Surefire EDC Series User manual

18300 MT. BALDY CIRCLE
FOUNTAIN VALLEY, CA 92708-6122
WWW.SUREFIRE.COM
Patents: RE40125, 6547415, 6712485
Revision B 4-2022
71-01-1127
EDC1-DFT-xx, EDC2-DFT-xx
MAINTENANCE
Wipe with a clean, dry cloth. For tips on maintaining your SureFire
illumination tool, visit www.surefire.com/faqs-maintenance.
THE SUREFIRE NO-HASSLE GUARANTEE
We’ll do what it takes to keep your SureFire gear running smoothly. SureFire
warrants that if you — our customer — purchase one of our products, and
we determine that it is defective in material and/or workmanship during
your lifetime, we will repair or replace it — no hassle!
Our warranty does not cover consumables or normal wear-and-tear —
things like batteries draining, headbands and headpads wearing out, ink
cartridges running out, and switches wearing out — or damage resulting
from abuse, alterations, unauthorized repairs, or use contrary to SureFire’s
user manuals.
Should you need a replacement product, SureFire reserves the right to
replace an obsolete product with a current production, like model. In the
event that any issue with a SureFire product is not covered under this
warranty SureFire can arrange to have the product repaired for a reasonable
fee.
STANDARD DISCLAIMER
Except as specified above or prohibited by applicable law: all express or
implied conditions and warranties, including, without limitation, any implied
warranty or condition of merchantability or fitness for a particular purpose,
or accuracy of any informational content, are hereby excluded and disclaimed
by SureFire; and in no event will SureFire be liable for any special, direct,
indirect, consequential, incidental or punitive damages howsoever arising
and regardless of the theory of liability, even if advised of the possibility of
such damages. Products, prices, availability, specifications, and offers are
subject to change or cancellation at any time without notice.
WARRANTY CLAIMS
For claims, contact Customer Service at 714-545-9444 to obtain a
Return Merchandise Authorization number (RMA#). Then package the
unit carefully and send to (no CODs):
SureFire, LLC.
Repairs Department, RMA#____
17680 Newhope Street, Suite B
Fountain Valley, CA 92708
SureFire will pay any reasonable shipping costs to return the unit to you.
HIGH-CANDELA DUAL-OUTPUT FLASHLIGHT
USER MANUAL
EDC1-DFT EDC2-DFT
OUTPUT SF18350: 650 / 25 lumens
123A: 350 / 25 lumens
SF18650B: 700 / 25 lumens
(2) 123A: 600 / 25 lumens
RUNTIME SF18350: 45 minutes / 11 hours
123A: 1 / 12 hours
SF18650B: 2.75 / 46.5 hours
(2) 123A: 2 / 23 hours
PEAK BEAM
INTENSITY
SF18350: 95,000 candela
123A: 55,000 candela
SF18650B: 100,000 candela
(2) 123A: 90,000 candela
DISTANCE SF18350: 616 meters
123A: 469 meters
SF18650B: 632 meters
(2) 123A: 600 meters
CONSTRUCTION Aluminum
FINISH Hard Anodized (MIL-A-8625 Type III, Class 2)
WEIGHT (w/batteries) 4.5 oz (129.3 g) 5.6 oz (158.8 g)
LENGTH 4.8 in (12.2 cm) 5.91 in (15 cm)
BEZEL DIAMETER 1.258 in (3.2 cm)
BATTERIES (1) SF18350 (incl.) / (1) 123A (1) SF18650B (incl.) / (2) 123A
SWITCHING Click Tailcap
All performance claims tested to ANSI/PLATO FL 1-2019 Standard.
SPECIFICATIONS
EDC1-DFT-xx
EDC2-DFT-xx

LOCKOUT TAILCAP (US PAT. RE40125)
To enable, rotate tailcap clockwise until light activates when tailcap
pushbutton is pressed.
To lock out tailcap, rotate counterclockwise until light will not
activate when pushbutton is pressed.
LIGHT OPERATION
Press or click pushbutton tailcap switch once for High output.
Return to Off and press or click on again, within 2 seconds, for Low
output.
BATTERY REPLACEMENT
To load or replace batteries:
1. Unscrew bezel counterclockwise and remove.
2. Remove old batteries and dispose of properly.
3. Insert new 123A lithium battery(ies) or one SF18350/SF18650B
battery with the positive (+) terminal(s) oriented forward.
4. Replace bezel by screwing on clockwise. Press pushbutton
(with tailcap enabled) to test.
BATTERY INFORMATION & WARNINGS
For complete battery information and warnings, reference the enclosed
BATTERY INFORMATION / WARNING insert in your illumination tool’s
original packaging or visit www.surefire.com/batteries.
SAFETY
The internal protection circuit integrated within the battery assembly
provides the following safety features; overcharge, overdischarge,
short circuit, undervoltage, overvoltage.
ENVIRONMENTAL
Storage Temperature Range: 0-35°C. 60±25% RH
Charging: 0°C-45°C, 65%±25%RH
Discharging: -20°C-+60°C, 65%±25%RH
Note: The battery’s metal button top also functions as a heatsink dur-
ing USB charging, which may result in it being very warm to the touch
during the high charge rate period.
ENABLE
DISABLE
PRESS OR
CLICK TO
ACTIVATE
SF18350 SF18650B
VOLTAGE 3.7 V
CAPACITY 1.1 Ahr 3.5 Ahr
CHARGE END VOLTAGE 4.2 V
DISCHARGE END VOLTAGE 2.5 V
STANDARD CHARGE RATE 500mA (USB), External 1A/1C
DISCHARGE RATE 10 A 8-10 A
USB CHARGE VOLTAGE 5.0 V ± 0.2 V
USB CHARGE CURRENT 600 mA ± 100 mA
SPECIFICATIONS
The SF18350/SF18650B are Lithium Ion protected batteries with micro
USB charge capability which allows the user to charge the batteries using
USB power sources such as a USB wall charger, computer, power bank, or
automotive USB port. An external 18350/18650 compatible CC-CV cradle
charger can be used to charge either battery; possibly at a faster rate if
so equipped.
The SF18350/SF18650B can be charged directly through the MICRO-
USB port, requiring no external charge cradle. The SF18350/SF18650B
comes with a 6-inch USB type A plug to Micro USB type B plug, with the
MICRO-USB plug being the end inserted into the battery. The battery side
includes a MICRO-USB type B receptacle. Once the cable is plugged into
the battery and a power source, the two LED indicators display the current
charge state: RED for charging and GREEN for fully charged. The battery
can be left connected to the charge source indefinitely as the internal
charge algorithm will restart the charge cycle once the cell voltage drops
below 4-5% of the float voltage. The charge time using the MICRO-USB
port for a fully depleted battery can be >5 hours. An external charger can
be used to shorten the total charge time. The batteries’ protection circuit
quiescent drain is 40uA, which in addition to the cell self-discharge, which
allows a fully charged battery to maintain usable capacity for 2-3 years.
