Belkin F1PI241EGau Reference guide

Self Help Guide
If you still require further assistance Call: 1300 55 47 80
contact Belkin Technical Support Visit: www.belkin.com.au/support
TSG-ANZ-VHD-7-F1PI241EGau-ENCRYPTION-10.4
Page 1 of 11
APPLIES TO:
• F1PI241EGau
TABLE OF CONTENTS:-
Before you begin: 3
STEPS: 3
WIRELESS SECURITY INFORMATION 5
64 Bit WEP:- 6
128 Bit WEP:- 7
WPA:- 8
WPA2:- 9
Connecting to the Wireless Network using
Apple Airport 10
Before you begin you will need:
• BelkinWireless/VoIPunit
• Powercable
• Networkcable
Hardware check:
• Yourcomputerisswitchedon
• TheWireless/VoIPunitisswitchedon
(power switch at rear)
• Networkcableconnectedfromcomputerto
 theWireless/VoIPunit
Enable wireless and wireless security on your Belkin VoIP modem/router.
STEPS:
1) Open your web browser (Safari)
2) In the Address Bar, delete any text and type in 10.1.1.1 or click here to open
the page directly
3)Typeinyourcurrentpassword(defaultpassword=admin)thenclickLOGIN
4) On the left hand side of the screen click Advanced Setup
5)Youwillnowbepresentedwithmoreoptionsinthemenuontheleft.
Click Wireless then click Enable Wireless Function and click Save Settings
Wirelessisnowenabled.WestronglyrecommendthatyousetupWirelessSecurity
to help protect your wireless network against unauthorised use.
If you would like to setup Wireless Security, please follow the steps on the
following page.
F1PI241EGau

Self Help Guide
Click the type of security you wish to setup:-
• 64 Bit WEP
• 128 Bit WEP
• WPA
• WPA2
WIRELESS SECURITY INFORMATION
Encryption Type Pros Cons Recommended usage
64 Bit WEP Mostcompatible Leastsecure Oldercomputers
 formofencryption  andwirelessadapters
 Easytosetup  (Windows98/ME/2000
 andmanage  &/or802.11bWirelessCards)
   Homeusers
128 Bit WEP More secure Long network key Apple Macintosh
 than64Bit,yetstill  /Ofceuse
widely supported (26 Characters)
by wireless cards
WPA Easytosetupand Limitedsupport WindowsXP(ServicePack2)
 moresecureform  Latermodelwirelesscards
of encryption
WPA2 Easytosetupand Limitedsupport MicrosoftWPA2Patch
 mostsecureform  WindowsXP(ServicePack3)
 ofencryption  MacComputers
F1PI241EGau
TSG-ANZ-VHD-7-F1PI241EGau-ENCRYPTION-10.4
Page 2 of 11
If you still require further assistance Call: 1300 55 47 80
contact Belkin Technical Support Visit: www.belkin.com.au/support

64 Bit WEP:-
1) Under Wireless click Security
2) Click WEP
3) Click 64 Bit for WEP Mode leave all other settings as default
4)PlaceatickinthePassphraseeld
5) In space provided in Passphrase, create a password – this can be any
combinationoflettersandnumbers
6) Click Save Settings
7) Write down the characters in Key 1 – this is now your “Network Key” or
“Encryption Key”
NB. There are ten (10) characters in total
This is the ‘key’ that will be required to be entered on your wireless MAC. When
you setup your wireless, it will ask you to type in a Password.
Clickhereforinformationonhowtoconnecttothewirelessnetwork.
Self Help Guide
F1PI241EGau
TSG-ANZ-VHD-7-F1PI241EGau-ENCRYPTION-10.4
Page 3 of 11
If you still require further assistance Call: 1300 55 47 80
contact Belkin Technical Support Visit: www.belkin.com.au/support

Self Help Guide
128 Bit WEP:-
1) Under Wireless click Security
2) Click WEP
3) Click 128 Bit for WEP Mode leave all other settings as default
4) PlaceatickinthePassphraseeld
5) In the space provided in Passphrase, create a new password - this can be
 anycombinationoflettersandnumbers
6) Click Save Settings
7) Write down the characters in Key 1 – this is now your ‘Network Key’
or ‘Encryption Key’
NB. There are Twenty Six (26) characters in total.
This is the ‘Key’ that will be required to be entered on your wireless MAC. When
you setup your wireless, it will ask you to type in a Password.
ClickhereforinformationonhowtoconnecttotheWirelessNetwork.
F1PI241EGau
TSG-ANZ-VHD-7-F1PI241EGau-ENCRYPTION-10.4
Page 4 of 11
If you still require further assistance Call: 1300 55 47 80
contact Belkin Technical Support Visit: www.belkin.com.au/support

Self Help Guide
WPA:-
1) Under Wireless click Security
2)ClickWPA/WPA2
3) Authentication is Pre-Shared Key – leave all other settings as default
4) InthespaceprovidedinPre-sharedKey,createapassword–minimumif
 eight(8)characters,itcanbeanycombinationofnumbersandletters
5) Click Save Settings
6) Ensure that WPA is still enabled. The Password you created earlier is now
your ‘Network Key’ or ‘Encryption Key’
This is the ‘Key’ that will be required to be entered on your Wireless MAC. When
you setup your wireless, it will ask you to type in a Password.
ClickhereforinformationonhowtoconnecttotheWirelessNetwork.
F1PI241EGau
TSG-ANZ-VHD-7-F1PI241EGau-ENCRYPTION-10.4
Page 5 of 11
If you still require further assistance Call: 1300 55 47 80
contact Belkin Technical Support Visit: www.belkin.com.au/support

Self Help Guide
WPA2:-
1) Under Wireless click Security
2) Click WPA2
3) Authentication is Pre-Shared Key – leave all other settings as default
4) InthespaceprovidedinPre-SharedKey,createapassword–minimumofeight
(8)characters,itcanbeanycombinationofnumbersandletters.
5) Click Save Settings
6) Ensure that WPA is still enabled. The password you created earlier is now your
‘Network Key’ or ‘Encryption Key’
This is the ‘Key’ that will be required to be entered on your wireless MAC. When
you setup your wireless, it will ask for a Password.
ClickhereforinformationonhowtoconnecttotheWirelessNetwork.
F1PI241EGau
TSG-ANZ-VHD-7-F1PI241EGau-ENCRYPTION-10.4
Page 6 of 11
If you still require further assistance Call: 1300 55 47 80
contact Belkin Technical Support Visit: www.belkin.com.au/support

Self Help Guide
Connecting to the Wireless Network using Apple Airport
Click the type of security you wish to setup:-
• 64 Bit WEP
• 128 Bit WEP
• WPA
• WPA2
WEP:-
1) OpenSystemPreference,clickNetwork
2)MakesureLocationisonAutomatic
3) Make sure Show is on Airport
4) Make sure By Default Join is selected to Preferred Networks
5)ClickthePlus(+)SymbolnexttotheEditbutton.
6)NexttoNetworkNamedropthelistdownandselectyournetwork.
7) Wireless security will be Showing WEP Password, please change this to
 WEP40/128BitHex.
F1PI241EGau
TSG-ANZ-VHD-7-F1PI241EGau-ENCRYPTION-10.4
Page 7 of 11
If you still require further assistance Call: 1300 55 47 80
contact Belkin Technical Support Visit: www.belkin.com.au/support

Self Help Guide
8) In the Password Field type in your WEP Encryption Code.
9) Press Ok
10) Press Apply Now
Your Wireless is now setup on your MAC with WEP Security.
WPA:-
1)OpenSystemPreference,clickNetwork
2)MakesureLocationisonAutomatic
3) Make sure Show is on Airport
4) Make sure By Default Join is selected to Preferred Networks
F1PI241EGau
TSG-ANZ-VHD-7-F1PI241EGau-ENCRYPTION-10.4
Page 8 of 11
If you still require further assistance Call: 1300 55 47 80
contact Belkin Technical Support Visit: www.belkin.com.au/support

Self Help Guide
5) ClickthePlus(+)SymbolnexttotheEditbutton.
6) NexttoNetworkNamedropthelistdownandselectyournetwork.
7) Wireless Security will be showing WPA Personal.
8) Type your Encryption Code into the Password Field
9) Click Ok
10) Click Apply Now
Your Wireless is now setup on your MAC with WPA Security.
F1PI241EGau
TSG-ANZ-VHD-7-F1PI241EGau-ENCRYPTION-10.4
Page 9 of 11
If you still require further assistance Call: 1300 55 47 80
contact Belkin Technical Support Visit: www.belkin.com.au/support

Self Help Guide
WPA2:-
1) OpenSystemPreference,clickNetwork
2) MakesureLocationisonAutomatic
3) Make sure Show is on Airport
4) Make sure By Default Join is selected to Preferred Networks
F1PI241EGau
TSG-ANZ-VHD-7-F1PI241EGau-ENCRYPTION-10.4
Page 10 of 11
If you still require further assistance Call: 1300 55 47 80
contact Belkin Technical Support Visit: www.belkin.com.au/support

Self Help Guide
5) ClickthePlus(+)SymbolnexttotheEditbutton.
6) NexttoNetworkNamedropthelistdownandselectyournetwork.
7) Wireless Security will be showing WPA2 Personal.
8) Type your Encryption Code into the Password Field
9) Click Ok
10) Click Apply Now
Your Wireless is now setup on your MAC with WPA2 Security.
F1PI241EGau
TSG-ANZ-VHD-7-F1PI241EGau-ENCRYPTION-10.4
Page 11 of 11
If you still require further assistance Call: 1300 55 47 80
contact Belkin Technical Support Visit: www.belkin.com.au/support
