Washing Machine
User Manual
WY124PT44MW
EN
Document Number=

This product was manufactured using the latest technology in environmentally friendly conditions.
Please read these instructions first before using your
appliance
Dear Customer,
Thank you for choosing a Beko appliance.
Please take some time to read this user manual before using your appliance, to ensure you
know how to safely operate the controls and functions.
Carefully follow all unpacking and installation instructions to ensure the appliance is
correctly connected and fitted prior to use.
Please write your product model and serial number on the last page of this user manual,
and store in a safe location close to the appliance for easy future reference.
This user manual may also be applicable for several other models. Differences between
models will be listed.
If you have any questions or concerns, please call our contact centre or find help and
information online at www.beko.co.uk .com
Explanaton of symbols used throughout ths User Manual
C
Important information or useful hints
about usage.
A
Warning for hazardous situations with
regard to life and property.
B
Warning for electric shock.
Recyclable materials.
Do not dispose of the packaging materials together with domestic or other wastes. Take
them to the packaging material collection points designated by the local authorities.

3 / EN
Washng Machne / User’s Manual
1 General safety instructions 5
1.1 Life and property safety ---------------------------------------------------------------------------5
1.2 Children's safety -----------------------------------------------------------------------------------5
1.3 Electrical safety ------------------------------------------------------------------------------------6
1.4 Hot surface safety---------------------------------------------------------------------------------7
2 Important instructions for the environment 7
2.1 Compliance with WEEE Directive------------------------------------------------------------------7
2.2 Package information ------------------------------------------------------------------------------7
3 Intended use 7
4 Your product 8
4.1 Overview -------------------------------------------------------------------------------------------8
4.2 Package Contents ---------------------------------------------------------------------------------9
4.3 Technical specifications---------------------------------------------------------------------------10
4.4 Installation-----------------------------------------------------------------------------------------11
4.4.1 Approprate nstallaton locaton ------------------------------------------------------------------------11
4.4.2 Removng packagng renforcement --------------------------------------------------------------------11
4.4.3 Removng the transportaton locks ---------------------------------------------------------------------12
4.4.4 Connectng the water supply----------------------------------------------------------------------------12
4.4.5 Connectng the dran hose to the dran -----------------------------------------------------------------13
4.4.6 Adjustng the feet----------------------------------------------------------------------------------------13
4.4.7 Electrcal connecton -------------------------------------------------------------------------------------14
4.4.8 Intal use -------------------------------------------------------------------------------------------------15
4.5 Preparation ----------------------------------------------------------------------------------------16
4.5.1 Sortng the laundry ---------------------------------------------------------------------------------------16
4.5.2 Preparng laundry for washng---------------------------------------------------------------------------17
4.5.3 Tps for energy savng------------------------------------------------------------------------------------17
4.5.4 Loadng the laundry --------------------------------------------------------------------------------------18
4.5.5 Correct load capacty -------------------------------------------------------------------------------------18
4.5.6 Usng detergent and softener ---------------------------------------------------------------------------18
4.5.7 Tps for effcent washng--------------------------------------------------------------------------------21
TABLE OF CONTENTS

4 / EN
Washng Machne / User’s Manual
4.6 Operating the product ----------------------------------------------------------------------------22
4.6.1 Control panel----------------------------------------------------------------------------------------------22
4.6.2 Dsplay symbols ------------------------------------------------------------------------------------------22
4.6.3 Programme and consumpton table---------------------------------------------------------------------23
4.6.4 Programme selecton ------------------------------------------------------------------------------------24
4.6.5 Programmes ----------------------------------------------------------------------------------------------25
4.6.6 Temperature selecton-----------------------------------------------------------------------------------28
4.6.7 Spn speed selecton -------------------------------------------------------------------------------------29
4.6.8 Auxlary functon selecton------------------------------------------------------------------------------30
4.6.8.1 Auxlary functons -------------------------------------------------------------------------------------31
4.6.8.2 Functons/Programmes Selected by Pressng the Functon Keys for 3 Seconds-------------------31
4.6.9 End Tme--------------------------------------------------------------------------------------------------32
4.6.10 Startng the programme--------------------------------------------------------------------------------33
4.6.11 Loadng door lock----------------------------------------------------------------------------------------33
4.6.12 Changng the selectons after programme has started -----------------------------------------------34
4.6.13 Cancellng the programme------------------------------------------------------------------------------35
4.6.14 End of programme --------------------------------------------------------------------------------------35
4.6.15 Adjustng the VOLUME level----------------------------------------------------------------------------35
4.6.16 Drum Illumnaton ---------------------------------------------------------------------------------------35
4.7 Maintenance and cleaning ------------------------------------------------------------------------36
4.7.1 Cleanng the detergent drawer --------------------------------------------------------------------------36
4.7.2 Cleanng the loadng door and the drum ----------------------------------------------------------------36
4.7.3 Cleanng the body and control panel --------------------------------------------------------------------36
4.7.4 Cleanng the water ntake flters ------------------------------------------------------------------------37
4.7.5 Dranng remanng water and cleanng the pump flter------------------------------------------------37
5 Troubleshooting 39
TABLE OF CONTENTS

5 / EN
Washng Machne / User’s Manual
1 General safety nstructons
This section contains safety instructions that will help protect from
risk of personal injury or property damage. Failure to follow these
instructions shall void any warranty.
1.1 Lfe and property safety
u
Never place the product on a carpet-covered floor. Otherwse, lack of
arflow beneath the machne wll cause electrcal parts to overheat.
Ths wll cause problems wth your product.
u
Unplug the product f t s not n use.
u
Always have the nstallaton and reparng procedures carred out by
the Authorzed Servce Agent. The manufacturer shall not be held
lable for damages that may arse from procedures carred out by
unauthorsed persons.
u
The water supply and dranng hoses must be securely fastened and
reman undamaged. Otherwse, there s the rsk of water leakage.
u
Whle there s stll water nsde the product, never open the loadng
door or remove the flter. Otherwse, rsk of floodng and njury from
hot water wll occur.
u
Do not force open the locked loadng door. The door wll open
mmedately after the washng cycle has ended. If the door does not
open,apply thesolutonsprovded for"Loadng doorcannotbe opened."
error n the Troubleshootng secton. In case of forcng the loadng door
to open, the door and the lock mechansm may get damaged.
u
Use detergents, softeners and supplements sutable for automatc
washng machnes only.
u
Follow the nstructons on the label of textle products and the
detergent package.
1.2 Chldren's safety
u
Ths product can be used by chldren at and above 8 years old and
by persons whose physcal, sensory or mental capabltes were not
fully developed or who lack experence and knowledge provded
that they are supervsed or traned on the safe usage of the product
and the rsks t brngs out. Chldren should not play wth the product.
Cleanng and mantenance works should not be performed by

6 / EN
Washng Machne / User’s Manual
chldren unless they are supervsed by someone. Chldren under the
age of 3 should be kept away unless contnuously supervsed.
u
Packagng materals are dangerous for the chldren. Keep packagng
materals n a safe place away from reach of the chldren.
u
Electrcal products are dangerous for the chldren. Keep chldren
away from the product when t s n use. Do not allow them to play
wth the product. Use chld lock to prevent chldren from ntervenng
wth the product.
u
Do not forget to close the loadng door when leavng the room where
the product s located.
u
Store all detergents and addtves n a safe place away from the
reach of the chldren by closng the cover of the detergent contaner
or sealng the detergent package.
1.3 Electrcal safety
uIf the product has a falure, t should not be operated unless t s repared
by the Authorzed Servce Agent! There s the rsk of electrc shock!
u
Ths product s desgned to resume operatng n the event of
powerng on after a power nterrupton. If you wsh to cancel the
programme, see "Cancellng the programme" secton.
u
Plug the product nto a grounded outlet protected by a 16 A fuse. Do
not neglect to have the groundng nstallaton made by a qualfed
electrcan. Our company shall not be lable for any damages that
wll arse when the product s used wthout groundng n accordance
wth the local regulatons.
u
Do not wash the product by sprayng or pourng water onto t! There
s the rsk of electrc shock!
u
Never touch the power cable plug wth wet hands! Never unplug by
pullng on the cable. Always press on the plug wth one hand and pull
out the plug by grabbng wth the other hand.
u
Product should be unplugged durng nstallaton, mantenance,
cleanng and repar procedures.
u
If the power cable s damaged, t must be replaced by the
manufacturer, authorzed servce or a smlarly qualfed person
(preferably an electrcan) or someone desgnated by the mporter n
order to avod possble rsks.

7 / EN
Washng Machne / User’s Manual
1.4 Hot surface safety
Theglassoftheloadingdoorgetstoohot
while washing at higher temperatures.
Therefore, especially do not allow
children touch the loading door glass
while washing.
3 Intended use
• This product has been designed for domestic use. It is not for commercial purposes or it
should not be used other than its intended use.
• The product must only be used for washing and rinsing of laundry that are marked
accordingly.
• The manufacturer waives any responsibility arising from incorrect usage or
transportation.
• The service life of your product is 10 years. During this period, original spare parts will be
available to operate the appliance properly.
2 Important instructions for the environment
2.1 Compliance with WEEE Directive
This product complies with EU WEEE Directive (2012/19/EU). This product
bears a classification symbol for waste electrical and electronic equipment
(WEEE).
This product has been manufactured with high quality parts and materials
which can be reused and are suitable for recycling. Do not dispose of the
waste product with normal domestic and other wastes at the end of its service
life. Take it to the collection center for the recycling of electrical and electronic
equipment. Please consult your local authorities to learn about these collection centres.
Compliance with RoHS Directive:
The product you have purchased complies with EU RoHS Directive (2011/65/EU). It does
not contain harmful and prohibited materials specified in the Directive.
2.2 Package information
Packaging materials of the product are manufactured from recyclable materials in
accordance with our National Environment Regulations. Do not dispose of the packaging
materials together with the domestic or other wastes. Take them to the packaging
material collection points designated by the local authorities.

8 / EN
Washng Machne / User’s Manual
4 Your product
4.1 Overview
1
2
3
4
5
6
7
8
1- Power cable
2- Top panel
3- Control panel
4- Drain hose
5- Loading door
6- Filter cap
7- Adjustable feet
8- Detergent drawer

9 / EN
Washng Machne / User’s Manual
4.2 Package Contents
9
10
11 12
abc
13
14
15
16
9- Power cable
10- Drain hose
11- Transportation safety bolts*
12- Mains water inlet hose (One of the following filter types is used for the mains hose
connection.)
a- Electronic water shut-off
b- Mechanical water shut-off
c- Standard
13- Liquid detergent container**
14- User Manual
15- Blind plug***
16- Plastic plug group
* Number of transportation safety bolts may change depending on the model of your product.
** This may be supplied with the machine depending on the model of your product.
*** It will be supplied if your product has double water inlet.
C
Figures in this manual are schematic and may not match the product exactly.

10 / EN
Washng Machne / User’s Manual
4.3 Technical specifications
Complying Commission Delegated Regulation (EU) No 1061/2010
Supplier name or trademark Beko
Model name WY124PT44MW
Rated capacity (kg) 12
Energy efficiency class / Scale from A+++ (Highest Efficiency) to D (Lowest Efficiency) A+++
Annual Energy Consumption (kWh) (1) 253
Energy consumption of the standard 60°C cotton programme at full load (kWh) 1,340
Energy consumption of the standard 60°C cotton programme at partial load (kWh) 0,970
Energy consumption of the standard 40°C cotton programme at partial load (kWh) 0,970
Power consumption in ‘off-mode’ (W) 0,440
Power consumption in ‘left-on mode’ (W) 0,640
Annual Water Consumption (l) (2) 13199
Spin-drying efficiency class / Scale from A (Highest Efficiency) to G (Lowest Efficiency) B
Maximum spin speed (rpm) 1400
Remaining moisture Content (%) 53
Standard cotton programme (3) Cotton Eco 60°C and 40°C
Programme time of the standard 60°C cotton programme at full load (min) 234
Programme time of the standard 60°C cotton programme at partial load (min) 190
Programme time of the standard 40°C cotton programme at partial load (min) 190
Duration of the left-on mode (min) N/A
Airborne acoustical noise emissions washing/spinning (dB) 58/77
Built-in No
Height (cm) 84
Width (cm) 60
Depth (cm) 67
Net weight (±4 kg.) 78
Single Water inlet / Double Water inlet • / -
• Available
Electrical input (V/Hz) 230 V / 50Hz
Total current (A) 10
Total power (W) 2200
Main model code 9715
(1) Energy Consumption based on 220 standard washing cycles for cotton programmes at 60°C and 40°C at full and partial load, and the
consumption of the low-power modes. Actual energy consumption will depend on how the appliance is used.
(2) Water consumption based on 220 standard washing cycles for cotton programmes at 60°C and 40°C at full and partial load. Actual water
consumption will depend on how the appliance is used.
(3) “Standard 60°C cotton programme” and the “standard 40°C cotton programme” are the standard washing programmes to which the information
in the label and the fiche relates and these programmes are suitable to clean normally soiled cotton laundry and that they are the most efficient
programmes in terms of combined energy and water consumption.
Technical specifications may be changed without prior notice to improve the quality of the product.
