TREND TCH/AT/B75R User manual
ANGLE TWIST TORCH
REF. TCH/AT/B75R
Thank you for purchasing this Trend product,
which should give lasting performance if used
in accordance with these instructions.
Denotes risk of personal injury, loss
of life or damage to the tool in case of
non-observance of the instructions.
INST/TCH/AT/B75R v1.0
CE DECLARATION CONFORMITY
This product conforms with EMC
Directive 2014/30/EU.
OPERATION
Remove battery safety tab before use.
Mode 1 Short press: Low – High – Off
Mode 2 Long press: UV – Off – Mode 1
When the torch is off or on Mode 1, long press
the button to turn to Mode 2.
The switch indicator will show green if battery
is more than 3.3V and it will show red if battery
falls below 3.0-3.3V.
If the battery is less than 3V, the indicator will
turn red and flash for 2 minutes until it goes out.
Charging
The battery has a safety tab fitted for transit,
this must be removed before use. To charge
battery use supplied USB cable to connect
with USB socket adaptor (not supplied).
The switch indicator will show red, which
means it is charging and will turn to green
when fully charged. Battery charge time can
take 6 to 8 hours.
INTENDED USE
This accessory is intended to be used as a
torch only. The torch has Low, High and UV
light functions.
SAFETY
Read and understand the instruction sheet
carefully before using. This is a sensitive
precision tool. Do not disassemble or drop it.
Please note the magnets in the base. Store out
of reach of children. Do not use as a toy or as
a weapon.
PLEASE KEEP THESE INSTRUCTIONS IN
A SAFE PLACE.
Users must be competent in using woodworking
equipment before using our products. Consider
working environment before using tools. Ensure
working position is comfortable and component
is clamped securely. Please keep children and
visitors away from tools and work area. All
tools have a residual risk so must therefore be
handled with caution.
Rechargeable
Angle Twist
Torch
TCH/AT/B75R
PTO
© Trend Machinery & Cutting Tools Ltd. 2018 E&OE
® All trademarks acknowledged
Trend Machinery & Cutting Tools Ltd
Odhams Trading Estate St Albans Road
Watford WD24 7TR England
Tel: 0044(0)1923 249911
www.trend-uk.com
GUARANTEE
All Trend products are guaranteed against
any defects in either workmanship or material,
except products that have been damaged due
to improper use or maintenance.
Remove battery safety tab before use.
Micro USB port
Micro
USB
TROUBLESHOOTING
Possible
Problem Cause Solution
Torch does Battery has Please recharge
not light up. run out. battery or fit new
battery ensuring
correct polarity.
Torch does Contact pin Please clean
not light up. dirty. with alcohol
wipes.
Batteries and the Environment
This unit uses Li-ion batteries.
When battery pack needs replacing,
we recommend the following:
Discharge the energy from the from
the tool.
Lithium Ion battery cells are recyclable: so
do not throw them away with your household
waste. They may end up in an incinerator or
landfill, which must be avoided. Instead, take
the batteries to a Trend Service Agent, your
local Dealer or a local recycling station. If
necessary contact your local municipality for
disposal information. The collected batteries
will be disposed of properly and/or used for
recycling purposes.
The attention of UK users is drawn to The
Provision and Use of Work Equipment
Regulations 1998, and any subsequent
amendments.
Users should also read the HSE/HSC Safe
Use of Woodworking Machinery Approved
Code of Practice and Guidance Document and
any amendments. Users must be competent
in using woodworking equipment before using
our products.
Our policy of continuous improvements mean
that specifications may change without notice.
Trend machinery & Cutting Tools Ltd. cannot
be held liable for any material rendered
unusable, or for any form of consequential loss.
MAINTENANCE
Please use only Trend original spare parts
and accessories.
Please do not open the fixed head parts,
otherwise there is a risk to damage the light
and invalidate the warranty.
Please use a good quality battery.
Cleaning
nClean with a cloth.
nWe advise that the current contact pin and
surface are often cleaned to ensure torch
functions normally, especially if the torch
light flashes on its own.
Storage
nTake out the battery when you are going
to power off for a long time otherwise the
battery may become damaged.
Battery Care
WARNING!
Check for correct polarity (+/-).
KEEP OUT OF REACH OF CHILDREN.
Do not swallow. If swallowed, seek medical
advice at once. Do not dissemble, recharge
or dispose of in fire. Do not mix used and new
batteries, different brands or types:
may explode, leak and cause damage.
Remove the battery before storing the
instrument, store separately to avoid short
circuit. Remove exhausted and expired
batteries promptly.
The product is designed to use 18650-size
battery only.
Do not throw 18650 batteries into fire or water.
Please put in correct polarity when charging.
We suggest charging the battery every three
months at least to protect battery life if you
plan to store for a long period of time.
WARNING!
Intense beam of light.
Intensity
1300cd
Beam Distance
72m
Drop Resistant
1.0m
ANSI FL1
IPX4
Low Mode
LUMENS
30
5.5h
High Mode
LUMENS
115
1h 15min
LED
CREE XP-E2 R3
Battery
Included
Magnetic Anti-slip
1x AA
(1.5v)
IMPORTANT!
Caution LEDs are extremely bright and direct
exposure to eyes may cause injury. For eye
protection, do not look directly into the light.
ENVIRONMENTAL PROTECTION
Recycle raw materials instead of disposing
as waste.
Packaging should be sorted for
environmental-friendly recycling.
Separate collection. This product
must not be disposed of with normal
household waste.
Household User
Local regulations may provide for separate
collection of electrical products from the
household, at municipal waste sites or by the
retailer when you purchase a new product.
Please call Trend Customer Services for
advice as to how to dispose of unwanted
Trend electrical product in an environmentally
safe way or visit www.trend-uk.com
Business User
Please call Trend Customer Services for
advice as to how to dispose of unwanted
Trend electrical product in an environmentally
safe way or visit www.trend-uk.com
UV Light
UV wave length: 395nm.
Caution: Avoid permanent UV radiation to the
skin or eyes.
Li-ion battery needs to be charged in every
3-6 months to function properly.
Battery
+
