Biostar EIH11-SWA User manual

FCC Informaon and Copyright
This equipment has been tested and found to comply with the limits of a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protecon
against harmful interference in a residenal installaon. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instrucons,
may cause harmful interference to radio communicaons. There is no guarantee that interference
will not occur in a parcular installaon.
The vendor makes no representaons or warranes with respect to the contents here and
specially disclaims any implied warranes of merchantability or tness for any purpose. Further
the vendor reserves the right to revise this publicaon and to make changes to the contents here
without obligaon to nofy any party beforehand.
Duplicaon of this publicaon, in part or in whole, is not allowed without rst obtaining the
vendor’s approval in wring.
The content of this user’s manual is subject to be changed without noce and we will not be
responsible for any mistakes found in this user’s manual. All the brand and product names are
trademarks of their respecve companies.
Dichiarazione di conformità sinteca
Ai sensi dell’art. 2 comma 3 del D.M. 275 del
30/10/2002
Si dichiara che questo prodoo è conforme
alle normave vigen e soddisfa i requisi
essenziali richies dalle direve
2004/108/CE, 2006/95/CE e 1999/05/CE
quando ad esso applicabili
Short Declaraon of conformity
We declare this product is complying with the
laws in force and meeng all the essenal
requirements as specied by the direcves
2004/108/CE, 2006/95/CE and 1999/05/CE
whenever these laws may be applied

2 | Table Of Contents
EIH11-SWA User’s Manual
Table Of Contents
FCC Informaon and Copyright ������������������������������������������������������������������������������� 1
Chapter 1: Introducon������������������������������������������������������������������������������������������� 3
1.1 Before You Start.................................................................................................................. 3
1.2 Specicaons...................................................................................................................... 4
1.3 Rear Panel Connectors........................................................................................................ 5
1.4 Motherboard Layout........................................................................................................... 6
Chapter 2: Hardware installaon����������������������������������������������������������������������������� 7
2.1 Central Processing Unit (CPU)............................................................................................. 7
2.2 Install a Heatsink................................................................................................................. 9
2.3 Connect Cooling Fans ....................................................................................................... 10
2.4 Installing System Memory ................................................................................................ 10
2.5 Expansion Slots ................................................................................................................. 12
2.6 Jumper & Switch Seng................................................................................................... 13
2.7 Headers & Connectors...................................................................................................... 14
Chapter 3: BIOS Setup������������������������������������������������������������������������������������������� 18
3.1 Main Menu ....................................................................................................................... 19
3.2 Advanced Menu................................................................................................................ 20
3.3 Chipset Menu.................................................................................................................... 32
3.4 Security Menu................................................................................................................... 37
3.5 Boot Menu........................................................................................................................ 39
3.6 Save & Exit Menu.............................................................................................................. 41

Chapter 1: Introducon | 3
EIH11-SWA User’s Manual
Chapter 1: Introducon
1�1 Before You Start
Thank you for choosing our product. Before you start installing the motherboard, please make
sure you follow the instrucons below:
• Prepare a dry and stable working environment with sucient lighng.
• Always disconnect the computer from power outlet before operaon.
• Before you take the motherboard out from an-stac bag, ground yourself properly
by touching any safely grounded appliance, or use grounded wrist strap to remove the
stac charge.
• Avoid touching the components on motherboard or the rear side of the board unless
necessary. Hold the board on the edge, do not try to bend or ex the board.
• Do not leave any unfastened small parts inside the case aer installaon. Loose parts
will cause short circuits which may damage the equipment.
• Keep the computer from dangerous area, such as heat source, humid air and water.
• The operang temperatures of the computer should be 0 to 45 degrees Celsius.
• To avoid injury, be careful of:
Sharp pins on headers and connectors
Rough edges and sharp corners on the chassis
Damage to wires that could cause a short circuit
Note
»
»The package contents may be dierent due to the sales region or models in which it was sold. For
more informaon about the standard package in your region, please contact your dealer or sales
representave.

4 | Chapter 1: Introducon
EIH11-SWA User’s Manual
1.2 Specifications
CPU
Supports Intel® Skylake & Kabylake processor
Socket 1151 for Intel® Core i7 / i5 / i3 / Penum / Celeron processor
Maximum CPU TDP (Thermal Design Power): 65 Wa
Chipset Intel H110 Chipset
Graphic
Integrated Intel® HD Graphics engine
Dual independent displays as below (Extended mode):
- By using the DDI to VGA Transmier(RTD2168-CG) and supports D-Sub 15 pin VGA output(Max
resoluon up to 1920x1200@60Hz)
- DVI-D
Main Memory 2x DDR4 2133/ 2400 MHz LONG-DIMM slot, Max Supports up to 32 GB Memory
- DDR4 - 2400 for 7th Generaon Intel® Core™ Processor Family
SATA 3x SATA III (6Gb/s) connector
Dual LAN 2x RTL8111H, 10 / 100 / 1000 Mb/s auto negoaon, Half / Full duplex capability
Sound Codec Realtek ALC662 Audio codec on board
Expansion Slots
1x PCI-E 3.0 x16 Slot
1x PCI-E 2.0 x1 Slot
1x M.2 (M Key) Slot: Support SATAIII (6.0 Gb/s) SSD
Back Panel I/O
1x PS/2 Keyboard (Through Y cable support PS/2 KB & Mouse)
1x VGA Connector (D-sub 15 pin)
1x DVI-I Connector
2x COM Port (RS-232)
- COM1 Support RS232/ RS422/ RS485
4x USB 2.0 Connector
2x USB 3.0 Connector
2x LAN port (RJ-45)
3x Audio Jack (Line-in/ Line-out / Mic)
On Board Connectors
& Headers
2 x SATA III connector
1 x 2*5 pins, 2.54pitch front panel header
1 x 2*5 pins, 2.54pitch Digital I/O header
1x 2*5 pins, 2.54pitch 2 USB 2.0 ports wafer connector
1x 2*5 pins, 2.54pitch wafer connector only support power
1 x 2*10 pins, 2.0pitch 2 USB 3.0 ports wafer connector
1 x 1*4 pins, CPU PWM-FAN header
2 x 1*3 pins, System DC-FAN header
1 x 24 pins, ATX power connector
1 x 2*2 pins, 12V power connector
1 x Buzzer
Board Size 220 mm (W) x 244 mm (L), ATX Form Factor
Operaon Temperature 0°C ~ 60°C
Storage Temperature -20°C ~ 80°C
Relave Humidity 10% ~ 90% (non-condensing)
Other Features
ACPI/APM
Power loss recovery
Eup : S5 <0.5W
Watchdog Timer Yes (65536 segments)
RoHS Compliant Yes
OS Support Windows 7 (32/64bits), Windows 8.1 (32/64bits), Windows 10 (32/64bits)
We reserve the right to add or remove support for any OS with or without noce.

Chapter 1: Introducon | 5
EIH11-SWA User’s Manual
1�3 Rear Panel Connectors
COM1: Serial port Connectors (RS-232/RS422/RS485)
15
69
RS-232 (Default) RS-422* RS-485*
Pin Assignment
1 Carrier detect (DCD) 422 TXD- 485 DATA-
2 Received data (RXD) 422 TXD+ 485 DATA+
3Transmied data (TXD) 422 RXD+ NC
4 Data terminal ready (DTR) 422 RXD- NC
5 Signal ground (GND) GND GND
6 Data set ready (DSR) NC NC
7 Request to send (RTS) NC NC
8 Clear to send (CTS) NC NC
9*RI, 5V, 12V selected by
(selected by JP1 seng) NC NC
COM2: Serial Port Connectors (RS-232)
15
69
Pin Assignment Pin Assignment
1 DCD 2 RXD
3 TXD 4 DTR
5 GND 6 DSR
7RTS 8CTS
9*RI, 5V, 12V selected by (selected by JP2 seng)
Note
»
»COM1/2 voltage selecon is controlled by JP1/ JP2 setup.
»
»COM1 (RS-232/422/485) & COM2 (RS-232) selecon is controlled by JSEL1/JSEL2.

6 | Chapter 1: Introducon
EIH11-SWA User’s Manual
1.4 Motherboard Layout
Note
»
» represents the 1st pin.

Chapter 2: Hardware installaon | 7
EIH11-SWA User’s Manual
Chapter 2: Hardware installaon
2.1 Central Processing Unit (CPU)
Step 1: Locate the CPU socket on the motherboard
Note
»
»Remove Pin Cap before installaon, and make good preservaon for future use. When the CPU is
removed, cover the Pin Cap on the empty socket to ensure pin legs won’t be damaged.
»
»The motherboard might equip with two dierent types of pin cap. Please refer below instrucon to
remove the pin cap.
Step 2: Pull the socket locking lever out from the socket and then raise the lever up.
Step 3: Remove the Pin Cap.

8 | Chapter 2: Hardware installaon
EIH11-SWA User’s Manual
Step 4: Hold processor with your thumb and index ngers, oriented as shown. Align the
notches with the socket. Lower the processor straight down without lng or sliding the
processor in the socket.
Note
»
»Ensure that you install the correct CPU designed for LGA1151 socket.
»
»The CPU ts only in one correct orientaon. Do not force the CPU into the socket to prevent
damaging the CPU.
Step 5: Hold the CPU down rmly, and then lower the lever to locked posion to complete the
installaon.

Chapter 2: Hardware installaon | 9
EIH11-SWA User’s Manual
2.2 Install a Heatsink
Step 1: Place the CPU fan assembly on top of the installed CPU and make sure that the four
fasteners match the motherboard holes. Orient the assembly and make the fan cable is closest
to the CPU fan connector.
Step 2: Press down two fasteners at one me in a diagonal sequence to secure the CPU fan
assembly in place. Ensure that all four fasteners are secured.
Note
»
»Do not forget to connect the CPU fan connector.
»
»For proper installaon, please kindly refer to the installaon manual of your CPU heatsink.

10 | Chapter 2: Hardware installaon
EIH11-SWA User’s Manual
2.3 Connect Cooling Fans
These fan headers support cooling-fans built in the computer. The fan cable and connector
may be dierent according to the fan manufacturer. Connect the fan cable to the connector
while matching the black wire to pin#1.
CPU_FAN1: CPU fan header
Pin Assignment
1 Ground
2+12V
3 FAN RPM rate sense
4 Smart Fan Control (By Fan)
SYS_FAN1/2: System fan header
Pin Assignment
1 Ground
2+12V
3 FAN RPM rate sense
Note
»
»System Fan Headers support 3-pin head connectors. When connecng with wires onto connectors,
please note that the red wire is the posive and should be connected to pin#2, and the black wire is
Ground and should be connected to GND.
2.4 Installing System Memory
DDR4 Modules

Chapter 2: Hardware installaon | 11
EIH11-SWA User’s Manual
Step 1: Unlock a DIMM slot by pressing the retaining clips outward. Align a DIMM on the slot
such that the notch on the DIMM matches the break on the slot.
Step 2: Insert the DIMM vercally and rmly into the slot unl the retaining clips snap back in
place and the DIMM is properly seated.
Note
»» If the DIMM does not go in smoothly, do not force it. Pull it all the way out and try again.
Memory Capacity
DIMM Socket Locaon DDR4 Module Total Memory Size
DIMMA1 4GB/8GB/16GB Max is 32GB.
DIMMB1 4GB/8GB/16GB
Note
»
»When installing more than one memory module, we recommend to use the same brand and
capacity memory on this motherboard.

12 | Chapter 2: Hardware installaon
EIH11-SWA User’s Manual
2.5 Expansion Slots
PEX16_1: PCI-Express x16 Slot (x16 speed)
• PCI-Express 3.0 compliant.
• Theorecal maximum bandwidth using two slots simultaneously is 16GB/s for each slot,
a total of 32GB/s.
PEX1_1: PCI-Express x1 Slot
• PCI-Express 2.0 compliant.
• Data transfer bandwidth up to 500MB/s per direcon; 1GB/s in total.
PCIE-M2_1: M.2 (Key M) Slot
• The M.2 slot supports M.2 Type 2242/2260/2280 SSD module. When installing M.2 SSD
module, please place the screw and hex pillar to correct posion.
• Support M.2 SATA III (6.0 Gb/s) module.

Chapter 2: Hardware installaon | 13
EIH11-SWA User’s Manual
2.6 Jumper & Switch Setting
Jumper Seng
The illustraon shows how to set up jumpers. When the jumper cap is placed on pins, the
jumper is “close”, if not, that means the jumper is “open”.
Pin opened Pin closed Pin 1-2 closed
JCMOS1: Clear CMOS Jumper
Placing the jumper on pin2-3 allows user to restore the BIOS safe seng and the CMOS data.
Please carefully follow the procedures to avoid damaging the motherboard.
Pin 1-2 Close: Normal Operaon (Default)
Pin 2-3 Close: Clear CMOS data
Clear CMOS Procedures:
1. Remove AC power line.
2. Set the jumper to “Pin 2-3 close”.
3. Wait for ve seconds.
4. Set the jumper to “Pin 1-2 close”.
5. Power on the AC.
6. Reset your desired password or clear the CMOS data.

14 | Chapter 2: Hardware installaon
EIH11-SWA User’s Manual
2.7 Headers & Connectors
ATXPWR1: ATX Power Source Connector
For beer compability, we recommend to use a standard ATX 24-pin power supply for this
connector. Make sure to nd the correct orientaon before plugging the connector.
Pin Assignment Pin Assignment
13 +3.3V 1+3.3V
14 -12V 2+3.3V
15 Ground 3 Ground
16 PS_ON 4 +5V
17 Ground 5 Ground
18 Ground 6 +5V
19 Ground 7 Ground
20 NC 8 PW_OK
21 +5V 9Standby Voltage+5V
22 +5V 10 +12V
23 +5V 11 +12V
24 Ground 12 +3.3V
ATXPWR2: ATX Power Source Connector
The connector provides +12V to the CPU power circuit.
Pin Assignment
1+12V
2+12V
3 Ground
4 Ground
JPANEL1: Front Panel Header
This connector includes Power-on, Reset, HDD LED and Power LED connecons. It allows user
to connect the PC case’s front panel switch funcons.
Pin Assignment Funcon Pin Assignment Funcon
1N/A N/A 2Power LED (+) Power
LED
3 SATA_LED (+) HDD LED 4
5SATA LED (-) 6Power LED (-)
7 Ground Reset
Buon
8Power Buon Power-On
Buon
9 Reset Control 10 Ground

Chapter 2: Hardware installaon | 15
EIH11-SWA User’s Manual
JDIO1: Digital I/O Connector
This connector oers digital I/O funcons and address is set in BIOS.
Pin Assignment
1 VCC5
2 DI1
3 DO1
4 DI2
5 DO2
6 DI3
7 DO3
8 DI4
9 DO4
10 GND
SATA3_1/2/3: Serial ATA 3.0 Gb/s Connectors (1*7 Pin)
The connector supports the thin Serial ATA cable for primary internal storage devices.
Pin Assignment
1 GND
2 TX+
3TX-
4 GND
5RX-
6 RX+
7 GND
JFRONT_USB3_1: Header for USB 3.0 Ports at Front Panel
This header allows user to add addional USB ports on the PC front panel, and also can be
connected with a wide range of external peripherals.
Pin Assignment Pin Assignment
1VBUS0 11 D2+
2SSRX1- 12 D2-
3 SSRX1+ 13 Ground
4 Ground 14 SSTX2+
5SSTX1- 15 SSTX2-
6 SSTX1+ 16 Ground
7 Ground 17 SSRX2+
8D1- 18 SSRX2-
9 D1+ 19 VBUS1
10 ID 20 Key

16 | Chapter 2: Hardware installaon
EIH11-SWA User’s Manual
F_USB1: USB 2.0 Header
The mainboard provides USB 2.0 pin header. Each header allows you to connect 2 addional
USB 2.0 ports.
Pin Assignment Pin Assignment
1+5V(fused) 2+5V(fused)
3USB - 4USB -
5 USB + 6 USB +
7 Ground 8 Ground
9Key 10 NC
F_USB2X: USB 2.0 Header
The mainboard provides USB 2.0 pin header. Each header allows you to connect 2 addional
USB 2.0 ports.
Pin Assignment Pin Assignment
1+5V(fused) 2+5V(fused)
3 NA 4 NA
5 NA 6 NA
7 Ground 8 Ground
9Key 10 NC
J_PRINT1: Printer Port Connector
This header allows you to connector printer on the PC.
Pin Assignment Pin Assignment
1-Strobe 14 Ground
2-ALF 15 Data 6
3 Data 0 16 Ground
4-Error 17 Data 7
5 Data 1 18 Ground
6-Init 19 -ACK
7 Data 2 20 Ground
8-Scln 21 Busy
9 Data 3 22 Ground
10 Ground 23 PE
11 Data 4 24 Ground
12 Ground 25 SCLT
13 Data 5 26 Key
JSEL1/JSEL2: RS-232/422/485 Switch Headers for COM1
The headers determine that COM1 belongs to RS-232 (Default), 422, or 485.

Chapter 2: Hardware installaon | 17
EIH11-SWA User’s Manual
JSEL1(JCOM1A)
RS-232 RS-422 RS-485
1-3 (Default) 3-5 3-5
2-4 (Default) 4-6 4-6
7-9 (Default) 9-11 9-11
8-10 (Default) 10-12 10-12
JSEL2(JCOM1A)
1-2 (Default) RS-232
3-4 RS-422
5-6 RS-485
JP1/2: Serial Port Voltage Switch Jumper for JCOM1/2
Pin 1-2 Close: Pin9=Ring(Default)
Pin 3-4 Close: 5V
Pin 5-6 Close: 12V

18 | Chapter 3: BIOS Setup
EIH11-SWA User’s Manual
Chapter 3: BIOS Setup
Introducon
The purpose of this manual is to describe the sengs in the AMI UEFI BIOS Setup program on
this motherboard. The Setup program allows users to modify the basic system conguraon
and save these sengs to NVRAM.
UEFI BIOS determines what a computer can do without accessing programs from a disk. This
system controls most of the input and output devices such as keyboard, mouse, serial ports
and disk drives. BIOS acvates at the rst stage of the boong process, loading and execung
the operang system. Some addional features, such as virus and password protecon or
chipset ne-tuning opons are also included in UEFI BIOS.
The rest of this manual will to guide you through the opons and sengs in UEFI BIOS Setup.
Plug and Play Support
This AMI UEFI BIOS supports the Plug and Play Version 1.0A specicaon.
EPA Green PC Support
This AMI UEFI BIOS supports Version 1.03 of the EPA Green PC specicaon.
ACPI Support
AMI ACPI UEFI BIOS support Version 1.0/2.0 of Advanced Conguraon and Power interface
specicaon (ACPI). It provides ASL code for power management and device conguraon
capabilies as dened in the ACPI specicaon, developed by Microso, Intel and Toshiba.
PCI Bus Support
This AMI UEFI BIOS also supports Version 2.3 of the Intel PCI (Peripheral Component
Interconnect) local bus specicaon.
DRAM Support
DDR3 SDRAM (Double Data Rate III Synchronous DRAM) is supported.
Supported CPUs
This AMI UEFI BIOS supports the latest CPU.
Using Setup
When starng up the computer, press <Del> during the Power-On Self-Test (POST) to enter the
UEFI BIOS setup ulity. In the UEFI BIOS setup ulity, you will see General Help descripon at
the top right corner, and this is providing a brief descripon of the selected item. Navigaon
Keys for that parcular menu are at the boom right corner, and you can use these keys to
select item and change the sengs.
Note
»
»The default UEFI BIOS sengs apply for most condions to ensure opmum performance of the
motherboard. If the system becomes unstable aer changing any sengs, please load the default
sengs to ensure system’s compability and stability. Use Load Setup Default under the Exit Menu.
»
»For beer system performance, the UEFI BIOS rmware is being connuously updated. The
UEFI BIOS informaon described in this manual is for your reference only. The actual UEFI BIOS
informaon and sengs on board may be slightly dierent from this manual.
»
»The content of this manual is subject to be changed without noce. We will not be responsible for
any mistakes found in this user’s manual and any system damage that may be caused by wrong-
sengs.

Chapter 3: BIOS Setup | 19
EIH11-SWA User’s Manual
3�1 Main Menu
Once you enter AMI UEFI BIOS Setup Ulity, the Main Menu will appear on the screen
providing an overview of the basic system informaon.
BIOS Informaon
Shows system informaon including UEFI BIOS version, model name, markeng name, built
date, etc.
Total Memory
Shows system memory size, VGA shard memory will be excluded.
System Language
Choose the system default language.
System Date
Set the system date. Note that the ‘Day’ automacally changes when you set the date.
System Time
Set the system internal clock.

20 | Chapter 3: BIOS Setup
EIH11-SWA User’s Manual
3.2 Advanced Menu
The Advanced Menu allows you to congure the sengs of CPU, Super I/O, Power
Management, and other system devices.
Note
»
»Beware of that seng inappropriate values in items of this menu may cause system to malfuncon.
»
»The opons and default sengs might be dierent by RAM or CPU models.
CPU Conguraon
Intel (VMX) Virtualizaon Technology
This item enables or disables Intel Virtualizaon Technology. When enabled, a VMM can ulize
the addional hardware capabiliteies provided by Vanderpool Technology.
Opons: Disabled (Default) / Enabled
