1.0 Introduction
This version of the operator’s manual is intended for C-100 consoles with firmware v2.00 or newer.
The BinMaster Model C-100 is a compact control console for a network of BinMaster SmartBob sensors.
It can control from 1 to 120 SmartBob sensors with a few keystrokes or automatically by use of an interval
timer or external start input signal. It has a 4-20mA current output that, in conjunction with the external
start input, provides for a traditional interface to a PLC (programmable logic controller) or DCS (distributed
control system) system. The console was designed with a NEMA 4X rating, thus if it is properly installed
it will be protected from windblown dust and rain. Vessel configuration is quick and easy with a simple
and intuitive user-interface, configurable in either the English or Spanish languages. Measurement
formats can be displayed as headroom percentage, headroom height, headroom weight, product
percentage, product height and product weight. Vessel configuration and user settings are stored in non-
volatile memory and will be retained during a power failure.
The Model C-100 can interface with up to five BinMaster C-50 Expansion consoles on a dedicated RS-
485 network. The Model C-50 is for interfacing the SmartBob system to a PLC or DCS system. Each
Model C-50 expansion console supports up to 6 analog I/O cards, each with 4 ports, for a total of 24
analog I/O ports per C-50. With five C-50’s each SmartBob sensor can have its own I/O port. Each input
can be used for externally starting a measurement and each output provides for a 4-20mA current output
of the last measurement. For more information on the Model C-50, contact one of BinMaster’s application
specialists or go to www.binmaster.com.
2.0 Specifications
Power Requirements
Isolated 24VDC source with 2W (0.085A) minimum output.
A quality earth connection is also required on the power terminal. Although this is not needed for
power or normal operations, it is required for proper protection from lightning and other electrical
surges.
SB-485 Port
RS-485 at 2400 bps using BinMaster’s proprietary half duplex protocol A or B and supporting 1 to
120 SmartBob sensors on up to 4,000 feet of a quality twisted-pair shielded cable.
EX-485 Port
RS-485 at 19,200 bps using a proprietary half duplex protocol to communicate to BinMaster
Model C-50 expansion consoles on up to 4,000 feet of a quality twisted-pair shielded cable.
External Start Input
Continuous monitoring for a dry contact closure to initiate a measurement with a response time of
less than 1 sec.
4-20mA Current Output
Continuous 4 – 20mA current output with 16 bits of resolution into a maximum loop resistance of
700Ω. If weight calculations are DISABLED, the output level is relative to the last measurement
of a user-assigned vessel and its entered height. If weight calculations are ENABLED, the output
level is relative to the calculated weight of a user-assigned vessel and all its entered parameters.
An error condition (did not drop, bob stuck or communications error) can also be presented at this
output with a user-selectable value of either 2mA or 22mA.

925-0270 Rev G 6
Interval Timer for Automatic Measurements
Any number of SmartBobs on the network can be configured for an automatic measurement with
a time between measurements ranging from 0 minutes (continuous) to 49 hours and 59 minutes
in 1 minute increments.
Vessel Parameters
Vessel Height in feet: 1.00 to 299.99 in 0.01 increments
Vessel Height in meters: 0.30 to 89.99 in 0.01 increments
Body Height in feet: 1.00 to 299.99 in 0.01 increments
Body Height in meters: 0.30 to 89.99 in 0.01 increments
Body Radius/Width in feet: 0.10 to 59.99 in 0.01 increments
Body Radius/Width in meters: 0.10 to 19.99 in 0.01 increments
Hopper Height in feet: 0.10 to 29.99 in 0.01 increments
Hopper Height in meters: 0.10 to 8.99 in 0.01 increments
Outlet Radius/Width in feet: 0.10 to 8.99 in 0.01 increments
Outlet Radius/Width in meters: 0.10 to 2.99 in 0.01 increments
Sensor Offset in feet: -99.99 to 99.99 in 0.01 increments
Sensor Offset in meters: -29.99 to 29.99 in 0.01 increments
Product Density in lbs/cu ft: 1.00 to 199.99 in 0.01 increments
Product Density in kg/cu m: 16.00 to 3,999.99 in 0.01 increments
Displayed Measurement Accuracy
Headroom Height: +/-0.01 of reading plus the accuracy of the SmartBob sensor.
Product Height: +/-0.01 of reading plus the accuracy of the SmartBob sensor
plus the accuracy of the entered vessel’s height.
Volume / Weight: +/-0.01 of reading plus the accuracy of the SmartBob sensor
plus the accuracy of all entered vessel parameters.
4-20mA Output Accuracy
Headroom Height: +/-0.16% plus the accuracy of the SmartBob sensor.
Product Height: +/-0.16% plus the accuracy of the SmartBob sensor plus the
accuracy of the entered vessel’s height.
Volume / Weight: +/-0.16% plus the accuracy of the SmartBob sensor plus the
accuracy of all entered vessel parameters.
Ambient Temperature
Storage: -4°to 158°Fahrenheit (-20°to 70°Celsius)
Operating: -4°to 158°Fahrenheit (-20°to 70°Celsius)

925-0270 Rev G 7
Physical
Dimensions: 6.5 x 6.3 x 3.5 inches (166 x 160 x 89 mm)
Weight: 1.5 lbs (0.7 kg)
Enclosure: Polycarbonate, light industrial gray.
Ingress Protection Rating NEMA Type 4x
3.0 Installation
3.1 Mounting
When locating a position to mount the C-100 SmartBob control console, make sure to allow for adequate
air flow around the unit and don’t place it near any equipment that produces excessive heat. If the
ambient temperature of the C-100 is going to exceed 122°F (50°C), consider using a fan of some type to
circulate the air. Allowing for good air flow around the C-100 will prolong the life of the unit. Also, to
prolong the life of the unit’s enclosure and front panel, avoid a location that would place it in direct and
constant sunlight.

925-0270 Rev G 8
3.1.1 Screw Mount
There are three screw holes that can be used for mounting the C-100 SmartBob control console as
shown in the diagram below. You will need one #8 wood screw at least 3/8” long and two #8 wood
screws at least 5/8” long.
1. Locate, drill a hole for and screw the 3/8” long screw into the mounting board/plate, leaving the
head of the screw out about 1/8”.
2. Hang the console with the one screw by the center mounting tab.
3. Remove the lower wiring cabinet cover and mark the locations for the two lower mounting screws
with a pencil or awl.
4. Remove the console and drill holes for the two lower mounting screws.
5. Hang the console again by the center mounting tab and fasten in place with the two lower
mounting screws.

925-0270 Rev G 9
3.2 Connections and Wiring
A minimum configuration will require a three-wire power connection and a three-wire RS-485 connection
to the SmartBob network. Optionally, there may be a two-wire 4-20mA connection, a two-wire external
start connection and another three-wire RS-485 connection for the Expansion network.
All wiring is fed through water-tight cordgrips and connected inside the lower wiring cabinet to pluggable
terminal blocks mounted on the printed circuit board. Remove the two screws on the lower wiring cabinet
cover to gain access to the terminal blocks. When wiring is complete, be sure that the lid is properly
fastened down for a water and dust-tight seal. Never remove or unscrew the nameplate lid with the
keypad and LCD window.
There are a total of five terminal blocks but only four cordgrip/entry points inside the wiring cabinet. It is
recommended that if all terminal blocks are being used, that the 4-20mA Output (CN3) and the External
Start Input (CN4) share the same cordgrip/entry point.
All five terminal blocks are capable of supporting 22 to 12 AWG size wires. Be sure to use the
appropriate wire gauge/size for the connections and follow all national and local codes concerning this
installation.
3.2.1 Power Connection
The power connection (CN8) is a three wire terminal block located on the far right. Two terminal screws
marked + and – are for connecting to a 24VDC source, isolated from earth ground. See section 2.0
Specifications for power source requirements. Due to the low power requirements of this console, a 16 or
18 AWG wire would be sufficient for these two power connections.
The terminal screw marked with the symbol should be connected to a quality earth for proper
protection from lightning and other electrical surges induced in an industrial environment. It is
recommended to use a 16 AWG wire or larger for the earth connection and connect it to the closest
possible source to earth.
It is recommended to use a separate isolated power source for every device on a SmartBob system. This
will provide additional protection from lightning and other electrical surges.
All three connections at CN8 are required for proper operation and protection of the console.

925-0270 Rev G 10
3.2.2 SB-485 for SmartBob Network
The SB-485 connection (CN7) is a three wire terminal block located near the center of the printed circuit
board and is for connection to the SmartBob RS-485 network. Two terminal screws marked + and –
should be connected to the positive and negative wires of the SmartBob network cable. The third
terminal screw marked SH should be connected to the shield of the SmartBob network cable. Do NOT
connect the shield to earth.
All three connections at this terminal block are required in order to properly communicate to any
SmartBob sensors.
A good quality twisted-pair shielded cable should be used for the SmartBob network. The cable should
connect to each device on the SmartBob network in a daisy-chain fashion. Branch lines or splits are not
recommended. The maximum length of the cable should be 4,000 feet or 1,220 meters.
The C-100 SmartBob control console has permanent biasing resistors for the SmartBob network, so
remove or un-switch any other bias resistors on all other devices connected to this network.
Devices located at the ends of the SmartBob network must be properly terminated. For the two devices
located at the ends, switch in their NTR or termination resistor. The C-100 SmartBob control console can
be located anywhere along the SmartBob network and has a software menu for switching it’s termination
in or out of circuit.
3.2.3 EX-485 for Expansion
The EX-485 connection (CN6) is a three wire terminal block located near the center of the printed circuit
board and is for connection to the Expansion RS-485 network. Two terminal screws marked + and –
should be connected to the positive and negative wires of the RS-485 network cable. The third terminal

925-0270 Rev G 11
screw marked SH should be connected to the shield of the RS-485 network cable. Do NOT connect the
shield to earth.
These three connections at this terminal block are optional and only needed when connecting BinMaster
C-50 expansion units to the system.
A good quality twisted-pair shielded cable should be used for the RS-485 network. The cable should
connect to each device on the network in a daisy-chain fashion. Branch lines or splits are not
recommended. The maximum length of the cable should be 4,000 feet or 1,220 meters.
This port has built-in line biasing and termination.
3.2.4 External Start Input
The External Start connection (CN4) is a two wire terminal block located towards the left of the printed
circuit board. It is identified with CN4 and an open switch symbol. These two terminal screws are polarity
independent and are intended only for a dry contact closure, such as a relay output from a PLC or a
pushbutton switch. This connection does not source or sink any negligible amount of current so a quality
twisted-pair cable of 20 to 22 AWG wiring is sufficient. A shielded cable is not required; however, if one is
used leave the shield un-connected at the console.
The External Start connection is optional and only needed when a PLC/DCS or remote pushbutton switch
is needed to initiate a measurement. This input can only trigger one SmartBob sensor but can be
assigned to any one on the network. This input is negative edge-triggered, meaning the dry contact must
be cycled open and then closed again to initiate a new measurement.

925-0270 Rev G 12
3.2.5 4-20mA Output
The 4-20mA Output connection (CN3) is a two wire terminal block located on the far left of the printed
circuit board. It is identified with CN3 and labeled with 4-20. The two terminal screws marked + and –
should be connected to the proper positive and negative wires of the load. This output is powered and
capable of driving up to a 700Ωloop. Depending on the distance this wiring must go, a quality twisted-
pair cable of 18 to 22 AWG wiring is sufficient. A shielded cable is not required; however, if one is used
leave it un-connected at the console.
The 4-20mA Output connection is optional and only needed when a 4-20mA output is needed to feed a
PLC or DCS system of the last measurement taken. This output can only represent one SmartBob
measurement but can be assigned to any SmartBob sensor on the network.
3.3 RS-485 Network Requirements
Both the SmartBob network (SB-485) and the Expansion network (EX-485) use RS-485 wiring and data
signaling techniques and must meet certain criteria for reliable operation. If these criteria are not met,
communications errors will most likely occur and result in failed measurements. Troubleshooting
communications errors can be expensive and time consuming, so BinMaster strongly encourages you to
take adequate time in understanding and installing the RS-485 networks and to use quality cabling and
connection techniques.
Summary of RS-485 requirements for BinMaster products:
•All devices must be wired or connected in a daisy-chain fashion.
•Use a quality twisted-pair cable with shield.
•Maintain correct polarity between all devices wired to the network cable.
•The two ends of the network cable must be terminated.
•Biasing must be applied in only one place anywhere along the cable or network.
•All devices on the network must support and be configured for the same protocol.

925-0270 Rev G 13
Wiring
All devices on an RS-485 network must be connected directly to the network cable with no splits,
taps or branch lines. The overall length of the cable must not exceed 4,000 feet or about 1,220
meters. Use a quality twisted-pair cable with shield and connect as per the wiring diagram in
section 3.5. Observe the polarity of the wiring between all devices on the network, making sure
that the wire connected to the + terminal at the C-100 SmartBob control console is also
connected to the + terminal on all other devices. Likewise, make sure that the wires connected to
the – and SH terminals at the C-100 SmartBob control console are also connected to the – and
SH terminals, respectively, on all other devices. Do not connect the wires or shield to anything
other than that specified.
Termination
All BinMaster RS-485 networks must be terminated at both ends with a 120Ωresistor for proper
operation and reliability. Normally this is done by the two devices connected at the very ends of
the network cable. On some devices the termination is set ON or OFF by a slide switch labeled
“NTR” and on other devices this may be set IN or OUT of circuit through a software menu.
The C-100 console uses a software menu titled “SB-485 Termination” for switching the
termination resistor IN or OUT on the SB-485 port. For the EX-485 port, the C-100 console has
the termination resistor permanently switched in and therefore the C-100 console must be located
at one end of the network. Refer to the manual of the other devices for instructions on how to
switch their termination.
Bias Resistors
All BinMaster RS-485 networks must have bias resistors installed or switched in for proper
operation and reliability. This must be done at only one device but anywhere along the network
cable.
The C-100 SmartBob control console has bias resistors permanently switched in for both the SB-
485 port and the EX-485 port, so for all other devices connected to either of these networks make
sure that the bias resistors are turned OFF or switched OUT of circuit. Refer to the manual of
these other devices for instructions on how to do so.
Protocol
All devices on an RS-485 network must be configured to use the same protocol. BinMaster
supports two protocols for the SmartBob network. Protocol A is newer, more reliable and more
efficient while protocol B is older and supported for legacy products. It is recommended to use
protocol A if all the devices on the SmartBob network support it; otherwise use protocol B.
Depending on the device, selecting the SmartBob protocol may be done with a switch, a jumper
position or a software menu. The C-100 SmartBob control console uses a software menu titled
“SB-485 Protocol” for configuration between SmartBobs protocol A or B. Refer to the manual of
the other devices for instructions on how to set or configure their SmartBob protocol.

925-0270 Rev G 14
3.4 Lightning/Surge Protection
All electronic devices connected to a large wired network are susceptible to damage from lightning and
other sources of electrical surges. Both the power source and an RS-485 network are a means for
electrical surges to enter the C-100 SmartBob control console and do damage. Although some level of
protection from electrical surges is built into the C-100 SmartBob control console, there are options to
further protecting your investment.
1. As recommended for the power connection at CN8, use an isolated power source and verify that
the output is NOT grounded or referenced to earth. Make sure that all devices connected to
either the SmartBob network or Expansion network uses a separate power source.
2. Be sure to connect the terminal at CN8 marked to a good quality earth using a 16 AWG size
wire or larger. This wire should be as short as possible to earth with no sharp bends or loops in
the wiring.
3. Use additional external lightning/surge arrestors on the RS-485 networks. This is very critical of
large outdoor networks that are high off the ground. Place 1 to 3 surge arrestors on the RS-485
network evenly spaced apart, following the manufacturer’s installation instructions and using a
good quality connection to earth.
4. Consider using BinMaster wireless solutions that not only greatly protect your investment from
lightning but can reduce installation time and eliminate the need for running long lengths of RS-
485 cable. Call BinMaster and speak with one of our applications specialist for more information
on our wireless solutions.

925-0270 Rev G 15
3.5 Wiring Diagram

925-0270 Rev G 16
4.0 Operation and Setup
The C-100 SmartBob control console is controlled and operated through the use of a 6-button icon-based
keypad and a simple intuitive text-based menu system. The menu system is user-selectable in either the
English or Spanish languages.
4.1 Keypad
The keypad consists of 6 membrane style keys appearing as shown to the right.
Four of them are labeled with left, right, up and down arrow keys and are used for
navigating menu selection bars and character cursors.
Another key is labeled with a (cross out) for cancel or escape and is generally used
to stop an action or to exit a screen without taking action.
The final key is labeled with a (check mark) for Ok and is generally used to accept
the current selection and/or to advance to the next screen.
Most operations will simply require a single press and release of a key; however
some operations may benefit from a key being held. For instance, holding the up or
down arrow keys will allow the user to continuously scroll through long lists of vessel
measurements. In some menus, the left and right arrow keys serve as a page up and page down key for
faster navigation through long lists. Also, in some menus with long lists, you can press the left and up
arrow keys simultaneously for a jump to the top of the list and pressing the right and down arrow keys
simultaneously for a jump to the bottom of the list.
4.2 Menu System
Each menu and/or screen maintains a common format for ease of understanding and use. The example
screen below shows a few of the common items found on most screens.
Scroll Up Indicator
Scroll Down Indicator
Selection Bar
Menu/Title Bar
Setting Indicator
The Menu/Title Bar will always be present at the top and identify the current menu or screen to the user.
Below that will be up to three lines of text or selection items, depending on the current menu or screen.
The Selection Bar is repositioned vertically with the / keys and is used for making a selection in a
menu. Normally a selection isn’t accepted until the key is pressed.
The Setting Indicator, displayed as a check mark towards the left of the screen, is used in various places
under the Setup Menu to indicate current or active settings.

925-0270 Rev G 17
The Scroll Up and Down Indicators, displayed as little up and down arrows towards the right of the
screen, will be present when more selections or information is available off screen. The Scroll Up
Indicator will be present when the user can scroll up to obtain more selections or information and the
Scroll Down Indicator will be present when the user can scroll down to obtain more selections or
information.
Navigating through the menu system is straight-forward, position the selection bar on the desired menu or
selection item and press the key. To go back a menu or escape from the current screen, press the
key. The menu system is structured as shown in the following diagram.
Main Menu Measure/View
Setup SB-485 Protocol
SB-485 Termination
Auto Add/Remove
Add/Remove
Units of Measure
C-50 Setup
I/O Assignment
4-20mA Output
4-20mA Error
Interval Timer
Access Code
Language/Idioma
Vessel Setup
Weight Calculations
Measurement Format
Measure All
001
Info/About
Capacity
Headroom
Product
002 Capacity
Headroom
Product
more... up to 120
Measurement Type

925-0270 Rev G 18
4.2.1 Main Menu
The Main menu has two selections: Measure/View and Setup. Select Measure/View if you want to take
an immediate measurement or view the results of the last measurement. Select Setup if you need to
change user display preferences, setup vessel parameters, SmartBob network settings or configure the
Expansion network. The main menu is at the top of the menu system, so pressing the key here will
have no effect.
4.2.2 Measure/View
The Measure/View menu provides a full listing of all the last measurement
results and a means to initiate a measurement. It will always have at least
two selections. The first selection will always be Measure All and selecting
it will immediately start a measurement process on all configured
SmartBob sensors. The second selection and any following selections will
contain the last measurement data next to its associated SmartBob
address. Note that SmartBob sensors are identified by their address and are always displayed with three
digits ranging from 001 to 120. Selecting any of the measurement data will bring up the details screen for
that SmartBob. If there is only one SmartBob sensor configured on the network then there will only be
two selections in this menu. If you have multiple SmartBob sensors configured, then you can scroll
through this menu to see them all. The title bar will also indicate whether the measurement data is of the
headroom (Hdrm) or of the product (Prod), as set under Measurement Format. Note that ‘headroom’
refers to the upper empty space in the tank and ‘product’ refers to the lower filled space.
The details screen displays additional data for a particular SmartBob and
provides a means to take a measurement with that particular SmartBob by
pressing the key. Use the / keys to cycle through all the data
(capacity, headroom and product) for the selected vessel and SmartBob.
In each mode, the percentage and height are displayed, as is volume or
weight if weight calculations are enabled. If the vertical scroll indicators
are present, the operator can scroll to other SmartBob measurement results.
The accuracy of these readings is dependent on both the SmartBob reading and the vessel parameters
entered into Vessel Setup.
4.2.3 Setup
The Setup menu has selections for setting user preferences, configuring the SmartBob network, the
Expansion network and defining SmartBobs and associated vessels. All settings and configurations
made will be retained during a loss of power.
SB-485 Protocol
This is a menu for setting which communications protocol to use on the SmartBob network, the
operator can choose A or B. The default setting is A.
All devices on the SmartBob network must be configured to use the same protocol. Protocol A is
newer, more reliable and more efficient while protocol B is older and supported for legacy
products. It is recommended to use protocol A if all the devices on the SmartBob network
support it; otherwise use protocol B. The protocol must be configured prior to running Auto
Add/Remove or any measurement process. See the SBRII or SB-TS1 manual for their protocol
jumper settings.

925-0270 Rev G 19
SB-485 Termination
This is a menu for setting whether the SmartBob network termination is switched In or Out of the
network. If the console is the final device connected at either end of the SmartBob network
choose In, otherwise choose Out. The default setting is In. The termination must be set prior to
running Auto Add/Remove or any measurement process.
Auto Add/Remove
This is a process the operator can choose to let the console automatically scan and detect any
SmartBob sensors on the network. After selecting Auto Add/Remove, it will begin searching for
SmartBob sensors currently connected to the network, adding or removing them from the working
list. If there are existing SmartBobs enabled, a confirmation screen will appear to make sure you
want to re-scan for new and removed SmartBob sensors. Press to cancel or to confirm.
The operator can choose to let it scan all the way to 120 or stop it once they feel it has found
them all.
Since this process uses SB-485 communications, make sure that SB-485 Protocol and SB-485
Termination have previously been set.
Add/Remove
This is a menu that allows the operator to manually add or remove SmartBob sensors to the
console’s working list. Use the , and keys to select and accept one or more SmartBob
addresses from the list to be configured for use. After all desired addresses are assigned, use
the key to exit.
Units of Measure
This is a menu for selecting the units used for entering vessel dimensions and product density in
Vessel Setup. It also determines the units used for readings when Measurement Format is set
for Height or Cubic Units. If weight calculations are enabled, your two choices are English (ft, lbs)
or Metric (m, kg) with the default being English (ft, lbs). If weight calculations are disabled, your
two choices are Feet (ft) or Meters (m) with the default being Feet (ft).
Changing this setting will convert all stored vessel parameters from one system to the other.
Weight Calculations
This is a menu for enabling or disabling volume and weight calculations. The default is disabled.
By enabling weight calculations, the operator will be able to view measurement results as a
volume or weight in various units. The option to disable this feature is provided due to the
complexity of entering vessel parameters that may not be needed on some systems.
This setting will have an effect on the following:
1. The amount of data to be entered under Setup > Vessel Setup.
2. Selections available under Setup > Measurement Format.
3. Data presented under Measure/View.
4. Data represented by the 4-20mA output.
Vessel Setup
This is a menu for entering the vessel parameters associated with the SmartBob addresses
previously configured in Add/Remove or Auto Add/Remove. Defining vessels accurately is critical
in obtaining accurate measurement data of weight or product height.

925-0270 Rev G 20
If weight calculations are disabled, this is simply for setting the overall height of the vessel, sensor
offset and maximum drop. The first screen is for selecting the vessel(s) to be configured, the
second screen is for entering the vessel height of the selected vessel(s), the third screen is for
setting a headroom offset and the fourth for setting maximum drop distance.
Vessel Selection – This is for selecting which vessel or vessels to configure parameters
for, choose either Set All or one particular vessel. If all vessels are to be the same or
similar use Set All, otherwise configure one at a time.
Vessel Height – For setting the overall height of the vessel.
Sensor Offset – For setting the offset or distance between the sensor and the full mark.
A positive value places the sensor below the full mark or down in the tank. A negative
value places the sensor above the full mark or up outside the tank.
SmartBob Max Drop – For setting the maximum drop distance the SmartBob will drop its
probe. If set to some value less than the height of the vessel, it would prevent the
SmartBob from dropping its probe down through the hopper outlet and into an auger.
Note: This feature is only available when configured for protocol A and will not function
properly unless the SmartBob contains firmware v2.8 or newer. Due to detection time
within the SmartBob itself, it may actually drop up to 1.5 inches more than this setting.
If weight calculations are enabled, this is a multi-page menu for entering vessel parameters and
product density required in calculating weight. Following is a listing of the different Vessel Setup
pages and a process flowchart.
Vessel Selection – See description above.
Vessel Shape – For setting the shape of the previously selected vessel(s), choose
between circular or rectangular.
Body Height – For setting the height of the vessel’s body. Note that this is just the main
body of the vessel and not the overall height.
Body Radius – For setting the radius of a circular vessel’s body.
Body Width 1 & Body Width 2 – For setting the two widths of a rectangular vessel’s body.
Hopper Present – Choose between Yes or No on whether a hopper is present.
Hopper Height – For setting the height of the hopper, if it exists.
Outlet Radius – For setting the radius of a circular hopper’s outlet, if a hopper exists.
Outlet Width 1 & Outlet Width 2 – For setting the two widths of a rectangular hopper’s
outlet, if a hopper exists.
Sensor Offset – See description above.
Product Density – For setting the weight density of the product or contents of the vessel.
SmartBob Max Drop – See description above.
