Bernard Cable Connectors User manual

Cable Connectors
• Heavy-duty ball-point set screw cable
connection
• Fully insulated covers for maximum safety
• Interchangeable with most popular models
• Connector locking screw designed for
longer life and superior electrical
connection
Positive Lock Terminal Lugs
• Lug screw designed for enhanced field
repairability
• Composite copper alloys for superior
conductivity
• Increased cable depth for better
connections
• Fully insulated covers are heat, oil and
abrasion resistant
Hammer-on Cable Lugs & Splicers
• Simple as driving a nail to attach
• No soldering, no bolting, no set screws, no
crimping tools required
• Twice as heavy as most crimp-type
connectors
• Same conductivity as the cable they
connect
Solder Type Lugs
• Copper alloy for excellent electrical
conductivity
• Flared end for easy cable access
• Stud hole size 17/32
Bernard Manual Welding
Products
Issued July 2007 • SPEC MP-1.3
Manual Products
Cable Connectors, Lugs, Splicers
USA
Made with
Pride and without
Compromise in the
Time Tested Performance.
Our Manual Welding Products provide
high quality with a wide range of
styles, sizes and capacities to enhance
your welding applications.
Phone: [phone] (US Only) 708-946-2281 (Outside US)
Fax: [phone]
For more information, visit us at BernardWelds.com
Bernard®
An Illinois Tool Works Company
449 West Corning Road, Box 667
Beecher, Illinois 60401 USA

Bernard® Tweco® Lenco® Jackson®
1BC* MPC/1 MBP LC 10 UB-1-BP
2BC* 2 MPC/2 MBP LC 40 UD-3-BP
4BC* 4 MPC/4 MBP LC 40 HD UB-4-BP
2-1BC 2-1-MBP LC 1040 UWB-BP
B-1AF 1-AF CT-10FA N/A
B-2AF 2-AF CT-40FA N/A
©2007 Bernard Printed in U.S.A.
Available Manual Products
CABLE CONNECTORS
Model: 1BC 2-1BC 2BC 4BC
Cable Sizes: 4,2,1 4,2,1 1/0, 2/0, 3/0 3/0, 4/0
(35-50 mm2) (35-50 mm2) (50-70 mm2) (70-95 mm2)
Details: 1BC-F: Female Mates w/ 2BC-F: Female 4BC-F: Female
1BC-M: Male 2BC-F or 4BC-F 2BC-M: Male 4BC-M: Male
TERMINAL LUGS
Model: B-1AF B-2AF
Accepts Cable Connector(s): 1BC-M 2BC-M, 4BC-M, 2-1BC
SOLDER TYPE LUGS
Model: B-62 B-120 B-3040
Cable Size: 6-2 1-2/0 3/0 and 4/0
Amperage Rating: 150 225 250
Size of Stud Hole: 17/32” 17/32” 17/32”
I.D. Cable Socket: .461” .559” .660”
Model: L11 L22 L33 L44
Cable Sizes: 3/0 and 4/0 1/0 and 2/0 2 and 1 6 thru 2
Size of Stud Hole: 21/32” 17/32” 33/64” 13/32”
I.D. Cable Socket: 5/8” 33/64” 13/32” 19/64”
Model: S11 S22 S33
Cable Sizes: 3/0 and 4/0 1/0 and 2/0 2 and 1
I.D. Cable Socket: 5/8” 33/64” 13/32”
TERMINAL LUGS
SOLDER TYPE LUGS
HAMMER-ON TYPE LUGS
SPLICERS
Bernard connectors are interchangeable with these products:
U.S. Patent. 5,366,392
*Male and Female sold separately in standard packs of two
