Hussmann Q1-SS Instruction Manual

24
1 of 24
Q1-SS
Technical Data Sheet
P/N Q1SS
Rev B
S
p
ecialt
y
Products
Q-Series
Rear
ETL Listed
40427
ETL Sanitation
40427
A
C
B
D
Item Part# Description Wiring Item #
A. Rear Discharge
N/A (integrated into rear wall)
B. Electrical Box Assembly
Ballast
Omni Stat
Switch
C. Evaporator Assembly
0392457 4 Watt Fan Motor
0420092 Fan Blade (exc. Wedge Cases)
175-01-1062 Fan Blade (45° OS Wedge Cases)
0409512 Fan Blade (45° IS Wedge Cases)
(TBD) Fan Blade (22.55° OS Wedge Cases)
(TBD) Fan Blade (22.55° OS Wedge Cases)
(TBD) Fan Blade (90° OS Wedge Cases)
0409510 Fan Shroud
D. Leg Assembly
NSF Adjustable Leg
NSF Caster
E. Rear Ledge
Replaceable/Optional
Contact Facility for available materials
We reserve the right to change or revise specifications and
p
roduct design in connection with any feature of our
p
roducts. Such changes do not entitle the buyer to
corresponding changes, improvements, additions or
replacements for equipment previously sold or shipped.
Item Part# Description Wiring Item #
F. Interior deck pans (materials/colors vary)
2’ deck pan: 4,6,8,10,12ft
2 1/2’ deck pan: 5 ft
G. Front Plex
037329 4’ Front Plex
037328 6’ Front Plex
037327 8’ Front Plex
037326 10’ Front Plex
037325 12’ Front Plex
H. Optional Ledge Light Bulbs
T5 1’ (F8)
T5 2’ (F14)
T5 3’ (F21)
T5 4’ (F28)
T5 5’ (F35)
G
F
H

24
2 of 24
Q1-SS
Technical Data Sheet
P/N Q1SS
Rev B
S
p
ecialt
y
Products
Q-Series
A
44 1/2
1129
D
OPT 1
10 1/4
258
6 1/2
164
32 1/2
825
34
871 1
25
6 1/2
166
C
28 1/4
715 31
789
4ft (1219.2) 5ft (1524) 6ft (1828.8) 8ft (2438.4) 12ft (3657.6)
General
(A) Case Length (without ends or partitions)
(Each end and insulated partition adds 1 ½ in. (38 mm) to case line up)
Maximum O/S dimension of case back to front
(not including bumper)
Back of case to front of splashguard
Back of case to O/S edge of front leg
Distance between center of external legs and center legs
Distance between center of center legs
Distance between center front legs and splashguard
OPT 1 Electrical Service (Electrical Field Wiring connection point)
(B) LH End of case to center of stub up area
Back of case to center of stub up area
Length of electrical raceway
OPT 2 Electrical Plug (case only, Self contained w/floor drain)
NEMA Type
LH End of case to center of cord
Cord Length
OPT 2 Electrical Plug (case only, Self contained w/condensate)
NEMA Type
LH End of case to center of cord
Cord Length
Optional Electrical 115V 15A Outlet
NEMA Type
LH End of case to center of cord
Cord Length
Waste Outlet
(C) Center of case to the center waste outlet
Back O/S of case to center of waste outlets
Schedule 40 PVC drip pipe
Refrigeration Outlet
Back of case to center of refrigeration outlet
(D) RH end of case to center of refrigeration outlet
48 (1219.2)
34.3 (870.7)
32.5 (824.6)
NA
NA
1.8 (46.1)
6.5 (165.1)
24 (610)
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
5 (127)
28.1 (713.7)
1 ¼
31 (788.7)
6.1 (156)
60 (1524)
34.3 (870.7)
32.5 (824.6)
NA
NA
1.8 (46.1)
6.5 (165.1)
24 (610)
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
5 (127))
28.1 (713.7)
1 ¼
31 (788.7)
6.1 (156)
72 (1828.8)
34.3 (870.7)
32.5 (824.6)
34.5 (876.3)
NA
1.8 (46.1)
6.5 (165.1)
24 (610)
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
5 (127)
28.1 (713.7)
1 ¼
31 (788.7)
6.1 (156)
96 (2438.4)
34.3 (870.7)
32.5 (824.6)
46.5 (1181.1)
NA
1.8 (46.1)
6.5 (165.1)
24 (610)
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
5 (127)
28.1 (713.7)
1 ¼
31 (788.7)
6.1 (156)
144 (3657.6)
34.3 (870.7)
32.5 (824.6)
46.5 (1181.1)
48 (1219.2)
1.8 (46.1)
6.5 (165.1)
24 (610)
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
5 (127)
28.1 (713.7)
1 ¼
31 (788.7)
6.1 (156)
Engineering
Plan View

24
3 of 24
Q1-SS
Technical Data Sheet
P/N Q1SS
Rev B
S
p
ecialt
y
Products
Q-Series
Engineering
CROSS SECTION
ETL Sanitation
These merchandisers are manufactured to meet ANSI/National Sanitation
Foundation Standard #7 requirements.
REFRIGERATION DATA
Note: This data is based on store temperature and
humidity that does not exceed 75F and 55% R.H.
Discharge Air (F) 26
Evaporator (F) 20
N
ote: Not recommended to control temp by regulating
coil temp allow t-stat to cycle and control temp.
Bt
u/hr/ft*
Parallel 660
Conventional 759
*For all refrigeration equipment other than Hussmann,
use conventional Btu values.
DEFROST DATA
Frequency Hrs 6
OFFTIME
Temp Term °F 45
Failsafe Minutes 30
ELECTRIC or GAS Not Recommended
PHYSICAL DATA
Merchandiser Drip Pipe (in.) 1 1/2
Merchandiser Liquid Line (in.) 3/8
Merchandiser Suction Line (in.) 5/8
Estimated Charge (lb)***
4ft 1.2
5ft 1.5
6ft 1.8
*** This is an average for all refrigerants types. Actual
refrigerant charge may vary by approximately half a
p
ound. GLYCOL REQUIREMENTS
GPM PSI
3ft 0.7 2.6
4ft 0.9 4.9
5ft 1.2 7.7
6ft 1.4 3.1
8ft 1.9 5.5
10ft 2.3 8.4
12ft 2.8 6.0

24
4 of 24
Q1-SS
Technical Data Sheet
P/N Q1SS
Rev B
S
p
ecialt
y
Products
Q-Series
Q1-SS-4R 4' W1750016
Q1-SS-5R 5' W1750040
Q1-SS-6R 6' W1750018
Q1-SS-8R 8' W1750018
Q1-SS-12R 12' W1750020
Q1-SS
Q1-SS-3R 3' W1750045
Q1-SS Q1-SS-4R 4' W1750021
OPTIONS Q1-SS-6R 6' W1750022
Q1-SS-8R 8' W1750023
Q1-SS-12R 12' W1750025
Q1-SS-S Q1-SS-3S 3' W1750035-01
Q1-SS-4S 4' W1750035-02
Q1-SS-5S 5' W1750035-03
Q1-SS-6S 6' W1750035-04
Q1-SS-7S 7' W1750035-05
Q1-SS-8S 8' W1750035-06
Q1-SS-9S 9' W1750035-07
Q1-SS-10S 10' W1750035-08
Q1-SS-11S 11' W1750035-09
Q1-SS-12S 12' W1750035-10
