BIGTREETECH ADXL345 V2.0 is a module for printer resonance compensation.
It can communicate through USB, greatly simplifying wiring.
Feature Highlights
The board has a reserved BOOT button for easy firmware updates.
Reserved solder points enable users to customize wiring easily.
The USB port has an added ESD protection chip to prevent the MCU from
being damaged by static electricity through the USB.
Specifications
Dimensions
33.25 x 15.5mm
Installation Dimensions
See BIGTREETECH ADXL345 V2.0-SIZE.pdf for
details.
Microprocessor
RP2040 Dual ARM Cortex-M0+ @ 133MHz
Input Voltage
DC 5V
Logic Voltage
DC 3.3V
Communication with PC
USB2.0
Sensor
ADXL345
Sensor Communication
4Line SPI
Resolution
Up to 3.9mg/LSB.
Output Data Rate
0.1-3200Hz
Sensor Operating
Temperature Range
-40℃ to +85℃
Firmware Support
This product currently only supports Klipper firmware.

BIGTREETECH ADXL345 V2.0 User Manual
5
Dimensions

BIGTREETECH ADXL345 V2.0 User Manual
6
Peripheral Interfaces
Pin Description
Interface Introduction
Connecting to BTT Pi V1.2 (Type-C)

BIGTREETECH ADXL345 V2.0 User Manual
7
Connecting to Manta M8P (Type-C)
Connecting to Manta M8P (Soldering Wires)

BIGTREETECH ADXL345 V2.0 User Manual
8
Klipper Firmware
Compiling Klipper Firmware
1. Connect to CB1/Raspberry Pi via SSH and enter the following
commands:
cd ~/klipper/
make menuconfig
Configure the firmware as shown in the provided image (update Klipper
firmware to the latest version if options are not available).
[*] Enable extra low-level configuration optionsMicro-controller
Micro-controller Architecture (Raspberry Pi RP2040) --->
Bootloader offset (No bootloader) --->
Flash chip (W25Q080 with CLKDIV 2) --->
Communication interface (USB) --->
2. After configuration, press q to exit, and select Yes when prompted to
save.
3. Enter make to compile the firmware. The resulting klipper.bin file will be
in the home/pi/klipper/out folder. This can be directly downloaded to
your computer from the SSH software's left panel.

BIGTREETECH ADXL345 V2.0 User Manual
9
Firmware Update via DFU
Raspberry Pi or CB1 update via DFU.
1. Hold the Boot button and connect the board to Raspberry Pi/CB1 via
Type-C cable to enter DFU mode.
2. Enter lsusb in the SSH terminal to query the DFU device ID.
3. Enter
cd klipper
navigate to the Klipper directory, and enter
make flash FLASH_DEVICE=2e8a:0003
start flashing the firmware (Note: Replace 2e8a:0003 with the actual
device ID found in the previous step.)
4. After flashing, enter
ls /dev/serial/by-id/
to query the device's Serial ID (only applicable for USB communication,
not for CANBus).
5. For USB communication, you don't need to press the Boot button for
subsequent updates. Enter the following command to flash the firmware
make flash FLASH_DEVICE=/dev/serial/by-id/usb-Klipper_rp2040_4550357128922FC8-if00
(Note: replacing /dev/serial/by-id/xxx with the actual ID found in the
previous step).
Configuring Klipper
1. Download the sample-bigtreetech-adxl345-v2.0.cfg config file from:
https://github.com/bigtreetech/ADXL345

BIGTREETECH ADXL345 V2.0 User Manual
10
2. Upload to the Configuration Files.
3. In printer.cfg, add:
[include sample-bigtreetech-adxl345-v2.0.cfg]
4. Set the correct ID number for your board.(USB serial or canbus)
5. Configure the module's functions according to the instructions in the link
below:
https://www.klipper3d.org/Config_Reference.html#adxl345
The axes_map parameter needs to be set according to the direction of
the module installation and the movement direction of the printer. The first
parameter represents the direction of the accelerometer module
corresponding to the axis when the printer's X-axis moves in the positive
direction (the silk screen on the module shows the direction of each axis
of the module), and the second parameter represents the direction of the
accelerometer when the Y-axis moves in the positive direction.

BIGTREETECH ADXL345 V2.0 User Manual
11
Assembly
Note: Avoid overtightening screws during installation to prevent damage.
Example using the Voron StealthBurner:
Method 1:
Install on the side bracket with the dual holes (matches official spacing).
Method 2:
Use screws through the PCB and rubber ring on the heater block as shown.

BIGTREETECH ADXL345 V2.0 User Manual
12
