Washing Machine
User Manual
WMY 914831
EN
Document Number=

1 General safety instructions
•While there is still water inside
the product, never open the
loading door or remove the filter.
Otherwise, risk of flooding and
injury from hot water will occur.
•Do not force open the locked
loading door. Door can be
opened a few minutes after the
washing cycle ends. In case
of forcing the loading door to
open, the door and the lock
mechanism may get damaged.
•Use detergents, softeners
and supplements suitable for
automatic washing machines
only.
•Follow the instructions on
the label of textiles and the
detergent package.
1.2 Hot surface safety
A
CAUTION!
•While washing the laundry
at high temperatures, the
loading door glass will get hot.
Considering this fact, during
washing operation keep the
children away from the loading
door of the product to prevent
them touching it.
This section includes security
instructions which may help prevent
the injuries and material damage risks.
All kinds of warranties shall be invalid if
these instructions are not observed.
1.1 Lfe and property safety
A
CAUTION!
•Never place the product on a
carpet-covered floor. Electrical
parts will get overheated since
air cannot circulate from under
the device. This will cause
problems with your product.
•Unplug the product if it is not in
use.
•Always have the installation and
repairing procedures carried
out by the Authorised Service
Agent. The manufacturer shall
not be held liable for damages
that may arise from procedures
carried out by unauthorised
persons.
•The water supply and
draining hoses must be
securely fastened and remain
undamaged. Otherwise, water
leak may occur.
This product was manufactured using the latest technology in environmentally friendly conditions.

3 / EN Washing Machine / User’s Manual
1.3 Chldren’s safety
A
CAUTION!
•This product can be used by
the children who are at the
age of 8 and over and the
people whose physical, sensory
or mental skills are not fully
developed or who do not have
necessary required experience
and knowledge as long as they
are supervised or trained about
the safe use of the product and
its risks. Children should not
play with the device. Cleaning
and maintenance works should
not be performed by children
unless they are supervised by
someone. Children of less than
3 years should be kept away
unless continuously supervised.
A
CAUTION!
•Packaging materials may be
dangerous for the children.
Keep packaging materials in a
safe place away from reach of
the children.
•Electrical products are
dangerous for the children.
Keep the children away from
the product when it is in use.
Do not allow them to play
with the product. Use child
lock to prevent children from
intervening with the product.
A
CAUTION!
•Do not forget to close the
loading door when leaving the
room where the product is
located.
•Store all detergents and
additives in a safe place away
from the reach of the children
by closing the cover of the
detergent container or sealing
the detergent package.
1.4 Electrcal safety
B
DANGER!
•If the product has a failure, it
should not be operated unless
it is repaired by the Authorised
Service Agent. Risk of electric
shock!
•This product is designed to
resume operating in the event
of powering on after a power
interruption. If you wish to
cancel the programme, see
“Cancelling the programme”
section.

4 / EN Washing Machine / User’s Manual
B
DANGER!
•Plug the product into a
grounded outlet protected by
a 16 A fuse. Do not neglect to
have the grounding installation
made by a qualified electrician.
Our company shall not be
liable for any damages that
will arise when the product
is used without grounding
in accordance with the local
regulations.
B
DANGER!
•Do not wash the product by
spraying or pouring water onto
it! Risk of electric shock!
•Never touch the power cable
plug with wet hands! Do not
grab the power cord to unplug
the machine, always unplug it
by holding the socket with one
hand, and pulling the plug with
the other hand.
•Product should be unplugged
during installation, maintenance,
cleaning and repair procedures.
B
DANGER!
•If the power cable is damaged,
it must be replaced by the
manufacturer, after sales service
or a similarly qualified person
(preferably an electrician) or
someone designated by the
importer in order to avoid
possible risks.
2.Important instructions for
environment
2.1 Compliance with WEEE Directive
This product complies with EU
WEEE Directive (2012/19/EU).
This product bears a classification
symbol for waste electrical and
electronic equipment (WEEE).
This product has been manufactured with
high quality parts and materials which can
be reused and are suitable for recycling. Do
not dispose of the waste product with normal
domestic and other wastes at the end of its
service life. Take it to the collection center
for the recycling of electrical and electronic
equipment. Please consult your local
authorities to learn about these collection
centers.
Compliance with RoHS Directive:
The product you have purchased complies
with EU RoHS Directive (2011/65/EU). It
does not contain harmful and prohibited
materials specified in the Directive.
2.2 Package information
Packaging materials of the product are
manufactured from recyclable materials in
accordance with our National Environment
Regulations. Do not dispose of the
packaging materials together with the
domestic or other wastes. Take them to
the packaging material collection points
designated by the local authorities.
3.Intended use
• Thisproducthasbeendesignedfordomestic
use. It is not for commercial purposes or it
should not be used out of its intended use.
• Theproductmustonlybeused
for washing and rinsing of laundry
that are marked accordingly.
• Themanufacturerwaivesanyresponsibility
arisen from incorrect usage or transportation.
• Theservicelifeofyourproductis10years.
During this period, original spare parts will be
available to operate the appliance properly.

5 / EN Washing Machine / User’s Manual
4 Technical specifications
Supplier name or trademark Beko
Model name WMY 914831
Rated capacity (kg) 9
Maximum spin speed (rpm) 1400
Built-in No
Height (cm) 84
Width (cm) 60
Depth (cm) 64
Net weight (±4 kg.) 72
Single Water inlet / Double Water inlet • / -
• Available
Electrical input (V/Hz) 220-240 V / 50Hz
Total current (A) 10
Total power (W) 2000-2350
Main model code 108
Technical specifications may be changed without prior notice to improve the quality of the product.

6 / EN Washing Machine / User’s Manual
4.1 Installation
• Applytothenearestauthorisedservice
agent for the installation of your product.
• Preparationofthelocationandelectrical,
tap water and waste water installations at
the place of installation is under customer's
responsibility.
• Makesurethatthewaterinletanddischarge
hoses as well as the power cable are not
folded, pinched or crushed while pushing
the product into its place after installation or
cleaning procedures.
• Makesurethattheinstallationandelectrical
connections of the product are performed
byauthorisedservice.Manufacturershall
not be held liable for damages that may
arise from procedures carried out by
unauthorised persons.
• Priortoinstallation,visuallycheckifthe
product has any defects on it. If so, do not
have it installed. Damaged products cause
risks for your safety.
4.1.1 Appropriate installation location
• Placetheproductonahardandlevelfloor.
Do not put it onto a carpet with high pile or
other similar surfaces.
• Whenthewashingmachineanddryerare
placed on top of each other, their total
weight –when loaded– amounts to 180 kg.
Place the product on a solid and flat floor
that has sufficient load carrying capacity!
• Donotplacetheproductonthepowercable.
• Donotinstalltheproductinthe
environments where the temperature falls
below 0 ºC.
• Leavingagapatthesidesofthemachineis
suggested to reduce vibration and noise
• Onagraduatedfloor,donotplacethe
product next to the edge or on a platform.
• DonotplaceheatsourcessuchasHobs,
Irons, Ovens, etc. on the washing machine
and do not use them on the product.
4.1.2 Removing packaging reinforcement
Tilt the machine
backwards to remove the
packaging reinforcement.
Remove the packaging
reinforcement by pulling
the ribbon. Do not make
this operation alone by
yourself.
4.1.3 Removing the
transportation locks
1 Loosenallboltswithanappropriatewrench
until they turn freely.
2 Remove the transport safety bolts by
turning them slightly.
3 Insert the plastic covers in the bag
containing the user manual to the openings
on the rear panel.
A
CAUTION!
• Remove the transportation safety bolts
before operating the washing machine!
Otherwise, the product will be damaged.
C
INFORMATION
• Keep the transportation safety
bolts in a safe place to reuse when
the washing machine needs to
be moved again in the future.
• Install the transport safety bolts in reverse
order of the disassembly procedure.
• Never move the product without
the transportation safety bolts
properly fixed in place!
4.1.4 Connecting water supply
C
INFORMATION
• The water supply pressure required to
run the product is between 1 to 10 bars
(0.1–1MPa).Itisnecessarytohave
10 – 80 liters of water flowing from the
fully open tap in one minute to have your
machine run smoothly. Attach a pressure
reducing valve if water pressure is higher.
A
CAUTION!
• Modelswithasinglewaterinletshould
not be connected to the hot water
tap. In such a case the laundry will get
damaged or the product will switch to
protection mode and will not operate.
• Do not use old or used water inlet
hoses on the new product. It may
cause stains on your laundry.

7 / EN Washing Machine / User’s Manual
1 Tighten the nuts of the hose by hand.
Never use a tool when tightening the nuts.
2 When hose connection is completed,
check whether there is leak problems at the
connection points by opening the taps fully. If
any leaks occur, turn off the tap remove the
nut. Retighten the nut carefully after checking
the seal. In order to prevent the water leaks
and resultant damages, keep the taps closed
when you do not use the product.
4.1.5 Connecting the drain
hose to the drain
• Attachtheendofthedrainhosedirectlyto
waste water drain, lavatory or bathtub.
A
CAUTION!
• Your drain house will be flooded if the
hose comes out of its housing during
waterdischarge.Moreover,thereisriskof
scalding due to high washing temperatures!
In order to prevent such situations and
make sure that the machine performs water
intake and discharge processes without
any problem, fix the drain hose securely.
40 cm
100 cm
•Connectthedrainhosetoaminimumheight
of 40 cm and a maximum height of 100 cm.
•Incasethedrainhoseiselevatedafterlaying
it on the floor level or close to the ground
(less than 40 cm above the ground), water
discharge becomes more difficult and the
laundry may come out excessively wet.
Therefore, follow the heights described in
the figure.
• Topreventthewastewatertogoback
into the machine again and to ensure easy
drainage, do not immerse the end of the
hose into the waste water or do not insert
it into the drain for more than 15 cm. If it is
too long, cut it short.
• Theendofthehoseshouldnotbebent,
it should not be stepped on and the hose
must not be pinched between the drain and
the machine.
• Ifthelengthofthehoseistooshort,use
it by adding an original extension hose.
Lengthofthehosemaynotbelongerthan
3.2 m. To avoid water leak failures, the
connection between the extension hose and
the drain hose of the product must be fitted
well with an appropriate clamp as not to
come off and leak.
4.1.6 Adjusting the feet
A
CAUTION!
• In order to ensure that the product
operates more silently and vibration-
free, it must stand level and balanced
on its feet. Balance the machine by
adjusting the feet. Otherwise, the product
may move from its place and cause
crushing and vibration problems.
• Do not use any tools to loosen the lock
nuts. Otherwise, they will get damaged.
1 Loosenthelocknutsonthefeetbyhand.
2 Adjust the feet until the product stands in a
stable and balanced way.
3. Tighten all lock nuts by hand again.

8 / EN Washing Machine / User’s Manual
4.1.7 Electrical connection
Connect the product to a grounded outlet
protected by a 16 A fuse. Our company shall
not be liable for any damages that will arise
when the product is used without grounding in
accordance with the local regulations.
• Connectionmustcomplywithnationalregulations.
• Thewiringfortheelectricaloutletcircuit
must be sufficient to meet the appliance
requirements. Use of a Groud Fault Circuit
Interrupter (GFCI) is recommended.
• Powercableplugmustbewithineasyreach
after installation.
• Ifthecurrentvalueofthefuseorbreaker
in the house is less than 16 Amps, have a
qualified electrician install a 16 Amp fuse.
• Thevoltagespecifiedinthe"Technical
specifications"sectionmustbeequalto
your mains voltage.
• Donotmakeconnectionsviaextension
cables or multi-plugs.
A
CAUTION!
• Damaged power cables must be replaced
by the Authorised Service Agents.
4.1.8 Initial use
Before starting to
use the product
make sure that
the preparations
are made which
are in line with the
“Important Safety
and Environment Instructions” and the
instructions in the “Installation” section.
To prepare the product for washing laundry,
perform first operation in Drum Cleaning
programme. If this program is not available
in your machine, apply the method which is
described in the section 4.4.2.
C
INFORMATION
• Use an anti-limescale suitable
for the washing machines.
• Some water might have remained
in the product due to the quality
control processes in the production.
It is not harmful for the product.
4.2 Preparation
4.2.1 Sorting the laundry
* Sort laundry according to type of fabric,
color, and degree of soiling and allowable
water temperature.
* Always obey the instructions given on the
garment tags.
4.2.2 Preparing laundry for washing
• Laundryitemswithmetalattachmentssuch
as, underwired bras, belt buckles or metal
buttons will damage the machine. Remove
the metal pieces or wash the clothes by
putting them in a laundry bag or pillow case.
• Takeoutallsubstancesinthepocketssuchas
coins, pens and paper clips, and turn pockets
inside out and brush. Such objects may
damage the product or cause noise problem.
• Putsmallsizeclothessuchasinfant'ssocks
and nylon stockings in a laundry bag or
pillow case.
• Placecurtainsinwithoutcompressingthem.
Remove curtain attachment items.
• Fastenzippers,sewloosebuttonsand
mend rips and tears.
• Wash“machinewashable”or“hand
washable” labeled products only with an
appropriate programme.
• Donotwashcoloursandwhitestogether.
New, dark coloured cottons release a lot of
dye. Wash them separately.
• Tough stains must be treated properly before
washing. If unsure, check with a dry cleaner.
• Onlyusethedyes/colorchangersand
descaling agents which are appropriate
to machine wash. Always follow the
instructions on the package.
• Washtrousersanddelicatelaundryturned
inside out.
• KeeplaundryitemsmadeofAngorawoolin
thefreezerforafewhoursbeforewashing.
This will reduce pilling.
• Laundrythataresubjectedtomaterialssuch
as flour, lime dust, milk powder, etc. intensely
must be shaken off before placing into the
machine. Such dusts and powders on the
laundry may build up on the inner parts of
the machine in time and can cause damage.
4.2.3 Things to be done
for energy saving
Following information will help you use the product
in an ecological and energy-efficient manner.

9 / EN Washing Machine / User’s Manual
• Operatetheproductinthehighest
capacity allowed by the programme you
have selected, but do not overload; see,
"Programmeandconsumptiontable".See,
“Programmeandconsumptiontable"
• Alwaysfollowtheinstructionsonthe
detergent packaging.
• Washslightlysoiledlaundryatlowtemperatures.
• Usefasterprogrammesforsmallquantities
of lightly soiled laundry.
• Do not use prewash and high temperatures
for laundry that is not heavily soiled or stained.
• Ifyouplantodryyourlaundryinadryer,
select the highest spin speed recommended
during washing process.
• Do not use more detergent than the
recommended amount specified on its package.
4.2.4 Loading the laundry
1. Open the laundry cover.
2. Put the laundry items into the machine in a
loose manner.
3. Push and close the loading cover until you
hear the locking sound. Ensure that no items
are caught in the door. The loading door is
locked while a programme is running. The
door can only be opened a while after the
programme comes to an end.
4.2.5 Correct load capacity
The maximum load capacity depends on the
type of laundry, the degree of soiling and the
washing programme desired.
Machineautomaticallyadjuststhewater
amount according to the weight of the laundry
put inside it.
A
WARNING!
• Follow the information in the
“Programme and consumption table”.
When overloaded, machine’s washing
performancewilldrop.Moreover,noise
and vibration problems may occur.
4.2.6 Using detergent and softener
C
INFORMATION
• When using detergent, softener, starch, fabric
dye, bleacher and decolorant, descaling
agents; read the manufacturer’s instructions
written on the package and follow the dosages
specified. Use measuring cup if available.
1
3
2
The detergent drawer
is composed of three
compartments:
– (1) for prewash
– (2) for main wash
– (3) for softener
– ( ) in addition, there
is a siphon piece in the
softener compartment.
Detergent, softener and other cleaning agents
• Adddetergentandsoftenerbeforestarting
the washing programme.
• Whilethewashingcycleisinprogress,do
not leave the detergent dispenser open!
• Whenusingaprogrammewithoutprewash,
do not put any detergent into the prewash
compartment(compartmentnr."1").
• Inaprogrammewithprewash,donot
put liquid detergent into the prewash
compartment(compartmentnr."1").
• Donotselectaprogrammewithprewashif
you are using a detergent bag or dispensing
ball. Place the detergent bag or the dispensing
ball directly among the laundry in the machine.
• Ifyouareusingliquiddetergent,do
not forget to place the liquid detergent
container into the main wash compartment
(compartment number “2”).
Choosing the detergent type
Detergent type to be used depends on the
fabric type and color.
• Usedifferentdetergentsforcolouredand
white laundry.
• Washyourdelicateclothesonlywithspecial
detergents (liquid detergent, wool shampoo,
etc.) used solely for delicate clothes.
• Whenwashingdarkcolouredclothesandquilts,
it is recommended to use liquid detergent.
• Washwoolenswithspecialdetergentmade
specifically for woolens.
A
CAUTION!
• Use only detergents manufactured
specifically for washing machines.
• Do not use soap powder.
Adjusting detergent amount
The amount of washing detergent to be used
depends on the amount of laundry, the degree
of soiling and water hardness.

10 / EN Washing Machine / User’s Manual
• Donotuseamountsexceedingthedosage
quantities recommended on the detergent
package to avoid problems of excessive
foam, poor rinsing, financial savings and
finally, environmental protection.
• Uselesserdetergentforsmallamountsor
lightly soiled clothes.
Using softeners
Pour the softener into the softener
compartment of the detergent drawer.
• Donotexceedthe(>max<)levelsignonthe
softener compartment.
• Ifthesoftenerhaslostitsfluidity,diluteitwith
water before putting it in the detergent drawer.
Using liquid detergents
If the product contains a liquid detergent cup:
2
2
• Puttheliquiddetergentcontainerintothe
compartment no “2”.
• Iftheliquiddetergentlostitsfluidity,dilute
it with water before putting it into the
detergent container.
If the product is equipped with a liquid
detergent part:
• Whenyouwanttouseliquiddetergent,pull
the apparatus towards yourself. The part
that falls down will serve as a barrier for the
liquid detergent.
• Ifrequired,cleantheapparatuswithwater
when it is in place or by removing it.
• Ifyouwillusepowderdetergent,the
apparatus must be secured at top position.
If the product does not contain a liquid
detergent cup:
• Donotuseliquiddetergentfortheprewash
in a programme with prewash.
• Liquiddetergentstainsyourclotheswhen
used with Delayed Start function. If you are
going to use the Delayed Start function, do
not use liquid detergent.
Using gel and tablet detergent
• If the gel detergent thickness is fluidal and
your machine does not contain a special liquid
detergent cup, put the gel detergent into the
main wash detergent compartment during
first water intake. If your machine contains a
liquid detergent cup, fill the detergent into this
cup before starting the programme.
• Ifthegeldetergentthicknessisnotfluidalor
in the shape of capsule liquid tablet, put it
directly into the drum before washing.
• Puttabletdetergentsintothemainwash
compartment(compartmentnr."2")or
directly into the drum before washing.
Using starch
• Puttheliquidsoda,powdersodaorthe
fabric dye into the softener compartment.
Do not use softener and starch together in a
washing cycle.
Wipe the inside of the machine with a damp
and clean cloth after using starch.
Using limescale remover
• Whenrequired,uselimescaleremovers
manufactured specifically for washing
machines only.
Using bleaches
Add the bleach at the beginning of the
washing cycle by selecting a prewash
program. Do not put detergent in the
prewash compartment. As an alternative
application, select a programme with extra
rinse and add the bleaching agent while the
machine is taking water from the detergent
compartment during first rinsing step.
• Donotusebleachingagentanddetergent
by mixing them. Use just a little amount
(approx. 50 ml) of bleaching agent and
rinse the clothes very well as it causes skin
irritation. Do not pour the bleach onto the
laundry and do not use it with the colored items.
• Whenusingoxygen-baseddecolorant,
select a program which washes the laundry
at a low temperature.
• Oxygen-baseddecolorantcanbeusedwith
the detergent; however, if it is not at the
same consistence, first put detergent in the
compartment number “2” in the detergent
dispenser and wait for the machine to flush
the detergent when taking in water. While
the machine continues taking in water, add
decolorant in the same compartment.

11 / EN Washing Machine / User’s Manual
4.2.7 Tips for efficient washing
Clothes
Light Colours and
Whites Colours Black/Dark Colours
Delicates/
Woolens/Silks
(Recommended
temperature range based
on soiling level: 40-90 oC)
(Recommended
temperature range based
on soiling level: cold-40
oC)
(Recommended
temperature
range based on
soiling level: cold
-40 oC)
(Recommended
temperature range
based on soiling
level: cold -30 oC)
Soiling Level
Heavily
Soiled
(difficult
stains such
as grass,
coffee,
fruits and
blood.)
It may be necessary to
pre-treat the stains or
perform prewash. Powder
and liquid detergents
recommended for whites
can be used at dosages
recommended for
heavily soiled clothes. It
is recommended to use
powder detergents to
clean clay and soil stains
and the stains that are
sensitive to bleaches.
Powder and liquid
detergents recommended
for colors can be used at
dosages recommended
for heavily soiled clothes.
It is recommended to use
powder detergents to
clean clay and soil stains
and the stains that are
sensitive to bleaches. Use
detergents without bleach.
Liquiddetergents
suitable for
colors and dark
colors can be
used at dosages
recommended
for heavily soiled
clothes.
Prefer liquid
detergents
produced for
delicate clothes.
Woolen and silk
clothes must
be washed with
special woolen
detergents.
Normally
Soiled
(For example,
stains caused
by body on
collars and
cuffs)
Powder and liquid
detergents recommended
for whites can be used at
dosages recommended
for normally soiled
clothes.
Powder and liquid
detergents recommended
for colors can be used at
dosages recommended
for normally soiled clothes.
Detergents which do not
contain bleach should be
used.
Liquiddetergents
suitable for
colors and dark
colors can be
used at dosages
recommended for
normally soiled
clothes.
Prefer liquid
detergents
produced for
delicate clothes.
Woolen and silk
clothes must
be washed with
special woolen
detergents.
Lightly
Soiled
(No visible
stains
exist.)
Powder and liquid
detergents recommended
for whites can be used at
dosages recommended
for lightly soiled clothes.
Powder and liquid
detergents recommended
for colors can be used at
dosages recommended
for lightly soiled clothes.
Detergents which do not
contain bleach should be
used.
Liquiddetergents
suitable for
colors and dark
colors can be
used at dosages
recommended
for lightly soiled
clothes.
Prefer liquid
detergents
produced for
delicate clothes.
Woolen and silk
clothes must
be washed with
special woolen
detergents.

12 / EN Washing Machine / User’s Manual
4.3 Operating the product
4.3.1 Control panel
17 - Programme selection knob
18-TemperatureselectionLEDs
19-SpinspeedselectionLEDs
20 - Duration information display
21-ChildlockenabledLED
22 - End Time Setting button
23-DoorlockenabledLED
24-Programmefollow-upindicatorLEDs
25 - On / Off button
26 - Start / Pause button
27 - Auxiliary function buttons
28 - Spin speed adjustment button
29 - Temperature adjustment button
30-ProgrammeSelectionLEDs
17 18 19 20 21 22 23 24
25
2627282930
4.3.2 Programme selection
1 Determine the programme suitable for the
type, quantity and soiling level of the laundry
inaccordancewiththe"Programmeand
consumptiontable".
1 Select the desired programme with the
“Programme Selection” knob.
A
INFORMATION
• Programmes are limited with the
highest spin speed appropriate for
that particular type of fabric.
• When selecting the program you will
use, always take fabric type, color,
soil degree and permitted water
temperature into consideration.
• Always prefer the lowest temperature
value which is fit to your laundry
type. Higher temperature means
higher power consumption.
4.3.3 Programmes
• Cottons
Use for your cotton laundry (such as bed
sheets, duvet and pillowcase sets, towels,
bathrobes, underwear, etc.). Your laundry will
be washed with vigorous washing action for a
longer washing cycle.
• Synthetics
Use to wash your synthetic clothes (shirts,
blouses, synthetic/cotton blends, etc.). It
washes with a gentle action and has a shorter
washing cycle compared to the Cottons
programme.
For curtains and tulle, use the Synthetic 40˚C
programme with prewash and anti-creasing
functions selected. As their meshed texture
causes excessive foaming, wash the veils/tulle
by putting little amount of detergent into the
main wash compartment. Do not put detergent
in the prewash compartment.
• Woollens
Use to wash your woolen clothes. Select
the appropriate temperature complying with
the tags of your clothes. Use appropriate
detergents for woolens.
“The wool wash cycle of this
machine has been approved
by The Woolmark Company
for the washing of machine
washable wool products
provided that the products are
washed according to the instructions on the
garment label and those issued by the
manufacturer of this washing machine.
M13985”
“In UK, Eire, Hong Kong and India the Woolmark
trade mark is a Certification trade mark.”
• Cottons Eco
Use to wash your normally soiled, durable
cotton and linen laundry. Although it washes
longer than all other programmes, it provides
high energy and water savings. Actual water
temperature may be different from the stated
wash temperature. When you load the machine
with less laundry (e.g. ½ capacity or less),
programme time may automatically get shorter.
In this case, energy and water consumption
will decrease more, providing a more economic
wash. This programme is available in the
models with the remaining time indicator.

13 / EN Washing Machine / User’s Manual
• BabyProtect+
Use this programme for your laundry for
which you require an anti-allergic and hygienic
washing at high temperature with intensive and
long washing cycle.
• Babyprotect+60°Cprogrammeis
tested and approved by “The British Allergy
Foundation” (Allergy UK) in United Kingdom.
• Hand Wash
Use to wash your woolen/delicate clothes that
bear “not machine-washable” tags and for
which hand wash is recommended. It washes
laundry with a very gentle washing action to
not to damage clothes.
• Daily Express
Use this programme to wash your lightly soiled
cotton clothes in a short time.
• Xpress Super Short
Use this programme to wash your little amount
of lightly soiled cotton clothes in a short time.
Yourclotheswillbewashedat30°Cinashort
time like 14 minutes.
• Gentle Care 20°
Use it to wash your delicate laundry. It washes
with a gentler action without any interim spins
compared to the Synthetics program. It should
be used for laundry for which sensitive wash is
recommended.
• Mix 40
Use this programme to wash your cotton and
synthetic clothes together without sorting
them.
• Freshen Up
Use this programme to remove the odour on
the laundry that are worn only for once and do
not contain any stains or dirt.
• Aqua 40’40°
Use this programme to wash your lightly soiled
and unstained cotton laundry in a short time.
• Duvet
Use this programme to wash your fiber duvets
thatbear"machinewashable"tag.Checkthat
you have loaded the duvet correctly in order
not to damage the machine and the duvet.
Remove the duvet cover before loading the
duvet into the machine. Fold the duvet into two
andloaditintothemachine.Loadtheduvet
into the machine paying attention to place it in
a way that it will not contact the bellow.
C
INFORMATION
• Do not load more than 1 double
fibre duvet (200 x 200 cm).
• Do not wash your duvets, pillows and
etc. that contain cotton in the machine.
A
CAUTION!
• Do not wash the items apart from
duvets such as carpets, rugs and
etc. in the machine. Permanent
damage occurs in the machine.
• Hygiene 20°
Use this programme for your laundry for which
you require washing at lower temperature with
intensive and long washing cycle. Use this
programme for your laundry for which you
require hygienic washing at lower temperature.
• Rinse
Use when you want to rinse or starch
separately.
• Spin+Drain
Use to drain the water in the machine.

14 / EN Washing Machine / User’s Manual
4.3.4 Temperature selection
Whenever a new programme is selected, the
recommended temperature for the selected
programme appears on the temperature
indicator. To decrease the temperature,
press the Temperature Adjustment button.
Temperature will decrease gradually.
C
INFORMATION
• If the programme has not reached
the heating step, you can change
the temperature without switching
the machine to Pause mode.
4.3.5 Spin speed selection
Whenever a new programme is selected, the
recommended spin speed of the selected
programme is displayed on the spin speed
indicator.
To decrease the spin speed, press the Spin
Speed Adjustment button. Spin speed
decreases gradually.
Then, depending on the model of the product,
"RinseHold"and"NoSpin"optionsappearon
thedisplay.See"Auxiliaryfunctionselection"
section for explanations of these options.
Rinse Hold
If you are not going to unload your clothes
immediately after the programme completes,
you can use rinse hold function to keep your
laundry in the final rinsing water in order to
prevent them from getting wrinkled when
there is no water in the machine. Press Start /
Pause button after this process if you want to
drain the water without spinning your laundry.
Programme will resume and complete after
draining the water.
If you want to spin the laundry held in water,
adjust the Spin Speed and press Start / Pause
button.
The programme resumes. Water is drained,
laundry is spun and the programme is completed.
C
INFORMATION
• If the programme has not reached
the spinning step, you can change
the speed without switching the
machine to Pause mode.
• Use a lower spin speed for
delicate laundries.

15 / EN Washing Machine / User’s Manual
4.3.6 Programme and consumption table
• :Selectable.
* : Automatically selected, no canceling.
**:EnergyLabelprogramme (IEC 60456:2010)
*** : If maximum spin speed of the machine is lower then this value, you can only select up to the
maximum spin speed.
- : See the programme description for maximum load.
EN 2
Auxiliary
functions
Programme (°C)
Max. Load (kg) Water Consumption (l) Energy Consumption (kWh) Max. Speed*** Prewash Quick Wash Pet Hair Removal
Selectable temperature
range °C
Cottons Eco
60 9 56,2 0,50 1400 Cold-60
60 4,5 42,7 0,80 1400 Cold-60
40 4,5 42,7 0,80 1400 Cold-60
Cottons
60** 9 56,2 0,50 1400 Cold-60
60 4,5 42,7 0,80 1400 Cold-60
40 4,5 42,7 0,80 1400 Cold-60
Synthetics 60 4 65 1,25 1200 • • • Cold-60
40 4 65 0,70 1200 • • • Cold-60
Woollens 40 2 48 0,28 1200 Cold-40
Hand Wash 30 1 44 0,25 1200 Cold-30
BabyProtect+ 90 9 92 2,50 1400 30-90
Duvet 40 - 65 0,90 1000 •Cold-60
Freshen Up - 2 32 0,15 1000 -
Mix 40 40 4 68 0,85 1000 • • • Cold-40
Aqua 40’ 40º 40 9 45 0,55 1400 Cold-40
Gentle Care 20º 20 4 45 0,15 1200 20
Hygiene 20° 20 4 98 0,42 1400 20
Xpress Super Short 30 2 36 0,10 1400 Cold-30
Daily Express
90 9 63 2,10 1400 Cold-90
60 9 60 1,10 1400 Cold-90
30 9 55 0,40 1400 Cold-90

16 / EN Washing Machine / User’s Manual
C
INFORMATION
• The auxiliary functions in the table may vary
according to the model of your machine.
• Water and power consumption may vary
subject to the changes in water pressure,
water hardness and temperature, ambient
temperature, type and amount of laundry,
selection of auxiliary functions and spin
speed, and changes in electric voltage.
• “You can see the washing duration on the
display of your machine while selecting a
programme. Depending on the amount of
laundry you have loaded into your machine,
there may be a difference of 1-1.5 hours
between the duration shown on the
display and the actual duration of the
wash cycle. Duration will be automatically
updated soon after the washing starts.“
• “Selection patterns for auxiliary
functions can be changed by the
manufacturer company. New selection
patterns can be added or removed.”
• “The spin speed of your machine may
vary according to the programme;
this spin speed cannot exceed the
max. spin speed of your machine.”
4.3.7 Auxiliary function selection
Select the desired auxiliary functions before
starting the programme.
Whenever a programme is selected, if a
relevant auxiliary function is selected its related
indicator light will illuminate.
C
INFORMATION
• Indicator lights of the auxiliary functions
that are not allowed to be selected
with the current programme will flash
and an audio warning is given.
Furthermore, you may also select or cancel
auxiliary functions that are suitable to the
running programme after the washing cycle
starts. If the wash cycle has reached a point
where no auxiliary function can be selected,
an audio warning will be given and the related
auxiliary function's light will flash.
C
INFORMATION
• Some functions cannot be selected
together. If a second auxiliary function
conflicting with the first one is selected
before starting the machine, the function
selected first will be canceled and the
second auxiliary function selection
will remain active. For example, if you
want to select Quick Wash after you
have selected the Additional Water,
Additional Water will be canceled and
Quick Wash will remain active.
• An auxiliary function that is not compatible
with the programme cannot be selected.
(See,“Programmeandconsumptiontable")
• Some programmes have auxiliary
functions that must be operated
simultaneously. Those functions
cannot be cancelled. The frame of the
auxiliary function will not be illuminated,
only inner area will be illuminated.
• Prewash
A Prewash is only worthwhile for heavily soiled
laundry. Not using the Prewash will save
energy, water, detergent and time.
C
INFORMATION
• Prewash without detergent is
recommended for tulle and curtains.
• Quick Wash
This function can be used in Cottons and
Synthetics programmes. It decreases the
washing times and also the number of rinsing
steps for lightly soiled laundry.
C
INFORMATION
• When you select this function, load your
machine with half of the maximum laundry
specified in the programme table.

17 / EN Washing Machine / User’s Manual
C
INFORMATION
• Additional laundry may be loaded during the
End Time countdown period. At the end of
the countdown, End Time indicator turns
off, washing cycle starts and the time of the
selected programme appears on the display.
• When the End Time selection is
completed, the time appears on the
screen consists of end time plus the
duration of the selected programme.
4.3.9 Starting the programme 1.
Press Start / Pause button to start the
programme.
2. Programme follow-up light showing the
startup of the programme will turn on.
C
INFORMATION
• If no programme is started or no key
is pressed within 1-10 minute during
programme selection process, the
machine will switch to OFF mode.
Display and all indicators are turned off.
• Selected programme data will be
displayed if you press On / Off button.
4.3.10 Loading door lock
There is a locking system on the loading
door of the machine that prevents opening
of the door in cases when the water level is
unsuitable.
"DoorLocked"LEDinthepanelturnsonwhen
the loading door is locked.
4.3.11 Changing the selections
after the programme has started
After the programme has started you can
make the following changes.
4.3.11.1 Switching the
machine to pause mode:
Press the Start/Pause button to switch the
machine to pause mode while a programme
is running. The light indicating the Start/Pause
status and programme step starts flashing
on the Programme Follow-up indicator to
show that the machine has been switched
tothepausemode.Also,LoadingDoorlight
will also flash until the door is ready to be
opened. When the loading door is ready to be
opened loading door light will will turn off and
programme step indicator and Start / Stop
LEDcontinuetoflash.
• Pet Hair Removal
This function helps to remove pet hair that
remain on your garments more effectively.
When you select this function, Prewash and
Extra Rinse steps are added to the normal
programme. Thus, washing is performed with
more water (30%) and the pet hair is removed
more effectively.
A
WARNING
• Never wash your pets in the
washing machine.
4.3.8 End Time
With the End Time function, the startup
of the programme may be delayed up to
24 hours. After pressing End Time button,
the programme's estimated ending time is
displayed. If the End Time is adjusted, End
Time indicator is illuminated.
In order for the End Time function to be
activated and the programme to be completed
at the end of the specified time, you must press
Start / Pause button after adjusting the time.
If you want to cancel End Time function, press
On / Off button to turn off and on the machine.
C
INFORMATION
• Do not use liquid detergents when
you activate End Time function! There
is the risk of staining of the clothes.
1 Open the loading door, place the laundry
and put detergent, etc.
2 Select the washing programme,
temperature, spin speed and, if required,
the auxiliary functions.
3 Set the end time of your choice by pressing
the End Time button. End Time indicator
illuminates.
4 Press Start / Pause button. Time
countdown starts. “:” sign in the middle of
the end time on the display starts flashing.

18 / EN Washing Machine / User’s Manual
Also, when the loading door is ready to be
opened,LoadingDoorlightwillalsoturnoffin
addition to the programme step light.
4.3.11.2 Changing the auxiliary
function, speed and temperature
Depending on the step the programme has
reached, you can cancel or select the auxiliary
functions.See,"Auxiliaryfunctionselection".
You can also change the speed and
temperaturesettings.See,"Spinspeed
selection"and"Temperatureselection".
C
INFORMATION
• If no change is allowed, the relevant
light will flash for 3 times.
4.3.11.3 Adding or taking out laundry
1. Press the Start / Pause button to switch the
machine to pause mode. The programme
follow-up light of the relevant step during
which the machine was switched into the
pause mode will flash.
2. WaituntiltheLoadingDoorcanbeopened.
3. OpentheLoadingDoorandaddortakeout
the laundry.
5. ClosetheLoadingDoor.
6.Makechangesinauxiliaryfunctions,
temperature and speed settings if
necessary.
7. Press Start/Pause button to start the
machine.
4.3.12 Child Lock
UseChildLockfunctiontopreventchildren
from tampering with the machine. Thus
you can avoid any changes in a running
programme.
C
INFORMATION
• You can switch on and off the machine
with On / Off button when the Child
Lockisactive.Whenyouswitchon
the machine again, programme will
resume from where it has stopped.
4.3.12.1 To activate the child lock:
Press and hold Auxiliary Function button
2 for 3 seconds. In the programme selection
displayonthepanel,"CLOn"lightwillturnon.
You can release Auxiliary Function button 2
when this warning is displayed.
4.3.12.2 To deactivate the child lock:
Press and hold Auxiliary Function button
2 for 3 seconds. In the programme selection
displayonthepanel,"CLOff"lightwillturnon.
4.3.13 Canceling the programme
The programme is cancelled when the
machine is turned off and on again. Press and
hold On / Off button for 3 seconds.
C
INFORMATION
• If you press On / Off button when
theChildLockisenabled,the
programme will not be cancelled. You
shouldcanceltheChildLockfirst.
• If you want to open the loading door
after you have cancelled the programme
but it is not possible to open the loading
door since the water level in the machine
is above the loading door opening,
then turn the Programme Selection
knob to Pump+Spin programme and
discharge the water in the machine.
4.3.14 End of programme
EndLEDappearsonthedisplaywhenthe
programme is completed.
If you do not press any button for 10 minutes,
the machine will switch to OFF mode. Display
and all indicators are turned off.
Completed programme steps will be displayed
if you press On / Off button.
4.3.15 Your machine features
"Standby Mode".
After you switch on your machine with On-Off
button, if no program is started or no other
procedure is performed at the selection step
or no action is taken within approx. 10 minutes
after the selected program ends, your machine
will switch to OFF mode automatically. Display
and all indicators are turned off. Selected
programme data will be displayed if you press
On / Off button. Before you start the program,
check the accuracy of your selections. If
necessary, repeat them. This is not an error.

19 / EN Washing Machine / User’s Manual
4.4 Maintenance and cleaning
Service life of product extends and frequently
experienced problems will be reduced if it is
cleaned at regular intervals.
4.4.1 Cleaning the detergent drawer
Clean the detergent
drawer at regular intervals
(every 4-5 washing cycles)
as shown below in order
to prevent accumulation of
powder detergent in time.
Lifttherearpartofthesiphontoremoveitas
illustrated.
If more than normal amount of water and
softener mixture starts to gather in the softener
compartment, the siphon must be cleaned.
1 Press the dotted point on the siphon in the
softener compartment and pull towards you
until the compartment is removed from the
machine.
2. Wash the detergent drawer and the
siphon with plenty of lukewarm water in a
washbasin. In order to prevent the residues to
contact your skin, clean it with an appropriate
brush by wearing a pair of gloves.
3 Insert the drawer back into its place after
cleaning and make sure that it is seated well.
4.4.2 Cleaning the loading
door and the drum
For products with drum cleaning programme,
please see Operating the product -
Programmes.
C
INFORMATION
• Repeat Drum Cleaning process
in every 2 months.
• Use an detergent / anti-limescale
suitable for the washing machines.
After every washing
make sure that no foreign
substance is left in the
drum.
If the holes on the bellow shown in the figure is
blocked, open the holes using a toothpick.
C
INFORMATION
• Foreign metal substances will cause
rust stains in the drum. Clean the
stains on the drum surface by using
cleaning agents for stainless steel.
A
WARNING
• Never use steel wool or wire wool.
These will damage the painted,
chromated and plastic surfaces.
4.4.3 Cleaning the body
and control panel
Wipe the body of the machine with soapy
water or non-corrosive mild gel detergents as
necessary, and dry with a soft cloth.
Use only a soft and damp cloth to clean the
control panel.
4.4.4 Cleaning the water intake filters
There is a filter at the end of each water intake
valve at the rear of the machine and also at
the end of each water intake hose where they
are connected to the tap. These filters prevent
foreign substances and dirt in the water to
enter the washing machine. Filters should be
cleaned as they do get dirty.
1. Close the
taps.
2. Remove the
nuts of the
water intake
hoses to
access the
filters on the
water intake
valves.
Clean them with an appropriate brush. If the
filters are too dirty, remove them from their
places with a pliers and clean in this way.
3. Take out the filters on the flat ends of the
water intake hoses together with the gaskets
and clean thoroughly under running water.
4. Replace the seals and filters carefully and
tighten their nuts by hand.

20 / EN Washing Machine / User’s Manual
4.4.5 Draining remaining water
and cleaning the pump filter
The filter system in your machine prevents
solid items such as buttons, coins and fabric
fibers clogging the pump impeller during
discharge of washing water. Thus, the water
will be discharged without any problem and the
service life of the pump will extend.
If the machine fails to drain water, the pump filter
is clogged. Filter must be cleaned whenever it
is clogged or in every 3 months. Water must be
drained off first to clean the pump filter.
In addition, prior to transporting the machine
(e.g., when moving to another house) and in
caseoffreezingofthewater,watermayhave
to be drained completely.
A
CAUTION!
• Foreign substances left in the pump
filter may damage your machine
or may cause noise problem.
• If the product is not being used,
shut the tap shut, remove mains
pipe and drain the water inside the
machineagainstanylikelyfreezing.
• After each use, turn off the water tap to
which the mains hose is connected.
In order to clean the dirty filter and discharge
the water:
1 Unplug the machine to cut off the supply
power.
A
CAUTION!
• Temperature of the water inside the
machine may rise up to 90 ºC. To avoid
the burning risk, clean the filter after the
water inside the machine is cooled down.
2. Open the filter cover.
3 Follow the below procedures in order to
drain water.
The product has an emergency water draining
hose, in order to drain the water:
a Pull the emergency draining hose out from
its seat
b Place a large container at the end of the
hose. Drain the water into the container by
pulling out the plug at the end of the hose.
When the container is full, block the inlet
of the hose by replacing the plug. After
the container is emptied, repeat the above
procedure to drain the water in the machine
completely.
c When draining of water is finished, close the
end by the plug again and fix the hose in its
place.
d Turn and remove the pump filter.
4. Clean any residues inside the filter as well
as fibers, if any, around the pump impeller
region.
5. Replace the filter.
6. If the filter cap is composed of two pieces,
close the filter cap by pressing on the tab.
If it is one piece, seat the tabs in the lower
part into their places first, and then press
the upper part to close.
