Bertazzoni Master Series User manual

REF30BMB…N… Series
REF36BMB…N… Series
REF36FDB…N… Series
WWW.BERTAZZONI.COM
BERTAZZONI
EN
REFRIGERATOR
INSTALLATION MANUAL

REF30BMB…N…
REF36BMB...N…
REF36FDB...N…
3
EN

4
CONTENTS
1. IMPORTANT INFORMATION 5
1.1 Symbols and Their Meanings ..............................................................................................................................................5
1.2 Disposing of the packing materials ...................................................................................................................................5
1.3 Climate class ............................................................................................................................................................................6
1.4 Product weight .........................................................................................................................................................................6
1.5 Food load bearing capacity of the doors ..........................................................................................................................6
2. BEFORE INSTALLATION 7
2.1 Installation location ................................................................................................................................................................7
2.2 Cabinetry ...................................................................................................................................................................................8
2.3 Ventilation .................................................................................................................................................................................8
2.4 Electrical Connection .............................................................................................................................................................8
2.5 Water Connection (where applicable) ...............................................................................................................................8
2.6 Tool list .......................................................................................................................................................................................8
2.7 Alternatives for installation .................................................................................................................................................9
2.8 Preparation for installation ..................................................................................................................................................9
2.9 Location of the Electrical Wiring .......................................................................................................................................10
2.10 Location of the Water System .........................................................................................................................................11
2.11 Product dimensions ...........................................................................................................................................................12
2.12Unpacking..............................................................................................................................................................................20
2.13 Removing the connectors on the side wall of the unit .............................................................................................21
2.14 Removing the Installation Hardware from the Freezer Compartment ...............................................................22
2.15 Removing the freezer drawer .........................................................................................................................................23
2.16 Removing the freezer door ..............................................................................................................................................23
2.17 Removing the lower and upper ventilation grill covers ...........................................................................................24
3. INSTALLATION INSTRUCTIONS 25
3.1 Before installation .................................................................................................................................................................25
3.2 Mounting the Anti-Tip Brackets ........................................................................................................................................25
3.3 Preparing the Water Hose and the Electrical Connection .........................................................................................28
3.4 Installation in the cabinet ....................................................................................................................................................28
3.5 Overlay panel installation and preparation ...................................................................................................................35
3.6 Hinge adjustment and reversing the door swing .........................................................................................................48

5
EN
1.1 Symbols and Their Meanings
Symbols used in the installation manual are as
follows.
Note
Important information or useful tips for use
Warning
Conditions that may damage the product or
aect its operation
Caution
Situations entailing a serious risk of injury
1.2 Disposing of the packing materials
The packing materials have been designed to
protect the product during transport.
The packing materials used for the product are not
harmful to the environment when disposed of and
they need to be recycled.
All plastic packing materials, bags, etc. must be
disposed of safely and kept out of the reach of
children.
Please return the packing materials to your dealer.
WARNING:
This installation manual is intended to
aid installation teams. The User Manual
provided with the product must also be
taken into account.
You may be seriously injured and your
product damaged if you ignore the warnings
provided in this manual. Please read the
following carefully.
WARNING:
R600a Refrigerant
This product contains R600a isobutane
refrigerant, which is a very eco-friendly
natural gas. However, it is also flammable.
Please heed the warnings below:
• If the product has been transported
horizontally, you must wait for a minimum
of 4 hours before plugging it in.
• The following instructions must be
followed during installation:
• The dimensions of the installation area
must be adequate.
• The dimensions, features and position of
the object used to support and secure the
product in said area must be suitable.
• Minimum clearances between product
parts and surrounding structures must
be adequate.
• Minimum dimensions and proper
positioning of ventilation holes must be
heeded.
• The product must be connected to a
non-GFCI protected dedicated circuit,
and there must be a suitable water line
connection (for models with ice maker
and water dispenser).
• The product must be able to be
disconnected from the power supply
after installation.
• The socket or fuse must be accessible,
so as to be able to shut o power to the
product.
• Extension cords and ungrounded (two-
prong) adapters may not be used.
CAUTION:
You must wear protective gloves and eye
protection when installing the product.
You must also wear hearing protection
when using a drill or similar tools.
CAUTION:
Make sure that the electrical circuit is
suitable for the product.
CAUTION:
The product must be installed by a qualified
technician according to the installation
instructions.
WARNING:
The product may tip over, because it is
quite heavy. Precautions must be taken to
prevent this from occurring.
The product's doors must be kept closed
until it reaches its destination; it must be
transported in the manner described in the
installation instructions.
1. IMPORTANT INFORMATION

REF30BMB…N…
REF36BMB...N…
REF36FDB...N…
6
1.3 Climate class
Climate range Ambient temperature of the room
This appliance has been designed to be
used in certain specific climates (ambient
temperatures ranges). It must not be used
outside of these ranges.
SN (Extended temperate) Between +50ºF (10ºC) and +90ºF (32ºC)
N (Temperate) Between +60ºF (16ºC) and +90ºF (32ºC)
ST (Subtropical) Between +60ºF (16ºC) and +100ºF (38ºC)
T (Tropical) Between +60ºF (16ºC) and +110ºF (43ºC)
1.4 Product weight
Category REF30BMBZPNV REF30BMBPNB REF36BMBZPNV REF36BMBPNB REF36FDBZPNV REF36FDBPNB
Product weight 342 lb (155 kg) 326 lb (148 kg) 373 lb (169 kg) 358 lb (162 kg) 355 lb (161 kg) 340 lb (154 kg)
Category REF30BMBZXNV REF30BMBXNB REF36BMBZXNV REF36BMBXNB REF36FDBZXNV REF36FDBXNB
Product weight 386 lb (175 kg) 370 lb (168 kg) 439 lb (199 kg) 424 lb (192 kg) 421 lb (191 kg) 406 lb (184 kg)
1.5 Food Load Bearing Capacity of the Doors
Max. load REF30BMB…N… REF36BMB...N… REF36FDB...N…
Fridge door 55 lb (25 kg) 55 lb (25 kg) 22 lb (10 kg)
Freezer drawer 22 lb (10 kg) 22 lb (10 kg) 22 lb (10 kg)
1. IMPORTANT INFORMATION

7
EN
2.1 Installation location
You must follow the instructions below:
> The floor on which the product is to be installed
must be capable of bearing 1,200 pounds (544 kg)
minimum.
> The kitchen floor and the bottom of the product
must be equally level. Otherwise, problems may
occur with the appliance's air flow.
> There must be no obstructions at the rear and on
the side walls of the product's installation location
that would prevent its installation.
> The electrical outlet must be in the correct place.
> The dimensions of the cabinet where the appliance
is to be installed must be in strict conformity with
the dimensions provided in the manual.
> Do not install the appliance adjacent to another
fridge/freezer. Otherwise, condensation and
damage may occur. (Please see "Dual-Fridge
Cabinet Installation" for detailed information).
> The level of the floor where the product is to be
installed must be checked with a bubble level.
> The installation location must not be exposed
to direct sunlight and must be away from heat
sources (ovens, radiators, etc.).
> The ambient temperature must be between 50°F
(10°C) and 110°F (43°C). Otherwise, malfunctions
may occur when the appliance is running.
> If it is not possible to avoid installing the product
near a heat source, the minimum clearances
provided below must be maintained between the
appliance and the given source:
• 1 1/4" (32 mm) from electric ranges or ovens
• 12" (305 mm) from gas or fuel-powered kitchen
ranges or ovens
Please heed the following rules:
> The electrical outlet or panel must be easily
accessible in case of an emergency; it must not be
hidden behind the product.
> Neither the plug nor the cable may touch the
back surface of the appliance. Otherwise, it may be
damaged by the appliance's vibrations.
> Do not connect other equipment plugs behind
this appliance.
If the humidity level is high where the appliance
is being used, its exterior surfaces may become
corroded.
To prevent corrosion, keep the installation room
dry and well-cleaned.
To prevent the risk of electric shock:
> Connect the plug to a grounded 3-prong outlet.
> Do not remove plug's grounding prong.
> Do not use adapters.
> Do not use extension cords.
CAUTION:
Failure to follow these instructions may
result in fire, electric shock or death.
Connecting the appliance's grounding
conductor in the wrong place may lead to
electric shock. Please have the grounding
checked by a qualified electrician or service
technician if you have any doubt about the
proper grounding of the appliance.
Installation, repairs and other procedures
performed by unqualified persons may
give rise to hazards. Before installing the
appliance, make sure that the voltage, load
and circuit current parameters on the data
plate are in compliance with the power
supply in your house.
The appliance is provided with a NEMA 5-15
P plug and a 3-prong power cord which is
in the UL list and ready to be connected to a
120 V, 60 Hz power supply. Fuse is 15 A. The
appliance must be connected to a 3-prong
socket. The plug must be installed only by a
licensed electrician.
If the electrical wiring or the electric power
supply of the house requires alteration, the
necessary procedures must be performed
by a qualified electrician.
CAUTION:
Do not install your refrigerator:
•in an outdoor space,
•in a location with dripping water,
•in a location where the temperature is
lower than 50°F (10°C).
2. BEFORE INSTALLATION

8
2.2 Cabinetry
Make sure that the cabinetry inside which you will
install the appliance has been securely mounted in
your kitchen.
Your cabinet must be properly secured to the
floor and to the wall using appropriate mounting
hardware.
For the best installation, clearances between the
cabinet and the appliance must be in compliance
with the measurements specified in the installation
instructions.
The side walls must be free of obstructions and
their surfaces must be flat. The minimum thickness
of the side walls must be 5/8" (16 mm).
The minimum thickness of the door panels to be
attached to the appliance must be ¾” (19 mm).
CAUTION:
There is a stainless steel door and stainless
kickplate option. Please consult your
Authorized Service Provider.
2.3 Ventilation
Ventilation openings where the air enters and exits
the unit must never be obstructed. The user is
responsible for periodically cleaning o the dust
and debris that can accumulate on the grill over
time.
2.4 Electrical Connection
> Never use an extension cord.
> The electrical outlet must be grounded and
checked by an authorized technician.
> The positioning of the electrical wiring must
comply with the measurements specified in the
manual.
CAUTION:
RISK OF ELECTRIC SHOCK
Electrical grounding is necessary. This
appliance is equipped with a three-prong
plug to protect you against possible electric
shocks.
•Do not remove the round grounding prong
from the plug.
•Do not use two-prong grounding adapters.
•Do not use an extension cord to supply
power to the product.
CAUTION:
Do not connect the grounding cable to the
gas line. Please have the grounding checked
by a qualified electrician if you are not sure
about the grounding of the appliance. Do
not install a fuse on the neutral line or on
the grounding circuit.
WARNING:
Please wait for 3-6 hour before connecting
the appliance to the power supply, in order
to protect it against possible damage. This
will allow the balance of the refrigerant and
the lubricants in the system to be restored.
2.5 Water Connection (where applicable)
> Water supply pressure must be within the range
specified in the manual.
> The location of the water line connection must
comply with the area measurements specified in
the manual.
Note:
A bypass plug is recommended for the
water filtering system if a reverse osmosis
system is used.
2.6 Tool List
The tools to be used when installing the product
are as follows:
Cordless drill
Safety goggles
½" wrench
Hammer
2. BEFORE INSTALLATION

9
EN
Ladder
Ø 2.4 drill bit
Ø 8.0 drill bit
Box cutter
Safety gloves
Tape measure
Phillips-head bit
¼" hex bit
Bubble level
Appliance dolly
Tape
2.7 Alternatives for Installation
The appliance can be installed in a variety of
ways depending on the kitchen design. It must be
installed in a location where it is certain that the
door can be opened and closed properly. If the
doors cannot open up to at least 90 degrees the
appliance drawers will not be able to be opened.
• Single-fridge cabinet placement methods
• Dual-fridge cabinet placement methods
2.8 Preparation for Installation
The instructions below refer to a built-in
installation.
In a built-in installation, the appliance is installed
in a cabinet niche or framed in with panels.
Niche Dimensions
• The niche dimensions below must be checked
before beginning the installation.

10
2.9 Location of the Electrical Wiring
The location of the electrical outlet in the cabinet
where the product is to be installed must be within
the area shown in the figure.
CAUTION:
Do not use extension cords or two-prong
adapters and do not remove the ground
terminal of the grounding cable.
CAUTION:
A qualified electrician must ensure that the
poles of the socket are connected correctly.
Verify that the grounding of the socket is
correct.
Category REF30BMB…N… REF36BMB...N… REF36FDB...N…
A width 30" (762 mm) 36" (914 mm) 36" (914 mm)
B depth 25" (635 mm) 25" (635 mm) 25" (635 mm)
C height 84" (2134 mm) 84" (2134 mm) 84" (2134 mm)
2. BEFORE INSTALLATION

11
EN
2.10 Location of the Water System
The water connected to the water supply must be
potable.
The location of the water line connection must be
within the area shown in the figure below.
The refrigerator's water system must be connected
to the house's main water supply.
The user must be able to switch it on/o using the
valve when necessary.
Objects that might pierce the water hoses or cause
them to twist must not be present where the water
line is installed.
The pressure of the water system must be between
25-80 psi (1.7-5.5 Bar).
If the water pressure exceeds 80 psi, install a
pressure limiting device or water impact protector
to the inlet valve. Do not install or operate the
appliance if it is possible for the water pressure to
exceed 120 psi.
WARNING:
Make sure that there is no water leakage
when establishing the water connections.
Otherwise, water may damage the cabinetry.
The water supply line must located in
the cabinet where the appliance is to be
installed.The user must be able to switch it
on/o using the valve when necessary. You
will need a hose with a minimum length of
60" (1.5 meters) and a diameter of ¼" for
the appliance's water connections during
installation. A connector that has a thread
with an external diameter of ¼" must be
used to connect the end of the hose to the
product.
Before completing the installation, make
sure that water flows and that there is no
water leakage.
WARNING:
• The level of the floor where the product
is to be installed must be checked with a
bubble level.
• The cabinet flanges must be checked
with a bubble level to ensure that they are
perfectly vertical.
• If the appliance is not perfectly level and
vertical, problems may arise with the
installation.

12
2. BEFORE INSTALLATION
2.11 Product dimensions
Category REF30BMB…N… REF36BMB...N… REF36FDB...N…
A29 3/4” (756 mm) 35 3/4” (908 mm) 35 3/4” (908 mm)
REF30BMB…N…
REF36BMB...N…
without panel: 23 5/16” (592 mm)
with panel: 24 ¼” (616 mm)
Adjustable feet

13
EN
REF36FDB...N…
without panel: 23 5/16” (592 mm)
with panel: 24 ¼” (616 mm)
Adjustable feet
Adjustable feet

14
2. BEFORE INSTALLATION
Category REF30BMB…N… REF36BMB...N… REF36FDB...N…
A15 1/4" (388 mm) 15 1/4" (388 mm) 15 1/4" (388 mm)
Category REF30BMB…N… REF36BMB...N… REF36FDB...N…
A32 7/16” (824 mm) 38 7/16” (976 mm) 41 1/8” (1044 mm)
B29 3/4“ (756 mm) 35 3/4“ (908 mm) 35 3/4“ (908 mm)
C55 1/16” (1398 mm) 61” (1550 mm) 42” (1067 mm)
Minimum distance to wall
90° door swing

15
EN
90° door swing

16
2. BEFORE INSTALLATION
Category REF30BMB…N… REF36BMB...N… REF36FDB...N…
A44 3/8” (1127 mm) 54 3/4” (1391 mm) 53 7/8” (1368 mm)
B29 3/4“ (756 mm) 35 3/4“ (908 mm) 35 3/4“ (908 mm)
C14 5/8” (371 mm) 19” (483 mm) 9 1/16” (230 mm)
D52 11/16” (1338 mm) 57 3/4” (1466 mm) 41 ¾” (1061 mm)
115° door swing
115° door swing
Minimum
distance to wall
Minimum
distance to wall

17
EN
Anti-tip bracket location
Space remaining
after installation
Minimum height
adjustment for
leveling
Front Rear

18
2. BEFORE INSTALLATION
Gap: 1/8" (3 mm)
Gap: 1/8" (3 mm)
Gap: 1/8" (3 mm)
Gap: 1/8" (3 mm)
Gap: 1/8" (3 mm)
Gap: 3/8" (10 mm)
Gap: 1/8" (3 mm)
Gap: 1/8" (3 mm)
Gap: 1/8"
(3 mm)
REF30BMB…N…
REF36BMB...N…
REF36FDB...N…

19
EN
Height of the kitchen countertop based on the min./max. height of the cabinet;
A B C
standard 4” (102 mm) 32 11/16” (831 mm) 84” (2134 mm)
minimum 3 13/16”(97 mm) 32 1/2“ (826 mm) 83 13/16“ (2129 mm)
maximum 5 3/8“(137 mm) 34 1/16” (866 mm) 85 3/8“ (2169 mm)
Category REF30BMB…N… REF36BMB...N… REF36FDB...N…
D30” (762 mm) 36” (914 mm) -
E29 3/4” (756 mm) 35 3/4” (908 mm) -
Fridge panel height Fridge panel height
Height of the kitchen countertop based on the min./max. height of the cabinet
A B C
standard 4” (102 mm) 32 11/16” (831 mm) 84” (2134 mm)
minimum 3 13/16”(97 mm) 32 1/2“ (826 mm) 83 13/16“ (2129 mm)
maximum 5 3/8“(137 mm) 34 1/16” (866 mm) 85 3/8“ (2169 mm)
Category REF30BMB…N… REF36BMB...N… REF36FDB...N…
D30” (762 mm) 36” (914 mm) -
E29 3/4” (756 mm) 35 3/4” (908 mm) -
Fridge panel height Fridge panel height
Freezer panel height
Freezer panel height
Wooden door panel
Wooden cabinet panel
Wooden door panel
Wooden cabinet panel

20
2. BEFORE INSTALLATION
2.12 Unpacking
WARNING:
At least two people must carry the
refrigerator.
• Use a box cutter to remove the tape.
• Cut the cardboard packaging along the dotted
lines using a box cutter and remove it.
• Remove the polystyrene packing material.
CAUTION:
Do not remove the tape from the upper
door of the appliance until the refrigerator
is placed in the cabinet.
Tipping risk.
