BeneVision N22 User manual

BeneVision N22/N19
Patient Monitor
Service Manual

I
Intellectual Property Statement
SHENZHEN MINDRAY BIO-MEDICAL ELECTRONICS CO., LTD. (hereinafter called Mindray) owns the
intellectual property rights to this product and this manual. This manual may refer to information
protected by copyrights or patents and does not convey any license under the patent rights of Mindray,
nor the rights of others. Mindray does not assume any liability arising out of any infringements of patents
or other rights of third parties.
, , and are the registered trademarks or trademarks owned by
Mindray in China and other countries.
Revision History
This manual has a revision number. This revision number changes whenever the manual isupdated due
to software or technical specification change. Contents of this manual aresubject to change without prior
notice.
Version number: 8.0
Release time: 2021-03
© 2016 - 2021 Shenzhen Mindray Bio-Medical Electronics Co., Ltd. All rights reserved.

II
Preface
Manual Purpose
This manual provides detailed information about the assembling, dissembling, testing and
troubleshooting of the equipment to support effective troubleshooting and repair. It is not intended to be
a comprehensive, in-depth explanation of the product architecture or technical implementation.
Observance of the manual is a prerequisite for proper equipment maintenance and prevents equipment
damage and personnel injury.
Intended Audience
This manual is for biomedical engineers, authorized technicians or service representatives responsible for
troubleshooting, repairing and maintaining the monitors
Passwords
A password may be required to access different modes. The passwords are listed below:
User maintenance: 888888
Manage Configuration: 315666
Factory maintenance: 332888
Demo mode: 2088

1
Contents
1 Safety ................................................................................................................................................................................. 1-1
1.1 Safety Information..........................................................................................................................................................................................1-1
1.1.1 Dangers ................................................................................................................................................................................................1-1
1.1.2 Warnings ..............................................................................................................................................................................................1-2
1.1.3 Cautions ...............................................................................................................................................................................................1-2
1.1.4 Notes .....................................................................................................................................................................................................1-3
1.2 Equipment Symbols ......................................................................................................................................................................................1-3
2 Operation Theory .............................................................................................................................................................. 2-1
2.1 Overview............................................................................................................................................................................................................2-1
2.2 Product System Architecture......................................................................................................................................................................2-1
2.2.1 Functions of the Main Control Module.....................................................................................................................................2-3
2.2.2 AC-DC Module ...................................................................................................................................................................................2-4
2.2.3 Functions and Socket Definitions of the DCDC Board........................................................................................................2-4
2.2.4 Front Housing Interface Board ....................................................................................................................................................2-7
2.2.5 iView Substrate..................................................................................................................................................................................2-7
2.3 Power System...................................................................................................................................................................................................2-8
2.3.1 Power Diagram of the Main Unit and the Module Rack ..................................................................................................... 2-8
2.3.2 The Secondary Screen of N22/N19 Uses Independent AC Adapter for Power Supply............................................ 2-9
2.4 Signal Logic Flow............................................................................................................................................................................................2-9
2.4.1 Startup Signal Flow..........................................................................................................................................................................2-9
2.4.2 Display Signal Flow ........................................................................................................................................................................2-10
2.4.3 Display Brightness Control..........................................................................................................................................................2-11
2.4.4 Module Initialization......................................................................................................................................................................2-12
3 WLAN Installation ............................................................................................................................................................. 3-1
3.1 Introduction......................................................................................................................................................................................................3-1
3.2 Network Deployment Process ...................................................................................................................................................................3-1
3.2.1 List of outputs....................................................................................................................................................................................3-2
3.3 Network Requirements ................................................................................................................................................................................3-3
3.4 Network Verification......................................................................................................................................................................................3-4
3.4.1 Tools and Resources.........................................................................................................................................................................3-4
3.4.2 Wi-Fi Signal Calibration...................................................................................................................................................................3-4
3.4.3 Network Verification Process........................................................................................................................................................3-5
3.5 Network Coverage Assessment with Patient Monitors ....................................................................................................................3-7
3.6 Recommended Devices for WLAN ...........................................................................................................................................................3-8
3.7 Setting Wireless Parameters for Patient Monitors ..............................................................................................................................3-8
3.8 Troubleshooting............................................................................................................................................................................................3-11
4 Testing and Maintenance ................................................................................................................................................. 4-1
4.1 Introduction......................................................................................................................................................................................................4-1

2
4.1.1 Test Equipment..................................................................................................................................................................................4-1
4.1.2 Test Report ..........................................................................................................................................................................................4-1
4.1.3 Preventative Maintenance ............................................................................................................................................................4-1
4.1.4 Recommended Frequency............................................................................................................................................................4-2
4.2 Preventative Maintenance Procedures...................................................................................................................................................4-3
4.2.1 Visual Inspection...............................................................................................................................................................................4-3
4.2.2 NIBP Tests.............................................................................................................................................................................................4-4
4.2.3 Sidestream and Microstream CO2Tests ....................................................................................................................................4-6
4.2.4 AG Tests ................................................................................................................................................................................................4-8
4.3 Power On Test ................................................................................................................................................................................................4-11
4.4 Module Performance Tests........................................................................................................................................................................4-11
4.4.1 ECG Tests............................................................................................................................................................................................4-11
4.4.2 Resp Performance Test..................................................................................................................................................................4-12
4.4.3 SpO2Test ............................................................................................................................................................................................4-12
4.4.4 NIBP Tests...........................................................................................................................................................................................4-13
4.4.5 Temp Test...........................................................................................................................................................................................4-13
4.4.6 IBP Tests..............................................................................................................................................................................................4-13
4.4.7 C.O. Test ..............................................................................................................................................................................................4-15
4.4.8 Mainstream CO2Tests....................................................................................................................................................................4-16
4.4.9 Sidestream and Microstream CO2Tests ..................................................................................................................................4-17
4.4.10 AG Tests............................................................................................................................................................................................4-17
4.4.11 EEG Test............................................................................................................................................................................................4-17
4.4.12 BIS Test .............................................................................................................................................................................................4-18
4.4.13 RM Test .............................................................................................................................................................................................4-19
4.4.14 CCO/SvO2 Tests ..............................................................................................................................................................................4-20
4.4.15 PiCCO Test .......................................................................................................................................................................................4-20
4.4.16 NMT Tests ........................................................................................................................................................................................4-23
4.4.17 ANI Test ............................................................................................................................................................................................4-23
4.5 Nurse Call Relay Performance Test .........................................................................................................................................................4-25
4.6 Analog Output Performance Test ...........................................................................................................................................................4-26
4.7 Electrical Safety Tests...................................................................................................................................................................................4-26
4.8 Touchscreen Calibration (Resistive Touchscreen) .............................................................................................................................4-26
4.9 Recorder Check .............................................................................................................................................................................................4-27
4.10 Network Print Test......................................................................................................................................................................................4-27
4.10.1 Device Connection and Setup.................................................................................................................................................4-27
4.11 Device Integration Check........................................................................................................................................................................4-28
4.12 Battery Check...............................................................................................................................................................................................4-28
4.13 Mounting Check .........................................................................................................................................................................................4-29
4.13.1 Overall Test and Check of Installed System ........................................................................................................................4-29
4.14 Factory Maintenance ................................................................................................................................................................................4-29
4.14.1 Accessing Factory Maintenance Menu.................................................................................................................................4-29
4.14.2 Monitor Information ...................................................................................................................................................................4-30
4.14.3 Production Test .............................................................................................................................................................................4-31
4.14.4 Setup.................................................................................................................................................................................................4-31

3
4.14.5 Debug...............................................................................................................................................................................................4-32
4.14.6 Power Info.......................................................................................................................................................................................4-32
4.14.7 ClinicalData ....................................................................................................................................................................................4-33
4.14.8 Transferring Clinical Data ..........................................................................................................................................................4-33
4.14.9 Software Version...........................................................................................................................................................................4-33
4.14.10 Monitor Information.................................................................................................................................................................4-33
5 Hardware Upgrade............................................................................................................................................................ 5-1
5.1 Overview............................................................................................................................................................................................................5-1
5.2 Upgrade of Parameter Function Modules .............................................................................................................................................5-1
5.3 Upgrade of Functional Assemblies ..........................................................................................................................................................5-3
5.3.1 Upgrading SMR .................................................................................................................................................................................5-3
5.3.2 Upgrading Secondary Display .....................................................................................................................................................5-4
5.3.3 Upgrading Split Unit........................................................................................................................................................................5-4
5.3.4 Upgrading Wireless Network Functions...................................................................................................................................5-4
5.3.5 Upgrading Handle Assembly .......................................................................................................................................................5-4
5.3.6 Upgrading Main Unit Battery .......................................................................................................................................................5-4
5.3.7 Upgrading iView System Functions...........................................................................................................................................5-4
6 Software Upgrade ............................................................................................................................................................. 6-1
6.1 Tool Software Installation Method ...........................................................................................................................................................6-1
6.2 PC and Monitor Connection Method......................................................................................................................................................6-2
6.3 How to enter the upgrade mode:.............................................................................................................................................................6-2
6.4 Software Tool Upgrade Operations..........................................................................................................................................................6-2
6.5 Guide to Software Upgrade Operations.................................................................................................................................................6-4
6.5.1 System Software Upgrading Method........................................................................................................................................6-4
6.5.2 Upgrading Module Rack Software .............................................................................................................................................6-4
6.6 Upgrading Secondary Display Software................................................................................................................................................6-5
6.7 Upgrading Module Software......................................................................................................................................................................6-6
6.8 Guide to Upgrade through a USB Disk ...................................................................................................................................................6-6
6.8.1 Directory Structure Preparation for Upgrade through a USB Disk................................................................................. 6-6
6.8.2 Inserting the USB Disk into the USB port of the Monitor...................................................................................................6-7
6.8.3 Entering Upgrade through the USB Disk .................................................................................................................................6-7
6.8.4 Selecting the File for Upgrade through the USB Disk .........................................................................................................6-7
6.8.5 Upgrade Completed through the USB Disk............................................................................................................................6-8
6.9 Upgrading CAA license function ..............................................................................................................................................................6-9
7 Troubleshooting................................................................................................................................................................ 7-1
7.1 Blank Screen upon Startup .........................................................................................................................................................................7-1
7.1.1 Software Version Check..................................................................................................................................................................7-2
7.2 Technical Alarm Check..................................................................................................................................................................................7-2
7.3 Troubleshooting Guide.................................................................................................................................................................................7-5
7.3.1 Power On/Off Failures .....................................................................................................................................................................7-5
7.3.2 Display Failures..................................................................................................................................................................................7-6

4
7.3.3 Module Rack Failures.......................................................................................................................................................................7-7
7.3.4 Alarm Failures.....................................................................................................................................................................................7-8
7.3.5 Output Interface Failures...............................................................................................................................................................7-9
7.3.6 Power Supply Failures .....................................................................................................................................................................7-9
7.3.7 Network Related Problems .........................................................................................................................................................7-10
7.3.8 Software Upgrade Problems ......................................................................................................................................................7-11
7.3.9 Technical Alarm Messages...........................................................................................................................................................7-11
8 Parts ................................................................................................................................................................................... 8-1
8.1 Main Unit ...........................................................................................................................................................................................................8-1
8.1.1 Exploded View....................................................................................................................................................................................8-1
8.1.2 Parts List ...............................................................................................................................................................................................8-1
8.2 D22/D19 Display Assembly (Capacitive Screen).................................................................................................................................8-2
8.2.1 Exploded View....................................................................................................................................................................................8-2
8.2.2 Parts List ...............................................................................................................................................................................................8-3
8.3 D22/D19 Display Assembly (Resistive Screen)..................................................................................................................................... 8-4
8.3.1 Exploded View....................................................................................................................................................................................8-4
8.3.2 Parts List ...............................................................................................................................................................................................8-4
8.4 Display Cover Assembly ...............................................................................................................................................................................8-6
8.4.1 Exploded View....................................................................................................................................................................................8-6
8.4.2 Parts List ...............................................................................................................................................................................................8-6
8.5 Module Rack.....................................................................................................................................................................................................8-7
8.5.1 Exploded View....................................................................................................................................................................................8-7
8.5.2 Parts List ...............................................................................................................................................................................................8-7
8.6 iVIEW Module(Win7/win10 system) ........................................................................................................................................................8-8
8.6.1 Exploded View....................................................................................................................................................................................8-8
8.6.2 Parts List ...............................................................................................................................................................................................8-8
8.7 Main Unit Separated Installation Auxiliary Accessories....................................................................................................................8-9
8.7.1 Exploded View....................................................................................................................................................................................8-9
8.7.2 Parts List ...............................................................................................................................................................................................8-9
8.8 MPM module (M51A) ..................................................................................................................................................................................8-10
8.8.1 Exploded View..................................................................................................................................................................................8-10
8.8.2 Parts List .............................................................................................................................................................................................8-10
8.9 M51C Module (Platinum)...........................................................................................................................................................................8-11
8.9.1 Exploded View..................................................................................................................................................................................8-11
8.9.2 Parts List .............................................................................................................................................................................................8-11
8.10 Others.............................................................................................................................................................................................................8-13
9 Disassembly and Repair ................................................................................................................................................... 9-1
9.1 Tools.....................................................................................................................................................................................................................9-1
9.2 Preparations for Disassembly.....................................................................................................................................................................9-1
9.3 Whole Unit Disassembly ..............................................................................................................................................................................9-1
9.3.1 Disassembling Display and Main Unit (Main Unit and Display Integrated Installation)......................................... 9-2
9.3.2 Removing Handle/Encoder (Optional Encoder)....................................................................................................................9-3

5
9.3.3 Removing Handle Cover ................................................................................................................................................................9-4
9.3.4 Removing Main Unit Housing/Main Unit Interface Adapter Board (Main Unit and Display
Separated Installation) ..............................................................................................................................................................................9-4
9.3.5 Removing Display Interface Adapter Board (Main Unit and Display Separated Installation)............................... 9-5
9.4 Disassembling Display (Resistive Touchscreen) .................................................................................................................................. 9-6
9.4.1 Removing Display Rear Housing Assembly (D19) ................................................................................................................ 9-7
9.4.2 Removing Display Rear Housing Assembly (D22..................................................................................................................9-7
9.4.3 Removing Switch Keypad Board.................................................................................................................................................9-8
9.4.4 Removing Display Interface Board/Touchscreen Panel...................................................................................................... 9-8
9.4.5 Removing USB Board ......................................................................................................................................................................9-9
9.4.6 Removing Display Screen............................................................................................................................................................9-10
9.4.7 Removing LED Board/Indicator Board....................................................................................................................................9-11
9.5 Disassembling Display (Capacitive Touchscreen) .............................................................................................................................9-11
9.5.1 Removing Display Rear Housing Assembly (D19) ..............................................................................................................9-12
9.5.2 Removing Display Rear Housing Assembly (D22) ..............................................................................................................9-12
9.5.3 Removing Switch Keypad Board...............................................................................................................................................9-13
9.5.4 Removing Display Interface Board/Touchscreen Panel....................................................................................................9-13
9.5.5 Removing USB Board ....................................................................................................................................................................9-14
9.5.6 Removing LED Board/Indicator Board....................................................................................................................................9-15
9.6 Disassembling Main Unit...........................................................................................................................................................................9-15
9.6.1 Removing iView Assembly (iView Assembly Optional) ....................................................................................................9-15
9.6.2 Removing iView Assembly Support Board/USB Interface Board (iView Assembly Optional) ............................9-16
9.6.3 Removing Battery...........................................................................................................................................................................9-16
9.6.4 Removing ACDC Power Board ...................................................................................................................................................9-17
9.6.5 Removing DCDC Power Management Board.......................................................................................................................9-18
9.6.6 Removing Antenna Module and Antenna Cable................................................................................................................9-18
9.6.7 Removing SSD Hard Disk.............................................................................................................................................................9-19
9.6.8 Removing Main Control Board ..................................................................................................................................................9-19
9.6.9 Removing Battery Backplane .....................................................................................................................................................9-20
9.7 Disassembling the Module Rack.............................................................................................................................................................9-20
9.7.1 Disasembling the Handle and Hooks......................................................................................................................................9-20
9.7.2 Disassembling the Rear Case of Module Rack .....................................................................................................................9-21
9.7.3 Disassembling the Module Rack Interface Board...............................................................................................................9-22
9.7.4 Disassembling the Infrared Backplane of Module Rack ...................................................................................................9-22
9.8 Disassembling the M51C Module...........................................................................................................................................................9-23
9.8.1 Disassembling the Front Panel Assembly..............................................................................................................................9-23
9.8.2 Disassembling the Parameter Board .......................................................................................................................................9-24
9.8.3 Disassembling the SpO2board..................................................................................................................................................9-24
9.8.4 Disassembling the Infrared Board ............................................................................................................................................9-24
9.8.5 Removing the Pump and Valve .................................................................................................................................................9-25
A Electrical Safety Inspection..............................................................................................................................................A-1
A.1 Power Cord Plug .............................................................................................................................................................................................A-1
A.1.1 The Power Plug .................................................................................................................................................................................A-1

6
A.2 Device Enclosure and Accessories ...........................................................................................................................................................A-2
A.2.1 Visual Inspection...............................................................................................................................................................................A-2
A.2.2 Contextual Inspection ....................................................................................................................................................................A-2
A.3 Device Labeling ..............................................................................................................................................................................................A-2
A.4 Protective Earth Resistance ........................................................................................................................................................................A-2
A.5 Earth Leakage Test .........................................................................................................................................................................................A-4
A.6 Patient Leakage Current ..............................................................................................................................................................................A-6
A.7 Mains on Applied Part Leakage ................................................................................................................................................................A-8
A.8 Patient Auxiliary Current ..........................................................................................................................................................................A-10
A.9 Scheduled Electrical Safety Inspection ...............................................................................................................................................A-11
A.10 Electrical Safety Inspection after Repair...........................................................................................................................................A-14

1-1
1Safety
1.1 Safety Information
DANGER
Indicates an imminent hazard that, if not avoided, will result in death or serious injury.
WARNING
Indicates a potential hazard or unsafe practice that, if not avoided, could result in death or
serious injury.
CAUTION
Indicates a potential hazard or unsafe practice that, if not avoided, could result in minor
personal injury or product/property damage.
NOTE
Provides application tips or other useful information to ensure that you get the most from
your product.
1.1.1 Dangers
There are no dangers that refer to the product in general. Specific “Danger” statements may be given in
the respective sections of this manual.

1-2
1.1.2 Warnings
WARNING
All installation operations, expansions, changes, modifications and repairs of this product are
conducted by Mindray authorized personnel.
There is high voltage inside the equipment. Never disassemble the equipment before it is
disconnected from the AC power source.
When you disassemble/reassemble a parameter module, a patient leakage current test must
be performed before it is used again for monitoring.
The equipment must be connected to a properly installed power outlet with protective earth
contacts only. If the installation does not provide for a protective earth conductor, disconnect
it from the power line and operate it on battery power, if possible.
Dispose of the package material, observing the applicable waste control regulations and
keeping it out of children’s reach.
1.1.3 Cautions
CAUTION
Make sure that no electromagnetic radiation interferes with the performance of the
equipment when preparing to carry out performance tests. Mobile phone, X-ray equipment
or MRI devices are a possible source of interference as they may emit higher levels of
electromagnetic radiation.
Before connecting the equipment to the power line, check that the voltage and frequency
ratings of the power line are the same as those indicated on the equipment’s label or in this
manual.
Protect the equipment from damage caused by drop, impact, strong vibration or other
mechanical force during servicing.

1-3
1.1.4 Notes
NOTE
Refer to Operation Manual for detailed operation and other information.
1.2 Equipment Symbols
See the N series Operator’s Manual for information about the symbols used on this product and its
packaging.

1-4
FOR YOUR NOTES

2-1
2Operation Theory
2.1 Overview
TheN22/N19 patient monitor provides rich functionality to monitor patient’s vital signs including ECG,
Resp, SpO2, Temp, NIBP, IBP, CO2, AG, O2, RM, C.O., CCO, ICG, SvO2/ScvO2, BIS, EEG, NMT, tcGas and rSO2.
Based on these parameters, the monitor supports alarm management, data review, recording and
printing of patient reports, and calculation. TheN22/N19 patient monitor is applicable to various
departments in a hospital, in particular, to the applications in intensive care, first aid, operation room and
the relevant departments.
The N22/N19patient monitor provides clinical decision-making tools to assist the medical personnel in
making diagnosis and clinical judgment faster and more accurately. Information access to clinical
information system can meet the information requirements of doctors and nurses so as to shorten the
time of obtaining information and analyze the clinical experience. These features could better meet the
application requirements of high-end users.
2.2 Product System Architecture
N22/N19 monitor mainly consists of three parts: main unit, display and module rack. All-in-one installation
or split-type installation could be adopted for the main unit and the display.

2-2
ACDC
Power manage Board& interface board Bay Trail Main
Board
Front Interface Board
For Integrate Type
Battery Interface
Board
WiFi
Module
Battery
LCD
Resistive
Touch
Panel
Speaker
Alarm
&logo LED
Board
Resistive
Touch Panel
Controller
Board
W1
W4
Backlight
LVDS
Remote
Receiver
(Reserved)
Touchpad&
knob&USB
Indicator
LED
Power
Button
W3
W5
W2
DP USB NET
UART2 STATUS
UART1
W6
W8
SMR SMR SMR
W7
The main PCBAs of the system include:
Main unit: DCDC and interface board, ACDC board, and main board and interface board.
Display: display interface board
Module rack: Module rack interface board, and 8-slot module rack communication board.

2-3
2.2.1 Functions of the Main Control Module
The main board is supported by the Bay Trail platform and uses Intel’s Bay Trail-I E38xx series processors.
Architecture of the Main Board
As the core control unit of the system, the main board is responsible for such core functions of the system
as display, data processing and data storage.
The main board also provides high-speed interfaces, such as USB connector, DP interface and network
connector.

2-4
2.2.2 AC-DC Module
The ACDC module converts the input voltage of 100~240V 50/60Hz AC into the output of 16V 10A DC.
2.2.3 Functions and Socket Definitions of the DCDC Board
2.2.3.1 Functions of the DCDC Board
On the one hand, the DCDC board is responsible for the conversion of the data signal of the main board
into the external interface; on the other hand, the DCDC board is responsible for generating the DCDC
power supply of the hardware system and for implementing the power management function. The major
functions include:
Generation and management of 12V, 5V, 3.3V, Vbus and 3.3VB power supply required for the system
operation;
Extension of connectors such as SMR;
Monitor startup and shutdown;
Battery management;
2.2.3.2 Definitions of the DCDC Board Socket
The DCDC board is the core for connecting other PCBAs inside the main unit, and the main sockets
include:
16V DC input power socket used for connecting to the ACDC board
Connector Type B6PH-VS
Pin No. Signal Name Signal Direction Function Definition Remarks
1 16V IN DC input /
2 16V IN DC input /
3 16V IN DC input /
4 GND / Ground /
5 GND / Ground /
6 GND / Ground /
Power connector of the battery interface board
Used for connecting the charging and discharging power of the battery interface board.
Connector Type B4PS-VH
Pin No. Signal Name Signal Direction Function Definition Remarks
1 GND / Ground /
2 BAT BI Battery power /
3 BAT BI Battery power /
4 GND / Ground /

2-5
Signal connector of the battery interface board
Used for connecting the battery availability signal and SMB signal of the battery interface board.
Connector Type B3B-PH-K-S
Pin No. Signal Name Signal Direction Function Definition Remarks
1 BAT_BC IN Battery availability signal /
2 SMB_D BI SMBus data signal /
3 SMB_C OUT SMBus clock signal /
Power connector of the main board
Used for connecting the main board to provide 3.3V, 5V and 16V DC power to the main board.
Connector Type 43045-0800
Pin No. Signal Name Signal Direction Function Definition Remarks
1 3.3V OUT DC output /
2 5V OUT DC output /
3 5V OUT DC output /
4 16V OUT DC output /
5 GND / Ground /
6 GND / Ground /
7 GND / Ground /
8 GND / Ground /
Signal connector of the main board
Used for connecting the main board, including SPI, USB, UART, reset, power indicator and management
signals.
Connector Type 5015714007
Pin No. Signal Name Signal Direction Function Definition Remarks
1 GND / Ground /
2 GND / Ground /
3 USB_DP BI USB D+ /
4 SPI_LVDS_CLKP IN SPI differential clock Reserved
5 USB_DM BI USB D- /
6 SPI_LVDS_CLKP IN SPI differential clock Reserved
7 GND / Ground /
8 GND / Ground /
9 USB_Hub_RST# IN USB Hub reset /
10 SPI_CLK IN SPI clock /
11 FPGA_RST# IN FPGA reset /
12 GND / Ground /

2-6
Connector Type 5015714007
Pin No. Signal Name Signal Direction Function Definition Remarks
13 NC / No signal connection /
14 SPI_MOSI IN Primary output of SPI /
15 NC / No signal connection /
16 GND / Ground /
17 NC / No signal connection /
18 SPI_MISO OUT Secondary output of SPI /
19 NC / No signal connection /
20 GND / Ground /
21 GND / Ground /
22 SPI_CS# IN SPI chip select /
23 EC_S3# IN S3 power status /
24 SPI_CTL1 IN GPI /
25 EC_S4# IN S4 power Status /
26 SPI_CTL2 OUT GPO /
27 PLTRST#_Report IN CPU reset status /
28 EC_RST#_Report IN EC reset status /
29 AC_BC OUT AC availability /
30 GND / Ground /
31 Battery_Yellow OUT Battery driven by yellow
LED /
32 M0_TXD OUT M0 UART sending /
33 Battery_Green OUT Battery driven by green
LED /
34 M0_RXD IN M0 UART receiving /
35 PWROK OUT Power supply status /
36 NC / No signal connection /
37 PWR_BTN# OUT Main control startup and
shutdown /
38 NC / No signal connection /
39 GND / Ground /
40 GND / Ground /
DC power output connector of the main unit
Used by the main unit for providing 12V power supply to the display.
Connector Type 43045-0409
Pin No. Signal Name Signal Direction Function Definition Remarks
1 12V OUT DC output /
2 12V OUT DC output Reserved
3 GND / Ground Reserved
4 GND / Ground /
