Beko B5W51041AW User manual

Washing Machine
User Manual
B5W51041AW
2820529584_EN/ 28-06-21.(8:37)
Document Number:

9 / EN Washing Machine / User Manual
4Technical specifications
C
SUPPLIER’S NAME MODEL IDENTIFIER
A
A
(*)
The model information as stored in the product database can be reached by
entering following website and searching for your model identifier (*) found
on energy label.
https://eprel.ec.europa.eu/
Supplier name or trademark Beko
Model name B5W51041AW
7178542400
Rated capacity (kg) 10
Maximum spin speed (rpm) 1400
Built-in No
Height (cm) 84
Width (cm) 60
Depth (cm) 58
Single Water inlet / Double Water inlet • / -
• Available
Electrical input (V/Hz) 230 V / 50Hz
Total current (A) 10
Total power (W) 2200
Main model code 1321
AWARNING: Consumption values are applicable for cases where the wireless network connection is off.
Rinse Spin+Drain
Prewash Fast Fast+ Extra
Rinse
Extra
Water
Anti
Crease
Pet Hair
Removal
Rinse
Hold
No
Water
Drain
Soaking
Spin No
Spin
Tap
Water
(Cold)
Steam
Time
Delay
Night
Modu
Temperature Door
Lock
Child
Lock
On/Off Start /
Pause
Soil Level Add
Garment
AutoDose Liquid
Detergent
Selection
Softener
Selection
Wash
Downloaded
Program
Steeping
Ok
(End)
Cancel AntiCrease+ Iron
Dry
Cupboard
Dry
Extra
Dry
Timed
Drying
Clean&
Wear
Symbols Table
Drying

10 / EN Washing Machine / User Manual
4.1 Installation
APlease read the “Safety Instructions” section first!
• Apply to the nearest authorized service agent for the installation of your product.
• Preparation of the location and electrical, tap water and waste water installations at the place of installation
is under customer's responsibility.
• Make sure that the water inlet and discharge hoses as well as the power cable are not folded, pinched or
crushed while pushing the product into its place after installation or cleaning procedures.
• Make sure that the installation and electrical connections of the product are performed by authorized
service agent. Manufacturer shall not be held responsible for damages caused by operations performed by
unauthorized persons.
• Prior to installation, visually check if the product has any defects on it. Do not have it installed if the
appliance is damaged. Damaged products cause risks for your safety.
4.1.1 Appropriate installation location
• Place the product on a solid and level floor. Do not place it onto a carpet with high pile or other similar
surfaces. Inappropriate floor may cause problems of noise and vibration.
• Total weight of the washing machine and the dryer -with full load- when they are placed on top of each
other reaches to approx. 180 kilograms. Place the product on a solid and flat floor that has sufficient load
carrying capacity!
• Do not place the product on the power cable.
• Do not install the product at places where temperature may fall below 0ºC. Freezing might damage your
product.
• Leave a minimum space of 1 cm between the product and the furniture.
• If you will install the product on a surface with steps, never place it close to the edge.
• Do not place the product on any platform.
• Do not place heat sources such as Hobs, Irons, Ovens, etc. on the washing machine and do not use them
on the product.
4.1.2 Assembly of bottom panel covers
Cover A Tilt the machine back slightly. Rest the tabs of Cover A against the
lower panel. Complete the assembly by rotating the cover.
Cover B Rest the tabs of Cover B against the lower panel. Complete the
assembly by rotating the cover.

11 / EN Washing Machine / User Manual
Cap Insert the cap by pushing it with your finger.
4.1.3 Removing transportation safety bolts
1 Loosen all transportation safety bolts with an appropriate wrench until they turn freely.
2 Stretch the internal component by pressing on the holding areas and pull the component out.
3 Attach the plastic covers supplied in the User Manual bag into the holes on the rear panel.
WARNING Remove the transportation safety bolts before operating the product! Otherwise, the product will get damaged.
WARNING
Keep the transportation safety bolts in a safe place to reuse when the product needs to be moved again in the future.
Install the transportation safety bolts in reverse order of the disassembly procedure.
Never move the product without the transportation safety bolts properly fixed in place!
4.1.4 Connecting to water supply
WARNING
Models with a single water inlet shall not be connected to the hot water tap. In such a case the laundry will get damaged or
the product will switch to protection mode and will not operate.
Do not use old or used water inlet hoses on a new product. It may cause water leakage from your machine and stain your
laundry.
1 Tighten all hose nuts by hand Never use a tool when tightening the nuts.
2 Open the taps completely after making the hose connection to check for water leaks at the connection
points. If any leak occurs, turn off the tap and remove the nut. Check the gasket and tighten the nut
carefully again. In order to prevent the water leaks and resultant damages, keep the taps closed when
you do not use the product.

12 / EN Washing Machine / User Manual
4.1.5 Connecting the drain hose to the drain
• Attach the end of the drain hose directly to waste water drain, washbasin or bathtub.
AYour house will be flooded if the drain hose is dislocated during water draining. There is also a risk of burning due to the
high washing temperatures! In order to prevent such situations and make sure that the product performs water intake and
drain processes without any problem, fix the drain hose securely.
• Connect the drain hose to a minimum height of 40 cm and a maximum height of 100 cm.
• In case the drain hose is elevated after laying it on the floor level or close to the ground (less than 40 cm
above the ground), water draining becomes more difficult and the laundry may come out excessively wet.
Thus, follow the heights provided in the figure.
40 cm
100 cm
• To prevent the waste water to go back into the product again and to ensure easy drainage, do not immerse
the end of the hose into the waste water or do not insert it into the drain for more than 15 cm. If it is too
long, cut it short.
• The end of the hose should not be bent, it should not be stepped on and the hose must not be pinched
between the drain and the product. Otherwise, water discharge issues may emerge.
• If the length of the hose is too short, use it by adding an original extension hose. The length of the hose
shall not be longer than 3.2 m. To prevent water leaks, always secure the connection between the extension
hose and the drain hose of the product with a suitable clamp so that it does not come off and cause leaks.
4.1.6 Adjusting the feet
WARNING
In order to ensure that the product operates more silently and vibration-free, it must stand level and balanced on its feet.
Ensure that the product is balanced by adjusting the feet. Otherwise, the product may move from its place and cause
crushing, noise and vibration problems.
Do not use any tools to loosen the lock nuts. Otherwise, they will get damaged.
1 Loosen the lock nuts on the feet by hand.
2 Adjust the feet until the product stands level and balanced.
3 Tighten all lock nuts again by hand.

13 / EN Washing Machine / User Manual
4.1.7 Electrical connection
Connect the product to a grounded outlet protected by a 13 A fuse. Our company shall not be liable for any
damages that may arise when the product is used without grounding in accordance with the local regulations.
• Connection must comply with national regulations.
• The electrical connection cable infrastructure of the product must be adequate and suitable for product
requirements. It is recommended to use a residual current device.
• Power cable plug must be within easy reach after installation.
• If the current value of the fuse or breaker in the house is less than 13 Amps, have a qualified electrician
install a 13 Amp fuse.
• The voltage specified in the "Technical specifications" section must be equal to your mains voltage.
• Do not make connections via extension cables or multi-plugs. Overheating and burning may occur due to
the connecting cable.
ADamaged power cables should be replaced by the authorized service in order to prevent possible danger.
Electrical requirements
Before you insert the plug into the wall socket make sure that the voltage and the frequency shown in the
rating label corresponds to your electricity supply.
We recommend that this appliance be connected to the mains supply via a suitable switched and fused socket
in a readily accessible position.
Should the mains lead of the appliance become damaged or need replacing at any time, it must be replaced
by a special purpose made mains lead which can only be obtained from an Authorised Service Agent.
WARNING This appliance must be earthed
If the fitted moulded plug is not suitable for your socket, then the plug should be cut off and an appropriate
plug fitted.
Destroy the old plug, a cut off plug with a bare cord could cause a shock hazard if inserted into a socket
elsewhere in the house.
The moulded plug on this appliance incorporates a 13A fuse. Should the fuse need to be replaced an ASTA
approved BS1362 fuse of the same rating must be used. Do not forget to refit the fuse cover. In the event of
losing the fuse cover, the plug must not be used until a replacement fuse cover has been fitted. Colour of the
replacement fuse cover must be the same colour as that visible on the pin face of the plug. Fuse covers are
available from any good electrical store.
Important
Fitting a different plug
As the colours of the wires in the mains lead of this appliance may not
correspond with the coloured markings identifying the terminals on your
plug, proceed as follows:
1 Connect the green - yellow or green (earth) wire to the terminal in
the plug marked ‘E’ or with the symbol or coloured green and
yellow or green.
2 Connect the blue (neutral) wire to the terminal in the plug marked
‘N’ or coloured black.
3 Connect the brown (live) wire to the terminal in the plug marked ‘L’
or coloured red.
With the alternative plugs a 13A fuse must be fitted either in the plug or
adaptor or in the main fuse box. If in doubt contact a qualified electrician.

14 / EN Washing Machine / User Manual
Transportation of the product
1. Unplug the product before transporting it.
2. Remove water drain and water supply connections.
3. Drain all water that has remained in the product.
4. Install transportation safety bolts in the reverse order of removal procedure.
CNever move the product without the transportation safety bolts properly fixed in place!
WARNING Packaging materials are dangerous to children. Keep packaging materials in a safe place away from reach of the children.
4.1.8 Initial use
Before starting to use the product make sure that the preparations
described in section “Environmental instructions” and “Installation”.
To prepare the product for washing laundry, perform first operation
in Drum Cleaning programme. If this program is not available in your
product, apply the method which is described in section "Cleaning the
loading door and the drum".
CSome water has remained in the product due to the quality control processes in the production. It is not harmful for the
product.

15 / EN Washing Machine / User Manual
4.2 Preparation
APlease read the “Safety Instructions” section first!
4.2.1 Sorting the laundry
• Sort laundry according to type of fabric, colour, and degree of soiling and allowable water temperature.
• Always observe the instructions given on the garment care labels.
4.2.2 Preparing laundry for washing
• Laundry items with metal attachments such as, underwiring, belt buckles or metal buttons will damage the
product. Remove the metal pieces or wash such clothes by putting them in a laundry bag or pillow case.
• Take out all substances in the pockets such as coins, pens and paper clips, and turn pockets inside out and
brush. Such objects may damage the product or cause noise problem.
• Put small size clothes such as infant’s socks and nylon stockings in a laundry bag or pillow case.
• Place curtains in without compressing them. Remove curtain attachment items. Curtain attachment items
may cause pulling and tearing on the curtain.
• Fasten zippers, sew loose buttons and mend rips and tears.
• Wash “Machine washable” or “Hand washable” labelled products only with an appropriate programme.
• Do not wash colours and whites together. New, dark coloured cottons release a lot of dye. Wash them
separately.
• Tough stains must be treated properly before washing.
• Wash trousers and delicate laundry turned inside out.
• Laundry that are subjected to materials such as flour, lime dust, milk powder, etc. intensely must be shaken
off before placing into the product. Such dusts and powders on the laundry may build up on the inner parts
of the product in time and can cause damage.
4.2.3 Tips for energy and water saving
Following information will help you use the product in an ecological and energy/water-efficient manner.
• Operate the product in the highest load capacity allowed for the programme you have selected, but do not
overload. See “Programme and consumption table“.
• Observe the temperature instructions on the detergent packaging.
• Wash slightly soiled laundry at low temperatures.
• Use faster programmes for small quantities of lightly soiled laundry.
• Do not use prewash and high temperatures for laundry that is not heavily soiled or stained.
• If you plan to dry your laundry in a dryer, select the highest spin speed recommended during washing
process.
• Do not use more detergent than the recommended on the detergent packaging.
4.2.4 Loading the laundry
1 Open the loading door.
2 Put the laundry items into the product in a loose manner.
3 Push the loading door to close until you hear a locking sound. Ensure that no items are caught in the door.
The loading door is locked while a programme is running. The door lock will open immediately after the
washing programme has ended. Then you can open the loading door. If the door does not open, apply the
solutions provided for “Loading door cannot be opened.” error in the Troubleshooting section.
4.2.5 Correct load capacity
The maximum load capacity depends on the type of laundry, the degree of soiling and the desired washing
programme.
The product automatically adjusts the water amount according to the weight of the laundry put inside it.
CFollow the information in “programme and consumption table”. When overloaded, product’s washing performance will drop.
Moreover, noise and vibration problems may occur.

16 / EN Washing Machine / User Manual
4.2.6 Using detergent and softener
WARNING Read the manufacturer instructions on the package while using detergents, softeners, starch, bleach and decolourants, anti-
limescale and follow the dosage information provided. Use a measuring cup, if any.
1
3
2
The detergent drawer comprises of three compartments:
– (1) for prewashing
– (2) for main washing
– (3) for softener
– ( ) there is also a syphon piece in the softener compartment.
– ( ) there is also a liquid detergent apparatus for liquid detergent use
in the main washing compartment.
Detergent, softener and other cleaning agents
• Add detergent and softener before starting the washing programme.
• Do not leave the detergent drawer open when the washing program is on!
• If you are using a program without pre-washing, do not put detergent in the pre-washing compartment
(compartment no. “1”).
• Do not put liquid detergent in the pre-washing compartment (compartment no. “1”) in a program with pre-
washing.
• Do not select a program with pre-washing if you are using a detergent bag or dispensing ball. Place the
detergent bag or the dispensing ball directly among the laundry in the product.
• If you are using a liquid detergent, follow the directions under “Liquid detergent use” and do not forget to
bring the liquid detergent apparatus to the correct position.
Choosing the detergent type
Detergent type to be used depends on the washing programme, fabric type and colour.
• Use different detergents for coloured and white laundry.
• Wash your delicate clothes only with special detergents (liquid detergent, wool shampoo, etc.) intended
solely for delicate clothes and at suggested programmes.
• When washing dark coloured clothes and quilts, it is recommended to use liquid detergent.
• Wash woollens at suggested programme with special detergent made specifically for woollens.
• Please review the programme descriptions part for suggested programme for different textiles.
• All recommendations about detergents are valid for selectable temperature range of programmes.
AOnly detergents, softeners and additives suitable for washing machines should be used.
Do not use soap powder.
Adjusting the detergent amount
The amount of detergent depends on the amount of laundry, how soiled they are and the water hardness.
• Do not exceed the recommended dosage values on the detergent packaging in order to eliminate excessive
foam and poor rinsing problems, to save money and protect the environment.
• Use lesser amounts of detergent for fewer or less soiled laundry.
Using softeners
Put the softener in the softener compartment of the detergent drawer.
• Do not exceed the (>max<) level sign in the softener compartment.
• If the softener is not fluid, dilute with water before placing in the softener compartment.
WARNING Do not use liquid detergents or other materials with cleaning properties unless they are intended for use in washing
machines for softening the laundry.

17 / EN Washing Machine / User Manual
Using liquid detergents
If the product has a liquid detergent apparatus
• Press and rotate the apparatus at where it is shown when you want to use liquid detergents.
The part falling below will serve as a barrier for liquid detergent.
• Clean with water at its place or by removing from its place when it is necessary. Do not forget to place
the apparats in the main washing compartment (compartment no. “2”) after cleaning.
• The apparatus should be up if you will use a powder detergent.
Use of gel and tablet detergents
• If the detergent is fluid and there is no liquid detergent compartment in your product, place the gel
detergent in the main washing detergent compartment in first water intake. If your product has a liquid
detergent compartment, fill the compartment with detergent before starting the program.
• If the gel detergent is not fluid or is in a capsule liquid tablet, place directly inside the drum before washing.
• Put the tablet detergent in the main washing compartment (compartment no. “2”) or directly inside the
drum before washing.
Using starch
• Put in the liquid starch, powder starch or fabric dye in the softener compartment.
• Do not use softener and starch in the same washing program simultaneously.
• Wipe the inside of the product with a damp and clean cloth after using starch.
Using anti-limescale
• When necessary, only use anti-limescale produced for washing machines.
Using bleach and decolourants
• Select a program with pre-washing and add bleach at the start of pre-washing. Do not put detergent in the
pre-washing compartment. As an alternative application, select a program with additional rinsing and add
the bleach while the product is receiving water to the detergent compartment in the first rinsing step.
• Do not mix and use bleach and detergent together.
• As bleach may cause skin irritation use only small amounts (1/2 tea cups - approximately 50 ml and rinse
the laundry well.
• Do not pour bleach directly onto the laundry.
• Do not use bleach for coloured clothes.
• Select a program with low temperature washing while using oxygen-based decolourants.
• Oxygen-based decolourants can be used together with detergents. However, if it does not have the same
viscosity as the detergent, first place the detergent in compartment no. “2” in the detergent drawer and
wait for the product to rinse away the detergent during water intake. Add the decolourant to the same
compartment while the machine continues taking in water.

18 / EN Washing Machine / User Manual
4.2.7 Tips for efficient washing
Clothes
Light Colours and
Whites Colours Black/Dark Colours
Delicates/
Woollens/Silks
(Recommended temperature
range based on soiling level:
40-90 oC)
(Recommended temperature
range based on soiling level:
cold -40°C)
(Recommended
temperature range
based on soiling level:
cold -40°C)
(Recommended
temperature range
based on soiling level:
cold -30°C)
Soiling Level
Heavily Soiled
(difficult stains such
as grass, coffee, fruits
and blood.)
It may be necessary to pre-treat
the stains or perform prewash.
Powder and liquid detergents
recommended for whites can be
used at dosages recommended
for heavily soiled clothes. It is
recommended to use powder
detergents to clean clay and soil
stains and the stains that are
sensitive to bleaches.
Powder and liquid
detergents recommended
for colours can be used
at dosages recommended
for heavily soiled clothes.
It is recommended to use
powder detergents to clean
clay and soil stains and the
stains that are sensitive to
bleaches. Detergents which
do not contain bleach should
be used.
Liquid detergents
suitable for colours
and dark colours can
be used at dosages
recommended for
heavily soiled clothes.
Prefer liquid
detergents produced
for delicate clothes.
Woolen and silk
clothes must be
washed with special
woolen detergents.
Normally Soiled
(For example, stains
caused by body on
collars and cuffs)
Powder and liquid detergents
recommended for whites can be
used at dosages recommended
for normally soiled clothes.
Powder and liquid detergents
recommended for colours
can be used at dosages
recommended for normally
soiled clothes. Detergents
which do not contain bleach
should be used.
Liquid detergents
suitable for colours
and dark colours can
be used at dosages
recommended for
normally soiled clothes.
Prefer liquid
detergents produced
for delicate clothes.
Woolen and silk
clothes must be
washed with special
woolen detergents.
Lightly Soiled
(No visible stains
exist.)
Powder and liquid detergents
recommended for whites can be
used at dosages recommended
for lightly soiled clothes.
Powder and liquid detergents
recommended for colours
can be used at dosages
recommended for lightly soiled
clothes. Detergents which
do not contain bleach should
be used.
Liquid detergents
suitable for colours
and dark colours can
be used at dosages
recommended for
lightly soiled clothes.
Prefer liquid
detergents produced
for delicate clothes.
Woolen and silk
clothes must be
washed with special
woolen detergents.
4.2.8 Displayed Program Duration
You can view the programme duration on the display of your machine while selecting a programme.
Depending on the amount of laundry you have loaded into your machine, foaming, unbalanced load conditions,
fluctuations in power supply, water pressure and program settings, the programme duration is automatically
adjusted while the programme is running.
SPECIAL CASE: At programme start of Cottons and Cotton Eco programmes, display shows the duration
of half load. It is the most common use case. After programme starts, in 20-25 minutes actual load is
detected by the machine. And if the detected load is higher than half load; washing program will be adjusted
accordingly and program duration increased automatically. You may follow this change on the display.

19 / EN Washing Machine / User Manual
4.3 Operating the product
APlease read the “Safety Instructions” section first!
4.3.1 Control panel
1 - Programme Selection knob
2 - Temperature level lights
3 - Spin level indicator lights
4 - Display
5 - Start / Pause button
6 - Remote Control button.
7 - End Time Setting button
8 - Auxiliary Function button 3
9 - Auxiliary Function button 2
10 - Auxiliary Function button 1
11 - Spin speed adjustment button
12 - Temperature adjustment button
4.3.2 Display symbols
1200
1000
800
600
90
˚
60
˚
40
˚
30
˚
20
˚
a b c d e
f
h
g
ikl jno mpr
a- Temperature indicator
b- Spin speed indicator
c- Duration information
d - Door lock is engaged symbol
e- Programme follow-up indicator
f- No Water indicator
g - Add Garment indicator
h- Bluetooth Connection indicator
i- Remote Control indicator
j - Delayed Start Enabled indicator
k - Auxiliary Function indicators 3
l- Child Lock is Engaged symbol
m- Auxiliary Function indicators 2
n- Auxiliary Function indicators 1
o- No Spin Indicator
p- Rinse Hold Indicator
r- Cold Water indicator
CThe visuals used for machine description in this section are schematic and may not match exactly with the features of your
machine.
1 2 3 4
79 8101112 6 5

20 / EN Washing Machine / User Manual
4.3.3 Programme and consumption table
• : Selectable.
* : Automatically selected, cannot be cancelled.
*** : Eco 40-60 with 40 °C temperature selection is the test programme in accordance with EN 60456:2016/A11:2020 and
energy label with Commission Delegated Regulation (EU) 2019/2014
***** : These programmes can be used with the HomeWhiz application. Energy consumption may increase with connection.
- : See the programme description for maximum load.
EN 2Auxiliary functions
Programme
Max. Load (kg) Water Consumption (l) Energy Consumption (kWh) Max. Speed Fast+ Prewash Extra Rinse Steam Anti Crease+
Selectable temperature
range °C
Cottons
90 10 98 2,75 1400 • • • • • Cold - 90
60 10 98 2,00 1400 • • • • • Cold - 90
40 10 95 1,10 1400 • • •• • Cold - 90
Eco 40-60
40 *** 10 59 0,820 1400 40-60
40 *** 5 38 0,473 1400 40-60
40 *** 2,5 27 0,210 1400 40-60
Synthetics 60 4 76 1,60 1200 • • • • • Cold - 60
40 4 74 1,10 1200 • • • • • Cold - 60
Quick / Super Quick
90 10 75 2,30 1400 • • • • Cold - 90
60 10 75 1,30 1400 • • • • Cold - 90
30 10 75 0,25 1400 • • • • Cold - 90
Quick / Super Quick + Fast+ 30 2 45 0,15 1400 • • • • Cold - 90
Hand Wash 40 2 60 0,60 1200 • Cold - 40
Dark Care 40 4 86 1,05 1200 • • * • • Cold - 40
Drum Clean 90 - 80 2,60 600 * 90
Sports 40 4 60 0,65 1200 • Cold - 40
SteamTherapy - 1 1,1 0,11 - * -
StainExpert 60 5 86 1,85 1400 • • 30-60
Anti Allergy 90 9 125 3,00 1400 * * 20-90
Duvet 60 - 100 1,60 800 • • Cold - 60
Shirts 60 4 70 1,40 800 • • • * • Cold - 60
Downloaded Programme*****
Mix 40 4 83 1,10 800 • • • • Cold - 40
Soft Toys 40 2 80 0,90 600 * Cold - 40
Towel 60 1 115 1,60 800 * • Cold - 60
Curtain 40 2 98 0,90 800 • * Cold - 40

21 / EN Washing Machine / User Manual
CThe auxiliary functions in the table may vary according to the model of your machine.
Water and power consumption may vary subject to the changes in water pressure, water hardness and temperature, ambient
temperature, type and amount of laundry, selection of auxiliary functions and spin speed, and changes in electric voltage.
You can see the washing duration on the display of your machine while selecting a programme. Depending on the amount of laundry
you have loaded into your machine, there may be a difference of 1-1.5 hours between the duration shown on the display and the
actual duration of the wash cycle. Duration will be automatically updated soon after the washing starts.
"Selection patterns for auxiliary functions can be changed by the manufacturer company. New selection patterns can be added or removed."
"The spin speed of your machine may vary according to the programme; this spin speed cannot exceed the max. spin speed of your machine."
Always select the lowest appropriate temperature. The most efficient programmes in terms of energy consumption are generally
those that perform at lower temperatures and longer duration.
Noise and remaining moisture content are influenced by the spinning speed: the higher the spinning speed in the spinning phase,
the higher the noise and the lower the remaining moisture content.
Consumption Values (EN)
Temperature Selection (°C) Spin Speed (rpm) Capacity (kg) Programme Duration (hh:mm) Energy Consumption (kWh/cycle) Water Consumption (L/cycle) Laundry Temperature (°C) Remaining Moisture Content (%)
Eco 40-60
40 1400 10 03:58 0,820 59 38 53,9
40 1400 5 02:59 0,473 38 30 53,9
40 1400 2,5 02:59 0,210 27 24 53,9
Cottons 20 1400 10 03:40 0,750 95 20 53,9
Cottons 60 1400 10 03:40 2,000 98 60 53,9
Synthetics 40 1200 4 02:20 1,100 74 40 40
Quick / Super Quick 30 1400 10 00:28 0,250 75 23 62
The values given for programmes other than the eco 40-60 programme are indicative only.
4.3.4 Programme selection
1 Determine the programme suitable for the type, quantity and soiling level of the laundry in accordance with
"Programme and consumption table".
C
Programmes are limited with the highest spin speed appropriate for that particular type of fabric.
When selecting a programme, always consider the type of fabric, colour, degree of soiling and permissible water temperature.
2 Select the desired programme with the Programme Selection knob.

22 / EN Washing Machine / User Manual
4.3.5 Programmes
Aquatech Technology
This technology replaces some of the intensive drum movements during the washing process with the power
of water. It provides faster washing that is also gentler to your laundry, without compromising the washing
performance.
A mix of water and detergent is sprayed from the top of the drum when the drum is stationary. The point in
the cycle when this happens is optimised for each programme and will occur at different times on different
programmes. Generally, the special spraying system is activated at a point between 25 to 60 minutes into the
wash cycle, depending on the load and temperature selection. In certain programmes, the special spraying
system will be activated at the beginning of the cycle (3 to 10 min into the wash).
• Eco 40-60
The Eco 40-60 programme is able to clean normally soiled cotton laundry declared to be washable at 40 °C
or 60 °C, together in the same cycle, and that this programme is used to assess the compliance with the EU
ecodesign legislation.
Although it washes longer than all other programmes, it provides high energy and water savings. Actual water
temperature may be different from the stated wash temperature. When you load the machine with less laundry
(e.g. ½ capacity or less), periods in programme stages may automatically get shorter. In this case, energy and
water consumption will decrease.
• Cottons
You can wash your durable cotton laundry (sheets, bedlinen, towels, bathrobes, underwear etc.) in this
programme. When the quick wash function button is pressed, programme duration becomes notably shorter
but effective washing performance is ensured with intense washing movements. If the quick wash function is
not selected, superior washing and rinsing performance is ensured for your heavily soiled laundry.
• Synthetics
You can wash your laundry (such as shirts, blouses, synthetic/cotton blended fabrics etc.) in this programme.
The programme duration gets notable shorter and washing with high performance is ensured. If the quick wash
function is not selected, superior washing and rinsing performance is ensured for your heavily soiled laundry.
• Hand Wash
Use to wash your woollen/delicate laundry. Select the appropriate temperature complying with the tag of your
clothes. Your laundry will be washed with a very gentle washing action in order not to damage the clothes.
• Anti Allergy
Applying a steam step at the beginning of the programme allows to soften the dirt easily.
Use this programme for your laundry (baby clothes, bed sheets, bedlinen, underwear, etc. cotton items) that
requires an anti-allergic and hygienic washing at high temperature with intensive and long washing cycle. The
high level of hygiene is ensured thanks to the steam application before the programme, long heating duration
and additional rinsing step.
• Programme was tested by „The British Allergy Foundation„ (Allergy UK) with the 60°C temperature option
selected and it was certified in terms of its efficacy in eliminating allergens in addition to bacteria and mould.
Allergy UK is the brand of the British Allergy Association. Seal of Approval is created to
guide people that require recommendation about a product that the related product restricts
/ reduces / eliminates the allergens or reduces the allergen content significantly in the
ambient where allergy patients exist. It aims to provide assurance that the products are
tested scientifically or examined in a way to provide measurable results.
• Duvet
Use this programme to wash your fibre duvets that bear "machine washable" tag. Check that you have loaded
the duvet correctly in order not to damage the machine and the duvet. Remove the duvet cover before loading
the duvet into the machine. Fold the duvet into two and load it into the machine. Load the duvet into the
machine paying attention to place it in a way that it will not contact the bellow or the glass.

23 / EN Washing Machine / User Manual
Besides, use this programme to wash your coats, vest, jackets etc. containing feathers with a "machine-
washable" label on them.
C
Do not load more than 1 double fibre duvet (200 x 200 cm).
Do not wash your duvets, pillows and etc. that contain cotton in the machine.
A
WARNING: Do not use the washing machine to wash materials such as carpets, rugs etc. Permanent damage occurs
in the machine.
• SteamTherapy
Use this programme to reduce the creases and ironing times of a small amount of unspotted cotton, synthetic
or mixed laundry.
• Curtain
You can use this programme to wash your tulles and curtains. As their meshed texture causes excessive
foaming, put little amount of detergent into the main wash compartment. Thanks to the special spin profile of
the programme, tulles and curtains crease lesser. Do not load your curtains above the specified capacity in
order not to damage them.
C
It is recommended to use special detergents produced for curtains in the powder detergent compartment in this programme.
• Shirts
This programme is used to wash the shirts made from cotton, synthetic and synthetic blended fabrics altogether.
It reduces wrinkles. Steam is applied at the end of the programme to help the wrinkle reducing function. The
special spin profile and steam applied at the end of the programme reduce the wrinkles on your shirts. When the
quick wash function is selected, the Pre-treatment algorithm is executed.
• Apply the pre-treatment chemical on your garments directly or add it together with detergent when the
machine starts to take water from the main washing compartment. Thus, you can obtain the same performance
as you obtain with normal washing in a much shorter period of time. Usage life of your shirts increases.
• Quick / Super Quick
Use this programme to wash your lightly soiled or unspotted cotton clothes in a short time. The programme
duration can be reduced down to 14 minutes when the quick wash function is selected. When the quick wash
function is selected, maximum 2 (two) kg of laundry must be washed.
• Dark Care
Use this programme to protect the colour of your dark-coloured garments or jeans. It performs high performance
washing with special drum movement even if the temperature is low. It is recommended to use liquid detergent
or woollen shampoo for dark coloured laundry. Do not wash your delicate clothes containing wool or etc.
• Mix
Use to wash your cotton and synthetic clothes together without sorting them.
• Sports
You can use this programme to wash sports and outdoors garments that contain cotton/synthetics mix and
water repellent covers such as gore-tex etc. It makes sure your garments are washed gently thanks to special
rotating movements.
• StainExpert
The machine has a special stain programme which enables the removal of different types of stains in the most
effective way. Use this programme only for durable colourfast cotton laundry. Do not wash delicate and pigmenting
clothes and laundry in this programme. Before washing, garment tags should be checked (recommended for
cotton shirts, trousers, shorts, t-shirts, baby clothes, pyjamas, aprons, table clothes, bed sheets, duvet covers,
pillowcases, bath-beach towels, towels, socks, cotton underwear that are suitable for washing at high temperature
and long time). You can use automatic stain programme to wash 24 types of stains divided into three different
groups that can be selected with the “Quick Wash” setting button. Below you can find the soil groups that can
be selected with the “Quick Wash” setting button. Depending on the selected stain group, a special washing
programme for which duration of rinse hold, washing action, washing and rinsing duration are modified.

24 / EN Washing Machine / User Manual
Below you can find the soil groups that can be selected with the “Quick Wash” setting button:
When “Quick Wash” is not
selected
When the “Quick Wash” button
is pressed once
When the “Quick Wash” button
is pressed twice
Sweat Blood
Tea
Collar soil Chocolate
Coffee
Meal Pudding
Fruit juice
Mayonnaise Grass
Ketchup
Salad dressing Mud
Red wine
Make-up Egg
Starch
Machine oil Butter
Jam
Baby food Curry
Coal
• Select the stain programme.
• Select the stain you want to clean by locating it in the groups above and selecting the related group with the
quick auxiliary function button.
• Read the garment tag carefully and ensure that correct temperature and spin speed are selected.
• Downloaded Programme
This is a special programme that allows you to download different programmes when you want to. At the start,
there is a programme you can see with the HomeWhiz application as default. However, you can use the HomeWhiz
application to select a programme from the predetermined programme set, and then change and use it.
CIf you want to use HomeWhiz feature and Remote Control function, you must select Downloaded Programme. Detailed
information can be found in 4.3.15 HomeWhiz Feature and Remote Control Function.
• Soft Toys
Soft toys must be washed in a delicate programme due to their delicate fabrics, and the fibre and accessories
they contain. Thanks to its delicate washing movements and spinning profile, the soft toys programme protects
the toys during washing. It is recommended to use liquid detergent.
CFragile toys with hard surfaces must not be washed under any circumstances.
Toys must not be washed together with your garments since they may harm laundry.
• Towel
Use this programme to wash durable cotton laundry such as towels. Load the towels into the machine paying
attention to place them in a way that they will not contact the bellow or the glass.
4.3.6 Temperature selection
-
-
-
-
-
-
Whenever a new programme is selected, the recommended temperature for the programme appears on the temperature
indicator. It is possible that the recommended temperature value is not the maximum temperature that can be selected for the
current programme.

25 / EN Washing Machine / User Manual
Press the Temperature Adjustment button to change the temperature. Temperature decreases gradually.
CNo change can be made in programmes where temperature adjustment is not allowed.
You can also change the temperature after the washing starts. This change can be made if the washing steps
allow it. Changes cannot be made if the steps do not allow it.
CIf you scroll to cold wash option and press Temperature Adjustment button again, the recommended maximum temperature
for the selected programme appears on the display. Press the Temperature Adjustment button again to decrease the
temperature.
4.3.7 Spin speed selection
-
-
-
-
-
-
Whenever a new programme is selected, the recommended spin speed of the selected programme is
displayed on the Spin Speed indicator.
CIt is possible that the recommended spin speed value is not the maximum spin speed that can be selected for the current
programme.
Press the Spin Speed Adjustment button to change the spin speed. Spin speed decreases gradually.
Then, depending on the model of the product, "Rinse Hold " and "No Spin " options appear on the display.
If you are not going to unload your laundry immediately after the programme completes, you can use Rinse
Hold function in order to prevent them from getting wrinkled when there is no water in the machine.
This function holds the laundry in the final rinsing water.
If you want to spin your laundry after the Rinse Hold function:
- Adjust the Spin Speed.
- Press Start / Pause / Cancel. The programme will resume. Machine drains the water and spins the laundry.
If you want to drain the water at the end of the programme without spinning, use No Spin function.
CNo change can be made in programmes where spin speed adjustment is not allowed.
You can change the spin speed after the washing starts if the washing steps allow it. Changes cannot be
made if the steps do not allow it.
Rinse hold
If you are not going to unload your clothes immediately after the programme completes, you can use rinse
hold function to keep your laundry in the final rinsing water in order to prevent them from getting wrinkled
when there is no water in the machine. Press Start / Pause button after this process if you want to drain the
water without spinning your laundry. Programme will resume and complete after draining the water.
If you want to spin the laundry held in water, adjust the Spin Speed and press Start / Pause button.
The programme will resume. Water is drained, laundry is spun and the programme is completed.
4.3.8 Auxiliary function selection
-
-
-
-
-
-

26 / EN Washing Machine / User Manual
Select the desired auxiliary functions before starting the programme. Whenever a programme is selected,
icons of the auxiliary function symbol that is selected together with it illuminates.
CWhen an auxiliary function button that cannot be selected with the current programme is pressed, the washing machine will
make a warning sound.
Some functions cannot be selected together. If a second auxiliary function conflicting with the first one is selected before
starting the machine, the function selected first will be cancelled and the second auxiliary function selection will remain
active. For example, if you want to select Quick Wash after you have selected the Additional Water, Additional Water will be
cancelled and Quick Wash will remain active.
An auxiliary function that is not compatible with the programme cannot be selected. (See "Programme and consumption table")
Some programmes have auxiliary functions that must be operated simultaneously. Those functions cannot be cancelled. The
frame of the auxiliary function will not be illuminated, only inner area will be illuminated.
4.3.8.1 Auxiliary functions
• Prewash
A Prewash is only worthwhile for heavily soiled laundry. Not using the Prewash will save energy, water,
detergent and time.
• Fast+
After selecting a programme, you can press the Quick Wash setting key to shorten the programme duration.
For some programmes, the duration can shorten by over 50%. Despite this, the washing performance is good
thanks to the changed algorithm.
Although it varies in each programme, when you press the Quick Wash key once, the programme duration
decreases to a certain level, and when you press the same key for the second time, it drops to the minimum level.
For a better washing performance, do not use the Quick Wash setting key when washing heavily soiled laundry.
Shorten the programme duration by using the Quick Wash key for Moderately and Slightly soiled laundry.
• Steam
This function helps reduc ing the wrinkles on your cotton, synthetic and mixed laundry, shortening the ironing
times, and removing the stains by softeningthem.
*Your laundry may be hotter at the end of the washing cycle when the steam function is applied at the end of
the programme. This is an expected condition within the operating conditions of the programme.
C
When you activate the steam function, do not use liquid detergent if the product does not have a liquid detergent cup or liquid
dosing function. Otherwise, stains might remain on the clothes.
• Remote Control
You can use this auxiliary function key to connect your product to smart devices. For detailed information, see
4.3.15 HomeWhiz Feature and Remote Control Function.
• Customized Programme
This auxiliary function can only be used for Cotton and Synthetics programmes together with the HomeWhiz
application. When this auxiliary function is activated, you can add up to 4 auxiliary rinsing steps to the
programme. You can select and use some auxiliary functions even though they are not found on your product.
You can increase and decrease the time of the Cottons and Synthetics programmes within a safe range.
CWhen the Customized Programme auxiliary function is selected, the washing performance and energy consumption will be
different than the declared value.

27 / EN Washing Machine / User Manual
4.3.8.2 Functions/Programmes Selected by Pressing the Function Keys for 3 Seconds
• Drum Clean
Press and hold the auxiliary function button 1 for 3 seconds to select the programme. Use regularly (once in
every 1-2 months) to clean the drum and provide the required hygiene. Steam is applied before the programme
to soften the residues in the drum. Operate the programme while the machine is completely empty. To obtain
better results, put powder lime-scale remover for washing machines into the detergent compartment no. „2“.
When the programme is over, leave the loading door ajar so that the inside of the machine gets dry.
CThis is not a washing programme. It is a maintenance programme.
Do not run the programme when there is something in the machine. If you try to do so, the machine detects that there is
load inside and aborts the programme.
• Anti Crease+
This function is selected when the spin selection button is pressed and held for 3 seconds and the programme
follow-up light for the relevant step turns on. When the function is selected, the drum rotates for up to 8 hours
for preventing the laundry from creasing at the end of the programme. You can cancel the programme and take
your laundry out at any time during the 8-hour duration. Press the function selection key or the machine on/off
key to cancel the function. The programme follow-up light will remain on until the function is cancelled or the
step is complete. If the function is not cancelled, it will be active in the subsequent washing cycles as well.
• Extra Rinse
This function is selected when the auxiliary function button 2 is pressed and held for 3 seconds.
This function enables the product to make another rinsing in addition to the one already made after the main
wash. Thus, the risk for sensitive skins (babies, allergic skins, etc.) to be effected by the minimal detergent
remnants on the laundry can be reduced.
• Child lock
Use Child Lock function to prevent children from tampering with the machine. Thus you can avoid any changes
in a running programme.
CYou can switch on and off the machine with On / Off button when the Child Lock is active. When you switch on the machine
again, programme will resume from where it has stopped.
When the Child Lock is enabled, an audio warning will be given if the buttons are pressed. Audio warning will be cancelled if
the buttons are pressed five times consecutively.
To activate the Child Lock:
Press and hold Auxiliary Function button 3 for 3 seconds. After the countdown as “3-2-1" on the
display is over, child lock symbol appears on the display. When this warning is displayed, you can release the
Auxiliary Function button 3.
To deactivate the Child Lock:
Press and hold Auxiliary Function button 3 for 3 seconds. After the countdown as “3-2-1" on the display
is over, child lock symbol disappears.
• Bluetooth 3’’
You can use the bluetooth connection function to pair your machine with your smart device. This way, you can use your smart
device to get information about your machine and control it.
To activate bluetooth connection:
Press and hold Remote Control function button for 3 seconds. Countdown “3-2-1” will be displayed,
and then Bluetooth icon will appear on the display. Release Remote Control function button. The bluetooth
icon will flash while the product is pairing with smart device. If connection is successful, icon will remain on.
