MCP6P-M2 Setup Manual
FCC Information and Copyright
This equipment has been tested and found to comply with the limits of a Class
B digital device, pursuant toPart15 of theFCC Rules.These limits are designed
to provide reasonable protec tion against harmful interference in a residential
installation. This equipment generates , uses, and c an radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications.There is no guarantee
that interference will not occur in a particular ins talla tion.
The ve ndor makes no represe nta tio ns o r warranties with respec t to the
contents here andspecially disclaims any implied warranties ofmerchantability
o r fi tn es s fo r a ny p u rp os e . F u rt he r t he ve nd o r res e rves t he ri g ht to r ev is e t his
publication and to make changes to the contents here without obligation to
notify any party beforehand.
D uplication of this publication, in part or in whole, is not allowed without first
obtaining the vendor’s approval in writing.
The content of this user’s manual is subject to be changed without notice and
we will not be res ponsible for any mis takes found in this user’s manual. A ll the
brand and product names are trademarks of their respective companies.

Table of Contents
Chapter 1: Introduction.....................................................3
1.1 Before You Start...................................................................3
1.2 Package Checklist................................................................ 3
1.3 MotherboardFeatures..........................................................4
1.4 Rear Panel Connectors..........................................................5
1.5 Motherboard Layout............................................................6
Chapter 2: Hardware Installation........................................7
2.1 Installing Central Processing Unit(CPU)................................ 7
2.2 FAN Headers........................................................................9
2.3 Installing System Memory.....................................................10
2.4 Connectors and Slots............................................................12
Chapter 3: Headers & Jumpers Setup.................................14
3.1 How to Setup Jumpers..........................................................14
3.2 Detail Settings.....................................................................14
Chapter 4: RAID Functions...............................................21
4.1 Operation System................................................................21
4.2 Raid Arrays.........................................................................21
4.3 How RAID Works.................................................................21
Chapter 5: Useful Help.....................................................25
5.1 Driver Installation Note .......................................................25
5.2 Award BIOS Beep Code........................................................26
5.3 Extra Information................................................................26
5.4 Troubleshooting...................................................................27
Appendencies: SPEC In Other Language.............................28
German................................................................................................28
France..................................................................................................30
Italian..................................................................................................32
Spanish................................................................................................34
Portuguese...........................................................................................36
Polish...................................................................................................38
Russian................................................................................................40
Arabic..................................................................................................42
Japanese..............................................................................................44

MCP6P-M2
3
CHAPTER 1: INTRODUCTION
1.1 BEFORE YOU START
Tha nk you for choosing our product. Before yo u sta rt installing the
mo the rboa rd , plea se make su re you fo llo w the ins tru ctio ns be lo w:
Prepare a dry and stable working environment with
s uf ficie nt ligh ting .
Always disconnect the computer from power outlet
be fo re ope ra tion .
Befo re you take the mo the rboa rd ou t f rom a n ti-s ta tic
bag, ground yourself properly by touching any safely
grounde d appliance, or use gro unded wrist strap to
remove the static charge.
Avo id tou ch ing the compone nts o n mo the rboa rd o r the
rear side of the board unless necessary. Hold the boa rd
on the edge, do not try to bend or flex the board.
Do not lea ve any unfastened small parts inside the
case after installation. Loose parts will cause short
circuits which ma y damage the equipment.
Keep the computer from dangerous area,such as heat
source, humid air and wate r.
1.2 PACKAGE CHECKLIST
HDD Cable X 1
Se ria l ATA Cab le X 1
Rear I/O Panel for ATX Case X 1
I ns tal la tion Gu ide X 1
Fully Se tup Drive r C D X 1 (fu ll ve rs ion manua l files ins ide )
FDD Cable X 1 (optional)
Se ria l ATA Po we r Cab le X 1 (o ptio nal)
USB 2.0 Cable X1 (optional)
S/P DI F ou t Ca ble X 1 (op tiona l)
Note: The package contents may differ by area or your motherboard version.

Motherboard Manual
4
1.3 MOTHERBOARD FEATURES
SPEC
CPU
Socket AM2
AMDAthlon 64 /Athlon 64 FX
/
At hlon 6
4
x2 / Sempron processors
AMD 64 Arc hitecture enables 32 and 64 bit computing
Supports Hyper Transport and Cool=n=Quiet
FSB Supports up to 1 GHz Bandwidth
Support HyperTransport
Chipset nForce 6100-430
SuperI/O
ITE 8716F
Provides themost commonl
y
us e d l e
g
ac
y
Super I/O functionality.
Low Pin Count Interface
Environment Control initiatives,
H/W Monitor
Fan Speed Controller
ITE's "Smart Guardian" function
Main
Memory
DDR2 DIMM Slots x 2
Max Memory Capacity 4GB
Each DIMM supports 256MB/512MB/1GB
/
2GB DDR2
Dual Channel Mode DDR2memorymodule
Supports DDR2 533 / 667 / 800
Registered DIMM and ECC DIMM is not supported
Graphics Int egrat ed in nForc e 6100-430 Chips et Max S hared V ideo M emory is 512MB
IDE Integrated IDEController Ultra DMA 33 / 66 / 100 / 133 Bus Master Mode
supports PIO Mode 0~4,
SA TA II I nt e gr at e d S e ri al ATA C ont r ol l er Datatransfer rates up to 3 Gb/s.
SATA Version 2.0specificationcompliant.
LAN Realtek RTL 8201CL 10 / 100 Mb/s auto negotiation
Half / Full duplexcapability
Sound ALC662 5.1 channels audio out
High Definition Audio
PCIslot x2 Supports PCI expansion cards
Slots PCI Express x16 slot x1 Supports PCI-E x16 expansioncards
Floppyconnector x1 Eachconnectorsupports 2 Floppy drives
PrinterPort connector x1 Eachconnectorsupports 1 Printer port
IDE Connector x1 Eachconnectorsupports 2 IDE device
SATA Connector x4 Eachconnectorsupports 1 SATA devices
Front Panel Connector x1 Supports front panel facilities
Front Audio Connector x1 Supports front panel audio function
On Board
Connector
CD-in Connector x1 Supports CD audio-in function

MCP6P-M2
5
SPEC
S/PDIF out connector x1 Supports digital audio out function
CPU Fan header x1 CPU Fan power s upply (with Smart Fan function)
System Fan header x1 System Fan Power supply
CMOS clear header x1 Restore CMOS data to factory default
USB connector x3 Eachconnectorsupports 2 front panelUSB ports
Power Connector (24pin) x1 Connects to Power supply
Power Connector (4pin) x1 Connects to Power s upply
Back Panel
I/O
PS/2Keyboard x1
PS/2 Mouse x1
VGA port x1
S e ri al P ort x 1
LAN port x1
USB Port x4
Audio Jack x3
Connects to PS/2 Keyboard
Connects to PS/2 Mouse
Connect to D-SUB monitor
Provide RS-232 Serial c onnection
Connect to RJ-45 ethernet cable
Connect to USB devices
Provide Audio-In/O ut and microphone c onnection
Board Size 190 mm(W) x 244 mm(L)
Special
Features
RAID 0 / 1 / 0+1 / 5 support
OS Support Windows 2000 / XP / VISTA BiostarReserves the right to add or removesupport for
any OS Withorwithout notice.
1.4 REAR PANEL CONNECTORS
PS/2
Mouse
PS/2
Keyboard USBX2USBX2
LAN
COM1 VGA
Li ne In/
Surr ound
Li ne Out
MicIn1/
Bass/ Center

Motherboard Manual
6
1.5 MOTHERBOARD LAYOUT
PCI-EX16
PCI2
FDD1
BAT1
Codec
DIMMA1 DIMMB1
Socket AM2
Super I/O
PCI1
JATXPWR4
JCFAN1
JPRNT1
JATXPWR1
JUSB3
JCMOS1
JSFAN1 JPANEL1
JSPDIF_OUT1
JCDIN1
SATA1
IDE1
LAN
JAUDIOF 1
JUSB4
JUSB2
SATA2
SATA4SATA3
JKBMS1
VGA
JUSB1
JUSBLAN1
JA UDIO1
nForce
6100-430
BI OS
JUSBPWR2
JUSBPWR1
JKBMSPWR1
JCOM1
Not e: represents the 1■st pin.

MCP6P-M2
7
CHAPTER 2: HARDWARE INSTALLATION
2.1 INSTALLING CENTRAL PROCESSING UNIT (CPU)
Step 1: Remove the socket protection cap.
Step 2:Pull thelever towarddirectionAfrom thesocket and then raise the
lever up toa 90-degree angle.
Step 3: Lookfor the whitetriangle on socket, and the gold triangle on
CPU shouldpointtowardsthiswhite triangle.The CPU will fitonly
inthe correctorientation.

Motherboard Manual
8
Step 4: Hold the CPUdownfirmly, and then close thelever toward direct
B to complete the installation.
Step 5: Put the CPU Fan on the CPUand buckle it. Connect the CPU
FAN power cable to the JCFAN1.Thiscompletestheinstallation.

MCP6P-M2
9
2.2 FAN HEADERS
These fan headerssupport cooling-fansbuiltinthecomputer.The fan
cable and connectormaybedifferent according tothe fanmanufacturer.
Connect thefancable to the connector while matching the blackwire to
pin#1.
JCFAN1: CPU Fan Header
Pin
Assignment
1 Ground
2 +12V
3 FAN RPMrate
sense
14
4 Smart Fan
Control (By Fan)
JSFAN1: System Fan Header
Pin
Assignment
1 Ground
2 +12V
13
3 FAN RPM
rate sense
Note:
The JCFAN1 supports 4-pin head connector. The J SFAN1 supports 3-pin head
connector. When connecti ng with wires onto connectors, pl ease note that the r ed wire is
the positi ve and should be connected to pin#2, and the black wire is Ground and s hould
be connected to GND.

Motherboard Manual
10
2.3 INSTALLING SYSTEM MEMORY
A. Memory Modules
DIMMA1 DIMMB1
1. Unlocka DIMM slotbypressing the retaining clipsoutward.Aligna
DIMM on the slotsuch thatthenotch onthe DIMM matchesthe
breakontheSlot.
2. Insert theDIMM verticallyand firmlyintotheslotuntil theretaining
chip snapbackin place and the DIMM isproperly seated.

MCP6P-M2
11
B. Memory Capacity
DIMM Socket
Location DDR2 Module To tal Memo r y
Size
DIMMA1 256MB/512MB/1GB/2GB
DIMMB1 256MB/512MB/1GB/2GB
Max is 4GB.
C. Dual Channel Memory installation
To trigger the Dual Channelfunction of the motherboard, the memory module
must meet the following requirements:
Install memory module of the same density in pair, shown in thefollowing table.
Dual Channel Status DIMMA1 DIMMB1
Disabled O X
Disabled X O
Enabled O O
(O meansmemory installed,Xmeansmemorynotinstalled.)
The DRAM buswidth of thememorymodule must be thesame (x8 or
x16)

Motherboard Manual
12
2.4 CONNECTORS AND SLOTS
FDD1: Fl oppy Di sk C onne ctor
The motherboard provides a standard floppy disk connectorthat supports 360K,
720K, 1.2M, 1.44M and 2.88Mfloppy disk types. This connector supports the
providedfloppy drive ribbon cables.
133
234
ID E1: Hard Di sk C onne ctor
The motherboard has a 32-bit Enhanced PCI IDEController that provides PIO
Mode 0~4, Bus Master, and Ultra DMA 33/66/100/133functionality.
The IDE connector can connect a master and a slave drive, soyou can connect
up to two hard disk drives.
21
3940

MCP6P-M2
13
PCI-EX16: PCI-Express x16 Slot
-PCI-Express 1.0a compliant.
-Maximum theoretical realized bandwidth of 4GB/s simultaneously per
direction,for an aggregate of 8GB/s totally.
-PCI-Express supports a raw bit-rate of 2.5GB/s on the data pins.
-2X bandwidth over the traditional PCI architecture.
PCI-EX16
PCI1~PCI2: Periphe ral Component Interconnect Slots
This motherboard is equipped with 2 standard PCI slots. PCI standsfor
Peripheral Component Interconnect, and it is a bus standardfor expansion
cards. This PCI slot is designated as 32 bits.
PCI1
PCI2

Motherboard Manual
14
CHAPTER 3: HEADERS & JUMPERS SETUP
3.1 HOW TO SET UP JUMPERS
The illustration showshow to set up jumpers. When the jumper cap is
placed on pins, thejumperis“close”, ifnot, thatmeansthejumperis
“open”.
Pin opened Pin closed Pin1-2 closed
3.2 DETAIL SETT INGS
JPANEL1: Front Panel Header
This 16-pin connector includes Power-on, Reset, HDD LED, Power LED, and
speaker connection. It allows user toconnect the PC case’s front panel switch
functions.
18
16
PWR_LED
On/Off
RST
HLED
SPK
++
+
9-
-
Pin Assignment Function Pin Assignment Function
1 +5V 9 N/A
2 N/A 10 N/A N/A
3 N/A 11 N/A N/A
4 Speaker
Speaker
Connector 12 Power LED (+)
5 HDD LED (+) 13 Power LED (+)
6 HDD LED (-) Hard drive
LED 14 Power LED (-) Power LED
7 Ground 15 Power button
8 Reset control Reset button 16 Ground Power-on button

MCP6P-M2
15
J ATXP W R 1 : A TX P o we r S ou rce C onne ct o r
This connector allows user to connect 24-pin power connector on the ATX
power supply.
1
12
13
24
Pin Assignment Pin Assignment
13 +3.3V 1 +3.3V
14 -12V 2 +3.3V
15 Ground 3 Ground
16 PS_ON 4 +5V
17 Ground 5 Ground
18 Ground 6 +5V
19 Ground 7 Ground
20 NC 8 PW_OK
21 +5V 9 StandbyVoltage+5V
22 +5V 10 +12V
23 +5V 11 +12V
24 Ground 12 +3.3V
J ATXP W R 4 : A TX P o we r S ou rce C onne ct o r
By connecting this connector, it will provide +12VtoCPU power circuit.
Pin Assignment
1 +12V
2 +12V
3 Ground
1
3
2
4
4 Ground

Motherboard Manual
16
JUSB2/JUSB3/JUSB4: Headers for USB 2.0 Ports at Front Panel
This header allows user to connect additional USB cable on the PCfront panel,
and also can be connected with internal USB devices, like USB card reader.
Pin Assignment
1 +5V (fused)
2 +5V (fused)
3 USB-
4 USB-
5 USB+
6 USB+
7 Ground
8 Ground
9 Key
10 NC
1
2
9
JUSB3
JUSB2
JUSB4
10
SATA1~SATA4: Serial ATA Connectors
The motherboard has a PCI to SATA Controller with 4 channels SATA interface.
Pin Assignment
1 Ground
2 TX+
3 TX-
4 Ground
5 RX-
6 RX+
14 7
SATA3
SATA1 SATA2
SATA4
7 Ground

MCP6P-M2
17
JAUDIO F1: Front Panel Audio Heade r
This header allows user to connectthe front audio output cable with the PCf ront
panel. This header allows only HD audiofront panel connector; AC’97 connector
is not acceptable.
Pin Assignment
1 Mic Left in
2 Ground
3 Mic Right in
4 GPIO
5 Right line in
6 JackSense
7 Front Sense
8 Key
9 Left line in
10 Jack Sense
1
9
2
10
JC DIN1: CD-RO M Audio-in Connector
This connector allows user to connect the audio sourcefrom thevariaty devices,
like CD-ROM, DVD-ROM, PCI sound card, PCI TV turner card etc..
Pin
Assignment
1 Left Channel
Input
2 Ground
3 Ground
1
4
4 Right Channel
Input

Motherboard Manual
18
JSPDIF_O UT1: Digi tal Au di o-ou t C onne ctor
This connector allows user toconnect the PCI bracket SPDIF output header.
Pin Assignment
1 +5V
2 SPDIF_OUT
13
3 Ground
JCMOS1:ClearCMOS Header
By placing the jumper on pin2-3, it allows user to restore the BIOS safe setting
and the CMOS data, please carefully followthe procedures to avoid damaging
the motherboard.
13
Pin 1-2 Close:
Normal Operation
(default).
13
13
Pin 2-3 Close:
Clear CMOS data.
※Clear CMOS Procedures:
1. Remove AC power line.
2. Set thejumperto“Pin 2-3close”.
3. Waitforfiveseconds.
4. Set thejumperto“Pin 1-2close”.
5. Power on the AC.
6. Resetyour desired password or clear the CMOS data.

MCP6P-M2
19
JPRNT1: Printer Port Connector
This header allows you to connector printer on the PC.
125
2
Pin Assignment Pin Assignment
1 -Strobe 14 Ground
2 -ALF 15 Data 6
3 Data 0 16 Ground
4 -Error 17 Data 7
5 Data 1 18 Ground
6 -Init 19 -ACK
7 Data 2 20 Ground
8 -Scltin 21 Busy
9 Data 3 22 Ground
10 Ground 23 PE
11 Data 4 24 Ground
12 Ground 25 SCLT
13 Data 5 26 Key

Motherboard Manual
20
J USB PW R1 /J USB PW R2 : P o we r S ou r ce Hea de rs fo r USB Po r ts
Pin1-2 Close:
JUSBPWR1: +5V for USB ports at JUSB1/JUSBLAN1.
JUSBPWR2: +5V for USB ports atfront panel (JUSB2/JUSB3/JUSB4).
Pin2-3 Close:
JUSBPWR1:USB ports at JUSB1/JUSBLAN1 are powered by +5V standby
voltage.
JUSBPWR2: USB ports at front panel (JUSB2/JUSB3/JUSB4) are powered
by +5V standby voltage.
1
3
Pin 1-2 close
1
3
JUSBPWR1
JUSBPWR2
1
3
1
3
Pin 2-3 close
Note:
In order to support this function “Power-On system via U SB device,” “JUSBPWR1/
JUSBPWR2” jumper cap should be placed on Pin 2-3 individuall y.
JKBMSPWR1: Power Source Header for PS/2 Keyboard and Mouse
13
Pin 1-2 close
+5V for PS/2 keyboard and
mouse.
13
13
Pin 2-3 close
PS/2 keyboard and mouse are
powered by+5V standby
voltage.
Note:
In order to support this function “Power-on system via keyboard and mouse”,
“JKBMSPWR1” jumper cap should be placed on Pin 2-3.
