Besam RD3 User manual

An ASSA ABLOY Group company
1003090-EI-2.0 – Issue 2006-12-21
Besam Revolving Door RD3/RD4
User Manual

2 Issue 2006-12-21 1003090-EI-2.0
© All rights in and to this material are the sole property of ASSA ABLOY Entrance Systems AB. Copying, scanning,
alterations or modifications are expressly forbidden without the prior written consent of applicable company within
ASSA ABLOY Entrance Systems AB. Rights reserved for changes without prior notice.

1003090-EI-2.0 Issue 2006-12-21 3
1. Important information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.1 Important safety instructions for use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.2 Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2. Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3. Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
4. Main parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
5. Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
5.1 Programme selector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
5.2 Start up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
5.3 Switch off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
5.4 Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
6. Safety equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
6.1 Standard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
6.1.1 Compressible safety switches. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
6.1.2 Force sensitive door leaves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
6.1.3 Emergency stop push-button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
7. Programme selector PCD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
7.1 General information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
7.2 Access code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
7.2.1 Login to the PCD. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
7.2.2 Logout from the PCD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
7.2.3 Change access code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
7.2.4 The ON/OFF switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
7.3 Changing operating mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
7.3.1 The different operating modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
7.4 Real time operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
7.4.1 Activation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
7.4.2 Deactivation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
7.4.3 ON/OFF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
7.4.4 Manually setting of operation mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
7.4.5 Summertime/Wintertime . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
7.5 Read speed settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
7.6 Real time clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
7.6.1 Read real time clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
7.7 Remote Control Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
7.7.1 Communication ON/OFF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
7.7.2 Login . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
7.7.3 Logout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
7.8 Main menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
7.9 Door operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
7.9.1 Other information on screen (EI). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
8. Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Table of content

4 Issue 2006-12-21 1003090-EI-2.0
9. Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
9.1 Compressible safety switches on the door leaves. . . . . . . . . . . . . . . . . . . . . . . . . . 24
9.2 Infrared presence sensor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
9.3 Vertical presence photocell sensor PDR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
9.4 Break-out kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
9.5 Emergency opening push-button. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
9.6 Push-button for disabled . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
9.7 Push-button inside door. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
10. Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
10.1 Rotation brake (lock) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
10.2 Electromechanical lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
10.3 Direction sensing radar DSR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
10.4 Night closing door NCD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
10.5 Modem. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
11. Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
11.1 Supervision system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
11.2 Simple troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
11.2.1 The door does not start at start up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
11.2.2 Service request . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
11.3 Code list. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
11.4 Status codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
11.4.1 Diagnostic out-put . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
11.4.2 Control unit CDC. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
12. Mark up table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
12.1 Floor levelling information from installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
12.1.1 Floor surface levelling values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
13. Revolving door log book. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
14. Real time operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Important information
1003090-EI-2.0 Issued 2006-12-21 5
1.0 Important information
1.1 Important safety instructions for use
To avoid bodily injury, material damage and malfunction of the product, the
instructions contained in this manual must be followed. Save these instructions.
1.2 Environment
This operator may be equipped with batteries containing materials which are haz-
ardous to the environment. Remove the batteries from the operator before it is
scrapped. The batteries must be disposed of safely.
2.0 Introduction
This manual contains necessary details and instructions for the daily use of the
Besam revolving door RD3/RD4.
Besam RD3/RD4 is designed to offer continuous use, a high degree of safety and
maximum lifetime. The system is self-adjusting to the effects caused by normal
variations in the weather conditions and to minor friction changes caused by e.g.
dirt.
Rights reserved for any changes without previous notice.

Service
6 Issued 2006-12-21 1003090-EI-2.0
3.0 Service
When your door needs to be serviced, contact the nearest authorized Besam
service centre.
We recommend inspection of doors at least once a year (see page 23). According
to regulations inspection of emergency escape doors is required at least twice a
year, carried out by an authorized service centre. Please check the service book.
Place for telephone number, stamp, sticker or the like.

Main parts
1003090-EI-2.0 Issued 2006-12-21 7
4.0 Main parts
No Description
1 Programme selector and reset push-button
2 Emergency stop push-button
3 Activation unit
1
3
2

Operation
8 Issued 2006-12-21 1003090-EI-2.0
5.0 Operation
5.1 Programme selector
The programme selector is equipped with a three position key switch and a reset
push-button.
Note! If the door is equipped with a PCD programme selector, (see page 13).
5.2 Start up
• Open the night security doors, if fitted
• Unlock the mechanical lock, if fitted
• Check that the door emergency stop push-button is released. If not, turn the
button in any direction to release
Automatic operation
• Turn the programme selector to automatic operation
• The electro-mechanical lock, if fitted, is now unlocked
The door is parked at home position when there is no traffic. As soon as the acti-
vation units detect approaching traffic, the door automatically starts to rotate.
Continuous rotation
• Turn the programme selector to continuous rotation
• The electro-mechanical lock, if fitted, is unlocked
The door rotates continuously at a low speed. As soon as the activation units
detect approaching traffic, the door accelerates to normal speed. The door will
then return to low speed when there is no traffic.

Operation
1003090-EI-2.0 Issued 2006-12-21 9
5.3 Switch off
• Check there is no traffic
• Turn the programme selector to off position
The door rotates to its home position
The electro-mechanical lock, if fitted, is locked
• Lock the mechanical lock, if fitted
• Close and lock the night security doors, if fitted
5.4 Reset
• In case of an error reset the door by pressing the reset push-button

Safety equipment
10 Issued 2006-12-21 1003090-EI-2.0
6.0 Safety equipment
Standard
Options
No Description
1 Compressible safety switches placed on the drum edges (see page 11)
2 Force sensitive door leaves (see page 11)
3 Emergency stop push-button (see page 12)
No Description
A Compressible safety switches placed on the door leaves (see page 24)
B Infrared presence sensing system (see page 24)
C Vertical presence photocell sensor PDR (see page 25)
D Break-out kit (see page 25)
E Push-button for disabled (see page 26)
ILL-00043
1
3
BC
E
D
2
A

Safety equipment
1003090-EI-2.0 Issued 2006-12-21 11
6.1 Standard
6.1.1 Compressible safety switches
Compressible safety switches on the drum edges. These stop the rotation if com-
pressed. When the obstacle is removed, the rotation continues.
6.1.2 Force sensitive door leaves
• If the system detects an obstacle blocking the door, the power to the motor is
shut-off
• The door makes three attempts to start. After these three attempts the door
waits for a while and then makes one new attempt to start
• If the door is pushed out of position during this waiting period, the system is
reset and starts to operate according to preset mode.
When the obstacle is removed the system can also be reset by pressing the
reset push-button
ILL-00048

Safety equipment
12 Issued 2006-12-21 1003090-EI-2.0
6.1.3 Emergency stop push-button
• The door rotation can be stopped by pressing the emergency stop push-button
• To reset the door to normal operation - release the emergency stop push-button
by rotating it in any direction and press the reset push-button or the C push-
button on the PCD (if installed)
ILL-00044
ILL-00049
C
PCD

Programme selector PCD
1003090-EI-2.0 Issued 2006-12-21 13
7.0 Programme selector PCD
As option the RD3/RD4 can be equipped with programme selector PCD (pro-
gramme control device) with access codes to operate the door.
7.1 General information
Information prompts on the display
The door has a lot of configurations, which
shall be left to Besam Service.
Key Function
0-9 Numeric inputs
# Confirm access code input
KSetpoint selection upwards
LSetpoint selection downwards
+ Setpoint value change upwards
- Setpoint value change downwards
F Function selection
S Setpoint confirmation and storage
C Error reset
Clear display
Leave menu
ON/OFF switch
Prompt Description
P1 ON/OFF switch in OFF position
P2 Service request. Call Besam for ser-
vice
P3 Real time operation ON, see “Real
time operation” on page 17
EAA154A
FUNC
DATA
ILL-00184
P1 P2
P3

Programme selector PCD
14 Issued 2006-12-21 1003090-EI-2.0
7.2 Access code
To be able to operate the PCD a login of access code must be done.
7.2.1 Login to the PCD
1. Type # to clear the display.
2. Type the access code, delivery code 1234, with the number key (four digits).
The display shows ==.
3. Type # to confirm the input.
If the access code is correct the display shows:
L I (Login)
0 1 (Level 01)
In case of two unauthorized attempts to access the PCD it takes five minutes
before a new attempt can be made.
7.2.2 Logout from the PCD
1. Type # to clear the display.
2. Type the access code. The display shows ==.
3. Type # to confirm the input.
If the access code is correct the display shows:
LO (Logout)
0 1 (Level 01)
4. Automatic logout ten minutes after the last key stroke.
5. Automatic logout can be inhibited by typing F561 on the PCD.
7.2.3 Change access code
At delivery the access code is 1234. To change do as follows:
1. Type # 1234 #. If the access code is correct the display shows:
L I (Login)
0 1 (Level 01)
2. Type F41. The display shows:
F 4
L 1
3. Type new code (4 digits).
4. Type Sto confirm.
5. Type the new access code a second time.
6. Type Sto confirm.

Programme selector PCD
1003090-EI-2.0 Issued 2006-12-21 15
7.2.4 The ON/OFF switch
The ON/OFF switch can be used in any operating mode (except manual mode). If
the door is locked with this switch (OFF), the prompt P1 is shown on the display.
If the door is locked with the ON/OFF switch it can be opened with a key impulse
switch (ask your local Besam Service). When the key impulse switch is activated,
the door unlocks, runs 360° and locks again.
7.3 Changing operating mode
1. Login to the PCD.
2. Type F2. The display shows F2 plus current operating mode.
3. Use the up or down arrow to change the operating mode.
4. Confirm the change and exit the operating mode selection function by typing
S.
5. Logout from the PCD (automatically Logout after 10 min)
ILL-00175
Key impulse switch
Key impulse switch
ON/OFF switch
Locked
ILL-00177
#Access code#
ILL-00182
S
ILL-00177
#Access code#

Programme selector PCD
16 Issued 2006-12-21 1003090-EI-2.0
7.3.1 The different operating modes
Closed (locked) 01
The door rotates to its closed position. If an electromechanical lock is fitted, the
lock is activated. The door can be opened with the key impulse switch, see “The
ON/OFF switch” on page 15. In this mode 01, the door will not run, even if the
ON/OFF switch is set to ON.
Automatic operation, start from open position 02
As soon as the outside or inside activation units detect approaching traffic, the
door starts rotating.
Continuous rotation 06
The door rotates at a low speed. As soon as the outside or inside activation units
detect approaching traffic, the door accelerates to normal speed. The door returns
to low speed when there is no traffic.
ILL-00180
Key impulse switch
ILL-00189
ILL-00190

Programme selector PCD
1003090-EI-2.0 Issued 2006-12-21 17
Manual operation “Cleaning position” 07
The door rotates forward as long as the + key is hold down and backwards as long
as the - key is hold down.
Note: During manual operation safety devices are disconnected.
7.4 Real time operation
Programming of real time operation must be done by Besam service engineer. Fill
in form on page 34.
The CDC-system has three different day schedules. Each day schedule may con-
tain up to 10 different operation modes. The week schedule informs the system of
which day schedule to run and in what order during a week. It is possible to make
up to 16 exceptions from this week schedule for e.g. public holidays etc.
7.4.1 Activation
1. Type F556 (Real time operation ON).
2. Prompt P3 lits up.
3. The door operates according to schedule.
7.4.2 Deactivation
1. Type F557 (Real time operation OFF).
2. Prompt P3 lits down.
3. The door operates according to manually set operation mode.
ILL-00191
+
-
F556 =
2
1
2
5
4
3
6
11
01
8
7
9
1
ILL-00181
ILL-00193
F557 =
2
1
2
5
4
3
6
11
01
8
7
9
1
ILL-00192
ILL-00193

Programme selector PCD
18 Issued 2006-12-21 1003090-EI-2.0
7.4.3 ON/OFF
The OFF position overrides real time operation. The door will be locked. When the
key switch is ON, the door resume settings according to schedule.
7.4.4 Manually setting of operation mode
If the door is running in real time operation mode and the operation mode is man-
ually changed, real time operation mode is automatically deactivated. To resume
real time operation mode it has to be reactivated by typing F556 again.
7.4.5 Summertime/Wintertime
1. To change from summertime to wintertime type F53 and select option number
02 with arrow ↑/↓keys.
2. Press + or - to select setting 00 or 01, [summertime off (wintertime) is value
00 and summertime on is value 01].
3. Press S (select).
To check the time change (see “Read real time clock” on page 19).
EAA204
FUNC
DATA
EAA400
↑/↓
+/−

Programme selector PCD
1003090-EI-2.0 Issued 2006-12-21 19
7.5 Read speed settings
1. Type F3. The display shows S1.
2. Use ↑or ↓to select setpoint number to read.
3. Press Cto leave the menu.
7.6 Real time clock
The CDC system has a real time clock built in. The clock is used for the log
record and when the door is running under real time settings.
7.6.1 Read real time clock
1. Type F71. The display shows 11 and present parameter value relating to year.
2. Use ↑or ↓to select parameter number and display the parameter value.
3. Press Cto leave the menu.
Summer and wintertime (see “Summertime/Wintertime” on page 18).
Setpoint Description Setpoint value
S1 High speed setpoint 1.0-6.0 rpm
S2 Low (handicap) speed setpoint 0.2-2.5 rpm
S3 Creep speed setpoint Fixed at 0.5 rpm
S4 Continuous speed setpoint 1.0-2.5 rpm
S5 Manual speed setpoint 0.2-2.0 rpm
S9 Door size parameter 1-9
FUNC
DATA
EAA254
↑/↓
11 Year
12 Month
13 Date
14 Hour
15 Minute
16 Second

Programme selector PCD
20 Issued 2006-12-21 1003090-EI-2.0
7.7 Remote Control Operation
To operate the door and have service control the CDC system can be connected to
a computer via the RS 232 connection “Read out”. It can be connected directly or
via a modem.
Ask your local Besam distributor for more information.
Software communication
To be able to communicate with the door Windows 3.1 or higher is needed. Make
following settings.
1. A)Windows 3.1/3.11.
Start terminal under Accessories.
B)Windows 95/98 or 2000XP.
Start hyperterminal under Accessories.
2. Make the following settings.
- Auto identification or VT100
- 8 bits data
- No parity
- One stop bit
- 9600 baud
EAA79
2
MODEM MODEM
Com. port
