Biontech BTM-105DN User manual

BIONTECH Co., Ltd.
OPERATION MANUAL
Under-sink type
Korea Food and Drug Administration (KFDA) Manufacturing
License No. 889 KFDA Product License No. 05-872
Dedicated to runing water lines
* Read this manual carefully for proper use of the product. Keep the manual
in a safe place and refer to the manual whenever necessary.
* Our company will not be held responsible for any malfunction or accident
resulting from incorrect installation or improper handling.
Model : BTM-105DN

Safety Precautions
2
The precautions are designed to prevent physical injury or property damage.
■ The precautionary symbols are classied as follows depending on the level of injury or damage
as a result of incorrect use of the product arising from ignoring the precautions.
Warning This symbol means that ignorance may result in fatality or severe physical injury.
Caution This symbol means that ignorance may result in possible physical injury or property damage.
This symbol means attention is required.
This symbol means prohibitory instruction should be observed.
This symbol means compulsory instruction should be complied with.
Use only potable water such as tap water
The receptacle should be installed safely and
correctly according to standard electricity and
indoor cabling and wiring regulations.
Do not exceed the limit of the receptacle or
power distribution devices. Use specied
voltage only.
Exceeding the limit of the electric
devices by multi-tapping may
result in overheating and eventual re.
Unsound electric construction work may
result in re or electric shock.
The receptacle should be installed by a
qualied electrician.
The product should be installed properly
according to the operation manual.
Prohibitory
instruction
Drinking water without removing
harmful substances may be hazardous
to health.
Incorrect installation may result in re,
electric shock or water leakage.
Warning
■The contents to be observed are described and classied as follows (examples):

3
Use the main unit, outlet faucets (water taps)
and installation accessories as a set.
Do not connect any other device to the outlet
faucets.
Make sure that no hose is bent, twisted or pulled.
Do not alter the stages of the product s electric valve.
During the nal inspection, check for water leakage at all pipe-connecting parts including the
outlet faucets.
Do not connect any other device to the outlet
faucets.
Piping should be carried out accurately and tightly
to avoid leakage. In particular, the metallic xing
parts should be xed tightly.
If abnormal pressure is applied to the
secondary side of the main unit, water
leakage may result.
Water leakage may result.
Do not apply abnormal water pressure to the product. If an outlet line is altered, water
leakage may result, causing serious indemnication consequences.
If any water leakage occurs, serious indemnication consequences may ensue.
If abnormal pressure is applied to the
secondary side of the main unit, water
leakage may result.
If they are not xed tightly, hoses may
become loose and water leakage may
occur, resulting in a ooded kitchen.
Do not connect the product to a wall mount-type
water tap.
If such connection is made, piping becomes
indistinct and indemnication consequences may
ensue.
Prohibitory
instruction
Prohibitory
instruction
Prohibitory
instruction
Prohibitory
instruction
If water leakage occurs, serious
indemnication consequences may
ensue.
Do not use the main unit and outlet
faucets (water taps) separately.
Caution

4
Warning
Warning
Do not x the power cord with a staple or similar
fastener.
Protect the power cord and the power plug
from damage.
Other than the pipe-connecting parts, do not
disassemble, repair or alter the product.
Completely insert the power plug.
Completely insert the power plug.When drilling a
hole in the sink, use a tool appropriate for the sink
material.
When drilling a hole on the sink shelf, be careful
not to damage the building s water pipes.
Pay particular attention to make tight connections to
prevent leakage on the primary supply line.
If the thickness of the sink material exceeds
30mm, do not attempt to drill a hole.
If installation of the product is impossible after
drilling the holes, indemnification consequences
may ensue.
(In the case of natural granite or other
special material composition, consult the sink
manufacturer and follow the work method
instructions.)
Drilling a hole in an inappropriate
manner may result in damage to
the sink.
If there is a leak in the building s water
pipes, serious indemnication
consequences may ensue.
If leakage occurs, serious
indemnication consequences may
ensue.
Do not hold the power plug with wet hands.
A partially inserted power plug may
result in re or electric shock.
Do not use a damaged power plug or
loose receptacle.
This application can be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision. If the supply cord is damaged,
it must be replaced by the manufacturer, its service agent or similarly qualied persons in order
to avoid a hazard.
It may result in electric
shock.
A damaged power cord
may result in re
or electric shock.
- Do not leave it near a heating device
or bend it with excessive force.
- Do not place heavy items on top of it
or alter it without authorization.
- Do not pull it with excessive force or tie
it up.
* A damaged power cord may result in
re,electric shock, or short circuit.
It may result in re or
electric shock.
Disassembly
prohibited
Prohibitory
instruction
Prohibitory
instruction
Prohibitory
instruction
Prohibitory
instruction
Do not handle
with wet hands.

5
Table of Contents
■ Install the product correctly according to this manual.
* Piping should be carried out considering the building construction, running water regulations and the
city s ordinances. It should be noted that the connection method of piping may differ depending on
the combination of the sink and oor cabinet.
■ During the nal inspection, be sure to check for leakage, operation and ow rate.
■ After completion of installation, hand over the manual, the warranty and pH measurement reagent to
the customer.
■ Depending on the local water quality, pH may deviate from the required range Particularly in areas
where underground water is supplied as tap water, make sure to measure pH before installation.
■ Our company will not be held responsible for any malfunction or accident resulting from incorrect
installation or improper handling. Conduct a thorough preliminary inspection.
* Parts and Accessories ...................................................................................................................................
1. Installation Reference Information ...............................................................................................................
* Operation Precautions ................................................................................................................................
2. Parts Drawings for Installation ......................................................................................................................
■ Development Drawing of Raw (City) Water Connection..........................................................................
3. Selecting Locations for Water Outlet Faucet ...............................................................................................
4. How to Fix Water Outlet Faucet ...................................................................................................................
5. Installation and Connection of Alkaline Electrolysis Ionized Water System Main Unit ...............................
6. Checkpoints after Installation .......................................................................................................................
* Troubleshooting ..........................................................................................................................................
7. Nomenclature and Descriptions ...................................................................................................................
* How to store and manage the product after it is used.
Precaution for using it .................................................................................................................................
8. How to Produce Alkaline Ionized Water .......................................................................................................
9. How to Use Water Purication Method ........................................................................................................
10. How to Perform Forced Cleaning (Production of Acidic Ionized Water) ...................................................
* About automatic cleaning operation ..........................................................................................................
11. How to Measure pH (Hydrogen Ion Concentration) ..................................................................................
12. Timing and Method of Filter Replacement .................................................................................................
* Cleaning Filter ............................................................................................................................................
* How to use cleansing Filter .......................................................................................................................
13. Use of Ionized Water
* Use of Alkaline Ionized Water ....................................................................................................................
* Use of Acidic Ionized Water .......................................................................................................................
14. Q & A ...........................................................................................................................................................
15. Troubleeshooting ........................................................................................................................................
* Final checklist .............................................................................................................................................
* Product Specications ...............................................................................................................................
* Consumer Damage Indemnication Guidelines .......................................................................................
* Product Warranty
........................................................................................................................................
6
7
8
12
13
14
15
16
17
18
19
21
22
23
24
25
26
27
28
29
30
31
32
34
36
37
38
39

6
Parts and Accessories
Dual spouted
Faucets
Fixing Nut
Union
Dust Filter Safety Pin
Rubber
Paking
Hose
■1/4 Standend Hose
■5/16 Standend Hose
X 8
Tubing Connector
cover
(including two screws)
Hose Fixing
panel
Hose xing bands pH Reagent
(Bottle is stored
in packing
materials)
The following are the parts necessary for piping to the sink
Reinforcing Plate
Electric drill
Pipe wrench or spanner Phillips Screwdriver
Operation manual (including warranty), color comparison table
Running water line
connection adaptor
(small)
■ Check the following parts and accessories:
■ The following tools are necessary for installation work
Dust Filter
Huse
Hole cutter Size
* Diameter 1.37
* Cutter
* File
* Pliers
* Ruler
■ 5/16”(1ea)
■ 1/4”(1ea)

■ Do not install the product in any of the following places (product malfunction may result if ignored):
- Near hot temperatures (40 oC or higher),
- A bathroom or a humid place,
- Outdoors or a place in direct exposure to rain and snow,
- A place contaminated with petrochemicals, or
- A place where the product may undergo freeze and burst.
* This product does not function in very cold places (below freezing point).
■Piping should be carried out considering the building construction, running water regulations and the
city s ordinances.
The connection method of piping should differ depending on the combination of the sink and oor cabinet.
■ This product has been authorized and registered as
compliant with running water regulations. Make sure to
use the original main unit, faucets and installation
auxiliary material set.
■ Before installing the main unit, install the power
receptacle inside the cabinet.
(In the event the receptacle cannot be installed inside
the cabinet)
- A place where it is difcult to connect/disconnect the
power plug.
- A place where leakage or condensed water may ow
into the receptacle.
■ You may install the product as part of kitchen sink
furniture (ie - inside the cabinet) depending on your
available options, but consult with the customer to
make sure easy lter replacement is possible.
(Minimum space required.)
■ The xing nuts for the outlet faucets of the alkaline
ionized water tube and acidic ionized water tube should
be tightened manually without using a tool. (Otherwise,
damage or leakage may result.)
■ Before beginning installation, if you require information
on the structure or composition of the sink, contact the
sink manufacturer for information.
■ It is essential to Solenoid valve protection lters on the upstream of the water intake of this product.
If the lter is not installed, contaminants may pass through the valve, resulting in malfunction of the valve
and leakage.
* If contaminants accumulate in the protection lters, it may reduce the amount of water intake. Check and
clean the lter periodically.
7
Parts and Accessories
320mm
400mm
Alkaline outlet Acidic outlet
↓
↓

8
Operation Precautions
The precautions are designed to prevent physical injury or property damage.
■ The precautionary symbols are classied as follows depending on the level of injury or damage
as a result of incorrect use of the product arising from ignoring the precautions.
■ The contents to be observed are described and classied as follows (examples):
This symbol means prohibitory instruction should be observed.
This symbol means compulsory instruction should be complied with.
Caution This symbol means that ignorance may result in possible physical injury or property damage.
For initial installation and relocation, consult the
retailer you purchased the product from.
The following should consult a physician
or pharmacist before drinking alkaline ionized water:
If you notice any health abnormalities after
drinking alkaline ionized water or no
improvement despite drinking for an extended
period, consult a physician or pharmacist.
If you notice any skin abnormalities after using
weak acidic (astringent) water, stop usage and
consult a physician.
The following should consult a physician or
pharmacist before using weak acidic (astringent)
water
- Persons with sensitive skin
- Persons with allergies
The following should not drink alkaline ionized
water:
Prohibitory
instruction
- Any problem with installation may
result in re, electric shock or
water leakage.
- Persons with chronic disease or in
delicate health.
- Persons with stomach or liver
disorders.
- Persons currently receiving treatment
from a physician or dentist.
Persons on medication
Persons with achlorhydria
Warning
Warning This symbol means that ignorance may result in fatality or severe physical injury.

9
Use only potable water (ofcially approved
tap water)
Do not insert or remove the power plug with
wet hands.
When removing the power plug from the
receptacle, make sure to hold the plug with your
hand. (However, do not unplug while replacing
the lter or when water supply is needed.)
Remove dust from the power plug periodically.
If dust gathers on the power plug, insulation may
be degraded, possibly resulting in re.
Remove the power plug from the receptacle and
clean it with a dry towel.
Completely insert the power plug.
It may damage the power cord and the power plug.
Do not exceed the limit of the power receptacle or
other power distribution devices.
- Exceeding the limit of electric devices by multi-
tapping may result in overheating and eventual re.
* For power cord or power plug repair, contact
your purchase retailer or our head ofce.
Appearance of scratching
Processed
Near a heating device
Bent excessively
Being pulled
Loading heavy items
- Using a scratched item may result
in re, electric shock or short circuit.
Never attempt to disassemble, repair or alter
the product.
Prohibitory
instruction
Prohibitory
instruction
Prohibitory
instruction
Do not handle
with wet hands
Remove the
power plug
- Electric shock may resuit
- Electric shock may result. - A partially inserted power plug may result in re or
electric shock.
* Do not use a damaged power plug or loose receptacle.
Do not attempt
to disassemble
- Drinking water with no sterilizing
capability or water containing
harmful substances may be
hazardous to health.
- Fire, electric shock or water leakage
may result.
* Request your purchase retailer or
our head ofce for repair.
Warning

10
Do not drink the following:
Do not clean the product by sprinkling water on it.
Do not apply excessive force or shock to the piping. Use the main unit, outlet faucets (water taps)
and installation accessories as a set.
* Do not use the main unit and outlet faucets
(water taps) separately.
Do not connect any other device on the upstream
of the alkaline electrolysis ionized water outlet
faucet.
When removing the power plug from the power
receptacle, make sure to hold the plug with your
hand
- Unplugging by pulling the power
cord may damage the cord and re
or electric shock may result.
Do not drink water with pH level 10.0
(step 5) or higher.
Do not place anything on the product.
Prohibitory
instruction
Prohibitory
instruction
Prohibitory
instruction
Prohibitory
instruction
Prohibitory
instruction
. Acidic ionized water
. Water discharged while the
abnormal lamp is on
. Drain water after cleaning
- It may be hazardous to health.
- It may result in electric leakage
or electric shock.
- It may fall off and damage other items
in the sink.
- Piping connection may become loose
and cause water leakage.
- It may apply abnormal pressure to the
secondary side of the Alkaline
Electrolysis Ionized Water System
and possibly cause water leakage.
- If there is water leakage, a serious
loss may be incurred.
* The recommended pH level for
drinking is about 8.5 (step 2 or 3).
* Consult a physician before drinking
water with pH level 10.0 (step 5) or
higher.
* Measure pH periodically (once every
month or every other month).
Warning

11
Prohibitory
instruction
Prohibitory
instruction
Prohibitory
instruction
Alkaline ionized water and puried water
should be stored refrigerated in a clean,
completely sealed container and should be used
within two days.
- Water free of chloride can easily go bad and
be hazardous to health.
Do not bend any hose excessively If you wish to use alkaline ionized
water, acidic ionized water or
puried water on another machine,
consult the machine manufacturer.
Do not use a container made
of aluminum or copper.
The former is vulnerable to
alkaline, and the latter to acidity.
Do not drink pH measurement reagent or water containing the reagent. Do not allow such liquid to get
into the eyes. (Keep away from children to prevent accidental ingestion.)
- The machine may malfunction or
break down.
- The container may become
discolored or corroded.
Do not pour alkaline ionized water, acidic ionized
water or puried water into a sh bowl.
- The sh may die due to environmental changes.
- Water leakage may result.
To use properly, drain any remaining water in the product before use.
- Discharge about 1 liter of water (for about 30 seconds) through the
product everyday before use.
- If you did not use the product for two days or longer, discharge about
10 liters of water (for about 5 minutes) through the product before use.
- It may be hazardous to health.
* If such liquid is accidentally swallowed, drink a lot of
water. If such liquid gets into the eyes, rinse with plenty
of water. In both cases, consult a physician as soon as
possible.
* The pH measurement reagent should be completely
sealed and kept out of the reach of children.
Caution

12
2. Parts Drawing for Installation
Check the positions of parts and accessories

13
Development Drawing of Raw (City)
Water Connection.
(Dust Filter)
Reduce Valve
NIPPLE
Safety pin
Safety pin
Safety pin
Adaptor(Small)
Water Flow
control screw
Control using by
driver
Increase Decrease
Hose
1) 1/4 Hose (Tubes:PE)
2) Gripper cap
3) Gripper Ring (STS)
4) Collets
5) O-ring (NBR)
6) Body (POM)
- Cut 1/4hose vertically before
inserting.
- 1/4hose should be clean &
without anyflaw.
- During insertion, completely put to
push till stop side of 1/4 hose
deeply although there feels
suspended in the middle.
- Slightly pull 1/4 hose to be sure to
setto hold correctly.
- Collets Stainless teeth prevent
from breakaway & O-ring prevent
from leak.
- Inserting safety pin between
collets surrounding 1/4& body
notto breakaway.
- Put to push collets surrounding
1/4 toward body not to have any
interval between them and pull
1/4 hoseto disassembleFitting.
3.ciP2.ciP1.ciP
6.ciP5.ciP4.ci
P
Hose
Hose
( )
(O)
How to assemble & disassemble one touch fitting
- Must useto cutthe edge of
damaged hose for recombination
after desorption.
<How to connect & caution>
1. Connect adaptor to water pipe and combine tting with entrance nipple of tap water of BTM-105D.
2. Combine hose on two touch tting of adaptor and connect the other side of hose with lter DUST
Filter's.
3. Completely insert hose to the end of one touch. If don's insert to the end, it may cause to leak.(pic.2)
4. After installing product, if water ow is more decreased or increased than standard, please control to be
standard using by adaptor water supply control valve.
While using the water ionizer, the power could not be turned on
occurs by the source water no pass though the contaminants
accumulate in the dust lter and lter strainer. At that time, please
wash up the lter strainer and the dust lter after remove from the
Water Inlet Elbow with owing water.
After 2 or 3 years using the water ionizer, we do
recommend you to replace all related connecting
parts to new ones as the shown on the left side box.
- Unless, some malfunctions of the product can
occur.
Dust Filter
Dust Filter
Adaptor(Small) Dust Filter
Hose(1/4")
Dust Filter

14
3. Selecting Locations for Water
Outlet Faucets
When drilling a hole in the sink, use a tool appropriate
for the sink composition.
(In the case of natural granite or
other special material composition,
consult the sink manufacturer and
follow the work method instructions.)
*Drilling a hole in an inappropriate manner may result
in damage to the sink.
If the thickness of the sink material exceeds 30mm, do
not attempt to drill a hole.
If installation of the product is
impossible after drilling the holes,
indemnication consequences may
ensue.
■ Drill a hole at a location of installation.
The diameter of the hole should be
35mm. Trim the hole with a le.
If the stainless steel product has
no reinforcing plate or is one with
thickness of 5mm or less, an
additional reinforcing plate should
be added.
Drill a hole with a diameter of 35mm
and do the same on a reinforcing
plate with thickness of 10 to 15mm,
and attach it with double-sided tape.
Hole-drilling in the sink
[Reinforcing plate]
■ Determine the locations for the outlet faucets.
●The locations for the outlet faucets should be determined with prudence.
●Set the faucets at a position that is about 40 to 120mm from the sink.
● Position suitable for installation
(about 300mm)
* Install the product according
to the instruction manual of
the kitchen furniture manufacturer.
* Do not allow the product
to touch the bottom of the
sink.
Caution
Prohibitory
instruction

15
4. How to Fix Water Outlet
Faucets
Fix the outlet faucets at the hole drilled on the sink using metallic xing accessories.
* Before xing the faucets, remove any dirt around the hole
Insert the controlling faucet into the hole on the sink.
And insert the reinforcing plate into the end of stand for the controlling faucet.
Tighten the faucet with the xing nut.
● Make sure the center of the xing nut and the hole on the sink is aligned.
(If they do not, internal water leakage may result.)
●Make sure the controlling faucet is accurately in place.
[Reinforcing plate] [Reinforcing plate]

16
5. Installation and Connection
of Alkaline Electrolysis Ionized
Water System Main Unit
* Close the valve located next to the water meter. Leave a water tap open until no water
ows out of the tap.
Install the Electrolysis Ionized Water System main unit in the sink cabinet, and connect the
main unit to the intermediary valve and the dual spouted faucets.
Connect the (1/4” size) water supply hose to the main unit.
(Using the white soft hose will result in leakage. Make sure to use the blue hose.)
Connect the water supply hose connected to the main unit to the nipple of the
intermediary valve.
Connect the control panel cord to the main unit.
■ In the case of piping extension necessity:
- Install the outlet hoses from the main unit (the alkaline ionized water hose and the
acidic ionized water hose) so that they are not bent or twisted.
- If the product is located far from the water valve, purchase an addition length of
hose to extend the water supply hose.
(1) Connect the connector of the control panel cord securely.
(2) Arrange the connector cord so that it can be pulled out through the cover groove.
- The cord outlet is located on the part of the cover.
- Do not apply excessive force to the connector.
(3) Close the connector cover.
* Make sure to close the connector cover.
(Insects may get inside the main unit through the connector cover.)
1. Make sure to check any leakage, after installation.
2. When connect water suppply hose, if the end of the hose isn’t straight, it can be caused leakage.
3. Make sure the water supply hose to connect by the one touch tting.
4. Make sure insert the water supply elbow to until edge of part.
* Secure a space for easy lter replacement.
* Make sure the alkaline ionized water hose, the
acidic ionized water hose and the supply water
hose are not bent.
(Otherwise, leakage may occur or improper pH levels.)
* Caution) Please ensure that the alkaline ionized water
hose and the acidic ionized water hose are not bent
into a U shape.
Cut the accessory hose (900mm) to a suitable length.
(If the length of the hose is not suitable, improper pH levels will result.)
* After completion of piping, x each hose with the bending hose-xing clip.
* After completion of piping, do not incline the main unit.
(Dust Filter)
Reduce Valve
NIPPLE
Safety pin
Safety pin
Safety pin
Adaptor(Small)
Water Flow
control screw
Control using by
driver
Increase Decrease
Hose
1) 1/4 Hose (Tubes:PE)
2) Gripper cap
3) Gripper Ring (STS)
4) Collets
5) O-ring (NBR)
6) Body (POM)
- Cut 1/4hose vertically before
inserting.
- 1/4hose should be clean &
without anyflaw.
- During insertion, completely put to
push till stop side of 1/4 hose
deeply although there feels
suspended in the middle.
- Slightly pull 1/4 hose to be sure to
setto hold correctly.
- Collets Stainless teeth prevent
from breakaway & O-ring prevent
from leak.
- Inserting safety pin between
collets surrounding 1/4 & body
notto breakaway.
- Put to push collets surrounding
1/4 toward body not to have any
interval between them and pull
1/4 hoseto disassembleFitting.
3.ciP2.ciP1.ciP
6.ciP5.ciP4.ciP
Hose
Hose
( )
(O)
How to assemble & disassemble one touch fitting
- Must useto cutthe edge of
damaged hose for recombination
after desorption.

17
6. Checkpoints after Installation
● Before supplying water to the main unit, drain the running water by opening the
valve at the water meter and opening one of the water taps in the building. Do not
open the outlet faucet at this time.
(This is to drain any foreign substances from the running water piping, thereby
preventing malfunction of the built-in Solenoid valve)
● Check for leakage at the pipe connection by pushing the POWER button.
(Do not push the switch for 3 seconds after water supply has begun.)
Leave the valve at the water meter open.
(Open the valve at the water meter which
was closed to connect the intermediary
valve.)
Open one of the running water taps to
drain foreign substances, if any.
Turn on the product by pushing the POWER button, select the purication function, and
drain about 10 liters of water (about 5 minutes).
- This is to remove any air bubbles and ne particles from the activated carbon in the lter.
Check for water leakage at piping connections and the lter.
- To check leakage at the lter, open the lter cover.
* Make sure that water comes out of the drain outlet
(acidic ionized water outlet faucet).
(If no water comes out, check if any part of the drain
hose is bent.)
Leave the (small) adaptor adjustment
screw of the intermediary valve. (The
product is shipped with the screw open.)
Insert the plug of the product into
the receptacle. (You should hear
beeping sound.)
Check the operation of the control panel
by pressing the POWER button.
(Make sure that the lamps on the
control panel turn on normally during
the different operation steps.)
Drain outlet
(Acidic ionized water)
Alkaline
outlet
faucet

18
Adjust the throughput
Adjust the throughput according to the following steps:
■ If water pressure is too low, you may not be able to obtain sufcient throughput.
(In cases when water pressure is lower than 1 kgf/ cm2.)
In this case, the lifespan of the lter may be shortened. Notify the customer of this fact.
■ If the throughput is low due to low water pressure, do not attempt electrolysis.
No lamp lights up on the control
panel after the product is plugged in.
No water comes out of the acid
water outlet faucet.
There is water leakage.
Water keeps coming out despite
pressing the POWER button
No water comes out after
pressing the POWER
button
The product responds abnormally to
button operation or does not
respond at all.
Is the connector of the control panel cord
completely connected?
* Is the acidic water hose bent?
* Is water throughput too low?
Are all parts completely connected?
Is the connector of the control panel cord
completely connected?
* A few drops from the alkaline or acidic
ionized water out faucet is not a sign of
machine malfunction.
* A foreign substance clogging up the
built-in Solenoid valve may prevent water
stoppage.
Are all parts completely connected?Is the
connector of the control panel cord completely
connected?
Is the connector of the control panel cord
completely connected?
Supply water to the product by pushing the POWER button.
Adjust the throughput by rotating the valve adjustment screw.
(Adjust the throughput so that a 200㎖ cup can be lled in 3 to 5 seconds.)
Set the product at normal operation conditions.
①
②
③
Operation Precautions
Problem Countermeasure (Checkpoint)

(Dust Filter)
Connent it to the running water line and adjust water supply
One-Touch Fitting
(1/4 x M10)
NIPPLE
Safety pin Safety pin
Running water tap
(not included in product
parts and accessories)
Adaptor(Small)
Hose
Water
Inlet elbow
Power cord
Rear of sink
Intermediary valve adaptor
Cold water side
1/4” Standend Hose
Electrolysis Ionized Water
System main unit
Left - Alkaline outlet nipple
(5/16” Hose)
Right - Acidic outlet nipple
( 1/4” Hose)
Alkaline ionized
water outlet faucet
Acidic water
outlet faucet
Control panel
19
7. Nomenclature and
Descriptions
Install the main unit inside the sink on the oor and install the outlet faucets above the sink.
(For details, refer to the installation instructions.)
* Install the receptacle at the rear of the sink so that it is not visible from the front.)

20
Control and indicating part
Choose the level that best suits your purpose.
Operation
POWER button
Alkaline ionized
water
& level selection
button
Water
Purication
button
Filter
consumption
indication
This switch turns on/off water
supply to the main unit.
Alkaline ionized water
outlet faucet
Acidic ionized water
outlet faucet
Use this button to select the
alkaline ionized water that best
suits your purpose.
Water will be puried but not
electrolyzed.
The Valum of lter consumption
is expressed in numerical form
ranging from 000 to 999.
The pH value i nstructed i s acquired by taking into consideration the source water based or Seoul, Korea
concentration of pH 7.0 0.5 based on the water flow of 1.5 /m ( 0.5 ).
The pH values of the alkaline and acidic ionized water may not fall into the range of the pH value instructed of the
table above depending on the water quality and water flow volume.
pH level selection
pH value instructed
Indicated
10.0 0
9.5
5
1.0
9.0 1.0
8.5 1.0
7.5 1.0
5.5 1.0
3.5 1.0
High
Alkaline
Low
Acidity
High
When infusing vegetables to remove their bitter taste
When washing vegetables
Use it for drinking after consulting the doctor
Recommendable for medical and culinary usage
Recommendable for drinking and cooking
Recommendable for daily drinking
Recommendable for initial drinking or dissolving
powdered milk
Recommended for skin care an astringent
For washing dishes
Strong acidic sanitary or rinsing water can come
out when the water volume is adjusted
Alkaline
Acidity
Step 5
Step 4
Step 3
Step 2
Step 1
Step 1
Step 2
5
