BENQ-SIEMENS CF61 User manual

Technical Documentation 08/2006
Service Manual
Level 1-2
for
CF61
Release Date Department Notes to change
R 1.0 12.07.2006 BenQ Mobile CC S CES New document
TD_Repair_L1-L2_CF61_R1.0.pdf Page 1 of 42
Created by inservio GmbH for BenQ mobile GmbH & Co. OHG - Company Confidential2006©inservio

Technical Documentation 08/2006
Table of Content
1Key Feature................................................................................................................................3
2Spare Part Overview of CF61 ...................................................................................................4
3Disassembly of CF61 ................................................................................................................6
4Assembly of CF61 ...................................................................................................................16
5BenQ Service Equipment User Manual.................................................................................26
6Setup of the Software..............................................................................................................27
7Software basic settings ..........................................................................................................28
8Software Download procedure...............................................................................................29
9Download PPF (Handset configuration)................................................................................31
10 Backup and Restore of Wap and Network Setting...............................................................32
11 Backup and Restore of Media Center content......................................................................33
12 Unlock Tool..............................................................................................................................34
14 International Mobile Equipment Identity, IMEI......................................................................36
15 General Testing Information...................................................................................................37
TD_Repair_L1-L2_CF61_R1.0.pdf Page 2 of 42
Created by inservio GmbH for BenQ mobile GmbH & Co. OHG - Company Confidential2006©inservio

Technical Documentation 08/2006
1 Key Feature
System •Tri-Band GSM 900/1800/1900
Battery •Li-Ion 750 mAh
Stand – by Time •Up to 225h
Talking Time •Up to 3 h
Antenna •Integrated
Main Display •262, 144 TFT, 128x160 pixels, 1.8 inches
Sub - Display •4,096 CSTN, 96x64 pixels
Storage •1.5 MB
Camera •1.3 megapixel, 4x linear digital zoom
Connectivity •USB 1.1, Bluetooth: Object Push Profile, Object
Exchange, Handsfree Profile, Headset Profile
Memory Slot •MicroSD
Processor •TI
TD_Repair_L1-L2_CF61_R1.0.pdf Page 3 of 42
Created by inservio GmbH for BenQ mobile GmbH & Co. OHG - Company Confidential2006©inservio

Technical Documentation 08/2006
2 Spare Part Overview of CF61
Exploded View
TD_Repair_L1-L2_CF61_R1.0.pdf Page 4 of 42
Created by inservio GmbH for BenQ mobile GmbH & Co. OHG - Company Confidential2006©inservio

Technical Documentation 08/2006
Order Number ( can be different by Variant specific parts)
Location E-commerce number:
BATTERY V30145-K1310-X457
MIC L50654-Z6-C146
VIBRATOR
METAL DOME MAIN KEY L50658-A220-A18-1
CVR BATTERY L50658-A220-A19-1
MAIN KEY L50658-A220-A2-1
RUBBER CAP I/O L50658-A220-A23-1
Flip PCB L50658-A220-A33-1
MAIN PCB S30880-Q3180-A1
KEYPAD PCB S30880-Q3183-A1
LCM L50658-A220-A24-1
DSC Module
Assy. CASE1 L50658-A220-A26-1
Assy. CASE2+3 L50658-A220-A27-1
Assy. CASE4 L50658-A220-A28-1
LENS SUB PMMA L50658-A220-A29-1
CVR ANT L50658-A220-A31-1
TD_Repair_L1-L2_CF61_R1.0.pdf Page 5 of 42
Created by inservio GmbH for BenQ mobile GmbH & Co. OHG - Company Confidential2006©inservio

Technical Documentation 08/2006
3 Disassembly of CF61
All repairs as well as disassembling and assembling have to be carried out in an ESD
protected environment and with ESD protected equipment/tools. For all activities the
international ESD regulations have to be considered.
For more details please check information in c – market
https://market.benqmobile.com/SO/welcome.lookup.asp
There you can find the document “ESD Guideline”.
Step 1
Remove Battery Cover.
Step 2
Remove Battery.
TD_Repair_L1-L2_CF61_R1.0.pdf Page 6 of 42
Created by inservio GmbH for BenQ mobile GmbH & Co. OHG - Company Confidential2006©inservio

Technical Documentation 08/2006
Step 3
Remove Rear Cover by using the
Alternative Opening Tool carefully.
Step 4
Remove screws by using the Torque
– Screwdriver.
T5+.
Step 5
Remove Lower Base Case Shell by
using the Alternative Opening Tool.
TD_Repair_L1-L2_CF61_R1.0.pdf Page 7 of 42
Created by inservio GmbH for BenQ mobile GmbH & Co. OHG - Company Confidential2006©inservio

Technical Documentation 08/2006
Step 6
Remove MMI Slot Cap.
Step 7
Step 8
Disconnect the Flex Cable by using
Tweezers.
TD_Repair_L1-L2_CF61_R1.0.pdf Page 8 of 42
Created by inservio GmbH for BenQ mobile GmbH & Co. OHG - Company Confidential2006©inservio

Technical Documentation 08/2006
Step 9
Remove the RF Control Board by
using the Alternative Opening Tool
carefully.
Step 10
Remove the Vibra-Alert by using
Tweezers.
Step 11
Remove the Microphone by using
Tweezers. Take care of the spring
contact.
TD_Repair_L1-L2_CF61_R1.0.pdf Page 9 of 42
Created by inservio GmbH for BenQ mobile GmbH & Co. OHG - Company Confidential2006©inservio

Technical Documentation 08/2006
Step 12
Remove the Side Key PCB.
Step 13
Remove the Side Key Left.
Step 14
Remove the Keypad PCB.
TD_Repair_L1-L2_CF61_R1.0.pdf Page 10 of 42
Created by inservio GmbH for BenQ mobile GmbH & Co. OHG - Company Confidential2006©inservio

Technical Documentation 08/2006
Step 15
Remove the Keypad by using the
Alternative Opening Tool.
Step 16
Remove Lower Lift Case Cap by
using the Alternative Opening Tool
carefully.
Step 17
Remove Screws by using the Torque
– Screwdriver. T5+.
TD_Repair_L1-L2_CF61_R1.0.pdf Page 11 of 42
Created by inservio GmbH for BenQ mobile GmbH & Co. OHG - Company Confidential2006©inservio

Technical Documentation 08/2006
Step 18
Remove Upper Lift Case Shell by
using the Alternative Opening Tool
carefully.
Step 19
It is mandatory to place a Protection
Foil onto the Display to avoid
scratches.
Step 20
Disconnect the Flex Cable.
TD_Repair_L1-L2_CF61_R1.0.pdf Page 12 of 42
Created by inservio GmbH for BenQ mobile GmbH & Co. OHG - Company Confidential2006©inservio

Technical Documentation 08/2006
Step 21
Step 22
It is mandatory to place a Protection
Foil onto the Display to avoid
scratches.
Step 23
Remove the Camera Module by
disconnecting it from the socket.
TD_Repair_L1-L2_CF61_R1.0.pdf Page 13 of 42
Created by inservio GmbH for BenQ mobile GmbH & Co. OHG - Company Confidential2006©inservio

Technical Documentation 08/2006
Step 24
Remove the Earpiece.
Step 25
Use the Hinge Tool very carefully to
remove the Upper Base Case Shell
from the Lower Lift Case Shell.
Step 26
TD_Repair_L1-L2_CF61_R1.0.pdf Page 14 of 42
Created by inservio GmbH for BenQ mobile GmbH & Co. OHG - Company Confidential2006©inservio

Technical Documentation 08/2006
Step 27
Take care of the Flex Cable, it easily
rips.
Step 28
Remove the Flex Cable carefully.
Step 29
Remove the Hinge by using the
Hinge Tool.
TD_Repair_L1-L2_CF61_R1.0.pdf Page 15 of 42
Created by inservio GmbH for BenQ mobile GmbH & Co. OHG - Company Confidential2006©inservio

Technical Documentation 08/2006
Step 30
Remove the Ringer by using
Tweezers carefully.
4 Assembly of CF61
Step 1
Assemble the Ringer.
Step 2
Assemble the Hinge.
TD_Repair_L1-L2_CF61_R1.0.pdf Page 16 of 42
Created by inservio GmbH for BenQ mobile GmbH & Co. OHG - Company Confidential2006©inservio

Technical Documentation 08/2006
Step 3
Assemble the Flex Cable. Take care
of it!
Step 4
Insert the Flex Cable into the Lower
Lift Case Shell.
Step 5
Assemble the Lower Lift Case Shell
and the Upper Base Case Shell by
using the Hinge Tool.
TD_Repair_L1-L2_CF61_R1.0.pdf Page 17 of 42
Created by inservio GmbH for BenQ mobile GmbH & Co. OHG - Company Confidential2006©inservio

Technical Documentation 08/2006
Step 6
Assemble the Earpiece by using the
Tweezers.
Step 7
Assemble the Camera Module by
connecting it with the socket.
Step 8
Remove Display Foil.
TD_Repair_L1-L2_CF61_R1.0.pdf Page 18 of 42
Created by inservio GmbH for BenQ mobile GmbH & Co. OHG - Company Confidential2006©inservio

Technical Documentation 08/2006
Step 9
Assemble the Display Module.
Step 10
Connect the Flex Cable with the
socket.
Step 11
Remove Display Foil.
TD_Repair_L1-L2_CF61_R1.0.pdf Page 19 of 42
Created by inservio GmbH for BenQ mobile GmbH & Co. OHG - Company Confidential2006©inservio

Technical Documentation 08/2006
Step 12
Assemble Upper Lift Case and Lower
Lift Case.
Step 13
Place screws by using the Torque –
Screwdriver T5+.
Step 14
Assemble the Lower Lift Case Cap.
