Beko WTV7825XCW1 User manual

Washing machine
User Manual
WTV7825XCW1
Document number :2820529653_EN/ 04-07-21.(0:13)
Translated from Dutch to English - www.onlinedoctranslator.com

1 General
safety instructions • The water supply and drain
hoses must be securely
attached and undamaged.
Otherwise, water may leak
out.
• Never open the loading door or
remove the filter if there is still
water in the product. Otherwise,
there is a risk of flooding and
injury from hot water.
• Do not open the locked loading
door forcibly. The door
will open immediately
after the end of the wash
cycle. If the door does
not open, apply the
solutions given for the
error
'Loading door cannot be
opened.' in the
'Troubleshooting' chapter. In
the event that the loading
door is forcibly opened, the
door and lock mechanism
may be damaged.
• Use detergents,
softeners and supplements
that are only suitable for
automatic washing machines.
• Follow the instructions on the
fabric label and on the
detergent packaging.
This chapter contains
safety instructions that can help to
avoid the risk of injury and
property damage. All types of
warranties are void if these
instructions are not followed.
1.1 Safety for
life and property
aPAY ATTENTION!
• Never place the product on a
carpeted floor. Otherwise, a
lack of airflow under the
machine will cause the
electrical parts to overheat.
This will cause problems
with your product.
• When the product is not in
use, unplug the power cord.
• Have the installation
and repair work
always be performed by an
authorized service technician. The
manufacturer cannot
be held liable for damage
caused by work
performed by
unauthorized persons.
This product has been manufactured using the latest environmentally friendly technology.

1.2 Safety on hot
surfaces aPAY ATTENTION!
• Packaging materials
are hazardous to
children. save all
packaging materials in a
safe place out of the reach
of children.
• Electrical products are
dangerous for children. Keep
children away from the
product during its operation.
Do not let them play with the
product. Use the child lock to
prevent children from
manipulating the product.
• Do not forget to close the loading
door when you leave the room
where the product is located.
• Keep all detergents and
additives in a safe place out
of the reach of children.
Close the lid of the
detergent container or seal
the package.
aPAY ATTENTION!
• The loading door window
becomes hot during washing
at higher temperatures.
Therefore, in particular, do
not allow children to touch
the loading door window
during washing.
1.3 Child safety
aPAY ATTENTION!
• This product can be used by
children aged 8 years and
above and persons with
physical, sensory or
mental disorders or by
inexperienced or unskilled
persons if they are
supervised or trained in the
safe use of the product and
understand the risks
involved. Children should not
play with the product.
Cleaning and maintenance
shall not be made by children
unless they are supervised.
Children under 3 years old
should be kept away if they
are under
under constant supervision.
3 / NL Washing Machine / User Manual

1.4 Electrical safety BDANGER
BDANGER • Do not clean the product by
spraying or pouring water
on it! There is a risk of
electric shock!
• Never touch the power cable
with wet hands! Never pull
the plug out of the socket by
pulling on the cable. Always
press the plug with one
hand and pull the plug out
by grasping it with the other
hand.
• The product must be
unplugged from the
mains socket during
installation, maintenance,
cleaning and repair work.
• If the power cord is damaged, it
must be replaced
replaced by the
manufacturer, an authorized
service agent or a similarly
qualified person (preferably
an electrician) or person
designated by the importer
to avoid potential hazards.
• If the product malfunctions,
do not operate it without
having it repaired by an
authorized service
technician. There is a risk of
electric shock!
• This product is designed to
resume operation in the
event of a power
resumption after a power
failure. If you want to
cancel the program, see
paragraph "Cancelling a
program".
• Connect the product to a
grounded outlet with a 16 A
fuse. Make sure that the
grounding wire is installed
by a licensed electrician. Our
company is not responsible
for damages arising from
the
use of the product without
grounding in accordance with
local regulations.
4 / NL Washing Machine / User Manual

2.Important Safety and
Environmental Instructions
3 Intended use
• This product is designed for household use.
It is not intended for
commercial purposes and should not be used
for any purpose not intended.
• The product may only be used to wash
and rinse laundry marked for this
purpose.
• The manufacturer declines any
responsibility arising from incorrect
use or transportation.
• The life of your product is 10 years.
During this period, original parts are
available to keep the device working
properly.
• This appliance is intended for household
use and similar applications such as:
– staff kitchens in shops, offices and other
work environments;
2.1 WEEE Standard Compliance
This product complies with the
EU WEEE standard (2012/19/
EU). This product bears the
classification symbol for the
selective sorting of waste
electrical and electronic
equipment (WEEE).
This product is made of high quality parts
and materials that can be reused and are
suitable for recycling. Do not dispose of the
product with normal household waste at
the end of its life. Take it to a collection
point for the recycling of electrical and
electronic equipment. Contact your local
authorities to find out where these
collection points are located.
– farms;
– by customers in hotels, motels and
other lodging facilities;
– bed and breakfast locations;
– common areas in apartment buildings or
laundromats.
Compliance with RoHS Directive:
The product you have purchased complies
with the EU RoHS Directive (2011/65/EU). It
does not contain any harmful and prohibited
materials as stipulated in the directive.
2.2 Packaging information
The product packaging materials are
made from recyclable materials in
accordance with our National
Environmental Regulations.
Do not dispose of the packaging
material with household or other
waste. Take it to the packaging
material collection points specified by
the local authorities.
5/ NL Washing Machine / User Manual

4 Technical specifications
Supplier name or trade name Beko
WTV7825XCW1
Model Name
7145745700
Rated power (kg) 7
Maximum spin speed (rpm) 1600
Built-in no
Height (cm) 84
Width (cm) 60
Depth (cm) 59
Single Water Inlet / Double Water Inlet †
• Available
Electric current (V/Hz) 230V / 50Hz
Total current (A) 10
Total power (W) 2200
Model code 9211
CINFORMATION
• You can view the model information contained in the
product database by going to the following website
and searching for your model identifier (*) which can
be found on the energy label.
SUPPLIER'S NAME MODEL IDENTIFIER †
aahttps://eprel.ec.europa.eu/
Symbol table
prewash Fast Fast+ Additional
rinse Extra water Anti wrinkle Removal of
pet hair steam night mode To soften rinse hold immerse Automatic
dosage Choice for
liquid
laundry detergent
Choice
fabric softener
To rinse Spin +
pumps Pumps Temperature Centrifuge Not
Centrifuge Tap water
(cold) No
water
Time delay Door
lock children
key lock
On off Start /
pause
Soil degree Add item Program
to download
Wash OK
(end)
Cancel Anti-crease+ To dry Extra Dry Cupboard Dry Iron dry Time drying wash and
to wear
6/ NL Washing Machine / User Manual

4.1 Installation 4.1.3 Removing the Transport
Locks
• Consult the nearest authorized service
for the installation of your product. 1. Loosen all bolts with a suitable wrench
until they turn freely
• Site preparation and electrical,
water supply and
- drainage installations at the installation site
are the responsibility of the customer.
2. Remove the transport safety bolts by
turning them slightly.
3. Insert the plastic covers in the user
manual bag into the holes on the back
panel.
• Make sure that the water inlet and drain
hoses as well as the power cord are not
bent, pinched or squeezed when placing
the product in place after installation or
cleaning work.
• Make sure that the installation and electrical
connections of the product are
performed by an authorized service. The
manufacturer cannot be held liable for
damage caused by work performed by
unauthorized persons. aPAY ATTENTION!
• Remove the transport security bolts
before using the washing machine!
Otherwise, the product will be damaged.
• Visually check the product for defects before
installation. In that case, don't install it.
Damaged products can pose a risk to your
safety.
4.1.1 Suitable installation location CINFORMATION
• Place the product on a hard and flat floor.
Do not place it on deep-pile carpet or
similar surfaces.
• Store the transportation security bolts in a
safe place for reuse for future
transportation.
• Install the transportation safety bolts in
the reverse order of the disassembly
procedure.
• Never move the product without the
transport security bolts securely in place!
• When the washer and dryer are placed on
top of each other, the total weight is
- when loaded - 180 kg. Place the product
on a firm and level floor that has sufficient
capacity to support the load.
• Do not place the product on top of the power cord.
• Do not install the product in environments
where the temperature may fall below 0 ºC. 4.1.4 Connecting the water supply
• It is recommended to leave a gap on
the sides of the machine to reduce
vibration and noise. CINFORMATION
• 10-80 liters of water per minute should flow
from the tap to keep your machine running
smoothly. Fit a pressure reducing valve if the
water pressure is too high.
• Do not place the product on a raised floor
next to the ledge or on a platform.
• Do not place heat sources such as hot plates,
irons, ovens, etc. on the washing machine or
use them on the product.
4.1.2 Remove packaging reinforcement aPAY ATTENTION!
• Models with single water supply should
not be connected to the hot water tap. In
this case, the laundry will be damaged or
the product will switch to protection
mode and not work.
Tilt the machine
back to remove the
packing reinforcement.
Remove the packaging
reinforcement by pulling
on the ribbon
Pull. Enter this
not only act.
7/ NL Washing Machine / User Manual

• In case the drain hose is raised after being
at ground level or close to the ground (less
than 40 cm above the ground), water
drainage may become more difficult and
the laundry may come out soaking wet.
Therefore, follow the heights listed in the
picture.
• To prevent the drain water from flowing
back into the machine and to ensure easy
drainage, do not immerse the end of the
hose in the drain water and do not insert
more than 15 cm into the drain. If it is too
long, shorten it.
1Tighten the hose nuts by hand. Never
use a wrench when tightening the nuts.
2When the hose connection is complete,
check for leakage problems at the
connection points by opening the valves
all the way. If there are leaks, turn off the
tap, remove the nut. Tighten the nut
again carefully after checking the seal.
Keep the taps of the product closed when
not in use to prevent water leakage and
resulting damage.
• The end of the hose must not be bent, it
must not be stepped on and the hose must
not be pinched between the drain and the
machine.
• If the hose is too short, use it by adding an
original extension hose. The hose should
not be longer than 3.2 m. To avoid failure
due to water leaks, the connection
between the extension hose and the
product drain hose must be properly fitted
with a suitable clamp so that it does not
come loose and leak.
4.1.5 The drain hose
connect to the drain
• Attach the end of the drain hose directly to
the water drain, sink or bathtub. 4.1.6 Adjust legs
aaPAY ATTENTION!
PAY ATTENTION!
• In order for your machine to operate more
quietly and without vibrations, it must be
level and balanced on its feet. Balance the
machine by adjusting the legs. Otherwise,
the product may move and cause
compression and vibration problems.
• Do not use any tools to loosen the locknuts.
Otherwise they may be damaged.
• Your floor will flood if the hose comes
out of its housing while draining
water. There is also a risk of burns
due to high
washing temperatures! To avoid such
situations and to ensure that the machine
takes in and pumps water without any
problems, the drain hose must be properly
secured.
1Loosen the locknuts on the feet by hand.
2Adjust the feet until the product is stable
and balanced.
3. Retighten all locknuts by hand.
• Connect the drain hose at a height of at least
40 cm and at most 100 cm.
8 / NL Washing Machine / User Manual
100 cm
40 cm

4.1.7 Electrical connection 4.2 Preparation
Connect the product to a grounded outlet
protected by a 16 amp fuse. Our company is
not responsible for damage resulting from
using the product without grounding in
accordance with local regulations.
4.2.1 Sorting the laundry
†Sort the laundry according to the type of
fabric, colour, degree of soiling and permitted
water temperature.
• The connection must comply with national
regulations.
†Always follow the instructions on the clothing labels.
4.2.2 Preparing the
laundry for washing
• The electrical outlet wiring must be
sufficient to meet the requirements of
the device. The use of an earth leakage
circuit breaker is recommended.
• Laundry with metal parts such as underwire
bras, buckles or metal buttons will
damage the machine. Remove the metal
parts or wash the clothes in a laundry bag
or pillowcase.
• The power cord plug should be
within easy reach after installation.
• If the current rating of the fuse or circuit
breaker in the home is less than 16 amps,
have a qualified electrician install a 16 amp
fuse.
• Take all objects out of the pockets such as
coins, pens and paper clips, turn the
pockets inside out and brush them out.
Similar objects may damage the product or
cause noise.
• The voltage stated in the "Technical specifications"
must be the same as the mains voltage. †Place small items of clothing such as baby socks
and nylon stockings in a laundry bag or
pillowcase.
• Do not make connections via extension cords
or multi-way plugs.
a• Insert curtains without compressing
them. Remove fastening hooks from the
curtains.
PAY ATTENTION!
• Damaged power cables must be
replaced by qualified service
technicians.
• Close zippers, sew loose buttons and
mend tears.
• Wash 'machine washable' or 'hand
washable' products only with a suitable
program.
4.1.8 First use
Before you start
using the product,
make sure the
preparations
be affected according to
the “Important
instructions
• Do not wash colors and white goods together.
New, dark-colored cotton fabrics give off a lot
of color. Wash them separately.
• Stubborn stains should be treated carefully
before washing. Check with a dry cleaner if
you are not sure.
for safety and environment” and the instructions in
the “Installation” section. • Only use paint / color refreshers and
descaling agents that are suitable for
machine washing. Always follow the
instructions on the packaging.
To prepare the product for washing laundry,
perform the first operation in the Drum
cleaning program. If this program is not
available on your machine, perform the
method as described in section 4.4.2.
• Wash trousers and delicates
inside out.
• Place angora wool items in the freezer for a
few hours before washing. This reduces
fluff.
CINFORMATION
• Laundry soiled with materials such as
flour, lime dust, milk powder, etc. must
be shaken out well before being placed
in the machine. Such dust and powder
on the laundry may accumulate on the
inner parts of the machine over time and
cause damage.
• Use an anti-scale agent suitable for
washing machines.
• Some water may have remained
in the product due to the
quality control processes in production.
This is not harmful to the machine.
9 / NL Washing Machine / User Manual

4.2.3 Tips to save energy
and water
4.2.6 Detergent and
use fabric softener
The following information will help you
to use the product in an ecological and
energy-saving manner. CINFORMATION
• If you use detergent, fabric softener, starch,
dye, bleach or descaler, read the
manufacturer's instructions on the
packaging and follow the dosage values.
Use a measuring cup if possible.
• Operate the product at the highest power
allowed by the program you selected, but
do not overload. See “Program and
consumption table”.
• Always follow the instructions on the
detergent packaging.
• Wash lightly soiled laundry at low
temperatures. 23 1 The
consists of three subjects:
detergent drawer e
• Use faster programs for small amounts
of lightly soiled laundry. – (1) for prewash
– (2) for main wash
– (3) for fabric softener
• Do not use prewash and high
temperatures for laundry that is not
heavily soiled or stained.
• If you intend to tumble dry your
laundry, select the high
recommended spin speed during
washing process.
– ( ) in addition, the fabric
softener compartment
a siphon.
• Do not use more detergent than the amount
recommended on the suit.
Detergent, fabric softener and other
cleaning agents
4.2.4 Loading the laundry • Add detergent and fabric softener before
starting the washing program.
1. Open the loading door.
2. Place the laundry loosely in the machine. • Do not leave the detergent drawer open during
washing!
3. Push the loading door shut until you hear a
click. Make sure nothing gets in the door.
The loading door is locked when a
program is running. The door lock will
open immediately after the wash cycle has
finished. You can then open the loading
door. If the door does not open, apply the
solutions provided for the error 'Loading
door cannot be opened.' in the
'Troubleshooting' chapter.
• If you run a program without prewash, do not put
detergent in the prewash compartment
(compartment no. "1").
• If you run a program with prewash, do not put
liquid detergent in the prewash compartment
(compartment no. "1").
†Do not select a program with prewash
when using a detergent bag or detergent
bulb. Place the bag or bulb directly
between the wax in the product.
4.2.5 Correct charging capacity • If you use liquid detergent, do not forget to
place the liquid detergent container in the
main wash compartment (compartment no.
"2").
The maximum load capacity depends on the
type of laundry, the degree of soiling and the
desired washing program.
The machine adjusts the amount of water
according to the weight of the laundry you
have placed.
Selecting the detergent type
The detergent to be used depends on the
washing program, type of material and colour.
aWARNING! • Use different detergents for colored and
white clothes.
• Follow the information in the "Table program
and consumption". If overcharged, the
machine performance will decrease. In
addition, noise and vibration problems may
arise.
• Wash your delicate clothes with special
detergents (liquid detergent, wool detergent,
etc.) especially for delicate clothes and on the
recommended programs.
10 / NL Washing Machine / User Manual

• It is recommended to use a liquid
detergent for washing dark clothes and
blankets.
• Wash wool at the recommended program
with a special wool detergent.
• See the program descriptions section for
recommended programs for different
fabrics.
• All detergent recommendations are valid
for the selectable temperature range of
programmes.
If the product is equipped with a liquid
detergent compartment:
• Press the dot indicated to turn the
appliance if you want to use liquid
detergent.
The part that falls down will act as a
barrier for the liquid detergent.
aWARNING!
• Only use detergents specifically intended
for the washing machine.
• Do not use soap powder. • If necessary, clean the appliance with water
while it is in place or by removing it.
Adjust the amount of detergent
The amount of detergent to be used depends on
the amount of laundry, the degree of soiling and
the water hardness.
• If you use powder detergent, the
appliance must be in the top position
• Do not exceed the dosage recommended
on the detergent packaging to avoid
problems such as excessive foaming,
poor rinsing, financial savings and also
environmental protection
• Use less detergent for small amounts
or lightly soiled clothes.
Using fabric softeners If the product is not equipped with a
liquid detergent container:
Place the softener in the softener compartment
of the detergent drawer. • Do not use liquid detergent for prewash in
a program with prewash.
• Do not exceed the (>max<) level in the
softener compartment. • Liquid detergent will stain your clothes if
used with the end time function to start
the program later. If you are going to use
the end time function, do not use liquid
detergent.
• If the fabric softener is no longer very
liquid, dilute it with water before placing
it in the detergent drawer.
aWARNING! Use gel and detergent tablets
• Do not use liquid detergents or other
cleaning products other than fabric
softeners to soften clothes that are suitable
for washing machines.
• If the gel detergent is liquid and your machine
does not have a special container for liquid
detergent, put the gel detergent in the main
wash compartment during the first water
supply. If your product is equipped with a
liquid detergent container, put the detergent
in this container before starting the
programme.
Using Liquid Detergents
If the product is equipped with a liquid
detergent container:
• Place the container for liquid detergent in
compartment no. "2". • If the gel detergent is not liquid or is in a
capsule, put it directly into the drum
before washing.
• If the liquid detergent has become less
liquid, dilute it with water before pouring it
into the detergent container. • Place the detergent tablets in the main wash
compartment (compartment no. "2") or directly
into the drum before washing.
11 / NL Washing Machine / User Manual

The use of starch • Do not use bleach mixed with detergent.
• Add liquid starch, powdered starch or colorant to
the fabric softener compartment. • Use a small amount (about 50 ml) of bleach
and rinse the clothes well, as this will
cause skin irritation.
• Do not use fabric softener and starch together
in a wash cycle.
• Wipe the inside of the machine with a
damp and clean cloth after using starch.
• Do not pour bleach on the laundry.
• Do not use bleach on colored laundry.
• When using oxygen-based bleach, select a
program that washes the laundry at a low
temperature.
Using anti-limescale products
• If necessary, only use anti-scaling agents
specifically intended for washing machines. • Oxygen-based bleach may be used in
conjunction with laundry detergent.
If the thickness is not the same as that of the
detergent, first put the detergent in
compartment no. Place "2" in the detergent
drawer and wait for the detergent to drain when
the product takes water. While the machine
continues to take in water, add the bleach to the
same compartment.
Use of bleach
• Select a program with prewash and add
bleach at the start of the prewash. Do not
put detergent in the prewash
compartment. As an alternative
application, select a program with extra
rinse and add bleach
while the machine takes water from the detergent
compartment during the first rinse phase.
4.2.7 Tips for efficient washing
Clothing
Light colors and
Kitchen appliances
Black / dark
colors
Delicates / wool /
silk
Colors
(Recommended
temperature based
of the degree of soiling: cold
- 40 oC)
(Recommended temperature
based on the degree of dirt: 40-
90 oC)
(Recommended temperature based
on the degree of soiling: cold
- 40 oC)
(Recommended
temperature based on the
degree of dirt: cold -30 oC)
Stains may require
pretreatment or prewash.
Washing powder and liquid
detergents recommended
for whites can be used in
recommended doses for
heavily soiled laundry. It is
recommended to use
washing powder to clean
clay and dirt and bleach
sensitive stains.
Washing powder and liquid
detergents recommended
for colored laundry can be
used in doses recommended
for heavily soiled laundry. It
is recommended to use
washing powder to clean
clay and dirt and bleach
sensitive stains. Use
detergents without
bleaching agents.
Prefer liquid
detergents
that became special
developed for
fine laundry. Wool
and silk should be
washed with special
developed for that purpose
detergents.
Liquid Detergents
suitable for
colored laundry and
dark colours
can in the
recommended doses
are used for
heavily soiled laundry.
Liquid Detergents
suitable for colored laundry
and dark clothes
colors can be used in the
recommended doses
are used
for normally soiled
laundry.
Prefer liquid
detergents
that became special
developed for delicates.
Wool and silk should be
washed with special
developed for that purpose
detergents.
Washing powder and liquid
detergents recommended for
colored laundry can be used in
doses recommended for
normally soiled laundry. Use
detergents that do not contain
bleach.
Washing powder and liquid
detergents recommended
for whites can be used in
recommended doses for
normally soiled laundry.
Prefer liquid
detergents
that became special
developed for delicates.
Wool and silk should be
washed with special
developed for that purpose
detergents.
Washing powder and liquid
detergents recommended for
colored laundry can be used in
doses recommended for
lightly soiled laundry. Use
detergents that do not contain
bleach.
Liquid Detergents
suitable for colored laundry
and dark clothes
colors can be used in the
recommended doses
are used for
lightly soiled laundry.
Washing powder and liquid
detergents recommended
for whites can be used in
the recommended doses
for lightly soiled laundry.
12 / NL Washing Machine / User Manual
Soil Degrees
Normally soiled
lightly soiled (For example for
causes stains through the body on collars and cuffs.)
heavily soiled
(Without visible stains.)
(Tough stains like grass, coffee, fruit, and blood.)

4.2.8 Displayed program time
You can see the duration of the program on the
machine's screen when you select a program.
The duration of the program is automatically
adjusted while the program is running,
depending on the amount of laundry you have
loaded in your machine, the foam, an
unbalanced load, fluctuations in the power
supply, the water pressure and the program
settings.
SPECIAL CASE:When starting the Cottons and
Cottons Eco programmes, the display shows
the duration of half a load, which is the most
common use. After the program starts, the
actual load is detected by the machine within
20-25 minutes.
If the detected load is more than half a load,
the washing program will be adjusted
accordingly and the program duration will be
increased automatically. You can see this
change on the display.
13 / NL Washing Machine / User Manual

4.3 Operating the product 1 - Program selector knob (top position
On / Off)
4.3.1 Control panel 2 - Screen
3 - End time setting button 4 -
Program progress indicator 5 -
Start/pause button
6 - Auxiliary function button 3 7 -
Auxiliary function button 2 8 -
Auxiliary function button 1
9 - Spin speed control knob 10 -
Temperature control knob
1 2 3
4
10 9 8 7 6 5
4.3.2 Preparing the machine 4.3.3 Program selection and
tips for efficient washing
1. Make sure the hoses are connected
securely. 1. Select the appropriate program for the
type, amount and degree of soiling of the
laundry according to the "Table of
program and consumption" and the
temperature table below.
2. Plug the machine into the wall socket.
3. Fully open the tap.
4. Place the laundry in the machine.
5. Add detergent and fabric softener. 2. Select the desired program with the
Program Selection knob.
4.3.4 Table program and consumption
NL 2Help function
Selectable
temperature range
in C
Program
90 7 95 2.40 1600 †††† Cold - 90
Cotton 60 7 95 1.80 1600 †††† Cold - 90
40 7 93 0.97 1600 †††† Cold - 90
40 *** 7 52 0.840 1600 40-60
Eco 40-60 40 *** 3.5 38 0.540 1600 40-60
40 *** 2 28 0.290 1600 40-60
60 3 75 1.35 1200 † † † † Cold - 60
Synthetic 40 3 70 0.85 1200 † † † † Cold - 60
90 7 66 2.20 1400 † † Cold - 90
Xpress / Super Xpress 60 7 66 1.20 1400 † † Cold - 90
30 7 66 0.20 1400 † † Cold - 90
Xpress / Super Xpress + Fast+ 30 2 40 0.15 1400 † † Cold - 30
Mix 40 40 3.5 83 1.00 800 † † † Cold - 40
Wool 40 1,5 62 0.55 1200 Cold - 40
Delicate 40 3.5 60 0.79 800 Cold - 40
Sportswear 40 3.5 58 0.60 1200 † Cold - 40
Dark textile 40 3 88 1.05 1200 † † † † Cold - 40
StainExpert 60 3.5 85 1.70 1600 † † 30-60
down jacket 60 2 105 1,90 1000 40-60
shirts 60 3 70 1,90 800 † † † † 40-60
Hygiene+ 90 7 135 2.70 1600 40-90
Drum cleaning 90 † 85 2.60 600 90
14 / NL Washing Machine / User Manual
max. Load (kg) Water consumption (l) Energy consumption (kWh) max. Speed
prewash Fast+ Pet Hair Removal Anti wrinkle

• : Selectable
* : Automatically selected, cannot be canceled.
* * * : Eco 40-60 with temperature selection 40 °C the test program conforms
EN 60456:2016/A11:2020 and energy label according to the Commission Delegated
Regulation (EU) 2019/2014
- : See program description for maximum load.
CINFORMATION
• Water and power consumption may vary due to changes in water pressure, water hardness
and water temperature, ambient temperature, type and amount of laundry, selection of
auxiliary functions and spin speed and variations in mains voltage.
• You can see the washing time on the machine's display when you select a program. Depending
on the amount of laundry loaded in the machine, there may be a difference of 1 to 1.5 hours
between the time shown on the display and the actual time of the washing program. The time
is automatically corrected just after the washing program starts.
• The auxiliary functions in the table may differ depending on the model of your machine.
• Selection modes of auxiliary functions can be changed by the manufacturer. Existing
choice modes can be removed or new choice modes can be added.
• Always select the lowest temperature that is suitable. The most efficient programs in terms of
energy consumption are mainly those that operate at low temperatures and have a long duration.
• Noise and residual moisture content are affected by the spin speed: the higher the spin
speed in the spin phase, the higher the noise and the lower the residual moisture content.
Consumption values (NL)
40 1600 7 03:27 0.840 52 34 44
Eco 40-60 40 1600 3.5 02:41 0.540 38 34 44
40 1600 2 02:41 0.290 28 24 45
Cotton 20 1600 7 03:25 0.600 93 20 44
Cotton 60 1600 7 03:25 1,800 95 60 44
Synthetic 40 1200 3 02:10 0.850 70 40 40
Xpress / Super Xpress 30 1200 7 00:28 0.200 66 23 62
The values given for the programs, except those of the Eco 40-60 program, are indicative only.
15 / NL Washing Machine / User Manual
Temperature selection (°C) Spin speed (rpm) Capacity (kg) Program duration (hh:mm) Energy consumption (kWh/ cycle) Water consumption (l/cycle) Wash temperature (°C) Residual moisture content †

4.3.5 Main programs of the stated washing temperature. Loading
the machine with less laundry (eg half
capacity or less) may automatically shorten
program phases. In this case, energy and
water consumption will decrease more.
Depending on the type of material, use the
following main programs.
• Cotton
You can wash your durable cotton laundry with this
program (sheets, bed linen, towels, bathrobes,
underwear, etc.). When the quick wash function
button is pressed, the program duration is
considerably shorter, but an effective washing
performance is guaranteed by intensive washing
movements. If the quick wash function button is
not selected, your heavily soiled laundry will be
washed and rinsed with superior performance.
• Hygiene+
Adding a steam step at the beginning of
the program makes the dirt less
stubborn.
Use this program for your laundry (cotton
clothes such as baby clothes, sheets, bed
linen, underwear, etc.) for which you want an
anti-allergic and hygienic washing program at
high temperatures with intensive and long
washing cycles. Thanks to the steam
application before the program starts, the
long heating time and extra rinse, a high level
of hygiene is guaranteed.
• Synthetic
You can use this program to wash T-shirts,
blended synthetic cotton fabrics, etc. The
program time is significantly reduced and
efficient washing performance is guaranteed.
If the quick wash function button is not
selected, your heavily soiled laundry will be
washed and rinsed with superior
performance.
• This program has been tested by “The
British Allergy Foundation” (Allergy UK) in
the 60°C temperature option and has
been certified for its effectiveness in
removing bacteria and mold as well as
allergens.
• Wool
Use this program to wash your woollens
and delicates. Select the correct
temperature that matches the clothing
label. Your laundry is washed with very
gentle movements to avoid damage.
Allergy UK is the trademark of The
British Allergy Foundation. It
label is designed to provide
individuals with information as to
whether the product has the amount
of allergens in the room, where it is
installed, significantly reduce or limit/
reduce/remove allergens. The aim is to
provide evidence that the products
have been scientifically tested or assessed to
provide measurable results.
4.3.6 End of the program
Additional programs are available on the
machine for special cases.
CINFORMATION • Delicate
• Additional programs may differ depending
on the machine model.
You can use this program to wash delicate items
such as cotton/synthetic blend clothes or socks.
The washing movements of this program are
more gentle. Set the temperature to 20 degrees
or use the cold water option for clothes whose
color you want to protect.
† Eco 40-60
The eco 40-60 program can clean normally
soiled cotton laundry marked as washable at
40 °C or 60 °C in the same cycle. This
program is used to assess compliance with
EU ecodesign legislation.
† Xpress / Super Xpress
Use this program to quickly wash your
lightly soiled cotton clothes. If the quick
wash function is selected, the program
duration can be reduced by up to 14
minutes. When the quick wash function is
selected, a maximum of 2 (two) kilos of
laundry may be washed.
Although the washing program lasts
longer than all other programmes, it saves
a lot of energy and water. Actual water
temperature may differ
16 / NL Washing Machine / User Manual

† Dark textile you are going to wash the clothing labels
(recommended for shirts, pants, shorts, T-
shirts, baby clothes, pyjamas, aprons,
tablecloths, bed linen, duvet covers, sheets,
bath/beach towels, towels, socks and cotton
underwear suitable for long high temperature
wash cycles). You can use the automatic stain
program to wash 24 kinds of stains, divided
into two different groups, according to the
quick function selection. Below you see the
stain groups based on the choice of the quick
function.
Use this program to protect the color of your
dark clothes or jeans. This program offers good
washing efficiency even at low temperatures,
thanks to a special drum movement. It is
recommended to use liquid detergent or wool
detergent for dark colored laundry. Do not use
this program for your delicate clothes containing
wool, etc.
†Mix 40
You can use this program to wash cotton
and synthetics together in one wash. Below you will find the stain groups
based on the quick function.
When the quick function is selected:
• Shirts Blood Fruit juice
Use this program to wash cotton and
synthetic shirts, as well as blended synthetics
together. It reduces wrinkling. At the end of
the program, steam is delivered to assist the
anti-crease function. At the end of the
programme, the special spin function and
steam are activated to reduce creases in your
shirts. If the quick wash function is selected,
the pre-treatment algorithm is executed.
Chocolate Ketchup
Pudding Red wine
Egg Curry
Tea Jam
Coffee Charcoal
If the quick function is not selected:
Butter food
Grass mayonnaise
Mud Salad dressing
Coke Makeup
• Apply the pre-treatment agent directly to your
clothes or add it to the detergent if the
machine starts to take water from the main
detergent compartment. This gives you the
same performance as a normal wash, but in
much less time. This extends the life of your
shirts.
Sweat Machine oil
Dirt on collars baby food
• Select the stain program.
• In the above stain groups, find the type of
stain you want to remove and choose the
shortcut button to select the relevant group.
• Sportswear • Read the clothing labels carefully and
make sure the selected temperature and
spin speed are correct.
Use this program to wash outdoor/sports
clothing that contains both cotton/synthetic
blends and water-resistant clothing with eg
gore-tex. This program washes your laundry
gently thanks to its special rotary movements. • Down jacket
Use this program to wash down coats, body
warmers, jackets, etc. that have a "machine
washable" label. Special twists ensure that
the water reaches the air holes around the
springs.
• StainExpert (Stain Expert) Your washing
machine has a special stain program that
removes different types of stains in the most
efficient way. Only use this program for
durable colorfast cotton.
Do not wash delicate clothes or clothes that are
not colourfast with this program. Check before
At the end of the programme, steam is
applied to soften bulky laundry such as
towels.
17 / NL Washing Machine / User Manual

4.3.7 Special programs spin speed. The spin speed will gradually
decrease. Then, depending on the product
model, "Rinse Hold" and "No Spin" options
appear on the screen. If “No Spin” is selected,
the rinse level lights will not come on.
For specific applications, select one of the
following programs.
• To rinse
Use this when you want to rinse or starch
separately. rinse hold
If you do not want to remove the laundry
immediately after the programme, you can
use the rinse hold function and leave your
laundry in the last rinse water to avoid
creasing when there is no more water in the
machine. After this phase, press the start/
pause button if you want to drain the water
without spinning your laundry. The program
will resume where it left off, drain the water
and finish.
• Spin + Pump
Use this program to remove the water on
the clothes/in the machine.
Before selecting this programme, choose the
desired spin speed and press the start/pause
button. The machine will first pump out the
water inside. It will then spin the laundry at
the set spin speed and pump out the water
that is released.
If you want to spin the laundry in the water,
adjust the spin speed and press the start/
pause button. The program will resume. The
water is drained, the laundry is spun and the
program ends.
If you only want to drain the water without
spinning your laundry, select the Drain+Spin
program and select the No Spin function
using the spin speed adjustment knob. Press
the start/pause button.
CINFORMATION CINFORMATION
• If the program has not yet reached the
spin cycle, you can adjust the speed
without pausing the machine.
• Use a lower spin speed for delicates.
4.3.8 Temperature selection
Whenever a new program is selected, the
recommended temperature for that
selected program will appear on the
temperature indicator.
4.3.10 Selection of auxiliary functions
Select the desired auxiliary functions before
starting the program. You can also select or
cancel auxiliary functions that suit the running
program while the machine is in operation
without pressing the start/pause button. To do
this, the machine must be in a step before the
auxiliary function you want to select or cancel. If
the auxiliary function cannot be selected or
cancelled, the relevant function light will flash 3
times to warn the user.
To lower the temperature, press the
"Temperature Adjustment" button again.
The temperature will gradually decrease. If
cold water is selected, the temperature
lights will remain off.
CINFORMATION
• If the program has not yet reached the
heating process, you can
temperature without putting the
machine in Pause mode.
CINFORMATION
• If, before the machine starts, a second
auxiliary function does not match the first
selected one, the first
selected function will be canceled and the second
auxiliary function will continue to operate.
• An auxiliary function that is not compatible
with the program cannot be selected. (See
"Table of program and consumption")
• The auxiliary function buttons may differ
depending on the model of your machine.
4.3.9 Spin speed selection
When a new program is selected, the
recommended spin speed of the selected
program is shown on the spin speed
indicator.
To decrease the spin speed, press the
button to adjust the
18 / NL Washing Machine / User Manual

4.3.10.1 Utilities
†prewash CINFORMATION
A prewash is only useful for very dirty laundry. If
you do not use a prewash, you will save energy,
water, detergent and time.
• This is not a washing program. It's a
maintenance program.
• Do not run this program if there are objects
in the machine. If you try this the machine
will detect a load and abort the program.
CINFORMATION
• Prewash without detergent is recommended
for net curtains and curtains. • Child lock
With the child lock you can prevent
children from touching the machine. This
way you can prevent changes to a
running program.
• Fast+
By selecting this function, the duration of the
relevant programs is reduced by 50%.
Thanks to the optimized washing steps, high
mechanical activity and optimum water
consumption, high washing results are
achieved despite the shortened time.
CINFORMATION
• If the program selector knob is turned while
the child lock is activated, "Con" will appear on
the display. When the child lock is activated,
you cannot make any changes to
programmes, selected temperature, spin
speed or auxiliary functions
apply.
• With the Child Lock activated, even if another
program is selected with the program
selector knob, the previously selected
program will continue to run.
• Pet Hair Removal
This feature lets you remove pet hair on your
clothes more efficiently.
If you select this function, Prewash and Extra
Rinse are added to the normal washing
programme. In this way, more water is used
for the wash cycle to ensure that pet hair is
removed more efficiently.
To activate the child lock:
Press and hold button 2 Auxiliary function
for 3 seconds. While pressing the button for
3 seconds, C03, C02 and C01 will be
displayed respectively. Then “Con” will
appear to warn the user that the parental
lock
is activated. If you press any button or
turn the program selector knob with
child lock activated, the same warning
will be displayed.
4.3.10.2 Selected functions/programs
by pressing the function buttons for 3
seconds
• Drum cleaning
Press and hold auxiliary function button
1 for 3 seconds to select this program.
Do this regularly (once every 1-2 months) to
clean the drum and keep it hygienic. Run the
program when the machine is completely
empty. For better results, add limescale remover
for washing machines to the detergent
compartment. "2". When the program is
finished, leave the loading door ajar to allow the
inside of the machine to dry.
19 / NL Washing Machine / User Manual

To deactivate the child lock: 2. Select the washing programme,
temperature, spin speed and, if desired,
the auxiliary functions.
Press and hold auxiliary function button 2
for 3 seconds while the program is running.
While pressing the button for 3 seconds,
C03, C02 and C01 will be displayed
respectively. Then “COF” appears to warn
the user that the child lock has been
deactivated.
3. Press the end time adjustment button
and select the desired time.
4. Press the start/pause button. The delay time you
have set is displayed. The countdown to the
delay time begins. On the display, “_” moves
from top to bottom until the delay time is
reached.
CINFORMATION
• In addition to the above method, you can
deactivate the child lock by turning the
program selector knob to the on/off
position when no program is running
and select another programme.
• The child lock is not deactivated after a
power failure or when the plug is pulled
out of the socket.
CINFORMATION
• If the program has not started, you can
add laundry to the machine during the
countdown to the delay time.
5. When the delay time is reached, the
duration of the selected program is
displayed. “_” will disappear and the
selected program will start.
†Anti wrinkle Changing the delay time
If you press and hold the auxiliary function
button 3 for 3 seconds, this function is
selected and the program progress light of
the relevant program lights up. If this function
is selected, the drum will run for up to eight
hours to ensure that the clothes do not
wrinkle at the end of the programme. You can
cancel the program and empty the machine at
any time during these eight hours. Just press
any button or turn the program selector knob
to end the function. The program progress
light will stay on even if you end the function
by pressing any button. If you end the
function by turning the program selector
knob, the program follow-up light will go out
or not depending on the selected
programme.
If you want to change the time during the countdown:
Turn the program selector knob to cancel the delay
time function and then set the desired time again.
1. Press the delay time adjustment button.
When pressed for the first time, the
program duration will be rounded to the
closest time to a round number. With
each subsequent press of the button, the
time will increase by one hour.
2. To decrease the delay time, press the
delay adjustment button repeatedly until
the desired time is displayed.
To cancel the delay time function
If you want to cancel the delay start countdown
and start the program immediately:
1. Turn the program selector knob to any
programme. In this way, the delay time is
cancelled. The end/cancel light flashes
continuously.
4.3.11 End time adjustment
The end time adjustment function lets you set the
end time of the program up to 19 hours later. You
can increase this time in 1 hour intervals.
2. Then select the program that you want to run
again.
3. Press the start/pause button to start the
program.
CINFORMATION 4.3.12 Starting the program
• Do not use liquid detergent if you have
selected the end time adjustment function.
This can cause stains on the clothes.
1. Press the start/pause button to start the
program.
2. The program progress light, which
indicates the start of the program, will
light up.
1. Open the loading door, place the laundry
and put detergent, etc.
20 / NL Washing Machine / User Manual
