Belmint BEL-CWF User manual
BELMINT
WATER FLOSSER
BELMINT
WATER FLOSSER
www.belmint.com
@belmintsproducts
@belmintproducts
What’s in the Box?
Product Details
- Belmint Water flosser
- Water reservoir
- 3 high-pressure tips
- Hydraulic, rotating toothbrush
- Periodontal tip
- Orthodontic tip
- Dental plaque tip
- Tongue cleaner
User Guide
Congratulations on your purchase!
You’re on your way to better oral health
Did you know that each of us have up to 200 different species of
bacteria living inside of our mouths? Some of these little guys are
beneficial to our health, but that can quickly change when things get
out of hand. That’s why it is so important to keep your mouth clean
with proper tools and techniques.
Studies have shown that good dental hygiene can reduce the
hazardous overgrowth of oral bacteria by over 90%! But just what is
good dental hygiene? And how do we make that happen?
Wonder no more! This deluxe Water flosser from Belmint is the key to
your oral health. We’ve taken the best dental tools from numerous
professional models and combined them into one seamless, joyful
experience for cleaner teeth and healthier gums. Now, you can have
that fresh ‘just had my teeth shined’ feeling in the comfort of your
own home!
Choose from six different flossing and brushing tips—perfect for
working your way around dental implants, braces, and caps. In just 3
minutes, you’ll have a set of squeaky-clean chompers.
And don’t forget to show off your new smile! They’re contagious, you
know.
Shine on!
The Belmint Team
Model
BEL-CWF
Voltage
110V - 220V
Around here, smiles are never hard to find!
But good service shouldn’t be
At Belmint, we strive to provide our customers with ultimate
relaxation.
If you encounter any issues with the performance of your device,
our authorized service personnel are here to help. Check back
cover for information.
12
Power Consumption
500 W
Dimensions
6.1*4.8*9.4 inch
Weight
1.5/1.9 Lbs
Water Tank
600 ml
Time to get grinning!
34
Using your device
1. Place your device on a flat, level surface near a polarized wall
socket.
2. Remove the reservoir and fill it with lukewarm water.
3. Re-attach the reservoir to the base, making sure that it clicks
firmly into place and that the lid is firmly closed.
4. Insert the desired dental tip into the water jet handle. When
properly fastened, the colored ring at the bottom of the tip
will be flush with the handle knob. To remove a current
attachment, press the tip eject button while gently pulling on
the tip. For more information on the different attachments,
please refer to the next section.
5. Place the device tip into your mouth, pointing the nozzle
toward your teeth—at a 90° angle to your gum line. To
reduce spillage, it is recommended that you lean over a sink
or other similar basin before turning on the device.
6. Turn the On/Off knob one click clockwise to turn the device
on.
7. Adjust the water pressure or speed to your preference by
continuing to turn the On/Off knob clockwise or
counterclockwise.
8. Direct the water stream around each tooth, workiang from
back to front and pausing at the space between each tooth.
To control the direction of the water, use your thumb and
forefinger to turn the rotating knob at the base of the nozzle.
9. If you need to pause the stream at any time, simply slide the
Pause button downward.
10. After 3 minutes, the device will automatically turn off. Or,
you can turn the device off before then by turning the On/Off
knob all the way to the left (counterclockwise).
11. When you are finished, make sure that the On/Off knob is set
to “Off”.
12. Empty the reservoir. Then clean and store the device
according to the instructions on the booklet.
56
Tip-Top Tips
More about your flosser aachments
Don’t brush this off...
To prevent potential injury or property damage, please read
this entire manual before operating your device. Keep it on
file for future reference.
1. Place your device on a flat, level surface near a polarized wall
socket.
2. Remove the reservoir and fill it with lukewarm water.
3. Re-attach the reservoir to the base, making sure that it clicks
firmly into place and that the lid is firmly closed.
4. Insert the desired dental tip into the water jet handle. When
properly fastened, the colored ring at the bottom of the tip
will be flush with the handle knob. To remove a current
attachment, press the tip eject button while gently pulling on
the tip. For more information on the different attachments,
please refer to the next section.
High-Pressure Tip : This tried-and-true attachment is a fan
favorite—designed to mimic traditional dental floss by
flushing away food particles and bacteria below the
gumline and between teeth. The high pressure stream also
stimulates gum circulation with twice as much effectiveness
as traditional flossing.
Periodontal Tip : Got sensitive gums? This periodontal tip is
perfect for cleaning beneath the gum line and within
periodontal pockets and furcations. The precision nozzle
directs a gentle stream of water, carefully cleaning the most
sensitive parts of your mouth. You can also add your liquid
dental medication to the reservoir and use this attachment
to apply it.
Orthodontic Tip : Use the specialized bristles on this
attachment to clean bacteria and food particles trapped
around braces and other dental work—removing three
times as much plaque as traditional dental floss. The
dual-action tip also releases a water jet to simultaneously
wash away any particles that are brushed off the teeth.
Dental Plaque Tip : For those with dental implants, crowns,
bridges, and veneers, this plaque-busting tip has proven to
be twice as effective as traditional flossing. Pulsating water
and sturdy bristles work together to clean plaque and food
debris off hard-to-reach areas, leaving your mouth feeling
cleaner than you ever thought possible.
Tongue Cleaner : Gently move the edge of this attachment
over the surface of your tongue (from back to front) to flush
bacteria, dead oral cells, and food particles out of your
mouth. Studies have shown that regular tongue cleaning can
reduce bad breath by removing bacteria and sulfur
compounds that have accumulated on the surface. It can
also prevent halitosis.
Rotating Toothbrush : This attachment is an enhanced
version of a traditional toothbrush, designed to clean on and
between your teeth more efficiently. Use like any other
electric toothbrush to wash away plaque, bacteria, and
food particles while a gentle water stream rinses away any
debris that you may have missed.
78
Show some love
Maintaining your Device
To Clean
1. Empty the reservoir of any remaining water
2. Rinse the reservoir with your desired, non-toxic
cleaning solution. Your dentist can give you advice on
which solution to choose.
3. Fill the reservoir with water again, aim the tip into
your sink or basin, and turn the device back on.
Continue to let the water flow through the nozzle until
the reservoir is empty.
4. Clean the outside of the unit using a soft cloth and a
mild, non-abrasive cleanser or lukewarm water to keep
all vents, buttons, and openings free of lint and dirt. Do
not immerse the unit in water.
2.Bind the cord gently with an electrician-approved
fastener. Do not wrap the cord around the device.
3. Store the device in a cool, dry place away from
damaging elements. If you must store in freezing
temperatures (even temporarily), be sure that the
device is empty and dry first to prevent ice damage to
the interior.
To Store
1. Make sure that the device is clean, empty, and dry.
To Maintain
1. Replace the high pressure tip and the tongue cleaner
every 6 months for optimal performance and sanitation.
2. For the orthodontic tip, periodontal tip, dental
plaque tip, and rotating toothbrush, replace every 3
months.
3. To order new attachments, contact the Belmint Team
using the information on back cover of this manual or
you can go to belmint.com/tip .
910
- Before each use, check your device for any damage,
especially to the power cord or other electrical
components.
- This device is not a toy. Keep out of reach of children
and do not leave unattended. Do not allow
dependents to use this device without supervision.
- For personal use only—as intended/directed. This
device is not intended as a substitute for medical
treatment. Anyone with a medical condition,
recovering from surgery, or women who are
pregnant/nursing should consult their doctor before
using this device.
- Always unplug the device immediately after using.
- Do not use this device while bathing or place the
device near where it could fall into a tub or sink. If the
device does fall into water, unplug before retrieving.
- Do not use attachments not approved by the
manufacturer.
- Keep the device away from heated surfaces.
Floss your worries away
How to prevent damage and injury
Keep the Peace
Troubleshooting Guide
Problem Solution
Water leakage
between the bottom
of the tip attachment
and the handle
Turn the device off. Remove the tip according
to the instructions on Page 3 and reinstall
Water leakage from
the irrigator hose.
Contact the Belmint Customer Support Team
(Back Cover) to request a repair kit.
Water leakage from
reservoir
Examine your device to ensure that the
reservoir is securely fastened to the base, the
lid is tightly shut, and the reservoir valve is
fastened firmly in the correct position
Weak water
pressure
Test or check that the outlet is getting full
power. Make sure that the device is fully
plugged in.
No water coming
from the nozzle
Make sure the reservoir is full and that the
device is on. The device will automatically
shut off after 3 minutes of active use.
If any of these issues persist or if any part of the device becomes
damaged, discontinue use and return to the service center for
evaluation and repair. Do not attempt to modify or repair the unit
yourself; doing so will nullify your purchase warranty and could
risk your safety.
