Beko WMB 510211 DS User manual

WMB 510211 DS
WMB 508211 DS
WMB 508211 D
WMB 510211 D
Washing Machine
User’s Manual
2820522988_EN/170512.0844

Please read this user manual first!
Dear Customer,
Thank you for prefering an Beko product. We hope that you get the best results from your product which
has been manufactured with high quality and state-of-the-art technology. Therefore, please read this
entire user manual and all other accompanying documents carefully before using the product and keep it
as a reference for future use. If you handover the product to someone else, give the user manual as well.
Follow all warnings and information in the user manual.
Remember that this user manual is also applicable for several other models. Differences between models
will be identified in the manual.
Explanation of symbols
Throughout this user manual the following symbols are used:
CImportant information or useful hints
about usage.
AWarning for hazardous situations with
regard to life and property.
BWarning for electric shock.
Packaging materials of the product are
manufactured from recyclable materials
in accordance with our National
Environment Regulations.
Do not dispose of the packaging materials together with the domestic or other wastes. Take them to the
packaging material collection points designated by the local authorities.

Washing Machine / User‘s Manual 3/ 36 EN
TABLE OF CONTENTS
1 Important instructions for safety and
environment 4
1.1 General safety . . . . . . . . . . . . . . . . . . . . . . . 4
1.2 Intended use . . . . . . . . . . . . . . . . . . . . . . . .4
1.3 Children's safety. . . . . . . . . . . . . . . . . . . . . .5
1.4 Package information. . . . . . . . . . . . . . . . . . .5
1.5 Disposing of the waste product . . . . . . . . . . .5
1.6 Compliance with WEEE Directive . . . . . . . . . .5
2 Your washing machine 6
2.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . .6
2.2 Package Contents . . . . . . . . . . . . . . . . . . . .7
2.3 Technical specifications . . . . . . . . . . . . . . . .8
3 Installation 9
3.1 Appropriate installation location. . . . . . . . . . .9
3.2 Removing packaging reinforcement . . . . . . .9
3.3 Removing the transportation locks. . . . . . . . .9
3.4 Connecting water supply. . . . . . . . . . . . . . .10
3.5 Connecting to the drain. . . . . . . . . . . . . . . .11
3.6 Adjusting the feet . . . . . . . . . . . . . . . . . . . .11
3.7 Electrical connection. . . . . . . . . . . . . . . . . .12
4 Preparation 13
4.1 Sorting the laundry . . . . . . . . . . . . . . . . . . .13
4.2 Preparing laundry for washing. . . . . . . . . . .14
4.3 Things to be done for energy saving . . . . . .14
4.4 Initial use . . . . . . . . . . . . . . . . . . . . . . . . . .14
4.5 Correct load capacity . . . . . . . . . . . . . . . . .15
4.6 Loading the laundry . . . . . . . . . . . . . . . . . .15
4.7 Using detergent and softener . . . . . . . . . . .15
4.8 Tips for efficient washing . . . . . . . . . . . . . .18
5 Operating the product 19
5.1 Control panel . . . . . . . . . . . . . . . . . . . . . . .19
5.2 Preparing the machine . . . . . . . . . . . . . . . .20
5.3 Programme selection . . . . . . . . . . . . . . . . .20
5.4 Main programmes . . . . . . . . . . . . . . . . . . .20
5.5 Additional programmes . . . . . . . . . . . . . . .20
5.6 Special programmes. . . . . . . . . . . . . . . . . .21
5.7 Temperature selection. . . . . . . . . . . . . . . . .21
5.8 Spin speed selection. . . . . . . . . . . . . . . . . .21
5.9 Programme and consumption table. . . . . . .22
5.10 Auxiliary function selection . . . . . . . . . . . .23
5.11 Starting the programme . . . . . . . . . . . . . .24
5.12 Child Lock . . . . . . . . . . . . . . . . . . . . . . . .24
5.13 Progress of programme . . . . . . . . . . . . . .25
5.14 Loading door lock. . . . . . . . . . . . . . . . . . .25
5.15 Changing the selections after programme
has started . . . . . . . . . . . . . . . . . . . . . . .25
5.16 Canceling the programme. . . . . . . . . . . . .25
6 Quick User Guide 26
6.1 Preparing the machine . . . . . . . . . . . . . . . .26
6.2 Programme selection . . . . . . . . . . . . . . . . .26
6.3 Auxiliary function selection . . . . . . . . . . . . .26
6.4 Starting the programme . . . . . . . . . . . . . . .26
6.5 Canceling the programme. . . . . . . . . . . . . .26
7 Maintenance and cleaning 27
7.1 Cleaning the detergent drawer . . . . . . . . . .27
7.2 Cleaning the loading door and the drum . . .27
7.3 Cleaning the body and control panel . . . . . .28
7.4 Cleaning the water intake filters . . . . . . . . .28
7.5 Draining remaining water and cleaning the
pump filter. . . . . . . . . . . . . . . . . . . . . . . .28
8 Troubleshooting 30

4/ 36 EN Washing Machine / User‘s Manual
1 Important instructions for safety and environment
This section contains safety instructions that will
help protect from risk of personal injury or property
damage. Failure to follow these instructions shall
void any warranty.
1.1 General safety
•Thisproductcanbeusedbychildrenatand
above 8 years old and by persons whose
physical, sensory or mental capabilities were
not fully developed or who lack experience and
knowledge provided that they are supervised or
trained on the safe usage of the product and the
risks it brings out. Children must not play with
the product. Cleaning and maintenance works
should not be performed by children unless they
are supervised by someone.
•Neverplacetheproductonacarpet-covered
floor. Otherwise, lack of airflow beneath the
machine will cause electrical parts to overheat.
This will cause problems with your product.
•Iftheproducthasafailure,itshouldnotbe
operated unless it is repaired by the Authorized
Service Agent. There is the risk of electric shock!
•Thisproductisdesignedtoresumeoperating
in the event of powering on after a power
interruption. If you wish to cancel the
programme, see "Cancelling the programme"
section.
•Connecttheproducttoagroundedoutlet
protected by a 16 A fuse. Do not neglect to have
the grounding installation made by a qualified
electrician. Our company shall not be liable for
any damages that will arise when the product is
used without grounding in accordance with the
local regulations.
•Thewatersupplyanddraininghosesmustbe
securely fastened and remain undamaged.
Otherwise, there is the risk of water leakage.
•Neveropentheloadingdoororremovethefilter
while there is still water in the drum. Otherwise,
risk of flooding and injury from hot water will
occur.
•Donotforceopenthelockedloadingdoor.
The loading door will be ready to open just a
few minutes after the washing cycle comes to
an end. In case of forcing the loading door to
open, the door and the lock mechanism may get
damaged.
•Unplugtheproductwhennotinuse.
•Neverwashtheproductbyspreadingorpouring
water onto it! There is the risk of electric shock!
•Nevertouchtheplugwithwethands!Never
unplug by pulling on the cable, always pull out
by grabbing the plug.
•Usedetergents,softenersandsupplements
suitable for automatic washing machines only.
•Followtheinstructionsonthetextiletagsandon
the detergent package.
•Theproductmustbeunpluggedduring
installation, maintenance, cleaning and repairing
procedures.
•Alwayshavetheinstallationandrepairing
procedures carried out by the Authorized
Service Agent. Manufacturer shall not be
held liable for damages that may arise from
procedures carried out by unauthorized persons.
•Ifthesupplycordisdamaged,itmustbe
replaced by the manufacturer, its service agent
or similary qualified persons in order to avoid a
hazard.
•Ifthepowercableisdamaged,itmustbe
replaced by the manufacturer, after sales service
or a similarly qualified person (preferably an
electrician) or someone designated by the
importer in order to avoid possible risks.
1.2 Intended use
•Thisproducthasbeendesignedfordomestic
use. It is not suitable for commercial use and it
must not be used out of its intended use.
•Theproductmustonlybeusedforwashingand
rinsing of laundry that are marked accordingly.
•Themanufacturerwaivesanyresponsibility
arisen from incorrect usage or transportation.
•Theservicelifeofyourproductis10years.
During this period, original spare parts will be
available to operate the appliance properly.

Washing Machine / User‘s Manual 5/ 36 EN
Important instructions for safety and environment
1.3 Children's safety
•Packagingmaterialsaredangeroustochildren.
Keep packaging materials in a safe place away
from reach of the children.
•Electricalproductsaredangerousforthe
children. Keep children away from the product
when it is in use. Do not let them to tamper with
the product. Use child lock to prevent children
from intervening with the product.
•Donotforgettoclosetheloadingdoorwhen
leaving the room where the product is located.
•Storealldetergentsandadditivesinasafeplace
away from the reach of the children by closing
the cover of the detergent container or sealing
the detergent package.
1.4 Package information
•Packagingmaterialsoftheproductare
manufactured from recyclable materials in
accordance with our National Environment
Regulations. Do not dispose of the packaging
materials together with the domestic or other
wastes. Take them to the packaging material
collection points designated by the local
authorities.
1.5 Disposing of the waste product
•Thisproducthasbeenmanufacturedwithhigh
quality parts and materials which can be reused
and are suitable for recycling. Therefore, do
not dispose the product with normal domestic
waste at the end of its service life. Take it to a
collection point for the recycling of electrical
and electronic equipment. Please consult your
local authorities to learn the nearest collection
point. Help protect the environment and natural
resources by recycling used products. For
children's safety, cut the power cable and break
the locking mechanism of the loading door so
that it will be non-functional before disposing of
the product.
1.6 Compliance with WEEE Directive
This appliance’s packaging material is
recyclable. Help recycle it and protect
the environment by dropping it off in
the municipal receptacles provided for
this purpose. Your appliance also
contains a great amount of recyclable
material. It is marked with this label to indicate the
used appliances that should not be mixed with
other waste. This way, the appliance recycling
organised by your manufacturer will be done under
the best possible conditions, in compliance with
European Directive 2002/96/EC on Waste
Electrical and Electronic Equipment. Contact your
town hall or your retailer for the used appliance
collection points closest to your home. We thank
you doing your part to protect the environment.

6/ 36 EN Washing Machine / User‘s Manual
2 Your washing machine
2.1 Overview
7
3
4
6
5
2
1
8
1- Power cable
2- Top panel
3- Control panel
4- Filter cap
5- Adjustable feet
6- Loading door
7- Detergent drawer
8- Drain hose

Washing Machine / User‘s Manual 7/ 36 EN
Your washing machine
2.2 Package Contents
1
2
3 4
a b c
5
6
7
1- Power cable
2- Drain hose
3- Transportation safety bolts *
4- Mains water inlet hose (One of the following filter types is used for the mains hose connection.)
a- Electronical water shut-off
a- Mechanical water shut-off
c- Standard
5- Liquid detergent container**
6- User Manual
7- Blind plug***
* Number of transportation safety bolts may change depending on the model of your machine.
** This may be supplied with the machine depending on the model of your machine.
*** This is supplied if your machine is equipped with double water inlet.

8/ 36 EN Washing Machine / User‘s Manual
Your washing machine
WMB 510211 DS WMB 510211 D WMB 508211 DS WMB 508211 D
55 5 5
84 84 84 84
60 60 60 60
45 45 45 45
59 59 59 59
220-240 V / 50Hz
10 10 10 10
2000-2350
1000 1000 800 800
1.35 1.35 1.35 1.35
0.25 0.25 0.25 0.25
929 929 929 929
-/• -/• -/• -/•
2.3 Technical specifications
CTechnical specifications may be changed without prior notice to improve the quality of the product.
CFigures in this manual are schematic and may not match the product exactly.
CValues stated on the product labels or in the documentation accompanying it are obtained in laboratory
conditions in accordance with the relevant standards. Depending on operational and environmental
conditions of the product, these values may vary.
Models (EN)
Maximum dry laundry capacity (kg)
Height (cm)
Width (cm)
Depth (cm)
Net weight (±4 kg.)
Electrical input (V/Hz)
Total current (A)
Total power (W)
Spin speed (rpm max.)
Stand-by mode power (W)
Off-mode power (W)
Main model code
Single Water inlet / Double Water inlet
•Available

Washing Machine / User‘s Manual 9/ 36 EN
3 Installation
Refer to the nearest Authorised Service Agent for
installation of the product. To make the product
ready for use, review the information in the user
manual and make sure that the electricity, tap
water supply and water drainage systems are
appropriate before calling the Authorized Service
Agent. If they are not, call a qualified technician
and plumber to have any necessary arrangements
carried out.
CPreparation of the location and electrical,
tap water and waste water installations
at the place of installation is under
customer's responsibility.
BWARNING: Installation and electrical
connections of the product must be
carried out by the Authorized Service
Agent. Manufacturer shall not be held
liable for damages that may arise from
procedures carried out by unauthorized
persons.
AWARNING: Prior to installation, visually
check if the product has any defects on
it. If so, do not have it installed. Damaged
products cause risks for your safety.
CMake sure that the water inlet and
discharge hoses as well as the power
cable are not folded, pinched or crushed
while pushing the product into its place
after installation or cleaning procedures.
3.1 Appropriate installation location
•Placethemachineonarigidfloor.Donotplace
it on a long pile rug or similar surfaces.
•Totalweightofthewashingmachineandthe
dryer -with full load- when they are placed
on top of each other reaches to approx. 180
kilograms. Place the product on a solid and flat
floor that has sufficient load carrying capacity!
•Donotplacetheproductonthepowercable.
•Donotinstalltheproductatplaceswhere
temperature may fall below 0ºC.
•Placetheproductatleast1cmawayfromthe
edges of other furniture.
3.2 Removing packaging
reinforcement
Tilt the machine backwards to remove the
packaging reinforcement. Remove the packaging
reinforcement by pulling the ribbon.
3.3 Removing the transportation locks
AWARNING: Do not remove the
transportation locks before taking out the
packaging reinforcement.
AWARNING: Remove the transportation
safety bolts before operating the washing
machine! Otherwise, the product will be
damaged.
1. Loosen all the bolts with a suitable spanner until
they rotate freely (C).
2. Remove transportation safety bolts by turning
them gently.

10 / 36 EN Washing Machine / User‘s Manual
Installation
3. Attach the plastic covers supplied in the User
Manual bag into the holes on the rear panel. (P)
CKeep the transportation safety bolts in
a safe place to reuse when the washing
machine needs to be moved again in the
future.
CNever move the product without the
transportation safety bolts properly fixed
in place!
3.4 Connecting water supply
CThe water supply pressure required to run
the product is between 1 to 10 bars (0.1
– 1 MPa). It is necessary to have 10 – 80
liters of water flowing from the fully open
tap in one minute to have your machine run
smoothly. Attach a pressure reducing valve
if water pressure is higher.
CIf you are going to use the double water-
inlet product as a single (cold) water-inlet
unit, you must install the supplied stopper
to the hot water valve before operating the
product. (Applies for the products supplied
with a blind stopper group.)
AWARNING: Models with a single water
inlet should not be connected to the hot
water tap. In such a case the laundry will
get damaged or the product will switch to
protection mode and will not operate.
AWARNING: Do not use old or used water
inlet hoses on the new product. It may
cause stains on your laundry.
1. Connect the special hoses supplied with the
product to the water inlets on the product. Red
hose (left) (max. 90 ºC) is for hot water inlet,
blue hose (right) (max. 25 ºC) is for cold water
inlet.
AWARNING: Ensure that the cold and hot
water connections are made correctly when
installing the product. Otherwise, your
laundry will come out hot at the end of the
washing process and wear out.
2. Tighten all hose nuts by hand. Never use a tool
when tightening the nuts.
3. Open the taps completely after making the
hose connection to check for water leaks at
the connection points. If any leaks occur, turn
off the tap and remove the nut. Retighten the
nut carefully after checking the seal. To prevent
water leakages and damages caused by them,
keep the taps closed when the machine is not in
use.

Washing Machine / User‘s Manual 11 / 36 EN
Installation
3.5 Connecting to the drain
•Theendofthedrainhosemustbedirectly
connected to the wastewater drain or to the
washbasin.
AWARNING: Your house will be flooded
if the hose comes out of its housing
during water discharge. Moreover, there
is risk of scalding due to high washing
temperatures! To prevent such situations
and to ensure smooth water intake and
discharge of the machine, fix the end
of the discharge hose tightly so that it
cannot come out.
•Thehoseshouldbeattachedtoaheightofat
least 40 cm, and 100 cm at most.
•Incasethehoseiselevatedafterlayingiton
the floor level or close to the ground (less than
40 cm above the ground), water discharge
becomes more difficult and the laundry may
come out excessively wet. Therefore, follow the
heights described in the figure.
•Topreventflowingofdirtywaterbackintothe
machine and to allow for easy discharge, do not
immerse the hose end into the dirty water or do
not drive it in the drain more than 15 cm. If it is
too long, cut it short.
•Theendofthehoseshouldnotbebent,it
should not be stepped on and the hose must not
be pinched between the drain and the machine.
•Ifthelengthofthehoseistooshort,useitby
adding an original extension hose. Length of the
hose may not be longer than 3.2 m. To avoid
water leak failures, the connection between
the extension hose and the drain hose of the
product must be fitted well with an appropriate
clamp as not to come off and leak.
3.6 Adjusting the feet
AWARNING: In order to ensure that
the product operates more silently and
vibration-free, it must stand level and
balanced on its feet. Balance the machine
by adjusting the feet. Otherwise, the
product may move from its place and
cause crushing and vibration problems.

12 / 36 EN Washing Machine / User‘s Manual
Installation
1. Loosen the lock nuts on the feet by hand.
2. Adjust the feet until the product stands level and
balanced.
3. Tighten all lock nuts again by hand.
AWARNING: Do not use any tools to
loosen the lock nuts. Otherwise, they will
get damaged.
3.7 Electrical connection
Connect the product to a grounded outlet
protected by a 16 A fuse. Our company shall not
be liable for any damages that will arise when the
product is used without grounding in accordance
with the local regulations.
•Connectionmustcomplywithnational
regulations.
•Powercableplugmustbewithineasyreach
after installation.
•Ifthecurrentvalueofthefuseorbreakerinthe
house is less than 16 Amps, have a qualified
electrician install a 16 Amp fuse.
•Thevoltagespecifiedinthe"Technical
specifications" section must be equal to your
mains voltage.
•Donotmakeconnectionsviaextensioncables
or multi-plugs.
BWARNING: Damaged power cables
must be replaced by the Authorized
Service Agents.
Transportation of the product
1. Unplug the product before transporting it.
2. Remove water drain and water supply
connections.
3. Drain all water that has remained in the product.
See 7.5
4. Install transportation safety bolts in the reverse
order of removal procedure; see 3.3.
CNever move the product without the
transportation safety bolts properly fixed
in place!
AWARNING: Packaging materials are
dangerous to children. Keep packaging
materials in a safe place away from reach
of the children.

Washing Machine / User‘s Manual 13 / 36 EN
4 Preparation
4.1 Sorting the laundry
•Sortlaundryaccordingtotypeoffabric,colour,anddegreeofsoilingandallowablewatertemperature.
•Alwaysobeytheinstructionsgivenonthegarmenttags.
LAUNDRY WASH SYMBOLS
Machine
Wash
Symbols
Normal wash No Iron Sensitive- Delicate wash Hand wash Not washable No Spin
WASH Water
Temperatures
Maximum 950C700C600C500C400C300C
Symbol(s) lll
lll
lll
l l
ll
ll
lll l l l
Drying
Symbols Suitable for
dryer No Iron Sensitive /
Delicate dry
Do not dry
with dryer
Do not dry Do not dry-
clean
DRYING
Drying
Settings
At any temperature At high temperature At medium temperature At low temperature Without heating Hang to dry Lay to dry Hang wet to dry Lay in shadow to dry Dry-cleanable
Iron -
IRON Dry or Steam
Iron at high
temperature
Iron at medium
temperature
Iron at low
temperature
Do not iron Iron without steam Maximum temperature 200 0C150 0C110 0C
All bleaches are allowed
Bleach (sodium
hypochlorite)
can be used
Bleach is not
allowed
Only bleaches without
chlorine are allowed
BLEACH

14 / 36 EN Washing Machine / User‘s Manual
Preparation
4.2 Preparing laundry for washing
•Laundryitemswithmetalattachmentssuchas,
underwired bras, belt buckles or metal buttons
will damage the machine. Remove the metal
pieces or wash the clothes by putting them in a
laundry bag or pillow case.
•Takeoutallsubstancesinthepocketssuchas
coins, pens and paper clips, and turn pockets
inside out and brush. Such objects may damage
the product or cause noise problem.
•Putsmallsizeclothessuchasinfant'ssocks
and nylon stockings in a laundry bag or pillow
case.
•Placecurtainsinwithoutcompressingthem.
Remove curtain attachment items.
•Fastenzippers,sewloosebuttonsandmend
rips and tears.
•Wash“machinewashable”or“handwashable”
labeled products only with an appropriate
programme.
•Donotwashcoloursandwhitestogether.New,
dark coloured cottons release a lot of dye. Wash
them separately.
•Toughstainsmustbetreatedproperlybefore
washing. If unsure, check with a dry cleaner.
•Useonlydyes/colourchangersandlimescale
removers suitable for machine wash. Always
follow the instructions on the package.
•Washtrousersanddelicatelaundryturned
inside out.
•KeeplaundryitemsmadeofAngorawoolinthe
freezer for a few hours before washing. This will
reduce pilling.
•Laundrythataresubjectedtomaterialssuchas
flour, lime dust, milk powder, etc. intensely must
be shaken off before placing into the machine.
Such dusts and powders on the laundry may
build up on the inner parts of the machine in
time and can cause damage.
4.3 Things to be done
for energy saving
Following information will help you use the product
in an ecological and energy-efficient manner.
•Operatetheproductinthehighestcapacity
allowed by the programme you have selected,
but do not overload; see, "Programme and
consumption table".
•Alwaysfollowtheinstructionsonthedetergent
packaging.
•Washslightlysoiledlaundryatlow
temperatures.
•Usefasterprogrammesforsmallquantitiesof
lightly soiled laundry.
•Donotuseprewashandhightemperaturesfor
laundry that is not heavily soiled or stained.
•Ifyouplantodryyourlaundryinadryer,select
the highest spin speed recommended during
washing process.
•Donotusedetergentinexcessoftheamount
recommended on the detergent package.
4.4 Initial use
Before starting to use the product, make sure
that all preparations are made in accordance
withtheinstructionsinsections“Importantsafety
instructions”and“Installation”.
To prepare the product for washing laundry,
perform first operation in Drum Cleaning
programme. If your product is not equipped with
Drum Cleaning programme, perform the Initial
Use procedure in accordance with the methods
describedunder“7.2Cleaningtheloadingdoor
andthedrum”sectionoftheusermanual.
CUse an anti-limescale suitable for the
washing machines.

Washing Machine / User‘s Manual 15 / 36 EN
Preparation
CSome water might have remained in
the product due to the quality control
processes in the production. It is not
harmful for the product.
4.5 Correct load capacity
The maximum load capacity depends on the type
of laundry, the degree of soiling and the washing
programme desired.
The machine automatically adjusts the amount
of water according to the weight of the loaded
laundry.
AWARNING: Follow the information in
the“Programmeandconsumptiontable”.
When overloaded, machine's washing
performance will drop. Moreover, noise
and vibration problems may occur.
Laundry type Weight (g)
Bathrobe 1200
Napkin 100
Duvet cover 700
Bed Sheet 500
Pillowcase 200
Tablecloth 250
Towel 200
Hand towel 100
Evening gown 200
Underclothing 100
Men’s overalls 600
Men’s shirt 200
Men’s pajamas 500
Blouses 100
4.6 Loading the laundry
1. Open the loading door.
2. Place laundry items loosely into the machine.
3. Push the loading door to close until you hear a
locking sound. Ensure that no items are caught
in the door.
CThe loading door is locked while a
programme is running. The door can only
be opened a while after the programme
comes to an end.
AWARNING: In case of misplacing the
laundry, noise and vibration problems may
occur in the machine.
4.7 Using detergent and softener
CWhen using detergent, softener, starch,
fabric dye, bleach or limescale remover
read the manufacturer's instructions on the
package carefully and follow the suggested
dosage values. Use measuring cup if
available.
Detergent Drawer
The detergent drawer is composed of three
compartments:
– (1) for prewash
– (2) for main wash
– (3) for softener
– (*) in addition, there is siphon piece in the
softener compartment.
1
23
Detergent, softener and other cleaning agents
•Adddetergentandsoftenerbeforestartingthe
washing programme.
•Neverleavethedetergentdraweropenwhilethe
washing programme is running!
•Whenusingaprogrammewithoutprewash,
do not put any detergent into the prewash
compartment (compartment nr. "1").
•Inaprogrammewithprewash,donotput
liquid detergent into the prewash compartment
(compartment nr. "1").
•Donotselectaprogrammewithprewashifyou
are using a detergent bag or dispensing ball.
Place the detergent bag or the dispensing ball
directly among the laundry in the machine.
•Ifyouareusingliquiddetergent,donotforget
to place the liquid detergent cup into the main
wash compartment (compartment nr. "2").

16 / 36 EN Washing Machine / User‘s Manual
Preparation
Choosing the detergent type
The type of detergent to be used depends on the
type and colour of the fabric.
•Usedifferentdetergentsforcolouredandwhite
laundry.
•Washyourdelicateclothesonlywithspecial
detergents (liquid detergent, wool shampoo,
etc.) used solely for delicate clothes.
•Whenwashingdarkcolouredclothesandquilts,
it is recommended to use liquid detergent.
•Washwoolenswithspecialdetergentmade
specifically for woolens.
AWARNING: Use only detergents
manufactured specifically for washing
machines.
AWARNING: Do not use soap powder.
Adjusting detergent amount
The amount of washing detergent to be used
depends on the amount of laundry, the degree of
soiling and water hardness.
•Donotuseamountsexceedingthedosage
quantities recommended on the detergent
package to avoid problems of excessive foam,
poor rinsing, financial savings and finally,
environmental protection.
•Uselesserdetergentforsmallamountsorlightly
soiled clothes.
Using softeners
Pour the softener into the softener compartment of
the detergent drawer.
•Donotexceedthe(>max<)levelmarkinginthe
softener compartment.
•Ifthesoftenerhaslostitsfluidity,diluteitwith
water before putting it in the detergent drawer.
Using liquid detergents
If the product contains a liquid detergent cup:
•Makesurethatyouhaveplacedtheliquid
detergent cup in compartment nr. "2".
•Iftheliquiddetergenthaslostitsfluidity,diluteit
with water before putting in the detergent cup.
If the product does not contain a liquid
detergent cup:
•Donotuseliquiddetergentfortheprewashina
programme with prewash.
•Liquiddetergentstainsyourclotheswhenused
with Delayed Start function. If you are going to
use the Delayed Start function, do not use liquid
detergent.
Using gel and tablet detergent
Apply the following instructions when using tablet,
gel and similar detergents.
•Ifthegeldetergentthicknessisfluidaland
your machine does not contain a special liquid
detergent cup, put the gel detergent into the
main wash detergent compartment during first
water intake. If your machine contains a liquid
detergent cup, fill the detergent into this cup
before starting the programme.
•Ifthegeldetergentthicknessisnotfluidalorin
the shape of capsule liquid tablet, put it directly
into the drum before washing.
•Puttabletdetergentsintothemainwash
compartment (compartment nr. "2") or directly
into the drum before washing.
CTablet detergents may leave residues
in the detergent compartment. If you
encounter such a case, place the tablet
detergent between the laundry, close
to the lower part of the drum in future
washings.
CUse the tablet or gel detergent without
selecting the prewash function.

Washing Machine / User‘s Manual 17 / 36 EN
Preparation
Using starch
•Addliquidstarch,powderstarchorthefabric
dye into the softener compartment.
•Donotusesoftenerandstarchtogetherina
washing cycle.
•Wipetheinsideofthemachinewithadampand
clean cloth after using starch.
Using bleaches
•Selectaprogrammewithprewashandadd
the bleaching agent at the beginning of the
prewash. Do not put detergent in the prewash
compartment. As an alternative application,
select a programme with extra rinse and add
the bleaching agent while the machine is taking
water from the detergent compartment during
first rinsing step.
•Donotusebleachingagentanddetergentby
mixing them.
•Usejustalittleamount(approx.50ml)of
bleaching agent and rinse the clothes very
well as it causes skin irritation. Do not pour the
bleaching agent onto the clothes and do not use
it for coloured clothes.
•Whenusingoxygenbasedbleaches,selecta
programme that washes at a lower temperature.
•Oxygenbasedbleachescanbeusedtogether
with detergents; however, if its thickness
is not the same with the detergent, put the
detergent first into the compartment nr. "2"
in the detergent drawer and wait until the
detergent flows while the machine is taking in
water. Add the bleaching agent from the same
compartment while the machine is still taking in
water.
Using limescale remover
•Whenrequired,uselimescaleremovers
manufactured specifically for washing machines
only.

18 / 36 EN Washing Machine / User‘s Manual
Preparation
4.8 Tips for efficient washing
Clothes
Light colours and
whites Colours Dark colours Delicates/Woolens/ Silks
(Recommended
temperature range
based on soiling level:
40-90ºC)
(Recommended
temperature range based
on soiling level: cold-40ºC)
(Recommended
temperature range
based on soiling
level: cold-40ºC)
(Recommended
temperature range
based on soiling level:
cold-30ºC)
Soiling Level
Heavily Soiled
(difficult stains
such as grass,
coffee, fruits and
blood.)
It may be necessary
to pre-treat the
stains or perform
prewash. Powder
and liquid detergents
recommended for whites
can be used at dosages
recommended for
heavily soiled clothes. It
is recommended to use
powder detergents to
clean clay and soil stains
and the stains that are
sensitive to bleaches.
Powder and liquid
detergents recommended
for colours can be used at
dosages recommended
for heavily soiled clothes.
It is recommended to use
powder detergents to
clean clay and soil stains
and the stains that are
sensitive to bleaches. Use
detergents without bleach.
Liquid detergents
suitable for
colours and dark
colours can be
used at dosages
recommended
for heavily soiled
clothes.
Prefer liquid
detergents produced
for delicate clothes.
Woolen and silk
clothes must be
washed with special
woolen detergents.
Normally Soiled
(For example,
stains caused by
body on collars
and cuffs)
Powder and
liquid detergents
recommended for whites
can be used at dosages
recommended for
normally soiled clothes.
Powder and liquid
detergents recommended
for colours can be used at
dosages recommended
for normally soiled clothes.
Use detergents without
bleach.
Liquid detergents
suitable for
colours and dark
colours can be
used at dosages
recommended for
normally soiled
clothes.
Prefer liquid
detergents produced
for delicate clothes.
Woolen and silk
clothes must be
washed with special
woolen detergents.
Lightly Soiled
(No visible stains
exist.)
Powder and
liquid detergents
recommended for whites
can be used at dosages
recommended for lightly
soiled clothes.
Powder and liquid
detergents recommended
for colours can be used at
dosages recommended
for lightly soiled clothes.
Use detergents without
bleach.
Liquid detergents
suitable for
colours and dark
colours can be
used at dosages
recommended
for lightly soiled
clothes.
Prefer liquid
detergents produced
for delicate clothes.
Woolen and silk
clothes must be
washed with special
woolen detergents.

Washing Machine / User‘s Manual 19 / 36 EN
5 Operating the product
5.1 Control panel
1 2
76543
Dark wash
(Darkcare)
Dark wash
(Darkcare)
Synthetics Cottons Pre-wash Main
wash
Rinse Wash Spin
Drain
(Pump)
Anti-
creasing
Duvet
(Bedding)
Child-
proof lock
Hand
Wash
BabyProtect Cotton
Eco
Woollens
Delicate Pet hair
removal
Daily
Lingerie
expres 14
Super short
express
Daily
express
Rinse hold Start/
Pause
No spin Quick
wash
Finished Cold Self
Clean
Temperature
Mixed 40
(Mix40)
Super 40 Extra rinse
(Rinse Plus)
Freshen
up
Shirts Jeans Sport Time delay Intensive Fasion
care
mini 30
Eco Clean
Anti-
allergic
On/Off
Door Ready
1 - Programme Selection knob (Uppermost
position On/Off)
2 - Programme Follow-up indicator
3 - Temperature Adjustment button
4 - Spin Speed adjustment button
5 - Auxiliary Function buttons
6 - Delayed Start button (in some models)
7 - Start / Pause button

20 / 36 EN Washing Machine / User‘s Manual
Operating the product
5.2 Preparing the machine
1. Make sure that the hoses are connected tightly.
2. Plug in your machine.
3. Turn the tap on completely.
4. Place the laundry in the machine.
5. Add detergent and fabric softener.
5.3 Programme selection
1. Select the programme suitable for the type,
quantity and soiling degree of the laundry
in accordance with the "Programme and
consumption table" and the temperature table
below.
90˚C
Heavily soiled white cottons and linens.
(coffee table covers, tableclothes, towels,
bed sheets, etc.)
60˚C
Normally soiled, coloured, fade proof
linens, cottons or synthetic clothes (shirt,
nightgown, pajamas, etc.) and lightly soiled
white linens (underwear, etc.)
40˚C-
30˚C-
Cold
Blended laundry including delicate textile
(veil curtains, etc.), synthetics and woolens.
2. Select the desired programme with the
Programme Selection button.
CProgrammes are limited with the highest
spin speed appropriate for that particular
type of fabric.
CWhen selecting a programme, always
consider the type of fabric, colour,
degree of soiling and permissible water
temperature.
CAlways select the lowest required
temperature. Higher temperature means
higher power consumption.
CFor further programme details, see
"Programme and consumption table"
5.4 Main programmes
Depending on the type of fabric, use the following
main programmes.
• Cottons
Use this programme for your cotton laundry (such
as bed sheets, duvet and pillowcase sets, towels,
bathrobes, underwear, etc.). Your laundry will be
washed with vigorous washing action for a longer
washing cycle.
• Synthetics
Use this programme to wash your synthetic
clothes (shirts, blouses, synthetic/cotton blends,
etc.). It washes with a gentle action and has a
shorter washing cycle compared to the Cottons
programme.
For curtains and tulle, use the Synthetic 40˚C
programme with prewash and anti-creasing
functions selected. As their meshed texture causes
excessive foaming, wash the veils/tulle by putting
little amount of detergent into the main wash
compartment. Do not put detergent in the prewash
compartment.
• Woollens
Use this programme to wash your woolen clothes.
Select the appropriate temperature complying
with the tags of your clothes. Use appropriate
detergents for woolens.
5.5 Additional programmes
For special cases, additional programmes are
available in the machine.
CAdditional programmes may differ
according to the model of the machine.
• Cotton Economic
You may wash your normally soiled durable cotton
and linen laundry in this programme with the
highest energy and water saving compared to
all other wash programmes suitable for cottons.
Actual water temperature may differ from the
declared cycle temperature. Programme duration
may automatically be shortened during later stages
of the programme if you wash less amount (e.g. ½
capacity or less) of laundry. In this case energy and
water consumption will be further decreased giving
you the opportunity for a more economical wash.
This feature is available for certain models having
remaining time display.
