PN# 13-316
TireGard™ Trike
Wireless Tire Pressure Monitoring System
Table of Contents
Precautions 2
TireGard™ Trike Features & Benefits 2
Controls 3
LCDReceiver/MonitorIconDescriptions 4
1.SystemMap 4
2. Setup of LCD Receiver/Monitor 5
3. Installation of the Front and Rear Sensors 6
Anti –Theft Ring for Sensors (installation is optional) 8
OperationInstructions 9
1. LCD Receiver/Monitor basic functions 9
2. Advanced setting mode 9
Operatingprocedure 11
Definition of Warnings 12
Troubleshooting 12
PackageContent 13
ProductSpecifications 14
Warranty 14
2

3
PRECAUTIONS
1. Make sure the LCD receiver/monitor can receive signals from all of the tire pressure sensors.
2. TireGard™ Trike WTPMS has a unique anti-theft device to prevent the sensors from being stolen.
3. Please confirm that all sensors are fitted tightly. If necessary, spread detergent water on the valve
stem to check for any air leakage. DO NOT OVER TIGHTEN SENSORS.
4. If tire pressure is low or dropping quickly, stop the trike immediately determine the problem.
5. The monitor will automatically make a connection with the sensors. It is normal that tire pressure
figures might not be updated immediately due to changes of tire pressure.
6. TireGard™ Trike WTPMS is designed to avoid interfering or being interfered with by other signals.
7. Many environmental factors can cause tire temperature rise or fall. For example, hot weather or a
warm tire will result in rising tire pressures.
8. The LCD Receiver/Monitor is NOT waterproof. If the LCD Receiver/Monitor accidentally gets wet,
don’t “power on” the system until it is completely dried.
TireGard™ Trike FEATURES & BENEFITS
The TireGard™ Trike Wireless Tire Pressure Monitoring System (WTPMS) is a powerful and
effective tool for maximizing safety, increasing fuel economy, improving vehicle handling, and reducing
operating cost. Through its wireless technology, tire pressure and temperature information is displayed
instantly on the easy to read Graphic User Interface (LCD Receiver/Monitor) in real time.
Do It Yourself (D.I.Y.) installation is quick and easy without any technical knowledge or special
equipment.
Wireless technology allows the Sensor and Monitor to connect automatically.
Real-time highly accurate sensor and monitor with powerful Graphical User Interface.
Fully adjustable pressure and temperature warning range with vibration and/or audible tone which
immediately alerts operator through the LCD Monitor of abnormal tire pressure or temperature.
Anti-Theft Ring to prevent removal of sensor.
Sensors and Monitor are battery powered with a low battery indicator on the LCD monitor which
will instantly alert rider of batter power status.

CONTROLS
LCD Receiver/Monitor Controls Description
4
Antenna
LCD monito
r
Sensor Description
SET
Power switch
Mute
Backli
g
h
t
T
e
m
pe
rat
u
r
e
Battery cover
Cover lock
Front of monitor Back of monito
r

LCD RECEIVER/MONITOR ICON DESCRIPTIONS
1. System Map
5

1. Setup of LCD Receiver/Monitor
Insert Battery:
A. One AAA battery is required.
B. To remove battery cover and follow the directions A and B on the picture shown
below.
C. Insert AAA battery properly.
D. After battery is inserted, the LCD Receiver/Monitor will issue a beep as it
automatically powers up.
E. Reinstall the battery cover onto LCD Receiver/Monitor.
6

2. Installation of the Front and Rear Sensors
Each sensor is designed specifically for the front and rear tires, you have to make sure they are
installed in their specified positions. When inserting the batteries into the sensors, do not mix up the
Front and Rear sensor caps. Each sensor is marked on its cap and within its body indicating its position
on the motorcycle.
Insert Batteries in Sensors
Battery installation for tire pressure sensor
A. Remove sensor cap by rotating counter-clockwise.
B. When inserting lithium battery make sure battery polarity is correct.
Immediately the LCD Receiver/Monitor will receive signals from the corresponding sensors and report
the pressure value on the screen. At first, you will find the value shows “00.0”. It is because sensors have
not been mounted yet.
7

Note: After removing the battery, you will need to let the system reset. Please allow it to sit for 10
seconds before inserting the battery again.
A. Install sensor cap by rotating clockwise.
Please ensure the sensors are in the correct (1, 2, or 3) position. Don’t mix up sensor caps. Both sensor
cap and sensor body have reference marks indicating position.
(1, 2, or 3) for example
8

Anti –Theft Ring for Sensors: (installation is optional)
Anti –Theft ring is designed to prevent the possibility of sensors being easily stolen.
A. Place the Anti-Theft Ring onto the valve stem.
B. Install sensor onto valve stem. Don’t over tighten the sensor as it may become damaged.
C. Adjust the Anti-Theft Ring position to seat it with the sensor firmly in place.
D. Insert the hex socket screw into the Anti-Theft Ring.
(Don’t exert excessive pressure or damage to the valve may occur.)
E. When all of the tire pressure sensors are installed, check for air leaks using detergent water.
(Spread detergent water on the valve stem and watch for bubbles.) If the tire pressure sensors
and tire valves are properly fitted no air will be leaking from the system.
9

OPERATING INSTRUCTIONS
1. LCD Receiver/Monitor basic functions
Set: Pressure unit setting
Temperature unit setting
Pressure warning value setting
Temperature warning value
Power switch: On / Off
Mute: On/ Off
Backlight
Temperature
2. Advanced setting mode
Press for 3 seconds to enter advanced setting mode.
Make your choices by pressing and these will adjust values up or down.
10

A. Set tire pressure measuring: Four types of pressure measuring units are available; PSI, KPA, BAR
and ... Users can make their own choices by pressing the thermometer button and the
star button .
B. Set tire temperature measuring: Adjust setting by pressing the thermometer button and star button
for adjusting up or down. Celsius and Fahrenheit are provided.
C. Setting low tire pressure: Adjust setting by pressing the thermometer button and star button for
adjusting up or down. The default value is 26 P.S.I.
D. Setting high tire pressure: Adjust setting pressing the thermometer button and star button for
adjusting up or down. The default value is 45 P.S.I.
E. Setting tire upper temperature warning value: Adjust setting pressing the thermometer button and
star button for adjusting up or down.
F. Setting tire low pressure: Adjust setting pressing the thermometer button and star button for
adjusting up or down.
Sensor learning mode
In the unlikelihood the sensor is broken or missing, the sensor learning mode provides a low cost
alternative to replace damaged or lost sensors. These ‘learnable sensors’ are available separately. The
LCD receiver/monitor can reload new sensors and the system will integrate this sensor information into
its system and will overwrite the replaced sensors information. Pressing the power switch and the SET
button at the same time for 3 seconds will activate the systems ‘learning mode’, and TireGard™ Trike
will start to recognize new sensors.
11

12
OPERATING PROCEEDURES
1. Initialization
Switch on LCD RECEIVER/monitor to boot up, LCD RECEIVER/monitor will be communicating with
sensors and showing the last tire pressure values before system was turned off.
2. Main Screen
After booting up, TireGard™ Trike will enter main screen mode. Most of time, your system will stay in
this mode and respond with the latest figures for both tire pressure and temperature. In this mode, you
will find the antenna icon will be flashing.
3. Automatic Power Off
A. After power on, if there is no signal from the sensors for 20 minutes the system will turn off.
B. The system will turn off if no signal is received for more than one hour after the last signal
update.
4. Abnormal StatusAlerts
The LCD receiver/monitor will beep and vibrate once in 10 seconds and repeat 5 times when:
A. Tire pressure is below low warning value.
B. Tire pressure is higher than upper warning value.
C. Tire temperature higher than upper warning value.
The LCD receiver/monitor will show low battery icon when:
D. LCD receiver/monitor runs out of power.
E. Tire pressure sensor runs out of power.
BATTERY INFORMATION
Under normal conditions, sensor batteries will last approximately 1~2 years. LCD Receiver/Monitor
battery will last approximately 6 months. (Service life may be shorter, depending on the conditions of use.)
When the battery becomes weak, the low battery indicator will appear on the screen. Replace the battery
with a new CR1632 lithium battery for the sensor or withAAA1.5V battery for the LCD
receiver/monitor.

13
Definition of Warnings
Item Status Purpose Pattern
1. Power on LCD monitor To remind rider of
power on now Beeps once
2. When tire pressure is
below lower warning
range, each 1 P.S.I.
down, warnings will be
given as well.
The warning of tire
pressure getting
lower
Beeps for 3 times,
vibrating and backlights
on. Repeat for 5 times.
3. When tire pressure is
higher than upper
warning range, each 1
P.S.I. up, warnings will
be given as well.
The warning of tire
pressure getting high Beeps for 3 times, vibrating and backlights
on. Repeat for 5 times.
4. When tire temperature
is higher than upper
warning range, each 1
P.S.I. up, warnings will
be given as well.
The warning of tire
temperature getting
high
Beeps for 3 times,
vibrating and backlights
on. Repeat for 5 times.
5. Learnable sensor is
integrated Finish learning mode Beeps once
TROUBLESHOOTING
The following checklist will help you remedy problems you may encounter with your unit. Before
going through the checklist below, check the connection and operating procedures.
1. Indications disappear from or do not appear in the display
a. Make sure power switch is on.
b. Make sure monitor has AAA battery properly installed observing correct polarity.
c. Use fresh batteries if necessary.
2. No connection between sensors and monitor and you find all tire pressure values are gone
(indicated by 3 dashes ‘---‘.)
a. Make sure sensor has CR1632 battery properly installed observing correct polarity.
b. Use fresh batteries if necessary.
3. Monitor display is getting dark.
a. When temperature is over 80° Celsius, it is natural that LCD screen will get dark. When
temperature is back to normal, LCD screen will revert back to its normal appearance.
b. When the temperature is below -20° Celsius, the response time of LCD screen will be
slower.
4. ‘Learning mode’can only accept ‘learnable sensors’not standard sensor.

13-316 - PACKAGE CONTENTS
Here are items in whole package.
14
Item Photo number
LCD Receiver/Monitor 1 pieces
Tire Pressure Sensor 3 pieces
CR1632 Battery 3 pieces
Hex head
socket wrench
1 piece
Anti-theft ring 3 pieces
Anti-Theft Ring
Hex head
socket screw
3 pieces
User Guide 1 piece
1.5VAAA Battery 1 piece

PRODUCT SPECIFICATIONS
Tire pressure sensor specifications
Frequency 433.92MHz
Tire pressure range 0 ~ 60PSI
Accuracy Tire pressure ±1 PSI / Tire temperature ±2°C
Operating voltage 3V DC
Operating temperature -40°C~125°C
Battery life 1~2 years (Approximately)
Dimensions Diameter 20.5mm x Height 20mm
Weight 10g ± 1g
LCD receiver/monitor specifications
Frequency 433.92MHz
Operating voltage 1.5V DC
Battery life 6 months (Approximately)
Operating temperature -20°C~80°C
Dimensions Length 58mm x Width 36mm x Height 19mm
Weight 43g
WARRANTY
Big Bike Parts® warrants its Show Chrome Accessories® merchandise shall be free from defective
material and workmanship under normal use and service for a period of one year from date of purchase.
This warranty does not apply to any merchandise that has been modified or becomes defective as a result
of improper use or mistreatment of the merchandise. This warranty is in lieu of any other expressed or
implied warranty on the part of Big Bike Parts® or anyone else. Big Bike Parts® shall not be liable for
any consequential or incidental damage arising out of the breach of any warranties of its merchandise.
