Biostar A620MT-E User manual

FCC Informaon and Copyright
This equipment has been tested and found to comply with the limits of a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protecon
against harmful interference in a residenal installaon. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instrucons,
may cause harmful interference to radio communicaons. There is no guarantee that interference
will not occur in a parcular installaon.
The vendor makes no representaons or warranes with respect to the contents here and
specially disclaims any implied warranes of merchantability or tness for any purpose. Further
the vendor reserves the right to revise this publicaon and to make changes to the contents here
without obligaon to nofy any party beforehand.
Duplicaon of this publicaon, in part or in whole, is not allowed without rst obtaining the
vendor’s approval in wring.
The content of this user’s manual is subject to be changed without noce and we will not be
responsible for any mistakes found in this user’s manual. All the brand and product names are
trademarks of their respecve companies.
Dichiarazione di conformità sintetica
Ai sensi dell’art. 2 comma 3 del D.M. 275
del 30/10/2002
Si dichiara che questo prodotto è
conforme alle normative vigenti e
soddisfa i requisiti essenziali richiesti
dalle direttive
2004/108/CE, 2006/95/CE e 1999/05/CE
quando ad esso applicabili
Short Declaration of conformity
We declare this product is complying
with the laws in force and meeting all
the essential requirements as specied
by the directives
2004/108/CE, 2006/95/CE and 1999/05/
CE
whenever these laws may be applied
The terms HDMI and HDMI High-Denion Mulmedia Interface, and the HDMI Logo are trademarks or
registered trademarks of HDMI Licensing Administrator, Inc. in the United States and other countries.

2 | Table Of Contents
Table Of Contents
FCC Informaon and Copyright ������������������������������������������������������������������������������� 1
Chapter 1: Introducon������������������������������������������������������������������������������������������� 3
1.1 Before You Start.................................................................................................................. 3
1.2 Package Checklist................................................................................................................ 3
1.3 Specicaons...................................................................................................................... 4
1.4 Rear Panel Connectors........................................................................................................ 6
1.5 Motherboard Layout .......................................................................................................... 7
Chapter 2: Hardware installaon��������������������������������������������������������������������������� 10
2.1 Install Central Processing Unit (CPU) ................................................................................ 10
2.2 Install a Heatsink............................................................................................................... 11
2.3 Connect Cooling Fans ....................................................................................................... 13
2.4 Install System Memory ..................................................................................................... 14
2.5 Expansion Slots ................................................................................................................. 16
2.6 Jumper & Switch Seng................................................................................................... 19
2.7 Headers & Connectors...................................................................................................... 20
2.8 LEDs .................................................................................................................................. 25
Chapter 3: UEFI BIOS & Soware��������������������������������������������������������������������������� 26
3.1 UEFI BIOS Setup................................................................................................................ 26
3.2 BIOS Update...................................................................................................................... 26
3.3 Motherboard BIOS Update ............................................................................................... 26
3.4 Soware............................................................................................................................ 31
Chapter 4: Useful help������������������������������������������������������������������������������������������� 32
4.1 Driver Installaon ............................................................................................................. 32
4.2 AMI BIOS Beep Code......................................................................................................... 33
4.3 Troubleshoong................................................................................................................ 33
4.4 RAID Funcons.................................................................................................................. 34
APPENDIX: Specicaons in Other Languages ������������������������������������������������������� 36
Arabic...................................................................................................................................... 36
German................................................................................................................................... 38
Spanish ................................................................................................................................... 40
Thai ........................................................................................................................................ 42
Japan....................................................................................................................................... 44

Chapter 1: Introducon | 3
A620MT-E | A620MT | A620MS
Chapter 1: Introducon
1�1 Before You Start
Thank you for choosing our product. Before you start installing the motherboard, please make
sure you follow the instrucons below:
• Prepare a dry and stable working environment with sucient lighng.
• Always disconnect the computer from power outlet before operaon.
• Before you take the motherboard out from an-stac bag, ground yourself properly
by touching any safely grounded appliance, or use grounded wrist strap to remove the
stac charge.
• Avoid touching the components on motherboard or the rear side of the board unless
necessary. Hold the board on the edge, do not try to bend or ex the board.
• Do not leave any unfastened small parts inside the case aer installaon. Loose parts
will cause short circuits which may damage the equipment.
• Keep the computer from dangerous area, such as heat source, humid air and water.
• The operang temperatures of the computer should be 0 to 45 degrees Celsius.
• To avoid injury, be careful of:
Sharp pins on headers and connectors
Rough edges and sharp corners on the chassis
Damage to wires that could cause a short circuit
1.2 Package Checklist
• Serial ATA Cable x2
• Rear I/O Panel for ATX Case x1
• WIFI antenna accessories x1
• Quick Installaon Guide x1
• Fully Setup Driver DVD x1
• M.2 Anchor x1
Note
»
»The package contents may be dierent due to the sales region or models in which it was sold. For
more informaon about the standard package in your region, please contact your dealer or sales
representave.

4 | Chapter 1: Introducon
1�3 Specifications
Specicaons
CPU Support
Socket AM5 support AMD® Ryzen™ 7000 series Processors
Support for future AMD Ryzen processors with BIOS update
* Please refer to www.biostar.com.tw for CPU support list.
Chipset AMD A620
Memory
AMD Ryzen 7000 series Processors:
Supports Dual Channel DDR5 4800/ 5200/ 5400(OC)/ 5600(OC)/ 6000+(OC)
2 x DDR5 DIMM Memory Slot, Max. Supports up to 96 GB Memory
Each DIMM supports non-ECC 8/ 16/ 24/ 32/ 48 GB DDR5 module
* Please refer to www.biostar.com.tw for Memory support list.
Storage
-- Total support 1 x M.2 Socket and 4 x SATA (6Gb/s) ports
AMD Ryzen 7000 Series Processors
1x M.2 (Key M) Socket (M2M_CPU) :
Supports M.2 Type 2242/ 2260/ 2280 SSD module
Supports PCIe 4.0 x4 (64Gb/s) - NVMe SSD
AMD A620 Chipset
4x SATA III Connector (6Gb/s) : Supports AHCI & RAID 0, 1, 5, 10
LAN Realtek RTL8111H
10/ 100/ 1000 Mb/s auto negoaon, Half / Full duplex capability
Audio Codec ALC897
7.1 Channels, High Denion Audio, Hi-Fi
USB
A620MT-E | A620MT
1x USB 3.2 Gen2 Type-C port (1 via internal headers)
6x USB 3.2 Gen1 port (4 on rear I/Os and 2 via internal headers)
6x USB 2.0 port (2 on rear I/Os and 4 via internal headers)
A620MS
6x USB 3.2 Gen1 port (4 on rear I/Os and 2 via internal headers)
6x USB 2.0 port (2 on rear I/Os and 4 via internal headers)
Expansion Slots
AMD Ryzen 7000 Series Processors
1 x PCIe 4.0 x16 Slot (x16 or x8/x8 mode)
AMD A620 Chipset
1 x PCIe 3.0 x1 Slot
Rear I/Os
A620MT-E
2x WiFi Antenna Port
1x BIOS UPDATE Buon
1x HDMI Port (HDMI1.4)
1x DP Port (DP1.2)
4x USB 3.2 (Gen1) Type-A Port
2x USB 2.0 Type-A Port
1x Giga LAN port
3x Audio Jack
A620MT | A620MS
1x BIOS UPDATE Buon
1x HDMI Port (HDMI1.4)
1x DP Port (DP1.2)
4x USB 3.2 (Gen1) Type-A Port
2x USB 2.0 Type-A Port
1x Giga LAN port
3x Audio Jack
»
»Connued on Next Page

Chapter 1: Introducon | 5
A620MT-E | A620MT | A620MS
Specicaons
Internal I/Os
A620MT-E
4x SATA III Connector (6Gb/s)
1x M.2 (E Key) Socket : Supports 2230 type Wi-Fi & Bluetooth module
2x USB 2.0 Header (each header supports 2 USB 2.0 ports)
1x USB 3.2 (Gen1) Header (each header supports 2 USB 3.2 (Gen1) ports)
1x USB 3.2 (Gen2) Type-C Header
1x 8-Pin Power Connector
1x 24-Pin Power Connector
1x CPU Fan Connector
1x System Fan Connector
1x CPU water cooling connector (CPU_OPT)
1x Front Panel Header
1x Front Audio Header
1x Internal Stereo Speaker Header
1x Clear CMOS Header
1x COM Port Header
1x TPM Header
* M.2 (E Key) Wi-Fi card is not provided
A620MT
4x SATA III Connector (6Gb/s)
2x USB 2.0 Header (each header supports 2 USB 2.0 ports)
1x USB 3.2 (Gen1) Header (each header supports 2 USB 3.2 (Gen1) ports)
1x USB 3.2 (Gen2) Type-C Header
1x 8-Pin Power Connector
1x 24-Pin Power Connector
1x CPU Fan Connector
1x System Fan Connector
1x CPU water cooling connector (CPU_OPT)
1x Front Panel Header
1x Front Audio Header
1x Internal Stereo Speaker Header
1x Clear CMOS Header
1x COM Port Header
1x TPM Header
A620MS
4x SATA III Connector (6Gb/s)
2x USB 2.0 Header (each header supports 2 USB 2.0 ports)
1x USB 3.2 (Gen1) Header (each header supports 2 USB 3.2 (Gen1) ports)
1x 8-Pin Power Connector
1x 24-Pin Power Connector
1x CPU Fan Connector
1x System Fan Connector
1x CPU water cooling connector (CPU_OPT)
1x Front Panel Header
1x Front Audio Header
1x Internal Stereo Speaker Header
1x Clear CMOS Header
1x COM Port Header
1x TPM Header
Form Factor u-ATX Form Factor, 221 mm x 235 mm
OS Support Windows 10(64bit) / Windows 11(64bit)
Biostar reserves the right to add or remove support for any OS with or without noce.

6 | Chapter 1: Introducon
1.4 Rear Panel Connectors
A620MT-E
A620MT | A620MS
Note
»
»Maximum resoluon
HDMI: 4096 x 2160 @30Hz, compliant with HDMI 1.4.
DP: 4096 x 2160@60Hz, compliant with DP 1.2
»
»When using the front HD audio jack and plug in the headset, the rear sound will be automacally
Disabled.
»
»The WiFi antenna port allows you to connect to the E Key module and use the WiFi & Bluetooth
funcon.

Chapter 1: Introducon | 7
A620MT-E | A620MT | A620MS
1.5 Motherboard Layout
A620MT-E
Note
»
» represents the 1st pin.

8 | Chapter 1: Introducon
A620MT
Note
»
» represents the 1st pin.

Chapter 1: Introducon | 9
A620MT-E | A620MT | A620MS
A620MS
Note
»
» represents the 1st pin.

10 | Chapter 2: Hardware installaon
Chapter 2: Hardware installaon
2.1 Install Central Processing Unit (CPU)
Step 1: Locate the CPU socket on the motherboard
Step 2: Open Lever and then load plate using nger tab.
Step 3: Align and seat processor package on socket.

Chapter 2: Hardware installaon | 11
A620MT-E | A620MT | A620MS
Step 4: Rotate lever and press lever nger, then locked the posion.
Note
»
»Ensure that you install the correct CPU designed for AM5 socket.
2.2 Install a Heatsink
<TypeA>
Step 1: Place the heatsink and fan assembly onto the retenon frame. Match the heatsink clip
with the socket mounng-lug. Hook the spring clip to the mounng-lug.
Step 2: On the other side, push the retenon clip straight down to lock into the plasc lug on
the retenon frame, and then press down the locker unl it stops.

12 | Chapter 2: Hardware installaon
<TypeB>
Step 1: Remove the heatsink and fan assembly bracket on the motherboard and keep the
cooler backplane under the motherboard.
Step 2: Place the heatsink and fan assembly on top of the installed CPU and make sure that the
fan cable is closest to the CPU fan connector. Please refer diagram to the following screw into
the screw hole in the order shown.
Note
»
»Do not forget to connect the CPU fan connector.
»
»For proper installaon, please kindly refer to the installaon manual of your CPU heatsink.

Chapter 2: Hardware installaon | 13
A620MT-E | A620MT | A620MS
2.3 Connect Cooling Fans
These fan headers support cooling-fans built in the computer. The fan cable and connector
may be dierent according to the fan manufacturer.
CPU_FAN/ CPU_OPT: CPU Fan Header
PWM Mode
Pin Assignment
1 Ground
2+12V
3Sense
4Speed Control Signal
SYS_FAN1: System Fan Header
PWM Mode
Pin Assignment
1 Ground
2+12V
3Sense
4Speed Control Signal
Note
»
»CPU_FAN, CPU_OPT, SYS_FAN1 support 4-pin head connectors. When connecng with wires onto
connectors, please note that the red wire is the posive and should be connected to pin#2, and the
black wire is Ground and should be connected to pin#1(GND).
»
»CPU Fan Header (CPU_FAN): Support water cooling fan and CPU fan.

14 | Chapter 2: Hardware installaon
2.4 Install System Memory
DDR5 Modules
Step 1: Unlock a DIMM slot by pressing the retaining clips outward. Align a DIMM on the slot
such that the notch on the DIMM matches the break on the slot.
Step 2: Insert the DIMM vercally and rmly into the slot unl the retaining clips snap back in
place and the DIMM is properly seated.
Note
»
»If the DIMM does not go in smoothly, do not force it. Pull it all the way out and try again.

Chapter 2: Hardware installaon | 15
A620MT-E | A620MT | A620MS
Memory Capacity
DIMM Socket Locaon DDR5 Module Total Memory Size
DDR5_A 8GB/ 16GB/ 24GB/ 32GB/ 48GB Max is 96GB.
DDR5_B 8GB/ 16GB/ 24GB/ 32GB/ 48GB
Dual Channel Memory Installaon
Please refer to the following requirements to acvate Dual Channel funcon:
Install memory module of the same density in pairs, shown in the table.
Dual Channel Status DDR5_A DDR5_B
Disabled O X
Disabled X O
Enabled O O
(O means memory installed, X means memory not installed.)
Note
»
»When installing more than one memory module, we recommend to use the same brand and
capacity memory on this motherboard.
»
»When installing a single memory, we recommend that you install it in the DDR5_B.

16 | Chapter 2: Hardware installaon
2.5 Expansion Slots
PCIEX16: PCI-Express Gen4 x16 Slots (x16 mode)
• PCI-Express 4.0 compliant.
• The maximum bandwidth of the PCIe slot is 64GB/s in total.
PCIEX1: PCI-Express Gen3 x1 Slots
• PCI-Express 3.0 compliant.
• The maximum bandwidth of the PCIe slot is 2GB/s in total.
M2M_CPU: M.2 (M Key) Socket
• Supports M.2 Type 2242/ 2260/ 2280 SSD module
• Supports PCIe 4.0x 4 (64Gb/s) - NVMe/ AHCI SSD

Chapter 2: Hardware installaon | 17
A620MT-E | A620MT | A620MS
M2E-WIFI: M.2 (E Key) Socket (M.2 (E Key) Wi-Fi card is not provided)
• Support M.2 (E Key) socket module.
• Supports WiFi/ Bluetooth module.

18 | Chapter 2: Hardware installaon
Install M.2 Anchor
1. Lock the M.2 Anchor into the motherboard hole which you use for type of M.2 SSD.
2. Insert the M.2 SSD into the M.2 socket.
3. Insert the pin on the M.2 Anchor into the hole on itself.
Install an Expansion Card
You can install your expansion card by following steps:
• Read the related expansion card’s instrucon document before install the expansion
card into the computer.
• Remove your computer’s chassis cover, screws and slot bracket from the computer.
• Place a card in the expansion slot and press down on the card unl it is completely
seated in the slot.
• Secure the card’s metal bracket to the chassis back panel with a screw. (This step is only
for installing a VGA card.).
• Replace your computer’s chassis cover.
• Power on the computer, if necessary, change BIOS sengs for the expansion card.
• Install related driver for the expansion card.
Note
»
»Please be note that you will need to use M2 type screwdriver if you want to install or uninstall the
screw. It is recommended not to use a screwdriver that does not meet the specicaons, otherwise
the screw may be damaged.

Chapter 2: Hardware installaon | 19
A620MT-E | A620MT | A620MS
2.6 Jumper & Switch Setting
The illustraon shows how to set up jumpers. When the jumper cap is placed on pins, the
jumper is “close”, if not, that means the jumper is “open”.
Pin opened Pin closed Pin 1-2 closed
JCMOS: Clear CMOS Jumper
The jumper allows users to restore the BIOS safe seng and the CMOS data. Please carefully
follow the procedures to avoid damaging the motherboard.
Pin 1-2 Open:
Normal Operaon (default).
Pin 1-2 Short:
Clear CMOS data.
Clear CMOS Procedures:
1. Remove AC power line.
2. Set the jumper to “Pin 1-2 short”, you can use a metal object like a screwdriver to touch the
two pins.
3. Wait for ve seconds.
4. Aer clearing the CMOS values, be sure the jumper is “Pin 1-2 open”.
5. Power on the AC.
6. Load Opmal Defaults and save sengs in CMOS.

20 | Chapter 2: Hardware installaon
2.7 Headers & Connectors
ATX: ATX Power Source Connector
For beer compability, we recommend to use a standard ATX 24-pin power supply for this
connector. Make sure to nd the correct orientaon before plugging the connector.
Pin Assignment Pin Assignment
13 +3.3V 1+3.3V
14 -12V 2+3.3V
15 Ground 3 Ground
16 PS_ON 4+5V
17 Ground 5 Ground
18 Ground 6 +5V
19 Ground 7 Ground
20 NC 8PW_OK
21 +5V 9Standby Voltage+5V
22 +5V 10 +12V
23 +5V 11 +12V
24 Ground 12 +3.3V
ATX_12V_2X4: ATX Power Source Connector
The connector provides +12V to the CPU power circuit. If the CPU power plug is 4-pin, please
plug it into Pin 1-2-5-6 of ATXPWR2.
Pin Assignment
1+12V
2+12V
3+12V
4+12V
5 Ground
6 Ground
7 Ground
8 Ground
Note
»
»Before you power on the system, please make sure that both ATX / ATX_12V_2X4 connectors have
been plugged-in.
»
»Insucient power supplied to the system may result in instability or the peripherals not funconing
properly. Use of a PSU with a higher power output is recommended when conguring a system with
more power-consuming devices.
