BIG TREE TECH SKR MINI MZ V1.0 User manual

SKR MINI MZ V1.0 User Guide Shenzhen BIGTREE Technology co., LTD.
Shenzhen Big Tree Technology CO.,LTD . 1/9 Website：www.BIGTREE-TECH.com
Shenzhen BIGTREE Technology
co., LTD.
BIGTREETECH
SKR MINI MZ V1.0
User Guide
【Please read the instruction manual before use】

SKR MINI MZ V1.0 User Guide Shenzhen BIGTREE Technology co., LTD.
2/9
Ⅰ.Product Introduction:
BIGTREETECH SKR MINI MZ V1.0 is a 32-bit 3D printer motherboard
launched by the 3D printing team of Shenzhen Big Tree Technology
CO., LTD. to upgrade your MEGA Zero 3D printer.
SKR MINI MZ V1.0 motherboard with one exturder and 4pcs TMC2209
stepper motor driver, which is specially tailored for MEGA Zero
printer, perfectly replacing the original MEGA Zero printer
motherboard.
1.Motherboard Features:
1 ） MCU:ARM 32 bit and 72MHz STM32F103RCT6 of Cortex-M3
series,Improved performance；
2 ） Equipped with highly modular and open source firmware
Marlin2.0, which is convenient for users to DIY and secondary
development,Eliminate the worries of not being able to master
the core code；
3）Marlin2.0 using powerful development tools, Visual Studio
Code integrated development environment: support online
debugging, more helpful for product development and
performance optimization, using C/C++ language development,
low development threshold;
4）The PCB board wiring is rigorous and beautiful, and has been
specially optimized for heat dissipation；
5）Using a dedicated power chip to support 12-24V power input；
6）Accept 24V input；
7）Support BIGTREETECH-3.5 TFT、LCD12864
8) The system supports simplified Chinese, English and other
languages, which can be switched by yourself；
9）Upgrade and configure the firmware through SD card, which
is simple,convenient and efficient;；
10 ） High performance MOSFET tube, better heat dissipation
effect;；
11）Using removable fuse makes the replacement process easier；

SKR MINI MZ V1.0 User Guide Shenzhen BIGTREE Technology co., LTD.
3/9
13）Adopt DC5.0 socket power input
12）Reserve BLTouch, PH2.0 normally open fan, hot bed output,
switch power input, resume printing while power
off ,filament break detection , and automatic shutdown
after printing port；
13）Support offline printing and online printing；
14）Reserved double Z-axis port
15）Support onboard SD card printing function
16）Onboard EEPROM: AT24C32
17）Support RGB light bar
2.Motherboard Parameters:
1）Appearance size: 100.7mm*70.8mm
2）Installation size： 59.7*51mm
3）Microprocessor： ARM 32-bit Cortex™-M3 CPU
4）Power Voltage：DC12V--DC24V
5）Motor Driver：Integration of TMC2209 UART mode
6）Motor drive interface：X、Y、Z0、Z1、E
7）Temperature sensor interface：BED、T0
9）Display：2.4 inch TFT/LCD, 3.5 inch TFT /LCD(Note: MEGA Zero
original screen is not supported)
10）PC communication interface：MINI USB（USB 2.0）, easy to
plug and unplug, communication baud rate 115200
11）Expand the interface function support: Resume Printing
While Power Off,Filament Break Detection, Automatic Shutdown
After Printing, Automatic leveling BL Touch,ect.
12）Support file format: G-code
13）Supported machine architecture： MEGA Zero
14）Recommended software： Cura、 Simplify3D、 pronterface、
Repetier-host、Makerware

SKR MINI MZ V1.0 User Guide Shenzhen BIGTREE Technology co., LTD.
4/9
Ⅱ.Motherboard Power Wiring
1.DC Power supply
2.Switch power supply
can only selected one of the two methods and cannot be connected
at the same time.
Before wiring, be sure to disconnect the 220V power supply and
distinguish the positive and negative poles (the red positive
and the black negative in the picture above) to avoid burning
the motherboard.

SKR MINI MZ V1.0 User Guide Shenzhen BIGTREE Technology co., LTD.
5/9
Ⅲ.Motherboard and Computer
Connection
After the motherboard is connected to the computer through
USB cable, the computer will automatically install the driver.
After the driver is installed, the motherboard can be
recognized for data transmission.
If the installation fails, you can go to our open source
website: https://github.com/bigtreetech?tab=repositories
to find the corresponding motherboard to download the driver.
After the driver is installed, open the "Device Manager" and
you can see the port as shown in the figure below, indicating
that the motherboard is connected to the computer normally

SKR MINI MZ V1.0 User Guide Shenzhen BIGTREE Technology co., LTD.
6/9
Ⅳ.Motherboard and Interface
Instruction
1.Motherboard Size Diagram
2.Motherboard Wiring Diagram

SKR MINI MZ V1.0 User Guide Shenzhen BIGTREE Technology co., LTD.
7/9
3.Motherboard Pin Diagram
For details, please refer to Pin file.
Ⅴ.Motherboard jumper description
1）If you need to use the Filament Break Detection function,
you need to connect the following 4 positions with a jumper cap：

SKR MINI MZ V1.0 User Guide Shenzhen BIGTREE Technology co., LTD.
8/9
2）If you need to enable BOOT mode, please use jumper caps to
connect the following positions：
Ⅵ.The firmware description of
Motherboard
1）At present, the SKR MINI MZ V1.0 motherboard only supports
the use of our company open source Marlin 2.0 firmware, which
can be found on our open source website：
https://github.com/bigtreetech?tab=repositories
Find the corresponding motherboard to download
2） Motherboard Marlin2.0 Firmware update method：
After downloading our open source Marlin2.0 firmware, use
Visual Studio Code to open the project to compile, then find
the firmware.bin file, copy it to the SD card, re-energize or

SKR MINI MZ V1.0 User Guide Shenzhen BIGTREE Technology co., LTD.
9/9
press the reset key, wait for about 10S. After that, the update
can be completed。（Or you can download firmware.bin directly.）
For detailed steps, please refer to the tutorial:
https://www.dropbox.com/s/ppjfflhf3j5yzh2/MarlinV2.0%20SKRV
1.1%20instruction.docx?dl=0
（ Note:File name cannot be changed,firmware.bin must be
lowercase!）
Ⅶ.Notes:
1. Can only supports our open source Marlin2.0 firmware.
2.U disk function is not supported temporarily, so stay tuned.
3.Before supplying 12V/24V power to the motherboard, make sure
to pay attention to the positive and negative poles of the power
supply.
4. Firmware file names in SD card cannot be changed
(including letter case),
5. Before powering on, make sure that all wires and jumper caps
are correctly and completely plugged in.
6. Do not use switching power supply and DC power supply at the
same time.
7.The MEGA Zero printer does not have a heat bed function for
the time being, but our SKR MINI MZ V1.0 has a reserved heat
bed function. If you need to use heat bed, please use a switching
power supply (ordinary DC power supply cannot provide the
required power for the hot bed).
