BIRO FBC-4800SS User manual

MODEL FBC-4800SS
STAINLESS STEEL
FROZEN MEAT CHIPPER
Operating Manual and Parts List
Applicable on Machines Starting with Serial No. 10200
Biro Designed Biro Built
+IMPORTANT NOTICE +
This Manual contains important
safety instructions which must
be strictly followed when using
this equipment.
PTCT
FBC-4800
029-10-05-16
029-5-07-17

TABLE OF CONTENTS
Page
NOTICETOOWNERSANDOPERATORS......................................... 1
SAFETYTIPS ............................................................... 2
INSTALLATION ............................................................. 3
UNCRATINGANDSETUP.............................................. 3-4
WIRINGDIAGRAM...................................................... 5
OPERATION................................................................ 6
TOPROCESSPRODUCT ................................................ 6
TROUBLESHOOTINGMACHINEOPERATION ............................... 7
MAINTENANCE ............................................................. 8
CLEANING................................................................. 9
PARTSDIAGRAMS...........................................................10
RUNNER AND GUILLOTINE BLADE REPLACEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-15
LUBRICATION ..............................................................14
GROVE GEAR REDUCER DIAGRAM & LUBRICATION. . . . . . . . . . . . . . . . . . . . . . 16-17-18-19-20
MORSEGEARREDUCERDIAGRAM&LUBRICATION................................21
OPERATOR'SNOTES.........................................................22
OPERATOR’SSIGNATUREPAGE................................................23
LIMITEDWARRANTY.........................................................24
OLD AND NEW STYLE BLADES AND OPERATOR’S NOTES

BIRO’s products are designed to process food products safely and efficiently. Unless the oper-
ator is properly trained and supervised, however, there is the possibility of a serious injury. It is the
responsibility of the owner to assure that this machine is used properly and safely, strictly following
the instructions contained in this Manual and any requirements of local law.
No one should use or service this machine without proper training and supervision. All opera-
tors should be thoroughly familiar with the procedures contained in this Manual. Even so BIRO
cannot anticipate every circumstance or environment in which its products will be used. You, the
owner and operator, must remain alert to the hazards posed by the function of this equipment —
particularly the MOVING SHUTTLE WITH SHARP CHIPPING BLADES, which can severly injure an
inattentive operator amputating fingers and limbs. No one under eighteen (18) years of age
should operate this equipment. If you are uncertain about a particular task, ask your supervisor.
This Manual contains a number of safe practices in the SAFETY TIPS section. Additional warn-
ings are placed throughout the Manual. Warnings related to your personal safety are indicated by:
Warnings related to possible damage are indicated by:
BIRO also has provided warning labels on the equipment. If any warning label or Manual be-
comes misplaced, damaged, or illegible, please contact your nearest Distributor or BIRO directly
for a replacement.
Remember, however, this Manual or the warning labels do not replace the need to be alert and
to use your common sense when using this equipment.
This Manual applies to SANITARY TIN machines with serial numbers 3100 to 5297, and
STAINLESS STEEL machines with serial numbers 10200 to present.
THE BIRO MANUFACTURING COMPANY
1114 Main Street
MARBLEHEAD, OHIO 43440-2099 U.S.A.
Phone [phone]
Fax [phone]
E-mail: [e-mail]
Web: http://www.birosaw.com
1
NOTICE TO OWNERS AND OPERATORS
OR
-NOTE -
Acopy of this manual is included with each MODEL FBC-4800SS
FROZEN MEAT CHOPPER MACHINE.
The descriptions and illustrations contained in this manual arenot
binding. The manufacturer reserves the right to introduce any
modification without updating the manual.

SAFETY TIPS
MOVING SHUTTLE WITH SHARP CHIPPING BLADES
TO AVOID SERIOUS PERSONAL INJURY
·NEVER Touch This Machine without Training and Authorization by Your Supervisor.
·ALWAYS Keep Hands Clear of Sharp Chipping Blades and Other Moving Parts.
·ONLY Use a Qualified Electrician to Install According to Local Building Codes: Machine MUST
Be Properly Grounded.
·ONLY Install on Level, Non-Skid Surface in a Clean, Well-Lighted Work Area Away from
Children and Visitors.
·DO NOT Tamper With or Remove Product Chute Cover.
·NEVER Operate With the Product Chute Cover in the Open Position.
·ALWAYS Close Product Chute Cover Completely Before Operating Machine.
·ALWAYS Turn Off, Unplug From Power Source and Perform Lockout/Tagout Procedure to
This Machine BEFORE Cleaning or Servicing.
·NEVER Leave Machine Unattended While Operating.
·PROMPTLY REPLACE Any Worn or Illegible Warning Labels.
·ALWAYS Read Operation and Service Manual BEFORE Operating, Cleaning, or Servicing.
·USE ONLY BIRO Parts and Accessories Properly Installed.
2

INSTALLATION
TO AVOID SERIOUS PERSONAL INJURY, PROPERLY INSTALL
EQUIPMENT IN ADEQUATE WORK AREA
·ALWAYS Use Qualified Technician and Electrician for Installation.
·ALWAYS Connect to Proper Voltage & Phase.
·ALWAYS Install Equipment in Work Area with Adequate Light and Space Away From Children
and Visitors.
·ONLY Operate on a Solid, Level, Non-Skid Surface.
·NEVER Bypass, Alter, or Modify This Equipment in Any Way From Its Original Condition.
·NEVER Operate With Product Chute Cover in Open Position.
·NEVER Operate Without all Warning Labels Attached and Owner/Operator Manual Available to
the Operator.
UNCRATING AND SET UP
1. Read this Manual thoroughly before installation and operation. Do not proceed with installation and operation if
you have any questions or do not understand anything in this Manual. Contact your local Distributor, or BIRO
FIRST.
2. Carefully remove cardboard crate wraparound. Remove meat lug dolly and set aside.
3. Remove 38bolt and nut holding machine to wood crate bottom.
4. Remove Meat Lug (Item No. 51199-MHD) from top of machine.
5. Install casters (3 ea. Item No. 51165 less brake and 1 ea. Item No. 51164 with brake) on the stainless steel Meat
Lug Dolly (Item No. 51582) with supplied fasteners. Set Meat Lug and Dolly aside.
6. With assistance of mechanical devices lift machine and block up. Remove machine legs from side of machine.
Replace legs to same mounting holes in vertical position, tightening the acorn nuts on the carriage bolts.
7. Remove stainless steel Chute Cover (Item No. 51597) from top of machine. Turn over and mount to stand offs at
top of chute opening. Tighten Chute Cover Hinge Pins (Item No. 51563). Do not over tighten. Chute should be
centered and still have free movement to open and close. Magnet should be centered over safety switch.
Tighten jam nuts on hinge pins.
8. Install Chute Cover Support (Item No. 51404) to Chute Cover. Be sure bushing is used to allow free movement
of chute support. Be sure chute support is in lock bracket welded to side of chute.
9. Place machine on a level, solid, non-skid surface in a well-lighted work area away from children and visitors.
10. Install floor stops over the front leg pads (opposite motor end). It is recommended that floor stops be anchored
to the floor with two 38-16 ´112" expansion anchors per floor stop.
3

11. After checking and making sure that the power supply is correct, plug in your machine.
12. Machine must be properly grounded. Use qualified electrician to install according to local building codes.
13. With rear motor cover removed and chute cover in the closed position, push the green “start” button located on
the side of the rear cover. Be sure that the motor and transmission are rotating in the proper direction. Should
be COUNTERCLOCKWISE when viewing the transmission output shaft and machine crank arm, as indicated by
the arrow on crank arm. Should machine be operating backwards, push red “stop” button. Disconnect machine
from incoming power source and interchange two lead wires.
14. When machine is operating in proper direction, replace rear motor cover. Machine is now ready for trained
operators to process product.
MOTOR WIRING AND ELECTRICAL REQUIREMENTS
(1) Interchange of current is made in motor outlet box. Leads are properly marked. Changing instructions are on
the motor plate or motor outlet box.
(2) All chippers are wired 220 volts unless otherwise specified. Be sure motor specifications (voltage, cycle, phase)
match power supply line. Be sure line voltage is up to specification.
(3) Electrical connections to be in accordance with safety codes and National Electrical Code.
(4) Rated voltage of the unit shall be identical with full supply voltage.
(5) Voltage drop on the supply line shall not exceed 10% of full supply voltage.
(6) The feederline conductor size in the raceway from the branch circuit to the unit must be correct to assure
adequate voltage under heavy starting and short overload conditions.
(7) The feederline conductor shall only be used for the supply of one unit of the relevant horsepower. For
connections of more than one unit on the same feederline, a local electrician will have to be consulted to
determine the proper conductor size.
(8) The size of the electrical wiring required from the power source to the frozen block chipper is a MINIMUM OF
No. 10 WIRE if the distance from the machine to electrical box is 25 feet or less. Over 25 feet a MINIMUM OF
No. 8 WIRE is to be used.
(9) The BIRO Manufacturing Company is not responsible for permanent wiring, connection or installation.
4
NOTE TO OWNER AND ELECTRICIAN: IF THIS MACHINE IS NOT CORD
AND PLUG CONNECTED TO THE ELECTRICAL SUPPLY SOURCE, THEN IT
SHOULD BE EQUIPPED WITH, OR CONNECTED TO, A LOCKABLE,
MANUALLY-OPERATED DISCONNECT SWITCH (OSHA 1010.147).
MOTOR SPECIFICATIONS FURNAS HEATER ELEMENTS
VOLTS HERTZ AMPS CODE NO. BIRO ITEM NO.
208 60 16.2 E62 50704
230 60 14.0 E61 52744
460 60 7.0 E51 50703
575 60 6.0 E50 50668
190 50 16.7 E62 50704
220 50 14.4 E60 50667
380 50 8.7 E54 50705
415 50 8.0 E53 50670

5

OPERATION
MOVING SHUTTLE WITH SHARP CHIPPING BLADES
TO AVOID SERIOUS PERSONAL INJURY
·ONLY Properly Trained Personnel Should Use This Equipment.
·ALWAYS Keep Hands Clear of Sharp Chipping Blades and Other Moving Parts.
·NEVER Operate With Product Chute Cover in the Open Position.
·DO NOT Tamper With or Remove Product Chute Cover.
·ALWAYS Close Product Chute Cover Completely Before Operating Machine.
·DO NOT Tamper With, Bypass, Alter, or Modify This Equipment in Any Way From Its Original
Condition.
·ALWAYS Turn Off, Unplug from Power Source and Perform Lockout/Tagout Procedure to This
Machine Before Cleaning or Servicing, or When Not in Use.
·NEVER Leave Unattended While Operating.
·NEVER Operate Without All Warnings Attached.
A. TO PROCESS PRODUCT
1. Place Meat Lug under machine to catch chipped product.
2. Prepare for processing a 60 pound tempered meat block. For optimum chipping the recommended block
temperature is 15 to 25 degrees F. With a maximum block size of 8" ´1612"´1912". This will yield finished
product chips approx. 312"´312"´14". For narrower meat blocks there is available an optional Chute Filler
Plate (Item No. 51526).
3. Lift the Chute Cover slightly to release the Chute Support. Close the chute cover completely. The magnet
attached to the chute must contact the safety switch. The machine will not operate with the Chute Cover in
the open position.
4. Push the green “START” button. When the machine is finished chipping, which should be approx. 60
seconds, push the red “STOP” button. Unplug machine from power source and perform lockout/tagout
procedures.
5. Remove meat lug from under machine. Product is now ready for grinding or mixing/grinding.
6

B. TROUBLE SHOOTING MACHINE OPERATION
1. Machine is not chipping properly. Check the following items:
A. Product block may be frozen too hard (temperature should be 15 to 25 degrees).
B. Product block may be too soft.
C. Either the Guillotine Knife (Item No. 51380) or the Runner Blades (Item No. 51379) may be dull or broken.
D. Chute Spring (Item No. 51416) may be missing, broken, or have lost its temper.
E. Product block may be too narrow, install optional Chute Filler (Item No. 51526).
F. The machine may be running in the wrong direction. Check rotation arrow on the Crank Arm (Item No.
51387) for proper direction. COUNTERCLOCKWISE — looking at transmission output shaft.
G. Slide bearings in shuttle may be worn (Item No’s. 51502 & 51503, two each).
H. Guillotine Knife (Item No. 51380) may have been installed backwards.
I. Guillotine Knife and Runner Blades may have been resharpened beyond their life span.
J. Slide Rods (Item No. 51382) may be dry. Lubricate with good grade food machine oil.
2. Machine is not operating properly. Check the following mechanical items:
A. Crank Arm Pin sheared (Item No. 51054). Replace.
B. Transmission Bronze Drive Gear damaged or stripped (Item No. 51074-7). Replace.
C. Transmission Shaft Key sheared (Item No. 51074-16). Replace.
D. Motor Shaft Key sheared (Item No. 51074-28). Replace.
7

MAINTENANCE
MOVING SHUTTLE WITH SHARP CHIPPING BLADES
TO AVOID SERIOUS PERSONAL INJURY
·ALWAYS Turn Off, Unplug from Power Source and Perform Lockout/Tagout Procedures to
This Machine BEFORE Servicing.
·NEVER Touch This Machine Without Training and Authorization By Your Supervisor
·NEVER Place Hands Into Machine Input or Output Openings.
·NEVER Bypass, Alter, or Modify This Equipment in Any Way From Its Original Condition.
·PROMPTLY REPLACE Any Worn or Illegible Labels.
·USE ONLY GENUINE BIRO Parts and Accessories Properly Installed.
LUBRICATION
1. SLIDE RODS: Lubricate daily or after each cleaning with a good grade food oil.
2. CRANK PIN: Soak Felt Wick (Item No. 51285) once a year with 90 weight oil.
3. TRANSMISSION: Change after first month of operation, then every one year after.
For room temperatures above 20 deg. F. use SAE90 multi-purpose gear oil.
For room temperatures below 20 deg. F. use SAE80 multi-purpose gear oil.
4. MOTOR: Grease Zerk fitting on top and bottom of motor once a year.
5. GEAR BOX: Grease Zerk fitting on top of gearbox once a year.
SHUTTLE ASSEMBLY
1. GUILLOTINE KNIFE: Check for wear and dulling. Resharpen or replace as necessary.
2. RUNNER BLADES: Check for wear and dulling. Resharpen or replace as necessary. Replace any broken
blades.
3. SLIDE BEARINGS: Check for excessive free play. Replace as necessary.
8

CLEANING
MOVING SHUTTLE WITH SHARP CHIPPING BLADES
TO AVOID SERIOUS PERSONAL INJURY
·ALWAYS Turn Off, Unplug From Power Source and Perform Lockout/Tagout Procedures to
This Machine Before Cleaning or Servicing.
·ONLY Use Recommended Cleaning Equipment, Materials and Procedures.
·NEVER Spray Water or Other Liquid Substances Directly at Motor, Power Switch or Any Other
Electrical Components.
·ALWAYS Thoroughly Clean Equipment at Least Daily.
CLEANING THE BIRO FROZEN BLOCK CHIPPER:
1. Turn “OFF”, unplug machine from power source, and perform lockout/tagout procedures.
2. Lift Chute Cover until notch in Chute Cover Support is in line with bracket on the side of the chute.
Disengage Chute Cover Support from bracket by pulling outward. Lift Chute Cover to fully open position and
allow to rest on top of the Drive Cover.
3. Loosen Hand Wheel (Item No. 51048) securing the Upper Frame Assembly (Item No. 51558). Move the
Hand Wheel and Catch Rod down to the unlock position. The Upper Frame Assembly is hinged to facilitate
cleaning. Lift to open Upper Frame Assembly. Assembly must be opened fully and resting against welded
Chute Cover hinge.
DO NOT SPRAY DIRECTLY AT ELECTRICAL COMPONENTS
4. Machine is now ready to be cleaned using warm soapy water and rinsed with clean water. Machine may be
cleaned by power spray washing, taking care not to spray directly at any electrical controls.
5. The shuttle may be removed for cleaning. This is accomplished by removing the hex head screws holding
the shuttle to the bearing bars.
6. After machine has been cleaned and allowed to air dry, the Slide Rods (Item No. 51382) should be coated
with a good food grade light oil or grease.
9

10
RECOMMENDED
FLOOR ANCHOR
SUPPLIED
38-16 ´1½²
EXPANSION
ANCHORS FOR
EACH (2)
FLOOR CHOCK,
FIGURE No. 17

PARTS LIST
For: SANITARY TIN MACHINES starting with Serial No. 3100 to Serial No. 5297
&
For: STAINLESS STEEL MACHINES starting with Serial No. 10200
IMPORTANT: ALWAYS ADVISE SERIAL NUMBER WHEN ORDERING PARTS
FIG. NO. ITEM NO. DESCRIPTION
14 HHS129S Hex Head Screw, 12-13 ´2, SS, Attach
Upper to Lower Frame
14A 0909 Acorn Nut, 12-13; Attach Upper Frame to Lower Frame
15 50721 Lower Frame Assembly, Stainless Steel (NSS)
16 54279 Front Leg, Stainless Steel
16A 51338 Leg Carriage Bolt, 12-13 ´1, SS
16B FW11S Flat Washer, 12", SS
16C LW30S Lock Washer, 12", SS
16D 0909 Acorn Nut, 12-13, SS
17 50604 Floor Stop
18 51194 Front Leg Pad
19 51193 Rear Leg Pad
20 54285 Right Rear Leg, Stainless Steel
22 51387 Crank
22A 1161 Allen Screw, 12-13 ´2"
22B 53783 Rotation Decal
23 51074G Transmission (see page 16-20) Grove gear reducer
23 51074 Transmission, (See Page 21) Morse reducer
23A 72251 Transmission Oil, 2 qts. (90 weight) for Morse reducer
23B HHS128S Hex Head Screw, 12-13 ´134,SS
23C LW30S Lock Washer, 12", SS
24 51054 Crank Pin
24A 16501WB Thrust Washer, Brass
25 51384 Pitman Arm Assembly with Bushings,
Wick & Pipe Plug, SS
25A 51051 Pitman Arm Bushings, Bronze
25B 0143 Pipe Plug, 12"
25C 51285 Felt Wick
26 50688 Magnetic Starter, 208/230/380/415/460-50/60-3
26 50735 Magnetic Starter, 575-60-3
26A See Page 4 for Item No. Overload Heater Coils
27 51075 Motor, 5HP, 208/230/380/415/460-50/60-3
27 51192 Motor, 5HP, 575-60-3
27A 51074-28 Motor Shaft Key, 316 ´138
28 51991 Fuse Holder
28A 53851 Fuse, 1 Amp, FNM-1
29 50639 Magnet for Safety Switch
29A FNS24S Flat Head Screw, 10-32 ´58
29B 1116 Acorn Nut, 10-32
30 42MC-Y64 Magnetic Safety Switch, to 240V
31 51404 Chute Cover Support
31A 51581 Chute Cover Support Bushing
31B 19CB Carriage Bolt, 14-20 ´34,SS
31C FW05S Flat Washer, 14", SS
31D AN15S Acorn Nut, 14-20, SS
32 51558 Upper Frame Assembly, Stainless Steel
33 13459 Junction Box
33A 13460 Junction Box Cover
34 51563 Chute cover hinge pin SS
34 HN30S Hex nut 38-16 SS
35 51074G-1 Sub-plate (grove gear reducer)
36 51597 Chute cover
37 51784 Rubber bumper
46A 50690 Push Button Junction Box
11

12

PARTS LIST
IMPORTANT: ALWAYS ADVISE SERIAL NUMBER WHEN ORDERING
FIG. NO. ITEM NO. DESCRIPTION
1 51382 Slide Rod
2 51547 Front Bearing Bar Assembly w/Bearings
2A 51503 Front Slide Bearings
2B HHS135S Hex Bolt, 12-13" ´212", SS
2C LW30S Lock Washer, 12",SS
3 51340 Runner Blade Retainer
3A FHS36S Flat Head Screw, 14-20 ´1, SS
3B 51454 Runner Blade Adjusting Set Screw
3C SSS13 Runner Blade Adjusting Set Screw ¼-20 ´38
3D SSS10 Locking Set Screw, 14-20 ´¼
4 51378 Runner Support
4A HHS080S Hex Head Screw, 38-16 ´112,SS
4B LW25S Lock Washer, 38,SS
5 51379 Runner Blade, Tapered Ends
6 51380 Guillotine Knife
7 51377 Knife Clamp, Rear
8 51550 Bare Slide, Stainless Steel
8A 51549 Slide Assembly Complete
9 RHS23S Round Head Screw, 14-20 ´38, SS, Brg. Retainer
10 51540 Rear Bearing Bar w/Slide Bushings
10A 51502 Rear Slide Bearing
10B HHS135S Hex Bolt, 12-13 ´212,SS
10C LW30S Lock Washer, 12", SS
11 51557 Pitman Arm Pin
12 51383 Slide Rod Bushing, SS
13 51093 Slide Rod Washer
13A HHS125S Hex Head Screw, 12-13 ´1, SS
13B LW30S Lock Washer, 12", SS
21 54284 Left Rear Leg, Stainless Steel
34 51165 Caster Less Brake
35 51164 Caster With Brake
35A 51269 Caster Assembly, (4 caster w/fasteners)
36 51582 Lug Dolly Assembly w/Casters, Stainless Steel
36A 51335 Lug Dolly Less Casters, Stainless Steel
37 51199-MHD Meat Lug
38 72334 Groove Pin for Catch Rod
38A 51348 Catch Rod, Stainless Steel
39 51048 Hand Wheel
40 51416 Chute Spring
40A CB74S Chute Spring Carriage Bolt, 516-18 ´34,SS
40B HNNL20S Chute Spring Nylok Nut, 516-18, SS
41 51784 Rubber Bumper for Chute Cover
42 51597 Chute Cover Assembly, Stainless Steel
43 51575 Drive Cover Door
44 51563 Chute Cover Hinge Pins, SS
44A HN30S Hex Nut, 38-16 light jam, SS
45 50757 Drive Cover, Stainless Steel
45A HHS025S Hex Head Screw ¼-20 ´½SS
45B LW10S Lock Washer ¼ SS
45C FW06S Flat Washer ¼ SS
46 50761 Push Button Plate w/Hood
46B 50681 Gasket
46E 42MC-Y73 Green Start Button
46F 42MC-Y74 Red Stop Button
47 50766 Switch Hole Filler Plate
48 51338 Leg carriage bolt ½-13 ´1SS
48 FW11S Flat washer ½ SS
48 LW30S Lock washer ½ SS
48 0909 Acorn nut ½-13 SS
49 54279 Front leg SS
NOT SHOWN 50777 Operating Manual & Parts List
13

RUNNER BLADE AND GUILLOTINE BLADE
REPLACEMENT PROCEDURE
1. Remove the slide assembly hex head mounting bolts (3 ea.)
2. Remove Item No. 51549 slide assembly from the machine.
3. Place on workbench.
4. Remove the runner support hex head bolts (4 ea.)
5. Remove Item No. 51378 runner support and Item No. 51377 knife clamp.
6. Clean the runner blade mounting grooves in the knife clamp.
7. Remove Item No. SSS10 locking set screws (4 ea.) and back out Item No. 51454 and No. SSS13S runner
blade adjusting screws (5 ea.)
8. Do not remove Item No. 51340 runner blade retainer.
9. Remove Item No. 51379 runner blades (5 ea.) and Item No. 51380 guillotine knife.
10. Clean the grooves.
11. Slide new Item No. 51379 runner blades into the slide frame under the Item No. 51340 runner blade retainer.
12. Lay new Item No. 51380 guillotine knife on the slide frame.
13. Push Item No. 51379 runner blades into the knife clamp.
14. Assemble Item No. 51377 knife clamp and Item No. 51378 runner support and bolt to the slide frame using
the 4 ea. 38-16 ´1½'' hex bolts and lock washers.
15. Be sure Item No. 51379 runner blades are sitting square and flush against Item No. 51380 guillotine knife
and Item No. 51377 knife clamp.
16. Tighten the mounting bolts.
17. Re-tighten the 5 ea. Item No. 51454 and No. SSS13S runner blade adjusting set screws until they are snug.
Do not over-tighten. Insert and tighten the 4 ea. ¼-20 ´¼ locking set screws in all adjusting set screw holes
except the middle one.
18. This assembly will prevent putting the runner blades in a bind.
19. Remount the slide assembly into the machine.
SHUTTLE ASSEMBLY
1. GUILLOTINE KNIFE: Check for wear and dulling. Resharpen or replace as necessary.
2. RUNNER BLADES: Check for wear and dulling. Resharpen or replace as necessary. Replace any broken
blades.
3. SLIDE BEARINGS: Check for excessive free play. Replace as necessary.
LUBRICATION
1. SLIDE RODS: Lubricate daily or after each cleaning with a good grade food oil.
2. CRANK PIN: Soak Felt Wick (Item No. 51285) once a year with 90 weight oil.
3. MOTOR: Grease Zerk fitting on top and bottom of motor once a year.
4. GEAR BOX: Grease Zerk fitting on top of gearbox once a year.
14

No. 51549 Slide Assembly Complete
With Blades and Without Bearing Bars
15

INSTALLATION INSTRUCTIONS
ALTERNATE
GROVE GEAR REDUCER
REPLACING
MORSE GEAR REDUCER
·ALWAYS Turn Off, Unplug From Power Source and Perform Lockout/Tagout Procedures to
the Machine Before Any Service is Performed.
REMOVAL
A. Remove Item No. 51575 Drive Cover Door.
B. Remove four bolts holding the Item No. 50690 Pushbutton box to the Item No. 50757 Drive Cover and let
box hang free.
C. Remove the Item No. 50757 Drive Cover.
D. Open the motor junction box and disconnect the electrical leads. Remove the switch wires and conduit from
the motor.
E. Remove the motor from the OEM gear reducer (Morse), taking care to locate the motor key.
F. Remove the Item No. 51054 Crank Pin and Item No. 16501WB Thrust Washer from the Item No. 51384
Pitman Arm and rest at the bottom of the base access slot.
G. Loosen the Item No. 1161 Allen Screw in the Item No. 51387 Crank. Remove the Crank from the gear
reducer output shaft. This may require a puller. Keep track of the Crank Key.
H. Remove the four bolts holding the Gear Reducer to the machine frame and remove the Gear Reducer.
16
