BENDIX Wingman Fusion FLR-21 Mounting instructions

1
portal. Currently, the system does not integrate alerts
from Bendix™BlindSpotter®or SmarTire®Tire Pressure
Monitoring System (TPMS) by Bendix CVS.
Bendix™FLR-21™
Radar Sensor
Bendix®ESP®
EC-80™Controller
Bendix™
AutoVue®
FLC-20™
Camera
SafetyDirect®
By Bendix CVS
Processor
Bendix™Driver
Interface Unit
(DIU™)
For more information: • Bendix AutoVue FLC-20 Camera - see SD-64-20124
• Bendix®ESP®EC-80™Controller - see SD-13-4986
• SafetyDirect®By Bendix CVS Processor - see SD-65-21025
Figure 2 – Major Bendix Wingman Fusion System Components
The major components that are used in the Wingman
Fusion system are the Bendix®ESP®EC-80™Controller,
the Bendix™ FLR-21™Radar Sensor, the Bendix™AutoVue®
FLC-20™Camera (powered by the Mobileye®
System-on-Chip EyeQ processor with state-of-the-art
vision algorithms), the Bendix™Driver Interface Unit (DIU™)
or OEM dash display, the SafetyDirect processor, and the
vehicle’s telematics system. See Figure 2.
Bendix®Wingman®Fusion™FLR-21™Radar Sensor
SD-61-4963
IMPORTANT
Bendix®-brand Electronic Control Units (ECUs)
are not designed to store data for purposes of
accident reconstruction, and Bendix®ACom®PRO™
Diagnostic Software is not intended to retrieve data
for purposes of accident reconstruction. Bendix
makes no representations as to the accuracy of
data or video retrieved and interpreted from ECUs
for purposes of accident reconstruction. Bendix
does not o󰀨er accident reconstruction services or
interpretation of stored data. Bendix ECUs are not
protected from re, loss of power, impact damage,
or other conditions that may be sustained in a crash
situation and may cause data to be unavailable or
irretrievable.
Integrating a camera, radar, and brakes, the Bendix®
Wingman®Fusion™Driver Assistance System (Fusion)
provides the following alerts and actions:
• Stationary Vehicle Braking (SVB)
• Enhanced Collision Mitigation Braking (CMB)
• Active Cruise with Braking (ACB)
• Overspeed Alert and Action (OAA)
• Lane Departure Warnings (LDW)
• Stationary Object Alerts (SOA)
• Alert Prioritization
NOTE:
data and video of certain events and, when integrated
with a telematics provider, can transmit this information
for viewing on the SafetyDirect®by Bendix CVS web
Figure 1 – Bendix®Wingman®Fusion™System
Vehicle Equipped with the
Bendix®Wingman®Fusion™
Driver Assistance System
Windshield-mounted
Camera
Front Bumper-mounted
FLR-21 Radar
NOT TO SCALE

2
GENERAL SAFETY GUIDELINES
WARNING! PLEASE READ AND FOLLOW THESE INSTRUCTIONS
TO AVOID PERSONAL INJURY OR DEATH:
When working on or around a vehicle, the following guidelines should be observed AT ALL TIMES:
▲Park the vehicle on a level surface, apply the
parking brakes, and always block the wheels.
Always wear personal protection equipment.
▲Stop the engine and remove the ignition key
when working under or around the vehicle.
When working in the engine compartment,
the engine should be shut o󰀨 and the ignition
key should be removed. Where circumstances
require that the engine be in operation, EXTREME
CAUTION should be used to prevent personal
injury resulting from contact with moving,
rotating, leaking, heated, or electrically charged
components.
▲Do not attempt to install, remove, disassemble,
or assemble a component until you have read,
and thoroughly understand, the recommended
procedures. Use only the proper tools and
observe all precautions pertaining to use of those
tools.
▲If the work is being performed on the vehicle’s
air brake system, or any auxiliary pressurized air
systems, make certain to drain the air pressure
from all reservoirs before beginning ANY work
on the vehicle. If the vehicle is equipped with
a Bendix®AD-IS®air dryer system, a Bendix®
DRM™dryer reservoir module, a Bendix® AD-9si®,
AD-HF®, or AD-HFi™air dryer, be sure to drain the
purge reservoir.
▲Following the vehicle manufacturer’s
recommended procedures, deactivate the
electrical system in a manner that safely removes
all electrical power from the vehicle.
▲Never exceed manufacturer’s recommended
pressures.
▲Never connect or disconnect a hose or line
containing pressure; it may whip and/or cause
hazardous airborne dust and dirt particles. Wear
eye protection. Slowly open connections with
care, and verify that no pressure is present. Never
remove a component or plug unless you are
certain all system pressure has been depleted.
▲Use only genuine Bendix®brand replacement
parts, components, and kits. Replacement
hardware, tubing, hose, fittings, wiring, etc.
must be of equivalent size, type, and strength as
original equipment and be designed speci cally
for such applications and systems.
▲Components with stripped threads or damaged
parts should be replaced rather than repaired.
Do not attempt repairs requiring machining or
welding unless speci cally stated and approved
by the vehicle and component manufacturer.
▲Prior to returning the vehicle to service, make
certain all components and systems are restored
to their proper operating condition.
▲For vehicles with Automatic Traction Control
(ATC), the ATC function must be disabled (ATC
indicator lamp should be ON) prior to performing
any vehicle maintenance where one or more
wheels on a drive axle are lifted o󰀨 the ground
and moving.
▲The power MUST be temporarily disconnected
from the radar sensor whenever any tests USING
A DYNAMOMETER are conducted on a vehicle
equipped with a Bendix® Wingman®system.
▲You should consult the vehicle manufacturer's operating and service manuals, and any related literature,
in conjunction with the Guidelines above.
Due to the inherent limitations of image recognition
technology, camera-based safety technology — on
rare occasions — may not be able to detect or may
misinterpret lane markings. At these times, alerts
may not occur, or erroneous alerts may occur.
Bendix safety technologies complement safe driving
practices. No commercial vehicle safety technology
replaces a skilled, alert driver exercising safe driving
techniques and proactive, comprehensive driver
training. Responsibility for the safe operation of the
vehicle remains with the driver at all times.
Improper use of the Bendix®Wingman®Fusion™Driver
Assistance System can result in a collision causing
property damage, serious injuries, or death. Be sure to
read, understand, and carefully follow the instructions
in the Operator’s Manual (BW2681).
IMPORTANT
It is the responsibility of the driver to remain
vigilant and change driving practices depending
on tra󰀩c and road conditions.

3
SD Sheet Index
Bendix®Wingman®Fusion™Driver Assistance System Overview . . . . . . . . . . . . . . . . . .1-5
1.0 Introduction to Troubleshooting Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.1 Troubleshooting Basics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.2 Narrowing Down The Problem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
1.3 Overview of Possible Issues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1.4 Important Note on Telematics Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.0 Troubleshooting/Diagnostics Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.1 Bendix®ACom®PRO™Diagnostic Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.2 Reading Diagnostic Trouble Codes (DTCs) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2.3 Reading The System Software Version . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2.4 How to Generate a Bendix Wingman Fusion System Diagnostic Trouble Code (DTC) Report . . . 13
2.5 Table of Bendix Wingman Fusion DTCs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.6 Clearing DTCs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
2.7 Troubleshooting DTCs: Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
2.8 Serial Data (J1939) Communications Link. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
2.9 Private Communications Network Test Procedure. . . . . . . . . . . . . . . . . . . . . . . . . . 31
2.10 Engine Communications (J1939) Test Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . 32
2.11 J1939 Troubleshooting Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
2.12 Troubleshooting Wiring Harnesses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
3.0 Other System Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
3.1 Reading Bendix Wingman Fusion System Key Indicators . . . . . . . . . . . . . . . . . . . . . . 33
3.2 Bendix Wingman Fusion System DTC Self-Clearing . . . . . . . . . . . . . . . . . . . . . . . . 33
3.3 Following Distance Adjustment Switch (Optional) . . . . . . . . . . . . . . . . . . . . . . . . . . 33
  . . . . . . . . . . . . . . 33
Appendices
Appendix A - Radar Mounting and Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Appendix B - Radar Alignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Appendix C - Radar Alignment Using a Bendix®Alignment Clip and Tool. . . . . . . . . . . . . . . 44
Appendix D - Dynamic Radar Alignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Appendix E - Driver Interface Unit (DIU™): Displays and Alerts . . . . . . . . . . . . . . . . . . . . 49
Appendix F - How to Generate, Read, and Reset the Bendix Wingman System
Diagnostic Trouble Codes (DTC) Using Bendix ACom PRO Diagnostic Software . . 61
Appendix G - How to Read Key System Indicators and Reset Alignment Values . . . . . . . . . . 64
Appendix H - How to Change the Following Distance Alert (FDA) Settings and
Enable Momentary Beeping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Appendix J - Situations That May Cause False Alerts by the Bendix Wingman Fusion System . . . 66
Appendix K - System Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Appendix L - Maintenance Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Appendix M - SPN and FMI Codes, Descriptions and Service Actions . . . . . . . . . . . . . . . . 82

4
NOTE: If during the intervention it is necessary to apply
the foundation brakes, or the vehicle speed falls below
the minimum cruise speed allowed, the vehicle will
not automatically resume the cruise control set speed.
EXCEPTION: It is possible that some Fusion applications
allow the cruise control to automatically resume after
the Fusion system applies the foundation brakes during
adaptive cruise. The driver is able to override the auto
resume feature by manually activating the brake pedal.
If the vehicle ahead slows below the cruise control’s set
speed, but then accelerates away – and the Fusion system
did not need to use the foundation brakes – the system will
automatically accelerate back to the original cruise control
set speed and maintain a set following distance behind any
detected forward vehicles.
Because the Bendix®Wingman®Fusion™system operates
along with normal cruise control, all the typical features
built into cruise control work as usual. For example, limits
imposed by factory-set road speed governors, etc. are fully
supported by the Fusion system.
ACTIVE CRUISE CONTROL WITH BRAKING
The active cruise control with braking feature is an
additional upgrade of ordinary cruise control. When using
cruise control, the Bendix®Wingman®Fusion™Driver
Assistance System (Fusion) will maintain the set speed,
and will also intervene – as needed – to help maintain a
set following distance behind a detected forward vehicle.
Using the Bendix®FLR-21™Radar Sensor mounted to the
front of the vehicle – with a range of approximately 500 ft
(152 m) – the Fusion system reacts to detected forward
vehicles in the same lane, traveling in the same direction.
See Figure 3.
The active cruise control with braking feature is designed to
help maintain a set following distance between the vehicle
and a detected forward vehicle when cruise control is set.
See the striped "Radar Beam" area in Figure 3.
Once cruise control is set and the system is maintaining a
set following distance between the vehicle and the forward
detected vehicle, if the forward detected vehicle slows down
below the cruise control’s set speed, the Fusion system
will intervene and, as necessary, in this order:
(a) reduce the engine throttle; then
(b) apply the engine retarder; then
(c) apply the foundation brakes
in an attempt to maintain the set following distance behind
the vehicle ahead.
Figure 3 – Bendix®Wingman®Fusion™Driver Assistance System Intervention Zone
Detected Forward
Vehicle
Vehicle Equipped with the Bendix®
Wingman®Fusion™System
Radar Beam
The DARK GRAY area approximates the
zone where the Wingman Fusion system
is ready to alert – and intervene with the
vehicle's brakes – as long as the vehicle
is traveling above 15 mph / 24 kph.
The STRIPED area approximates the
zone where the Active Cruise with
Braking feature is ready to alert – and
intervene with the vehicle's brakes –
when the cruise control is set.
NOT TO SCALE
FEATURES OF THE BENDIX®WINGMAN®FUSION™SYSTEM
Windshield-mounted
Camera
Front Bumper-
mounted Radar

5
ALERTS
The Bendix®Wingman®Fusion™System also assists by
giving audible and visual alerts, whether or not cruise
control is on. See Appendix E and Appendix K for more
information on the types of alerts the driver may hear and/
or see.
COLLISION MITIGATION TECHNOLOGY
See the striped area in Figure 3. The Fusion system’s
collision mitigation technology is designed to be ready to
alert the driver to detectable objects in front of the vehicle
(whether or not cruise control is set) and react to the
presence of stationary/moving vehicles in the lane ahead.
Collision mitigation interventions provide the driver with
an alert before an intervention occurs. The driver must
immediately act to potentially avoid, or lessen the severity
of, a collision.
OVERSPEED ALERT AND ACTION (OAA)
The Fusion system has the ability to assist the driver by
recognizing U.S. and Canadian speed limit signs. This
allows the system to display the current posted speed
limit and alert the driver when overspeed thresholds are
detected. When changing between regions which post
speeds in miles and those which post in kilometers, the
speed limit sign recognition feature will not function until
the correct U.S./metric selection has been made.
LANE DEPARTURE WARNING
The Fusion system will monitor the visible lane markings
on the road and when an unexpected lane change – a
lane change without an activated turn signal – takes place,
the system will alert the driver to make a correction. Tired,
distracted, or inattentive drivers are alerted and can take
remedial actions.
SAFETY DATA RECORDING AND TRANSMISSION
Many Fusion-equipped vehicles use the SafetyDirect®
by Bendix CVS processor and the vehicle’s telematics
processor to record vehicle and driver safety data after
safety system events. Data collected includes signals on
the vehicle communication network, images, video from
the Bendix™AutoVue®FLC-20™camera, and internally
generated data. Telematics devices transmit this data and
video to the SafetyDirect web portal.

6
Troubleshooting Basics (1.1)
Questions/Instructions Next Steps
1. Have the driver run the
Power-Up Self-Test.
Power-Up Self-Test
This is a self-diagnostic check to determine if the system operation is normal.
1.
2.
3.
4.
5.
󰀨
Put the key into the ignition and turn to the “ignition power” position.
Toggle the cruise control switch at least once, and leave it in the “on” position.
Start the vehicle, but do not drive away.
Note that if the cruise control is in the “o󰀨” position, or if the vehicle is
moving, this test will not run.

to complete.
        󰀨   
during the initial 15 seconds after ignition “on.”)
As the Bendix Wingman Fusion system self-test runs, the driver should hear a
short set of beeps. The test checks the engine, transmission, and brake systems
to make sure they are communicating. In addition, depending on the vehicle,

Vehicle Detected icon in the instrument cluster to illuminate; this is normal.
2. Does the driver hear a
long warning beep?
If no problem is found and the test is passed, no additional beeps/lamps will be
displayed nor will a trouble code be set.
If the system has found an issue that will prevent it from functioning properly, a long
warning beep will sound to alert the driver, and a Diagnostic Trouble Code (DTC)
will be logged in the system (typically with a status indicator/dash icon illuminated).
For descriptions of all DTCs, see Section 2.5: Diagnostic Trouble Codes.
3. Have the driver describe
the system behavior that
they believe shows it is not
working properly.
When diagnosing the system, especially in cases where there are no DTCs logged,

4. Fill out the Troubleshooting
Checklist (pages 7–8)
and create a DTC report
(Appendix F).
The Checklist and DTC Report will clarify the problem and be necessary if a call to
the Bendix Tech Team is needed.
Also See Section 1.2: Narrowing Down the Problem.
Call the Bendix Tech Team at 1-800-AIR-BRAKE (1-800-247-2725), option 2, for troubleshooting assistance.
Table 1 – Troubleshooting Basics
1.0 INTRODUCTION TO
TROUBLESHOOTING SECTION
This section introduces three (3) initial steps to accurately
troubleshoot the Bendix®Wingman®Fusion™system.
We recommend reading this introductory section – as well
as the Troubleshooting/Diagnostics Section (2.0) – before
performing any troubleshooting.
When diagnosing the Fusion system, a current version
of Bendix®ACom®PRO™diagnostic software is required.
This software is available as a download from bendix.com.
1.1 TROUBLESHOOTING BASICS

7
Troubleshooting Checklist (Pages 7–8)
WARNING: The Troubleshooting Checklist should not be completed while the vehicle is in motion
and the while the driver is completing the scenarios and tests.
Detailed Scenarios and Tests Record Driver’s Answers for
Follow-up with Bendix
Does the vehicle maintain its set speed when the cruise control
is switched on and set? Yes No _____________
Is the cruise control “set” icon displayed? Yes No _____________
While following a forward vehicle within radar range and the cruise control is
switched on and set, record your response to the following:
Is the “forward vehicle detected” icon displayed?
What color is the icon?
When the forward vehicle slows down, does the truck also slow down to
maintain the set distance?
Yes No __________
Icon Color______________
Yes No _____________
󰀨
become faster as the truck moves closer to the forward vehicle? Yes No _____________
With cruise control switched on and set, when the forward vehicle slows
moderately or cuts in front of the truck and slows, did the driver observe any of
the following conditions?
Does the vehicle slow and the Bendix®Wingman®Fusion™system
maintain the following distance?
Is the engine throttle reduced?
Is the engine retarder applied?
Are foundation brakes applied?
Are there Diagnostic Trouble Codes (DTCs) logged?
Does the truck proceed toward the forward vehicle without a following
distance alert or braking intervention?
Yes No _____________
Yes No _____________
Yes No _____________
Yes No _____________
Yes No _____________
Yes No _____________
With cruise control engaged, and while following a vehicle ahead in gentle
curves (assuming a 3 to 3.5 second following distance):
Does the Bendix Wingman Fusion system continue to follow the vehicle
through the curves at a constant distance?
Does the truck proceed toward the forward vehicle without a following
distance alert or braking intervention?
Yes No _____________
Yes No _____________
With cruise engaged, when your vehicle passes a slower vehicle on the left or
right on a straight or slightly curvy road:
Does the Bendix Wingman Fusion system ignore
the vehicle you are overtaking?
Does it give a following distance alert?
Yes No _____________
Yes No _____________

8
Troubleshooting Checklist (Pages 7–8)
WARNING: The Troubleshooting Checklist should not be completed while the vehicle is in motion
and the while the driver is completing the scenarios and tests.
Detailed Scenarios and Tests Record Driver’s Answers for
Follow-up with Bendix
With cruise engaged, if a faster vehicle passes your vehicle on the left or right
on a straight or slightly curvy road:
Does your vehicle throttle up and try to keep pace
with the faster moving vehicle?
Does it give a following distance alert?
Yes No _____________
Yes No _____________
With cruise control engaged, if the vehicle ahead slows moderately or cuts in
front of your truck and slows down:
Does your vehicle slow and Bendix®Wingman®Fusion™
maintain the following distance?
Is the engine throttle reduced?
Is the engine retarder applied?
Are the foundation brakes applied?
Are there Diagnostic Trouble Codes (DTCs) logged?
Does your truck proceed toward the forward vehicle without
a following distance alert or braking intervention?
Yes No _____________
Yes No _____________
Yes No _____________
Yes No _____________
Yes No _____________
Yes No _____________
What version of Bendix®ABS and Bendix Wingman Fusion system is installed on
the vehicle? See Section 2.3: Reading the System Software Version. ___________________________
What are the key system indicators?
See Section 3.1: Reading Bendix Wingman Fusion System Key Indicators.
___________________________
___________________________
___________________________
___________________________
___________________________

9
1.2 NARROWING DOWN THE PROBLEM
Use the questions found in Table 2 below to help assess if the Bendix®Wingman®Fusion™system is not performing
correctly. Be sure to have a thorough understanding of the system’s normal behavior; this will reduce the troubleshooting
time. The table provides a guide to basic troubleshooting questions and possible corrective actions. Items in Italics cross-
reference to the service procedures in this manual to repair the condition described.
If Bendix Tech Team assistance is needed, prior to calling us at 1-800-AIR-BRAKE (1-800-247-2725), option 2, complete
the Troubleshooting Checklist to help reduce the time needed to troubleshoot the system.
Narrowing Down the Problem (1.2)
Questions Next Steps
Blocked Radar Sensor Issues
Is mud, ice, or snow covering the
radar sensor?
Is anything blocking the view of the
radar sensor?
Clean the radar sensor front surface immediately. Remove anything blocking the radar
sensor then power cycle and read any remaining trouble codes.
Read Section 2.5: Diagnostic Trouble Codes.
Read Appendix A3: Bendix™FLR-21™Radar Sensor Mounting Clearance.
If the radar sensor is blocked by ice, snow, mud, tampering, etc. so that it cannot "see" a
forward vehicle, the Bendix Wingman Fusion system will notify the driver by an audible
and/or visual alert. After the blockage is removed, the audible and/or visual alert will be
removed. Drivers should visually check the radar sensor for blockage during the pre-trip
inspection.
Potential False Warnings
Do false warnings seem to happen
in construction zones or going under
bridges?
Several road scenarios have a tendency to cause false warnings, including construction
zones and bridges. Unless these false warnings are frequent, the system is likely reacting
normally. The driver should not set the cruise control in construction zones. If driver

presenting the problems. Review proper operating conditions in the operator's manual.
Mounting Problems
Is the radar sensor mounting
location (bumper or cross-member)
damaged?
Does the system seem to not "see"
as far as it “used to”, or warn on
many more overhead bridges/signs
than previously?
Re-align the radar sensor vertically and laterally. Use the following procedures:
• Inspect the radar mounting. A solid mounting surface is necessary in order to hold the

align the radar sensor.
• Appendix B1 - Go to Appendix B1
needed. Follow the actions directed in the procedure(s) and align the radar.
• Appendix B4 - Check the vertical alignment and adjust if needed.
Does the mounting bracket look
damaged or tampered with?
Other than expected surface scratches or some discoloration over time, there should be no
visible damage to the radar sensor bracket assembly or the bumper. If no visible damage is
found, realign the radar sensor vertically and laterally.
• Check the Vertical Alignment (Appendix B4) and adjust if needed.
• Check the Lateral Alignment (Appendix B2 and B3) and adjust if needed.
The radar sensor needs a solid mounting surface in order to hold the alignment. If the
radar sensor alignment cannot be held in place, the bracket assembly must be replaced,
and/or if the bumper or mounting cross-member is damaged, replace it as needed. Where
replacing either or both of these, align the radar sensor using the procedure shown in
Appendix C.
Call the Bendix Tech Team at 1-800-AIR-BRAKE (1-800-247-2725), option 2, for troubleshooting assistance.
Table 2 – Narrowing Down the Problem (Pages 9–10)

10
Narrowing Down the Problem (1.2)
Questions Next Steps
Has the system worked without
problems in the past but is not
working as expected now?
This is a good indication that something has changed – such as misalignment of the radar
sensor. Review the following questions with the driver to further diagnose the problem.
Has the radar sensor been
changed recently?
If so, the new radar sensor may be incompatible with the vehicle. In addition, check any
system Diagnostic Trouble Codes (DTCs) with Bendix®ACom®PRO™Diagnostic Software.
Read Section 2.5: Diagnostic Trouble Codes.
Did the radar sensor currently on
the vehicle come from another
vehicle?
The radar sensor may be incompatible with the new vehicle. Follow Section K1.15: Radar
Sensor Interchangeability procedure and check system DTCs with Bendix ACom PRO
diagnostic software. Read Section 2.5: Diagnostic Trouble Codes.
With cruise control set, does the
system consistently apply the
foundation brakes when a forward
vehicle slows?
This is normal operation. Continue asking the driver questions to determine if the radar
system interventions are not the expected Bendix®Wingman®Fusion™system behavior. If
the radar system interventions are not typical, the radar sensor may be misaligned.
• Inspect the radar mounting. A solid mounting surface is necessary in order to hold the

align the radar sensor.
• Appendix B1 - Go to Appendix B1 
needed. Follow the actions directed in the procedure and align the radar.
• Appendix B4 - Check the vertical alignment and adjust if needed.
The service technician will need to check trouble codes as well. Read Section 2.5:
Diagnostic Trouble Codes.
Does a DTC seem to occur when
driving through the desert or in
barren areas (no road signs, trees,
or vehicles)?
In normal operation, the active cruise control with braking feature of the Bendix Wingman
Fusion system may indicate a DTC if it hasn’t detected a metallic object after a pre-
determined period. This is rare, but most likely to occur when driving in deserts or barren
areas. If the system does set a DTC, the Bendix Wingman Fusion system provides a
visible warning to the driver. In addition, the vehicle will also drop out of cruise mode,
󰀨
road and cycle the ignition before the vehicle’s cruise control can be used.
Does the system seem to
disengage after an automatic
braking event?
This is normal operation. The driver must set or "resume" the cruise control once again to
regain the following distance function.
Does cruise control disengage
sometimes when the brakes come
on and not at other times?
This is normal operation. When traveling with lightly loaded trailers, or “bobtail”, the active
cruise control with braking feature of the Bendix Wingman Fusion system may continue to
function even after an automatic brake application. No driver input is needed.
Does the connector or wiring
appear damaged?
Wires can become corroded if the radar sensor is not plugged in properly. Clean the
connectors on the wire harness, as well as the radar sensor, and reattach. If wires are
chafed, replace the wire harness. Also, check for trouble codes.
Read Section 2.5: Diagnostic Trouble Codes, and
Section 2.12: Troubleshooting Wiring Harnesses.
Does the system generate a DTC
going down a grade when using
ACB (Active Cruise-control with
Braking) to slow the vehicle, but the
code goes away later?
This is normal operation. The active cruise control with braking feature of the Bendix
Wingman Fusion system is not intended to be used on grades. Verify there are no DTCs.
Proper downgrade driving techniques should be used.
Read Section 2.5: Diagnostic Trouble Codes.
Does the radar sensor have
noticeable damage beyond normal
discoloration or surface scratches?
The radar sensor and bracket are very durable. However, if the radar sensor housing or
cover is cracked or broken, immediately look for trouble codes via Bendix ACom PRO
diagnostic software and replace the damaged radar sensor. Read Section 2.5: Diagnostic
Trouble Codes, and Appendix A3: Radar Sensor Mounting Clearance.
Call the Bendix Tech Team at 1-800-AIR-BRAKE (1-800-247-2725), option 2, for troubleshooting assistance.
Table 2 – Narrowing Down the Problem (Pages 9–10)

11
Overview of Possible Issues (1.3)
Issue Description
Vehicle Diagnostic
Trouble Codes
(DTCs)
The Bendix Wingman Fusion system will not operate and will set a DTC if any of the
following vehicle systems also show a DTC: engine, engine cruise, instrument cluster,
Bendix®ABS, Bendix®ATC, Bendix®ESP®, or transmission. These components must be
repaired and cleared of DTCs before troubleshooting the Wingman Fusion system. (NOTE:
Clearing the vehicle DTCs may be the only step needed to reestablish full Fusion system
functionality. See Section 2.6: Clearing Diagnostic Trouble Codes (DTCs).
System familiarity Verify the system functionality. Is it operating normally or not? Drivers who are unfamiliar with
the system may report dissatisfaction over the way it beeps or how it activates the brakes.
Use Section 1.0: Introduction to Troubleshooting, Section 1.1: Troubleshooting Basics, and
Section 2.5: Diagnostic Trouble Codes to verify if the system is functioning normally; then
continue.
DTCs caused by
temporary operating
conditions
Some DTCs indicate a temporary condition and will clear when that condition is no longer
present. If these persist, further investigation is warranted.
See Section 1.1: Troubleshooting Basics.
Radar sensor
blocked
If the system doesn’t seem to work at all, the radar sensor may possibly be blocked. If the
radar is blocked, an alert should be issued to the driver to indicate this condition. Visually
inspect the area around the radar, clear the blockage, turn the ignition on and run through a
power cycle. See Appendix A3 for more information about radar mounting and clearances.
Damaged radar
sensor or bracket
If the vehicle has been in an accident, it is likely the radar sensor will need to be re-aligned
or replaced. Inspect the radar sensor and housing for damage. Radar sensor discoloration

will require radar sensor replacement. Regardless of the exterior condition, check for DTCs
outlined in the Section 2.5: Diagnostic Trouble Codes (DTCs) to determine if radar sensor
replacement is necessary.
Damaged connector
or wiring

2.7: Troubleshooting Diagnostic Trouble Codes: Power Supply and 2.8 Serial Data (J1939)
Communications Link of this document for additional troubleshooting.
Radar sensor
misalignment
Inspect the front of the vehicle. If a) it has been damaged; or b) the vehicle does not track
straight, either of these conditions must be repaired before troubleshooting the Bendix Wingman
Fusion system.
If there is a DTC set or if the system does not function, the radar sensor may be severely
misaligned and the Wingman Fusion system will not operate until this is corrected. See
Appendix B - Radar Alignment.
J1939 network
problems
If the entire system is non-functional, it may be a J1939 network problem. Follow the
instructions in Section 2.8: Serial Data (J1939) Communications Link.
Power to radar
sensor problems
If the entire system is non-functional, another likely cause may be a lack of power to the radar sensor.
Follow the instructions in Section 2.7: Troubleshooting Diagnostic Trouble Codes: Power Supply.
Call the Bendix Tech Team at 1-800-AIR-BRAKE (1-800-247-2725), option 2 for troubleshooting assistance.
Table 3 – Overview of Possible Issues
1.3 OVERVIEW OF POSSIBLE ISSUES
Some customer issues are actually misunderstandings of how the Bendix®Wingman®Fusion™system performs normally.
Use Table 3 below to learn the causes of potential issues if the Fusion system is not performing correctly. Some issues
can be investigated by a visual inspection. Others may cause a Diagnostic Trouble Code (DTC) to be logged: See Section
2.5: Diagnostic Trouble Codes.

12
1.4 IMPORTANT NOTE ON
TELEMATICS WIRING
Where a vehicle does not have an On Board Computer/
Telematics (OBC/T) system – in order to prevent
interference to the SafetyDirect®by Bendix CVS Web
Portal Processor – disconnect the OBC/T harness (any
wiring harness provisionally installed in the vehicle for
potential use for Telematics) from the main vehicle harness.
Re-connect the harness only when an OBC/T system is
installed. (See Appendix K, Figure K6).
2.0 TROUBLESHOOTING/
DIAGNOSTICS SECTION
IMPORTANT
All vehicle Diagnostic Trouble Codes (DTCs)
related to the engine, transmission, instrument
cluster, engine cruise control, and Bendix®
ABS, ATC, or ESP®systems must first be
resolved – with no trouble codes present
during the vehicle operation while in cruise
control – before attempting to diagnose
Bendix®Wingman®Fusion™system DTCs.
Important examples are VDC2 and EBC
DTCs which are typically related to the brake
controller. The hierarchy of Electronic Control
Units (ECUs) determines that any DTCs on
the brake controller must be resolved before
attempting to troubleshoot the Wingman
Fusion system.
2.1 BENDIX®ACOM®PRO™
DIAGNOSTIC SOFTWARE
Bendix®ACom®PRO™Diagnostic Software is a PC-based
software program available to purchase from bendix.com.
This software provides the technician with access to all
the available Electronic Control Unit (ECU) diagnostic
     

ACom PRO Diagnostic Software.
STARTING BENDIX ACOM PRO
DIAGNOSTIC SOFTWARE
The ACom PRO Diagnostic Software can be started from
the desktop shortcut. To begin, the technician should
select “Connect” from the main toolbar, then “Heavy Duty”
connection type. The “Heavy Duty” button connects to the
vehicle BUS using all vehicle protocols. This process could
take approximately two (2) minutes. After the connection is
complete, the roll call will show the ECU and its active and
inactive DTCs. The connection depends on a compatible
RP1210C adapter. For assistance with the ACom PRO
Diagnostic Software, contact the Bendix Tech Team at
1-800-AIR-BRAKE (1-800-247-2725, option 2, option 2).
Figure 5 - Starting Bendix ACom PRO Diagnostic Software
Figure 4 – Bendix ACom PRO Diagnostic Software

13
2.2 READING DIAGNOSTIC
TROUBLE CODES (DTCS)
1. Connect a current version of the Bendix®ACom®
PRO™Diagnostic Software to the vehicle.
2. Once the roll call is complete, you can view active
and inactive DTCs and clear DTCs from all vehicle
components or solely from a selected Bendix
controller.
3. To read and clear DTCs from all vehicle components
at the same time, select the vehicle on the roll call and
clear the DTCs by selecting “Clear Faults.”
4. To read and clear DTCs from a specific Bendix
Electronic Control Unit (ECU), select the Bendix ECU
on the roll call select “Clear Faults.”
For assistance with ACom PRO Diagnostic Software,
contact the Bendix Tech Team at 1-800-AIR-BRAKE
(1-800-247-2725, option 2, option 2).
2.3 READING THE SYSTEM
SOFTWARE VERSION
Connect a current version of Bendix®ACom®PRO™
Diagnostic Software to the vehicle. View the software
version by selecting the appropriate vehicle.
2.4 HOW TO GENERATE A BENDIX WINGMAN FUSION SYSTEM
DIAGNOSTIC TROUBLE CODE (DTC) REPORT
1. Connect a current version of the Bendix®ACom®PRO™
Diagnostic Software with the vehicle.
2. Once the roll call is complete, you can select the DTC Report
icon on the top menu.
3. The DTC report drop-down gives you the following options:
• Print DTC Report
• Print Preview of the DTC Report
• Submit DTC Report
4. Select “Print Preview” to generate and save the report
Figure 5 – Starting Bendix ACom
PRO Diagnostic Software
Figure 6 – Bendix®ACom®PRO™Diagnostic Software
Starter Screen Showing Software Version

14
ADDITIONAL SUPPORT AT BENDIX.COM/1-800-AIR-BRAKE (1-800-247-2725), OPTION 2
For the latest information, and for downloads of the Bendix®ACom®PRO™Diagnostic Software, visit the Bendix
website at bendix.com.
®Wingman®ACB system.
For direct telephone technical support, contact the Bendix Tech Team at 1-800-AIR-BRAKE (1-800-247-2725), option 2.
Representatives are available Monday through Thursday, 8:00 a.m. – 6:00 p.m., and Friday, 8:00 a.m. – 5:00 p.m. ET.

(pages 7–8) and a Bendix ACom PRO diagnostic software DTC report (Section 2.4) before calling.
You can also reach the Bendix Tech Team by email at [email protected].

15
2.5 TABLE OF BENDIX®WINGMAN®FUSION™DIAGNOSTIC TROUBLE CODES (DTCs)
NOTE: Bendix™FLR-10™ radar sensors use a dierent set of DTCs – see SD-61-4962.
For DTC(s), refer to Table 4A. [Alternately, see a table sorted by SPN (Suspect Parameter Number) and FMI (Failure


Table 4A: Diagnostic Trouble Codes (DTCs), Descriptions, and Service Action Codes
Go to the
Service Action
Code List in
Table 4B
(Pages 22-30)
DTC Description SPN FMI
1–2 Internal radar sensor error 886 12 A
3 Antenna is dirty or partially blocked 886 17 B
4 Battery voltage too low 886 4 C
5 Battery voltage too high 886 3
6–10 Internal radar sensor error 630 12 A
11 J1939 Error Frame limit reached: J1939 wiring error 639 19
Y
12 Radar detects intermittent loss of J1939 messages from vehicle
components 639 9
13–14 Not used #N/A #N/A Not Used
15 Internal radar sensor error 886 12 A
16 Antenna is dirty or partially blocked 886 1 B
17–18 Internal radar sensor error 630 12 A
19 Not used #N/A #N/A Not Used
20 Internal radar sensor error 630 12 A
21 Not used #N/A #N/A Not Used
22 Internal radar sensor error 886 14 A
23–27 Internal radar sensor error 886 12
28 Internal radar sensor error 1799 14 D
29 J1939 signal: Missing AEBS2 message 5681 14
30 J1939 signal: Missing CCVS1 message 527 14 D
31 J1939 signal: Missing CVW message 1760 14
D
32 J1939 signal: Missing EBC1 message 1243 14
33 J1939 signal: Missing EBC2 message 904 14
34 J1939 signal: Missing EBC5 message 2919 14
35 J1939 signal: Missing EEC1 message 190 14
36 J1939 signal: Missing EEC2 message 91 14
37 J1939 signal: Missing ERC1_DR message 520 9
38 J1939 signal: Missing ERC1_XR message 520 14
39 Not used #N/A #N/A Not Used
40 J1939 signal: Missing OEL message 2876 14 D
41 Not used #N/A #N/A Not Used
42 J1939 signal: Missing VDC2 message 1807 14 D
43 Not used #N/A #N/A Not Used
44 J1939 signal: Missing EBC3 message 1091 14 D
45 Not used #N/A #N/A Not Used
46 Radar sensor is misaligned 886 7 G
Note: The system will not report newly active J1939 Diagnostic Trouble Codes (DTCs) until the engine has been
running for 15 seconds. Do not attempt to diagnose J1939 DTCs without the engine running.
Call the Bendix Tech Team at 1-800-AIR-BRAKE (1-800-247-2725), option 2, for troubleshooting assistance.
Table 4A – DTC Code to Service Action Code (Pages 15 – 21)

16
Table 4A: Diagnostic Trouble Codes (DTCs), Descriptions, and Service Action Codes
Go to the
Service Action
Code List in
Table 4B
(Pages 22-30)
DTC Description SPN FMI
47 Internal radar sensor error 886 12 A
48 Internal radar sensor error 630 14 A
49–53 Not used #N/A #N/A Not Used
54 Internal radar sensor error 630 12 A
55–58 Not used #N/A #N/A Not Used
59 Internal radar sensor error 886 31
A
60 Internal radar sensor error 886 12
61 Internal radar sensor error 886 14
62 Not used #N/A #N/A Not Used
63 Internal radar sensor error 886 12 A
64–65 Not used #N/A #N/A Not Used
66 Internal radar sensor error 886 12
A
67 Internal radar sensor error 886 8
68–77 Internal radar sensor error 886 12
78 Bendix®ABS J1939 proprietary message signal missing or error state 2551 14 H
79–81 Internal radar sensor error 886 12 A
82 Active Cruise Control braking overuse 3839 0 J
83 ®
Wingman®5606 13 K
84–85 Internal radar sensor error 630 12 A
86 
sensor 886 13 L
87 J1939 signal: Missing VDC1 message 1814 14 D
88 CMT braking overuse 2920 0 M
89–91 Not used #N/A #N/A Not Used
92 J1939 signal: Invalid CCVS2 wheel speed 84 2 N
93 J1939 signal: Error in CCVS1 wheel speed 84 19 N
94 J1939 signal: Not available CCVS1 wheel speed 84 9 N
95 J1939 signal: Invalid CCVS1 CC speed 86 2 N
96 J1939 signal: Error in CCVS1 CC speed 86 19 N
97 J1939 signal: Not available CCVS1 CC speed 86 9 N
98 J1939 signal: Error CCVS1 CC active 595 19 N
99 J1939 signal: Not available CCVS1 CC active 595 9 N
100 J1939 signal: Error in CCVS1 CC enable 596 19 N
101 J1939 signal: Not available CCVS1 CC enable 596 9 N
102–103 Not used #N/A #N/A Not Used
104 J1939 signal: Invalid CVW GCVW 1760 2 N
105 J1939 signal: Error in CVW gross combination vehicle weight (GCVW) 1760 19 N
106 J1939 signal: Not available CVW GCVW 1760 9 N
107 J1939 signal: Error in EBC1 brake switch 1121 19 N
108 J1939 signal: Not available EBC1 brake switch 1121 9 N
109 J1939 signal: Error in EBC1 ABS fully operational 1243 19 N
110 J1939 Signal: Not available EBC1 ABS Operate 1243 9 N
Note: The system will not report newly active J1939 Diagnostic Trouble Codes (DTCs) until the engine has been
running for 15 seconds. Do not attempt to diagnose J1939 DTCs without the engine running.
Call the Bendix Tech Team at 1-800-AIR-BRAKE (1-800-247-2725), option 2, for troubleshooting assistance.
Table 4A – DTC Code to Service Action Code (Pages 15 – 21)

17
Table 4A: Diagnostic Trouble Codes (DTCs), Descriptions, and Service Action Codes
Go to the
Service Action
Code List in
Table 4B
(Pages 22-30)
DTC Description SPN FMI
111 J1939 signal: Invalid EBC2 front axle 904 2 N
112 J1939 signal: Error in EBC2 front axle 904 19 N
113 J1939 signal: Not available EBC2 front axle 904 9 N
114 J1939 signal: Invalid EBC2 LF wheel 905 2 N
115 J1939 signal: Error in EBC2 LF wheel 905 19 N
116 J1939 signal: Not available EBC2 LF wheel 905 9 N
117 J1939 signal: Invalid EBC2 RF wheel 906 2 N
118 J1939 signal: Error in EBC2 RF wheel 906 19 N
119 J1939 signal: Not available EBC2 RF wheel 906 9 N
120 J1939 signal: Invalid EBC2 LR1 wheel 907 2 N
121 J1939 signal: Error in EBC2 LR1 wheel 907 19 N
122 J1939 signal: Not available EBC2 LR1 wheel 907 9 N
123 J1939 signal: Invalid EBC2 RR1 wheel 908 2 N
124 J1939 signal: Error in EBC2 RR1 wheel 908 19 N
125 J1939 signal: Not available EBC2 RR1 wheel 908 9 N
126 J1939 signal: Invalid EBC5 XBR state 2917 2 N
127 J1939 signal: Error in EBC5 XBR state 2917 19 N
128 J1939 signal: Not available EBC5 XBR state 2917 9 N
129 J1939 signal: Error in EBC5 brake use 2919 19 N
130 J1939 signal: Not available EBC5 brake use 2919 9 N
131 J1939 signal: Invalid EBC5 XBR limit 2921 2 N
132 J1939 signal: Error in EBC5 XBR limit 2921 19 N
133 J1939 signal: Not available EBC5 XBR limit 2921 9 N
134 J1939 signal: Error in EBC5 brake temp 3839 19 N
135 J1939 signal: Not available EBC5 brake temp 3839 9 N
136 J1939 signal: Invalid EC1 engine reference torque 544 2 N
137 J1939 signal: Error in EC1 engine reference torque 544 19 N
138 J1939 signal: Not available EC1 engine reference torque 544 9 N
139 J1939 signal: Invalid EEC1 engine speed 190 2 N
140 J1939 signal: Error in EEC1 engine speed 190 19 N
141 J1939 signal: Not available EEC1 engine speed 190 9 N
142 J1939 signal: Invalid EEC1 driver torque 512 2 N
143 J1939 signal: Error in EEC1 driver torque 512 19 N
144 J1939 signal: Not available EEC1 driver torque 512 9 N
145 J1939 signal: Invalid EEC1 actual torque 513 2 N
146 J1939 signal: Error in EEC1 actual torque 513 19 N
147 J1939 signal: Not available EEC1 actual torque 513 9 N
148 J1939 signal: Invalid EEC2 accelerator pedal position 91 2 N
149 J1939 signal: Error in EEC2 accelerator pedal position 91 19 N
150 J1939 signal: Not available EEC2 accelerator pedal position 91 9 N
151–154 Not used #N/A #N/A Not Used
155 J1939 signal: Invalid OEL turn signal 2876 2 N
156 J1939 signal: Error in OEL turn signal 2876 19 N
Note: The system will not report newly active J1939 Diagnostic Trouble Codes (DTCs) until the engine has been
running for 15 seconds. Do not attempt to diagnose J1939 DTCs without the engine running.
Call the Bendix Tech Team at 1-800-AIR-BRAKE (1-800-247-2725), option 2, for troubleshooting assistance.
Table 4A – DTC Code to Service Action Code (Pages 15 – 21)

18
Table 4A: Diagnostic Trouble Codes (DTCs), Descriptions, and Service Action Codes
Go to the
Service Action
Code List in
Table 4B
(Pages 22-30)
DTC Description SPN FMI
157 J1939 signal: Not available OEL turn signal 2876 9 N
158 J1939 signal: Error in VDC1 ROP brake control 1818 19 N
159 J1939 signal: Not available VDC1 ROP brake control 1818 9 N
160 J1939 signal: Error in VDC1 ROP engine control 1816 19 N
161 J1939 signal: Not available VDC1 ROP engine control 1816 9 N
162 J1939 signal: Error in VDC1 YC brake control 1819 19 N
163 J1939 signal: Not available VDC1 YC brake control 1819 9 N
164 J1939 signal: Error in VDC1 YC engine control 1817 19 N
165 J1939 signal: Not available VDC1 YC engine control 1817 9 N
166 J1939 signal: Invalid VDC2 steer angle 1807 2 N
167 J1939 signal: Error in VDC2 steer angle sensor 1807 19 N
168 J1939 signal: Not available VDC2 steer angle 1807 9 N
169 J1939 signal: Invalid VDC2 yaw rate 1808 2 N
170 J1939 signal: Error in VDC2 yaw rate 1808 19 N
171 J1939 signal: Not available VDC2 yaw rate 1808 9 N
172–174 Not used #N/A #N/A Not Used
175 J1939 signal: Invalid TSC1 requested torque limit 518 2 N
176 J1939 signal: Error in TSC1 requested torque limit 518 19 N
177 J1939 signal: Not available TSC1 requested torque limit 518 9 N
178 Antenna is dirty or partially blocked 886 17 B
179 Vehicle Cruise Control and ACC out of sync 886 14 S
180 󰀨 886 2 T
181 J1939 signal: EBC1 ABS not fully operational 1243 2 U
182 J1939 signal: VDC1 VDC not fully operational 1814 2 H
183 J1939 signal: Error in VDC1 VDC fully operational 1814 19 N
184 J1939 signal: Not available VDC1 VDC fully operational 1814 9 N
185 ABS tire size needs recalibration 1069 13 V
186 Internal radar sensor error 630 12 A
187 J1939 signal: Error in ACC1 ACC mode 5606 2 N
188 J1939 signal: Not available ACC1 ACC mode 5606 19 N
189 
Wingman 5606 13 K
190 Internal radar sensor error 5676 14 A
191 Internal radar sensor error 2921 12 A
192–193 Internal radar sensor error 630 12 A
194 Proprietary CAN: Message counter error 625 19 X
195 Proprietary CAN: Message timeout 625 9 X
196 Proprietary CAN: Message inconsistent 625 2 X
197 Not used #N/A #N/A Not Used
198 J1939 signal: Missing EC1 message 188 14 D
199 J1939 signal: Error in AEBS2 driver activation demand 5681 19 N
200 J1939 signal: Not available AEBS2 driver activation 5681 9 N
201 J1939 signal: Error in AEBS2 message checksum 5683 19 N
Note: The system will not report newly active J1939 Diagnostic Trouble Codes (DTCs) until the engine has been
running for 15 seconds. Do not attempt to diagnose J1939 DTCs without the engine running.
Call the Bendix Tech Team at 1-800-AIR-BRAKE (1-800-247-2725), option 2, for troubleshooting assistance.
Table 4A – DTC Code to Service Action Code (Pages 15 – 21)

19
Table 4A: Diagnostic Trouble Codes (DTCs), Descriptions, and Service Action Codes
Go to the
Service Action
Code List in
Table 4B
(Pages 22-30)
DTC Description SPN FMI
202–204 Not used #N/A #N/A Not Used
205 J1939 signal: Invalid ACC2 requested ACC distance mode 1799 2 N
206 J1939 signal: Error in ACC2 requested ACC distance mode 1799 19 N
207 J1939 signal: Not available ACC2 distance mode 1799 9 N
208 J1939 signal: Error in ACC2 ACC usage demand 5023 19 N
209 J1939 signal: Not available ACC2 ACC usage 5023 9 N
210 J1939 signal: Error in AUXIO1 trailer ABS operational 707 19 N
211 J1939 signal: Not available AUXIO trailer ABS operational 707 9 N
212 J1939 signal: Error in AUXIO1 trailer ABS detected 706 19 N
213 J1939 signal: Not available AUXIO trailer ABS detected 706 9 N
214 J1939 signal: Error in AUXIO1 trailer connected 705 19 N
215 J1939 signal: Not available AUXIO trailer connected 705 9 N
216 J1939 signal: Error in CCVS1 parking brake switch 70 19 N
217 J1939 signal: Not available CCVS1 parking brake switch 70 9 N
218 J1939 signal: Error in CCVS1 Cruise Control set switch 599 19 N
219 J1939 signal: Not available CCVS1 set switch 599 9 N
220 J1939 signal: Error in CCVS1 Cruise Control coast switch 600 19 N
221 J1939 signal: Not available CCVS1 coast switch 600 9 N
222 J1939 signal: Error in CCVS1 Cruise Control resume switch 601 19 N
223 J1939 signal: Not available CCVS1 resume switch 601 9 N
224 J1939 signal: Error in CCVS1 Cruise Control accelerate switch 602 19 N
225 J1939 signal: Not available CCVS1 ACCL switch 602 9 N
226 J1939 signal: Error in CCVS1 Cruise Control pause switch 1633 19 N
227 J1939 signal: Not available CCVS1 pause switch 1633 9 N
228 J1939 signal: Invalid EBC1 brake pedal position 521 2 N
229 J1939 signal: Error in EBC1 brake pedal position 521 19 N
230 J1939 signal: Not available EBC1 brake pedal position 521 9 N
231 J1939 signal: Error in EBC1 anti-lock braking active 563 19 N
232 J1939 signal: Not available EBC1 ABS active 563 9 N
233 J1939 signal: Error in EBC1 ASR engine control active 561 19 N
234 J1939 signal: Not available EBC1 ASR engine control active 561 9 N
235 J1939 signal: Error in EBC1 ASR brake control active 562 2 N
236 J1939 signal: Not available EBC1 ASR brake control active 562 19 N
237 J1939 signal: Error in EBC1 source address of controlling device 1481 2 N
238 J1939 signal: Not available EBC1 source address of controlling device 1481 19 N
239 J1939 signal: Invalid EBC5 XBR active control mode 2918 2 N
240 J1939 signal: Error in EBC5 XBR active control mode 2918 19 N
241 J1939 signal: Not available EBC5 XBR active control mode 2918 9 N
242–245 Not used #N/A #N/A Not Used
246 J1939 signal: Invalid EC1 engine speed at idle point 1 188 2 N
247 J1939 signal: Error in EC1 engine speed at idle point 1 188 19 N
248 J1939 signal: Not available EC1 engine speed at idle point 1 188 9 N
249 J1939 signal: Invalid EEC3 nominal friction percent torque 514 2 N
Note: The system will not report newly active J1939 Diagnostic Trouble Codes (DTCs) until the engine has been
running for 15 seconds. Do not attempt to diagnose J1939 DTCs without the engine running.
Call the Bendix Tech Team at 1-800-AIR-BRAKE (1-800-247-2725), option 2, for troubleshooting assistance.
Table 4A – DTC Code to Service Action Code (Pages 15 – 21)

20
Table 4A: Diagnostic Trouble Codes (DTCs), Descriptions, and Service Action Codes
Go to the
Service Action
Code List in
Table 4B
(Pages 22-30)
DTC Description SPN FMI
250 J1939 signal: Error in EEC3 nominal friction percent torque 514 19 N
251 J1939 signal: Not available EEC3 nominal friction percent torque 514 9 N
252 J1939 signal: Error in ETC1 transmission driveline engaged 560 19 N
253 J1939 signal: Not available ETC1 transmission driveline engaged 560 9 N
254 J1939 signal: Invalid ETC2 transmission selected gear 524 2 N
255 J1939 signal: Error in ETC2 transmission selected gear 524 19 N
256 J1939 signal: Not available ETC2 transmission selected gear 524 9 N
257 J1939 signal: Invalid ETC2 transmission actual gear ratio 526 2 N
258 J1939 signal: Error in ETC2 transmission actual gear ratio 526 19 N
259 J1939 signal: Not available ETC2 transmission actual gear ratio 526 9 N
260 J1939 signal: Invalid ETC2 transmission current gear 523 2 N
261 J1939 signal: Error in ETC2 transmission current gear 523 19 N
262 J1939 signal: Not available ETC2 transmission current gear 523 9 N
263 J1939 signal: Error in TC1 transmission requested gear 525 19 N
264 J1939 signal: Not available TC1 transmission requested gear 525 9 N
265 J1939 signal: Missing AUXIO message 701 14 D
266 J1939 signal: Missing DM1 message 1214 14 D
267 J1939 signal: Missing EEC3 message 514 14 D
268 J1939 signal: Missing ETC1 message 560 14 D
269 J1939 signal: Missing ETC2 message 524 14 D
270 J1939 signal: Missing TC1 message 525 14 D
271 J1939 signal: Missing FLC message 1705 14 D
272 J1939 signal: AUXIO trailer ABS not fully operational 707 2 H
273 Proprietary CAN: Message counter increment error 625 10 X
274 
sensor 630 19 L
275 J1939 signal: Missing ETC5 message 767 14 D
276 J1939 signal: Error in ETC5 reverse switch 767 19 N
277 J1939 signal: Not available ETC5 reverse switch 767 9 N
278 J1939 signal: Error in CCVS1 brake switch 597 19 N
279 J1939 signal: Not available CCVS1 brake switch 597 9 N
280 XBR is locked-out 1196 19 S
281 Internal radar sensor error 630 12
282 Automatic braking system was activated too many times 2920 0 M
283 Internal radar sensor error 886 12 A
284 
sensor 625 13 L
285 AEBS deactivated because of factory mode 5681 13 B
286 System detected an error requiring a radar shutdown 886 18
287 System detected engine not properly responding to control messages 513 13 FF
290 J1939: Engine Controller Signal Invalid - ERC1 Actual Engine Torque 1717 2 Z
291 J1939: Retarder Controller Signal Error - ERC1 Actual Max Torque 1717 19 AA
Note: The system will not report newly active J1939 Diagnostic Trouble Codes (DTCs) until the engine has been
running for 15 seconds. Do not attempt to diagnose J1939 DTCs without the engine running.
Call the Bendix Tech Team at 1-800-AIR-BRAKE (1-800-247-2725), option 2, for troubleshooting assistance.
Table 4A – DTC Code to Service Action Code (Pages 15 – 21)
