Biasi B40/6 Specification sheet

PAGE 1
BIASI B/40
LINEAR
6-12 SECTION
REV. H
Please Read Instructions Carefully
Save for uture Reference
Manufactured by:
Manufactured by:Manufactured by:
Manufactured by:
Biasi S.p.A.
Biasi S.p.A.Biasi S.p.A.
Biasi S.p.A.
Verona, Italy
Verona, ItalyVerona, Italy
Verona, Italy
Distributed By:
Distributed By:Distributed By:
Distributed By:
QHT
QHTQHT
QHT
QUI CY HYDRO IC TECH
QUI CY HYDRO IC TECHQUI CY HYDRO IC TECH
QUI CY HYDRO IC TECH OLOGY
OLOGYOLOGY
OLOGY, I C.
, I C., I C.
, I C.
3560 LAFAYETTE RD
3560 LAFAYETTE RD3560 LAFAYETTE RD
3560 LAFAYETTE RD
PORTSMOUTH, H 0380
PORTSMOUTH, H 0380PORTSMOUTH, H 0380
PORTSMOUTH, H 03801
11
1
PHO E: 603
PHO E: 603PHO E: 603
PHO E: 603-
--
-334
334334
334-
--
-6400
64006400
6400
FAX: 603
FAX: 603FAX: 603
FAX: 603-
--
-334
334334
334-
--
-6401
64016401
6401
Boiler Manual And Installation
Instructions for Atmospheric Venting
LINEAR BOILER
If the information in this manual is not followed
e actly, a fire e plosion may result causing property
damage, personal injury or loss of life.
WARNING
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance
• Do not touch any electric switch; do not use any
phone in your building
• Immediately call your gas supplier from another
location. Follow the gas supplier’s instructions.
• If you can not reach your gas supplier call the
fire department
DANGER
All manuals and user guides at all-guides.com
all-guides.com

BIASI B/40
PAGE 2
Dear Customer:
Thank you for buying a Linear commercial boiler.
The Linear is a cast iron, oil or gas fired hot water boiler, using the famous 3-pass design. The
boiler is simple, rugged and engineered for ma imum heating efficiency.
We realize that it is not possible to answer all questions about the Linear series boiler in this
manual. Reading this installation manual does not make the reader an e pert in all aspects of
installation and operation, and does not replace the need for a qualified, licensed heating
contractor. We urge you to contact your installing contractor or distributor if you are in question
about any aspect of your boiler's performance. Our main concern is that you are satisfied with
your boiler and its performance. We require that your contractor complete efficiency tests
using instruments.
The controls and accessories listed in this manual are intended to serve as guidelines rather than
specific recommendations. We realize that other makes and models of such devices are
available and can be used as successfully as those we specify. The installing contractor is the
best judge of a system's specific requirements, as well as the local availability of certain makes
and models of controls and accessories. The preceding does not apply, however, to the
equipment that comes with every boiler, such as the overheat control (L4006E) and pressure
relief valve. The installation of the specific devices supplied with every boiler is absolutely
necessary to the safe operation of the boiler and protection of the heating system.
This Linear boiler has a limited warranty, a copy of which is provided with the boiler. Please
be sure to return the warranty registration card as the warranty will be void without your boiler's
serial numbers, date of installation and the name of your installer being on record in our files.
Thank you for purchasing our B-40 Linear series boiler. If you have questions or comments,
please don't hesitate to contact us immediately. Our goal is 100% customer satisfaction.
All manuals and user guides at all-guides.com

PAGE 3
BIASI B/40
BIASI B-40 Linear Series Section Page
Important Information 1 4
General Information 2 6
Codes and Regulations 3 6
Combustion Air Supply 4 7
Boiler Location 5 7
Boiler Block Assembly 6 8
Boiler Trim Kit Installation 7 8
Boiler Tapping Diagram - 9
Burner Set-up 8 10
Gas Piping 9 12
Breeching and Chimney 10 14
Piping 11 15
Boiler Jacket Assembly 12 17
Boiler Jacket E plosion Diagram - 18
Wiring 13 19
B-40 Control Panel Wiring 20-23
Commissioning 14 24
Maintenance 15 24
Installer Notes 16 25
TABLE OF CONTENTS
All manuals and user guides at all-guides.com

BIASI B/40
PAGE 4
IMPORTANT IN ORMATION
Please read this page carefully.
ALL BOILERS MUST BE INSTALLED IN ACCORDANCE WITH NATIONAL, STATE AND
LOCAL PLUMBING, HEATING AND ELECTRICAL CODES AND ORDINANCES, AS WELL AS
THE REGULATIONS OF THE SERVING ELECTRICAL, WATER AND GAS UTILITIES.
All systems should be designed by competent contractors, and only persons knowledgeable in the
layout and installation of heating systems should attempt the installation of any boiler.
It is the responsibility of the installing contractor to see that all controls are correctly installed and
operating properly when the installation is completed.
Do not burn volatile garbage, gasoline, naphtha or other flammable liquids other than No. 2 fuel
oil. All flammable liquids (especially gasoline), chemicals, rags, paper, wood scraps, debris, etc.,
should be kept away from the boiler at all times. Keep the boiler area clean and free of all fire
hazards.
Please read the literature and warranties supplied by the manufacturers of the various accessory
equipment. This equipment is warranted by the respective manufacturers, not by Quincy Hydronic
Technologies, Inc. Each piece of equipment must be installed and used according to the
recommendations of the manufacturer.
This Linear boiler has a limited lifetime warranty, a copy of which is printed on the back page of this
manual.
All manuals and user guides at all-guides.com

PAGE 5
BIASI B/40
Any appliance that burns natural gas, propane gas, fuel oil, wood or coal is capable of producing
carbon mono ide (CO). Carbon Mono ide (CO) is a gas which is odorless, colorless and tasteless but
is very to ic.
If your BIASI B-40 boiler is not working properly, or is not vented properly, dangerous levels of CO
may accumulate. CO is lighter than air and thus may travel throughout the building. BRIE
EXPOSURE TO HIGH CONCENTRATIONS O CO, OR PROLONGED EXPOSURE TO
LESSER AMOUNTS O CO MAY RESULT IN CARBON MONOXIDE POISONING.
EXPOSURE CAN BE ATAL AND EXPOSURE TO HIGH CONCENTRATIONS MAY
RESULT IN THE SUDDEN ONSET O SYMPTOMS INCLUDING UNCONSCIOUSNESS.
Symptoms of CO poisoning include the following:
Dizziness Vision problems Shortness of breath
Headache Loss of muscle control Unclear thinking
Nausea Weakness Unconsciousness
The symptoms of CO poisoning are often confused with those of influenza, and the highest incidence
of poisoning occurs at the onset of cold weather or during flu season. A victim may not e perience
any symptoms , only one symptom, or a few symptoms. Suspect the presence of carbon mono ide if
symptoms tend to disappear when you leave your home.
The following signs may indicate the presence of carbon mono ide:
* Hot gasses from appliance, venting system, pipes or chimney,
escaping into the living space.
* Flames coming out around the appliance.
* Yellow colored flames in the appliance.
* Stale or smelly air.
* The presence of soot or carbon in or around the appliance.
* Very high une plained humidity inside the building.
If any of the symptoms of CO occur, or if any of the signs of carbon mono ide are present, VACATE
THE PREMISES IMMEDIATELY AND CONTACT A QUALI IED HEATING SERVICE
COMPANY OR THE GAS COMPANY AND THE IRE DEPARTMENT.
To reduce the risk of CO poisoning, have your heating system "tuned up" by a licensed heating
contractor or the gas company - preferably before each heating season. Also have the service
company check your chimney or vent pipes for blockage.
The building should be adequately ventilated, particularly if you have tightly insulated your home.
ONLY QUALI IED, LICENSED SERVICE CONTRACTORS SHOULD PER ORM WORK
ON YOUR BIASI B-40 BOILER.
WARNING
All manuals and user guides at all-guides.com

BIASI B/40
PAGE 6
The Linear series are wet base design, sectional, cast-iron boilers for forced hot water heating
systems. The Linear boilers are designed for firing with oil and deliver high efficiencies through
unique design and construction.
The Linear series boilers are shipped from the factory in assembled blocks and each boiler can
range from 6 to 12 sections. The sections can then be disassembled before delivery to the jobsite by
QHT and then field assembled. The boiler jacket, burner and controls are packed separately for
shipping.
Note: All equipment should be inspected upon delivery, and any damage or shortage should
be reported immediately.
Boiler
Model
Number
Number of
Sections
Heating
Capacity
Input
Oil
G.P.H.
Input
Gas
MBH
Net Output
MBH Efficiency %
Water
Content
Gals.
Length
(L) inches
Weight
(LBS)
B40/6 6 265 2.20 308 230 86.0 17 34.8 902
B40/7 7 352 2.90 406 305 86.7 20 39.5 1023
B40/8 8 437 3.60 504 380 86.8 23 44.4 1144
B40/9 9 524 4.30 602 456 87.0 26 49.2 1265
B40/10 10 610 5.00 700 532 87.2 28 53.9 1386
B40/11 11 696 5.70 798 607 87.2 31 58.8 1507
B40/12 12 783 6.40 896 684 87.4 34 63.8 1628
Ma imum Water Working Pressure 72 psi Ma imum Relief Valve is 50 psi @ 900 MBH
2. General Information:
Installation of the boiler, burner, oil tank and related equipment must conform to national,
state and local regulating agencies and codes applicable to the installation of the equipment. In the
absence of local requirements, the following codes apply:
•
••
• ANSI/N PA - #31 Installation of Oil Burning Equipment
•
••
• ANSI/N PA - #70 National Electric Code
•
••
• ANSI/N PA - #211 Chimneys and Vents
The above codes are available from:
National Fire Protection Association (NFPA)
Battery March Park
Quincy, Massachusetts, 02269
3. Conforming to Codes and Regulations:
All manuals and user guides at all-guides.com
all-guides.com

PAGE 7
BIASI B/40
Locate the boiler to provide sufficient clearance for inspection, servicing and maintenance.
Minimum clearance to construction or combustible materials shouldn't be less than si (6) inches from
the top, sides and rear of unit, and eighteen (18) inches from the flue pipe in any direction. Front
clearance should be at least twenty four (24) inches. When choosing a location for the boiler, take
into consideration the 12” supply manifold on the back of the boiler. Adequate space must be given to
pipe the manifold in and for the smoke pipe to clear the manifold. Greater distances for ease of access
should supersede fire protection clearances. The boiler must be located on a non-combustible floor. A
smooth, level concrete floor is recommended. Locate the boiler as close as possible to the chimney. If
boiler is installed on combustible flooring, consult local authorities for proper method of covering
floor. The boiler must not be installed on carpeting.
Caution: Do not store or use flammable materials, chemicals or flammable liquids,
especially gasoline, in the vicinity of this heating appliance.
The boiler location must provide air for proper combustion and ventilation of the surrounding
area. To burn efficiently, oil requires 30 CFM/GAL. In general, boiler rooms should incorporate two
(2) permanent air supply openings, one commencing within 12 inches of the ceiling, and one
commencing within 12 inches of the floor. These openings should freely communicate with the
outdoors.
OUTSIDE AIR: When combustion air is supplied directly through an outside door or wall,
each opening shall have a free area of one square inch per 4,000 BTUH input for the total input of all
the appliances in the enclosure.
INSIDE AIR: When combustion air is supplied from inside the building, each opening shall
have a free area of one square inch per 1,000 BTUH input for the total of all appliances in the
enclosure. In no case shall the openings be less than 105 square inches each.
In both cases, check manufacturers ratings for louver net free area, and correct for screen
resistance to net free area.
If the boiler is to be installed where the operation of e haust fans, attic fans, kitchen
ventilation systems, clothes dryers or fireplaces may create severe negative vent pressures causing
unsatisfactory combustion and venting, special provisions should be made for additional make-up air
to supply the other air requirements. If building is of tight construction, combustion air requirements
may not be met and combustion air ducts from outside may be necessary. Please refer to NFPA No.
31.
Do not install the boiler until the proper combustion air has been arranged
4. Combustion Air Supply:
5. Boiler Location:
All manuals and user guides at all-guides.com

BIASI B/40
PAGE 8
All Linear series boilers are shipped either as an assembled boiler block or a knock-down
boiler block. If the block came unassembled, or if the assembled block needs to be split for installa-
tion purposes, please read the following:
To assemble split blocks, move the sections into a line facing each other. Sections may be slid
along boards placed underneath the sections. Inspect nipple ports for damage or burrs. Remove any
burrs by brushing the port very lightly. Wipe the push nipples and nipple ports with a clean cloth.
Apply a film of nipple compound to both the nipple and port. Install the nipple in the port and then
seal it by hitting it with a rubber mallet. Apply section sealant to one section only and slide sections
together. If the boiler came in sections, you will want to draw the sections together 2 or three at a time
to insure that the blocks are coming together properly. Install the four draw rods and draw the sections
together evenly (measure with yardstick). The longer draw rods should be installed on the top of the
boiler. The shorter draw rods are installed on the bottom of the boiler. The bottom draw rods should
not e tend past the front section. Draw the sections together until sections make iron-to-iron contact
at a point around the top and bottom ports of each section. Check to insure that the combustion cham-
ber is sealed using a flash light or other lighting device. Place the flashlight into the combustion
chamber and look for light on the floor or surrounding walls (this is best done in a dark room). If light
appears out of the boiler use a high temperature caulk to fill in the gaps between the block sections.
DO NOT OVER TIGHTEN DRAW RODS
6. Boiler Block Assembly:
The BIASI B-40 Boiler Trim Kit includes the following components.
The above mechanical components should be installed following the diagram of the boiler
tappings on the following page. The installation of the above wiring components (wiring harness) will
be described in the wiring portion of this installation manual.
7. Installation of Boiler Trim Components:
1— Honeywell L4006 E Aquastat
1— 3/4” X 3” Nipple
1— 3/4” Elbow
1— 50 PSI Pressure Relief Valve
1— Immersion Well
1— Four Wire Mole Wire Harness
1— Pressure/Temperature Gauge
1— 3/4” Boiler Drain
1— 1/4”X3/4” Bushing
1— 2 1/2” MPT Supply Manifold
1— 2 1/2” MPT Return Manifold
All manuals and user guides at all-guides.com

PAGE 9
BIASI B/40
Figure 1:Diagram illustrating the location and function of the front and rear boiler tappings.
Boiler Model Length (L)
B-40/6 34.8”
B-40/7 39.5”
B-40/8 44.5"
B-40/9 49.2"
B-4/10 53.9"
B-4/11 58.8"
B-4/12 63.9"
2.5” MPT Return
2.5” MPT Supply
8” Breech
Control Panel with
operating aquastats
All manuals and user guides at all-guides.com

BIASI B/40
PAGE 10
Good, reliable operation with a minimum of service starts with attention to the small details:
1. Setting the nozzle position and electrodes "by the book" using the manufacturer's gauges.
2. Installing a quality micron filter at the burner.
3. Making careful/tight flare connections without couplings on oil suction line.
4. Checking fuel pump pressure.
5. Checking draft at the breeching to insure it is adequate to overcome flue gas resistance.
6. Setting the air band properly with well maintained instruments. A good target is 11% to 12.5% of (CO
2
) or 6.5%
to 3.8% of (O
2
).
Note: Oil and Gas burners on B40-series boilers cannot be properly commissioned without instruments and gauges.
The following information applies only to the BIASI B-40 series boilers at a ma imum output
for power venters or lined chimneys only.
8. Burner Setup:
BURNER MANUFACTURER Heatwise
Boiler Model B-406 B-407 B-408 B-409 B-410 B-411 B-412
B rner Model P2- A P2- P2- DE-10 DE-10 DE-10 DE-10
Firing Rate 2.2 GPH 2.8 GPH 3.5 GPH 4.25 GPH 5.0 GPH 5.7 GPH 6.4 GPH
Insertion Depth FULL FULL FULL FULL FULL FULL FULL
Nozzle 2.00 X 45 2.25 X 60 2.75 X 60 3.25 X 60 3.75 X 60 4.5 X 45 5.50 X 45
Spray Pattern solid solid solid solid solid solid solid
P mp Press re 140 psi 170 psi 175 psi 175 psi 175 psi 160 psi 140 psi
Head Position 12 16 18 1 1.5 2 2.5
Air Setting 11.50 15.00 18.00 3.5 4.5 5.5 6.75
BURNER MANUFACTURER Riello
Boiler Model B-406 B-407 B-408 B-409 B-410 B-411 B-412
B rner Model F-10 F-10 F-15 F-15 F-15 F-20 F-20
Firing Rate 2.4 GPH 2.6 GPH 3.3 GPH 4.0 GPH 4.6 GPH 5.3 GPH 5.9 GPH
Insertion Depth 4.5" 4.5" 4.5" 4.5" 4.5" 4.5" 4.5"
Nozzle 2.00X60 2.00X60 2.50X60 3.00X60 3.50X60 4.0X60 4.5X60
Spray Pattern B B B B B B B
P mp Press re 145 PSI 175 PSI 175 PSI 175 PSI 175 PSI 175 PSI 175 PSI
T rb lator 3.75 4.5 1.8 2.1 2.8 3.1 5
Air Gate 5 6 3 4 5.5 4 6
BURNER MANUFACTURER Beckett
Boiler Model B-407 B-407 B-408 B-409 B-410 B-411 B-412
B rner Model CF 375 CF 375 CF 500 CF 500 CF 800 CF 800 CF 800
Firing Rate 2.1 GPH 2.7 GPH 3.2 GPH 3.7 GPH 4.3 GPH 4.8 GPH 5.3 GPH
Insertion Depth 4.5" 4.5" 4.5" 4.5" 4.5" 4.5" 4.5"
Nozzle 1.75X60 2.00X45 2.75X45 2.75X45 3.25X45 4.0X30 4.0X30
Spray Pattern ES hollow solid solid solid solid solid
P mp Press re 140 psi 180 psi 140 psi 180 psi 175 psi 145 psi 180 psi
Head Type
Head Position 0 2 3 4.5 3 3 4.5
Air Setting 9/0 3/1 7/0 10/0 7/0 8/0 10/2
All manuals and user guides at all-guides.com

PAGE 11
BIASI B/40
BURNER MANUFACTURER Heat Wise
Boiler Model B-406 B-407 B-408 B-409 B-410 B-411 B-412
B rner Model SU-3 SU-3 SU-4 SU-5 SU-5 SU-6 SU-6
F el Natural Natural Natural Natural Natural Natural Natural
Inp t 315 420 499 577 672 847 954
Min. Gas Inlet Size 1" 1" 1" 1" 1" 1" 1-1/4"
Manifold in w.c. 1.95" 3" 3.5" 2" 2.8" 1.16" 1.4"
Air 9.5 14 21 7.5 9 4.25 5
Head 6 11 20 2" 2" 2-5/8" 2-5/8"
BURNER MANUFACTURER Heat Wise
Boiler Model B-406 B-407 B-408 B-409 B-410 B-411 B-412
B rner Model SU-3 SU-3 SU-4 SU-5 SU-5 SU-6 SU-6
F el Propane Propane Propane Propane Propane Propane Propane
Inp t 315 420 527 634 740 847 954
Min. Gas Inlet Size 3/4" 3/4" 1" 1" 1" 1" 1"
Manifold in w.c. 1.65" 2.4" 2.75" 1" 1.27"
Air 7.25 15 21.5 5.2 5.8
Head 6 10 18 2" 2" 2-5/8" 2-5/8"
The following information applies only to the BIASI B-40 series boilers at a ma imum output
for power venters or lined chimneys only.
8. Burner Setup:
Good, reliable operation with a minimum of service starts with attention to the small details:
1. Setting the electrode and flame rod settings against manufacturer's specs to insure proper operation.
2. Installing properly sized gas piping according to BTU input required and length of gas line run.
3. Making sure there is proper manifold pressure before and after the gas valve using a calibrated manometer.
4. Checking draft at the breeching to insure it is adequate to overcome flue gas resistance.
5. Setting the air band properly with well maintained instruments. A good target is 9.5% to 10.5% of (CO
2
) or 5%
to 2.5% of (O
2
) for natural gas, or 10% to 12% of (CO
2
) or 5% to 2.5% of (O
2
) for lp gas
Note: Oil and Gas burners on B40-series boilers cannot be properly commissioned without instruments and gauges.
To determine how much gas is coming into the
burner, or to set the gas meter correctly, the follow-
ing formula can be used.
The chart to the right can be used to determine the
flow rate depending upon the time per revolution and
the size of the gas meter dial.
Ft
3
/hr = [3600/(sec. Per rev.)]*(Size of gas meter)
Size of Gas Meter Dial
(Cubic Foot)
0.5 1 2
20 90 180 360
25 72 144 288
30 60 120 240
35 51 103 206
40 45 90 180
45 40 80 160
50 36 72 144
55 33 65 131
60 30 60 120
Seconds per
Revolution
All manuals and user guides at all-guides.com
all-guides.com

BIASI B/40
PAGE 12
To check for
gas leaks, use
a gas detector
or apply a
soap solution
to the joints.
DO NOT USE AN
Direction of
flow
Manual Shutoff Valve
Height of shutoff valve
above ground level to
conform to local codes,
Pressure Gauge
Port
(1/8” NPT plugged)
Minimum
1” X 1” X 1” Tee Male Union 1” NPT
Burner Gas
Pipe Cap
3” MINIMUM
INSTALLATION O SEDIMENT TRAP AND BURNER SUPPLY
Gas supply piping is to be sized and installed properly in order to provide a supply of gas sufficient
to meet the ma imum demand without undue loss of pressure between the meter and the boiler. It is
advisable to run a separate gas line from the meter to the gas burner to avoid pressure drops. Consult
with the National uel Gas Code ANSI Z223.1 for proper sizing of gas piping for various lengths and
diameters.
Locate a drop pipe adjacent to, but not in front of the boiler. Locate a tee in the drop pipe at the
same elevation as the gas inlet connection to the boiler. E tend the drop line with a nipple towards the
floor and cap to form a sediment trap. Install a tee handle shut off valve before the tee with sediment
trap and a union after the tee before the combination gas valve.
When installing the boiler, Use black steel pipe and malleable fittings (do not use cast iron parts) with
a suitable pipe dope which is resistant to liquefied petroleum gases.
Check piping for leaks. Always check leaks with a water and soap solution. DO NOT USE A
FLAME FOR CHECKING GAS LEAKS
The boiler and its individual shut-off valve must be disconnected from the gas supply piping
during any pressure testing of that piping at test pressures in e cess of 1/2 psi.
9. Gas Line Piping
All manuals and user guides at all-guides.com

PAGE 13
BIASI B/40
Piping should consist of:
1. A shut off valve appro imately 6’ away from the unit.
2. A 1/8” plugged NPT tapping for gas pressure measurement preferably on the manual
shut-off valve (as shown or anywhere between the gas valve and the shut off value).
Note: he manual shut off valve and tapping are NO part of the SU-4 Gas Burner.
Please make sure you conform to local and state codes.
3. A gas union.
4. A drip pipe.
Caution: he gas valve should not be subjected to more than ½” PSIG. herefore, the
burner should be isolated during high-pressure gas leak tests. The appliance and its
individual shut off valve must be disconnected from the gas supply piping system
during any pressure testing of that system at test pressures in e cess of ½ psig. The
appliance must be isolated from the gas supply piping by closing its individual man-
ual shut off valve during any pressure testing of the gas supply piping system at test
pressures equal to or less than ½ psig.
INSTALLATION O SEDIMENT TRAP AND BURNER SUPPLY
All manuals and user guides at all-guides.com

BIASI B/40
PAGE 14
The B-40 Linear boiler is a high efficiency unit that requires proper venting. The boiler must
be vented to the outdoors by means of a tile lined masonry or an approved pre-fabricated chimney of
the size and height recommended by the manufacturer or by a listed "power venting" unit which
provides draft by mechanical venting .
The chimney discharge opening must be located at least 24 inches above any part of the
building structure within 10 feet of the chimney. Be sure the chimney and smoke pipe don't become
obstructed by squirrels, bird nests, soot buildup, chimney liner deterioration, etc. The "power ventor"
system should be installed on the leeward side of the building. Very specific requirements must be
met concerning clearances from combustibles and distances from doors and windows. Please consult
with manufacturer of "power ventor" for this information. In any case, the "ventor" must be installed
by a licensed burner mechanic and done in accordance with local codes. The B-40 boiler is a very low
stack temperature boiler (between 320 and 400F gross stack temp.) so caution should be used when
connecting to an outside built chimney. Should you have concern that the flue gases could condense,
then you should consider using a listed, "power venting" unit. If "power venting" is used to discharge
flue gases, then the power vent unit should be equipped with a postpurge control as well as delay-off,
timing control to prevent problems with fogging and nozzle post drip.
Note: 88% steady state efficiency is achieved when flue gas contains over 12.5% CO2 and the gross
stack temp. is below 350F.
The smoke-pipe connection from the boiler to the chimney should be as short as possible, with
a minimum number of elbows. The vent pipe must have a vertical rise of at least 1/4 inch per foot of
horizontal run. The vent pipe must be of the same diameter as the flue outlet on the boiler. The
chimney connector should have a minimum thickness of 24 gauge, corrosion resistant (galvanized)
steel, assembled with a minimum of three (3) sheet-metal screws, and sealed with high temperature
silicon at each joint. In most cases a barometric draft control isn't recommended as the B-40 is
designed to be pressure-fired. However, one may be needed if the boiler is being used in a high draft
situation.
10. Breeching and Venting:
All manuals and user guides at all-guides.com

PAGE 15
BIASI B/40
All piping must conform to state and local codes.
The supply and return manifolds for B-40 Linear boilers are 2 1/2” male NPT. Be sure to
provide unions and gate valves at the manifold inlet and outlet of the boiler, so the boiler may be
readily isolated for service.
Install the provided pressure relief valve so the discharge is piped directly to a drain, if
possible. If not, the discharge should be piped to the floor. In either case, the discharge pipe should be
of the same diameter as the outlet of the relief valve, with no valves or obstructions to impede
overflow from the boiler. The installation locations on the manifold for the Pressure Relief Valve, the
Temperature/Pressure Gauge as well the Honeywell L4006E Aquastat can be seen on the following
page.
Install manual and/or automatic air venting devices at the high points in the system to eliminate
trapped air.
The weight of all piping should be supported by suitable hangars and floor stands, not by the
boiler.
It is recommended that the make-up water line have a backflow preventer and a pressure-
reducing valve to reduce line pressure to 10 to 15 psi installed adjacent to the boiler.
NOTE: If the heating system is to be filled with antifreeze, use only formulations e pressly made for
hydronic heating systems (such as propylene glycol). Do not use automotive types of antifreeze
(ethylene glycol). Use of antifreeze will alter system output and characteristics. Consult factory rep's
for details or assistance.
Clearance for hot water pipes are 1 inch to combustibles.
11. Piping:
1. Pierce a 5/8” hole into the vent pipe near the appliance outlet. Remove one of the securing nuts
from the pipe of the safety switch. Tighten the other securing nut onto the pipe as far as possible.
2. Insert the threaded pipe end into the pierced hole, then install the securing nut, then install the se-
curing nut, which was removed in step 1, and tighten securely.
3. Please consult the wiring section of this manual for the wiring of the blocked flue switch.
10. Blocked lue Switch:
All manuals and user guides at all-guides.com

BIASI B/40
PAGE 16
All manuals and user guides at all-guides.com
all-guides.com

PAGE 17
BIASI B/40
NOTE: All piping, boiler controls, gauges and valves must be installed before the jacket has been
assembled on the boiler. Refer to the following page to clarify these boiler jacket assembly
instructions.
Insert the separate piece of insulation (# 92) on top of boiler so the entire top and sides of boiler
are covered. Use plastic strapping to secure the insulation in place. Mount the panel installation
bracket (#82) onto the draw-rods on the upper front of the boiler. Install the si spacers (#86) onto the
draw-rods. Two on the upper draw rods in the front and the remaining spacers onto the draw-rods in
the back of the boiler. Install the rear insulation (#101) onto the boiler. Place the side panels (#66,52)
onto the boiler making sure the draw rod spacers are between the side panels and the boiler casting.
Tighten the sides of the casing to the panel installation bracket (#82) using sheet metal screws. Screw
two studs (#90) into the bottom front of the boiler and screw on the threaded he spacers (#87) onto
the studs. Attach the lower mounting bracket (#83) to the boiler by using two bolts (#89) and screw-
ing them into the threaded he spacers. Then using sheet metal screws, attach the lower mounting
bracket to the sides of the casing. Slide the control panel (#110) onto the casing from the top and se-
cure it to the control panel support (#82) using sheet metal screws. Attach the rear panels (#84,85)
using sheet metal screws. Place the top panel (#76) onto the sides of the casing and assure that the
pins on the sides are aligned with the retaining holes on the top casing panel. Finally attach the front
panel (#81) onto the casing by aligning the retaining pins with the retaining holes. Push to insure a
positive connection.
12. Boiler Jacket Assembly:
Boiler Components &
Parts Vega B40 - Series
Boiler Jacket Assembly:
Part# Description
84,85 — Rear Jacket Panels
*1
92,101— Insulation
52 — Right Jacket Panel
66 — Left Jacket Panel
83 — Front Jacket Supports
110 — Control Panel
82 — Control Panel Support
76 — Top Jacket Panel
81 — Front Jacket Panel
*2
*1
Rear insulation not attached, but
included with the casing
*2
Front insulation attached to the
casing
76
101
All manuals and user guides at all-guides.com

BIASI B/40
PAGE 18
1 2 3 4 5
6 7 8 9
1 On/Off Switch
2 Min. Boiler Temp. Thermostat
3 Ma Boiler Temp. Thermostat
4 Thermostat By-Pass Button
5 Circulator Switch
6 Boiler On/Off Signal Lamp
7 Temperature Gauge
8 Manual Reset High Limit
9 Burner Lock Out Signal Lamp
* NOTE: If the thermostat test button is closed, the thermostats will be bypassed and the burner
will not shutoff until the boiler reaches the manual high limit.
The electricity to the boiler shall come from a dedicated breaker in the electric service bo . A
service switch should be mounted on the side of the boiler so the burner man can service the burner
and controls. The electrical wiring should be routed so as not to interfere with normal servicing of the
boiler. Wiring done in the field between devices not attached to boiler shall conform with the
temperature limitations for type T wire (63F/35C) or other specified wire as applicable when installed
in accordance to manufacturer's
instructions and wiring diagrams.
Please refer to the wiring section of this manual for instructions on wiring the supplied control
panel.
13. Wiring:
All manuals and user guides at all-guides.com

PAGE 19
BIASI B/40
1 2 3 4 5
6 7 8 9
1. On/Off Switch — Turns power to control panel on and off and will disable power to the burner
assuming the panel is wired correctly.
2. Minimum Boiler Temperature Thermostat — Maintains a minimum boiler temperature be-
tween 50 degrees F and 170 degrees F.
3. Maximum Boiler Temperature Thermostat — High limit temperature setting for boiler be-
tween 50 degrees F and 205 degrees F.
4. Thermostat Test Button — This button jumps out both thermostats allowing a technician to eas-
ily start the burner for testing if there is no call for heat. Warning, with both thermostats disabled
the only high limit left will be the manual high limit.
5. Circulator Switch - Supplies power to boiler circulator or relay panel. It is not suggested to use
this switch and it is not utilized in any of the suggested wiring diagrams in this manual.
6. Boiler On/Off Signal Lamp — Signal lamp to indicate whether main power switch is turned on
or off.
7. Temperature Gauge - Temperature gauge which takes temperature reading from top front of
boiler.
8. Manual Reset High Limit - Safety high limit that is set to 214 degrees F. If the manual high
limit is tripped, use a flat head screw driver to protective cap on reset button. Then depress reset
button making sure that it stays depressed once you have removed your finger. Once the switch is
reset replace the protective cover.
9. Burner Lock Out Signal Lamp - Lamp to indicate if the burner has gone out on lockout.
CONTROL PANEL DESCRIPTION
All manuals and user guides at all-guides.com

BIASI B/40
PAGE 20
B-40 Control Panel Wiring Diagram for Beckett/Heat Wise Oil Burner 24V
CIRCULATOR RELAY
BURNER CONTROL
All manuals and user guides at all-guides.com
