Beswell BW-112X User manual

INSTRUCTION
MANUAL
IMPORTANT:
Upon receipt of the product, read
and follow all safety rules, operating
instructions before first use it. And
retain this manual for future reference.
Contain:
◎Technical Data
◎Important safety rules
◎Operating Instructions
◎Maintenance
◎Parts List
1/2” Air Composite Impact Wrench(Twin Hammer)
Model No.:BW-112X

※ Technical Data
Square drive……………………………………………………………………………………1/2”
Free speed………………………………………………………………………………………6,800rpm
Max torque………………………………………………………………………………1100ft/lb(1492N.m)
Avg. air consumption…………………………………………….…………………………..9cfm
Operating pressure……………………………………………………………………………...90psi(6.3bar)
Air inlet size…………………………………………………………………………………….1/4”
Air Hose (ID)…………………………………………………………………………………….3/8”（10 mm）
Weight………………………………………………………………………………………...7.4Lbs(1.9 kgs)
Standard Bolt Capacity ………………………………………………………………………...M24(0.95 inch)
Max Bolt Capacity ………………………………………………………………………... M30(1-1/5 inch)
※ Important Safety Rules
1. Always wear safety goggles or glasses.
2. Always ensure machine is switched off before connecting to air supply.
3. Disconnect any machine from the air supply before changing blades or discs, and before servicing any type of
machine.
4. Always keep your air tool clean and lubricated. Daily lubrication is essential to avoid internal corrosion and
possible failure.
5. Do not wear watches, rings bracelets or loose clothing when using air tools.
6. Using only light weight coil hoses from a tool to the wall or compressor coupling. Do not fit quick change
couplings onto the machine as vibration can cause the coupling to fail.
7. Do not overload the machine. Allow the tool to operate at its optimum speed for maximum efficiency.
8. Do not increase the air pressure above the manufacturers recommended level, as excessive overload can cause
the machine casing to split. Also this creates excessive wear on moving parts and possible failure.
9. In the interests of safety and possible damage to the machine/operator, always ensure that the machine has
stopped before putting it down after use.
10. Always ensure that the workpiece is firmly secured leaving both hands free to control the machine.
11. Always ensure that the accessories such as blades, discs, sockets, etc. are designed for use with the machine.
Also correctly and securely fastened before connecting the machine to the air supply.
12. When grinding, sanding or cutting always wear an appropriate face mask or respiratory equipment.
※Operating Instruction
Description
Durable twin hammer composite impact wrench mechanism,light weight,Adjustable power regulator ,Super Torque,
Rear exhaust,Sheer power and performance features to tackle the toughest jobs with ease and proven durability and
economy.

Air supply
1. Ensure wrench air valve (or trigger) is in the “off” position before connecting to the air supply.
2. You will require an air pressure of 90psi, and an air flow according to specification.
3. WARNING! Ensure the air supply is clean and does not exceed 90psi while operating the wrench. Too high an
air pressure and unclean air will shorten the product life due to excessive wear, and may be dangerous causing
damage or personal injury.
4. Drain the air tank daily. Water in the air line will damage the wrench.
5. Clean air inlet filter weekly.
6. Line pressure should be increased to compensate for unusually long air hoses (over 8 metres). The minimum
hose diameter should be 3/8” I.D. and fittings must have the same inside dimensions.
7. Keep hose away from heat, oil and sharp edges. Check hose for wear, and make certain that all connections are
secure.
Lubrication
An automatic in-line filter-regulator-lubricator is recommended (Fig4) as it increases tool life and keeps the tool in
sustained operation. The in-line lubricator should be regularly checked and filled with air tool oil.
Proper adjustment of the in-line lubricator is performed by placing a sheet of paper next to the exhaust ports and
holding the throttle open approximately 30 seconds. The lubricator is properly set when a light stain of oil collects
on the paper. Excessive amounts of oil should be avoided.
In the event that it becomes necessary to store the tool for an extended period of time (overnight, weekend, etc.), it
should receive a generous amount of lubrication at that time. The tool should be run for approximately 30 seconds
to ensure oil has been evenly distributed throughout the tool. The tool should be stored in a clean and dry
environment.
It is most important that the tool be properly lubricated by keeping the air line lubricator filled and correctly
adjusted. Without proper lubrication the tool will not work properly and parts will wear prematurely.
Use the proper lubricant in the air line lubricator. The lubricator should be of low air flow or changing air flow
type, and should be kept filled to the correct level. Use only recommended lubricants, specially made for
pneumatic applications. Substitutes may harm the rubber compounds in the tools O-rings and other rubber
parts.
IMPORTANT!!!
If a filter/regulator/lubricator is not installed on the air system, air operated tools should be lubricated at least once
a day or after 2 hours work with 2 to 6 drops of oil, depending on the work environment, directly through the male
fitting in the tool housing.

Assembly,Loading and operation
WARNING: Ensure you read, understand and apply safety instructions before use.
As a standard practice,drain walter from the air compressor tank and air lines prior to use
each day(reference your compressor operators manual for detailed instructions)
1. Remove the air inlet protective cap(Fig1) FIG6
2. Thread the male plug by hand into the inlet bushing (Fig 2)
3. Add 2-3 drops oil into male plug before each use (Fig 3)
4. Connect to air source with quick coupler (Fig 4)
5. Insert the sockets on socket retainer (Fig 5)
Attention:Only use sockets which are specifically designed for use with this tool.
6. One thing shall make sure the direction of rotation before actuate this tool.
The Three Circles indicts Foreword and the One Circle indicts reverse. Forward is
defined as clockwise direction seen from the operator’s position.(FIG 6)
7. Torque adjusting: Forward torque have 3 steps (small circles to big circles) on
right side with Three Circles mark; Reverse torque have only one step on left side
with One Circle mark (FIG 6)
DO NOT use any additional force upon the tool in order to work
DO NOT allow tool to free run for an extended period of time
as this will shorten its life.
Turn on the air compressor and allow it to build up pressure once
all of jobs done.Adjust the air compressor’s regulator or the supply line
regulator to 90PSI.Squeeze trigger gently.
FIG1 FIG2 FIG3 FIG4 FIG5

※Maintenance
WARNING: Disconnect wrench from air supply before changing accessories, servicing or performing
maintenance. Replace or repair damaged parts. Use genuine parts only. Non-authorised parts may be dangerous
1. Lubricate the air wrench daily with a few drops of air tool oil dripped into the air inlet
2. DO NOT use worn, or damaged sockets.
3. Loss of power or erratic action may be due to the following:
a) Excessive drain on the air line. Moisture or restriction in the air pipe. Incorrect size or type of hose connectors.
To remedy check the air supply and follow instructions .
b) b) Grit or gum deposits in the wrench may also reduce performance. If your model has an air strainer (located
in the area of the air inlet), remove the strainer and clean it..
4. When not in use, disconnect from air supply, clean wrench and store in a safe, dry, childproof location.
※ Trouble Shooting
The following form lists the common operating system with problem and solutions. Please read the form
carefully and follow it.
WARNING: If any of the following symptoms appears during your operating, stop using the tool
immediately, or serious personal injury could result. Only a qualified persons or an authorized service center can
perform repairs or replacement of tool.
Disconnect tool from air supply before attempting repair or adjustment. When replacing O-rings or Cylinder,
lubricate with air tool oil before assembly.
PROBLEMS POSSIBLE CAUSES REMEDIES
Tool runs at normal speed
but loses under load
■. Motor parts worn.
■Cam clutch worn or sticking
due to lack of lubricant.
■Lubricating clutch housing.
■Check for excess clutch oil. Clutch cases need
only be half full. Overfilling
can cause drag on high speed clutch parts, ie. a
typical oiled/lubricated wrench requires 1⁄2
ounce of oil.
GREASE LUBRICATED:NOTE: Heat
usually indicates insufficient grease in chamber.
Severe operating conditions may require more
frequent lubrication.

Tool runs slowly. Air flows
slightly from exhaust
■ Motor parts jammed with dirt
particles
■Power regulator in closed
position
■Air flow blocked by dirt.
■Check air inlet filter for blockage.
■ Pour air tool lubricating oil into air inlet as
per instructions.
■Operate tool in short bursts quickly reversing
rotation back and forth where applicable.
■ Repeat above as needed.
Tools will not run. Air flows
freely from exhaust
■One or more motor vanes
stuck due to material build up.
■Pour air tool lubricating tool into air inlet.
■Operate tool in short bursts of forward and/or
reverse rotation where applicable.
■Tap motor housing gently with plastic mallet.
■Disconnect supply. Free motor by rotating
drive shank manually where applicable
Tool will not shut off ■‘O’ rings throttle valve
dislodged from seat inlet valve.
■Replace ‘O’ ring.
Note: Repairs should be carried out by a qualified person.
Parts list

NO DESCRIPTION Q'TY NO DESCRIPTION Q'TY
1 HAMMER CASE 1 25 O-RING 1
3 BUSHING 1 26 REVERSE THROTTLE 1
4 O-RING 1 27 SPRING 1
5 RETAINER 1 28 STELL BALL(φ2.5) 1
6 ANVIL 1 29 EXHAUST DEFLECTOR 1
7 HAMMER FRAMER PIN 1 30 O-RING 2
8 HAMMER FRAMER PIN 1 31 VALVEPAD 1
9 HAMMER FRAME 1
32
O-RING 1
10 ANVIL 2 O-RING 1
11 REAR WASHER 1 BUSHING 1
12 BEARING 1 BUSHING 1
13 CYLINDER 1 33 VALVE STEM 1
14 VANE 7 VALVE 1
15 ROTOR 1 35 SPRING 1
16 REAR BRARING PLATE 1 36 VALVE PAD 1
17 BEARING 1 37 INLET 1
18 SEREW M4 x L90 4 38 SILENCER 1
19 SPRING φ3x10L 1 39 EXHAUST DEFLECTOR 1
20 TRIGGER 1 40 SCREW M4 x L8 4
PIN 1 41 SPRINGφ3x32 1
21 O-RING 1 42 SPRINGφ3x22 1
22 HOUSING 1 43 GASKET 1
23 O-RING 1 44 F/R Switch Gasket 1
24 F/R SWITCH WHEEL 1
