BI 656 Series User manual

Type 12200
Blood Bank Dri-Bath
Operation Manual
and Parts List
Series 656
Model # Voltage
DB12215E 120
DB12215E-60 120
LT656X1 • 10/8/02

IMPORTANT INFORMATION
This manual contains important operating and safety information. You must carefully
read and understand the contents of this manual prior to the use of this equipment.
Safety Information ..............................................................................................................................................3
Alert Signals..................................................................................................................................................3
Warnings ......................................................................................................................................................3
Introduction..........................................................................................................................................................5
Performance Characteristics and Specifications ..........................................................................................5
Intended Use ................................................................................................................................................5
Function ........................................................................................................................................................5
Installation ....................................................................................................................................................5
Operation ............................................................................................................................................................6
10mm (-60) Block Models ............................................................................................................................6
Calibration ..............................................................................................................................................6
12mm Block Models ....................................................................................................................................7
Calibration ..............................................................................................................................................7
Maintenance........................................................................................................................................................8
Cleaning........................................................................................................................................................8
Parts List ............................................................................................................................................................9
Ordering Procedures ........................................................................................................................................10
One Year Limited Warranty ..............................................................................................................................12
2
Table of Contents

Your Barnstead Thermolyne Type 12200 Blood Bank Dri-
Bath has been designed with function, reliability, and
safety in mind. It is the user’s responsibility to install it in
conformance with local electrical codes. For safe opera-
tion, please pay attention to the alert signals throughout
the manual.
Warnings
To avoid electrical shock, always:
1. Use a properly grounded electrical outlet of cor-
rect voltage and current handling capacity.
2. Disconnect from the power supply prior to main-
tenance and servicing.
To avoid personal injury:
1. Do not use in the presence of flammable or
combustible materials. Fire or explosion may
result. This device contains components which
may ignite such materials.
2. Caution: Hot Surface - Avoid Contact. The block
becomes hot while the unit is operating and will
remain hot for some time after the unit is turned
off.
3. Refer servicing to qualified personnel.
3
Safety Information
Caution
Cautions alert you to a possibility of
damage to the equipment.
Warning
Warnings alert you to a possibility of
personal injury.
Note
Notes alert you to pertinent facts and
conditions.
Alert Signals

Please note the following WARNINGS:
This warning is presented for compliance with California
Proposition 65 and other regulatory agencies and only
applies to the insulation in this product. This product
contains refractory ceramic, refractory ceramic fiber or
fiberglass insulation, which can produce respirable dust or
fibers during disassembly. Dust or fibers can cause
irritation and can aggravate preexisting respiratory
diseases. Refractory ceramic and refractory ceramic
fibers (after reaching 1000°C) contain crystalline silica,
which can cause lung damage (silicosis). The Internation-
al Agency for Research on Cancer (IARC) has classified
refractory ceramic fiber and fiberglass as possibly
carcinogenic (Group 2B), and crystalline silica as
carcinogenic to humans (Group 1).
The insulating materials can be located in the door, the
hearth collar, in the chamber of the product or under the
hot plate top. Tests performed by the manufacturer
indicate that there is no risk of exposure to dust or
respirable fibers resulting from operation of this product
under normal conditions. However, there may be a risk of
exposure to respirable dust or fibers when repairing or
maintaining the insulating materials, or when otherwise
disturbing them in a manner which causes release of dust
or fibers. By using proper handling procedures and
protective equipment you can work safely with these
insulating materials and minimize any exposure. Refer to
the appropriate Material Safety Data Sheets (MSDS) for
information regarding proper handling and recommended
protective equipment. For additional MSDS copies, or
additional information concerning the handling of refracto-
ry ceramic products, please contact the Customer Service
Department at Barnstead International at
1-800-553-0039.
4
SAFETY INFORMATION
Warning
Refer servicing to qualified personnel.

Operating Range: Ambient Plus 5°C to 60°C
Temperature Uniformity: + 0.5°C
Temperature Stability: + 0.5°C
Ambient Operating Range: 68-74°F (20-23°C)
Repeatability: + 0.5°C
Factory Calibrated to 37°C.
Heat-up time of unloaded dri-bath from a cold start to
37°C — 20 minutes.
Heat-up time for 40 each 10mm x 75mm or 12mm x
75mm tubes filled to heating block level with water placed
in a preheated block at 37°C — 10 minutes.
Designed for continuous service.
Intended Use
The Type 12200 Blood Bank Dri-Bath provides a con-
trolled dry heat environment for 10mm or 12mm test tubes
containing in vitro diagnostic specimens or samples for
qualitative or quantitative test procedures. Please refer to
the clinical laboratory method specified by the reagent
manufacturer or established by medical technology for
product application.
Function
The Blood Bank Dri-Bath provides incubating tempera-
tures in the range of Ambient Plus 5°C-60°C for 10mm or
12mm test tubes. The -60 units contain wells for 10mm
tubes.
Installation
Remove the incubator from the carton. Check the voltage
specifications and plug into the properly grounded recep-
tacle.
5
Introduction
Model Volts Amps Watts Hz Wells
DB12215E, DB12215E-60 120 .4 47 50/60 40
Performance Characteristics & Specifications

10mm (-60) Block Models
Plug the dri-bath into the properly grounded receptacle.
Insert a calibrated laboratory thermometer* into a 10 x
75mm test tube containing 1.10 mls. of solution. Place the
test tube in a well. Wait the specified time until the ther-
mometer indicates 37°C. You are ready to incubate your
tubes when the thermometer temperature has stabilized
within + 0.5°C.
Calibration
Equipment required:
•Regular tip (slot type).080” screwdriver.
•Test tube — 10 x 75mm.
•Calibrated laboratory thermometer*
*Calibrated for 25mm immersion depth.
Pour 1.10 mls. of solution into the 10 x 75mm test tube.
Insert the thermometer into the tube and place tube in
any dri-bath well. Wait until the dri-bath has come to tem-
perature and stabilized. Insert the screwdriver into the
5/16” calibration port located in the rear of the unit. Turn
the adjusting screw clockwise to increase temperature
and counterclockwise to decrease temperature. One com-
plete turn will change the temperature approximately
10°C. Allow 10 minutes stabilization time between fine
adjustments.
6
Operation
Note
Do not place dri-bath in a draft, sun-
light or near equipment which emits
heat or cold as this may result in fluc-
tuating temperatures.
Test tube liquid levels should not
exceed the level of the well depth.
(25mm).
Placing a full load of cold tubes in the
dri-bath will extend recovery time.Only
10mm test tubes should be used in
the (-60) dri-bath to obtain optimum
results.
Warning
Do not use in the presence of flamma-
ble or combustible chemicals. Fire or
explosion may result; this device con-
tains components which may ignite
such materials. Caution: Hot Surface -
Avoid Contact. The block becomes hot
while the unit is operating and will
remain hot for some time after the unit
is turned off.
Note
Unplug unit when making calibrating
adjustments.

12mm Block Model
Plug the dri-bath into the properly grounded receptacle.
Insert a calibrated laboratory thermometer* into a 12 x
75mm test tube containing 1.25 mls. of solution. Place the
test tube in a well. Wait the specified time until the ther-
mometer indicates 37°C. You are ready to incubate your
tubes when the thermometer temperature has stabilized
within + 0.5°C.
Calibration
Equipment required:
•Regular tip (slot type) .080” screwdriver
•Test tube 12 x 75mm
•Calibrated laboratory thermometer*
*Calibrated for 25mm immersion depth.
Pour 1.25 mls. of solution into the 12 x 75mm test tube.
Insert the thermometer into the tube and place tube in
any dri-bath well. Wait until the dri-bath has come to tem-
perature and stabilized. Insert the screwdriver into the
1/4” calibration port located in the rear of the unit. Turn
the adjusting screw clockwise to increase temperature
and counterclockwise to decrease temperature. One com-
plete turn will change the temperature approximately
10°C. Allow 10 minutes stabilization time between fine
adjustments.
7
OPERATION
Note
Do not place dri-bath in a draft, sun-
light or near equipment which emits
heat or cold as this may result in fluc-
tuating temperatures.
Test tube liquid levels should not
exceed the level of the well depth.
(25mm).
Placing a full load of cold tubes in the
dri-bath will extend recovery time.Only
12mm test tubes should be used in
the dri-bath to obtain optimum results.
Warning
Plug the dri-bath into the properly
grounded receptacle. Insert a calibrat-
ed laboratory thermometer* into a 12 x
75mm test tube containing 1.25 mls. of
solution. Place the test tube in a well.
Wait the specified time until the ther-
mometer indicates 37°C. You are
ready to incubate your tubes when the
thermometer temperature has stabi-
lized within + 0.5°C.
Note
Unplug unit when making calibrating
adjustments.

Cleaning
Unplug incubator. Use a moist cleaning cloth to clean the
painted case and wells. Dry thoroughly.
8
Maintenance

Series 656
Part No. Description No. Req.
120 Volt Models
PC656X1A Control 1
EL656X1A Element 1
BK250X1A Block, Heating 12MM 1
BK250X2A Block, Heating 10 MM (-60 Models) 1
CR598X1 Cord Set 1
PLX97 Light, Pilot 1
9
Parts List

Please refer to the Specification Plate for the complete
model number, serial number, and series number when
requesting service, replacement parts or in any corre-
spondence concerning this unit.
All parts listed herein may be ordered from the Barnstead
International dealer from whom you purchased this unit or
can be obtained promptly from the factory. When service
or replacement parts are needed we ask that you check
first with your dealer. If the dealer cannot handle your
request, then contact our Customer Service Department
at 563-556-2241 or 800-553-0039.
Prior to returning any materials to Barnstead International,
please contact our Customer Service Department for a
“Return Goods Authorization” number (RGA). Material
10
Ordering Procedures

11

One Year Limited Warranty
Barnstead International (“BARNSTEAD”) warrants that if a product manufactured by Barnstead shall be free
of defects in materials and workmanship for one (1) year from the first to occur of (i) the date the product is
sold by BARNSTEAD or (ii) the date the product is purchased by the original retail customer (the
“Commencement Date”). Except as expressly stated above, BARNSTEAD MAKES NO OTHER WARRANTY,
EXPRESSED OR IMPLIED, WITH RESPECT TO THE PRODUCTS AND EXPRESSLY DISCLAIMS ANY
AND ALL WARRANTIES, INCLUDING BUT NOT LIMITED TO, WARRANTIES OF DESIGN, MERCHANT
ABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
An authorized representative of BARNSTEAD must perform all warranty inspections. In the event of a defect
covered by BARNSTEAD’s warranty, BARNSTEAD shall, as its sole obligation and exclusive remedy, provide
free replacement parts to remedy the defective product. In addition, for products sold by BARNSTEAD within
the continental United States or Canada, BARNSTEAD shall provide provide free labor to repair the products
with the replacement parts, but only for a period of ninety (90) days from the Commencement Date.
BARNSTEAD’s warranty provided hereunder shall be null and void and without further force or effect if there
is any (i) repair made to the product by a party other than BARNSTEAD or its duly authorized service repre-
sentative, (ii) misuse (including use inconsistent with written operating instructions for the product), mishan-
dling, contamination, overheating, modification or alteration of the product by any customer or third party or
(iii) use of replacement parts that are obtained from a party who is not an authorized dealer of BARNSTEAD.
Heating elements, because of their susceptibility to overheating and contamination, must be returned to the
BARNSTEAD factory and if, upon inspection, it is concluded that failure is due to factors other than excessive
high temperature or contamination, BARNSTEAD will provide warranty replacement. As a condition to the
return of any product, or any constituent part thereof, to BARNSTEAD’s factory, it shall be sent prepaid and a
prior written authorization from BARNSTEAD assigning a Return Goods Number to the product or part shall
be obtained.
IN NO EVENT SHALL BARNSTEAD BE LIABLE TO ANY PARTY FOR ANY DIRECT, INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES, OR FOR ANY DAMAGES RESULTING FROM LOSS OF
USE OR PROFITS, ANTICIPATED OR OTHERWISE, ARISING OUT OF OR IN CONNECTION WITH THE
SALE, USE OR PERFORMANCE OF ANY PRODUCTS, WHETHER SUCH CLAIM IS BASED ON CON-
TRACT, TORT (INCLUDING NEGLIGENCE), ANY THEORY OF STRICT LIABILITY OR REGULATORY
ACTION.
The name of the authorized Barnstead International dealer nearest you may be obtained by calling 1-800-
446-6060 (563-556-2241) or writing to:
2555 Kerper Boulevard
P.O. Box 797
Dubuque, Iowa 52001-0797
Phone: [phone] or 800-553-0039
Fax: [phone]
E-mail: [email protected]
www.barnstead.com
