Berg Fmdp-47 User manual

Ice Cream Dipping Cabinet

This manual contains important information regarding your unit. Please read this manual

thoroughly prior to equipment set-up, operation and maintenance. Failure to comply with regular

maintenance guidelines outlined in this manual may void the warranty.

INSTRUCTION MANUAL

WARNINGS

• Please inspect unit for any possible shipping damage before installation.

•Hydro-Carbon R290, a ammable and explosive refrigerant, is used in this unit. The following

safety precautions must be enforced due to the use of R290 refrigerant:

• The unit should be kept far away from any heat source or open ame

• Do not use mechanical devices to defrost the unit

• Do not puncture the refrigerant tubing

• Only qualied technicians are authorized to repair the unit especially when refrigerant leakage occurs

• Dispose of unit in accordance with federal or local regulations

• Unit must be installed and placed properly by qualied technicians.

• Keep unit far away from ammable vapors and liquids.

• During maintenance and cleaning, please unplug the unit.

• Do not plug or unplug the cord with wet hands.

• It is recommended that a separate circuit, serving only your unit, be used. Use receptacles that

cannot be turned off by a switch or pull chain.

• To prevent skin from getting stuck to the cold surfaces, keep hands and other body parts dry when

touching cold surfaces in the refrigerated compartment .

• Children are strictly banned from climbing, standing or hanging on the appliance to avoid hurting

themselves or damaging the unit.

• Never clean refrigerator parts with ammable uids. These fumes can create a re hazard or explosion.

Do not store or use gasoline or other ammable vapors and liquids near this or any other appliance

as the fumes can create a re hazard or explosion.

• Do not attempt to repair or replace any part of your freezer unless it is specically recommended in this manual.

All other servicing should be done by a qualied technician.

• This unit is specically designed to merchandise ice cream or yogurt type products.

• Do not use this freezer for other than its intended purpose.

ELECTRICAL CONNECTION

• This unit must be properly grounded at all times for your safety.

• Never use an adapter plug or extension cord to power the unit.

• The wall outlet, circuit and supply voltage must be checked carefully by qualied electricians.

• Do not plug unit into outlet if the power cord is broken or frayed.

• Make sure that the unit is not resting on or against the electrical cord and plug.

• Make sure the power supply is switched off before servicing the unit.

• Wiring diagram can be referenced if needed.

•WARNING: Failure to follow these instructions can lead to personal injury or damage to the unit

TO INSTALL:

• Remove unit from box and make sure all plastic, tape and packaging materials are removed.

• Place the unit on a at, secure surface with at least 4” of open space around all sides to ensure proper air circulation

• Place the unit in a dry area to prevent the compartment body from getting rusty

• Place the unit in an area that is not in direct sunlight or any other sources of heat

TO USE:

• Make sure the unit is plugged in properly

• The unit should be running 2 to 3 hours before loading products to detect any potential electrical

failure and/or concealed shipping damage.

• Do not replace the temperature controller or change its parameters without the help of a qualied technician.

• Do not restart the unit immediately when it is disconnected or shut off. Wait several minutes before restarting.

CLEANING AND MAINTENANCE

Stainless Steel Cleaning

• Ammonia and soap can be used to polish the stainless steel surfaces and wipe off ngerprints and smears.

• Other specialized commercial detergents can be used to remove grease and oil.

• Soft cloths, towels and sponges are recommended to be used along with detergents.

• Do not use steel wool to clean stainless steel.

• Hydrochloric acid or chlorine-based products cannot be used for stainless steel cleaning

• Stainless steel surfaces should be wiped dry after cleaning.

• WARNING: Failure to follow the above instructions may result in abrasion, pitting and rusting of stainless steel surfaces

Transparent Lid Cleaning

• The lid can be removed from the unit by taking down the hinge bracket when cleaning.

• The lid can be washed with non-abrasive detergents and soapy water.

• Rough cloths should not be used for cleaning to prevent the lid surface from being scratched.

• Do not use acetone, alcohol or dry-cleaning uid to clean the plastic lid.

Can Holder Cleaning

• The plastic can holder can be removed from the unit for easy cleaning.

• The can holder can be washed with non-abrasive detergents and soapy water.

• A non-metallic brush is recommended for best results.

Condenser Cleaning

• The condenser should be cleaned at least once a month due to dirt, grease, lint and dust build up.

• The following instructions help to reduce compressor failure and minimize your maintenance expense:

1. You will need a screwdriver, adjustable wrench and stiff bristle brush when cleaning the condenser

2. Unscrew all screws with screwdriver to remove the grill covering the condenser

3. Use a stiff bristle brush to get rid of the accumulated dirt, grease, lint and dust from the condenser.

4. Clean the coils and fan blades of the condenser carefully and cautiously to avoid any damage.

5. Ensure that the condenser and other accessories are assembled correctly before reinstalling the grill.

6. Reinstall the grill and tighten all the screws.

7. Connect the unit and check that it is functioning properly.

TROUBLESHOOTING

Before requesting any service on your unit, please check the following chart. Please note that this guide

serves only as a reference for solutions to common problems

Problem Possible Cause Corrective Action

Compressor not running • Fuse blown, or circuit breaker tripped

• Power cord unplugged

• Thermostat set too high

• Unit in defrost cycle

• Replace fuse or reset circuit breaker

• Plug in power cord

• Set thermostat to lower temperature

• Wait for defrost cycle to nish

Condensing unit runs for

long period of time

• Excessive amount of warm product

placed in unit

• Prolonged door opening or door ajar

• Door gasket(s) not sealing properly

• Dirty condenser coil

• Evaporator coil iced over

• Allow adequate time for product to cool down

• Ensure doors are closed when not in use.

Avoid opening doors for long periods of time

• Ensure gaskets are snapped in completely.

Remove gasket and wash with soap and water.

Check condition of gasket and replace if necessary

• Clean the condenser coil

• Unplug unit and allow coil to defrost.

Make sure thermostat is not set too cold.

Ensure the door gasket(s) are sealing properly

Unit is too warm • Thermostat set too warm

• Bad air circulation

• Excessive amount of warm product

placed in cabinet

• Fuse blown, or circuit breaker tripped

• Dirty condenser coil

• Prolonged door opening or door ajar

• Evaporator coil iced over

• Set thermostat to lower temperature

• Re-arrange product to allow for proper air ow.

Make sure there is at least four inches of

clearance from evaporator

• Allow adequate time for product to cool down

• Replace fuse or reset circuit breaker

• Clean the condenser coil

• Ensure doors are closed when not in use.

Avoid opening doors for long periods of time

• Unplug unit and allow coil to defrost.

Make sure thermostat is not set too cold.

Ensure that door gasket(s) are sealing properly

Unit is noisy • Loose part(s)

• Tubing vibration

• Locate and tighten loose part(s)

• Ensure tubing is free from contact

with other tubing or components

WARRANTY

ONE YEAR WARRANTY

Warrants to the original purchaser of this unit, the cabinet and all parts thereof, to be free from defects in material or workmanship, under normal use and

service, for a period of one (1) year from the date of original installation or 1 year after shipment date, whichever occurs first.

Any parts covered by this warranty that are examined and determined to have been defective within one (1) year of original installation or 1 year after

shipment date from manufacturer, whichever occurs first, shall be repaired or replaced as stated below. Shall be deemed to have fully complied with its

obligation under the foregoing warranties by electing either one of the following procedures

1.Furnishing a replacement part, freight collect, in even exchange for the returned part, freight collect.

2.Receiving the defective part, freight collect; repairing it; and returning it, freight collect.

ADDITIONAL FOUR YEAR COMPRESSOR PART WARRANTY

In addition to the (1) one year warranty stated above, warrants its hermetically and semi-hermetically sealed compressor to be free from defects in both

material and workmanship under normal use and service for a period of four (4) additional years from the date of original installation but not to exceed five

(5) years and three (3) months after shipment from manufacturer.

Compressors determined to have been defective within this extended time period will be either repaired or replaced with a compressor or compressor parts

of similar design and capacity.

The four (4) year extended compressor warranty applies only to hermetically and semi-hermetically sealed parts of the compressor and does not apply to

any other parts or components, including, but not limited to, cabinet, paint finish, temperature control, refrigerant, metering device, driers, motor starting

equipment, fan assembly any other electrical component, etc.

134A (404A) AND R290 COMPRESSOR WARRANTY

The four year compressor warranty detailed above will be voided if the following procedure is not carefully adhered to:

1.This system contains R134A (R404A) and R290 refrigerant and polyol ester lubricant. The Polyester lubricant has rapid moisture absorbing qualities. If

long exposure to the ambient conditions occur, the lubricant must be removed and replaced with new. Failure to comply with recommended lubricant

specification will void the compressor warranty.

2.Dryer replacement is very important and must be changed when a system is opened for servicing. Dryer must be used with XH-9 desiccant.

3.Micron level vacuums must be achieved to insure low moisture levels in the system. 500 microns or lower must be obtained.

WHAT IS NOT COVERED BY THIS WARRANTY

Obligation under warranty is limited to either repair or replacement of parts, subject to the additional limitations below. This warranty neither assumes nor

authorizes any person to assume obligations other than expressly covered by this warranty.

1.WARRANTY IS NOT TRANSFERABLE. This warranty is not assignable and applies in favor of the original purchaser/user to whom delivered. Any

such assignment or transfer shall void the warranties herein made and shall void all warranties, express or implied, including any warranty of

merchantability or fitness for a particular purpose.

2.NO CONSEQUENTIAL DAMAGES. Not responsible for economic loss: profit loss or special, indirect, or consequential damages, including without

limitation, losses or damages arising from food or product spoilage claims whether or not on account of refrigeration failure.

3.ALTERATION, NEGLECT, ABUSE, MISUSE, ACCIDENT, DAMAGE DURING TRANSIT OR INSTALLATION, FIRE, FLOOD, ACTS OF GOD.

Not responsible for the repair or replacement of any parts that have been subjected after the date of manufacture to alteration, neglect, abuse, misuse,

accident, damage during transit or installation, fire, flood, or an Act of God.

4.NO IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. There are no other warranties, express,

implied or statutory, except the one(1) year warranty and the additional four(4) year compressor warranty as described above. These warranties are

exclusive and in lieu of all other warranties, including implied warranty and merchantability or fitness for a particular purpose. There are no warranties

which extend beyond the description on the face hereof.

5.TRANSPORTATION COSTS. Will accept parts covered under this warranty freight collect, provided that shipment has received prior approval. Not

responsible for any other transportation costs, but will ship freight collect parts either repaired or replaced under these warranties.

6.WARRANTY CLAIMS. All claims should include: model number of the cooler, the serial number of the cabinet, proof of purchase, date of installation,

and all pertinent information supporting the existence of the alleged defect. Any action or breach of these warranty provisions must be commenced within

one (1) year after that cause of action has occurred.
