Biancheng Electronic Technology BCT-6980 User manual

Wireless Paging System BCT-6980
1. Product Description
2. Parameter & Manual
Transmitter
Pager
Input Power
DC12V/1.5A
Working voltage
Li-ion 3.7V 200mAh
Frequency
433.92MHz
Frequency
433.92MHz
Transmit Power
+23dBm
Standby Current
<12mA
Standby Power
<600mW
Standby Duration
24h
Modulation Type
OOK
Sensitivity
-108dBm
Charging Pagers
20pcs
Max Distance
500m
Max Capacity
998pcs
Alarm Mode
Vibration/Buzzer/Flashing
Keyboard
Touching Pad
Alarm Time
1-999s settable
Material
ABS
Material
ABS
Dimensions
290*155*32mm
Dimensions
100*50*10mm
* The parameters were measured in laboratory. They may vary depend on using cycles and environment.

Note：
1. Press Gear button to enter F1.
2. : Return to the previous menu & Cancel the operation.
3. : In working state, they are used to check recent 10 called numbers. The showing number can be re-called by
pressing CALL. In setting mode, they are used to switch from F1 to F4.
4. In F2, use UP or DOWN buttons to choose from 000 to 010 settings. All pagers must be in the charging slot,
So functions from 004 to 010 can be changed on the pager.
Menu
Instructions
Function
Operation
F1
Pairing
As shown in B part of instructions.
F2
000
Keyboard prompt disabled
In 000 and press call, no beep or vibration on
keyboard when touching.
001
Keyboard only beeps
In 001 and press call, keyboard only beeps when
pressed.
002
Keyboard only shakes
In 002 and press call, keyboard only vibrates when
pressed.
003
Keyboard beeps & vibrates
In 003 and press call, keyboard will beep & vibrate
when pressed
004
Pager, beep mode
In 004 and press call, pager works by beep only.
005
Pager, vibration mode
In 005 and press call, pager works by vibration
only.
006
Pager, LED flash mode
In 006 and press call, pager works by flashing LED
only.
007
Pager, beep + vibration
In 007 and press call, pager works by beep &
vibration both.
008
Pager, vibration + LED flash
In 008 and press call, pager works by vibration &
LED both.
009
Pager, beep + LED flash
In 009 and press call, pager works by beep & LED
both.
010
Pager, beep + vibration + LED
flash
In 010 and press call, pager works by beep &
vibration & LED.
F3
Beep / Vibrate / Flash Time
In F3, 000 is displayed. Input number(1-999) and
press CALL. The prompt time can be set from 1 to
999 seconds.
F4
Keyboard Transmitter ID
In F4, press CALL, and the original ID is displayed.
Input number from 1 to 999 and press CALL can
change the ID. When the ID is changed, all pagers
need to be paired again.
