User Guide
B350
3rd edition
www.binatonegps.com
Binatone Navigation software

IMPORTANT
1Binatone Help Line: 0845 345 9677 (for UK only. Local Call rate)
IMPORTANT
Satellite signals are required for this product to function in Navigation Mode.
There may be occasions within your home or surrounding area when the signal
strength is limited and Navigation Mode may not be possible.
This is quite normal for product of this type.
You can check the number of satellite signals that the unit is receiving and the
strength of those signals by viewing the GPS Receiver.
If you need help....
The Help line is available from 9:00am to 5:00pm, Monday to Friday, on 0845
345 9677 Calls are charged al Local Call rate (for UK only)
Unpacking your Binatone Navigation System
B350
In the box you will find
·GPS navigation device
·Car mounting kit
·In-car charger
·USB cable
·User guide
Keep the packaging materials in a safe place in
case you later need to transport the unit. Keep your
sales (till) receipt, which is your guarantee. Before
you can use the unit, you’ll need to fully charge the
battery as described on page 6, please also read
the notes on the page 2.
WARNING:
Your GPS device operates under open sky
conditions in order to receive a satellite signal.
Please ensure that you are not using the device
indoors or in areas where the satellite signal is
weak.
For the first time of use or after a few days of no
use, it may take up to 10 minutes to acquire a
satellite signal. It is recommended to be stationary
during the start up process.
*USB cable can be either used to charge your device with you computer or
update your system (latest map and software, latest safety camera information)
via your computer and the internet (updates are payable). Charging via USB
cable will be faster when the unit is powered off.

SAFETY
2Binatone Help Line: 0845 345 9677 (for UK only. Local Call rate)
Safety
The Global Positioning System
The Global Positioning System (GPS) is a satellite based system that provides
location and timing information around the globe. GPS is operated and controlled
under the sole responsibility of the Government of the United States of America,
who are responsible for its availability and accuracy. Any changes in GPS
availability and accuracy, or in environmental conditions, may impact the
operation of you Binatone Carrera Personal Navigation Device (PND).
Using Your PND in the Car
When using your PND while driving it is essential that you drive with due care
and attention. Never modify the settings or program your PND while driving. Only
look at he PND map when it is safe to do so. When mounting the PND in your car
make sure that it does not obscure your view or impede the operation of any
driving controls.
Prohibited Areas
Do not operate your PND in hospitals or near any electrical medical equipment.
Do not operate your PND in aircraft.
Do not operate while sat in a petrol station forecourt.
Battery
Your PND uses a Li-polymer battery. Do not use it in humid, wet or corrosive
environments. Do not operate or store your PND in high temperatures (>60℃) or
in direct sun light. Do not pierce or break the battery casing.
Failure to follow these cautions will invalidate the warranty and may
cause the battery to leak acid, become hot, explode or ignite and
cause injury or damage.
If you come into contact with leaked battery acid wash the contact
area thoroughly and seek medical attention.
The Li-polymer battery contained in this unit must be recycled or
disposed of properly.
Do not dispose of in household waste or burn.

CONTENTS
3Binatone Help Line: 0845 345 9677 (for UK only. Local Call rate)
CONTENTS
Important………………………………………………………………………. 01
In the Box ……….………………………………………………………... 01
Safety …………………………………………………………………………… 02
The Global Positioning System ……………………………………………02
Using Your PND in the Car .…………………………………………….. 02
Prohibited Areas .…………………………………………………….…… 02
Battery..…………………………………………………………………….. 02
Contents .………………………………………………………………………. 03
Quick Start Guide …………………………………………………………… 05
Position of the Controls ………………………………………………… 05
Charging the Battery ……………………………………………………. 06
SD Memory Card ………………………………………………………... 06
Car Adaptor ……………………………………………………………… 06
Turning the Sat Nav Unit On/Off ……………………………………….. 07
Turning the Sat Nav Unit Off (Sleep Mode) .………………………….. 07
System Reset ……………………………………………………………. 07
Windscreen Holder Installation ………………………………………… 08
Getting Started …….…………………………………………………………. 09
Starting Up ... ……………………………………………………………… 09
Settings ……………………………………………………………………. 10
Multi-Media ………………………………………………………………… 11
Picture Viewer..……………………………………………………... 11
Document Viewer …………………………………………………... 12
GPS Receiver ……………………………………………………………… 12
Additional maps and upgrades ……………………………………………13
INTRODUCTION……………………………………………………………….. 14
Navigate to .…………………………………………………………………… 17
Entering your Waypoints/destination ………………………………….. 18
Address ……………………………………………………………... 18
POI (Points of Interest).……………………………………………. 20
POI Near You ………………………………………………………. 20
POI in City …………………………………………………………... 21
Favourites …………………………………………………………… 22
Recent Destinations………………………………………………... 22
Map …………………………………………………………………... 23
Browse Map Options …………………………………………… 23
Zoom to Address ……………………………………………….. 23
View POI ………………………………………………………… 23
Zoom to Current Pos ………………………………………….. 23
Night/Day ………………………………………………………. 23
3D/2D Map View ………………………………………………. 24
Show Trace Record …………………………………………… 24
Coordinates…………………………………………………………. 25
Navi/Simulate …………………………………………………………….. 26

CONTENTS
4Binatone Help Line: 0845 345 9677 (for UK only. Local Call rate)
Navigation Screen…………………………………………………... 27
Navigation Options…………………………………………………. 28
View Route ……………………………………………………… 28
Navi Settings…………………………………………….……... 28
Save Map View………………………………………………… 29
Night/Day ……………………………………………………….. 30
3D/2D …………………………………………………………… 30
Brightness….…………………………………………………… 30
Volume …………………………………………………………. 30
Road Block……………………………………………………... 30
Trace Record…………………………………………………… 30
GPS Status ……………………………………………………. 30
Main Menu.……………………………………………………… 30
Simulation Screen…………………………………………………... 31
View Route ……………………………………………………... 31
Simulate.………………………………………………………… 31
Back …………………………………………………………….. 31
GO .……………………………………………………………… 31
Route Options………………………………………………….. 32
Driving Method………………………………………….. 32
Routing Style .…………………………………………. 32
Routing Parameters……………………………………. 32
Go Home……………………………………………………………………….. 33
Edit Favourites ………………………………………………………………. 33
Add………………………………………………………………………... 33
Edit………………………………………………………………………… 34
On Map.…………………………………………………………………… 34
Recent Destinations ……………………………………………………… 34
View Map …………………………………………………………………….. 35
Settings ……………………………………………………………………….. 36
Language…………………………………………………………………. 36
Set Home Address………………………………………………………. 36
Units ………………………………………………………………………. 36
Brightness………………………………………………………………… 36
Volume ……………………………………………………………………. 37
About ……………………………………………………………………… 37
GPS Status …………………………………………………………………… 37
Time Zone Setting ………………………………………………… 38
Safety Cameras …………………………………………………………… 38
Frequently asked questions ………………………………………… 39
Technical Specifications ………………………………………………. 40

QUICK START GUIDE
5Binatone Help Line: 0845 345 9677 (for UK only. Local Call rate)
Quick Start Guide
Please make sure that your read all of the information contained within this user
guide before operating this unit.
If you experience any problems, please go through the user guide before contacting
the customer helpline.
Position of the controls
1. Touch Screen
2. Charge Indicator – Displays the battery charging status.
Red or Orange; charging, Green; fully charged.
3. On/Off Switch – Turn the unit On/Off using this switch, if the unit is not to be
used for long periods of time.
4. Reset – System reset switch.
5. Speaker – For voice guidance instructions.
6. Memory Card Slot – For use with SD type cards. Do not remove memory
card while in use.
7. Power Connection USB Port – For charging and data transfer.
8. Sleep mode Button – Switches the unit In/Out off sleep mode, handy when
stopping for short periods to conserve battery power.

QUICK START GUIDE
6Binatone Help Line: 0845 345 9677 (for UK only. Local Call rate)
Charging the Battery
Before using your PND for the first time, we recommend you to charge the unit for 5
hours via the USB cable, or 2 hours via the car charger in order to charge the
battery.
Plug the USB cable, or the car charger into the USB socket
The charging indicator on the front of the unit will light up red or orange. When the
unit is fully charged the red light will turn green.
When you use the PND in you car, we recommend that you always use the car
charger in order to maintain the battery level.
If you have a SD memory Card, you may install it refer to the picture
(below)
Switch the unit off first before installing or removing the SD card.
When installing it can only be fitted one way – the contacts should be towards you
and the cut-off corner at the top. Slide the card in and push it in so that it clicks into
place.
Once the card is installed it does not need to be removed.
If you need to remove the card, push the card in and it will eject from the slot.
Car Adapter
When using your PND in the car we recommend that you always use the in-car
charger to power the unit, especially on long journeys.
Plug the in-car charger into the USB socket of the unit. Pug the other end of the
adapter into the car’s cigarette-lighter / 12V DC socket.

QUICK START GUIDE
7Binatone Help Line: 0845 345 9677 (for UK only. Local Call rate)
Turning the Sat Nav Unit On/Off
To switch the unit On slide the power switch located on the back of the unit to the On
position, the unit will power up and display the warning screen.
To switch the unit Off slide the power switch to the Off position.
Turning the Sat Nav Unit Off Via Sleep Mode
Press and hold down the sleep button on the top of the unit, after about 3 seconds
the unit will enter sleep mode. Press and hold the button again, to bring the unit out
of sleep mode. When brought out of sleep mode the unit will show the same screen
as when the unit entered sleep mode.
If the unit is not to be used for a long period of time it is advised that you slide the
power switch on the back of the unit to Off.
System Reset
Under extreme circumstances it may be necessary to reboot the system. Reset the
system if the following situation occurs:
•Long delay experienced with screen refresh rate or operation, resulting in an
inoperable unit.
•The system will not turn Off with the power button.
•No response with selection made on the screen.
The reset button can be found on the back of the unit. Insert the tip of the stylus pen
into the reset switch in order to press. The system will be immediately reset.

QUICK START GUIDE
8Binatone Help Line: 0845 345 9677 (for UK only. Local Call rate)
Windscreen Holder Installation
The car mount has a suction pad that fits to the windscreen or a flat area on the
dashboard.
A. Fitting to windscreen
Pull the lever away from the suction pad. Place the pad on the widescreen and push
the lever towards the pad until it clicks into place.
B. Fitting the holding bracket
It is best to fit this to the unit before it is attached to the windscreen.
Slide the bracket onto the securing lug on the end of the ball mount at the end of the
car mount and then push down firmly, until it clicks in to place. The bracket can only
be fitted one way.
C. Fitting the Unit
Slide the unit into the bottom of the bracket and carefully push the unit up and back
until it clicks into place at the top.
To remove the unit from the car mount; Press and lift the tab at the top of the bracket
then pull the unit forward and up out of the bottom of the bracket.
To remove the Car mount from the windscreen; Lift the lever away from the
windscreen, then gentle pull the tab on the suction cup to release the suction as you
pull the mount away from the windscreen.

GETTING STARTED
9Binatone Help Line: 0845 345 9677 (for UK only. Local Call rate)
Starting Up
Turn the power switch on the side panel to ON.
The following screens will be displayed:
When you press MENU, the following screens will be displayed:

GETTING STARTED
10 Binatone Help Line: 0845 345 9677 (for UK only. Local Call rate)
Settings
NOTE: You do not need to enter the SETTINGS menu before you start to navigate.
If you press on the SETTINGS icon the following screen is displayed.
To exit this page or exit any subsequent page, press the cross at the top of the
screen.
Volume
Press ’volume’ you can modify the volume level of the voice prompts. You can
increase or decrease the level by clicking “ ” or “ ”. This can also be done via
the navigation software later.
Backlight
Press ‘Backlight’ to change the brightness of the screen. You can make it darker or
brighter by clicking “ ” or “ ”. This can also be done via the navigation software
later.
Time & Date
This device can auto-set the current date and time by receiving three GPS signals.
However you can also change it by yourself by
1.) Click
2.) Clicking on and to scroll to the right year, month, date, time and time
format.
Note: the unit does not save the time & date when the unit is switched off, this
is because the unit automatically sets the time & date from the satellite signals.
Power
The power page contains the information of your battery level.
Language
Press ”Language” to change the language by clicking << and >>
About
The About page contains information about your software version.
It also allows you to default the unit or to calibrate the screen to your touches.
The unit will be returned to how it was when it left the factory. After selecting this
option you will be asked to confirm.

GETTING STARTED
11 Binatone Help Line: 0845 345 9677 (for UK only. Local Call rate)
Default
Reset to factory default settings.
Calibrate
This function calibrates the unit to respond to your screen taps. You will need to use
this function only if the unit begins to respond inconsistently to your screen taps, then
follow the on screen dissections. Once the calibration has been completed, press
anywhere on the screen to return to the previous menu.
Multi Media
NOTE: if you press on the MULTI MEDIA icon the following screen is displayed.
Picture Viewer
This device supports, .bmp, .jpg and .gif file formats only (recommended picture size
for optimum usage: 500kb – it is not recommended to view pictures over 2mb). Press
the “Picture viewer” to show a list of names for all the picture files then click on the
file you want to view.
To view pictures (bmp and jpeg formats only):
1) Copy all the pictures you want to view onto a SD card.
2) Insert your SD card into the PND.
3) Select Multi Media and then Picture viewer a list of pictures or folders containing
pictures will be shown.
4) Click on folder to open it and then click on a picture to load it into the viewer.
The following screen will be shown:

GETTING STARTED
12 Binatone Help Line: 0845 345 9677 (for UK only. Local Call rate)
Document Viewer
This device supports, txt file format viewing only. Press the “Doc Viewer” to show the
list of files available for viewing. The procedure for viewing documents is the same
for viewing pictures. But once loaded the following screen will be shown.
GPS Receiver
NOTE: This page is for information only. You can view the number of satellite signals
the unit is receiving also the strength of these signals.
This page gives your current position in degrees longitude and latitude, your current
speed and the status of your position, i.e. Fixed 3D or Fixed Invalid etc.
The compass circle shows the satellites that the unit is receiving and the bar chart
shows the signal strength for these satellites

GETTING STARTED
13 Binatone Help Line: 0845 345 9677 (for UK only. Local Call rate)
NOTE:
At least four GPS signals are required for the PND to function.
There may be occasions within your home or surrounding area when the
signal strength is limited and GPS navigation Mode may not be possible.
This is quite normal of products of this type.
Additional maps and upgrades:
Please visit on www.binatonegps.com website for more information.

INTRODUCTION
14 Binatone Help Line: 0845 345 9677 (for UK only. Local Call rate)
Introduction
You have chosen a cutting-edge navigation system. Congratulations! Please enjoy
using it. This navigation system leads you straight to your destination, whether you
are travelling by car or on foot. You can navigate and plan your route with an easy-
to-use and intuitive interface, just by using your finger. You can also use this
application to plan your trip to suit your personal preferences and interests and to
save interesting destinations before your set off on your journey.
This manual leads you through the main features of the system.
GPS connection
Your navigation device uses GPS technology for navigation. The device receives
signals from a number of GPS satellites in order to determine your current position.
•Place your navigation device in a location with an unobstructed view to the sky to
set up your first satellite connection. In the car this will usually mean mounting the
unit on the lower part of the windscreen.
Note; It may take up to 10 minutes to establish the first connection.
Subsequent connections will be faster (30 seconds to 1 minute), but if you
have not used the unit for several days or are far away from the last location
where you used the unit, it may take up to 10 minutes again to find a strong
signal.

NAVIGATION MENU
15 Binatone Help Line: 0845 345 9677 (for UK only. Local Call rate)
Getting Started
Please make sure that the battery in your device is charged.
Switch on the unit and from the menu select Navigation. The navigational software
will start to load.
You will first see the warning statement screen tap on “I accept” to confirm that you
have read the statement and to continue. If you do not wish to be shown this screen
in the future check the box next to “Don’t show this statement again”. You will now
be shown the Binatone screen, which shows the progress of the loading software on
the yellow bar at the bottom.
Once the software has loaded you will be shown the navigation main menu, this is
the starting point for all your navigating needs.

NAVIGATION MENU
16 Binatone Help Line: 0845 345 9677 (for UK only. Local Call rate)
Navigate to – Opens the destination page. From here you can select a
point to navigate to or you can select a start/destination point and then simulate the
route between them, just as if you were driving it. You can also gain access to the
route options so that you can set your driving preferences.
Go Home – This allows you to navigate to your home in one simple button
press. Note: you will have to first set your home address via the settings menu first.
Edit Favourites – Allows you to add and edit locations of interest to you, so
that they can be quickly used again for navigating to.
Recent Destinations – A list which keeps a record of all the destinations
you have recently entered, so that they can be quickly used again for navigating to.
View Map – allows you to view any part of the installed map, handy so that
you can have a detailed view of the area around you selected destination before you
set off.
Settings – allows access to the main setting of the unit, which you can set
to you personal preference.
Exit – Exits from navigation mode back to the unit’s main menu.
Satellite Signal Indicator – allows you to quickly view the status of the GPS
signal. Green means a GPS lock is obtained, Grey means that a GPS lock cannot be
currently achieved. Also allows for access to the GPS Status screen when tapped.
Time bar – Shows the current time and data as automatically
set by the received satellite signals. Also allows for access to the Time Zone setting
when tapped.

NAVIGATION MENU
17 Binatone Help Line: 0845 345 9677 (for UK only. Local Call rate)
Navigate to
Tap this option to begin any journey or if
you wish to set up a route simulate. The
screen will change to the Route Planning
menu.
Navi – Used to navigate to a destination,
via a number of waypoints if also set.
Simulate – Used to plan a route which
can then be simulated.
Route options – Opens the route options
menu allowing you to set your preferred driving preferences.
Up/Down arrow – Used to scroll to view the list of waypoints/destination which are
currently not shown.
Move Up/Down – Use to shift the position of the waypoints/destination you have
entered.
On Map – Use to view the selected waypoint/destination on the map.
Delete – Used to delete a selected waypoint/destination from the list, you will be
asked to confirm the deletion. The currently selected item will be highlighted orange.
Back – Used to go back to the main menu.
Go – Use to switch to the Navigation screen and begin you journey/simulation.
Note: You can only enter a maximum of 10 waypoints/destination in the list,
when the list is full a message will be displayed informing you that you have
reached the maximum number.
In Navi the unit will display the list items in numerical order, when in Simulate
the first list item will be displayed with an S to indicate that it is your start point.
In order to navigate you need a valid GPS signal, for simulating a route this
can be done without a GPS signal.

NAVIGATION MENU
18 Binatone Help Line: 0845 345 9677 (for UK only. Local Call rate)
Entering your Waypoints/destination
Tap on the next empty list slot, this is the list item
which says “Click here to add a new destination”.
This will always appear in the next available list
slot, when in simulate the first list slot will have the
text “Click here to set the starting point”.
The Search From screen will appear allowing you
to choose your waypoint/destination from several
different methods.
Note: The unit will remember the last waypoints/destination used for the last
journey. It may be necessary to delete these Waypoints/Destination from the
list first, Before you can start a new journey. This happens if the actual
destination on the map was not reached. Select each Waypoint/Destination in
turn and tap delete, tap OK to confirm the deletion
Address
The most commonly used method for entering a
new waypoint/destination into the unit, when tapped
the Address Search screen will open. This screen
allows you to add information into several fields so
that you can accurately find the location you are
looking for. When a field is tapped a new screen will
be displayed showing a keypad, this is to allow you
to enter the desired address for your
waypoint/destination.
Firstly you will need to enter the city for which your waypoint/destination is located.
The current country for which the address will
be searched for will be shown in the top right of
the screen. If you wish to change the country
tap on the currently shown name, the screen
will change to show you a list of available
countries. Use the up/down arrows to scroll
through the list, when the desired country has
been found select the country be tapping on the
name in the list (you will see a blue bar
surround the name). Then tap OK to confirm
the selection, if you do not wish to change
countries tap Cancel.

NAVIGATION MENU
19 Binatone Help Line: 0845 345 9677 (for UK only. Local Call rate)
When entering information into the search as well as just characters you have the
following special keys.
To enter a space in an entry tap the button which is blank shown on the bottom row.
To delete a character Tap the DEL button.
To Change between Characters/Digits and Special Characters. Tap the key to scroll
between the available options. The order of the options is ABC, ÄÖÜ, 123. The key
will always show the next selectable option.
Use the keypad to start to enter the desired
city, as you enter characters you will see a
list of possible matches appear as a list on
the screen. As you enter further characters
the list will narrow down until there are only
1 or 2 options available. This is handy if you
do not know how to spell the city you are
searching for, simple enter the first part of
the city name and let the unit do the rest. As
the list is populated by possible matches,
the matches will be white in colour. Wait
until the list items have turned dark blue,
then use the up/down arrows to scroll through the list to find the city you were
looking for. Then simple tap OK to accept the selected item.
The screen will return back to the Address search screen and the chosen city will
now appear in the City field.
Alternatively; if you know the postcode of the waypoint/destination, select the
Postcode field from the Address Search screen. Enter the full postcode making sure
that there is a space between the two parts i.e. AB1 9CD and not AB19CD. Again
your selection will be narrowed down as you enter more characters/digits. Select the
correct entry from the list and tap OK, you will be returned to the Address Search
screen. The road field will be automatically filled in by the unit. you will notice that
some fields will now be shown in grey these fields can no longer be altered.
Note : When the unit is searching, the matched Locations or Post Codes will be
shown in the results screen in white text. When the search has completed
the first search result will be shown with a blue highlighted bar, If you see
your location before the search has completed. You can select the correct
location using the stylus make sure it is shown with a blue highlight before
pressing the OK button. In this way you do not have to wait for a full search
to be carried out.
Secondly if you have not used the postcode to search for your waypoint/destination,
you will have to enter the road name. This is done in exactly the same way as for
entering a city.
Thirdly you have the option to enter a house number. If you do not know the house
number it is possible to specify the waypoint/destination by selecting an intersection
with another road. Tap crossroad, you will be shown a list of all the other roads
which either join or cross the selected road. Use the up/down arrows to scroll the list
until you find the correct road which intersects with your named road.
