MEMORY CONFIGURATION
FOR
X11 UP/DP/MP MOTHERBOARDS
(FOR INTEL®81XX/61XX/51XX/41XX/31XX-BASED PLATFORMS)
USER’S GUIDE
Revision 1.0c

2
Acknowledgements
Memory tables listed on Page 4 and Page 5 of this document are extracted from Section 7.5 and Section 7.6 of Intel's
Xeon-SP Design Guide Rev. 1.17, 12/2016. Intel is the rightful owner of these memory tables and the copyright thereof.
Super Micro Computer, Inc. incorporates the memory tables into this document under a general licensing provision
between the two companies. The information provided in this document is for general reference only.
Disclaimer
The information in this user’s manual has been carefully reviewed and is believed to be accurate.The vendor assumes
no responsibility for any inaccuracies that may be contained in this document, and makes no commitment to update
or to keep current the information in this manual, or to notify any person or organization of the updates. Please Note:
For the most up-to-date version of this manual, please see our website at www.supermicro.com.
Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product described in this manual
at any time and without notice. This product, including software and documentation, is the property of Supermicro and/
or its licensors, and is supplied only under a license. Any use or reproduction of this product is not allowed, except
as expressly permitted by the terms of said license.
IN NO EVENT WILL Super Micro Computer, Inc. BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,
SPECULATIVEORCONSEQUENTIALDAMAGESARISINGFROMTHEUSEORINABILITYTOUSETHISPRODUCT
OR DOCUMENTATION, EVEN IFADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, SUPER
MICRO COMPUTER, INC. SHALL NOT HAVE LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED
OR USED WITH THE PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING,
INSTALLING OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.
Any disputes arising between manufacturer and customer shall be governed by the laws of Santa Clara County in the
State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution
of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
Manual Revision 1.0c
Release Date: March 23, 2018
Unless you request and receive written permission from Super Micro Computer, Inc., you may not copy any part of this
document. Information in this document is subject to change without notice. Other products and companies referred
to herein are trademarks or registered trademarks of their respective companies or mark holders.
Copyright © 2018 by Super Micro Computer, Inc.
All rights reserved.
Printed in the United States of America

3
Memory Support for the X11 UP/DP/MP Motherboards
This document provides the user with an easy-to-use guide for proper memory configuration
and installation for the X11 UP/DP/MP (Socket P/Socket P0) Motherboards utilizing
RDIMM/3DS RDIMM/LRDIMM/3DS LRDIMM memory modules. To ensure proper memory
installation, please follow the information and instructions listed below.
1 ESD Precautions
Electrostatic Discharge (ESD) can damage electronic components including memory modules.
To avoid damaging your DIMM modules, it is important to handle it very carefully. The following
measures are generally sufficient to protect your equipment from ESD.
Precautions
•
Use a grounded wrist strap designed to prevent static discharge.
• Handle the memory module by its edges only.
• Put the memory modules into the antistatic bags when not in use.
• Check the Supermicro website for recommended memory modules
2 Memory Support
The X11 UP/DP/MP motherboard supports 3DS LRDIMM (3DS Load Reduced DIMM)/
LRDIMM (Load Reduced DIMM)/3DS RDIMM (3DS Registered DIMM)/RDIMM (Registered
DIMM), DDR4 (288-pin) ECC 2133/2400/2666 MHz memory modules. Refer to the following
tables for detailed information on memory support for the X11 UP/DP/MP motherboards.
DIMM Population Guidelines

4
3 Memory Installation Sequence
Memory modules for the X11 UP/DP/MP motherboards are populated using the "Fill First"
method. The blue memory slot of each channel is considered the "first DIMM module" of
the channel, and the black slot, the second module of the channel. When installing memory
modules, be sure to populate the blue memory slots first and then populate the black slots.
To maximize memory capacity and performance, please populate all DIMM slots on the
motherboard, including all blue slots and black slots.
4 General Memory Population Requirements
1. Be sure to use the memory modules of the same type and speed on the motherboard.
Mixing of memory modules of different types and speeds is not allowed.
2. Using unbalanced memory topology such as populating two DIMMs in one channel while
populating one DIMM in another channel on the same motherboard will result in reduced
memory performance.
DDR4 Memory Support (for 1-Slot Per-Channel Configuration)
Type Ranks Per DIMM
and Data Width DIMM Capacity (GB)
Speed (MT/s); Voltage (V); Slots per Channel
(SPC) and DIMMs per Channel (DPC)
1 Slot per Channel
1DPC (1-DIMM per Channel)
4 Gb 8 Gb 1.2 V
RDIMM SRx4 8 GB 16 GB 2666
RDIMM SRx8 4 GB 8 GB 2666
RDIMM DRx8 8 GB 16 GB 2666
RDIMM DRx4 16 GB 32 GB 2666
RDIMM 3Ds QRX4 N/A 2H-64GB 2666
RDIMM 3Ds 8RX4 N/A 4H-128GB 2666
LRDIMM QRx4 32 GB 64 GB 2666
LRDIMM
3Ds QRX4 N/A 2H-64GB 2666
8Rx4 N/A 4H-128 GB 2666
DDR4 Memory Support (for 2-Slot Per-Channel Configuration)
Type Ranks Per DIMM and
Data Width DIMM Capacity (GB)
Speed (MT/s); Voltage (V); Slots per Channel
(SPC) and DIMMs per Channel (DPC)
2 Slots per Channel
1DPC (1-DIMM per
Channel) 2DPC (2-DIMM per Channel)
4 Gb 8 Gb 1.2 V 1.2 V
RDIMM SRx4 8 GB 16 GB 2666 2666
RDIMM SRx8 4 GB 8 GB 2666 2666
RDIMM DRx8 8 GB 16 GB 2666 2666
RDIMM DRx4 16 GB 32 GB 2666 2666
RDIMM 3Ds QRX4 N/A 2H-64GB 2666 2666
RDIMM 3Ds 8RX4 N/A 4H-128GB 2666 2666
LRDIMM QRx4 32 GB 64 GB 2666 2666
LRDIMM
3Ds QRX4 N/A 2H-64GB 2666 2666
8Rx4 N/A 4H-128 GB 2666 2666
Supermicro Memory Configuration User Guide for the X11 Series Motherboards

5
5 DIMM Population Guidelines for Optimal Performance
For optimal memory performance, follow the instructions listed in the tables below when
populating memory modules.
5.1 Key Parameters for DIMM Configuration
Key Parameters for DIMM Configurations
Parameters Possible Values
Number of Channels 1, 2, 3, 4, 5, or 6
Number of DIMMs per Channel 1DPC (1 DIMM Per Channel) or 2DPC (2 DIMMs Per Channel)
DIMM Type RDIMM (w/ECC), 3DS RDIMM, LRDIMM, 3DS LRDIMM
DIMM Construction • non-3DS RDIMM Raw Cards: A/B (2Rx4), C (1Rx4), D (1Rx8), E (2Rx8)
• 3DS RDIMM Raw Cards: A/B (4Rx4)
• non-3DS LRDIMM Raw Cards: D/E (4Rx4)
• 3DS LRDIMM Raw Cards: A/B (8Rx4)
5.2 DIMM Mixing Guidelines
General DIMM Mixing Guidelines
DIMM Mixing Rules
• All DIMMs must be all DDR4 DIMMs.
• x4 and x8 DIMMs can be mixed in the same channel.
• Mixing of LRDIMMs and RDIMMs is not allowed in the same channel, across different
channels, and across different sockets.
• Mixing of non-3DS and 3DS LRDIMM is not allowed in the same channel, across
different channels, and across different sockets.
Mixing of DIMM Types within a Channel
DIMM Types RDIMM LRDIMM 3DS LRDIMM
RDIMM Allowed Not Allowed Not Allowed
LRDIMM Not Allowed Allowed Not Allowed
3DS LRDIMM Not Allowed Not Allowed Allowed
DIMM Population Guidelines
3. Populating memory slots with a pair of DIMM modules of the same type and size will
result in interleaved memory, which will improve memory performance.

6
5.3 Memory Population Tables for the X11UP Motherboards
For your system memory to work properly, please follow the memory population tables
below to install your memory modules on the X11UP motherboard. These memory
population tables were created based on the general memory population guidelines
provided by Intel to support Supermicro's X11UP motherboards.
5.3.1 Memory Population for the X11UP Motherboards with 6 DIMM Slots
Onboard
Note 1. Unbalanced memory configuration decreases memory performance and is not
recommended for Supermicro motherboards.
Note 2. The following memory population table supports Supermicro's X11UP moth-
erboards with 6 DIMM memory slots onboard, such as X11SPW-TF/CTF, X11SPM-F/
TF/TPF, and X11SPG-TF.
Memory Population Tables for the X11UP Motherboard w/6 DIMM Slots Onboard
Memory Population Sequence
1 DIMM DIMMA1
2 DIMMs DIMMA1/DIMMD1
3 DIMMs DIMMC1/DIMMB1/DIMMA1
4 DIMMs DIMMB1/DIMMA1/DIMMD1/DIMME1
5 DIMMs
(Unbalanced: not recommended) DIMMC1/ DIMMB1/DIMMA1/DIMMD1/DIMME1
6 DIMMs DIMMC1/DIMMB1/DIMMA1/DIMMD1/DIMME1/DIMMF1
Supermicro Memory Configuration User Guide for the X11 Series Motherboards
DIMMA1
DIMMD1
DIMME1
DIMMF1
DIMMB1
DIMMC1

7
5.3.2 Memory Population for the X11UP Motherboards with 8 DIMM Slots
Onboard
Note 1. Unbalanced memory configuration decreases memory performance and is not
recommended for Supermicro motherboards.
Note 2. The following memory population table supports Supermicro's X11UP moth-
erboards with 8 DIMM memory slots onboard, such as X11SPi-TF, X11SPL-F, and
X11SPH-NCTF/NCTPF.
Memory Population Table for the X11UP Motherboard w/8 DIMM Slots Onboard
Memory Population Sequence
1 DIMM DIMMA1
2 DIMMs DIMMA1/DIMMD1
3 DIMMs DIMMC1/DIMMB1/DIMMA1
4 DIMMs DIMMB1/DIMMA1/DIMMD1/DIMME1
5 DIMMs
(Unbalanced: not recommended) DIMMC1/ DIMMB1/DIMMA1/DIMMD1/DIMME1
6 DIMM DIMMC1/DIMMB1/DIMMA1/DIMMD1/DIMME1/DIMMF1
7 DIMMs
(Unbalanced: not recommended) DIMMC1/DIMMB1/DIMMA1/DIMMA2/DIMMD1/DIMME1/DIMMF1
8 DIMMs DIMMC1/DIMMB1/DIMMA1/DIMMA2/DIMMD2/DIMMD1/DIMME1/DIMMF1
DIMM Population Guidelines
DIMMA1 DIMMA2
DIMMD2
DIMMD1
DIMME1
DIMMF1
DIMMB1
DIMMC1

8
5.4 Memory Population Tables for the X11DP Motherboards
For your system memory to work properly, please follow the memory population tables
below to install your memory modules on the X11DP motherboard. These memory
population tables were created based on the general memory population guidelines
provided by Intel to support Supermicro's X11DP motherboards.
5.4.1 Memory Population for the X11DP Motherboards with 8 DIMM Slots
Onboard
Note 1. Unbalanced memory configuration decreases memory performance and is not
recommended for Supermicro motherboards.
Note 2. The following memory population table supports Supermicro's X11DP moth-
erboards with 8 DIMM memory slots onboard, such as X11DPL-i.
Memory Population Table for the X11DP Motherboard w/8 DIMM Slots Onboard
When 1 CPU is used: Memory Population Sequence
1 CPU & 1 DIMM CPU1: P1-DIMMA1
1 CPU & 2 DIMMs CPU1: P1-DIMMA1/P1-DIMMD1
1 CPU & 3 DIMMs
(Unbalanced: not recommended) CPU1: P1-DIMMB1/P1-DIMMA1/P1-DIMMD1
1 CPU & 4 DIMMs CPU1: P1-DIMMB1/P1-DIMMA1/P1-DIMMD1/P1-DIMME1
When 2 CPUs are used: Memory Population Sequence
2 CPUs & 2 DIMMs CPU1: P1-DIMMA1
CPU2: P2-DIMMA1
2 CPUs & 4 DIMMs CPU1: P1-DIMMA1/P1-DIMMD1
CPU2: P2-DIMMA1/P2-DIMMD1
2 CPUs & 6 DIMMs CPU1: P1-DIMMB1/P1-DIMMA1/P1-DIMMD1/P1-DIMME1
CPU2: P2-DIMMA1/P2-DIMMD1
2 CPUs & 8 DIMMs CPU1: P1-DIMMB1/P1-DIMMA1/P1-DIMMD1/P1-DIMME1
CPU2: P2-DIMMB1/P2-DIMMA1/P2-DIMMD1/P2-DIMME1
Supermicro Memory Configuration User Guide for the X11 Series Motherboards
CPU2
P1-DIMMA1
P1-DIMMD1
P1-DIMME1
P1-DIMMB1
P2-DIMMB1 P2-DIMMA1
P2-DIMMD1
P2-DIMME1
CPU1
Pin 1
Pin 1

9
5.4.2.1 Memory Population for the X11DP Motherboards with 12 DIMM Slots
Onboard
Note 1. Unbalanced memory configuration decreases memory performance and is not
recommended for Supermicro motherboards.
Note 2. The following memory population table supports Supermicro's X11DP mother-
boards with 12 DIMM memory slots onboard, such as X11DDW-L/NT, X11DPFR-S(N),
X11DGQ, X11DPFF-SN and X11DSN-TS.
Memory Population Tables for the X11DP Motherboard w/12 DIMM Slots Onboard
When 1 CPU is used: Memory Population Sequence
1 CPU & 1 DIMM CPU1: P1-DIMMA1
1 CPU & 2 DIMMs CPU1: P1-DIMMA1/P1-DIMMD1
1 CPU & 3 DIMMs CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1
1 CPU & 4 DIMMs CPU1: P1-DIMMB1/P1-DIMMA1/P1-DIMMD1/P1-DIMME1
1 CPU & 5 DIMMs
(Unbalanced: not recomended) CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1/P1-DIMMD1/P1-DIMME1
1 CPU & 6 DIMM CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1/P1-DIMMD1/P1-DIMME1/P1-DIMMF1
When 2 CPUs are used: Memory Population Sequence
2 CPUs & 2 DIMMs CPU1: P1-DIMMA1
CPU2: P2-DIMMA1
2 CPUs & 4 DIMMs CPU1: P1-DIMMA1/P1-DIMMD1
CPU2: P2-DIMMA1/P2-DIMMD1
2 CPUs & 6 DIMMs CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1
CPU2: P2-DIMMC1/P2-DIMMB1/P2-DIMMA1
2 CPUs & 8 DIMMs CPU1: P1-DIMMB1/P1-DIMMA1/P1-DIMMD1/P1-DIMME1
CPU2: P2-DIMMB1/P2-DIMMA1/P2-DIMMD1/P2-DIMME1
2 CPUs & 10 DIMMs CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1/P1-DIMMD1/P1-DIMME1/P1-DIMMF1
CPU2: P2-DIMMB1/P2-DIMMA1/P2-DIMMD1/P2-DIMME1
2 CPUs & 12 DIMMs CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1/P1-DIMMD1/P1-DIMME1/P1-DIMMF1
CPU2: P2-DIMMC1/P2-DIMMB1/P2-DIMMA1/P2-DIMMD1/P2-DIMME1/P2-DIMMF1
DIMM Population Guidelines
CPU1
CPU2
P1-DIMMA1
P1-DIMMD1
P1-DIMME1
P1-DIMMF1
P1-DIMMB1
P1-DIMMC1
Pin 1
P2-DIMMA1
P2-DIMMD1
P2-DIMME1
P2-DIMMF1
P2-DIMMB1
P2-DIMMC1
Pin 1

10
5.4.3 Memory Population for the X11DP Motherboards with 16 DIMM Slots
Onboard
Note 1. Unbalanced memory configuration decreases memory performance and is not
recommended for Supermicro motherboards. Note 2. The following memory popula-
tion table supports Supermicro's X11DP motherboards with 16 DIMM memory slots
onboard, such as X11DPi-N(T), X11DPT-PS, X11DPU-X(LL), X11DPH-i/T(q), X11DPG-
QT, X11DAi-N, X11DPX-T, X11DPG-SN, X11DAC.
Memory Population Table for the X11DP Motherboard w/16 DIMM Slots Onboard
When 1 CPU is used: Memory Population Sequence
1 CPU & 1 DIMM CPU1: P1-DIMMA1
1 CPU & 2 DIMMs CPU1: P1-DIMMA1/P1-DIMMD1
1 CPU & 3 DIMMs CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1
1 CPU & 4 DIMMs CPU1: P1-DIMMB1/P1-DIMMA1/P1-DIMMD1/P1-DIMME1
1 CPU & 5 DIMMs
(Unbalanced: not recom-
mended) CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1/P1-DIMMD1/P1-DIMME1
1 CPU & 6 DIMM CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1/P1-DIMMD1/P1-DIMME1/P1-DIMMF1
1 CPU & 7 DIMMs
(Unbalanced: not recom-
mended) CPU1:P1-DIMMC1/P1-DIMMB1/P1-DIMMA1/P1-DIMMA2/P1-DIMMD1/P1-DIMME1/P1-DIMMF1
1 CPU & 8 DIMMs
(Unbalanced: not recom-
mended)
CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1/P1-DIMMA2/P1-DIMMD2/P1-DIMMD1/P1-
DIMME1/P1-DIMMF1
When 2 CPUs are used: Memory Population Sequence
2 CPUs & 2 DIMMs CPU1: P1-DIMMA1
CPU2: P2-DIMMA1
2 CPUs & 4 DIMMs CPU1: P1-DIMMA1/P1-DIMMD1
CPU2: P2-DIMMA1/P2-DIMMD1
2 CPUs & 6 DIMMs CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1
CPU2: P2-DIMMC1/P2-DIMMB1/P2-DIMMA1
2 CPUs & 8 DIMMs CPU1: P1-DIMMB1/P1-DIMMA1/P1-DIMMD1/P1-DIMME1
CPU2: P2-DIMMB1/P2-DIMMA1/P2-DIMMD1/P2-DIMME1
2 CPUs & 10 DIMMs CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1/P1-DIMMD1/P1-DIMME1/P1-DIMMF1
CPU2: P2-DIMMB1/P2-DIMMA1/P2-DIMMD1/P2-DIMME1
2 CPUs & 12 DIMMs CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1/P1-DIMMD1/P1-DIMME1/P1-DIMMF1
CPU2: P2-DIMMC1/P2-DIMMB1/P2-DIMMA1/P2-DIMMD1/P2-DIMME1/P2-DIMMF1
2 CPUs & 14 DIMMs
(Unbalanced: not recom-
mended)
CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1/P1-DIMMA2/P1-DIMMD1/P1-DIMME1/P1-DIMMF1
CPU2: P2-DIMMC1/P2-DIMMB1/P2-DIMMA1/P2-DIMMA2/P2-DIMMD1/P2-DIMME1/P2-DIMMF1
2 CPUs & 16 DIMMs
(Unbalanced: not recom-
mended)
CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1/P1-DIMMA2/P1-DIMMD2/P1-DIMMD1/P1-
DIMME1/P1-DIMMF1
CPU2: P2-DIMMC1/P2-DIMMB1/P2-DIMMA1/P2-DIMMA2/P2-DIMMD2/P2-DIMMD1/P2-
DIMME1/P2-DIMMF1
Supermicro Memory Configuration User Guide for the X11 Series Motherboards

11
Note: Please refer to the memory population table on the previous page for memory
population.
DIMM Population Guidelines
CPU1
P2-DIMMA1
P2-DIMMA2
P2-DIMMD2
P2-DIMMD1
P2-DIMME1
P2-DIMMF1
P2-DIMMB1
P2-DIMMC1
P1-DIMMD2
CPU2
Pin 1
Pin 1
P1-DIMMD1
P1-DIMME1
P1-DIMMF1
P1-DIMMA2
P1-DIMMA1
P1-DIMMB1
P1-DIMMC1

12
5.4.4 Memory Population for the X11DP Motherboards with 24 DIMM Slots
Onboard
Notes 1. Unbalanced memory configuration decreases memory performance and is
not recommended for Supermicro motherboards. 2. The memory table below supports
the X11DP motherboards with 24 DIMM memory slots, such as X11DPU, X11DPT-B,
X11DPU-Z+, X11DSC+, X11PDT-BH, X11DSF, X11DPG-OT-CPU, X11DPS-R.
Supermicro Memory Configuration User Guide for the X11 Series Motherboards
Memory Population Table for the X11DP Motherboard w/24 DIMM Slots Onboard
When 1 CPU is used: Memory Population Sequence
1 CPU & 1 DIMM CPU1: P1-DIMMA1
1 CPU & 2 DIMMs CPU1: P1-DIMMA1/P1-DIMMD1
1 CPU & 3 DIMMs CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1
1 CPU & 4 DIMMs CPU1: P1-DIMMB1/P1-DIMMA1/P1-DIMMD1/P1-DIMME1
1 CPU & 5 DIMMs
(Unbalanced: not recom-
mended) CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1/P1-DIMMD1/P1-DIMME1
1 CPU & 6 DIMM CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1/P1-DIMMD1/P1-DIMME1/P1-DIMMF1
1 CPU & 7 DIMMs
(Unbalanced: not recom-
mended) CPU1: P1-DIMMB1/P1-DIMMB2/P1-DIMMA1/P1-DIMMA2/P1-DIMMD1/P1-DIMME1/P1-DIMMF1
1 CPU & 8 DIMMs CPU1: P1-DIMMB1/P1-DIMMB2/P1-DIMMA1/P1-DIMMA2/P1-DIMMD2/P1-DIMMD1/P1-DIMME2/P1-DIMME1
1 CPU & 9 DIMMs
(Unbalanced: not recom-
mended)
CPU1: P1-DIMMC1/P1-DIMMC2/P1-DIMMB1/P1-DIMMB2/P1-DIMMA1/P1-DIMMA2/
P1-DIMMD1/P1-DIMME1/P1-DIMMF1
1 CPU & 10 DIMMs
(Unbalanced: not recom-
mended)
CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMB2/P1-DIMMA1/P1-DIMMA2/
P1-DIMMD2/P1-DIMMD1/P1-DIMME2/P1-DIMME1/P1-DIMMF1
1 CPU & 11 DIMMs
(Unbalanced: not recom-
mended)
CPU1: P1-DIMMC1/P1-DIMMC2/P1-DIMMB1/P1-DIMMB2/P1-DIMMA1/P1-DIMMA2/
P1-DIMMD2/P1-DIMMD1/P1-DIMME2/P1-DIMME1/P1-DIMMF1
1 CPU & 12 DIMMs CPU1: P1-DIMMC1/P1-DIMMC2/P1-DIMMB1/P1-DIMMB2/P1-DIMMA1/P1-DIMMA2/
P1-DIMMD2/P1-DIMMD1/P1-DIMME2/P1-DIMME1/P1-DIMMF2/P1-DIMMF1
When 2 CPUs are used: Memory Population Sequence
2 CPUs & 2 DIMMs CPU1: P1-DIMMA1
CPU2: P2-DIMMA1
2 CPUs & 4 DIMMs CPU1: P1-DIMMA1/P1-DIMMD1
CPU2: P2-DIMMA1/P2-DIMMD1
2 CPUs & 6 DIMMs CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1
CPU2: P2-DIMMC1/P2-DIMMB1/P2-DIMMA1
2 CPUs & 8 DIMMs CPU1: P1-DIMMB1/P1-DIMMA1/P1-DIMMD1/P1-DIMME1
CPU2: P2-DIMMB1/P2-DIMMA1/P2-DIMMD1/P2-DIMME1
2 CPUs & 10 DIMMs CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1/P1-DIMMD1/P1-DIMME1/P1-DIMMF1
CPU2: P2-DIMMB1/P2-DIMMA1/P2-DIMMD1/P2-DIMME1
2 CPUs & 12 DIMMs CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1/P1-DIMMD1/P1-DIMME1/P1-DIMMF1
CPU2: P2-DIMMC1/P2-DIMMB1/P2-DIMMA1/P2-DIMMD1/P2-DIMME1/P2-DIMMF1
2 CPUs & 14 DIMMs CPU1: P1-DIMMB1/P1-DIMMB2/P1-DIMMA1/P1-DIMMA2/P1-DIMMD2/P1-DIMMD1/P1-DIMME2/P1-DIMME1
CPU2: P2-DIMMC1/P2-DIMMB1/P2-DIMMA1/P2-DIMMD1/P2-DIMME1/P2-DIMMF1
2 CPUs & 16 DIMMs CPU1: P1-DIMMB1/P1-DIMMB2/P1-DIMMA1/P1-DIMMA2/P1-DIMMD2/P1-DIMMD1/P1-DIMME2/P1-DIMME1
CPU2: P2-DIMMB1/P2-DIMMB2/P2-DIMMA1/P2-DIMMA2/P2-DIMMD2/P2-DIMMD1/P2-DIMME2/P2-DIMME1
2 CPUs & 18 DIMMs CPU1: P1-DIMMC1/P1-DIMMC2/P1-DIMMB1/P1-DIMMB2/P1-DIMMA1/P1-DIMMA2/P1-DIMMD2/P1-DIMMD1/ P1-DIMME2/P1-DIMME1/P1-DIMMF2/P1-DIMMF1
CPU2: P2-DIMMC1/P2-DIMMB1/P2-DIMMA1/P2-DIMMD1/P2-DIMME1/P2-DIMMF1
2 CPUs & 20 DIMMs CPU1: P1-DIMMC1/P1-DIMMC2/P1-DIMMB1/P1-DIMMB2/P1-DIMMA1/P1-DIMMA2/P1-DIMMD2/P1-DIMMD1/ P1-DIMME2/P1-DIMME1/P1-DIMMF2/P1-DIMMF1
CPU2: P2-DIMMB1/P2-DIMMB2/P2-DIMMA1/P2-DIMMA2/P2-DIMMD2/P2-DIMMD1/P2-DIMME2/P2-DIMME1
2 CPUs & 22 DIMMs
(Unbalanced: not recom-
mended)
CPU1: P1-DIMMC1/P1-DIMMC2/P1-DIMMB1/P1-DIMMB2/P1-DIMMA1/P1-DIMMA2/
P1-DIMMD2/P1-DIMMD1/P1-DIMME2/P1-DIMME1/P1-DIMMF1
CPU2: P2-DIMMC1/P2-DIMMC2/P2-DIMMB1/P2-DIMMB2/P2-DIMMA1/P2-DIMMA2/
P2-DIMMD2/P2-DIMMD1/P2-DIMME2/P2-DIMME1/P2-DIMMF1
2 CPUs & 24 DIMMs CPU1: P1-DIMMC1/P1-DIMMC2/P1-DIMMB1/P1-DIMMB2/P1-DIMMA1/P1-DIMMA2/ P1-DIMMD2/P1-DIMMD1/P1-DIMME2/P1-DIMME1/P1-DIMMF2/P1-DIMMF1
CPU2: P2-DIMMC1/P2-DIMMC2/P2-DIMMB1/P2-DIMMB2/P2-DIMMA1/P2-DIMMA2/
P2-DIMMD2/P2-DIMMD1/P2-DIMME2/P2-DIMME1/P2-DIMMF2/P2-DIMMF1

13
DIMM Population Guidelines
Note: Please refer to the memory population table on the previous page for memory
population.
CPU1
P1-DIMMA1
P1-DIMMA2
P1-DIMMD2
P1-DIMME2
P1-DIMMD1
P1-DIMME1
P1-DIMMF2
P1-DIMMF1
P1-DIMMB1
P1-DIMMC1
P1-DIMMB2
P1-DIMMC2
Pin 1
CPU2
P2-DIMMA1
P2-DIMMA2
P2-DIMMD2
P2-DIMME2
P2-DIMMD1
P2-DIMME1
P2-DIMMF2
P2-DIMMF1
P2-DIMMB1
P2-DIMMC1
P2-DIMMB2
P2-DIMMC2
Pin 1

14
5.5 Memory Population Tables for the X11MP Motherboards
For your system memory to work properly, please follow the memory population tables
below to install your memory modules on the X11MP (4-way/8-way) motherboards.
These memory population tables were created based on the general memory popula-
tion guidelines provided by Intel to support Supermicro's X11 Series motherboards.
5.5.1 Memory Population for the 4-way Motherboard w/Half Memory
Configuration Support (X11QPH+ with 24 DIMM Slots Installed)
Note 1: Unbalanced memory configuration decreases memory performance and is not
recommended for Supermicro motherboards.
Note 2: The following memory population table supports Supermicro's X11MP 4-way
motherboards, such as X11QPH+.
Memory Population Table for the 4-way Motherboard w/Half Memory Configuration Support
(X11QPH+ w/4 CPUs & 24 DIMMs Installed)
4 CPUs & 24 DIMMs
(6 DIMMs per CPU) Memory Population Sequence
CPU1 + 6 DIMMs CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1/P1-DIMMD1/P1-DIMME1/P1-DIMMF1
CPU2 + 6 DIMMs CPU2: P2-DIMMC1/P2-DIMMB1/P2-DIMMA1/P2-DIMMD1/P2-DIMME1/P2-DIMMF1
CPU3 + 6 DIMMs CPU3: P3-DIMMC1/P3-DIMMB1/P3-DIMMA1/P3-DIMMD1/P3-DIMME1/P3-DIMMF1
CPU4 + 6 DIMMs CPU4: P4-DIMMC1/P4-DIMMB1/P4-DIMMA1/P4-DIMMD1/P4-DIMME1/P4-DIMMF1
Note: The diagram below shows DIMM module population for each CPU installed on
the motherboard. Please install your processors starting with CPU Socket 1.
Supermicro Memory Configuration User Guide for the X11 Series Motherboards
DIMMA1
DIMMD1
DIMME1
DIMMF1
DIMMB1
DIMMC1
Pin 1

15
DIMM Population Guidelines
5.5.2 Memory Population for the 4-way Motherboard w/Full Memory
Configuration Support (X11QPH+ with 48 DIMM Slots Installed)
Note 1: Unbalanced memory configuration decreases memory performance and is not
recommended for Supermicro motherboards.
Note 2: The following memory population table supports Supermicro's X11MP 4-way
motherboards, such as X11QPH+.
Memory Population Table for the 4-way Motherboard w/Full Memory Configuration Support
(X11QPH+ w/4 CPUs & 48 DIMMs Installed)
4 CPUs & 48 DIMMs
(12 DIMMs per CPU
board) Memory Population Sequence
CPU1 + 12 DIMMs CPU1: P1-DIMMC1/P1-DIMMC2/P1-DIMMB1/P1-DIMMB2/P1-DIMMA1/P1-DIMMA2/
P1-DIMMD2/P1-DIMMD1/P1-DIMME2/P1-DIMME1/P1-DIMMF2/P1-DIMMF1
CPU2 + 12 DIMMs CPU2: P2-DIMMC1/P2-DIMMC2/P2-DIMMB1/P2-DIMMB2/P2-DIMMA1/P2-DIMMA2/
P2-DIMMD2/P2-DIMMD1/P2-DIMME2/P2-DIMME1/P2-DIMMF2/P2-DIMMF1
CPU3 + 12 DIMMs CPU3: P3-DIMMC1/P3-DIMMC2/P3-DIMMB1/P3-DIMMB2/P3-DIMMA1/P3-DIMMA2/
P3-DIMMD2/P3-DIMMD1/P3-DIMME2/P3-DIMME1/P3-DIMMF2/P3-DIMMF1
CPU4 + 12 DIMMs CPU4: P4-DIMMC1/P4-DIMMC2/P4-DIMMB1/P4-DIMMB2/P4-DIMMA1/P4-DIMMA2/
P4-DIMMD2/P4-DIMMD1/P4-DIMME2/P4-DIMME1/P4-DIMMF2/P4-DIMMF1
Note: The diagram below shows DIMM module population for each CPU installed on
the motherboard. Please install your processors starting with CPU Socket 1.
DIMMA1
DIMMA2
DIMMD2
DIMME2
DIMMD1
DIMME1
DIMMF2
DIMMF1
DIMMB1
DIMMC1
DIMMB2
DIMMC2
Pin 1

16
5.5.3 Memory Population for the 8-way Motherboard w/Half CPU & Half
Memory Configuration Support (X11OPi+ w/4 CPU Boards & 24 DIMM Slots
Installed)
Note 1: Unbalanced memory configuration decreases memory performance and is not
recommended for Supermicro motherboards.
Note 2: The following memory population table supports Supermicro's X11MP 8-way
motherboards, such as X11OPi+.
Note: The diagram below shows DIMM module population for each CPU Board in-
stalled in your system. Please install your processors starting with CPU Board #1.
Supermicro Memory Configuration User Guide for the X11 Series Motherboards
Memory Population Table for the 8-way Motherboard w/Half CPU & Half Memory Configuration
Support (X11OPi+ w/4 CPUs & 24 DIMMs Installed)
4 CPUs & 24 DIMMs
(6 DIMMs per CPU board) Memory Population Sequence
CPU Board 1 + 6 DIMMs CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1/P1-DIMMD1/P1-DIMME1/P1-DIMMF1
CPU Board 2 + 6 DIMMs CPU2: P2-DIMMC1/P2-DIMMB1/P2-DIMMA1/P2-DIMMD1/P2-DIMME1/P2-DIMMF1
CPU Board 3 + 6 DIMMs CPU3: P3-DIMMC1/P3-DIMMB1/P3-DIMMA1/P3-DIMMD1/P3-DIMME1/P3-DIMMF1
CPU Board 4 + 6 DIMMs CPU4: P4-DIMMC1/P4-DIMMB1/P4-DIMMA1/P4-DIMMD1/P4-DIMME1/P4-DIMMF1
DIMMA1
DIMMD1
DIMME1
DIMMF1
DIMMB1
DIMMC1
Pin 1

17
5.5.4 Memory Population for the 8-way Motherboard w/Half CPU & Full
Memory Configuration Support (X11OPi+ w/4 CPU Boards & 48 DIMM Slots
Installed)
Note 1: Unbalanced memory configuration decreases memory performance and is not
recommended for Supermicro motherboards.
Note 2: The following memory population table supports Supermicro's X11MP 8-way
motherboards, such as X11OPi+.
Memory Population Table for the 8-way Motherboard w/Half CPU & Full Memory Configura-
tion Support (X11OPi+ w/4 CPU Boards & 48 DIMMs Installed)
4 CPU boards & 48 DIMMs
(12 DIMMs per CPU board) Memory Population Sequence
CPU Board 1 + 12 DIMMs CPU1: P1-DIMMC1/P1-DIMMC2/P1-DIMMB1/P1-DIMMB2/P1-DIMMA1/P1-DIMMA2/
P1-DIMMD2/P1-DIMMD1/P1-DIMME2/P1-DIMME1/P1-DIMMF2/P1-DIMMF1
CPU Board 2 + 12 DIMMs CPU2: P2-DIMMC1/P2-DIMMC2/P2-DIMMB1/P2-DIMMB2/P2-DIMMA1/P2-DIMMA2/
P2-DIMMD2/P2-DIMMD1/P2-DIMME2/P2-DIMME1/P2-DIMMF2/P2-DIMMF1
CPU Board 3 + 12 DIMMs CPU3: P3-DIMMC1/P3-DIMMC2/P3-DIMMB1/P3-DIMMB2/P3-DIMMA1/P3-DIMMA2/
P3-DIMMD2/P3-DIMMD1/P3-DIMME2/P3-DIMME1/P3-DIMMF2/P3-DIMMF1
CPU Board 4 + 12 DIMMs CPU4: P4-DIMMC1/P4-DIMMC2/P4-DIMMB1/P4-DIMMB2/P4-DIMMA1/P4-DIMMA2/
P4-DIMMD2/P4-DIMMD1/P4-DIMME2/P4-DIMME1/P4-DIMMF2/P4-DIMMF1
Note: The diagram below shows DIMM module population for each CPU Board in-
stalled in your system. Please install your processors starting with CPU Board #1.
DIMM Population Guidelines
DIMMA1
DIMMA2
DIMMD2
DIMME2
DIMMD1
DIMME1
DIMMF2
DIMMF1
DIMMB1
DIMMC1
DIMMB2
DIMMC2
Pin 1

18
5.5.5 Memory Population for the 8-way Motherboard w/Full CPU &Half
Memory Configuration Support (X11OPi+ w/8 CPU Boards & 48 DIMM Slots
Installed)
Note 1: Unbalanced memory configuration decreases memory performance and is not
recommended for Supermicro motherboards.
Note 2: The following memory population table supports Supermicro's X11MP 8-way
motherboards, such as X11OPi+.
Memory Population Table for the 8-way Motherboard w/Full CPU & Half Memory Configuration
Support (X11OPi+ w/8 CPU Boards & 48 DIMMs Installed)
8 CPU boards & 48 DIMMs
(6 DIMMs per CPU board) Memory Population Sequence
CPU Board 1 + 6 DIMMs CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1/P1-DIMMD1/P1-DIMME1/P1-DIMMF1
CPU Board 2 + 6 DIMMs CPU2: P2-DIMMC1/P2-DIMMB1/P2-DIMMA1/P2-DIMMD1/P2-DIMME1/P2-DIMMF1
CPU Board 3 + 6 DIMMs CPU3: P3-DIMMC1/P3-DIMMB1/P3-DIMMA1/P3-DIMMD1/P3-DIMME1/P3-DIMMF1
CPU Board 4 + 6 DIMMs CPU4: P4-DIMMC1/P4-DIMMB1/P4-DIMMA1/P4-DIMMD1/P4-DIMME1/P4-DIMMF1
CPU Board 5 + 6 DIMMs CPU5: P5-DIMMC1/P5-DIMMB1/P5-DIMMA1/P5-DIMMD1/P5-DIMME1/P5-DIMMF1
CPU Board 6 + 6 DIMMs CPU6: P6-DIMMC1/P6-DIMMB1/P6-DIMMA1/P6-DIMMD1/P6-DIMME1/P6-DIMMF1
CPU Board 7 + 6 DIMMs CPU7: P7-DIMMC1/P7-DIMMB1/P7-DIMMA1/P7-DIMMD1/P7-DIMME1/P7-DIMMF1
CPU Board 8 + 6 DIMMs CPU8: P4-DIMMC1/P8-DIMMB1/P8-DIMMA1/P8-DIMMD1/P8-DIMME1/P8-DIMMF1
Supermicro Memory Configuration User Guide for the X11 Series Motherboards
DIMMA1
DIMMD1
DIMME1
DIMMF1
DIMMB1
DIMMC1
Pin 1

19
DIMM Population Guidelines
Memory Population Table for the 8-way Motherboard w/Full CPU & Memory
Configuration Support (X11OPi+ w/8 CPU Boards & 96 DIMMs Installed)
8 CPU boards & 96 DIMMs
(12 DIMMs per CPU board) Memory Population Sequence
CPU Board 1 + 12 DIMMs CPU1: P1-DIMMC1/P1-DIMMC2/P1-DIMMB1/P1-DIMMB2/P1-DIMMA1/P1-DIMMA2/
P1-DIMMD2/P1-DIMMD1/P1-DIMME2/P1-DIMME1/P1-DIMMF2/P1-DIMMF1
CPU Board 2 + 12 DIMMs CPU2: P2-DIMMC1/P2-DIMMC2/P2-DIMMB1/P2-DIMMB2/P2-DIMMA1/P2-DIMMA2/
P2-DIMMD2/P2-DIMMD1/P2-DIMME2/P2-DIMME1/P2-DIMMF2/P2-DIMMF1
CPU Board 3 + 12 DIMMs CPU3: P3-DIMMC1/P3-DIMMC2/P3-DIMMB1/P3-DIMMB2/P3-DIMMA1/P3-DIMMA2/
P3-DIMMD2/P3-DIMMD1/P3-DIMME2/P3-DIMME1/P3-DIMMF2/P3-DIMMF1
CPU Board 4 + 12 DIMMs CPU4: P4-DIMMC1/P4-DIMMC2/P4-DIMMB1/P4-DIMMB2/P4-DIMMA1/P4-DIMMA2/
P4-DIMMD2/P4-DIMMD1/P4-DIMME2/P4-DIMME1/P4-DIMMF2/P4-DIMMF1
CPU Board 5 + 12 DIMMs CPU5: P5-DIMMC1/P5-DIMMC2/P5-DIMMB1/P5-DIMMB2/P5-DIMMA1/P5-DIMMA2/
P5-DIMMD2/P5-DIMMD1/P5-DIMME2/P5-DIMME1/P5-DIMMF2/P5-DIMMF1
CPU Board 6 + 12 DIMMs CPU6: P6-DIMMC1/P6-DIMMC2/P6-DIMMB1/P6-DIMMB2/P6-DIMMA1/P6-DIMMA2/
P6-DIMMD2/P6-DIMMD1/P6-DIMME2/P6-DIMME1/P6-DIMMF2/P6-DIMMF1
CPU Board 7 + 12 DIMMs CPU7: P7-DIMMC1/P7-DIMMC2/P7-DIMMB1/P7-DIMMB2/P7-DIMMA1/P7-DIMMA2/
P7-DIMMD2/P7-DIMMD1/P7-DIMME2/P7-DIMME1/P7-DIMMF2/P7-DIMMF1
CPU Board 8 + 12 DIMMs CPU8: P8-DIMMC1/P8-DIMMC2/P8-DIMMB1/P8-DIMMB2/P8-DIMMA1/P8-DIMMA2/
P8-DIMMD2/P8-DIMMD1/P8-DIMME2/P8-DIMME1/P8-DIMMF2/P8-DIMMF1
5.5.6 Memory Population for the 8-way Motherboard w/Full CPU &Memory
Configuration Support (X11OPi+ w/8 CPU Boards & 96 DIMM Slots
Installed)
Note 1: Unbalanced memory configuration decreases memory performance and is
not recommended for Supermicro motherboards. To maximize memory capacity and
performance, please populate DIMM modules to
Note 2: The following memory population table supports Supermicro's X11MP 8-way
motherboards, such as X11OPi+.
Note: The diagram below shows DIMM module population for each CPU Board in-
stalled in your system. Please install your processors starting with CPU Board #1.
DIMMA1
DIMMA2
DIMMD2
DIMME2
DIMMD1
DIMME1
DIMMF2
DIMMF1
DIMMB1
DIMMC1
DIMMB2
DIMMC2
Pin 1

20
BIOS LICENSE
MAC CODE
BAR CODE
X11DAi-N
REV:1.01
6 DIMM Installation
1. Follow the instructions given in the
memory population guidelines listed in
the previous sections to install memory
modules on your motherboard. For the
system to work properly, please use
memory modules of the same type and
speed on the motherboard. (See the Note
below.)
2. Push the release tabs outwards on both
ends of the DIMM slot to unlock it.
3. Align the key of the DIMM module with the
receptive point on the memory slot.
4. Align the notches on both ends of the
module against the receptive points on the
ends of the slot.
5. Use two thumbs together to press the
DIMM module straight down into the slot
until the module snaps into place.
6. Press the release tabs to the lock positions
to secure the DIMM module into the slot.
7 DIMM Removal
Reverse the steps above to remove the DIMM
modules from the motherboard.
Release Tabs
Notches
Insert the DIMM module into the memory slot.
Note: All graphics including the layout drawing above are for reference only. Your sys-
tem components may look or may not look the same as graphics shown in this guide.
DIMM Population Guidelines
