BenQ 4012EU User manual

User’s Guide
Copyright
Copyright © 2001 by thiscompany. Allrightsreserved. No part of thispublication
may be reproduced, transmitted, transcribed, stored in a retrieval system or
translated into any language or computer language, in any form or by any means,
electronic,mechanical, magnetic,optical, chemical, manual or otherwise, without
the prior written permission of this company.
Disclaimer
This company makes no representations or warranties, either expressed or implied,
with respect to the contents hereof and specifically disclaims any warranties,
merchantability or fitness for any particular purpose. Further, this company
reserves the right to revisethis publication and to make changes from time to time
in the contents hereof without obligation of this company to notify any person of
such revision or changes.
Canadian Department of Communications
RegulatoryStatement
This digital apparatus does not exceed Class B limits for radio noise emissions
from digital apparatus set out in the Radio Interference Regulations of the Canadian
Department of Communications.
Le présent appareil numérique n'émet pas de bruits radio-électriques dépassant les
limites applicables auxappareils numériques de la classe B prescrites dans le
Réglement sur le brouillage radioélectrique édictépar le ministère des
Communications du Canada.
FCC Class B Radio Frequency
Interference Statement
Note:
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates,uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
1. Reorient or relocate the receiving antenna.

User’s Guide
2. Increase the separation between the equipment and receiver.
3. Connectthe equipment into an outlet on a circuit different from that to which the
receiver is connected.
4. Consult the dealer or an experienced radio/television technician for help.
Notice 1:
The changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Notice 2:
Shielded interface cables must be used in order to comply with the emission limits.
Notice 3:
This product complies with the requirements set out in the Council Directive on the
Approximation of the Laws of the Member States relating Electromagnetic
Compatibility (89/336/EEC). For the evaluation regarding the electromagnetic
compatibility, the following standards were applied:
EN50082-1, IEC 801-2, IEC 801-3, IEC 801-4
EN50081-1, EN55022
D.N.S.FI. RegulatoryStatement
Class 1 laser product
(EN 60825: 1991)
or
Luokan 1 laserlaite
Klass 1 laser apparat
(EN 60825: 1991)
Additional remarks:
VAROITUS - Laitteen käyttäminen muulla kuin tässäkäyttöohjeessa mainitulla
tavalla saattaa altistaa käyttäjän turyallisuusluokan 1 ylittävälle näkymättömälle
lasersäteilylle.
Varning - Om apparaten används päannat sätt än i denna bruksanvisning
specificerats, kan användaren utsättas för osynlig lasersträlning, som överskrider
gränsen för laserkläss 1.
According to EN 60825 sub-clause 6, regarding actions to be taken against
dangerous radiation including copies of all warning labels and information about the
laser components and radiation data such as wavelength, output power and pulse
times.

User’s Guide
Safetyinstructions
1. Followall warnings and instructions marked on the product.
2. DANGER: Invisible laser radiation when open. Avoid direct exposure to beam.
3. Unplug this productfrom the wall outlet before cleaning. Do not use liquid
cleaners or aerosol cleaners. Use a damp cloth for cleaning.
4. Openings in the front panel and the back or bottom are provided for ventilation.
To protectit from overheating, these openings must not be blocked or covered.
This productshould never be placed near or over a radiator or heat register, or
in a built-in installation unless proper ventilation is provided.
5. Asuitable power adapter must be obtained through the authorized dealer
or franchisee.
6. Never push objects of any kind into this product through cabinet slots as they
may touch dangerous voltage points or short cut parts that could result in a fire
or electric shock. Never spill liquid of any kind on the product.

User’s Manual
E
-1
Table of Contents
NOTICE ABOUT USING AN EXTERNAL USB CD-REWRITER .........................................2
MATAIN THE DEVICE PERFORMANCE ........................................................................2
PREVENT FROM THE “BUFFER UNDERRUN”ERROR....................................................2
RECOMMENDED SYSTEM CONFIGURATIONS...............................................................3
PRODUCT DESCRIPTION...........................................................................................4
FRONT VIEW...........................................................................................................4
REAR VIEW.............................................................................................................5
LEFT VIEW..............................................................................................................5
INSTALLATION.........................................................................................................6
HARDWARE INSTALLATION .......................................................................................6
CD WRITING SOFTWARE INSTALLATION.....................................................................8
OPERATION INSTRUCTIONS ......................................................................................9
LOAD A CD DISC .....................................................................................................9
REMOVING A CD DISC .............................................................................................9
MAINTENANCE.........................................................................................................9
EMERGENCY EJECT.................................................................................................9
FREQUENTLY ASKED QUESTION (FAQ).....................................................................10
TECHNICAL SUPPORTS ............................................................................................14
HOW TO FIND THIS INFORMATION..............................................................................14
MS-DOS, Windows 95, Windows 98, and Windows NT are registered trademarks of Microsoft Corporation. Pentium is
a registered trademark of Intel Corporation. Names of products mentioned herein are used for identification purposes
only and may be trademarks and/or registered trademarks of their respective company.
All specifications subject to change without notice.

User’s Manual
E
-2
Notice About Using An External USB
CD-Rewriter
Maintain The Device Performance
If you want to maintain the CD-Rewriter’s better performance, we recommend you
connecting only one of the CD-Rewriter to your computer at a time. However, there is an
extreme reduction in performance when two or more of fast USB devices (such as
CD-ROM, CD-Writer, scanners, printers and hard drive) are used simultaneously.
)
NOTE: Please make sure your computer meets the system requirements
(or system configurations) shown on the box or on the next page of this
manual.
Prevent From the “Buffer Underrun” error
What is a buffer underrun? An uninterrupted data flow to the CD-Recorder drive is
needed when using mastering software like Easy CD Creator. A buffer underrun occurs
when the PC cannot consistently send the required data flow writing to the CD-Recorder.
If a buffer underrun occurs during writing, your CD-R disc is unusable anymore. To
understand how to prevent from the buffer underrun error, please refer to “What can I do
to prevent Buffer underrun?” on page E-11.

User’s Manual
E
-3
Recommended System Configurations
The system requirements listed below are recommended for ensuring consistent writing
performance.
 Operating system: Windows98 or higher
 RAM: 32 MB or larger.
 CPU: Pentium 166 MHz or above
 Hard disc drive: Minimum 50 MB of free space for installing software. 750 MB free
HD is needed when duplicating a CD through HD (10 MB free space for each
minute of recorded music).
 An available USB (Universal Serial Bus) port.

User’s Manual
E
-4
Product Description
Front View
1. Open/Close button: Open and close for disc loading and removal.
2. Play/Skip button: Play audio CD and skip one track forward if press again.
3. Disc In indicator: Lights up when data is being read from the disc; flashes
during seek operation. Please refer to the chart below for
detailed status description.
4. Writing indicator: Lights up while data is being written to or erased from the
disc. Please refer to the chart below for detailed status
description.
5. Volume controller: Adjusts headphone volume level.
6. Headphones jack: Attach to headphones or self-amplified speakers.
7. Emergency eject hole: Inserts a straightened paper clip to manually eject the
tray.
Indicators status
INDICATORS
WRITING DISC IN STATUS DESCRIPTION
Off Off Drive ready and no disc loaded.
Off Blinking Green Power on or reading.
Off Steady Green Disc loaded and ready to be accessed.
Blinking Red Blinking Green Test before writing.
Steady Red Blinking Green Writing.

User’s Manual
E
-5
Rear View
1. Power switch: turns the CD-Rewriter on and off.
2. USB interface connector: connects the CD-RW drive to the USB cable.
3. Power supply connector
Left View
1. Power led: indicates the power supply status

User’s Manual
E
-6
Installation
Hardware Installation
Installation procedure
1. Turn on your computer and enter the Windows 98SE/ 2000/ ME operating system.
2. Connect the AC transformer to the CD-Rewriter and the power outlet.
3. Turn on the power. And the power indicator should be on at this time.
4. Connect the CD-Rewriter to the PC’s USB slot with a USB cable.
P
ower outlet
P
ower indicator
Off On
Step 1
S
tep 2

User’s Manual
E
-7
5. Once you finish the above steps, the system will automatically detect the presence
of the CD-Rewriter. Please finish the driver’s installation according to the
computer’s instruction (the driver software is on the attached 1.44MB disk). After
rebooting, the computer system will automatically recognize the CD-Rewriter.
(Additional software programs, provided with the product, can be installed. For
additional information on installing and using software and hardware, please refer to
the product’s Instruction Manual as well as the User Manual enclosed in the
CD-ROM.)
Note

If the “New hardware help”box does not show up after the
CD-Rewriter is connected to the computer, it is possible that
the USB slot is not in order. Please reboot your computer and
enter the main board’s BIOS (Basic Input and Output System)
to check whether the USB is disabled or not. If the USB is
disabled, change the setting to enabled.
Note

Once you complete the installation of the USB driver, the
computer will recognize the CD-Rewriter every time you
connect the USB cable to it. User can start operating directly.
6. By using the vertical stand, you can place the CD-Rewriter in various ways to make
the most use of your space.
7. After finishing all the steps above, please de-install the product in the reverse order
of step 3 to 1.

User’s Manual
E
-8
CD writing software installation
Before you start…
Please understand that CD recording is a non-interruptible process. Therefore, a stable
recording environment is a must. It is the best condition, if you have a HDD only for CD
recording purpose. That is, in this HDD, only Windows 98SE or higher and the necessary
software are installed, nothing else. Then the recording process will be smooth. However
if an extra HDD is not available, you might need to carry out the following steps to
optimize your Windows CD recording process.
1. Close all resident programs including Anti-Virus, Screen Saver, System Agent,
Power Management, etc. Turn off Auto Insert Notification. Further, maximizing and
minimizing windows are not recommended either. If not, any operation of these
applications will intrude the CD recording process and damage your disk.
2. Defragment your HDD before any CD recording. This is particularly important when
you write files to CD from HDD. Defragmentation of HDD reallocates all the files so
that these relevant files are placed in the nearby clusters. This saves time and risks
when Easy CD Creator is trying to search for the files you want to record on CD.
3. It is not advisable that you have too many devices internally connected to the
system. Heavy load carried by the system power supply may result in unstable
power delivery to each of the internal devices thus causes system unsteadiness.
Installing CD writing software
1. Load the software CD in CD-ROM or your CD-ReWriter.
2. Follow the instructions shown on screen and proceed to installation.
3. Some program may require your system to be rebooted after installation. Follow the
program's request to reboot your PC accordingly.

User’s Manual
E
-9
Operation Instructions
Load a CD disc
 Press the eject button on the CD-ReWriter front panel and the tray will eject
automatically.
 Put the CD disc in the tray with the labeled side up.
 Press the eject button or slightly push on the front of the tray to close the tray.
When a CD disc is loaded, you should be able to read files properly on the disc
within a program.
Removing a CD disc
 Press the eject button on the CD-ReWriter front panel.
 Remove CD disc from the tray.
 Press the eject button or slightly push on the front of the tray to close the tray.
Maintenance
Typically, the CD-ReWriter needs no maintenance or cleaning. Most problems will be
prevented if you keep CD discs clean. Use lens-cleaning cloth to slightly wipe away dusts
on disc surface and avoid scratching it.
Emergency Eject
If the tray does not eject automatically, you may manually pull out the tray. Follow these
steps:
♦ Switch off the power.
♦ Insert a straightened paper clip into the emergency hole (please refer to the
illustration in Front View). The tray will be partially ejected.
♦ Gently pull out the tray.

User’s Manual
E
-10
Frequently Asked Question (FAQ)
The following FAQ’s are the most common problems you may find during installation or
regular use. Please review these FAQ’s to have your problem solved. In case you do not
find any items that answer your problem, please contact your dealer or technical support.
Q: The CD-ReWriter doesn’t show up in My Computer or Explorer.
The following steps will assist you to get your drive to work as a CD-ROM:
 If you cannot find CD-ReWriter in Explorer, restart your computer, or shut it down
and then turn it on again.
 Make sure the computer is plugged in and that each device has power. To check if
the CD-ReWriter receives power properly, you can check the power indicator or test
it by pressing eject button to see if the tray opens and closes.
 Disconnect and then reconnect the CD-Rewriter’s power cable. This might fix a
faulty connection.
 Disconnect and then reconnect the USB cable.
Q: Not sure which drive letter was assigned to the CD-ReWriter.
The CD-ReWriter will have an icon, just like a CD-ROM drive. You can easily see which
icon is CD-ReWriter by double-clicking “My Computer”icon, then right-click CD drive’s
icon, and selecting Eject. The tray of selected drive will open.
Q: The CD-ReWriter has problem in reading CD disc.
There are several ways to solve this problem as follows:
 The CD disc in the tray may be loaded upside-down, or a little off-center. Try
re-loading the CD disc with its label side up.
 After loading a CD disc, it will take a moment to let the CD-ReWriter read the disc
information. When the indicator on the front panel stops flashing and stays green, it
is ready for access.
 If the disc you just loaded is a blank CD disc, try it later after copying some
information to the CD.
Q: Error message when double-clicking on the CD-ReWriter icon.
 If there is no CD in the CD-ReWriter, load a CD disc and try again.
 After loading a CD disc, you need to wait for a short moment to let the CD-ReWriter
read the disc information and ready for further access. The CD-ReWriter is ready
when the light stops flashing and stays green.
 The CD disc in the tray may be loaded upside-down, or a little off-center. Try
re-loading the CD disc with its label side up.
 If the disc you just loaded is a blank CD disc, try it later after copying some
information to the CD.
Q: What are possible causes of buffer underrun
Hard Disk
 Extremely fragmented hard drive.
 Not enough space in temporary directory.
 Hard disk compression may cause buffer underruns. We do not recommend writing
from a compressed hard disk or disk partition.
 "Dumb" thermal re-calibration (only on very old hard drives).

User’s Manual
E
-11
Other Hardware
 Spin-down of CD-ROM drives you're copying data or audio from.
 Slow source devices.
 Source devices that transfer data in bursts.
 Incorrect recorder controller settings.
 Inability of the devices to sync properly.
 Overall system configuration.
 Computer is unable to allow data transfer fast enough.
 Setting hard drive’s read ahead optimization to "none" may cure buffer underruns in
some cases. (Go to the Start menu | Settings | Control Panel | System |
Performance | Advanced Settings/File System | Hard Disk and set "Read-ahead
optimization" to "None.")
Networks
Recording across the network (a network may be too slow to maintain adequate
throughput speed).
Files to Be Recorded
 Recording many small files.
 Damaged source files (data loss).
 Trying to record files in use by the system or other applications.
Other
 Copying from a CD that is scratched, dirty, or damaged.
 Recorder malfunction
Q: What can I do to prevent Buffer underrun?
You can try the following procedures to prevent buffer underrun:
♦ Use a faster hard drive and defragment your hard drive at least once a week.
♦ Do not record across a network. Copy the desired files to your local hard drive.
♦ If your source hard disk is more than five years old, make sure it does smart
thermal re-calibration.
♦ It may be necessary to write audio at slower speeds than those you can achieve for
data, since writing CD-DA audio requires streaming more bits per second to the
recorder.
♦ Record in lower speed –it takes linger time to empty the buffer when recording at
lower speed.
♦ Keep the CDs, the recorder, and your source CD-ROM drive free of dust.
♦ Close all other application programs.
♦ Disable the screen saver and anti-virus programs.
♦ PC power management makes PC slower and thus it may result in buffer underrun.
Disable the power management or delay the power saving time.
♦ Keep your CD-R/CD-RW cool. Sometimes the drive fails when they overheat.
♦ Your system must fulfill the minimum configuration of yourCD-recording Mastering
software.
♦ Do not try to copy empty directories, zero byte files, or files that may be in use by
the system at the time of recording.
♦ If your data includes more than 10,000 very small files, create a disc image first, or
record at a slower speed.
♦ The temporary directory should always have space free at least twice the size of
the largest file you are recording.
♦ Try a different brand of recordable disc.

User’s Manual
E
-12
Q: Cannot directly copy from one CD to another.
 Some CD-ROM disc will not allow direct copying to the CD-ReWriter or are not
capable of digital audio extraction.
 You need to have a supported CD-ROM drive to use as your source.
 Some CD discs may have copy protections or other features that do not allow a
CD-to-CD copy.
Q: Poor audio quality.
 Make sure the audio cable is connected completely between the sound card and
CD-ReWriter or CD-ROM.
 Make sure that you do not have any sound-muting feature turned on by way of the
monitor or software.
 Try listening to the wave files (.WAV) on your hard drive to see if they sounded poor
before you copy them to CD.
Q: Unable to see a second session reading from a CD-ROM drive.
 Eject the CD and re-load it.
 Refresh the screen. Select the My Computer icon in Windows Explorer and press
F5.
 Make sure if your CD-ROM drive reads CD-RW discs. CD-RW discs can only be
used in CD-ReWriter or newer MultiRead CD-ROM.
 For Windows 3.x users: If some other programs create the CD disc, please verify
you are using version 2.23 of the MSCDEX.EXE file. First, restart your PC and
when you see “Starting MS-DOS…” on your monitor, press F8. Each line in your
CONFIG.SYS and AUTOEXEC.BAT files will load one at a time. Press “Y”until you
see a line containing “MSCDEX.EXE”, then press “Y”and you will see the version
number displayed on monitor. The number shall be 2.23 or greater. In case you
cannot find this file, you can download it from Microsoft's FTP site:
ftp://ftp.microsoft.com/Softlib/MSFILES/MSCD223.EXE. That is a self-extracted
ZIP file. Please run it to retrieve MSCDEX.EXE file.
 See if the CD-ReWriter or other CD-ROM drives can read the CD disc properly. If
so, then the problem is probably with the CD-ROM drive. Contact the manufacturer
of the drive for updated drivers or patch files.
Q: Unable to see the CD label or all files on the CD within Windows Explorer.
Refresh the screen. Select My Computer icon in Windows Explorer and press F5.
Q: Applications cannot locate the CD in CD-ReWriter.
Some programs only locate the first logical drive letter assigned to a CD-ROM or a
CD-ReWriter drive. For example, if your CD-ROM drive is assigned to drive D and
CD-ReWriter is assigned to drive E, the program locates drive D only and will not locate
drive E. Thus you need to reassign drive letters to both your CD-ROM and CD-ReWriter
drives in case you need to run the program in CD-ReWriter.
 Windows: right-click My Computer icon. Click Properties item, open Device
Manager and double-click CD-ROM drive, then click Setting tab. Under Reserved
drive letters, select the drive letter after the existing letter (for both start and end
drive letter) and click OK. Then double-click CD-ReWriter icon, then click Setting
tab. Under Reserved drive letters, select the drive letter before current one and
click OK.

User’s Manual
E
-13
Q: Can I use hard drive compression software?
It is not recommended to use hard drive compression software when CD-ReWriter is
installed. CD-R and CD-RW writing program may check free space to estimate needed
space. However, due to the hard drive compression software’s compression ratio may
vary from time to time. The actual free space available may not be enough for disc
copying.
Q: To maintain optimal writing performance
Regularly run disc de-fragmentation and scanning programs on your hard drive (please
refer to your Windows manual for detailed information). Doing this improves the access
time to the hard drive, and thus ensures writing in higher performance.
Finally, these are only GENERAL rules and not necessary to apply to any combination of
CD-ROM drives, HDD and motherboards. A few trials on different configurations before
recording are recommended. Also, try out different CD-R media before you proceed to
make volumes duplication as you may figure out which brand of CD-R media originates
smoother recording and easier access. As long as you find the best CD recording way,
stick to it. Have a nice recording time.

User’s Manual
E
-14
Technical Supports
In case you cannot solve the problems by FAQs, contact customer support. Please have
the following information ready before you call or email us. It is also helpful to write down
any error messages you received.
Information In your computer
CD-ReWriter firmware version
Drive serial number
Computer or motherboard brand/model
CPU type and speed
RAM size
BIOS, if any
IDE –Primary/Master
IDE –Primary/Slave
IDE –Secondary/Master
IDE –Secondary/Slave
VGA card type, if any.
Sound Card
Operating System and version
How to find this information
CD-ReWriter firmware version
In Windows 98SE or higher: Right-click My Computer icon, then select Properties, click
Device Manager tab. Double-click CD-ROM item and double-click ATAPI CD-R/RW.
Select Properties and click Setting tab. Firmware version is displayed within Setting tab.
Example: Firmware revision: A.AW
CD-ReWriter serial number
Serial number is printed on a label affixed on bottom of the CD-ReWriter.
Computer or motherboard brand/model
The computer brand and model appear on the front of your computer system. Or you may
find it in the manuals come with your system. The motherboard brand and model can be
found when you remove the housing or casing, or on the packing box.
Example: XYZ TX586-3.
CPU type and speed
This information typically can be found in your computer’s manual or in boot-up screen.
Example: Pentium MMX 166, or AMD K6-200.
Operating system and RAM size
In Windows 98 or higher: Right-click My Computer icon. Then select General tab and
both operating system version and RAM size are shown there.
Example: 4.10.1998, 64.0 MB RAM.
