Bindertek Dealer Solutions 2-Tier Lockfile User manual

LockFile®Assembly Instructions
2-Tier
Lockfile
3-Tier
Lockfile
800.456.3453

Please read these instructions carefully before mounting
and setting up the furniture. They contain notes on assembling
the furniture safely and correctly.
2Bindertek Dealer Solutions |800.456.3453
DESCRIPTION OF SYMBOLS
Warning on a potential danger
Warning on a potentially wrong assembly
Which variant is my preferred choice?
Requires more than one person to assemble
The following tools are required
Mounting instructions must be exactly followed
Parts must click into place giving an audible sound
When setting up the furniture please observe the legal regulations for
office workplaces. Make sure there is sufficient ground-bearing capacity
(minimum 1000 kg/m2)

Unpack the contents and ensure nothing is missing.
Lockfile Base 02.2009
800.456.3453 |Bindertek Dealer Solutions 3

Unpack the contents and ensure nothing is missing.
Lockfile Base 02.2009
4Bindertek Dealer Solutions |800.456.3453

We recommend having another person assist with the assembly.
The packaging material can be used as a support.
800.456.3453 |Bindertek Dealer Solutions 5

The adjusting screws must not touch the base edge.
Only when the LockFile®Base stands on its final location
can it be aligned using the adjusting screws. (See page 7)
Use the felt sliders when placing on a non-carpeted surface.
6Bindertek Dealer Solutions |800.456.3453

When the LockFile®Base stands on its final location,
it must be carefully aligned using a level. This is particularly
important if the LockFile®Base is chain-linked using further
LockFile®elements.
800.456.3453 |Bindertek Dealer Solutions 7

On the following pages, the assembly of Base with
[Flex] extension is described.
As for the assembly of the extension variants Base [SKI],
Base [TSK], Base [THR], Base [TP] and Base [TZ],
please follow the separate mounting instructions which
are enclosed with the respective extension modules.
8Bindertek Dealer Solutions |800.456.3453

The plastic parts must click into place in 4 positions respectively,
giving an audible sound.
The bearing ring must be fitted with the openings facing to the top.
800.456.3453 |Bindertek Dealer Solutions 9

Adjust the level distance as required. Max load per level: 90kg
10 Bindertek Dealer Solutions |800.456.3453

Insert the tambour door and the guide of the handle profile so that
it fits exactly in the groove on the bottom and the top.
Before screwing on the upper shelf, check to be sure the tambour
door can be moved back and forth easily.
800.456.3453 |Bindertek Dealer Solutions 11

We recommend having 4 people assist in placing the LockFile®elements on top
of each other. Using 3 distance wedges, place the upper element on top of the
lower one and move it into the proper position. The locating pins fit exactly in
the hexagonal holes of the Allen screws. Position the LockFile®elements in
such a way that they are exactly flush on top of each other.
12 Bindertek Dealer Solutions |800.456.3453

800.456.3453 |Bindertek Dealer Solutions 13

Operation, Cleaning and Care
Tambour Door
Over the course of time, if the tambour door becomes too difficult to move, clean the
lower running groove. Apply and spread a few drops of silicon oil (from the tool set) in
the running groove using a cloth. Then slide the tambour door back and forth a few times.
Tambour Door Lock
The tambour door lock can only be opened using a fitted key. To do so, turn the key to
the right. The tambour door will spring open. The tambour doors are closed by a slight
swing or by turning the key while pushing the handle profile at the same time. If the
tambour door becomes difficult to close, add two drops of silicon oil as directed above.
Cleaning and Care
The cabinet surfaces are easy to clean. For regular cleaning, we recommend using a mild
household cleaning agent with a wet cloth. Please DO NOT use scouring agents.
14 Bindertek Dealer Solutions |800.456.3453

Overview of Spare Parts
Lockfile Base 02.2009
Please retain instructions for future use.
800.456.3453 |Bindertek Dealer Solutions 15

Overview of Spare Parts
Lockfile Base 02.2009
