AD-T388 Walkie Talkie
Model: AD-T388

19.CTCSS / Menu option
PIC 01
TALK
SPK/MIC
/CHG
8.Speaker /Mic
/Charge Jack
15.Talk Button
12.Call Button 5.Monitor Button
6.Power Button
9.Speaker
11.MENU Button
4.Up Button
7.Down Button
10.Microphone
1.Antenna
21.Scan Button
20.Lamp Button
22.Lamp
SCAN
18.Channel/Menu item
17.Scanning
16.Vox
14.Battery Level
13.Keypad Lock
2.TX/RX Icon
3.Volume

23
PIC 02
24
25 26

EN~ Instructions foruse
This set includes2 walkie-talkie units:these are
communication devices whichoperate on mobileradio
frequencies. Theycome with 8/20/22(option)channels as well
as a back-litLCD screen, enablingyou to communicateover
several kilometres free-of-charge (up to3 km inopen areas)
NOTE: Please readthese user instructionscarefully before
using the equipmentand retain forfuture consultation!
SPECIFIC RECOMMENDATIONS
· If youcarry any kindof personal medicaldevice, consult a
doctor before use.
· To avoid therisk of burns,do not usethe device ifthe aerial
is damaged inany way.
· Do notuse the devicein a potentiallyexplosive setting
(e.g. around petrolpumps, on thelower deck ofa boat or
around a fuelstorage installation orchemical products)
· If travellingin a caror by bike,stop before usingthe device.
Switch off thedevice if onan aeroplane orin a hospital.
· Never usethe device inclose proximity toa radio toavoid
interference.
· Remove thebatteries if thedevice is notin use foran
extended period oftime. Never mixused and newbatteries.
· Position thetransmitter and antennaat least 25cm from your
face. Direct theantenna upwards andspeak normally.
· Clean thedevice with adamp cloth.Avoid theuse of cleaning
agents and solvents.
· Do notmodify the devicein any way. In theevent of damage
occurring, ensure thatthe device ischecked by aqualified
professional.
· The devicecannot be usedto contact theemergency services.

ITEM DESCRIPTION (Pic01,02)
1. Antenna
2. RX icon -Displayed when receiving
TX icon -Displayedwhen transmitting
3. Volume level indicator
4. Adjustorbutton Up ( )
5. Continued reception( )
6. On /off button( )
7. Adjustorbutton Down ( )
8. Earphone socket
9. Loud speaker
10.Microphone
11. Menu:
Enter the menusettings
12. Call button(CALL)
13. Keypad lockindicator
14. Battery levelindicator
15. Push totalk (TALK)button
16. VOX indication
17. Scanning indication:
Displayed during scanmode
18. Channel/Menu itemindication
19. CTCSS /Menu option -value
23. Belt attachmentclip
24. Belt attachment
25. Batteries (notsupplied)
26. Battery compartment
20.Lamp Button
21.Scan Button
22.Lamp
