Belkin Bluetooth USB Adapter F8T012 User manual

Bluetooth™ USB Adapter
F8T012 - F8T013
Connect your peripherals and
computing devices, without cables
User Manual
F8T012 - F8T013
SV
FI
DA
NO
PL
CZ
HU
UK
FR
DE
NL
ES
IT
PT

Bluetooth™ USB Adapter
F8T012 - F8T013
Connect your peripherals and
computing devices, without cables
User Manual
F8T012 - F8T013
EN

Table of Contents
Introduction ......................................................................................................... 4
Product Features .................................................................................................. 5
System Requirements ........................................................................................... 6
Package Contents ................................................................................................ 7
USB Adapter Specifications .................................................................................. 8
Software Setup .................................................................................................... 9
Hardware Setup ................................................................................................. 16
Initial Configuration Wizard ................................................................................. 19
Uninstalling the Software .................................................................................... 22
How to use the Belkin Bluetooth software ............................................................ 26
UK-5

Introduction
Thank you for purchasing the Bluetooth USB Adapter (the USB Adapter) from Belkin.
The USB Adapter features breakthrough Bluetooth wireless technology that lets you
create efficient communications between your USB desktop PC or notebook and
devices using Bluetooth wireless technology—without physical connectors or cables.
Before you install and start using your new Bluetooth USB Adapter, please take
a few minutes to review some of the terms that you will be seeing throughout the
document.
UK-4
UK-4

Product Features
• Bluetooth allows you to create an adhoc network
• Higher speed access up to 3Mbps (effective throughput of 2.2 Mbps)
• Adds Bluetooth 2.0 + EDR wireless technology to your
USB desktop computer, or notebook
• Fast paring time between 3.5 to 5 sec.
• Lower power consumption
• Bit Error Rate (BER) improved performance
• Manufacturer’s Lifetime Warranty
• Offers backwards compatibility with any Bluetooth v1.1 and v1.2-compliant device
• Installs easily with Plug-and-Play convenience
• Allows you to work at distances of up to 100 metres (Class 1) and 10 metres (Class 2)**
• Supports Microsoft® Windows® 98 SE, Me, 2000, XP, and Mac OS® X v10.3 and higher*
** Range is dependent upon environment, number of users and other wireless devices within immediate proximity.
UK-5
UK-5

PC System Requirements
• PC-compatible computer, CPU speed of 200MHz or above
• Memory: 64MB or above, 128MB recommended
• One available USB port, USB 1.1 or 2.0
• Windows 98 SE, Me, 2000, and XP
Mac® System Requirements
• One available USB port, USB 1.1 or 2.0
• Mac OS X v10.3 and higher*
*Mac OS X driver and software provided by Apple.
System Requirements
UK-6
UK-6

Package Contents
• Bluetooth USB Adapter
• CD-ROM for installation software and documentation
• User Manual on CD
• Quick Installation Guide
• Registration Card
UK-7
UK-7

USB Adapter Specifications
Bluetooth Compliance: Version 2.0
Physical Interface: USB UHCI/OHCI 2.0-compliant
Operating Frequency: 2.4 to 2.4835GHz
Output Power: (F8T012) 4~20 dBm, Class I
(F8T013) -6~4 dBm, Class II
Sensitivity: <0.1% BER @ -80 dBm
Data Rate: 3Mbps (effective throughput of 2.2 Mbps)
Typical Power
Consumption: (F8T012) Tx: 150mA, Rx 80mA
(F8T013) Tx: 65mA, Rx 45mA
Operating Range: (F8T012) 100-meter radius indoors
(F8T013) 10-meter radius indoors
Network Topology: Point-to-Multipoint
Packet Support: 1/3/5 Slots Packet
Operation: Master/Slave
Frequency Stability: +/- 10PPM
LED Indicator: Power On/Data Traffic
Antenna Type: Integrated, 0 +/- 1 dBi
Dimensions: 58mm (L) x 18mm (W) x 8mm (H)
Weight: 0.2oz. (7g)
Operating Temp: 0 to 70 degrees Celsius
Storage Temp: -30 to 80 degrees Celsius
Humidity: 5-90% (non-condensing)
Supply Voltage: 5.0V DC
Nominal Current: 100mA
Spread Spectrum: FHSS (Frequency Hopping
Spread Spectrum)
Modulation: GFSK (Gussian Frequency
Shift Keying)
Certifications: FCC, CE, ICES, C-Tick,
BQB, WHQL for XP
Specifications are subject to change without notice.
UK-8
UK-8

Software Setup
1. Insert the CD and wait for the software to run automatically.
2. Press on “Install Bluetooth Software”.
UK-9
UK-9

Software Setup
Software Setup for Windows 98 SE, Me, 2000, and XP
To install the software for the USB Adapter, follow the instructions below:
Note: The installation process for Windows XP may look slightly different from
Windows 98 SE, Me, and 2000.
Note: Do not insert the USB Adapter into the USB port prior to software installation.
1. Insert the software installation CD-ROM into the PC’s CD-ROM drive.
2. The “Software InstallShield Wizard” window appears. Click on “Next” to begin the
installation process.
UK-10
UK-10

3. Choose “I accept the terms in the
license agreement” to accept the
license agreement. Click on “Next” to
continue.
4. Specify the location where the software
files will be installed on your hard drive.
It is recommended that you install
the software in the default directory
“C:\Program Files\Belkin\Bluetooth
Software\”. Click on “Next” to continue.
Software Setup
UK-11
UK-11

Software Setup
5. Confirm that the device software is
ready to be installed and click on
“Install”.
6. The InstallShield Wizard will begin to
install the Belkin Bluetooth Software.
This may take several minutes.
UK-12
UK-12

Software Setup
7. The Driver Signature Notice window will appear. Press OK for the next step.
UK-13
UK-13

Software Setup
8. During the installation process you may be prompted to insert your USB Adapter.
If your USB Adapter is not plugged into your computer at this time, you may
insert it into an available USB 1.1-compliant port on your desktop or notebook
computer, then click “OK” to continue. Click on “Cancel” to continue installation
without the Bluetooth device inserted. Refer to the “Hardware Installation”
section of this User Manual for instructions for installing the hardware.
Note: If at any time during the installation process you receive a “Driver Signature
Notice”, click “OK” to continue the installation process.
UK-14
UK-14

Software Setup
9. Confirm the completion of the software installation; click “Finish” and restart the
system if prompted to do so.
UK-15
UK-15

Hardware Setup
Hardware Setup for Windows 98 SE, Me, 2000, and XP
Follow these instructions to install your USB Adapter on your PC.
Note: Your USB Adapter is sensitive to static electricity, which can damage its
delicate electrical components. To protect your device, always touch the metal chassis
of your computer before handling the USB Adapter. This will ground any potential
electrostatic discharge. Avoid touching the metal connector when handling the USB
Adapter. Dry weather conditions or walking across carpeted floors may cause you to
acquire an electrostatic charge.
1. Connect the USB Adapter directly to
an available USB A-type connector on
your desktop or notebook computer.
Your system should register a new USB
device found.
2. Choose “Install from a list or specific
location”; then click “Next”.
UK-16UK-16

Hardware Setup
UK-17UK-17
3. Browse for the location of the device
driver “:\Program Files\Belkin\
Bluetooth\Software\bin\” then click
“Next”.
4. If you receive the following “Hardware
installation notice”, click on
“Continue Anyway” to continue with
the installation process.

Hardware Setup
UK-18
UK-18
5. A window will appear that confirms the completion of the hardware installation;
click on “Finish” to complete the installation process.
