BigBlue AL1200RAFO User manual

AL1200RAFO
The Big Blue AL 1200RAFO Li-ion Rechargeable Battery Wide Bearn LED
light cornes with an innovative Auto Flash-o function, giving you bet-
ter control over lighting and prevent annoying hotspot from spoiling
your picture perfect shots. Combined with brilliant luminosity, durable
construction and reliable performance, this is the diving light you must
take with you on your next underwater photo shoot.
Our high output LED system delivers brilliant luminosity at 1200 lumens, a
55°strong and even light beam, making it ideal for video.
- The light can be attached to a lanyard.
- The unique XML high intensity LED is energy efficient to guarantee a long
burn time of up to 50,000 heurs, reducing the need for frequent bulb re-
placement.
- Automatic flash-off function triggered by the flashlight of strobe.
- The Auto Flash-Off cornes on automatically for 0.2 seconds when your
underwater strobe is triggered, avoiding that accidentai hot spot from
ruining your pictures.
- The body can be twist opened easily to replace the old battery pack inside
for long lasting performance.
- The 6500K white light reflects the true vibrant colors of the underwater
surrounding while diving.
- The push button not only makes it easy to change between the power
output levels, but it is also designed to be insulated from ail internai parts,
eliminating the risk of leakage.
- The product cornes with a smart charger, enabling you to smart qui-
ck-charge in 2-3 hours.
- Built in red LED for viewing shy little creatures and enhancing focusing
performance.
- The thermal protection system prevents the light from overhea-
ting by automatically cutting o its power supply in the event of
prolonged use on land, or exposure to temperatures in excess of
70°C. As soon as the lamp cools down, power is restored.
INTRODUCTION
FEATURES
LI-ION RECHARGEBALE BATTERY
WIDE BEARN LED LIGHT
WITH AUTO-FLASH OFF FUNCTION
PRECAUTIONS AND ADVICE
CONCERNING THE LI-ION RECHARGEABLE BATTERY
INSTRUCTION MANUAL
LI-ION RECHARGEABLE BATTERY
Congratulations on your purchase of our BigBlue product. The BigBlue
Diving Light uses carefully selected materials that have met rigorous
industry standards. With innovative manufacturing processes, and
strict quality controls, we guarantee the reliability of ail BigBlue Di-
ving products.
1. BigBlue guarantees the proper operation of this product by the
original retail purchaser under norrnal and intended use.
2. This warranty applies only to the original retail purchaser, which
does not cover commercial or rentai use, and it is not transferable
to third parties.
3. If the original retail purchaser detects defect in the materials
or workmanship, return the product together with proof of pur-
chase, including the date of purchase to an authorized BigBlue
dealer or BigBlue.
4. The warranty covers a period of up to one year from the date of
purchase. Warranty for rechargeable battery pack is valid for six
months only.
5. This limited warranty is in lieu of all other warranties. No other
person or party is authorized to assume for BigBlue any other lia-
bility in connection with the sales of this product.
6. This warranty will be voided if the product or any of its parts have
been tempered with, repaired, modied, transformed, adapted,
or damaged without authorization by BigBlue.
7. This warranty does not cover parts subjected to normal wear and
tear, including and is not limited to the following: O-ring, battery
pack, front glass (surface scratch or damage on impact).
8. This warranty does not cover damages due to impact, used in
chlorinated or polluted waters, and extended exposure to heat
sources.
LIMITED WARRANTY
- Intended to be used with the custom-made BATCELL18650 Li-ion
rechargeable battery pack only.
- Make sure to connect with the correct polarity. Incorrect connec-
tion can damage the unit.
- Fully charge the batteries before using for the rst lime.
- Use only the power adapters supplied with the charger. Using in-
compatible adapters may damage the charger or result in tire or
electric shock.
- Charge lime will depend on the remaining charge in the battery
and the surrounding temperature.
- Do not charge near hot temperature, under direct sunlight, co-
ver the charger with a blanket, or place under heavy pressure. If
the temperature is too high, il may cause the battery to leak or
rupture.
- When storing or carrying the battery, avoid direct contact with
metal abjects to avoid short circuit.
- The Li ion battery should not be dropped or be subjected to strong
mechanical shock.
- Do not operate the battery or the charger if il has been damaged
or subjected to shock.
- Remove the battery from the light if il is not going to be in use for
an extended period of lime.
- Do not dispose of in re. Do not heat, deform, solder, disassemble
or modify.
- Do not dispose of your rechargeable battery with general
household waste. Check with your local collection system for
electrical and electronic products.
- Do not short-circuit, overcharge, crush, drop, mutilate, penetrate
with foreign abjects, apply reverse polarity, expose to high tempera-
ture or disassemble packs and cells.
- Use only lithium-ion cells with a designated protection circuit and
approved charger.
- Discontinue using the battery and/or charger if the battery gels
excessively warm.
- The electrolyte is highly ammable and battery rupture can
cause physical injury.
- Use a foam extinguisher, C02, dry chemical, powdered graphite,
copper powder or soda (sodium carbonate) to extinguish a
lithium-ion lire. Only pour water to prevent the tire from sprea-
ding.
- If the lire of a burning lithium-ion battery cannot be extinguished,
allow the pack to burn out on its own in a controlled and safe
manner.
Charge the battery after each use. It is not necessary to discharge the
battery before charging. It is preferable to recharge the battery every
month, even if it is not in use.

: XML LED + 2 x XPE RED LED
: 120 Lm (level I), 300 Lm (level II),
600 Lm (level III), 1200 Lm (level IV)
: 150 Lm
: aluminum alloy (anti-corrosive anodized)
: Li-ion rechargeable battery pack 18650
: 55° (wide beam)
: 6500K
: 0.2 sec. +/- 0.1 sec.
: 2h (level IV), 5h (level III), 10h (level II)
et 20h (level I)
: 100 m tested
: dia. 42.4 x L. 128.3 mm
: 242 g (including battery)
: -129 g (including battery)
: push button with battery indicator
: tempered optical glass
: included
For Red LED setting, two very short rapid presses of the button will swit-
ch ta red light mode. Switch back ta bright light mode with a slightly
longer press and release.
For SOS setting, press the push button for 2 sec ta get SOS eect and
back ta normal when you press the push button once agam.
For OFF setting, press the push button one time after 1 sec of level selec-
tion or press the ush button ve times after 4-Levels setting.
TECHNICAL SPECIFICATIONS
Place the Li-ion battery inside the USB
Charger.
Plug the intelligent rapid charger connec-
tor into the BATCELL18650 Li-ion rechar-
geable battery pack socket.
Comes with ball joint for easy system
setup.
Red light means charging is in progress,
green light means charging is complete.
There is no need to discharge after use.
Charge time will depend on the remaining
capacity in the battery and the surroun-
ding temperature.
CHARGER LA BATTERIE
Contact Europe : Custom Diving Systems - www.customdivingsystems.com
Email : [email protected]
Bigblue Dive Lights, Bossk International Company Ltd - www.bigblue.com.hk
MADE IN CHINA Patent Pending
1. Never put your battery on a charger and leave il unattended. Check
the « lime required to fully re-charge » and plan to have someone
be in attendance.
2. D iscontinue using charger and/or battery if the battery gels ex-
cessively warm.
3. If the battery does not charge in the approximate lime suggested
by the manufacturer contact the manufacturer to determine if
the problem is with the battery or the charger. Do not continue
charging the cell.
CHARGING LI ION BATTERY
1. Fully charge the battery before using it rst lime.
2. Use only the power adapter supplied with the charger.
3. Plug in the charger before you place the battery in the charger.
4. Connect with the correct polarity (+ and -) only, incorrect connec-
tion can damage the unit.
5. The red light on the charger will light up after a short lime, indica-
ting charging is taking place. If the red light does not light up, dis-
connect the battery and re-connect it again. If the red light does
not light up after several attempts, the battery does not function.
6. Green light on the charger indicates fully charged battery. The
battery should then be disconnected.
7. Charge the battery after each use. lt does not have to be
discharged before charging. Should charge the battery every
month even you don’t use it.
8. Do not turn on the light, if the light has tumed o due to low bat-
tery capacity. Tuming on the light with a fully discharged battery
can damage the battery.
9. Charge lime will depend on the remaining charge in the battery
and the surrounding temperature.
10. Remove the battery from the light if il is not going to be used for
extended period of lime.
USING THE RECHARGEABLE LI-ION BATTERY
After each dive, always rinse with fresh water. If the diving light and the
battery will not be used for a prolonged period of time (more than a
month), remove the battery from the light.
To avoid unwanted switching on, we recommend disconnecting the
lamp’s battery.
In rare cases of ooding, discontinue use. Turn the light o immedia-
tely, disconnect the battery, and rinse with fresh water. Let the compo-
nent dry completely, and return it to BigBlue for service.
Flooding damage cannot be repaired on site.
For good practice, put the light into fresh water for few hours after eve-
ry dive.
Dry it out and put the silicone crease on the O-Ring. Ready for other
dive.
LI-ION BATTERY CHARGE AND CARE
Unscrew the body and then slide out the
old battery pack.
REPLACING THE BATTERY PACK INSIDE
THE BODY
Press the push button every time to
choose the desired output level :
1 - output at 10%, 2 - output at 25%,
3 - output at 50%, 4 - output at 100%.
For 4-Levels setting, press the push button
each time to change the level of output
accorclingly.
CHOOSING BETWEEN 4-LEVELS
AND SOS OF OUTPUT
Color of LEDs change from the time being.
lt will change from blue to green and green
to red. When the red led ashes, it reminds
people to charge up the battery.
BATTERY LEVEL INDICATOR BUILT-IN
light source
light output
red mode
casing material
power source
angle of light beam
color temperature
afo interval
burn time
maximum depth
size
weight in air
buoyancy in seawater
switching system
front glass
lanyard
