IEI Technology NANO-QM871-i1 User manual

NANO-QM871-i1 EPIC SBC
Page i
User Manual
EPIC SBC with 4th Generation Intel
®
Mobile Core™ i7/i5/i3 or
Celeron® Processor, Dual HDMI, LVDS, VGA, Dual PCIe GbE,
SATA 6Gb/s, USB 3.0, PCIe Mini, Intel® AMT 9.0, iRIS-1010,
Audio and RoHS
MODEL:
NANO-QM871-i1
Rev. 1.00 – July 10, 2014

NANO-QM871-i1 EPIC SBC
Page ii
Revision
Date Version Changes
July 10, 2014 1.00 Initial release

NANO-QM871-i1 EPIC SBC
Page iii
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

NANO-QM871-i1 EPIC SBC
Page iv
Table of Contents
1 INTRODUCTION.......................................................................................................... 1
1.1 INTRODUCTION........................................................................................................... 2
1.2 MODEL VARIATIONS ................................................................................................... 3
1.3 FEATURES................................................................................................................... 3
1.4 CONNECTORS ............................................................................................................. 4
1.5 DIMENSIONS............................................................................................................... 5
1.6 DATA FLOW................................................................................................................ 6
1.7 TECHNICAL SPECIFICATIONS ...................................................................................... 7
2 PACKING LIST........................................................................................................... 10
2.1ANTI-STATIC PRECAUTIONS.......................................................................................11
2.2 UNPACKING PRECAUTIONS........................................................................................11
2.3 PACKING LIST........................................................................................................... 12
2.4 OPTIONAL ITEMS...................................................................................................... 13
3 CONNECTOR PINOUTS........................................................................................... 15
3.1 PERIPHERAL INTERFACE CONNECTORS..................................................................... 16
3.1.1 Layout .............................................................................................................. 16
3.1.2 Peripheral Interface Connectors ..................................................................... 17
3.1.3 External Interface Panel Connectors............................................................... 18
3.2 INTERNAL PERIPHERAL CONNECTORS...................................................................... 18
3.2.1 Audio Connector .............................................................................................. 18
3.2.2 Battery Connector............................................................................................ 19
3.2.3 Chassis Intrusion Connector............................................................................ 20
3.2.4 Digital I/O Connector...................................................................................... 21
3.2.5 Fan Connector (CPU)...................................................................................... 22
3.2.6 Fan Connector (System) .................................................................................. 23
3.2.7 Front Panel Connector .................................................................................... 23
3.2.8 IPMI Active LED Connector............................................................................ 24
3.2.9 iRIS Module Slot.............................................................................................. 25
3.2.10 Keyboard and Mouse Connector ................................................................... 26

NANO-QM871-i1 EPIC SBC
Page v
3.2.11 LAN Active LED Connector........................................................................... 27
3.2.12 LVDS Connector............................................................................................ 27
3.2.13 LVDS Backlight Connector............................................................................ 29
3.2.14 PCIe Mini Card Slot ...................................................................................... 29
3.2.15 Power Connector (12V)................................................................................. 31
3.2.16 RS-232 Serial Port Connectors...................................................................... 32
3.2.17 RS-422/485 Serial Port Connector (COM3).................................................. 32
3.2.18 SATA 6Gb/s Drive Connectors....................................................................... 33
3.2.19 SATA Power Connectors................................................................................ 34
3.2.20 SMBus Connector .......................................................................................... 35
3.2.21 SO-DIMM Connector..................................................................................... 36
3.2.22 SPI Flash Connector...................................................................................... 37
3.2.23 SPI Flash Connector (EC)............................................................................. 38
3.2.24 TPM Connector.............................................................................................. 38
3.2.25 USB 2.0 Connector ........................................................................................ 39
3.3 EXTERNAL INTERFACE CONNECTORS....................................................................... 40
3.3.1 Ethernet Connectors ........................................................................................ 40
3.3.2 HDMI Connectors............................................................................................ 41
3.3.3 USB 2.0 Connector .......................................................................................... 42
3.3.4 USB 3.0 Connector .......................................................................................... 43
3.3.5 VGA Connector................................................................................................ 43
4 INSTALLATION ......................................................................................................... 45
4.1ANTI-STATIC PRECAUTIONS...................................................................................... 46
4.2 INSTALLATION CONSIDERATIONS.............................................................................. 46
4.3 COOLING KIT INSTALLATION.................................................................................... 48
4.4 SO-DIMM INSTALLATION ....................................................................................... 50
4.5 IRIS-1010 MODULE INSTALLATION.......................................................................... 51
4.6 PCIE MINI CARD INSTALLATION .............................................................................. 53
4.7 SYSTEM CONFIGURATION......................................................................................... 55
4.7.1 AT/ATX Mode Selection................................................................................... 55
4.7.2 Clear CMOS..................................................................................................... 56
4.7.3 LVDS Voltage Selection.................................................................................... 57
4.7.4 LVDS Resolution Selection .............................................................................. 58
4.8 CHASSIS INSTALLATION............................................................................................ 59

NANO-QM871-i1 EPIC SBC
Page vi
4.8.1 Airflow.............................................................................................................. 59
4.8.2 Motherboard Installation................................................................................. 59
4.9 INTERNAL PERIPHERAL DEVICE CONNECTIONS........................................................ 60
4.9.1 AT/ATX Power Connection.............................................................................. 60
4.9.2 Audio Kit Installation....................................................................................... 61
4.9.3 LVDS LCD Installation.................................................................................... 62
4.9.4 SATA Drive Connection ................................................................................... 64
4.9.5 Single RS-232 Cable........................................................................................ 65
4.10 EXTERNAL PERIPHERAL INTERFACE CONNECTION ................................................. 66
4.10.1 HDMI Display Device Connection................................................................ 66
4.10.2 LAN Connection............................................................................................. 67
4.10.3 USB Connection (Dual Connector)............................................................... 68
4.10.4 VGA Monitor Connection .............................................................................. 69
4.11 INTEL®AMTSETUP PROCEDURE .......................................................................... 70
5 BIOS.............................................................................................................................. 72
5.1 INTRODUCTION......................................................................................................... 73
5.1.1 Starting Setup................................................................................................... 73
5.1.2 Using Setup...................................................................................................... 73
5.1.3 Getting Help..................................................................................................... 74
5.1.4 Unable to Reboot after Configuration Changes.............................................. 74
5.1.5 BIOS Menu Bar................................................................................................ 74
5.2 MAIN........................................................................................................................ 76
5.3ADVANCED............................................................................................................... 77
5.3.1 ACPI Settings................................................................................................... 78
5.3.2 RTC Wake Settings........................................................................................... 79
5.3.3 Trusted Computing........................................................................................... 81
5.3.4 CPU Configuration.......................................................................................... 82
5.3.5 SATA Configuration ......................................................................................... 84
5.3.6 Intel(R) Rapid Start Technology....................................................................... 85
5.3.7 AMT Configuration.......................................................................................... 86
5.3.8 USB Configuration........................................................................................... 87
5.3.9 iWDD H/W Monitor......................................................................................... 88
5.3.9.1 Smart Fan Mode Configuration................................................................ 88
5.3.10 F81866 Super IO Configuration.................................................................... 90

NANO-QM871-i1 EPIC SBC
Page vii
5.3.10.1 Serial Port n Configuration..................................................................... 91
5.3.11 Serial Port Console Redirection..................................................................... 94
5.3.12 iEi Feature ..................................................................................................... 97
5.4 CHIPSET ................................................................................................................... 98
5.4.1 PCH-IO Configuration .................................................................................... 99
5.4.1.1 PCI Express Configuration..................................................................... 100
5.4.2 System Agent (SA) Configuration .................................................................. 101
5.4.2.1 Graphics Configuration........................................................................... 101
5.4.2.2 Memory Configuration ........................................................................... 103
5.5 BOOT...................................................................................................................... 104
5.6 SECURITY............................................................................................................... 106
5.7 SAVE &EXIT.......................................................................................................... 107
6 SOFTWARE DRIVERS............................................................................................ 108
6.1AVAILABLE SOFTWARE DRIVERS ............................................................................ 109
6.2 STARTING THE DRIVER PROGRAM .......................................................................... 109
6.3 CHIPSET DRIVER INSTALLATION..............................................................................111
6.4 GRAPHICS DRIVER INSTALLATION...........................................................................114
6.5 LAN DRIVER INSTALLATION...................................................................................117
6.6 USB 3.0 DRIVER INSTALLATION ............................................................................ 122
6.7AUDIO DRIVER INSTALLATION ............................................................................... 125
6.8 INTEL®AMTDRIVER INSTALLATION .................................................................... 127
A BIOS OPTIONS ........................................................................................................ 130
B TERMINOLOGY...................................................................................................... 133
C DIGITAL I/O INTERFACE..................................................................................... 137
C.1 INTRODUCTION...................................................................................................... 138
C.2 DIO CONNECTOR PINOUTS.................................................................................... 138
C.3ASSEMBLY LANGUAGE SAMPLES........................................................................... 139
C.3.1 Enable the DIO Input Function..................................................................... 139
C.3.2 Enable the DIO Output Function.................................................................. 139
D HAZARDOUS MATERIALS DISCLOSURE....................................................... 140
D.1 HAZARDOUS MATERIALS DISCLOSURE TABLE FOR IPB PRODUCTS CERTIFIED AS
ROHS COMPLIANT UNDER 2002/95/EC WITHOUT MERCURY ..................................... 141

NANO-QM871-i1 EPIC SBC
Page viii
List of Figures
Figure 1-1: NANO-QM871-i1 ..........................................................................................................2
Figure 1-2: Connectors ..................................................................................................................4
Figure 1-3: NANO-QM871-i1 Dimensions (mm)...........................................................................5
Figure 1-4: Data Flow Diagram......................................................................................................6
Figure 3-1: Connector and Jumper Locations...........................................................................16
Figure 3-2: Audio Connector Location.......................................................................................19
Figure 3-3: Battery Connector Location.....................................................................................20
Figure 3-4: Chassis Intrusion Connector Location...................................................................21
Figure 3-5: Digital I/O Connector Location ................................................................................21
Figure 3-6: CPU Fan Connector Location..................................................................................22
Figure 3-7: System Fan Connector Location.............................................................................23
Figure 3-8: Front Panel Connector Location .............................................................................24
Figure 3-9: IPMI Active LED Connector......................................................................................25
Figure 3-10: iRIS Module Slot Location......................................................................................26
Figure 3-11: Keyboard and Mouse Connector Location...........................................................26
Figure 3-12: LAN Active LED Connector Location....................................................................27
Figure 3-13: LVDS Connector Location......................................................................................28
Figure 3-14: LVDS Backlight Inverter Connector......................................................................29
Figure 3-15: PCIe Mini Card Slot Location.................................................................................30
Figure 3-16: Power Connector Location ....................................................................................31
Figure 3-17: RS-232 Serial Port Connector Location................................................................32
Figure 3-18: RS-422/485 Serial Port Connector Location.........................................................33
Figure 3-19: SATA 6Gb/s Drive Connector Locations..............................................................34
Figure 3-20: SATA Power Connector Locations .......................................................................35
Figure 3-21: SMBus Connector Location...................................................................................36
Figure 3-22: SO-DIMM Connector Locations.............................................................................37
Figure 3-23: SPI Flash Connector Location...............................................................................37
Figure 3-24: EC SPI Flash Connector Location.........................................................................38
Figure 3-25: TPM Connector Location........................................................................................39
Figure 3-26: USB Connector Locations......................................................................................40

NANO-QM871-i1 EPIC SBC
Page ix
Figure 3-27: External Interface Connectors...............................................................................40
Figure 3-28: Ethernet Connector.................................................................................................41
Figure 3-29: HDMI Connector......................................................................................................42
Figure 3-30: VGA Connector .......................................................................................................44
Figure 4-1: Install Support Bracket.............................................................................................48
Figure 4-2: Align the Cooling Kit.................................................................................................49
Figure 4-3: Secure the Cooling Kit..............................................................................................50
Figure 4-4: SO-DIMM Installation................................................................................................51
Figure 4-5: Removing the Retention Screw for the iRIS-1010 Module....................................52
Figure 4-6: Inserting the iRIS-1010 Module into the Slot at an Angle.....................................52
Figure 4-7: Securing the iRIS-1010 Module ...............................................................................53
Figure 4-8: Removing the Retention Screw...............................................................................54
Figure 4-9: Inserting the Full-size PCIe Mini Card into the Slot at an Angle..........................54
Figure 4-10: Securing the Full-size PCIe Mini Card ..................................................................55
Figure 4-11: AT/ATX Mode Selection Jumper Location............................................................56
Figure 4-12: Clear CMOS Jumper Location ...............................................................................57
Figure 4-13: LVDS Voltage Selection Jumper Location ...........................................................57
Figure 4-14: LVDS Resolution Selection Jumper Location......................................................59
Figure 4-15: Power Cable to Motherboard Connection............................................................60
Figure 4-16: Connect Power Cable to Power Supply................................................................61
Figure 4-17: Audio Kit Cable Connection ..................................................................................62
Figure 4-18: LVDS Connector......................................................................................................63
Figure 4-19: Backlight Inverter Connection...............................................................................64
Figure 4-20: SATA Drive Cable Connection...............................................................................65
Figure 4-21: Single RS-232 Cable Installation ...........................................................................66
Figure 4-22: HDMI Connection....................................................................................................67
Figure 4-23: LAN Connection......................................................................................................68
Figure 4-24: USB Connector........................................................................................................69
Figure 4-25: VGA Connector .......................................................................................................70
Figure 6-1: Start Up Screen ...................................................................................................... 110
Figure 6-2: Drivers..................................................................................................................... 110
Figure 6-3: Chipset Driver Welcome Screen........................................................................... 111
Figure 6-4: Chipset Driver License Agreement...................................................................... 112
Figure 6-5: Chipset Driver Read Me File ................................................................................. 112
Figure 6-6: Chipset Driver Setup Operations ......................................................................... 113

NANO-QM871-i1 EPIC SBC
Page x
Figure 6-7: Chipset Driver Installation Finish Screen............................................................ 114
Figure 6-8: Graphics Driver Welcome Screen ........................................................................ 115
Figure 6-9: Graphics Driver License Agreement.................................................................... 115
Figure 6-10: Graphics Driver Read Me File............................................................................. 116
Figure 6-11: Graphics Driver Setup Operations..................................................................... 116
Figure 6-12: Graphics Driver Installation Finish Screen ....................................................... 117
Figure 6-13: Windows Control Panel....................................................................................... 118
Figure 6-14: System Control Panel.......................................................................................... 118
Figure 6-15: Device Manager List ............................................................................................ 119
Figure 6-16: Update Driver Software Window ........................................................................ 120
Figure 6-17: Locate Driver Files............................................................................................... 120
Figure 6-18: LAN Driver Installation ........................................................................................ 121
Figure 6-19: LAN Driver Installation Complete....................................................................... 121
Figure 6-20: USB 3.0 Driver Welcome Screen........................................................................ 122
Figure 6-21: USB 3.0 Driver License Agreement.................................................................... 123
Figure 6-22: USB 3.0 Driver Read Me File............................................................................... 123
Figure 6-23: USB 3.0 Driver Setup Operations....................................................................... 124
Figure 6-24: USB 3.0 Driver Installation Finish Screen ......................................................... 124
Figure 6-25: Audio Driver Welcome Screen............................................................................ 125
Figure 6-26: Audio Driver Installation...................................................................................... 126
Figure 6-27: Audio Driver Installation Complete.................................................................... 126
Figure 6-28: Intel® ME Driver Welcome Screen ..................................................................... 127
Figure 6-29: Intel® ME Driver License Agreement................................................................. 128
Figure 6-30: Intel® ME Driver Setup Operations.................................................................... 128
Figure 6-31: Intel® ME Driver Installation Finish Screen ...................................................... 129

NANO-QM871-i1 EPIC SBC
Page xi
List of Tables
Table 1-1: Model Variations...........................................................................................................3
Table 1-2: Technical Specifications..............................................................................................9
Table 2-1: Packing List.................................................................................................................13
Table 2-2: Optional Items.............................................................................................................14
Table 3-1: Peripheral Interface Connectors...............................................................................18
Table 3-2: Rear Panel Connectors..............................................................................................18
Table 3-3: Audio Connector Pinouts ..........................................................................................19
Table 3-4: Battery Connector Pinouts........................................................................................20
Table 3-5: Chassis Intrusion Connector Pinouts......................................................................21
Table 3-6: Digital I/O Connector Pinouts....................................................................................22
Table 3-7: CPU Fan Connector Pinouts......................................................................................22
Table 3-8: System Fan Connector Pinouts ................................................................................23
Table 3-9: Front Panel Connector Pinouts.................................................................................24
Table 3-10: IPMI Active LED Connector Pinouts.......................................................................25
Table 3-11: Keyboard and Mouse Connector Pinouts..............................................................27
Table 3-12: LAN Active LED Connector Pinouts.......................................................................27
Table 3-13: LVDS Connector Pinouts.........................................................................................28
Table 3-14: Backlight Inverter Connector Pinouts....................................................................29
Table 3-15: PCIe Mini Card Slot Pinouts ....................................................................................31
Table 3-16: Power Connector Pinouts........................................................................................31
Table 3-17: RS-232 Serial Port Connector Pinouts...................................................................32
Table 3-18: RS-422/485 Serial Port Connector Pinouts............................................................33
Table 3-19: DB-9 RS-422/485 Pinouts.........................................................................................33
Table 3-20: SATA 6Gb/s Drive Connector Pinouts....................................................................34
Table 3-21: SATA Power Connector Pinouts.............................................................................35
Table 3-22: SMBus Connector Pinouts ......................................................................................36
Table 3-23: SPI Flash Connector Pinouts ..................................................................................38
Table 3-24: EC SPI Flash Connector Pinouts ............................................................................38
Table 3-25: TPM Connector Pinouts...........................................................................................39
Table 3-26: USB Port Connector Pinouts...................................................................................40

NANO-QM871-i1 EPIC SBC
Page xii
Table 3-27: LAN Pinouts ..............................................................................................................41
Table 3-28: Connector LEDs........................................................................................................41
Table 3-29: HDMI Connector Pinouts .........................................................................................42
Table 3-30: External USB 2.0 Port Pinouts ................................................................................42
Table 3-31: External USB 3.0 Port Pinouts ................................................................................43
Table 3-32: VGA Connector Pinouts...........................................................................................44
Table 4-1: LVDS Voltage Selection Jumper Settings................................................................57
Table 4-2: LVDS Resolution Selection Jumper Settings..........................................................58
Table 5-1: BIOS Navigation Keys................................................................................................74

NANO-QM871-i1 EPIC SBC
Page xiii
BIOS Menus
BIOS Menu 1: Main.......................................................................................................................76
BIOS Menu 2: Advanced..............................................................................................................78
BIOS Menu 3: ACPI Settings .......................................................................................................78
BIOS Menu 4: RTC Wake Settings..............................................................................................79
BIOS Menu 5: Trusted Computing..............................................................................................81
BIOS Menu 6: CPU Configuration...............................................................................................82
BIOS Menu 7: SATA Configuration.............................................................................................84
BIOS Menu 8: Intel(R) Rapid Start Technology .........................................................................85
BIOS Menu 9: AMT Configuration...............................................................................................86
BIOS Menu 10: USB Configuration.............................................................................................87
BIOS Menu 11: iWDD H/W Monitor .............................................................................................88
BIOS Menu 12: Smar Fan Mode Configuration..........................................................................89
BIOS Menu 13: F81866 Super IO Configuration........................................................................90
BIOS Menu 14: Serial Port n Configuration Menu.....................................................................91
BIOS Menu 15: Serial Port Console Redirection.......................................................................94
BIOS Menu 16: iEi Feature...........................................................................................................97
BIOS Menu 17: Chipset................................................................................................................98
BIOS Menu 18: PCH-IO Configuration........................................................................................99
BIOS Menu 19: PCI Express Configuration ............................................................................ 100
BIOS Menu 20: System Agent (SA) Configuration................................................................. 101
BIOS Menu 21: Graphics Configuration.................................................................................. 102
BIOS Menu 22: Memory Configuration.................................................................................... 104
BIOS Menu 23: Boot.................................................................................................................. 104
BIOS Menu 24: Security............................................................................................................ 106
BIOS Menu 25: Save & Exit.......................................................................................................107
NANO-QM871-i1

NANO-QM871-i1 EPIC SBC
Page 1
Chapter
1
1 Introduction

NANO-QM871-i1 EPIC SBC
Page 2
1.1 Introduction
Figure 1-1: NANO-QM871-i1
The NANO-QM871-i1 is an EPIC SBC with a 4th generation Intel® mobile Core™ i7/i5/i3
or Celeron® processor and Intel® QM87 Express Chipset. Storage on the board is
handled by two SATA 6Gb/s ports and one PCIe Mini socket for connecting a hard drive,
optical drive or SSD.
The NANO-QM871-i1 features Intelligent Platform Management Interface (IPMI) that
helps lower the overall costs of server management by enabling users to maximize IT
resource, save time and manage multiple systems. The NANO-QM871-i1 supports
IPMI 2.0 through the optional iRIS-1010 module.
The NANO-QM871-i1 has three types of graphics outputs that support triple independent
display. A VGA output connects to a VGA monitor. One LVDS connector supports
18/24-bit dual-channel display. Two HDMI connectors support up to 1920x1200 resolution.
Other connectors include RS-232 ports, RS-422/485 port, Gigabit Ethernet, USB 3.0 ports,
USB 2.0 ports, TPM, SMBus and digital I/O.

NANO-QM871-i1 EPIC SBC
Page 3
1.2 Model Variations
There are four models of the NANO-QM871-i1 series. The model variations are listed in
Table 1-1.
On-board Processor
Model Name Speed Cache TDP
NANO-QM871-i1-i7 Intel® mobile Core™ i7-4700EQ 2.4 GHz 6 MB 47 W
NANO-QM871-i1-i5 Intel® mobile Core™ i5-4400E 2.7 GHz 3 MB 37 W
NANO-QM871-i1-i3 Intel® mobile Core™ i3-4100E 2.4 GHz 3 MB 37 W
NANO-QM871-i1-C Intel® mobile Celeron® 2000E 1.5 GHz 2 MB 37 W
Table 1-1: Model Variations
1.3 Features
Some of the NANO-QM871-i1 motherboard features are listed below:
EPIC form factor
4th generation Intel® mobile Core™ i7/i5/i3 or Celeron® processor
One 204-pin 1600/1333 MHz DDR3/DDR3L SO-DIMM supported (system
max. 8.0 GB)
Dual PCIe GbE
Intel® AMT 9.0 support
Supports triple independent display with dual HDMI+VGA/dual
HDMI+LVDS/HDMI+VGA+LVDS
Supports IPMI 2.0 via the optional iRIS-1010 module
One PCIe Mini card slot with mSATA support
Complete I/O with six USB (two USB 3.0, four USB 2.0), two SATA 6Gb/s,
three COM (two RS-232, one RS-422/485) and audio
RoHS compliant

NANO-QM871-i1 EPIC SBC
Page 4
1.4 Connectors
The connectors on the NANO-QM871-i1 are shown in the figure below.
Figure 1-2: Connectors

NANO-QM871-i1 EPIC SBC
Page 5
1.5 Dimensions
The main dimensions of the NANO-QM871-i1 are shown in the diagram below.
Figure 1-3: NANO-QM871-i1 Dimensions (mm)

NANO-QM871-i1 EPIC SBC
Page 6
1.6 Data Flow
Figure 1-4 shows the data flow between the system chipset, the CPU and other
components installed on the motherboard.
Figure 1-4: Data Flow Diagram

NANO-QM871-i1 EPIC SBC
Page 7
1.7 Technical Specifications
The NANO-QM871-i1 technical specifications are listed in Table 1-2.
Specification NANO-QM871-i1
Form Factor EPIC
CPU Standard
oIntel® mobile Core™ i7-4700EQ processor with Intel® AMT
9.0 support (2.4 GHz, quad-core, 6 MB cache, TDP=47 W)
oIntel® mobile Core™ i5-4400E processor with Intel® AMT 9.0
support (2.7 GHz, dual-core, 3 MB cache, TDP=37 W)
oIntel® mobile Core™ i3-4100E processor
(2.4 GHz, dual-core, 3 MB cache, TDP=37 W)
oIntel® mobile Celeron® 2000E processor
(2.2 GHz, dual-core, 2 MB cache, 37 W TDP)
By request
oIntel® mobile Core™ i5-4402E processor with Intel® AMT 9.0
support (1.6 GHz, dual-core, 3 MB cache, TDP=25 W)
oIntel® mobile Core™ i3-4102E processor
(1.6 GHz, dual-core, 3 MB cache, TDP=25 W)
oIntel® mobile Celeron® 2002E processor
(1.5 GHz, dual-core, 2 MB cache, TDP=25 W)
PCH Intel® QM87
Memory One 204-pin 1600/1333 MHz DDR3/DDR3L SO-DIMM supported
(system max. 8 GB)
Graphics Engine Intel® HD Graphics Gen 7.5 supports DirectX 11.1, OpenGL 3.2 and
OpenCL 1.2
Full MPEG2, VC1, AVC decode
Ethernet Controllers LAN1: Intel® I217LM PHY with Intel® AMT 9.0 support
LAN2: Intel® I210-AT PCIe Ethernet controller with NC-SI support
Audio Realtek ALC662 HD Audio codec
One internal audio connector (10-pin header)
