bioBidet BB-1700 Technical Document

Installation Manual and
Operating Instructions
BB-1700 & BB-2000
This product should be installed according to this manual.
Please read this manual carefully and install properly.
Please keep this manual for future reference.
Please register warranty for proper service.
PERSONAL HYGIENE APPLIANCE
Lifestyle Upgrade
Head office:
205 Berg St.
Algonquin, IL 60102
U.S.A
Tel : [phone]
Fax: [phone]
BBC Innovation Corporation
www.biobidet.com

Thank you for purchasing Bio Bidet Advanced Toilet Seats.
Intended for household use only.
MAINTENANCE
WATER DRAINING
TROUBLE SHOOTING
SPECIFICATIONS
WARRANTY
INFORMATION TO THE USER
OPERATION (BASIC)
OPERATION (DETAILS)
INSTALLATION
SEPARATION OF THE UNIT FROM
THE TOILET BOWL
IMPORTANT SAFEGUARDS /
GENERAL CAUTIONS
CAUTIONS BEFORE INSTALLATION
CARTON CONTENTS / IDENTIFICATION
4
6
8
12
14
18
21
22
23
24
25
26
27
Installation Manual and Operating Instructions
2 3
Lifestyle Upgrade Contents
PREPARATION OPERATION INSTALLATION MAINTENANCE

The following terms are used in this manual to indicate hazards of varying degrees of severity.
Indicates potentially hazardous situation which, if not avoided, may result in minor or
moderate injury or in damage to the product or other property.
Indicates potentially hazardous situation which, if not avoided,
could result in death or serious injury.
WARNING
Indicates an imminently hazardous situation which, if not avoided,
will result in death or serious injury.
DANGER
CAUTION
READ ALL INSTRUCTIONS BEFORE INSTALLATION AND USE
DANGER - To reduce the risk of electrocution
WARNING - To reduce the risk of burns, electrocution, fire, or injury to persons
PLEASE OBSERVE THE FOLLOWING PRECAUTION BEFORE USING THIS PRODUCT
Do not open the product to repair or remodel.
Only qualified service personnel should service this product.
Do not use attachments not recommended by the manufacturer.
Do not dismantle
Connect this product to cold water supply pipe carrying potable water.
Do not connect to an industrial water supply line that
does not carry water of drinking quality.
This will negatively effect hygiene and performance.
Prohibited
About Low Temperature Burns-
A burn occurs when the skin has been exposed to high temperatures.
However, a low temperature burn may occur when the skin has been in contact with an
object at relatively low temperature (about 104 ℉). Close supervision is necessary when
this product is used by children or adults with sensitive skin.
Prohibited
If using any chemical toilet bowl cleaner, be sure to wipe up
any spills that splash onto Electric Bidet.
Do not use benzene or any acid chemical detergent.
Only neutral detergent permitted.
Prohibited
Do not plug in the power cord before connecting the water supply hose.
Prohibited
This product must be grounded.
An approved Ground Fault Circuit Interrupt must be used.
Grounding
Do not splash water on this product.
Please provide adequate ventilation to avoid high levels of humidity
which can damage the electronic components.
It is necessary to provide adequate ventilation with a fan,
open door or open window when bathing.
Do not spray water
Do not touch the power cord with wet hands.
Do not reach for a product that has fallen into water.
Unplug immediately!
Wet hands prohibited
This product must be connected to a standard voltage power source.
Do not connect power cord if the cord is damaged or broken.
Do not plug the unit into a loose electric outlet.
Observe at all times
Please disconnect the power cord when you clean this product or
detach it from toilet bowl.
Do not supply electrical power to the unit until the plumbing work
has been completed.
Observe at all times
Keep the electrical cord away from heated surfaces to prevent a fire
hazard.
Also, keep any flammable materials away from this product at all times.
Use of fire prohibited
Installation Manual and Operating Instructions
4 5
1
IMPORTANT SAFEGUARDS / GENERAL CAUTIONS
PREPARATION

6
CAUTION
Never operate this product if it is not
working properly, if it has been
dropped or damaged, or dropped into
water. Return the product to a service
center for examination and repair.
Prohibited
Do not obstruct or put
anything into the dry air
outlet. Do not apply
excessive force to the
shower nozzle.
Prohibited
Do not strain or push the connected hose and tube connecter;
it may cause water leakage.
Never drop or insert any object into any opening or hose.
Use proper plumbing supplies if any modification is to be made.
Prohibited
Drain the water from unit and unplug the power if this product is
not going to be used for an extended period of time.
Refer to page 19.
Observe at all times
Do not stand or sit on
the seat cover lid.
It is not designed to
support a user’s
body weight.
Prohibited
Allow the seat
and lid to close
automatically.
Do not force the
lid closed.
Prohibited
Use this product only as described
in the operating instructions.
Never use while sleeping or drowsy.
Do not use while bathing.
Observe at all times
Be careful so that
this product does not
become stained with
excrement and urine.
Observe at all times
- SAVE THESE INSTRUCTIONS -
THIS PRODUCT MUST BE PLUGGED into a regular voltage grounded GFCI outlet (North America 120V ac).
The rated power consumption is 1400W. In locations where only a standard two-prong outlet is available,
it is the responsibility of the user to install a grounded three-prong outlet.
Using a higher voltage is dangerous and may result in a fire or other accident.
This product is not responsible for damage resulting from the use of it on other than specified voltage,
or operating it without proper grounding.
WIRING REQUIREMENT
(1) This product has a three-prong grounding plug, which must be plugged into an outlet that is properly installed and
grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an
escape wire for the electric current. If repair or replacement of the cord or plug is necessary, do not connect the
grounding wire to either flat blade terminal. The wire with insulation having an outer surface that is green with or
without yellow stripes is the grounding wire. Check with a qualified electrician or service person if the grounding
instructions are not completely understood, or if in doubt as to whether the product is properly grounded.
(2) This product is for use on a nominal 120V circuit, and has a grounding plug that looks like the plug illustrated in
sketch A in Figure 1. A temporary adapter, which looks like the adapter illustrated in sketches B and C, may be
used to connect this plug to a 2-pole receptacle as shown in sketch B if a properly grounded outlet is not available.
The temporary adapter should be used only until a properly grounded outlet (sketch A) can be installed by a qualified
electrician. The green colored rigid ear, lug, or the like extending from the adapter must be connected to a permanent
ground such as a properly grounded outlet box cover. Whenever the adapter is used, it must be held in place by the screw.
This appliance has to be earthed.
GROUND INSTRUCTIONS
GROUNDING PIN
ADAPTER ADAPTER
METAL SCREW TAB for
Grounding Screw
GROUNDED
OUTLET
- Figure 1-
The use of an extension cord is not recommended or advised. If it is necessary to use an extension cord, use
only a three-prong extension cord (one to one), and a three slot built-in GFCI receptacle that will accept the
plug on this product. The marked rating of the extension cord should be equal to or greater than the electrical
rating of the unit (10amp). Consult a qualified electrician or service person if you are not sure whether the unit is
properly grounded.
IMPROPER GROUNDING CAN RESULT IN A RISK OF ELECTRIC SHOCK.
Electric wiring has to be done in accordance with all local codes,
or in the absence of local codes, with the National Electrical Codes.
DANGER
OPTIONAL GROUND INSTRUCTIONS
This Product must be on a separate circuit. No other appliance
should share the circuit with this product.
Sharing a circuit could cause the branch circuit fuse to blow
or the circuit breaker to trip. Continuous usage under these
conditions could result in fire or property damage.
WARNING
GROUNDED
OUTLET BOX
Installation Manual and Operating Instructions
6 7
1
IMPORTANT SAFEGUARDS / GENERAL CAUTIONS
2
CAUTIONS BEFORE INSTALLATION
PREPARATION

MAIN UNIT
1
ACCESSORIES
2
Posterior Wash Nozzle
Turbo Wash Nozzle
Digital Occupied Sensor
Drain / Quick Release
Operation LED Window
Heated Seat
Lid
Caution Label
Deodorizer
Dryer Vent
Control Panel for BB-1700
Feminine Wash Nozzle
BB-1700
Installation Manual and Operating Instructions
8 9
3 Identification
BB-1700 Control Panel
3
Cone packing
(2 pcs)
Mounting bolts (2 pcs) Base Plate (1 pc)
Nuts
(2 pcs)
Bolt Case
(2 pcs)
User manual
For plumbing For product fixation Installation
instructions
Water supply hose
(for electrical toilet seat)
Water supply hose
(for toilet flush water tank)
T-Valve
- When you sit down on this product, sit in the center in order to activate the sensor.
Stop all operation.
Posterior wash. Feminine wash.
Turbo wash. Dry washed area.
Adjust the water pressure and
warm air dryer temperature.
Adjust the oscillation function and
nozzle position (5 levels).
Adjust the water temperature (3 levels). Adjust the seat temperature (3 levels).
When selected during the wash function, the
nozzle oscillates automatically for a wider wash.
When selected during the wash function,
it starts the massage wash.
If move button is selected when user is not sitting
on the seat, it operates nozzle shower function.
If massage function selected when user is not
using wash functions, it automatically operates
wash and dry function sequentially.
If Economy mode is selected, seat temperature
and water temperature will stay at 89.6℉.
When user sits on the seat, it automatically
operates to deodorize. (Can select on/off)
Drain button
PREPARATION
L-Valve

MAIN UNIT
1
Digital Occupied Sensor
Drain / Quick Release
Operation LED Window
Heated Seat
Lid
Caution Label
Deodorizer
Dryer Vent
Posterior Wash
Feminine Wash
Dry
Turbo
Deodrant
Remote signal intensity
battery life
Set Water Temperature
Heated Water
❿
󱆌
󱆍
󱆎
󱆏
󱆐
󱆑
Heated Seat
Set Seat Temperature
Water Pressure
Dry On / Off
Set Nozzle position
Watter pressure
Nozzle position
❶❷❸
❹❺
❻
❼
❽
❾
❿
󱆌
󱆍
󱆎
󱆏
󱆐
󱆑
Display
Installation Manual and Operating Instructions
10 11
3 Identification
BB-2000
ACCESSORIES
2
Cone packing
(2 pcs)
Mounting bolts (2 pcs) Base Plate (1 pc)
Nuts
(2 pcs)
Bolt Case
(2 pcs)
Remote control User manual
Remote control
holder
1.5V AAA type
Battery (2pcs)
For plumbing For product fixation For remote control Installation
instructions
Water supply hose
(for electrical toilet seat)
Water supply hose
(for toilet flush water tank)
BB-2000 Remote Control
3
Simple Operation Panel
Feminine
Wash
Posterior
Wash
Stop
- When you sit down on this product, sit in the center in order to activate the sensor.
❶
❷
❸
❹
❺
❻
❼
❽
❾
Stop all operation.
Posterior wash.
Feminine wash.
Dry washed area.
VORTEX wash.
When selected during wash function nozzle
oscillates automatically for a wider wash.
If move button is selected when user is not sitting on
the seat, it operates nozzle shower function.
When selected during wash function,
it start massage wash.
If massage function selected when user is not using
wash functions, it automatically operates wash and
dry function sequentially.
When user sits on the seat, it automatically operates
to deodorize. (Can select on/off)
The water temperature can be adjusted up to 4 levels
(off, low, middle, high).
Can set time in the remote control with
hour( ) and minutes( ) buttons.
If Economy mode is selected, seat temperature
and water temperature will stay at 89.6℉.
If this( ) symbol flashes, please change
the battery in remote control.
The seat temperature can be adjusted up to 4 levels
(off, low, middle, high).
Simple Operation Panel
For BB-2000
Drain button
PREPARATION
Posterior Wash Nozzle
Turbo Wash Nozzle
Feminine Wash Nozzle
T-Valve L-Valve

PREPARATION
2
SIT DOWN ON THE SEAT
•When you sit down on the seat, the ORANGE LED lamp on the control panel will light up.
•When the digital sensor on the seat is activated, the operation LED window on the main unit
will light “Occupied sensor” and simultaneously, the deodorizer fan will start to work.
(BB-1700 / BB-2000 Models)
•See page 14 for details about changing the seat or water temperature.
•Please plug the power cord into AC110V power outlet.
•Plug the unit into the proper power source and the LED power light will start flashing.
•Wait until the LED power light stops flashing and becomes solid red.
•The water tank will be filled after pushing a “Wash”( or , or ) button.
•When the water tank is filling the buzzer “Beeps” continuously.
After the water tank is full the buzzer will end with “One Solid Beep”.
Check for any water leaks.
1
•Please turn on the water supply valve and check connected spots(1~5) for the leakage.
OPERATION
3
CLEANSING
•CLEANSING 1. (Posterior Wash)
1- Press “Posterior Wash”( , ). Automatically, the nozzle comes out and
sprays warm water to posterior.
2- Additional functions during your Posterior Wash experience are available. See Oscillation,
page 15 and Massage, page 16 for details.
STOP
•Press this button to stop all operation.
•CLEANSING 2. (Feminine Wash)
1- Press “Feminine Wash”( , ). Automatically, the nozzle comes out and
sprays warm water to feminine area.
2- Additional functions during your Feminine Wash experience are available. See Oscillation,
page 15 and Massage, page 16 for details.
•CLEANSING 3. (Turbo Wash / Vortex Wash)
1- Press “Turbo Wash” ( ) or “Vortex Wash” ( ), the nozzle spray is more or
focused to produce the effect of strong wash, to help stimulate bowel movement.
2- Press “Water pressure - High & Low button” to adjust the water pressure.
CLEANSING cont.
•CLEANSING 3. (Turbo Wash or Vortex Wash)
1- Press “Turbo Wash” or “Vortex Wash” continuously for 3 to 5 seconds. Automatically, the water
nozzle comes out and sprays a warm stream of water to the posterior center of the rectum.
2- If necessary, adjust “Position” of water stream with the ( / )buttons.
3- Press “Water pressure High & Low button”( / )to adjust the water pressure
to your desired comfort.
4- Press the “STOP”( )button when you feel your abdomen is full or wait until
the “Turbo Wash” or “Vortex Wash” function stops, approximately 1 minute.
5- You will shortly feel the urge to push the water out of your colon, push the water and feces
out as thoroughly as you can.
6- Relax for a few minutes and be sure you feel your colon is empty and then use
the “Posterior Wash” and “Air Dry” function to finish.
Installation Manual and Operating Instructions
12 13
4 Operation (Basic)
CAUTION
Please press the “off” or “low” button to reduce the seat temperature after using.
Special precautions should be taken for children, those who cannot adjust the temperature,
and those who have sensitive skin.
CAUTION
OPERATION
CAUTION
DO NOT ALLOW CHILDREN TO USE THE TURBO WASH or VORTEX WASH FUNCTION!
SUPERVISION IS STRONGLY RECOMMENDED FOR THE ELDERLY OR OTHER PERSONS
THAT MAY HAVE LIMITATIONS IN BODY MOVEMENT, ILLNESS OR DISABILITIES!
Observe at all times
water supply
vavle
①
②
③
⑤
④
①
②
③
④
⑤

•Nozzle position is adjustable to the desired position by pressing “Front”( ) or
“Rear”( ) button from 1 to 5 positions.
After using this product, the nozzle will return to position 3.
NOZZLE POSITION ADJUSTMENT
DEODORIZER
•When using Posterior or Feminine Washing functions, pressing the “MOVE”( , )
button will provide a short-motion, front to back oscillating spray for a much wider cleansing
experience.
•You may change the position of the Oscillating spray by pressing the “MOVE”( , )
button again and “Front”( ) or “Rear”( ) buttons simultaneously.
•Push the “MOVE”( , ) button again and the oscillation motion will stop automatically.
Auto-Setting of Oscillation Feature
•You can set this function to automatically oscillate whenever the seat is occupied and the Posterior or
Feminine washes are in operation.
Step 1: Sit on this product.
Step 2: Press the “MOVE”( , ) button for 3 seconds or until you hear a single Chime.
Step 3: Sit on the this product and proceed with Posterior or Feminine Wash.
Note: In the automatic setting, you may still adjust the position of the Oscillating spray by pressing the
“Front”( ) or “Rear”( ) buttons.
Canceling the Automatic Oscillation function
Step 1: Sit on this product.
Step 2: Press the “MOVE”( , ) button for 3 seconds or until you hear a double Chime.
OSCILLATION ( Nozzle Movement Function)
Installation Manual and Operating Instructions
14 15
5 Operation (Details)
- Select: Single Chime
- Cancel: Double Chime
Deodorizer ON/Off (initial setting is Off)
- Press button for( , ) 3 seconds (press the button again for 3 seconds, the function is canceled.)
- After setting Deodorizer function, it is automatically activated when sensing the human body.
- Once used, the Deodorizer function automatically stops after 1 minute of operation.
“Deodorizer” button
Press 3 seconds
Single Chime
“Deodorizer” button
Press 3 seconds
Double Chime
Reference
- Deodorizer function stops while dryer is selected. After dryer function completes, deodorizer automatically is activated.
WARM WATER TEMPERATURE
AND SEAT TEMPERATURE ADJUSTMENT
WARM AIR DRYER
1- Press “Dry”( , ), warm, dry air is gently directed to washed area for about 3 minutes.
2- You may adjust the warm air temperature by pressing High( ) and Low( ) buttons.
※This product memorizes the air temperature of prior use.
WATER PRESSURE ADJUSTMENT
•After sitting down on the this product, the LED lamp( ) for water
pressure on the Power Control will light at third or middle level( ).
•Press high( ) , or low( ) to adjust the pressure of the water spray to
your desired comfort level.
•The temperature of water and seat are adjustable to the desired level by pressing
the “WATER”( )and “SEAT”( ) button.
OFF /
Room temperature
GREEN
approx. 93.2℉
ORANGE
98.6℉
RED
104℉
WATER TEMPERATURE
OFF /
Room temperature
GREEN
approx. 93.2℉
ORANGE
98.6℉
RED
104℉
SEAT TEMPERATURE
BB-1700
WARM WATER TEMPERATURE
AND SEAT TEMPERATURE ADJUSTMENT
•The temperature of water and seat are adjustable to the desired level by pressing
the “WATER”( )and “SEAT”( ) button.
OFF /
Room temperature
GREEN
approx. 93.2℉
ORANGE
98.6℉
RED
104℉
WATER TEMPERATURE
BB-2000
SEAT TEMPERATURE
BB-1700 BB-2000
OPERATION

Installation Manual and Operating Instructions
16 17
5 Operation (Details)
NOZZLE CLEANING (Automatically)
•This product has an automatic nozzle self-cleaning function that
cleans the nozzle before and after each use.
Auto Wash
- If the “MASSAGE” ( , ) function selected when user is not using wash functions,
it automatically operates wash and dry function sequentially.
- Wash (30 Seconds) + Dryer (1minute) then automatically stops
NOZZLE CLEANING (Manual)
•Nozzle can be cleaned manually by pressing “Posterior Wash”( / ) button for 3 seconds
without being occupied on the seat and nozzle will come out without spraying water. After cleaning
the nozzle, Press “Stop”( / ) button to return nozzle to stand-by mode.
( , : in Simple Operation panel -Remote Model)
Nozzle Shower
- If the “MOVE” ( , ) button is selected without sitting on the seat,
it operates nozzle shower function.
- Water flows automatically to nozzle and nozzle moves for about 20 seconds
to wash entire nozzle and then it automatically retracts.
•When using the Posterior Wash or Feminine Wash functions, pressing the “MASSAGE” ( , )
button will provide a pulsation spray.
•You may change the pressure of the spray by pressing the “High”( ) button or “Low”( ) buttons.
•Push the “MASSAGE”( , ) button again and the pulsating action will stop automatically.
Auto-Setting of Massage Feature
•You can set this function to automatically pulsate whenever the seat is occupied and the Posterior
or Feminine washes are in operation.
Step 1: Sit on this product.
Step 2: Press the “MASSAGE”( , ) button for 3 seconds or until you hear a single Chime.
Step 3: Sit on this product and proceed with Posterior or Feminine Wash.
Note: In the automatic setting, you may still adjust the pressure of the pulsating spray by
pressing the “high”( ) or “low”( ) functions.
Canceling the Automatic Oscillation function
Step 1: Sit on this product.
Step 2: Press the “MASSAGE”( , ) button for 3 seconds or until you hear a double Chime.
MASSAGE (Rhythm Wash) ECONOMY (Energy Save Mode)
- Keep seat cover closed when not in use to prevent heat from being lost.
- Keep temperature set to low.
- Unplug the power cord if you do not plan to use the unit for a long period of time.
Saver On/ Off
- When pressing( , ) the energy saver LED on the main unit will turn on.
(press button again, the saver LED will turn off)
- Energy saver mode automatically maintains a water and
seat temperature of 89.6℉(32℃).
- When using bidet in saver mode, it is turned to automatic saver.
- When you rise from the seat, it goes into saver mode.
- Seat temperature is maintained 32℃.
Other energy saver tips
In order to save energy, please abide by the following instructions:
In energy saver mode, the seat heating temperature could appear to be
lower than the actual temperature setting.
OFF
State
ON
State
Flashing
State
OPERATION
OCCUPIED
SENSOR
ENERGY
SAVER
POWER
BB-2000
DEODORANT ENERGY
SAVER
POWER
BB-1700

CAUTION BEFORE INSTALLATION
•Do not plug in before installation.
•If you need an electric power system or extension, please consult a qualified electrician.
STEPS
•Shut off the water supply shut off valve.
•Drain the toilet tank completely.
•Then remove the existing fill valve water supply hose.
Flexible Tube
Water supply hose
(for toilet flush water tank)
1Connect T-Valve.
•Remove existing supply hose connected to the toilet tank.
Make sure not to damage the water supply hose
•Install T-Valve at the thread from tank.
2
Removing the existing seat and lid.
•Remove mounting bolts to release existing
toilet seat from toilet.
※Check for any water leaks. ※Check for any water leaks.
3Connect water supply hose to
the T-Valve.
4
Turn Off Water.
Catch plate
Place the plate and guides over each mounting hole.
Insert the mounting bolts through the plate and
mounting holes.
5
1. Slide this product onto the catch plate
centering the unit with the guide arrows on the Base.
2. You will hear a click once this product is securely
mounted to the catch plate.
3. This product will feel a little loose on the toilet bowl.
Adjust the fit from front to back and side to side for balance.
4. Tighten the nuts on both bolts securely.
7
Check for any water leaks.
8
Slide cone packing and washers onto the bolts
then fasten to securely mount bidet seat to toilet.
6
Installation Catch Plate. Bolt and Nut Assembly.
Assembly. Connect the flexible tube from side of
T-Valve to this product,
Open the Angle Stop valve to fill water.
Cone Packing
Nut
Bolt Guide
Bolt
Installation Manual and Operating Instructions
18 19
6 Installation
Central mounting
groove
Bolt
BACK
INSTALLATION
L-Valve

Wireless remote mounting guide. (BB-2000)
9
Nozzle Change
10
Disconnect the power plug.
Close water supply shut-off valve.
Drain water from bidet seat using drainage
as illustrated.
Remove bidet seat from toilet as illustrated.
Do not turn unit upside down.
1
2
3
4
Installation Manual and Operating Instructions
20 21
6 Installation 7
Separation Of Unit From The Toilet Bowl
Install wireless remote with adhesive tape
Inserting batteries
•Insert supplied batteries (1.5V AAA) and close battery cover.
Nozzle Combiation
Nozzle Seperation
•Remove adhesive from back of bracket and
place bracket where desired.
(Please check the polarity,
before insert the batteries.)
Adhesive
tape Wall
INSTALLATION

MAINTENANCE FOR WINTER SEASON
•When the “Posterior Wash ( / )” button is pressed
for 3 seconds without occupying the seat, the nozzle can be
cleaned with a soft toothbrush.
•After cleaning the nozzle, push the “Stop ( / )”
button once again, and the nozzle retracts itself.
( : in Simple Operation panel -Remote Model)
1) Close the water shut off valve.
2) Flush the toilet to empty the water reservoir.
3) Unscrew the water filter nut.
4) Clean the strainer with a small brush or water.
5) Re-screw the water filter nut.
6) Open the water shut off valve.
This product will not operate
properly if the strainer is clogged.
Please clean the strainer regularly.
( : in Simple Operation panel -Remote Model)
CLEANING THE NOZZLE DRAINING THE WARM WATER TANK IN THE UNIT
•When you clean this product, do not use thinner, benzene or
toilet bowl cleaner. It may cause damage to the surface of unit.
•Use a wet cloth when you clean this product.
•Do not spray water directly on to this product.
•When you clean this product, disconnect the power plug.
CLEANING THE BODY OF UNIT
CLEANING THE STRAINER
If you do not intend to use this product for 14 days or longer,
drain the water from this product’s warm water tank.
1) Disconnect the power plug.
2) Close the water shut off valve.
3) Press the drain lever until the water is
completely drained from water tank.
4) To re-supply water after draining,
open the water shut off valve.
Do not drink the drained water.
Do not insert finger into the drain hole.
Before draining, unplug the power cord and wait 30 minutes until the unit has cooled down.
Check the power cord if it is plugged in or not.
1
Keep the water temperature on “Middle or High Level” to prevent water from freezing.
2
If you do not intend to use the unit for 14 days or longer, disconnect the power
plug and drain the water.
3
Installation Manual and Operating Instructions
22 23
8 Maintenance 9 Water Draining
MAINTENANCE
BB-2000
BB-1700

Trouble Cause Remedy
1. The water tank is not filled.
2. The shut off valve is closed.
3. Freezing inside the main unit or the
water supply pipe.
1. Disconnected the power cord.
2. The seat is not occupied.
3. The battery of remote controller is
exhausted.
(Only BB-2000 model)
1. Check the water supply system
1. The water pressure level is set to
“LOW”.
2. The strainer is clogged.
1. The water temperature is set to
“LOW”.
2. Continuous operation has depleted
the supply of warm water.
1.The seat & dryer temperature is set
to “LOW”.
1. Wait about one minute.
2. Press the desired washing button once
again.
3. Turn on the shut off valve to open.
4. Heat the room (for about two hours).
Operating the unit while parts are
frozen will cause a malfunction.
1.Connect the power cord.
2. Check the power supply system in
your house.
3. Occupy the seat (The unit has an
occupied sensor).
4. Replace the battery.
1. If water is leaking from the main unit,
call the service center or the place you
purchased unit.
1.Set the water pressure to “HIGH”.
2.Clean the strainer.
1.Set the water temperature to “HIGH”.
2. Wait about three minutes.
1. Set the seat & dryer temperature to
“HIGH”.
The washing water
does not spray
The unit is not
operating
Water is leaking
The washing water
pressure is weak
The washing water
is not warm
The seat and dryer is
not warm
Feminine Wash
Wash
Device
Heated Seat
Warm
Air Dryer
Device
Posterior Wash
Water Pressure
Adjustable
Warm Water
Temperature
Heater
Safety Devices
Temperature
Heater
Safety Device
Adjustable Dry Temperature
(Room Temp~45℃)
Deodorizer
Turbo& Vortex Function
Remote control
Inlet water temperature
3℃~ 35℃( 37.4℉~ 95℉)
3℃~ 40℃( 37.4℉~ 104℉)
Ambient Temperature
Dimension
Weight (kg)
Heater
(250W)
Safety Device
(Themal fuse, bimetal)
Power Rating
Power cord
Type
Water inlet type
Water inlet pressure
Specification
Direct Inlet flow type
0.4 ~ 7.5 kgf/㎠( 5.69 psi ~ 106.7psi )
1.2m (4 feet): AMERICA
Max. 0.7ℓ/min ( Max. 0.32 GPM )
Max. 0.7ℓ/min ( Max. 0.32 GPM )
5 Levels
Room Temp - 40
℃ ( Room Temp. 104 ℉ )
1340 W
Thermal fuse, Thermal switch, Float switch
Room Temp ~ 41
℃ ( Room Temp. ~ 105.8 ℉ )
55 W
Thermal fuse
4.9kg 4.8kg
BB-1700 BB-2000
○
○
-
-
○
○
○
○
W : 460mm / L : 531mm / H : 152mm W : 392mm / L : 531mm / H : 152mm
America or Canada: 120Vac, 60Hz, 1400W
Elongated(Control) Elongated (Remote)
Installation Manual and Operating Instructions
24 25
10 Trouble Shooting 11 Specifications
MAINTENANCE

Three Year Limited Warranty
1. 100% Coverage of all parts and labor for the entire product for the first year from original date of purchase.
2. 75% Coverage of all parts and labor for the entire product for the second year from original date of purchase.
3. 50% Coverage of all parts and labor for the entire product for the third year from original date of purchase.
BBC Innovation warrants its products to be free from manufacturing defects under normal use and service for a period of
three (3) years pro-rated based as outlined above from original date of purchase.
This warranty is extended only to the ORIGINAL PURCHASER.
BBC Innovation’s obligations under this warranty are limited to repair or replacement, at BBC Innovation’s option, of products or
parts found to be defective, provided that such products were properly installed and used in accordance with instructions.
BBC Innovation reserves the right to make such inspections as may be necessary in order to determine the cause of the defect.
BBC Innovation will not charge for labor or parts in connection with warranty repairs or replacements.
BBC Innovation is not responsible for the cost of removal, return and/or reinstallation of products.
This warranty does not apply to the following items:
Damage or loss sustained in a natural calamity such as fire, earthquake, flood, thunder electrical storm, etc.
Damage or loss resulting from any unreasonable use, misuse, abuse, negligence, or improper maintenance of the product.
Damage or loss resulting from removal, improper repair, or modification of the product.
Damage or loss resulting from sediments or foreign matter contained in a water system.
Damage or loss resulting from improper installation or from installation of a unit in a harsh and/or hazardous environment.
This warranty gives you specific legal rights. You may have other rights which vary from state to state.
To obtain warranty repair service under this warranty, you must take the product or deliver it prepaid to a BBC Innovation service
facility together with a letter stating the problem, or contact a BBC Innovation distributor or products service contractor, or write
directly to BBC Innovation Corporation, 205 Bert Street, Algonquin, IL 60102.
This written warranty is the only warranty made by BBC Innovation. Repair or replacement as provided under this warranty shall be
the exclusive remedy available to the purchaser. BBC Innovation shall not be responsible for loss of the product or for other
incidental, special or consequential damages or expenses incurred by the purchaser, or for labor or other costs due to installation or
removal, or costs of repairs by others, or for any other expense not specifically stated above. Except to the extent prohibited by
applicable law, any implied warranties, including that of merchantability or fitness for use, are expressly limited to the duration of
this warranty. Some states do not allow limitations on how long an implied warranty lasts, or the exclusion or limitation of
incidental or consequential damages, so the above limitation and exclusion may not apply to you.
Warning! BBC Innovation shall not be responsible or liable for any failure of, or damage to, this plumbing product or product
component caused by either chloramines in the treatment of public water supply or in-tank bowl cleaners containing chlorine
(calcium hypochlorite).
Note: The use of high concentration of chlorine or chlorine related products can seriously damage the fittings.
This damage can cause leakage and serious property damage.
For Service & Technical Support, call or write to:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one more of the
following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the manufacturer could void the user's authority to
operate the equipment.
Note : The manufacturer is not responsible for any Radio or TV interference caused by unauthorized
modifications to this equipment. Such modifications could void the user's authority to operate the equipment.
WARNING
BBC Innovation Corporation
205 Berg Street
Algonquin, IL 60102
U.S.A
Tel : [phone]
Fax: [phone]
[email protected]
Installation Manual and Operating Instructions
26 27
12 Warranty 13
INFORMATION TO THE USER (For America)
MAINTENANCE
