Beldray BEL0747 User manual

www.beldray.com
TWO IN ONE
CORDLESS IRON
INSTRUCTION MANUAL

2
Please read all of the instructions carefully and retain for future reference.
Safety Instructions
When using electrical appliances, basic safety precautions should
always be followed.
Check that the voltage indicated on the rating plate corresponds
with that of the local network before connecting the appliance to
the mains power supply.
Children aged from 8 years and people with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge can use this appliance, only if they have been given
supervision or instruction concerning use of the appliance in a
safe way and understand the hazards involved.
Children should be supervised to ensure that they do not play
with the appliance.
Unless they are older than 8 and supervised, children should not
perform cleaning or user maintenance.
This appliance is not a toy.
This appliance contains no user serviceable parts. If the power
supply cord, plug or any part of the appliance is malfunctioning,
if there is any leakage or if it has been dropped or damaged, only
a qualied electrician should carry out repairs. Improper repairs
may place the user at risk of harm.
Keep the appliance and its power supply cord out of the reach
of children.
Keep the appliance and its power supply cord away from heat or
sharp edges that could cause damage.
Keep the power supply cord away from any parts of the appliance
that may become hot during use.
Keep the appliance away from other heat emitting appliances.
Do not immerse the appliance in water or any other liquid.
Do not expose the appliance to rain.
Do not operate the appliance with wet hands.
GB

3
Do not leave the appliance unattended whilst connected to the
mains power supply.
Do not remove the appliance from the mains power supply by
pulling the cord; switch it off and remove the plug by hand.
Do not pull or carry the appliance by its power supply cord.
Do not direct steam at people or animals.
Do not direct steam towards equipment containing
electrical components.
Do not use the appliance in an enclosed space lled with vapour
given off by oil-based paint thinners, some mothproong
substances, ammable dust or other explosive or toxic vapours.
Do not use the appliance for anything other than its intended use.
Do not use any accessories other than those supplied.
Do not use this appliance outdoors.
Do not touch any sections of the appliance that may become hot or
the heating components of the appliance, as this could cause injury.
Do not use the appliance after a malfunction or if it has been dropped,
damaged or if there are visible signs of damage or if it is leaking.
Always unplug the appliance after use and before any cleaning or
user maintenance.
Always ensure that the appliance has cooled fully after use before
performing any cleaning or maintenance or storing away.
Always use the appliance on a stable, heat-resistant surface, at a
height that is comfortable for the user.
Use of an extension cord with the appliance is not recommended.
This appliance should not be operated by means of an external
timer or separate remote control system.
This appliance is intended for domestic use only. It should not be
used for commercial purposes.
Caution: The appliance emits very hot steam; always
exercise extreme caution during use.
Hot surface – do not touch the hot section or heating
components of the appliance.

4
Warning: Danger of scalding.
Keep the appliance away from ammable materials.
Care and Maintenance
Before attempting any cleaning or maintenance, always unplug the
iron from the mains power supply and allow it to cool sufciently.
STEP 1: Drain the remaining water from the water tank to prevent
it from leaking during cleaning.
STEP 2: Wipe the ceramic soleplate with a soft, damp cloth and
dry thoroughly.
STEP 3: If polyester has burnt onto the ceramic soleplate, wipe
it with a soft cloth dipped in methylated spirits. Clean off the
methylated spirits with a soft, damp cloth and dry thoroughly.
STEP 4: To remove any build-up around the steam holes, use a
cotton wool tip dampened with methylated spirits. Wipe off the
methylated spirits with a soft, damp cloth and dry thoroughly.
Getting Started
Remove the appliance from the box.
Remove any packaging from the appliance.
Place the packaging inside the box and either store or dispose of safely.
In the Box
Two in One Cordless Iron
Power unit with cord
Iron stand
Measuring jug
Instruction manual
Features
2600 W power
Water spray and self-clean functions
Anti-calc and anti-drip functions
Large 300 ml water tank
Variable temperature and steam control
Ceramic soleplate
Easy-grip handle
1.9 m power cord

5
Description of Parts
1. Two in One Cordless Iron
2. Temperature control dial
3. Temperature indicator light
4. Steam control trigger
5. Steam setting indicator
6. Steam burst button
7. Water spray button
8. Self-clean button
9. Spray nozzle
10. Water tank
11. Water tank cap
12. Max. ll mark
13. Easy-grip handle
14. Ceramic soleplate
15. Cord guard
16. Heel rest
17. Power unit with cord
18. Iron stand
19. Locking switch
20. Measuring jug
1
2
3
45
6
7
8
9
10
11
12
13
14
15
16 17 18 19
20

6
Instructions for Use
Before First Use
STEP 1: Switch off and unplug the iron from the mains power supply.
STEP 2: Wipe the exterior surface of the iron with a soft, damp cloth and dry thoroughly.
STEP 3: To remove any impurities that may have occurred during the manufacturing
process, it is best to use the iron on an old piece of cloth, making sure that it is on the
highest temperature setting suitable for the material. Plug in and switch on the iron at
the mains power supply, place the iron onto the cloth and then push the steam burst
button 2–3 times, waiting approx. 5 seconds in-between each burst; this will remove any
impurities from the ceramic soleplate.
Do not immerse the iron in water or any other liquid.
Note: When using the iron for the rst time, a slight odour and
a small amount of smoke may be emitted. This is normal and
will soon subside. Allow for sufcient ventilation around the iron
when it is in use.
Filling the Water Tank
STEP 1: Switch off and unplug the iron from the mains power supply.
STEP 2: Check that the steam setting indicator is set to the ‘0’ position (off).
STEP 3: Place the iron onto the iron stand and open the water tank cap.
STEP 4: Fill the measuring jug with water, without exceeding the Max. ll mark. Carefully
pour the contents of the measuring jug into the water tank.
STEP 5: Close the water tank cap.
Caution: Do not ll the water tank past the max. ll mark; it is best
to check the water level when the iron is positioned upright.
Warning: Never add descaling, aromatic, alcoholic or
detergent products to the water tank, as this could cause
damage to the iron or injury to the user.
Using the Two in One Cordless Iron
Using as a Cordless Iron
STEP 1: Check that the iron is switched off and unplugged from the mains power supply.
STEP 2: When the iron is on the iron stand, make sure that the heel of the iron is pushed
back and is secure.
STEP 3: Move the locking switch up to the cordless position. This will lock the power
unit to the iron stand and release the iron.
STEP 4: Plug in and switch on the iron at the mains power supply; the temperature light
will illuminate to signal that the iron is charging.

7
STEP 5: When the temperature indicator light switches off after approx. 25 seconds,
remove the iron from the iron stand and use as a cordless iron.
STEP 6: Put the iron back onto the iron stand to recharge any point. Recharge time is
approx. 5 seconds.
Using as a Corded Iron
STEP 1: Check that the iron is switched off and unplugged from the mains power supply.
STEP 2: When the iron is on the iron stand, make sure that the heel of the iron is pushed
back and is secure.
STEP 3: Move the locking switch to the corded position. This will lock the power unit to
the iron.
STEP 4: Plug in and switch on the iron at the mains power supply.
STEP 5: Remove the iron from the iron stand and use as a corded iron.
Note: When the iron is not in use, keep the locking switch in the
‘locked’ position in the centre. This is ideal for storage.
Ironing with Steam
The steam settings are ideal for removing creases from fabrics such as cotton and linen
with ease.
STEP 1: Fill the water tank following the instructions in the section entitled ‘Filling the
Water Tank’.
STEP 2: Plug in and switch on the iron at the mains power supply.
STEP 3: To increase the temperature of the iron, rotate the temperature control dial in
a clockwise direction until the desired heat setting is reached. Reduce the temperature
by rotating the temperature control dial in an anticlockwise direction. The temperature
indicator light will illuminate to signal that the iron is heating up; this will switch off once
the iron is ready to use. The iron will only produce steam when the temperature control
dial is set to the 3-dot heat setting.
STEP 4: Select the desired steam setting by pressing the steam control trigger until
either ‘1’ or ‘2’ is visible on the steam setting indicator. The steam setting can be
switched off at any time by pressing the stream control trigger until it reaches ‘0’.
STEP 5: After use, rotate the temperature control dial to the ‘Off’ position. Switch off and
unplug the iron from the mains power supply and allow to cool thoroughly.
Note: Allow the iron to reach the desired heat setting before
use; not doing so may cause water to drip from the water tank.
The temperature indicator light will illuminate whilst the iron
is heating up but not when it is cooling down; it should not be
misinterpreted as a ready-to-use indicator light.

8
The temperature indicator light will cycle on and off during use
to regulate the temperature.
Warning: Never leave the iron’s ceramic soleplate resting on
fabric for any longer than 15 seconds.
If ironing with steam for prolonged periods of time, it is
advisable to use the iron as a corded unit.
Ironing without Steam
For removing creases from more sensitive fabrics, try ironing without steam.
STEP 1: Press the steam control trigger until the steam setting indicator is set to ‘0’.
STEP 2: Plug in and switch on the iron at the mains power supply.
STEP 3: To increase the temperature of the iron, rotate the temperature control dial in
a clockwise direction until the desired heat setting is selected. Reduce the temperature
by rotating the temperature control dial in an anticlockwise direction. The temperature
indicator light will illuminate to indicate that the iron is heating up; this will switch off
once the iron is ready to use.
STEP 4: Test the iron on a small area of the fabric to check that the selected temperature
is suitable; adjust if necessary.
STEP 5: After use, rotate the temperature control dial to the ‘Off’ position. Switch off and
unplug the iron from the mains power supply and allow to cool thoroughly.
If ironing with steam for prolonged periods of time, it is advisable to use the iron as a
corded unit.
Steam Burst Function
For creases that are stubborn and difcult to remove, use the steam control trigger to
select the desired steam setting; if necessary, press the steam burst button for extra
steam. Wait approx. 5 seconds in-between each burst to prevent any water leaking out
from the steam holes.
Note: The iron will only produce steam when the temperature
control dial is set to the 3-dot heat setting.
Vertical Steam Ironing
The steam burst button can also be used to vertically steam curtains and other
hanging garments.
STEP 1: Hang up the item to be vertically steamed.
STEP 2: Press the steam control trigger until the steam setting indicator is set to ‘0’.
STEP 3: Fill the water tank following the instructions in the section entitled ‘Filling the
Water Tank’.

9
STEP 4: Plug in and switch on the iron at the mains power supply.
STEP 5: Rotate the temperature control dial until the 3-dot heat setting is selected; the
higher the temperature, the more powerful the steam.
STEP 6: Hold the iron approx. 15 cm away from the item and press the steam burst
button to remove any creases, waiting approx. 5 seconds in-between each burst.
Water Spray Function
The water spray function can be used to help to remove stubborn creases on heavier
fabrics. It can also be used when dry ironing delicate fabrics that cannot be steam ironed.
To use the water spray function, hold the iron over the area to be ironed and then press
the water spray button.
Note: The water spray function will not work if the water tank
is empty.
When using the water spray function for the rst time, it may be
necessary to press the water spray button several times.
Anti-drip Feature
The iron has an anti-drip feature to prevent water leaking out from the steam holes when
the temperature is not high enough to generate steam. This is an automatic feature that
is permanently activated.
Anti-calcium Feature
The iron has a built-in resin anti-calcium lter located in the water tank to prevent
calcium and limescale build-up. Calcium build-up, which is prominent in areas with hard
water, can hinder performance and lower the lifespan of the iron. This is an automatic
feature that is permanently activated.
Note: The lter is built in and does not need replacing.
Self-clean Function
The self-clean function removes limescale and impurities from within the ceramic soleplate.
It is recommended to use this function on a fortnightly basis or more often if the iron is
used in a hard water area.
STEP 1: Switch off and unplug the iron from the mains power supply.
STEP 2: Press the steam control trigger until the steam control indicator is set to ‘0’.
STEP 3: Place the iron onto the iron stand.
STEP 4: Fill the water tank following the instructions in the section entitled ‘Filling the
Water Tank’.
STEP 5: Plug in and switch on the iron at the mains power supply.

10
STEP 6: Set the temperature control dial to the highest heat setting and allow the iron to
heat up until the temperature indicator light switches off.
STEP 7: Switch off and unplug the iron from the mains power supply.
STEP 8: Remove the iron from the iron stand and carefully hold it over a sink, making
sure that the power supply cord and plug are kept away from the ceramic soleplate.
STEP 9: Press and hold the self-clean button. Hot water and steam will expel from the
steam holes along with any impurities.
STEP 10: After approx. 1 minute or when the water tank is completely empty, release
the self-clean button.
STEP 11: Place the iron onto the iron stand and allow to cool thoroughly.
STEP 12: When the iron has sufciently cooled, wipe it with a soft, damp cloth.
STEP 13: Plug in and switch on the iron at the mains power supply.
STEP 14: Set the temperature control dial to the highest heat setting.
STEP 15: Once the temperature indicator light has switched off, use the iron on an old
piece of fabric to remove any excess water and impurity build-up from in the steam holes.
Note: Water may be ejected from the steam holes whilst the
iron is heating up.
For best results, carry out the self-clean process immediately
after unplugging the iron from the mains power supply.
Caution: Never press the self-clean button when using the iron;
only press it when the iron is switched off and unplugged from
the mains power supply and is safely held over a sink.
Hints and Tips
Always start ironing on a low heat setting and work up to a higher one, if necessary; it
takes less time for the iron to heat up than it does to cool down.
The temperature of the iron is the hottest when it has initially heated up and will
therefore need time to stabilise. Once the iron has heated up, allow the temperature
indicator light to cycle off and on again before using the iron.
Storage
Check that the iron is cool and dry and that the water tank is empty before storing in a
cool, dry place.
Wrap the cord loosely around the iron; never wrap it tightly as this could cause damage.
Troubleshooting
Warning: To reduce the risk of re, electric shock or injury,
switch off and unplug the iron from the mains power supply
before troubleshooting.

11
Problem Possible Cause Possible Solution
Reduced constant
steam or no
constant steam.
The steam holes
are blocked.
The steam control is
set to ‘0’.
Clear the steam holes of any blockages.
Select a steam setting using the steam
control trigger.
The fabric shows
signs of melting.
The temperature
selected is too high.
Reduce the temperature using the
temperature control dial.
The iron will not
turn on.
The iron is not
connected to the
mains power supply.
The fuse in the mains
plug has blown.
Plug in and switch on the iron at the mains
power supply.
Replace the fuse in the plug with one of
the same rating.
Water does not
spray out of the
spray nozzle.
There is no water in
the water tank.
The iron is being
used for the rst time.
Fill the water tank following the instructions in
the section entitled ‘Filling the Water Tank’.
Press the spray button several times until
water is released from the spray nozzle.
The iron is not
removing the
creases from
the fabric.
The temperature is
set too low.
The steam control
trigger is set to the
‘Off’ position.
Increase the temperature using the
temperature control dial, ensuring that the
fabric’s care instructions are followed.
Select a steam setting using the steam
control trigger.
Water is leaking
from the soleplate.
The temperature is
set too low.
The iron has not
been recharged.
Increase the temperature using the
temperature control dial, taking care that the
fabric’s care instructions are followed.
Put the iron back onto the iron stand to
recharge any point. Recharge time is
approx. 5 seconds. If ironing with steam for
prolonged periods of time, it is advisable to
use the iron as a corded unit.
Specications
Product code: BEL0747N
Input: 220–240 V ~ 50/60 Hz
Output: 2600 W
Water tank capacity: 300 ml

12
Notes:

Connection to the mains
Please check that the voltage indicated on the product corresponds with your
supply voltage.
Important
As the colours in the mains lead of this appliance may not correspond with the coloured
markings identifying the terminals in your plug, please proceed as follows:
The wires in the mains lead are coloured in
accordance with the following code:
Blue Neutral (N)
Brown Live (L)
Green/Yellow Earth ( )
FOR UK USE ONLY - Plug tting details
(where applicable).
The wire coloured BLUE is the NEUTRAL and must be connected to the terminal marked N
or coloured BLACK.
The wire coloured BROWN is the LIVE wire and must be connected to the terminal
marked L or coloured RED.
The wire coloured GREEN/YELLOW must be connected to the terminal marked with the
letter E or marked .
On no account must either the BROWN or the BLUE wire be connected to the
EARTH terminal ( ).
Always ensure that the cord grip is fastened correctly.
The plug must be tted with a fuse of the same rating already tted and conforming to
BS 1362 and be ASTA approved.
If in doubt consult a qualied electrician who will be pleased to do this for you.
Non-rewireable mains plug
If your appliance is supplied with a non-rewireable plug tted to the mains lead and
should the fuse need replacing, you must use an ASTA approved one (conforming to
BS 1362 of the same rating).
If in doubt, consult a qualied electrician who will be pleased to do this for you.
If you need to remove the plug - DISCONNECT IT FROM THE MAINS and then cut it off
the mains lead and immediately dispose of it safely. Never attempt to reuse the plug or
insert it into a socket outlet as there is a danger of an electric shock.
13 13

14
UP Global Sourcing UK Ltd.,
Victoria Street, Manchester OL9 0DD. UK.
If this product does not reach you in an acceptable condition please contact our
Customer Services Department by one of the following methods:
Telephone: [phone]*
*Telephone lines are open Monday–Friday, 9 am–5 pm (Closed Bank Holidays)
Email: [email protected]
Fax: [phone]
Please have your delivery note to hand as details from it will be required.
If you wish to return this product please return it to the retailer from where it was
purchased with your receipt (subject to their terms and conditions).
Guarantee
All products purchased as new carry a manufacturer’s guarantee; the time period of the
guarantee will vary dependent upon the product. Where reasonable proof of purchase
can be provided, Beldray will provide a standard 12 month guarantee with the retailer
from the date of purchase. This is only applicable when products have been used as
instructed for their intended, domestic use. Any misuse or dismantling of products will
invalidate any guarantee.
Under the guarantee, we undertake to repair or replace free of any charge any parts
found to be defective. In the event that we cannot provide an exact replacement, a
similar product will be offered or the cost refunded. Any damages from daily wear and
tear are not covered by this guarantee, nor are consumables such as plugs, fuses etc.
Please note that the above terms and conditions may be updated from time to time and
we therefore recommend that you check these each time you revisit the website.
Nothing in this guarantee or in the instructions relating to this product excludes, restricts
or otherwise affects your statutory rights.
The crossed out wheelie bin symbol on this item indicates that this
appliance needs to be disposed of in an environmentally friendly way
when it becomes of no further use or has worn out. Contact your local
authority for details of where to take the item for recycling.
14

*To be eligible for the extended guarantee,
go to www.beldray.com and register your product
within 30 days of purchase.
PRODUCT
HERE
www.facebook.com/Beldray
PRODUCT
HERE

Manufactured by:
UP Global Sourcing UK Ltd.,
Victoria Street, Manchester OL9 0DD. UK
[phone]
[email protected]
©Beldray Trademark. All rights reserved.
Please retain instructions for future reference.
Made in China.
CD190219/MD000000/V1
