M7 VKD
ENGINEERING VALIDATION TEST REPORT
COVER SHEET
CHANGE CONTROL
Description of Change Revision Sections/Pages Affected Date
Initial Release 1.0 2001/1/10
For The Athlon XP Test. 1.0 2001/08/29
For The Windows XP Test. 1.0 2001/10/13
1.2 2002/3/16
Project: M7 VKD VIA KT-133A For AMD Athlon/Duron ATX Motherboard
Date: 2002/4/1
Owner: Biostar Group
Contact: TEL: [phone] FAX: [phone]
Home Page: http://www.biostar.com.tw

2
CONTENTS
PRODUCT INFORMATION........................................................................4
Motherboard General Information.............................................................................. 4
Chipset Details............................................................................................................ 4
BIOS Details............................................................................................................... 4
CPU Support............................................................................................................... 4
Memory Support......................................................................................................... 4
On-board Features and Devices.................................................................................. 4
Mechanical.................................................................................................................. 5
DESIGN REVIEW........................................................................................7
Mainboard Voltage Measurement............................................................................... 7
Bus Clock.................................................................................................................... 7
REQUIRED BIOS DEFAULT SETTINGS ..................................................9
BIOS FEATURES SETUP......................................................................................... 9
CHIPSET FEATURES SETUP.................................................................................. 9
POWER MANAGEMENT SETUP ......................................................................... 10
PnP / PCI CONFIGURATION................................................................................. 11
INTEGRATED PERIPHERALS.............................................................................. 11
PC Health Status....................................................................................................... 11
FUNCTIONALITY.....................................................................................12
Setup Installation Test Of Operating System............................................................ 12
Basic On-board Function Test.................................................................................. 12
MS-DOS Operating .................................................................................................. 12
Windows 98 SE Operating........................................................................................ 15
Windows2000 Operating.......................................................................................... 22
Windows ME Operating ........................................................................................... 26
Windows XP (Home Edition ) Operating................................................................. 28
Linux (Red Hat) Operating....................................................................................... 30
RELIABILITY TEST..................................................................................31
Motherboard General Information............................................................................ 31
Burn-in Step.............................................................................................................. 31
OVER CLOCK TEST .................................................................................32
PERFORMANCE TEST .............................................................................33
Windows Me............................................................................................................. 33
NT 4.0 Workstation .................................................................................................. 35
Windows2000........................................................................................................... 36
Windows XP (Home Edition)................................................................................... 38
Windows XP (Home Edition)................................................................................... 39
HARDWARE COMPATIBILITY LIST.....................................................40
CPU........................................................................................................................... 40
CD-ROM................................................................................................................... 41
Camera Device.......................................................................................................... 41
DVD-ROM ............................................................................................................... 41
FDD........................................................................................................................... 42

3
HDD.......................................................................................................................... 42
Joystick ..................................................................................................................... 43
Keyboard................................................................................................................... 43
LAN Card.................................................................................................................. 44
Memory..................................................................................................................... 44
Modem Card ............................................................................................................. 45
Mouse........................................................................................................................ 46
Power Supply............................................................................................................ 46
Printer........................................................................................................................ 46
Scanner...................................................................................................................... 47
SCSI Card ................................................................................................................. 47
Sound Card................................................................................................................ 47
LAN HUB................................................................................................................. 48
USB HUB ................................................................................................................. 48
Display Card ............................................................................................................. 48
ZIP/LS120................................................................................................................. 49
Monitor ..................................................................................................................... 49
SOFTWARE COMPATIBILITY LIST.......................................................50
DOS........................................................................................................................... 50
Windows................................................................................................................... 50
Server........................................................................................................................ 50
VCORE WAVEFORM MEASUREMENT-Ver 1.0 ...................................51
Vcore Ripple Test(Dos Mode).................................................................................. 51
Vcore Transient Test(Dos Mode) ............................................................................. 52
Vcore Ripple Test(Open up the DOS Editor)........................................................... 53
Vcore Ripple Test(Standby/Resume Mode)............................................................. 54
VCORE WAVEFORM MEASUREMENT (For Athlon XP) .....................55
Vcore Ripple Test(Dos Mode).................................................................................. 55
Vcore Transient Test(Dos Mode) ............................................................................. 56
Vcore Ripple Test(Open up the DOS Editor)........................................................... 57
Vcore Ripple Test(Standby/Resume Mode)............................................................. 58
Vcore Ripple Test(Standby/Resume Mode)............................................................. 59
VCORE WAVEFORM MEASUREMENT.................................................60
Vcore Ripple Test(Dos Mode).................................................................................. 60
Vcore Transient Test(Dos Mode) ............................................................................. 61
Vcore Ripple Test(Open up the DOS Editor)........................................................... 62
Vcore Ripple Test(Standby/Resume Mode)............................................................. 63
Vcore Ripple Test(Standby/Resume Mode)............................................................. 64
VCORE STATIC LOAD TEST......................................................................65
THERMAL IMAGE TEST – Ver 1.0..........................................................66
Motherboard General Information............................................................................ 66
THERMAL IMAGE TEST – Ver 1.2..........................................................67
Motherboard General Information............................................................................ 67
FOUR CORNER TEST-Ver 1.0..................................................................68

4
PRODUCT INFORMATION
Motherboard General Information
Vendor Biostar
Model Number M7 VKD
Version Number V1.0/1.2
Platform AT ;ATX Micro ATX
FCC ID Number OK
CE Logo OK Chipset Details
System Chipset Vendor VIA
North Bridge Revision VT8363A /0046CD
South Bridge Revision VT82C686B /0043CD
Clock Generator Vendor ICW/Cypress
Clock Generator Revision W230-03H
Audio Chipset Vendor Realtek
Audio Chipset Revision ALC201A BIOS Details
BIOS Vendor AMI ;Award Phoenix Others
BIOS Revision Number VKD 0319x
BIOS Memory Size 1M ;2M 4M
Flash EPROM BIOS ;Yes No
CPU Support
Type CPU Frequency Bus Speed Comments:
Socket A AMD- Athlon Max=1400 MHz Max=133 MHz
Socket A AMD- Athlon XP Max=2100+ Max=133 MHz
Socket A AMD- Duron Max=1300 MHz Max=100 MHz
Memory Support
Maximum Memory Support SDRAM 1500 (MB)
Number of Memory Slots ;DIMM 3 .
Type of Memory Supported ;VCM ;SDRAM RDRAM DDR RAM
Parity Support ;Yes No N/A
ECC Support ;Yes No N/A
On-board Features and Devices
No of PCI Full Length Slots 2 3 4 ;5
No of ISA Full Length Slots ;1 2 3 4
Number of Shared Slots ;1 None
AMR Slot Support ;Yes No
CNR Slot Support Yes ;No
ACR Slot Support Yes ;No
100/133 MHz Front Side Bus Supports ;Yes No
PCI v2.2 Compliance ;Yes No

5
ATA-3 Compliance ;Yes No
ATAPI Compliance ;Yes No
USB Connector Support ;Yes No
AGP (2X/4X) Slot Support ;Yes No
Support AGP SideBand Addressing Mode ;Yes No
Ultra DMA 33 Support ;Yes No
Ultra DMA 66 Support ;Yes No
ATA-100 Support ;Yes No
Power on by LAN Support ;Yes No
Power on by Ring Support Yes ;No
Infrared Support ;Yes No
Enhanced Parallel Port ;Yes No
DMI Compliance ;Yes No
Hardware Monitor Support ;Yes No
ACPI v1.0/APM v1.2 Compliance ;Yes No
On-board Graphics Controller Yes ;No
On-board Network Adapter 1Mb 10Mb 100Mb ;No
On-board Audio Device Hardware ;AC97 CODEC No
Mechanical
Board Dimensions Length 30.5 cm Width 22.2 cm
Visual Inspection of Soldering ;Excellent Fair Poor
Visual Inspection of Layout Placement Connectors Quality
Screw Holes Line Up with Case ;Yes No ;Excellent Fair Poor
Power Connector placement in PCB ;Yes No ;Excellent Fair Poor
DIMM Socket placement in PCB ;Yes No ;Excellent Fair Poor
CPU Socket placement in PCB ;Yes No ;Excellent Fair Poor
FAN Connector placement in PCB ;Yes No ;Excellent Fair Poor
FDD Connector placement in PCB ;Yes No ;Excellent Fair Poor
IDE Connector placement in PCB ;Yes No ;Excellent Fair Poor
Front Panel Connectors in PCB ;Yes No None ;Excellent Fair Poor
PS/2 Connectors Line Up in Case ;Yes No None ;Excellent Fair Poor
USB Port Connectors Line Up in Case ;Yes No None ;Excellent Fair Poor
COM Port Connectors Line Up in Case ;Yes No None ;Excellent Fair Poor
Printer Port Connectors Line Up in Case ;Yes No None ;Excellent Fair Poor
VGA Port Connectors Line Up in Case Yes No ;None Excellent Fair Poor
Audio Port Connectors Line Up in Case ;Yes No None ;Excellent Fair Poor
Game Port Connectors Line Up in Case ;Yes No None ;Excellent Fair Poor
AGP Slot(Card) Line Up in Case ;Yes No None ;Excellent Fair Poor
ISA Slots(Card) Line Up in Case ;Yes No None ;Excellent Fair Poor
PCI Slots(Card) Line Up in Case ;Yes No None ;Excellent Fair Poor
AMR Slot(Card) Line Up in Case ;Yes No None ;Excellent Fair Poor
CNR Slot(Card) Line Up in Case Yes No ;None Excellent Fair Poor

6
ACR Slot(Card) Line Up in Case Yes No ;None Excellent Fair Poor
Daughter Card Slot in PCB Yes No ;None Excellent Fair Poor
Wake-on LAN connector in PCB ;Yes No None ;Excellent Fair Poor
Wake-on Modem connector in PCB Yes No ;None Excellent Fair Poor
CD Audio-in Connector in PCB ;Yes No None ;Excellent Fair Poor
AUX Audio-in Connector in PCB Yes No ;None Excellent Fair Poor
Telephony Connector in PCB ;Yes No None ;Excellent Fair Poor
Digital Video Connector Yes No ;None Excellent Fair Poor
Other Jumper in PCB ;Yes No None ;Excellent Fair Poor
Comments:

7
DESIGN REVIEW
Mainboard Voltage Measurement
Voltage List Voltage SPEC Voltage Measured Result
Battery Voltage 3.0V/7uA 3.0V/6.4uA Pass
+5V 5.0V+-5% 5.09 Pass
+12V 12.0V+-5% 12.05 Pass
-5V -5.0V+-5% -4.89 Pass
-12V -12.0V+-10% -11.37 Pass
+3.3V +3.3V+-5% 3.31 Pass
Bus Clock
Clock Frequency Spec Value (MHz) Measured Value Pass/Fail
CPU and Clock Host 100.00 100 Pass
133.33 133.7 Pass
SDRAM Clock 100.00 100 Pass
133.33 133.3 Pass
PCI Clock 33 33.11 Pass
ISA Clock 8 8.278 Pass
AGP Clock 66.67 66.67 Pass
USB Clock 48 48.08 Pass
Reference Clock 14.31818 14.33 Pass
Clock Voltage Level Spec Value (v) Measured Value Pass/Fail
CPU and Host Clock Voltage Level 3.3v 2.41 Pass
SDRAM Clock Voltage Level 3.3v 3.4 Pass
ISA Clock Voltage Level 3.3v 3.23 Pass
PCI Clock Voltage Level 3.3v 3.43 Pass
AGP Clock Voltage Level 3.3v 3.42 Pass
Reference Clock Voltage Level 2.5v 2.32 Pass
Clock Timing Spec Value (v) Measured Value Pass/Fail
CPU Clock High Time 100.00 Min 2.5ns 4.16 Pass
133.33 Min 1.4ns 2.94 Pass
CPU Clock Low Time 100.00 Min 2.4ns 4.16 Pass
133.33 Min 1.4ns 3.24 Pass
CPU Clock Rising Time 100.00 0.4ns~1.6ns 0.88 Pass
133.33 0.4ns~1.6ns 0.58 Pass
CPU Clock Falling Time 100.00 0.4ns~1.6ns 0.92 Pass
133.33 0.4ns~1.6ns 0.68 Pass
PCI Clock High Time Min.11ns 12.7 Pass
PCI Clock Low Time Min.11ns 11.7 Pass
PCI Clock Rising Time 1ns~4ns 2.9 Pass
PCI Clock Falling Time 1ns~4ns 2.8 Pass

8
Comments:

9
REQUIRED BIOS DEFAULT SETTINGS
Lists Specification Result
BIOS FEATURES SETUP
Anti-Virus Protection Enabled Pass
CPU Internal Cache Enabled Pass
External Cache Enabled Pass
CPU L2 Cache ECC Checking Enabled Pass
Quick Power On Self Test Enabled Pass
First Boot Device Floppy Pass
Second Boot Device HDD-0 Pass
Third Boot Device LS120 Pass
Boot Other Device Enabled Pass
Swap Floppy Driver Disabled Pass
Boot up Floppy Seek Enabled Pass
Boot Up Numlock Status On Pass
Gate A20 Option Fast Pass
Security Option Setup Pass
OS Select For DRAM > 64MB Non-OS2 Pass
Shadow Control Press Enter Pass
Video BIOS Shadow Enable Pass
C8000-CBFFF Shadow Disabled Pass
CC000-CFFF Shadow Disabled Pass
D0000-D3FFF Shadow Disabled Pass
D4000-D7FFF Shadow Disabled Pass
D8000-DBFFF Shadow Disabled Pass
DC000-DFFF Shadow Disabled Pass
CHIPSET FEATURES SETUP
Onchip Device Control Press Enter Pass
OnChip Sound Auto Pass
OnChip Modem Auto Pass
OnChip USB Enable Pass
OnChip USB 2 Enable Pass
USB Keyboard Support Disable Pass
AGP device control Press Enter Pass
AGP Aperture Size 64M Pass
AGP Driving Control Auto Pass
X AGP Driving Value DA Pass
AGP Master 1 WS Write Disable Pass
AGP Master 1 WS Read Disable Pass
Back 0/1 DRAM Timing SDRAM 8/10ns Pass
Back 2/3 DRAM Timing SDRAM 8/10ns Pass
Back 4/5 DRAM Timing SDRAM 8/10ns Pass
SDRAM Cycle Length 3 Pass

10
DRAM Clock Host CLK Pass
P2C/C2P Concurrency Disabled Pass
Fast R-W Turn Around Disabled Pass
Video RAM Cacheable Disabled Pass
ISA I/O Recovery Time Disabled Pass
AGP-4X Mode Enabled Pass
K7 CLK_CTL Select Optimal Pass
PCI#2 Access #1 Retry Enabled Pass
POWER MANAGEMENT SETUP
ACPI Function Enabled Pass
Power Management Press Enter Pass
Power Management User Define Pass
HDD Power Down Disable Pass
Doze Mode Disable Pass
Suspend Mode Disable Pass
ACPI Suspend Type S1(POS) Pass
PM Control by APM YES Pass
Video Off Option Suspend - > off Pass
Video Off Method V/H SYNC+Blank Pass
Modem Use IRQ 3 Pass
Soft-off by PWR-BTN Instant-off Pass
Wake Up Events Press Enter Pass
VGA OFF Pass
LPT & COM LPT/COM Pass
HDD & FDD ON Pass
PCI Master OFF Pass
Power On by PCI Card Disable Pass
Wake up On lan/Ring Disable Pass
RTC Alarm Resume Disable Pass
X Date ( of Month) 0 Pass
X Resume Time (hh : mm :ss) 0 0 0 Pass
Primary INTR ON Pass
IRQs Activity Monitoring Press Enter Pass
IRQ3 (COM2) Enabled Pass
IRQ4 (COM1) Enabled Pass
IRQ5 (LPT2) Enabled Pass
IRQ6 (Floppy Disk) Enabled Pass
IRQ7 (LPT1) Enabled Pass
IRQ8 (RTC Alarm) Disabled Pass
IRQ9 (IRQ2 Redir) Disabled Pass
IRQ10 (Reserved) Disabled Pass
IRQ11 (Reserved) Disabled Pass
IRQ12 (PS/2 Mouse) Enabled Pass

11
IRQ13 (Coprocessor) Enabled Pass
IRQ14 (Hard Disk) Enabled Pass
IRQ15 (Reserved) Disabled Pass
PnP / PCI CONFIGURATION
PnP OS Installed No Pass
Reset Configuration Data Disabled Pass
Resources Controlled By Auto(ESCD) Pass
X IRQ Resources Press Enter Pass
X DMA Resources Press Enter Pass
PCI/VGA Palette Snoop Disabled Pass
Assign IRQ for VGA Enabled Pass
Assign IRQ for USB Enabled Pass
INTEGRATED PERIPHERALS
OnChip IDE Control Press Enter Pass
Muti-Media setting Press Enter Pass
Init Display First PCI Slot Pass
Onboard FDD Controller Enabled Pass
Onboard Serial Port 1 3F8/IRQ4 Pass
Onboard Serial Port 2 2F8/IRQ3 Pass
UART 2 Mode Standard Pass
X IR Function Duplex Half Pass
X TX,RX inverting enable No,Yes Pass
Onboard Parallel Port 378/IRQ7 Pass
Onboard Parallel Mode Normal Pass
ECP Mode Use DMA 3 Pass
Parallel Port EPP Type EPP1.9 Pass
PC Health Status Write Actual Values
CPU Host Clock (CPU/PCI) Default
Show H/W Monitor in POST 3 sec
Current CPU Fan Speed 4964 RPM
Current System Fan Speed 4519 RPM
Vcore 1.81V
Vcc SRAM 3.29V
+3.3V 3.31V
+5.0V 5V
+12V 12.12V
Comments:

12
FUNCTIONALITY
Setup Installation Test Of Operating System Pass/Fail
DOS 6.22 Pass
Windows 98 Pass
Windows 98 Second Edition Pass
Windows ME Pass
Windows NT 4.0 Workstation Pass
Windows 2000 Professional Pass
Windows XP Home Edition Pass
Windows XP Professional Pass
Linux (Red Hat 7.0) Pass
Basic On-board Function Test ---
Test Platform MS-DOS Operating Comment
CPU Athlon 1200 MHz
Memory Inficon 64M *2 (PC133 )
HDD Quantum 15G
CDROM BTC 52X
Sound Card Onboard
Video Card Power Color / TNT2 M 64
LAN Card Intel 82557 and Intel 82559
Test Item Pass/Fail
Clear CMOS with Jumper Pass
Cold Boot (Power Turn on ) Pass
CMOS Load Default Setup Pass
Memory Size Counter Check Pass
BIOS Lock Function Pass
Warm Boot (HW/SW Reset) Pass
System Configuration Review (CPU Type/Cache/SDRAM/HDD…) Pass
Power Fail Function Test None
Prompt Into DOS Mode Pass
Typing Some DOS Comment Pass
Run Scandisk Pass
PS/2 Keyboard Test Pass
USB Keyboard Legacy Support Test Pass
Boot Floppy Driver A Pass
FDISK Hard Disk Driver Pass
Format Hard Disk Driver Pass
Boot Hard Disk Driver C Pass
Power LED Check Pass
HDD LED Check Pass
Systems Speaker Pass

13
Buzz None
SMI Function Test ---
SMI Pin Function Test Pass
Time Out Function Test Pass
Power LED Flash Check Pass
Power On Control ---
Power On By RTC Test Pass
Power On By LAN Test (Intel SPD3) Pass
Power On By Modem Test Pass
Boot Management ---
Boot Form CD-ROM Pass
Boot From SCSI HDD Pass
Boot From ATAPI ZIP/LS120 Drive Pass
Boot From LAN Pass
RTC Test ---
COMS RTC Date Check Pass
Windows 98SE RTC Date Check Pass
COMS RTC Time Out Test Pass
Windows 98SE RTC Time Out Test Pass
Qaplus 7.0 Test ---
All Test RTC Fail (Utility
issue)
Checkit 4.0 ---
System Board Test Pass
Memory Test Pass
Hard Disk Test Pass
Floppy Test Pass
Serial Port Test Pass
Parallel Port Test Pass
Modem Test Pass
Video Card Test Pass
Printer Test Pass
Keyboard Test Pass
AMIDiag 6.0 ---
System ---
Processor Test (CPU Frequency Detect error) Fail (Utility issue)
DMA Controller Test Pass
Interrupt Controller Test Pass
Timer Test Pass
Real Time Clock Test Pass
CMOS Validity Test Pass
Speaker Test Pass
PCI System Test Pass

14
Plug-n-Play Test Pass
Multimedia CPU Extensions Pass
Memory ---
BIOS ROM Test Pass
Parity Test Pass
Pattern Test Pass
Extended Pattern Test Pass
Walking 1’s Test Pass
Walking 0’s Test Pass
Random Memory Test Pass
Address Test Pass
Refresh Test Pass
Data Bus Test Pass
Cache Memory Test Pass
IDE ---
IDE HDD Test Pass
IDE CD Test Pass
FDD ---
Drive Speed Test Pass
Random R/W Test Pass
Sequential R/W Test Pass
Elevator Seek Test Pass
Disk Change Line Test Pass
KBD ---
Controller Test Pass
Scan/ASCII code test Pass
Keyboard LED Test Pass
Keyboard Clock Line Test Pass
Keyboard Data Line Test Pass
Video ---
Video Memory Test Pass
Attribute Test Pass
Page Selection Test Pass
Color Test Pass
Text Mode Test Pass
Graphics Mode Test Pass
VESA Video Mode Test Pass
VESA Video Memory Test Pass
Misc. ---
Serial Port Test Pass
Parallel Port Test Pass
PS / 2 Mouse Test Pass
APM Functionality Test Pass

15
Device APM Test Pass
ACPI Test Pass
I82557 Ethernet chip Pass
Comments:
Test Platform Windows 98 SE Operating Comment
CPU Athlon 1333 MHz
Memory Hitachi 128M X3
HDD IBM DTLA-307030
CDROM A-Open 48x
Sound Card On board
Video Card ELSA GLADIAC ULTRA
LAN Card Intel 82559
Test Item Pass/Fail
System Comparability Test Pass
Windows 98 Setup Installation Test Pass
Supports Driver Installation Test Pass
Standby Mode Test Pass
Shut Down Test Pass
Restart Test Pass
Restart In MS-DOS Mode Pass
Scandisk Test Pass
Disk Defragmenter Test Pass
Disk Converter Test (FAT32) Pass
System Properties Information Review (System Device Manager) Pass
Setup installation Microsoft Office 2000 Test Pass
Reboot Program test for over night Pass
Memory Comparability Test ---
Running AVI Files With Multi Stress Pass
Winstone 99 Test Pass
3D Winbench 99 Test Pass
Final Reality 1.01 Test Pass
BCM Memory Test Pass
Device Comparability Test ---
PS/2 Connector Test ---
PS/2 Keyboard Test Pass
PS/2 Mouse Test Pass
COM Port Test ---
Add Serial Mouse PnP Test Pass
Add Modem PnP Test Pass

16
Print Port Test ---
Add Printer PnP Test Pass
Add ZIP Device Test Pass
LL5 Cable test (Data Transfer test) Pass
IrDA Function Test ---
Add IR Printer Test Pass
Peer to Peer Data Transfer Test (Ir-In/Ir-Out) Pass
FDD Connector Test ---
Create Windows98 Startup Disk Pass
Format 1.44 Floppy Driver Pass
IDE Connectors Test ---
CD-ROM Data Read Test Pass
DVD-ROM Data Read Test Pass
Format ZIP Driver With Floppy A Type Pass
Format ZIP Driver With Removable Device Type Pass
LS120 Device Driver Test Pass
PIO Mode 4 Hard Disk Test Pass
Ultra DMA 33 Hard Disk Test Pass
Ultra DMA 66 Hard Disk Test Pass
Ultra DMA 100 Hard Disk Test Pass
ZIP Device Driver Test Pass
USB Ports Test ---
Add Keyboard PnP Test Pass
Add Mouse PnP Test Pass
Add Printer PnP Test Pass
Add Scanner PnP Test Pass
Add Camera PnP Test Pass
Add Modem PnP Test Pass
Add Joystick PnP Test Pass
Add ZIP PnP Test Pass
Add LAN PnP Test Pass
LAN Card Test ---
Boot ROM Function Test None
Login Server Test Pass
Peer to Peer 10Mbps or 100Mbps Data Transfer Test Pass
Power On By LAN Test Pass
Playing AVI Files By The LAN Pass
Shut Down By LAN Test Pass
Shut Down To DOS Mode Then Resume Windows And Login Server Test Pass
Setup Installation Winstone 99 By The LAN Pass
Setup Installation Winbench 99 By The LAN Pass
Setup Installation 3D Winbench 99 By The LAN Pass
Add Token Ring LAN Card Test Pass

17
Wake On LAN Test (Standby Mode) Pass
PCI Slots Test ---
Add SCSI Card Test Pass
Add LAN Card Test Pass
Power On By LAN Test (Intel 82558B) Pass
Wake On LAN Test (Standby Mode) Pass
Shut Down By LAN Test Pass
Add Token Ring LAN Card Test Pass
Add Sound Card Test Pass
Add Modem Card Test Pass
Wake On Modem Test (Standby Mode) Pass
Add MPEG II Card Test Pass
ISA Slots Test ---
Add LAN Card Test Pass
Add Token Ring LAN Card Test Pass
Add Sound Card Test Pass
Add Modem Card Test Pass
AMR Slots Test ---
Add AMR Software Modem Card Test Pass
Connect Performance Check Pass
Internet Explorer Test Pass
Netscape Browser Test Pass
Connect to ISP For 12 hours Pass
Download Server Files For 12 hour Pass
Download Files using AMR Modem (Over 10MB) Pass
Send & Receive e-mail Test Pass
Modem Fax Function Test (Transmit a fax to Fax Machine) Pass
Modem Fax Function Test (Transmit a fax to Modem) Pass
Modem Fax Function Test (Receive a fax from Fax Machine) Pass
Modem Fax Function Test (Receive a fax from Modem) Pass
Wake on Ring Test (Standby Mode) Pass
Recording a MP3 File From Internet ISP Server Pass
Voice Pass
VGA Function Test ---
VGA Drivers Setup Installation Test Pass
Display Properties Information Review Pass
Change Resolution / Color Test Pass
Run 3D Screen Saver Pass
Run 3D Games Pass
VGA Resolution Test ( Monitor : ViewSonic GF775 /AGP: V3800M ) ---
Resolution Color Depth Optimal 75 Hz 85 Hz 100 Hz
640x480 16 √none none none Pass

18
640x480 256 √√√√Pass
640x480 16 bit √√√√Pass
640x480 32 bit √√√√Pass
800x600 256 √√√√Pass
800x600 16 bit √√√√Pass
800x600 32 bit √√√√Pass
1024x768 256 √√√√Pass
1024x768 16 bit √√√√Pass
1024x768 32 bit √√√√Pass
1152x864 256 √√√none Pass
1152x864 16 bit √√√none Pass
1152x864 32 bit √√√none Pass
1280x1024 256 √√√none Pass
1280x1024 16 bit √√√none Pass
1280x1024 32 bit √√√none Pass
Check Screen Have No Any Shadow Or Garbage Pass
Playing MPEG Files Test Pass
Playing VCD Test Pass
Playing DVD Test Pass
Playing *.AVI files (Stress Test for Over Night) Pass
Audio Function Test ---
Audio Drivers Setup Installation Test Pass
Audio Control Panel Function Test Pass
CD-In Function Check Pass
Game Port Test Pass
Line-In Function Check Pass
Mic-In Function Check Pass
R/L Channel Check Pass
Sound Recorder Test Pass
Run MPG Files Pass
System Properties Information Review Pass
Speaker Out Quality Test Pass
Telephony Function Supports Pass
Playing Audio CD Test Pass
Playing Wave Test Pass
Playing MIDI Test Pass
Playing Video Test Pass
Playing MP3 Test Pass
FF Function (Playing CD music,MIDI,WAV,AVI files using Media player) Pass
FW Function (Playing CD music,MIDI,WAV,AVI files using Media player) Pass
Pause Function (Playing CD music,MIDI,WAV,AVI files using Media player) Pass
S1 Function Supports Test Pass

19
S3 Function Supports Test None
Windows Utility Test ---
WinTach 1.2 Pass
Speedy 1.0 Pass
BCM Diagnostics ---
System Info Pass
DMI Info Pass
Processor Test Pass
Memory Test Pass
Audio Test Pass
Video Test Pass
Graphics Test Pass
Hard Disk Test Pass
Floppy Disk Test Pass
CD-ROM Test Pass
Stress Test Pass
MS Mouse Pass
MS Joystick Pass
MS ScanDisk Pass
PC-Doctor For Windows ---
CPU Test Pass
Hard Driver Test Pass
Floppy Test Pass
LS-120 Driver Test Pass
CD-ROM/DVD Test Pass
ZIP Driver Test Pass
Memory Test Pass
PCI Test Pass
Video Test Pass
AGP Test Pass
SCSI Test Pass
IR Driver Test Pass
COM Loopback Pass
Serial Port Internal Test Pass
Parallel Port Internal Test Pass
Parallel Port Loopback Pass
USB Test Pass
CMOS Test Pass
Keyboard Test Pass
AVI Video Test Pass
Microphone Test Pass
Audio Test Pass
Mouse Test Pass

20
Monitor Test Pass
Printer Test Pass
Joystick Test Pass
Winstone 99 ---
Business Winstone 99 Pass
Winstone 2000 ---
Winstone 2000 Pass
Winstone 2001 ---
Winstone 2001 Pass
Winbench 99 ---
Business Disk WinMark 99 Pass
Business Graphics WinMark 99 Pass
CPUmark99 Pass
DirectDraw Tests Pass
Disk Inspection Tests Pass
Disk WinMark Pass
FPU WinMark Pass
GDI/USER Inspection Tests Pass
High-End Disk WinMark 99 Pass
High-End Graphics WinMark 99 Pass
Video Tests Pass
3D Winbench 2000 ---
3D Performance Pass
3D Processing Pass
3D Quality Pass
3D WinMark Pass
3D Mark 2000 ---
3D Marks Pass
Demo Mode Pass
Audio Winbench99 (Based onboard Sound controller) ---
Direct Sound CPU Util 44.1 kHz 16bit Static ---
Hardware Voices 0
Voice 8 3.69
Voice 16 4.15
Voice 32 5.04
DirectSound CPU Util , 44.1 kHz , 16 bits Streaming ---
Hardware Voice 0
Voice 8 3.68
Voice 16 4.16
Voice 32 5.07
DirectSound CPU Util , 22 kHz , 8 bits Static ---
Hardware Voice 0
Voice 8 3.37
