located.
• Storealldetergentsinasafeplace
out of reach of the children.

EN
8
Removing packaging
reinforcement
Tilt the machine to remove the
packaging reinforcement. Remove the
packaging reinforcement by pulling the
ribbon.
Opening the transportation
locks
CTransportation safety bolts must
be removed before operating the
washingmachine!Otherwise,the
machine will be damaged!
1. Loosen all the bolts with a spanner
untiltheyrotatefreely(“C”)
2. Remove transportation safety bolts
by turning them gently.
3. Fitthecovers(suppliedinthebag
withtheOperationManual)intothe
holesontherearpanel.(“P”)
C Keepthetransportationsafety
bolts in a safe place to reuse when
the washing machine needs to be
moved again in the future.
CNever move the appliance without
the transportation safety bolts
properly fixed in place!
Appropriate installation
location
Install the appliance in environments
which have no risk of freezing, in a
stable and level position.
CThe floor must be capable of
carrying the load on it!
C If the washing machine and a drier
are placed on top of each other, their
approximate weight together may
reach 180 kg when they are full.
Important:
• Donotplacetheapplianceontopof
the power cable.
• Keepatleast1cmdistancefromthe
edges of other furniture.
• Placethemachineonafirmsurface;
do not position it on a long pile rug
or such like surfaces.
Adjusting the feet
CDo not use any tools to loosen the
locknuts.Otherwise,theycanbe
damaged.
1.Manually(byhand)loosenthelock
nuts on the feet.
2. Adjust them until the machine stands
level and firm.
3.Important:Tightenalllocknutsup
again.
Connecting to the water
supply.
Important:
3Installation

EN
9
• Thewatersupplypressurerequired
to run the machine must be 1-10 bar
(0,1–1,0MPa).Attachapressure-
reducing valve if the water pressure
is higher.
• Connectthespecialhosessupplied
with the machine to the water intake
valves on the machine. The hose
bearingthe“red”sign(90°Cmax)
is the hot water inlet and the hose
bearingthe“blue”sign(25°Cmax)is
for the cold water inlet.
• Ifyouaregoingtouseyourdouble
water-inletmachineasasingle(cold)
water-inlet unit, you must install the
stopper*, supplied with your machine
to the hot water valve.
If you want to use both water inlets
of the product, you can connect the
hot water hose after removing the
stopper and gasket group from the
hot water valve.
* Applies for the products supplied
with a blind stopper group.
• Openthetapscompletelyafter
making the hose connection to
check if there is any water leakage
at the connection points. Turn off
the tap and remove the nut in case
of any leakage. Retighten the nut
carefully after checking the seal.
To prevent any water leakage and
any other damage to be caused by
it, keep the taps closed when the
machine is not in use.
• Modelswithasinglewaterinlet
should not be connected to the hot
water tap. Laundry may be damaged
or the appliance may switch to
protection mode and not work.
When returning the appliance to its
place after maintenance or cleaning,
care should be taken not to fold,
squeeze or block the hoses.
Connecting to the drain
The water discharge hose can be
attached to the edge of a washbasin or
bathtub. The drain hose should be firmly
fitted into the drain as to not loosen in
its housing.
Important:
• Theendofthedrainhosecanbe
directly connected to the wastewater
drain or to the washbasin. The
fitting must be secured in all types
ofconnections.Yourhousemaybe
flooded if the hose falls out of its
housing during water discharging.
• Thehoseshouldbeattachedtoa
height of at least 40 cm, and 100 cm
at most.
• Incasethehoseiselevated

EN
10
after laying it on the floor level or
closetotheground(lessthan
40cmabovetheground),water
discharge becomes more difficult
and the laundry may come out wet.
Therefore, the heights described in
the figure should be followed.
• Topreventdirtywaterrefillingthe
machine, and to allow for easy
discharge, the end of the hose must
not be submerged in the drain water.
The end of the hose must be able
to take in air. The hose should be
pushed into the drainage for more
than 15 cm. If it is too long you may
have it shortened.
• Theendofthehoseshouldnotbe
bent, it should not be stepped on
and it must not be folded between
the drain and the machine.
• Thelengthofthehoseistooshort,
you may add an extension hose to
the original section. The length of the
hose must not be longer than 3.2
m after coming out of the machine.
To avoid water leakage failures, the
connection between the extension
hose and the drain hose of the
product must be fitted well with an
appropriate clamp as not to come
off and leak.
Electrical connection
Connect the machine to an earthed
outlet protected by a fuse of suitable
capacity.
Important:
• Connectionshouldcomplywith
national regulations.
• Powercordplugmustbewithineasy
reach after installation.
• Thevoltageandtheallowedfuse
protection are specified in the
section“TechnicalSpecifications”.
• Thespecifiedvoltagemustbeequal
to your mains voltage.
• Connectionviaextensioncordsor
multi-plugs should not be made.
BA damaged power cable must be
replaced by a qualified electrician.
BThe appliance must not be operated
unless it is repaired! There is the risk
of electric shock!
Destroying the packaging
material
Packagingmaterialcanbedangerousto
children.Keepthepackagingmaterials
out of reach of children or dispose
them by classifying according to
waste directives. Do not dispose them
together with normal domestic waste.
Packagingmaterialsofyourmachineare
manufactured from recyclable materials.
Disposing of the old machine
Dispose of your old appliance in an
environmental friendly manner.
• Youmayrefertoyourlocalagentor
solid waste collection center in your
municipality to learn how to dispose
of your machine.
Before disposing of your old washing
machine, cut off the mains plug and
make the door lock unusable.

EN
11
Sorting the laundry
• Sortthelaundryaccordingtotypeof
fabric, colour, and degree of soiling
and permissible water temperature.
Always follow the advice on the
garment labels.
Suitable for
drier Do not dry with drier
Can be ironed
with hot iron Can be ironed with
warm iron
Dry on a
hanger
Do not iron
Washing water
temperature
Do not use
bleach
Bleach can be
used
Non machine
washable
Hang without
spinning
Do not
dry-clean
Dry
horizontally
Do not wash
Dry-cleanable
Wash with
sensitive, short
programmes.
Preparing clothes for washing
Laundry items with metal attachments
such as, bras, belt buckles and metal
buttons will damage the machine.
Remove metal attachments or place the
items in a clothing bag, pillow case, or
something similar.
• Emptypocketsandremoveall
foreign objects such as coins, pens
and paper clips. If possible, turn
pockets out and brush.
• Placesmallitemslikeinfants’socks
and nylon stockings, etc. in a laundry
bag, pillow case or something similar.
This will also save your laundry from
getting lost.
• Placecurtainsinthemachinewith
care. Remove curtain rails and
pullers.
• Fastenzippers,sewloosebuttons
and mend rips and tears.
• Wash“machinewashable”or“hand
washable”labelledproductsonly
withanappropriateProgramme.
• Donotwashcoloursandwhites
together. New, dark coloured cottons
may release a lot of dye. Wash them
separately.
• Toughstainsmustbetreated
properly before washing. If you are
not sure, check with a dry cleaner.
• Useonlydyes/colourchangersand
lime removers suitable for machine
wash. Always follow the instructions
on the packaging.
• Washtrousersanddelicateclothes
turned inside out.
• KeeplaundryitemsmadeofAngora
wool in the freezer for a few hours
before washing. This will reduce
pilling.
4Initial preparations for washing

EN
12
Correct load capacity
• Themaximumloadcapacity
depends on the type of laundry, the
degree of soiling and the washing
Programmeyouwishtouse.
CThe machine adjusts the amount of
water according to the amount of
laundry placed inside.
C Pleasefollowtheinformationin
the"ProgrammeSelectionTable".
Washing results will degrade when
the machine is overloaded.
Following weights are given as
examples.
Laundry type Weight(gr.)
Bathrobe 1200
Napkin 100
Duvet cover 700
Bed Sheet 500
Pillowcase 200
Tablecloth 250
Towel 200
Evening gown 200
Underclothing 100
Men’soveralls 600
Men’sshirt 200
Men’spyjamas 500
Blouse 100
Loading door
ThedoorislockedduringProgramme
operation. The door can be opened after
sometimefollowingtheProgramme
end.
• Openthedoor.
• Placelaundryitemslooselyinthe
machine.
• Pushthedooruntilitclicksinto
place tightly. Ensure that no items
are caught in the door.
Detergents and softeners
Detergent drawer
The detergent drawer is composed of
threecompartments:
The detergent dispenser may be in two
different types according to the model of
your machine.
-(I)forprewash
-(II)formainwash
-(III)siphon
–( )forsoftener
Detergent, softener and other
cleaning agents
Add detergent and softener before
startingthewashingProgramme.
Never open the detergent dispenser
drawerwhilethewashingProgrammeis
running!
WhenusingaProgrammewithout
pre-wash, no detergent should be
put into the pre-wash compartment
(Compartmentno.I).
AProgrammewithoutpre-washshould
be selected if a detergent bag or a
dispensing ball is going to be used.
Youcanplacethedetergentbagor
the dispensing ball directly among the
laundry in your machine.
Choosing the detergent type
The type of detergent to be used
depends on the type and colour of
fabric.
• Usedifferentdetergentsforcoloured
and white clothes.
• Washwoollenwithaspecial
detergent specifically for woollens.
• Useonlydetergentsmanufactured
specifically for automatic washing
machines.
Detergent quantity
The amount of washing detergent to
be used depends on the amount of
laundry, the degree of soiling and water
hardness.
• Donotuseamountsexceeding

EN
13
the quantities recommended on
the package to avoid problems
of excessive foam, poor rinsing,
financial savings and finally,
environmental protection.
• Usesmallamountsofdetergentata
suitable measure for small amounts
of laundry or for only slightly soiled
laundry.
• Useexactmeasuresforhighly
concentrated detergents.
Detergent
quantity
for prewashing 1/2 measure
for main washing 1 measure
with hard water an additional 1/2
measure
Softener
Putthesoftenerintothesoftener
compartment of the detergent dispenser.
• Usetheproportionsrecommended
on the packet.
• Neverexceedthe(>max<)level
marking;otherwise,thesoftenerwill
be wasted without being used.
• Ifthesoftenerhaslostitsfluidity,
dilute dense softener with water
before placing it in the detergent
drawer.
Liquid detergent
When using liquid or gel washing
detergents,pleasenotethefollowing:
• Theliquiddetergentmayleavestains
on your laundry if time delay feature
is selected.
• Donotuseliquiddetergentifyou
want to wash using the time delay
feature.
• Donotuseliquiddetergentforthe
main wash in a cycle with pre-wash.
• Usethedetergentmanufacturer’s
measuring cup and follow the
instructions on the package.
Starch
• Addliquidstarch,powderstarch
or the fabric dye into the softener
compartment as instructed on the
package.
• Neverusefabricsoftenerandstarch
together in the same washing cycle.
• Wipetheinsideofthedrumafter
using starch.
Eliminating lime formation
• Whenrequired,useonlyappropriate
lime removers developed specifically
for washing machines and always
follow the instructions on the
package.

EN
14
7 - On/OffButton
8 - Door Indicator *
9 - ProgramFollow-upIndicator
10 - SpinSpeedAdjustmentKnob*
11 - TemperatureAdjustmentKnob*
12 - ProgramSelectionKnob
13 - AuxiliaryFunctionKeys
14 - Start/Pause/CancelButton
* According to your machine’s model
Control panel
5Selecting a Program and Operating Your Machine
7
13
14
98 12

EN
15
Turning the machine on
Youcanpreparethemachinefor
program selection by pressing the
the“On/Off”button.Whenthe“On/
Off”buttonispressed,the“Lid”light
illuminates indicating that the door is
unlocked.Pressthe“On/Off”button
again to shut down the machine.
CPressingthe“On/Off”buttondoes
not necessarily mean that the
programhasstarted.Press"Start/
Pause/Cancel"buttontostartthe
program.
Program selection
Select the appropriate program from the
program table and the following washing
temperature table according to type,
amount and degree of soiling of the
laundry. Select the desired program with
the program selection button.
C Each of these main programmes
comprise of a complete washing
process, including washing, rinsing
and, if required, spin cycles.
90˚C
Normally soiled, white
cottonsandlinens.(Ex.:
coffee table covers,
tablecloths, towels, bed
sheets)
60˚C
Normally soiled, fade proof
colored linens, cottons
or synthetic clothes
(Ex.:shirts,nightgowns,
pajamas)andlightlysoiled
whitelinenclothes(Ex.:
underwear)
40˚C
30°C
Cold
Fordelicateclothes(Ex.:
lacecurtains),blended
clothes including synthetics
and woolens.
C Programsarelimitedwiththehighest
spin speed appropriate for that
particular type of cloth.
C Sort the laundry according to type
of fabric, color, degree of soiling and
permissible water temperature when
choosing a program.
C Always select the lowest required
temperature. Higher temperature
means higher power consumption.
C For further program details, see,
“ProgramSelectionTable”
Main programs
Depending on the type of textile, the
followingmainprogramsareavailable:
• Pamuklu (Cottons)
Youcanwashyourdurableclotheswith
this program. Washes with vigorous
washing movements in a longer
washing cycle. It is recommended for
yourcottonitems(suchasbedsheets,
duvet and pillowcase sets, bathrobes,
underclothing,etc.).
• Sentetik (Synthetics)
Youcanwashyourlessdurableclothes
on this program. Washes with gentler
washing movements and in shorter
washing cycles. It is recommended for
yoursyntheticclothes(suchasshirts,
blouses, synthetic/cotton blended
garments,etc.).Forcurtainsandlace,
usingthe“Synthetic40”programwith
pre-wash and anti-creasing functions
selected is recommended. Detergent
should not be put in the pre-wash
compartment. Less detergent should be
put in the main wash compartment as
looseknitfabrics(lace)foamtoomuch
due to its meshed structure.
• Yünlü (Woollens)
Youcanwashyourmachine-washable
woolen garments on this program. Wash
by selecting the proper temperature
according to the labels of your clothes.
It is recommended to use appropriate
detergents for woolens.
Additional programs
For special cases, there are also extra
programsavailable:
C Additional programs may differ
according to the features of your
machine.
• Narin (Delicate)
Youcanwashyourdelicateclothes
on this program. It has more sensitive
washing movements and does not

EN
16
make intermediate spinning compared
to the synthetic program. It must be
used for clothes for which sensitive
washing is recommended.
• Elde Yıkama (Hand wash)
Youcanwashyourwoolen/delicate
clothes that bear “not machine-
washable”labelsforwhichhandwash
is recommended on this program. It
washes the laundry with very tender
washing movements without damaging
your clothes.
• Mini 30
This program is used to quickly wash
(30minutes)asmallamountoflightly
soiled cotton garments.
• Eko 40
This program washes for a longer period
at 40°C and gives the same result as
the“Cottons60°C”program,thusit
saves energy. It is suitable for clothes for
which you cannot use the “Cottons 60
°C”program.
Special programs
For specific applications, you can select
anyofthefollowingprograms:
• Durulama (Rinse)
This program is used when you want to
rinse or starch separately.
• Sıkma+Pompa (Spin + Drain)
This program spins with maximum
possible rpm in the default setting after
the water drains from the machine.
C Youshouldusealowerspinspeed
for delicate laundries.
Spin Speed selection
Youcanhaveyourclothesspinat
the maximum rpm selection on your
machine by using the selection knob in
models equipped with an rpm selection
knob. In order to protect your clothes,
your machine will not spin above 800
rpm on synthetic programs and 600
rpm on woolens program. Furthermore,
if you want to skip the spin cycle and
take your clothes out, turn the rpm
selectionknobto“nospin”position.
In machines not equipped with a spin
speed selection knob, the machine will
spin in the maximum possible rpm in the
default setting of the selected program.

EN
17
Program selection and consumption table
•:Selectable
*:Automaticallyselected,notcancellable.
**:EnergyLabelprogramme(EN60456)
Water and power consumption and programme duration may differ from the table
shown, subject to changes in water pressure, water hardness and temperature,
ambient temperature, type and amount of laundry, selection of auxiliary functions,
and fluctuations in the supply voltage.
CThe auxiliary functions in the table may differ according to the model of your
machine.
EN 2Auxiliary functions
Programme
Max.Load(kg) ProgrammeDuration(~min) WaterConsumption(l) EnergyConsumption(kWh) ÖnYıkama İlave Durulama SudaBırakma Spin speed reduction No Spin No Heat
Pamuklu 90 5 133 45 1.65 ••••••
Pamuklu 60** 5 145 49 0.85 ••••••
Pamuklu 40 5 142 49 0.69 ••••••
Eko 40 40 5 165 45 0.78 •••
Sentetik 60 2.5 113 52 0.92 ••••••
Sentetik 40 2.5 125 52 0.56 ••••••
Narin 30 2 65 45 0.36 •••••
Yünlü 40 1.5 60 45 0.36 •••••
EldeYıkama 30 1 45 32 0.21 •••
Mini30 30 2.5 30 43 0.17 •••

EN
18
Auxiliary functions
Auxiliary function selection keys
• Desiredauxiliaryfunctiondepending
on the program is selected.
• Somecombinationscannotbe
selected together.
• Warningsignalontheselected
auxiliary function will light up.
Auxiliary function buttons may differ
according to the model of your machine.
Auxiliary function selection
If an auxiliary function that should not
be selected together with a previously
selected function is chosen, the first
selected function will be cancelled and
the last auxiliary function selection will
remain active.
Auxiliary function that is not compatible
with the program cannot be selected.
(see,“ProgramSelectionTable”)
• Ön Yıkama (Prewash)
A pre-wash is only worthwhile for heavily
soiled laundry. Without pre-wash you
save energy, water, detergent and time.
C Pre-washwithoutdetergentis
recommended for lace and curtains.
Less detergent should be put in the
main wash compartment as loose
knitfabrics(lace)foamtoomuchdue
to its meshed structure.
• İlave Durulama (Rinse Plus)
With this function, you can increase the
number of current rinsing steps. Thus,
sensitive skins’ risk of being affected by
the remainder detergent on the clothes
will be decreased.
• Suda Bırakma (Rinse Hold)
If you do not want to unload your
clothes immediately after the cotton,
synthetics, woolen and delicate fabrics
program, you may release your clothes
inside the machine in the last rinsing
water by pressing the rinse hold button
in order to prevent your clothes become
wrinkled. After this process you may
spin your laundry by pressing “Start/
Pause/Cancel”buttonoryoumayend
theprogrambypressing“Start/Pause/
Cancel”buttonfor3sec.
•In the machines equipped with spin
speed selection knob or button, you
can spin by selecting the desired
spinspeedandpress“Start/Pause/
Cancel”button.
•As for machines not equipped with
a spin speed selection knob, you
can end the program without a
spin cycle by pressing the “Start/
Pause/Cancel”buttonanddraining
the water. If you wish your clothes
be spun, you can spin them by
selecting“pump+spin”program.
• No Heat
If you wish to wash your clothes in cold
water, you can use this program.
• No Spin
Youmayusethisprogramifyoudonot
want to spin your clothes at the end of
cottons, synthetics, woolen or delicate
programs.
• Spin speed reduction
Youmayusethespeedreductionbutton
whenever you wish to spin your clothes
below the maximum spin speed. When
speed reduction button is pressed, spin
speed will be at the minimum rpm given
on the panel.
Starting the Program
1. Press“Start/Pause/Cancel”button
to start the program.
2. “Start/Pause/Cancel”buttonwilllight
up to indicate that the program has
started.
3. Thedoorislockedandthe“Lid”light
fades.
Progressing a program
Progressofarunningprogramisshown
through the program follow-up indicator.
•At the beginning of every program
step, the relevant indicator lamp will
light up and light of the completed
step will turn off. The symbol that is
lit up at the far right of the series of
symbols indicates the step that is
being carried out.
The“Wash”lightontheprogramfollow-

EN
19
up indicator illuminates when “Start/
Pause/Cancel”buttonispressedafter
selecting the washing program. The
“Programfinished”lampilluminates
andthe“Wash”lightwillfadewhenthe
programcomestoanend.The“Lid”
lightflashes.Meanwhile,thedoorwill
stay locked for your safety and when it
issafetoopen,the“Lid”and“Program
Finished”lightsremainon.
Youcanputyourmachineinto“Pause”
modebypressingthe“Start/Pause/
Cancel”buttonwhenitisoperating.
Inthiscase,the“Start/Pause/Cancel”
light will flash. Some changes in
program settings can be made in pause
mode(See.ChangingaProgram)
andif“Pause”modeisenteredatan
appropriate step of the program, the
adding laundry function may be used.
(See,Addingandtakingoutlaundry).
Press“Start/Pause/Cancel”button
againtoreturntothe“Wash”mode
from“Pause”mode.Inthiscasethe
“Start/Pause/Cancel”buttonwilllight
up continuously and the machine will
resume operating from the step it was
paused.
•If the machine is not spinning, the
program may be in rinse hold mode
or the automatic spin correction
system has been activated because
of unbalanced distribution of laundry
in the machine.
Changing the program after
the program has started
Youcanusethisfeatureafteryour
machine has started to wash different
textile groups in the same batch
of clothes under higher or lower
temperatures.
Forexample;
Pressandholdthe“Start/Pause/
Cancel”buttonfor3secondsto
“Cancel”theprograminordertoselect
“Cottons40”programinsteadof
“Cottons60”program.
Selectthe“Cottons40”programby
rotating the program knob.
Press“Start/Pause/Cancel”buttonto
start the program.
CThe program which is selected
first will go on even if the program
selection button is moved and
another program mode is selected
whilethemachineisoperating.You
must cancel the ongoing program
in order to change the washing
program.(See,CancelingaProgram)
Selecting or cancelling an auxiliary
function/temperature/spin speed
1. Pressthe“Start/Pause/Cancel”
button to switch the machine to
“Pause”mode.
2. Change the auxiliary function’s
temperature and spin speed.
Press“Start/Pause/Cancel”buttonto
start the program.
CThe selection to be made must be
appropriate. For example, if your
machine is on the main wash cycle,
you may select additional rinse
auxiliary function, but you cannot
select pre-wash.
CThe spin speed and temperature
which are selected first will keep on
being valid even if the position of the
spin speed or temperature selection
knobischanged.Pressthe“Start/
Pause/Cancel”buttonandswitch
themachineto“Pause”modein
order to change the spin speed or
temperature. New spin speed or
temperature can be selected.
Adding/removing laundry in standby
mode
If you want to add more laundry into the
machine after the washing cycle has
started,putthemachineinto“Pause”
modebypressingthe“Start/Pause/
Cancel”button.The“Lid”lamponthe
program follow-up indicator will light up
steadily after 1-2 minutes if the water
level in the machine is suitable. Laundry
may be added or taken out by opening
thedoor.Ifthe“Lid”lampdoesnot

EN
20
light up continuously at the end of this
time, the water level in the machine
is not suitable and laundry cannot be
added.Youcanresumetheprogram
bypressingthe“Start/Pause/Cancel”
button again.
Child-proof lock
There is a childproof lock to prevent
any program interruption because of
pressing the keys while the program is
on.
C Yourmachinecanbeturnedon
andoffwithOn/Offbuttonwhile
the child-proof lock is activated. In
this case, your machine will resume
its program with child-proof lock
activated.
In order to activate the childproof
lock, press on the 1st and 2nd
auxiliary function keys from the left
simultaneously for 3 seconds after
the washing program has started.
1st auxiliary function light will flash
continuously.
To start a new program after the
program is over or to interfere the
program, childproof lock should be
deactivated. To deactivate the child-
proof lock, press the same buttons for
3 sec.
Ending the program through
canceling
The program which is selected first will
keep on going even if the position of the
program selection button is changed. A
new program can be selected or started
after“Programiscancelled”inorderto
change the washing program.
Tocancelanyselectedprogram;
• Press“Start/Pause/Cancel”button
for 3 seconds. The machine starts
todischargethewater.“Wash”and
“ProgramFinished”lightswilllight
up.
• “Start/Pause/Cancel”and“Wash”
lights will go off after discharging
processisoverandthe“Lid”light
will start flashing.
• “Lid”lampwilllightupcontinuously
whenthedoorisunlocked.Youcan
select and start a new program.
• Iftheprogramiscancelledinthe
middleoftheprocess,“Wash”
and“ProgramFinished”lightswill
light up. The machine can drain
all the water or can take in water
for 3 times at most to cool down
the clothes and complete draining
process.
• Whenthewaterdischargingprocess
iscompleted,the“Wash”lightwill
gooff,“ProgramFinished”light
willlightupandthe“Lid”lightwill
continuously flash until the door
isunlocked.Youcanmakeanew
programselectionwhenthe“Lid”
light is illuminated continuously.
End of Program
The“ProgramFinished”lamponthe
program follow-up indicator will light up
when the program comes to an end.
The lid is unlocked 2 minutes later, the
“ProgramFinished”and“Lid”lampswill
light up continuously. The machine is
now ready for a second cycle.
If any key is pressed when the machine
is at the end of the program or if
the position of the selection knob is
changed,the“ProgramFinished”light
willgooffandonlythe“Lid”lampwill
remainaslit.Meanwhile,ifthedooris
stilllocked,the“Lid”lightwillcontinue
flashing until the door is opened.
Pressthe“On/Off”buttontoshutdown
the machine.
