BIS TRADITION CE 506128-19 User manual

EPA Wood-Burning Fireplace
P/N 506128-19 REV. J 05/2013
BISTRADCE
MODEL
BIS®TRADITION CE
INSTALLATION AND
OPERATION INSTRUCTIONS
SAVE THESE INSTRUCTIONS
FOR FUTURE REFERENCE
Listed to standards:
ULC-S610 and UL-127
Report No. 307-4084
EPA Cert. No. 537
WARNING
• Hot! Do not touch! The glass and
surfaces of this appliance will be hot
during operation and will retain heat
for a while after shutting off the appli-
ance. Severe burns may result.
• Carefully supervise children in the
same room as appliance.
• If small children are present in the home, it is
recommended that this appliance be fitted with
an adjustable safety gate or barrier screen.
WARNING
• The fireplace cannot be operated without a door
or firescreen. Consult your dealer to select the
correct replacement door or firescreen.
• The replace is equipped with a blower, electri-
cal connection must be made prior to fireplace
installation
• Important! To assure proper alignment of glass
doors: Install this fireplace in a square and
plumb condition, using shims as necessary at
sides and/or bottom.
• Install the fireplace only as described in these
instructions.
PIBISTRADCE REV. 9 05/2013
This installation manual will enable you to obtain a safe, efcient
and dependable installation of your fireplace system. Please read
and understand these instructions before beginning your installation.
Do not alter or modify the fireplace or its components under any cir-
cumstances. Any modication or alteration of the replace system,
including but not limited to the replace, chimney components and
accessories, may void the warranty, listings and approvals of this system
and could result in an unsafe and potentially dangerous installation.
IHP wood-burning fireplaces are designed for use as a supplemental
heater. They are not intended for continuous use as a primary heat
source.
Fireplace, also for use in mobile or
manufactured homes with solid fuel only.
5/10/2013
An French manual is available upon request. Order P/N 506128-20.
Ce manuel est disponible en francais, simplement en faire la demande. Numéro
de la pièce 506128-20.

IMPORTANT! GENERAL SAFETY
PRECAUTIONS. READ AND
UNDERSTAND THESE SAFETY
RULES BEFORE YOUR FIRST FIRE.
WARNING
To avoid the risk of damaging
fireplace materials and increas-
ing the risk of re, do not use the
fireplace to cook or warm food.
IMPORTANT
When burning wood, use SOLID
NATURAL DRY WELL-SEASONED
WOOD ONLY. Hardwoods are rec-
ommended(soft woodstendto burn
very quickly).
• DO NOT burn treated wood,
charcoal, coal, trash, cardboard,
driftwood, woods dipped in tar,
Christmas tree greens, pitch, pine
tar, creosote, chemical chimney
cleaners, ame colorants, poly-
styrene packaging, wood prod-
ucts with synthetic binders (i.e.
plywood). Plywood, lumber and
other misc. materials canproduce
abnormally high temperatures,
sputtering and smoking fires and
may contain hazardous chemicals
to treat insects and fungus.
• Burning unapproved fuels can
produce excessive temperatures,
beyond the design capabilities
of the fireplace and may produce
excess sparks or may contain
hazardous chemicals. Burning
unapproved fuels can result in
a chimney fire, a house fire,
personal injury, death or loss of
property.
WARNING
Never leave children unattended
when there is a fire burning in the
fireplace.
WARNING
NEVER use gasoline, gasoline-
type lantern fuel, kerosene,
charcoal lighter uid, naphtha,
engine oil or similar liquids to
start or “freshen up” a fire in this
replace. Keep any ammable
liquids a safe distance from the
fireplace at all times.
WARNING
Use care when selecting window
treatments for windows located
near the fireplace. Avoid using
combustible flowing window
treatments such as curtains on
nearby windows that are of suf-
ficient length to be blown in front
of an open ame when the window
is opened. Keep any combustible
furniture, materials or decorative
pillows at least 48" (1219 mm)
from the front fireplace opening.
WARNING
Never modify or alter your fireplace
system in any way. To do so may
create a potential fire hazard and
void the limited warranty, listings
and approvals of this system.
WARNING
Never leave your fireplace unat-
tended while it is burning.
WARNING
Always ensure that the air inlet to
the fireplace is free from debris
and any other obstructions that
can block the entrance of air.
WARNING
Neither the manufacturer nor the
seller warrants “smoke free”
operation nor are we respon-
sible for inadequate system draft
caused by mechanical systems,
general construction conditions,
inadequate chimney heights,
adverse wind conditions and/or
unusual environmental factors or
conditions beyond our control.
IMPORTANT
WHEN INSTALLED IN A MOBILE OR
MANUFACTURED HOME:
• Mobile or manufactured home
installations must be installed in
accordance with the requirements
of the Department of Housing and
UrbanDevelopment (HUD)“Mobile
HomeConstructionandSafetystan-
dards” for US or Canada Mortgage
and Housing Corporation (CMHC)
for Canada.
• The replace must be fastened to
the oor by unfolding and screwing
the small tabs on both sides at the
bottom of the fireplace.
• It is necessary to have access
openings, for inspection purpose
only, into built-in enclosures sur-
rounding the fireplace installation.
Such openings to require a house-
hold tool for access.
• The vapor barrier of the mobile
home shall be as close as possible
of the location where the chimney
assembly penetrates the ceiling
and roof structure with no interfer-
ence to the required clearance to
combustible material.
• When the mobile or manufactured
home has a at roof, the Attic Radia-
tion Shield must be installed from
below going through the roof (See
Figures 22b and 22d).
• Warning: Do not install in a
sleeping room.
• Caution: The structural integrity
of the manufactured home oor,
wall, and ceiling/roof must be
maintained.
WARNING
The BIS®Tradition CE fireplace
must be installed with anoutside
air kit intake, which is included
with the fireplace
2
WARNING
THE FIREPLACE MUST BE OPER-
ATED WITH THE DOORS FULLY
OPENEDORDOORSFULLYCLOSED.
IF THE DOORS ARE LEFT PARTLY
OPENED, GAS AND FLAME MAY BE
DRAWN OUT OF THE FIREPLACE
OPENING, CREATING RISKS OF
BOTH FIRE AND SMOKE. IF THE
UNIT IS OPERATED WITH THE
DOORS FULLY OPENED, THE FIRE
SCREEN MUST BE USED.
WARNING
THIS FIREPLACE HAS NOT BEEN
TESTED WITH AN UNVENTED
GAS OR A FIREPLACE INSERT.
TO REDUCE RIS K OF FIRE OR
INJURY, DO NOT INSTALL AN
UNVENTED GAS LOG SET OR
FIREPLACE INSERT OR OTHER
PRODUCTS NOT SPECIFIED FOR
USE WITH THIS FIREPLACE.

TABLE OF CONTENTS
Safety Rules and Specifications for
Mobile or Manufactured
Home Installation.........................Page 2
Introduction ......................................Page 3
Parts Required .................................Page 3
Optional Equipment...........................Page 3
Operating The BIS®Tradition CE
Fireplace..........................................Page 3
Fuel ...................................................Page 3
Starting And Maintaining A Fire ........Page 4
Combustion Control .........................Page 4
Refueling For Best Performance .......Page 4
Smoking – Causes And
Troubleshooting ..............................Page 4
Important Cautions ...........................Page 5
Maintaining Your Fireplace................Page 5
Creosote............................................Page 5
Chimney Maintenance.......................Page 5
Dealing With A Chimney Fire.............Page 5
Finish Door Casing Care....................Page 5
Disposing of Ashes ...........................Page 6
Refractory Installation.......................Page 6
Door Installation ...............................Page 6
Door Adjustment...............................Page 6
Facade Installation ............................Page 7
Hearth Extension Requirements........Page 7
Cold Climate Installations..................Page 7
Framing Dimensions.........................Page 8
Nailing Flanges..................................Page 9
Facing And Mantel ............................Page 9
Fireplace Blower................................Page 10
Hot Air Ducting Installation ..............Page 10
Gravity Kit .........................................Page 10
Outside Air Kit ..................................Page 11
Chimney System...............................Page 12
Chimney Installation Notes ...............Page 12
Chimney Installation Instructions......Page 13
Offset Chimney Installation ...............Page 14
Angled Wall Radiation Shield ............Page 16
Glass Care - Replacement.................Page 17
Glass Care - Cleaning........................Page 17
Gasket Replacement ........................Page 17
Fireplace Installation ........................Page 17
Chimney Support Installation............Page 18
Chimney Chase And
Multiple Terminations......................Page 18
Masonry Application Instructions .....Page 19
Installation Accessories ....................Page 20
Replacement Parts............................Page 21
Specifications....................................Page 21
Clearances to Combustibles..............Page 21
Chimney Components Lists ..............Page 22
Product Reference Information.........Page 24
THE FIREPLACE
INTRODUCTION
The BIS®Tradition CE wood-burning fireplace
is an energy efficient, heat circulating, closed
combustion fireplace. You will receive a lifetime
of comfort and enjoyment from your fireplace
provided it is installed, maintained and oper-
ated properly.
• Please read these instructions and retain
this manual for future reference.
• Before beginning the fireplace installation,
consult the local authorities to obtain your
building permit and check your localbuilding
codes. Install the fireplace only as described
in these instructions and using only IHP
components.
• ThisreplacehasbeentestedforCAN/ULC
S610-M87andANSI/UL127underreport
number 307-4084. It has also been tested
for EPA 40 C.F.R Part 60, section 60.532(b).
Certificate number 537.
• TheBIS Tradition CE fireplace is NOTintended
for use with a gas log set. Do not use a
fireplace insert or any other product with
this fireplace unless it is specified by Lennox
for use with this appliance. Failure to follow
these instructions will void the certification
and the warranty of the fireplace and may
result in an unsafe installation.
• Theseappliancesaredesignedtoprovide
supplemental heat to the immediate area
only. Therefore, it is advisable to have an
alternate heat source when installed in a
dwelling.
PARTS REQUIRED
Fireplace Model BIS Tradition CE
• 6” diameter chimney *- Model ASHT+,
S-2100+, HT6000+, HT6103+ or AC
manufactured by Security Chimneys Inter-
national™ only, including:
- Chimney lengths
- Elbows (where necessary)
- Associated components as per these
installation instructions
•..Decorative Door - Required
....(Order Separately - See Page 20)
•Front Facade kit - Required
...(Order Separately - See Page 20)
•UZY5 blower (included in the fireplace).
•VRUW Blower Speed Control (included)
•Outside air kit (Includedw/Fireplace)
OPTIONAL EQUIPMENT
• Additional Equipment (optional)
- Forced Air Kit u
- AC Chimney Adaptor *
(required if using AC Chimney)
CONGRATULATIONS!
When you purchased your new fireplace, you joined the ranks of thousands of individuals
whose answer to their home heating needs reflects their concern for aesthetics, efficiency
and our environment. We extend our continued support to help you achieve the maximum
benefit and enjoyment available from your new fireplace.
Thank you for selecting a IHP fireplace as the answer to your home supplemental heat-
ing needs.
- AC Chimney Outside Air Kit
- Gravity Venting System
- Rigid Firescreen
uNot tested under EPA certification. If in-
stalled, this appliance no longer qualifies
for EPA certification.
OPERATING THE FIREPLACE
Fuel
USE SOLID NATURAL WOOD FUEL ONLY.
The BIS Tradition CE fireplace is designed
to work best when fueled with dry seasoned
natural wood only. Hardwoods are preferred to
softwoods since the energy content of wood is
relative to its density. Hardwoods will result in
a longer burning fire and less frequent refueling.
A moisture content of 15% to 20% (seasoned)
is recommended. Wood that has been cut and
split and let to dry under a cover for a period
of one year will usually meet that criteria. The
required drying time will vary depending on the
climate. Wood that is packed tight together will
take longer to dry. Seasoned wood is darker in
color than wet wood and will have visible cracks
in the grain on the ends. Excessively wet wood
will be difficult to burn and will result in lower
efficiency, increased creosoting and deposits on
the glass and in the chimney. Excessively dry
wood will burn well but will also have higher
emissions and shorter burning time.
Do not burn scrap or garbage, treated wood or
wood such as driftwood from the ocean which
has been exposed to salt or other chemicals.
Salt or chemicals can corrode the firebox and
chimney. Do not burn large amounts of paper,
cardboard, Christmas tree branches or building
construction materials. Intense firing with these
materials may overheat the fireplace, causing
damage to the unit, a fire or even possibly ignit-
ing a chimney fire if the chimney is creosoted.
Burning unapproved fuel, resulting in excessive
pollutants being emitted, may be prohibited and
subject to a fine or other penalty by the authority
having jurisdiction in your area.
Processedrelogscanbeused.Useonlyrelogs
that have been evaluated for the application
of fireplace and refer to firelog warnings and
caution markings on packaging prior to use.
First Fires
Before using thefireplacemakesureto remove
the plastic wrapping and EPA label on plated
door. Remove any glue residue left by the
label using mild soap.
The first five or six fires should be small fires of
short duration (about 30 to 60 minutes). This
will help cure the refractory bricks. During the
first few fires of this appliance there may be
some odor and smoke due to the curing of the
paint, dust accumulation and burning off of
lubricants used in the manufacturing process.
It may set off a smoke alarm located in the same
room. For this reason the room should be well
ventilated for the first few fires.
*Available from Security Chimneys™
3

Building a Fire
(starting and maintaining a fire)
To start a fire, place several crumpled up balls of
newspaper in the firebox. Place small dry pieces
of kindling ontopofthepaper, criss-crossing the
kindling so that there are air spaces in between.
Keep the fuel far back enough so that air can
get underneath. Open the air controls fully
and light the newspaper. Once the newspaper
and the kindling is well ignited, close the door.
Once the kindling fire is well established, cord
wood can be added (see Primary Air Combus-
tion Control section for proper operation of the
air controls).
The unit will burn best with 2-3 pieces of cord
wood spaced 1 to 2 inches apart and allowing air
to get under the fuel. Criss-crossing or arrang-
ing the fuel so that air can get underneath, will
help the fire to get started easily. The unit should
be operated with the air control fully open long
enough to get the cord wood well ignited.
COMBUSTION CONTROLS
Primary Air and Air Boost Controls
There is no flue damper in the BIS®Tradition
CE wood burning fireplace. As is common with
air tight stoves, the combustion air control sets
the flow of air entering the firebox. This allows
for a more precise control of the fire. The com-
bustion air control is located below the door on
For instance, a long chimney will necessitate
closing the damper more. To obtain the proper
combustion, close the damper completely, then
openitabout1/4”to1/2”.Threemediumsize
pieces of wood should be burning on a bed of
hot coals. The heat output will be approximately
30,000BTUperhourandtheloadingtimewill
be about every 3-4 hours. Softwoods may be
burned using this method but the time will be
substantially reduced.
Slow Combustion
When the air combustion control is completely
closed, thefireplace isin aslow combustion phase.
If the hearth is hot enough, slow combustion will
not extinguish the fire, but there will be a notice-
able change in the flame pattern. The flames will
be slow and may appear dirty if the wood is too
wet (moisture content of 20% and more). Do not
allow the wood to burn without flame, since this
will produce excessive creosote in the unit.
Creosote may accumulate on the glass door.
This method of burning should be used only
after operating the BIS Tradition CE fireplace
with the air control opened to produce a hot
fire for about an hour or at medium pace for at
least three (3) hours. Slow combustion can be
used at night in order to reduce the heat output
and to prolong the burn. The loading time will
be between 6-8 hours.
REFUELING FOR BEST PERFORMANCE
The BIS Tradition CE fireplace will operate best
if attention is given to operating the unit with
the damper fully opened after refueling in order
to bring the firebox and the chimney system
up to their optimum operating temperature.
Combustion efficiency is relative to firebox
temperature. A temperature of 500º C (932º F)
and up, with a visible flame, in the upper part
of the firebox indicates a maximum efficiency.
To obtain this temperature, the fireplace must
be operated with the primary air and air boost
controls fully opened during 10 to 20 minutes
after reloading, depending on the heat and on
the moisture content of the wood.
Once you have reachedthe desiredtemperature,
the air boost can be closed and the primary air
set to a medium setting. You know you have
reached the desired temperature when, closing
the primary air control, you can see a flame
at the top of the firebox. The benefit of this
technique will be cleaner glass, less creosoting,
greater efficiency and the most pleasing fire for
your enjoyment.
SMOKING –
CAUSES AND TROUBLESHOOTING
To reduce the likelihood of smoking when open-
ing the door, set the combustion air controls to
the left before opening the door. Your fireplace
has been designed and tested to provide smoke
free operation. Occasionally, there may be a
small amount of smoking upon lighting the fire,
until the chimney heats up but this should not
continue. If the fireplace continues to smoke it
is probably for one of the following reasons:
Combustion Air Register
Push to Close
Air Boost
Pull to Open
Air Boost
Open
Close
Figure 1
the left side. The main source of air (primary
air) entering the firebox can be diminished by
moving the air combustion control from left
to right. The primary air is fully opened when
the air control is completely moved to the left.
The air control device can also be used to add
an extra boost of air especially during fire start
up and reloading of the unit.
Pulling the air combustion control will inducean
air boost at the base of the fire allowing an easier
fire start up. When the fire is well established,
the control can be pushed in to shut down the
air boost allowing for a longer burn time. The
combustion air control should be in the closed
position (primary air and air boost) when the
replaceisnotinuse.Thiswillminimizeair
leakage up the chimney. The combustion air
control should be opened before opening the
doortominimizethepossibilityofbackdraft
coming into the room.
Accelerated Combustion
The maximum heat output for the BIS Tradition
CE fireplace is achieved by burning with the
door closed and the combustion air opened and
pulled out. By this method, the BIS Tradition
CEreplacecanproduceupto55,000BTUof
heat per hour. However, it will be necessary to
reload with wood every one or two hours. This
is the least efficient method of burning the BIS
Tradition CE fireplace.
Usecautionwhenringwiththecombustion
air control wide open. Only burn cord wood in
this manner. Small dry pieces of softwood and
construction scraps will burn very intensely us-
ing this method and may damage the firebox.
Medium Combustion
This is the recommended mode of operating
the BIS Tradition CE fireplace and should be
the one normally used since it will deposit
the least amount of creosote on the glass and
in the chimney. The combustion air control
mustbe3/4closedandpushedintoclosethe
air boost. The precise setting will depend on
many factors, including chimney length and the
moisture content of the wood.
WARNING
Be careful adding wood fuel to the
fireorhandling fireplacetoolssuch
as shovels, tongs or pokers.
WARNING
The bottom refractory can be
cracked by excessiveabuse such
as tossing heavy logs onto the
grate or gouging with fireplace
tools. Exercise caution when
adding wood to your fireplace.
4
NOTE:DIAGRAMS&ILLUSTRATIONSARENOTTOSCALE.

A. Negative pressure in the house - As the fire
burns, air goes up the chimney. This air
must be replaced through leakage into the
house or through theoutside air duct. When
operating the BIS®Tradition CE fireplace,
open a nearby window temporarily to check
if there is adequate replacement air supply.
B. Fans operating (e.g.: range hood) - These
fans draw air out of the house and may
actually cause a negative pressure in the
house. Turn off all fans and open a nearby
window to determine if this is the cause of
the problem.
C. Wetwood-Wet or tarred wood willsmoulder
andsmokeinsteadofburningproperly.
Your
dealer can help you determine if you have
properly seasoned wood for burning.
D. Dirty or blocked chimney - Check to make
sure the chimney is clear and clean.
If dirty
call a certified chimney sweep or use a
properlysizedchimneybrushtoclean.
E. Chimney not long enough - The minimum
chimney height is twelve (12) feet (3.7 m)
not including the fireplace height. The
chimney must extend at least three (3) feet
(915 mm) above its point of contact with
the roof and at least two (2) feet (610 mm)
higher than any roof or wall within ten (10)
feet (3 m) of it. When installed with offsets,
the minimum chimney height is fifteen (15)
feet (4.6 m). Additional height will increase
draft and will decrease the tendency to
smoke.
F. Poor chimney draft - With no fire, there
should be sufficient draft to exhaust cigarette
smoke introducedunder thebaffle. Chimneys
installed against an outside wall without
protection may generate back draft problems
which will cause start-up problems. To
prevent this, open a nearby window, roll up
a piece of paper and light it. Then, hold it in
the upper part of the firebox to warm up the
chimney. Wait until the draft is sufficient,
then start the fire.
IMPORTANT CAUTIONS
A. Do not block the hot air vents to the fire-
place as this will cause the fireplace to
overheat.
B. Never use gasoline, gasoline-type lantern
fuel, kerosene, charcoal lighter uid, or
similar liquids to start or ‘freshen up’ a fire
in this fireplace. Keep all such liquids well
away from the fireplace while it is in use.
C. Do not burn coal. The sulphur in coal will
corrode the firebox and chimney.
D. Keep combustible materials at least 48”
(1.2 m) away from the front of the fireplace
opening.
E. Never leave children unattended when
there is a fire burning in the fireplace.
F. Do not use the fireplace as an incinerator
to burn paper, cardboard or construction
material such as pressed wood, plywood
or lumber. Use only untreated wood.
Wood protectors, metallic paper, coal,
plastic, waste, beach wood, Christmas
tree, sulphur and/or oil will damage the
fireplace.
G. Do not burn driftwood which has beeninthe
ocean or salt water. The salt will corrode
the firebox and chimney.
H. Do not burn wood in the area in front of the
grate.
I. Do not allow the wood to smoulder or burn
without ame, since this will produce
excessive creosote in the unit as well as
increased particulate emissions.
J. Blower for forced air kit operating - Make
surethattheblowerisatthe“off”positionwhen
you open the fireplace door for reloading.
MAINTAINING YOUR FIREPLACE
Creosote - Formation and Need for Removal
When wood is burned slowly, it produces tar
and other organic vapors, which combine
with expelled moisture to form creosote. The
creosote vapors condense in the relatively
cool chimney flue of a slow-burning fire. As
a result, creosote residue accumulates on the
flue lining. When ignited this creosote makes
an extremely hot fire.
The chimney shall be inspected at least twice
a year during the heating season to determine
when a creosote buildup has occurred.
When creosote has accumulated it shall be
removed to reduce the risk of a chimney fire.
When the creosote accumulation is large, a
creosote fire in the chimney can damage the
chimney and overheat the surrounding wood
framing. Creosote formation in a chimney can
beminimizedbymakingsurethereisalways
visible flame burning, avoid smouldering fires
and by proper refuelling techniques.
Chimney Maintenance
Regular chimney inspection and maintenance
combined with proper operation will prevent
chimney fires. Keep your chimney clean. Do not
allowmorethan1/16”(1.6mm)creosotebuild
up in your chimney. The amount of creosote will
depend on variables such as frequency of use
and type of fire. We recommend that you:
A. Initially inspect the chimney system weekly.
From this, you will learn how often it will be
necessary to clean your chimney.
B. Have your chimney cleaned by a qualified
chimney sweep. If you wish to clean it
yourself, we recommend using a stiff plastic
or non-metallic brush. If a metal brush is
used,itssizeshouldbeslightlysmallerthan
the flue to avoid damaging the chimney. Do
not use a brush that will scratch the stainless
steel interior of the chimney.
C. Do not expect chemical cleaners to keep
your chimney clean. The rain cap can be
removedforinspectionand/orcleaningof
the chimney.
Caution: It is necessary to remove the bafe
from the top of the firebox before cleaning the
chimney. See “Top Bafe Removal Prior To
Chimney Sweep.”
Finish Door Casing Care
Useaglasscleanerandasoftclothtopolish
the casing. Do not use abrasives such as steel
wool, steel pads or an abrasive polish for they
may scratch the casing’s finish.
Figure 2B - Top Baffle Removal
Figure 2A - Top Baffle Removal
Dealing With a Chimney Fire
Regular chimney maintenance and inspection
can prevent chimney fires. If you have a chimney
fire, follow these steps:
1. Close the fireplace door and the combustion
air controls.
2. Alert your family of the possible danger.
3. If you require assistance, alert your fire
department.
4. If possible, use a dry chemical fire extin-
guisher, baking soda or sand to control the
fire. Do not use water as it may cause a
dangerous steam explosion.
5. Check outside to ensure that sparks and hot
embers coming out of the chimney are not
igniting the roof.
6. Do not use the fireplace again until your
chimney and fireplace have been inspected
by a qualified chimney sweep or a Fire
Department Inspector.
Top Bafe Removal Prior to Cleaning The
Chimney
Before starting to clean your chimney, we
recommend that you remove the top baffle to
avoid creosote dust collection at the top of the
baffle. Follow these steps to set the top baffle
out of the way:
1. Remove the side refractory holder. They are
located at the top of the refractory.
2. Lift the front baffle.
3. Slide the back baffle under the front baffle.
You now have access to the chimney.
NOTE:DIAGRAMS&ILLUSTRATIONSARENOTTOSCALE.
5

REFRACTORY REPLACEMENT
The intense heat of the fire will normally cause
hairline cracks in the refractory. These cracks
canbeminimizedbypropercuringasdescribed
in“FirstFires”.Theywillnotnormallydimin-
ish the effectiveness of the refractory. If large
cracks develop, then the refractory should be
replaced. To replace the refractory bricks, fol-
low these steps:
1. Remove the front refractories
2. Remove the bottom refractory
3. Remove the left side refractory
4. Remove the right side refractory
5. Remove the back refractory
6. Remove the front ceramic baffle
7. Remove the rear ceramic baffle
To install the new refractories, follow the above
steps in reverse.
Figure 3
Figure 4
DOOR INSTALLATION
The door must be installed only when the installation of the BIS®Tradition CE fireplace is completed.
All you have to do is fit the male part of the hinge, already on the door, to the female part, which
is on the fireplace. To remove the door, simply pull the door up from the hinges (see Figure 4).
The door adjustment has been set at the factory. If the fit is still not perfect, you can adjust the
door using the hinge screws.
DOOR ADJUSTMENT
The door may need to be adjusted to be completely airtight. The gaskets’ air-tightness can be
adjusted using the adjustment screw located on the right side of the fireplace facade (An Allen key
#1/8–notsupplied-willbenecessaryforthisadjustment).
Checking Door Seal
A one-inch strip of paper may be used to perform a test of the integrity of the door seal. Close
the door on the paper in at least eight points. It is normal to feel only a slight amount of friction.
Thedoorgasketdoesnotneedtobe“tight”inallareas,sinceasmallamountofleakageisnot
hazardousordetrimentaltotheperformanceofyourreplace.
Figure 5
Door Installation
WARNING
• Use only a IHP glass doors, specically designed for the BIS Tradition
CE fireplace.
• The fireplace cannot be operated without door or firescreen. Consult
your dealer to select the correct replacement door or firescreen.
• Important! To assure proper alignment of glass doors: Install this
replace in a square and plumb condition, using shims as necessary
at sides and/or bottom.
1
2
3
7
6
5
4
Hinges Adjustment
Gasket Adjustment Screw
DISPOSING OF ASHES
Remove ashes only when the fire is out and
the ashes are cold (24 to 48 hours after the
fire is out).
Do not leave the ashes in the house as they give
off carbon monoxide and other toxic gases.
WARNING
Disposal of Ashes: Ashes should
be placed in a steel container
with a tight fitting lid and moved
outdoors immediately. The
closed container of ashes should
be placed on a non-combustible
oor or on the ground well away
from all combustible materials,
pending final disposal. If the
ashes are disposed of by burial
in soil or otherwise locally dis-
persed, they should be retained
in the closed container until all
cinders have thoroughly cooled.
1. Front Refractories
2. Bottom Refractory
3. Left Side Refractory
4. Right Side Refractory
5. Back Refractory
6. Front Ceramic Bafe
7. Rear Ceramic Bafe
NOTE:DIAGRAMS&ILLUSTRATIONSARENOTTOSCALE.
6

Facade Installation
Install the Facade per instructions provided in
Facade Kit (ordered separately - see Page 20).
Framing, Facing And Mantel
The construction of the framing, facing, and
mantel must be in accordance with the stan-
dards and the following illustrations (Figures
10 and 11):
A.Framethereplaceusing2”x3”orheavier
lumber.
B. WARNING: Combustible materials can-
not be used in the space directly above
the replace, except for the studs above
the facade that support the facing and
mantel. This area must remain empty
for a height of 6’8” (2,032 mm) mea-
sured from the base of the appliance.
C. Frame the fireplace with vertical studs at the
sides of the fireplace running from floor to
ceiling (see Figure 8). If combustible facing
is to be used, position the studs back, from
the front edge of the fireplace (a space that
is the thickness of the facing material, so
that the facing can be installed flush with the
fireplace facing). Frame headers between
the vertical studs only as follows:
• Place 2” x 3”  or  2” x 4” headers,
only along the upper part of the front,
side and back faces (some codes
mayrequirea2”x6”onanoutside
bearing wall). Do not put wood or
any combustible material within the
area above the fireplace except on the
front facing.
• Placeheadersonlyasrequiredtosup-
port the facing and mantel.
D. WARNING: The fireplace must not be in
contact with any insulation or loose fill-
ing material. Cover the insulation with
drywall panels around the fireplace.
Hearth Extension Requirements
The BIS®Tradition CE fireplace may be installed
directly on a combustible floor. The supplied
safety metal strip must be positioned asfollows:
One half under the front of the fireplace and the
other half must extend on the floor over which
thehearthextensionwillbebuilt(seeFigure7A).
* The safety metal strip must cover the entire
width of the fireplace.
The combustible floor in front of the fireplace
must be covered with a non-combustible mate-
rial (tile, marble, stone, etc). See Figures 7B.
COLD CLIMATE INSTALLATIONS
Climates where temperatures will fall below
32° F (0° C).
The heating performance of the appliance will
vary depending upon the level of insulation,
house design, how the appliance is operated,
etc.
If this fireplace is being installed in a cold
climate, it is especially important to seal all
cracks around the fireplace and wherever cold
air could enter the room with noncombustible
material.
Also,theoutsideairinletductshouldbewrappedwithnoncombustibleinsulationtominimize
the formation of condensation. Do not place insulation materials directly against the chimney
sections. We recommend that you use the insulated wall radiation shield since it will maintain the
home’s thermal barrier. AC chimney is NOT recommended in very cold climates (in areas with
temperatures below 32°F (0°C).
Figure 7B
42”
(1067mm)
Min.
18”
Area where wood
Mantel can be
installed
Non-Combustible Material
45 Deg.
4”
36”
17” Min.
Hearth
Extension
(457mm)
(914mm)
(432mm)
(102mm)
Mantel
WARNING: THE HEARTH EXTEN-
SION IS TO BE INSTALLED ONLY
AS ILLUSTRATED.
The crack between the fireplace
and the hearth extension must be
sealed with a non-combustible
material such as sand-cement
grout.
Safety Metal Strip
Hearth Extension
Non-Combustible
Finish Material
Floor
Figure 7A - Hearth Extension Requirements
Fireplace
1/2”
13mm
uElevated fireplace installations
require a special “Z” Metal
Safety Strips (eld provided),
in place of the safety metal strip
shown above. The safety strip
should extend the full width of
the fireplace. When more than
one safety stripis used they must
overlap by a minimum of 1”.
Platform
2”
Fireplace
Elevated Fireplaces
u
12" MAX.
(305mm)
Hearth extension of an elevated fireplace
must respect the same minimal dimensions
as a replace installed directly on the oor.
7
NOTE:DIAGRAMSandILLUSTRATIONSARENOTTOSCALE.

FRAMING DIMENSIONS
Fireplace Opening Width
A 36-1/4” 921 mm
B 42” 1067 mm
C 30-1/16” 764 mm
D 13-1/2” 343 mm
E 77” 1956 mm
F 37-1/2” 953 mm
G *24-1/2” 603 mm
J 53-3/4” 1365 mm
K 8” 203 mm
L 1” 25 mm
Fireplace Framing
Header
B
A
OUTSIDE CHASE
G
C
A
Back Wall of Chase/Enclosure
Including Finising Materials if any
Rough Framing Face (Unfinished Shown)
* Zero Clearance
From Back
Spacer to Wall
Corner Installation
* Total depth is 25 inches (635mm) including the
back spacer minus 1/2 inch (13mm) for drywall
to be ush with the facing.
7’
Min. B
G
2” x 3”
Min.
Rough Framing Face
(dimension includes finish
material inside framing, if any)
19-19/32”
F
20-1/2”
J
E
D
9-3/4”
28-1/32” 1”
13-15/16”
10-3/8”
24”
22-19/32”
36-1/16”
36”
42”
22-1/2”
12-1/4”
3-1/4”
6-3/4
8-1/4”
17-3/4”
24”
15-1/2”
12-3/4
3-3/4
17-3/4”
Figure 8 - Framing Dimensions
Combustible materials can NOT
be used in the space directly
above the fireplace. Do not fill
the space above the fireplace
with any material (Except the
wood framing)
Notes
Diagrams, illustrations and photo-
graphs are not to scale – consult
installation instructions. Product
designs, materials, dimensions,
specifications, colors and prices are
subject to change or discontinuance
without notice.
All framing dimensionscalculated for
1/2" dry wall at the fireplace face. If
sheathing the chase or finishing with
other thickness materials, calcula-
tions will need to be made.
* The fireplace must not be in
contact with any insulation or loose
filling material. Cover the insulation
with Drywall panels around the
fireplace.
K
Combustion Air Kit
NOTE:DIAGRAMS&ILLUSTRATIONSARENOTTOSCALE.
1. Combustible material must be
installed flush with the fireplace. It
may not project in front of and on
the fireplace (i.e. the steel facade of
the fireplace) (Figure 12).
2. Non-combustible materials such as
brick, stone or ceramic tile may proj-
ect in front of and onto the fireplace
facing (Figure 13).
IMPORTANT
The facade must be removable
once installed. The facade is
designed to overlap any facing
material installed on the front of
the fireplace. If thicker material
is installed, use the facade as a
template and make sure it can be
easily removed for servicing.
Facing
Plywood 1/2”
8

Figure 9
INSULATED CHASE CONSTRUCTION
Figure 11
Floor
Ceiling
Wall
• Must have the same firestopping
resistance as adjacent wall.
• Must have the same insulation as
adjacent ceiling.
• Follow local rules regarding framing
construction.
Attic Radiation
Shield
Roof Support Storm Collar
Flashing
Drywall or Any Rigid
Material
2” x 4”
FIREPLACE
1/2” Plywood
Firestop
13
4
5
6
2
1
2
7
3
4
1. Fireplace
2. Front of fireplace
3. Wood frame (2” x 3” min)
4. Drywall
5. Tiles
6. Rock board or other
7. Brick
Fireplace Frame Section
(Top View)
Figure 10
Mantel
Rock Board
or Other
Noncombustible
Facing
Drywall
Spacer
Mantel and Facing
(Side View)
Insulate Joists
Same As Ceiling
Draft Stops
Firestop
CTDT
Termination
Note: Non-
Combustible
Chase
Flashing
Must Be
Used To
Cover
Chase
Opening
Optional
Insulation
In Outside
Walls Of
Chase
Solid
Continuous
Surface
Outside
Base
Insulation
(Thermal Barrier)
8'
Level
7’
(2.1 m)
Min.
6’ 8”
(2 m)
Min.
8’
(2.4 m)
Level
42” (1067mm)
2” X 3” Min.
(51mm x 76mm)
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
...
..
Rock Board
or Other
Noncombustible
Facing
Drywall
NOTE: It is recommended that the
chase walls and floor be insulated
in the same manner, using the
same insulation, as the rest of the
building, below the attic.
SEE NOTE
Mantel and Facing
The mantel must be installed at least 42”
(1067 mm) above the base of the fireplace
(Figure 11).
Nailing Flanges
Four nailing flanges are provided to secure the
fireplace to the floor (see figure below). Bend
the nailing flanges down so that each flange is
flush with the floor, then using nails or screws,
secure the fireplace to the floor (2 places each
side). The heads of the screws or nails must
be large enough to completely cover the holes
in the nailing flanges.
Fireplace Side
Nailing Flange
(2 places each side)
Unbend to oor
and nail/screw
NOTE:DIAGRAMS&ILLUSTRATIONSARENOTTOSCALE.
9

HOT AIR DUCTING INSTALLATION
The BIS® Tradition CE wood burning fireplace
is approved for use with a Gravity kit (hot air
ducting system).
Gravity Kit
The gravity kit is designed for double hot air
outlets and includes: (See Figure 14).
 - Two(2)telescopiclengths8”I.D.
 - Two(2)90ºelbows8”I.D.
- Two (2) hot air outlet kits
(grill and frames)
- Two (2) adaptors
See Gravity Kit Accessories Page 20.
For safe installation, the gravity kit must meet
the following requirements:
Minimum height*68”(1,727mm)
Maximum length See Figure 14
* The height of the louver must be measured
from the base of the BIS Tradition CE fireplace
to the middle point of the louver.
The only blower that can be usedwith thegravity
kit is the one sold with the fireplace.
To extend the double outlet system, it will be
necessary to purchase two adjustable lengths
(H8951).
Figure 15
When installing the double outlet system, the
hot air outlets can be installed in the same room
as the fireplace, or one or both of the outlets
can be installed in adjacent or upper rooms.
Installing the ducts at different elevations will
tend to exhaust more heat out of the higher
outlet (Figure 14).
Figure 14
Frame
Grill
Noncombustible Facing
Drywall
2” X 3” Min.
Rock Board or Other
Spacer
Figure 12
FIREPLACE BLOWER
The fireplace comes equipped with a heat acti-
vated blower. It is located in the bottom of the
fireplace, towards the back. It uses 120V and
must be connected to the main electrical circuit
by a qualified electrician. For connection,use the
electrical box supplied with the unit located on
the bottom right corner of the fireplace.
If you wish to adjust the blower speed, the
variablespeedcontrol(VRUW)providedmust
be installed in line with the wiring. Again, use
a qualified electrician for installation.
If the blower requires servicing,
1- Remove the doors and decorative facade.
2- Remove the screw located below the blower
motor that holds it to the back of fireplace.
3- Pull the blower out of the unit through the
square hole located in the front bottom right
corner.
Figure 13
Only non-combustible mate-
rial should be superposed or
projecting over the front of
the fireplace.
42”
(1067mm)
Min.
WARNING: Both pipes of
the double hot air outlet
must be installed. Any oth-
er installation may cause
fire and void warranty.
NOTE:DIAGRAMS&ILLUSTRATIONSARENOTTOSCALE.
10
13” x 13”
10’
(3.1m)
Max.
Maintain at least 6-1/2”
(160 mm) clearance from
the outlet grill framing to
a combustible ceiling,
side wall or mantel.
Outlet Grill
Outlet Grill
WARNING: The outlet grills
should not be installed fac-
ing upward through a oor.
Danger of burns can result
if grills in oor are stepped
on.
(330mm x 330mm)
10’ (3.1m)
Max.

Figure 17
OUTSIDE AIR KIT
It is mandatory to install an outside air con-
nection to the BIS®Tradition CE wood burn-
ing fireplace. The following components are
required and are included with the fireplace:
• Outsideairkit(includes4inchexthatgoes
up to ten (10) feet long)
• 4”Adaptorforreplaceconnection
The outside air assembly must be installed ac-
cording to the following requirements:
Outside Air Installation
The outside air assembly may be installed ac-
cording to the following requirements:
A) Duct length should be kept to a minimum.
Themaximumlengthofa4”interiordiameter
(100 mm) insulated flexible duct is twenty
(20) feet (6.1 m). (See note below).
B) The air intake register must not be installed
more than ten (10) feet (3050 mm) above
the base of the fireplace.
C) The fresh air must come from outside the
house. The air intake must not draw air from
the attic, basement or garage.
D) The air intake should be installed where
it is not likely to be blocked by snow or
exposed to extreme wind and away from
automobile exhaust fumes, gas meters and
other vents.
E) The duct and register may be installed above
or below floor level.
Makea4-1/4”(110mm)holeintheoutside
wall of the house at the chosen location. From
outside, place the outside air register in the hole
(open side down) and fasten the register to the
wall with screws as shown (see Figure 18).
Slip the pipe into the insulated sleeve. Place
the insulated pipe over the register tube and
over the fireplace’s outside air connector (see
Figure 19). At each end, carefully pull back the
insulation and plastic cover exposing the flex-
iblepipe.Usingthealuminiumtapeprovided,
wrap the tape around the joint between the
flexible pipe and the air inlets. Carefully push
the insulation and plastic cover back over the
pipe.Usingaluminiumtape,fastentheplastic
cover in place.
NOTE: We recommend not to exceed twenty
(20) feet of 4” flexible pipe. If you require a
longer length we recommend that you use a 5”
diameter flexible pipe for the complete run up
to thirty (30) feet and a 6” diameter pipe for a
run of up to forty (40) feet.
The duct system must be installed respecting
the following:
1. Removetheplatesclosingupthe8”dia.holes
on top of the fireplace. Then, cut the insula-
tioninordertoobtaintwo8”dia.openings.
Fix the adaptors on the fireplace openings
by turning clockwise (Figure 15).
2.Maintainatleasta2”(50mm) clearance
between the ducts and any combustible
material;therequiredholesizeis13”x13”
(330 mm x 330 mm).
Exception #1: For the grills, the fram-
ing can be 10-3/4” x 10-3/4” (275 mm
x 275 mm) to provide the clearance as
required by the integral spacers on the
double outlet duct system.
3. The maximum number of elbows in a run
of duct is two.
4.Maintainatleast6-1/2”(160mm)clearance
from the outlet grill framing to a combustible
ceiling, side wall or mantel.
5. When traversing a combustible wall or floor,
a firestop must be installed at the wall or
oor penetration.  The hole size must be
13”x13”(330mmx330mm)
6. Do not connect the hot air ducts to a central
heating system. Malfunction of the heating
system’s blower will cause the fireplace to
overheat. A furnace duct is only single wall
and not double wall as is required for the
BIS®Tradition CE fireplace hot air exhaust.
7.Use only IHP grills and components as
described in this manual. Other grills or
registers, for example, may be too restrictive
and may overheat the fireplace or ceiling.
8. Do not use insulated flexible ducts as they
will overheat.
9. Do not use tees or any other components
than the ones specifically listed here.
10.Never allow the ducting to pitch down as
hotairwillbetrappedcreatingarehazard.
Never route the ducting downwards.
11.The hot air outlet grills must be installed with
the louvers pointing downwards in order to
prevent overheating adjacent ceilings.
12.Always install the two outlet grills when
using the double hot air outlet kit.
Rain Cap
Flashing Collar
Flashing
Firestop
68” Min.
(1727mm)
42” Min.
(1067mm)
Non-Combustible
Facing
Roof Support
Attic Radiation Shield
6-1/2” Min.
(165mm) to ceiling
NOTE:DIAGRAMS&ILLUSTRATIONSARENOTTOSCALE.
11

Figure 18
OUTSIDE CONNECTION
Figure 19
Aluminum Tape
Aluminum Tape
Fireplace
Connection
Plastic
Cover
Insulation
Flexible Pipe
Fireplace
5. All chimney installations must include at least one support. Re-
ducing the amount of chimney weight on the fireplace will help avoid
the noise created when the fireplace expands. This can be achieved
by having the chimney supported by the supports. The maximum
chimney length that can be supported by the fireplace is nine (9) feet
(2.75m)forS-2100+/HT6000+,twelve(12)feet(3.7m)forASHT+*
/HT6103+*and 26 feet (8 m) for AC chimney*.
6. The chimney must extend at least three (3) feet (915 mm) above its point
of contact with the roof and at least two (2) feet (610 mm) higher than
any wall, roof or building within ten (10) feet (3m) of it (Figure 20).
7. If the chimney extends higher than five (5) feet (1,500 mm) above its point
of contact with the roof, it must be secured using a roof brace.
8. A rain cap must be installed on top of the chimney. Failure to install
a rain cap may cause corrosion problems.
9. Cut and frame square holes in all floors, ceilings, and roof that the
chimneywillgothroughtoprovidea2”(50mm)clearancebetween
thechimneyandanycombustiblematerials.Donotllthis2”space
with insulation or any other combustible material.
10.Portions of the chimney which may extend through accessible spaces
must be enclosed to avoid contact with combustible materials or
damage to the chimney.
11.When offsets are used, the pipe may not penetrate a ceiling or floor
unless it is running vertical (no 30° offsets).
Outside
Intake
Screw
Opening
Facing
Down
Wall
Aluminum Tape
Plastic Cover
Insulation
Flexible Pipe
Aluminum Tape
NOTE:DIAGRAMS&ILLUSTRATIONSARENOTTOSCALE.
NOTE:2"clearancetocombustiblesaroundchimneycomponentsrequired.
NOTE: Blown or fill type insulation materials must not be in contact with
the fireplace or in the enclosure frame as described in ‘’Enclosure’’ section.
NOTE: Local codes may not require firestopping at the ceiling levels for
outside chase installations. However, it is recommended for safety and
the reduction of heat loss.
THE CHIMNEY SYSTEM
Chimney Installation Notes
1. If possible, install an interior chimney as it will provide better perfor-
mance. In areas with continuous temperatures below -18° C (0° F),
the use of an exterior chimney increases the likelihood of operating
problems such as low draft, high rate of creosoting, and poor start-up
characteristics. Exterior chimneys are also prone to down-with dry and
flow reversal. Installations, which are located on lower floors in the
house, such as in a basement, in combination with outside chimney,
are especially prone to flow reversal.
2. The IHP fireplace model BIS®Tradition CE may be installed only with
SecurityChimneysInternational6”diameterchimneysystems.
3. A chimney venting a fireplace shall not vent any other appliance.
4. The minimum chimney height is twelve (12) feet (3.7 m). In altitude,
add18”(450mm)tothechimneyforevery2,000feet(600m)above
sea level.
Figure 20
two (2) feet Min.
three (3) feet Min.
ten (10) feet
12
*Available from Security Chimneys™

CHIMNEY INSTALLATION
INSTRUCTIONS
1. Cut and frame the holes in the ceiling, floor
and roof where the chimney will pass (see
Figure 21).Useaplumb-bobtolineupthe
centeroftheholes.Thesizesareindicated
in Table 2 for the floor and ceiling holes
and Table 3 (Page 15)for the roof holes.
2.Frombelow,installarestopineachceiling/
floor separation through which the chimney
will pass. At the attic level, install an attic
radiation shield from above (Figures 22a
and 22b).
3.ForASHT+/HT6103+andS2100+/HT6000+
chimneys*
place the first chimney length on
thereplace.Tolockitinplace,turn1/4of
a turn clockwise. With the AC chimney, you
must use a starter section before installing
the first chimney length (Figure 23). Con-
tinue installing chimney lengths making sure
to lock each length in place.
4. Every time the chimney passes through
a ceiling or a wall, install the appropriate
firestop. When you reach the desired height,
install the roof support. When installing a
support, slightly lift the chimney system so
the weight will lie on the support, not on the
fireplace to reduce expansion noises (refer
to instructions included with the support).
5. Then, put the roof flashing in place and seal
the joint between the roof and the flashing
with roofing pitch (see Figures 24 and 25).
For sloping roofs, place the flashing under
the upper shingles and on top of the lower
shingles. Nail the flashing to the roof, using
roofing nails.
6. Place the spacers and the storm collar over
the flashing, and tighten it with the bolt
supplied. Finally, seal the joint between the
storm collar and the chimney, using silicone
caulking.
7. Install the chimney cap. Once the chimney
cap is in place, the roof flashing can be
washed with a solvent or vinegar and then
painted with rust-proof paint.
CHIMNEY MODEL
*
SQUARE HOLE
SIZE OPENING
ASHT+ / HT6103+ 12-3/8” (314 mm)
S-2100+ / HT6000+ 14-1/8” (359 mm)
AC 15 in (380 mm)
NOTE: See Table 3 for Sloped Roof Framing
Table 2 - Flat Roof Framing
Figure 23
Rain Cap
Collar
Flashing
Attic Radiation
Shield
Firestop
Universal Support
Outside Combustion
Air Kit
AC Starter Section
Figure 21
Chimney Outside
Air Intake
(required when
using AC chimney)
AC CHIMNEY INSTALLATION*
Figure 22a
Attic Radiation Shield
ASHT / S2100
HT6103+ / HT6000+
Solid Packed Pipe*
AC
Air Cooled Pipe*
Figure 22c
Radiation Shield
Attic Radiation
Shield
Firestop
Figure 22b
Flashing
Attic Radiation
Shield
Roof
Mobile / Manufactured Home with Flat Roof
ASHT / S2100
HT6103+ / HT6000+*
Mobile / Manufactured Home with Flat Roof
AC Chimney*
Flashing
Attic Radiation
Shield
Figure 22d
(AIR COOLED GALVANIZED CHIMNEY)
u
uCombustibles are not allowed below top spacers
above the fireplace. Facing in front of fireplace must
be non-combustible below this area.
13
NOTE:DIAGRAMS&ILLUSTRATIONSARENOTTOSCALE. *Available from Security Chimneys™

Roof Down Slope Hole Size
SLOPE ASHT+ / HT6103+ S-2100+ / HT6000+ AC
Roof Pitch 6” 6” 6”
0 * 12-3/8” (314 mm) 14-1/8” (359 mm) 15” (380 mm)
2/12 12-9/16” (319 mm) 14-3/8” (365 mm) 15 3/8” (390 mm)
4/12 13” (330 mm) 14-7/8” (378 mm) 16 1/8” (410 mm)
6/12 13-7/8” (352 mm) 15-3/4” (400 mm) 16 7/8” (430 mm)
8/12 14-7/8” (378 mm) 17” (432 mm) 18 1/4” (465 mm)
10/12 16-1/8” (410 mm) 18-3/8” (467 mm) 19 5/8” (500 mm)
12/12 17-1/2” (445 mm) 20” (508 mm) 21 3/8” (545 mm)
* Cross Slope Hole Size
Put the chimney cap into place.
Wash the roof flashing with a solvent or vinegar, then paint it with rust-proof paint.
Table 3
Figure 24 Figure 25
Figure 31
Minimum Chimney Height Using Elbows
Fireplace Model BIS®Tradition CE
Chimney Model ASHT+ / S2100+ / HT6103+ / HT6000+ / AC
Vertical installation 12 feet (3.66 m)
Two (2) elbows 15 feet (4.57 m)
Four (4) elbows 17 feet (5.18 m)
Table 4
After reaching the location requiring the
elbow, proceed as follows:
ASHT+ / HT6103+ / S-2100+ / HT6000+
Chimneys
1. Install the first elbow; turn it in the required
direction. Fasten it to the chimney with
thethree(3)1/2”(12mm) metal screws
provided with the elbow.
2. Install the necessary chimney lengths to
achieve the requiredoffset. Lock the chimney
lengths together: it is recommended to use
three(3)1/2”(12mm)screws.Iftheoffset
length is made of two (2) chimney lengths or
more, use an offset or roof support halfway
up the offset. If penetrating a wall, install
a wall radiation shield (see Figures 27 and
29).
3.Use another elbow to turn the chimney
vertically. Secure the elbow, using three
(3)1/2”(12mm)screws(providedwiththe
elbow).
4.Useaplumb-bobtoline upthecenterof
the hole. Cut a hole for the chimney in the
ceiling/oor.Framethisholeasdescribed
previously (refer to section Chimney Instal-
lation Instructions).
5. From below, install a firestop (See Figure
22a).
6. A support (ST or SO) must be used on the
first 15’ section (5 m).
7. Continue with the regular installation.
AC Chimney
1. Install the first elbow. Turn it in the required
direction.Tolockitinplace,turn1/8ofa
turn. Fasten the straps attached to the elbow
to the surrounding frame, using nails or
drywall screws (see Figure 27).
2. Install the necessary chimney lengths to
achieve the requiredoffset. Lock the chimney
lengths together. If penetrating a wall, use
a wall radiation shield.
3.Use another elbow to turn the chimney
vertically. Lock it to the chimney. Fasten
the straps attached to the elbow to the
surrounding framing using nails or drywall
screws.
4.Useaplumb-bobtolineupthecenterofthe
hole. Cut a hole for the chimneyin theceiling.
Frame this hole as described previously.
5. From below, install a firestop (see Figure
22c).
6. Continue with the regular installation.
NOTE: When using AC chimney, an AC6SB
starter section must be used before install-
ing an elbow. When an offset is needed
immediately off the top of the fireplace, an
elbow starter section, AC6SB30 (H3780), is
available.
AC
Air Cooled Chimney
Collar
Chimney
Flashing
OFFSET CHIMNEY INSTALLATION
After reaching the location requiring the elbow, proceed as follows. The minimum chimney height
when using elbows is:
Spacer (built
into ashing)
NOTES:
• Must return to vertical before penetrating ceiling or floor.
• A maximum of 2 offsets are allowed.
NOTE:DIAGRAMS&ILLUSTRATIONSARENOTTOSCALE.
14

Figure 26
Chimney
6”
*
Elbow Offset &
Height
One Length Between Elbows Two Lengths Between Elbows
8” 12” 18” 24” 36” 48” 8” & 48” 12” & 48” 18” & 48” 24” & 48” 36” & 48” 48” & 48”
Secure
Temp®
ASHT
Nova
Temp
HT6103+
15º
A
3-5/16”
(84mm)
4-5/16”
(110mm)
5-7/8”
(149mm)
7-7/16”
(189mm)
10-1/2”
(267mm)
13-5/8”
(346mm)
15-3/8”
(391mm)
16-7/16”
(418mm)
18”
(457mm)
19-1/2”
(495mm)
22-5/8”
(575mm)
25-3/4”
(654mm)
B
15-11/16”
(398mm)
19-9/16”
(497mm)
25-3/8”
(645mm)
31-3/16”
(792mm)
42-3/4”
(1086mm)
54-3/8”
(1381mm)
60-15/16”
(1548mm)
64-13/16”
(1646mm)
70-9/16”
(1792mm)
76-3/8”
(1940mm)
87”
(2210mm)
99-9/16”
(2529mm)
30º
A
7-7/16”
(189mm)
9-7/16”
(240mm)
12-7/16”
(316mm)
15-7/16”
(392mm)
21-7/16”
(545mm)
27-7/16”
(697mm)
30-13/16”
(783mm)
32-13/16”
(833mm)
35-13/16”
(910mm)
38-13/16”
(986mm)
44-13/16”
(1138mm)
50-13/16”
(1291mm)
B
20”
(508mm)
23-1/2”
(597mm)
28-11/16”
(729mm)
33-7/8”
(860mm)
44-1/4”
(1124mm)
54-11/16”
(1389mm)
60-9/16”
(1538mm)
64“
(1627mm)
69-1/4”
(1759mm)
74-7/16”
(1891mm)
84-13/16”
(2154mm)
95-1/4”
(2419mm)
45º
A
10-5/16”
(262mm)
13-3/16”
(335mm)
17-3/8”
(441mm)
21-5/8”
(549mm)
30-1/8”
(765mm)
38-5/8”
(981mm)
43-7/16”
(113mm)
46-1/4”
(1175mm)
50-1/2”
(1283mm)
54-3/4”
(1391mm)
63-1/4”
(1607mm)
71-11/16”
(1818mm)
B
17-13/16”
(452mm)
20-5/8”
(524mm)
24-7/8”
(632mm)
29-1/8”
(740mm)
37-5/8”
(956mm)
46-1/8”
(1172mm)
50-15/16”
(1294mm)
53-3/4”
(1365mm)
58”
(1473mm)
62-1/4”
(1581mm)
70-3/4”
(1797mm)
79-3/16”
(2011mm)
Chimney
6”*
Elbow Offset &
Height
One Length Between Elbows Two Lengths Between Elbows
--- 12” 18” --- 36” 48” --- 12” & 48” 18” & 48” --- 36” & 48” 48” & 48”
AC
6”
15” A----
----
4-13/16”
(122 mm)
6-1/8”
(156 mm)
----
----
11”
(280 mm)
14-1/8”
(359 mm)
----
----
16-7/8”
(429 mm)
18-7/16
(468 mm)
----
----
23”
(584 mm)
26-3/16”
(665 mm)
B----
----
27-11/16”
(703 mm)
33-1/2”
(851 mm)
----
----
50-7/8”
(1292 mm)
62-1/2”
(1588 mm)
----
----
72-5/8”
(1845 mm)
78-7/16”
(1992 mm)
----
----
95-3/4”
(2432 mm)
107-3/8”
(2727 mm)
30” A----
----
9-3/8”
(238 mm)
12-3/8”
(314 mm)
----
----
21-3/8”
(543)
27-3/8”
(695 mm)
----
----
32-5/8”
(829 mm)
35-5/8”
(905 mm)
----
----
44-5/8”
(1134 mm)
50-5/8”
(1286 mm)
B----
----
25-3/4”
(654 mm)
31”
(787 mm)
----
----
46-1/2”
(1181 mm)
57”
(1448 mm)
----
----
66”
(1676 mm)
71-1/4”
(1810 mm)
----
----
86-7/8”
(2207 mm)
97-1/4”
(2740 mm)
N OTE: With the AC chimney
*
, a starting length of 6” high must be used on top of the fireplace before installing an elbow.
Chimney
6”*Elbow Offset &
Height
One Length Between Elbows Two Lengths Between Elbows
8” 12” 18” 24” 36” 48” 8” & 48” 12” & 48” 18” & 48” 24” & 48” 36” & 48” 48” & 48”
Secure
Temp
S2100+
Nova Temp
HT6000
15º A3-5/16”
(84mm)
4-5/16”
(110mm)
5-7/8”
(149mm)
7-7/16”
(189mm)
10-1/2”
(267mm)
13-5/8”
(346mm)
15-1/2”
(394mm)
16-1/2”
(419mm)
18-1/16”
(459mm)
19-5/8”
(498mm)
22-3/4”
(578mm)
25-13/16”
(656mm)
B16”
(406mm)
19-7/8”
(505mm)
25-11/16”
(652mm)
31-1/2”
(800mm)
43-1/16”
(1094mm)
54-5/8”
(1387mm)
61-7/16”
(1561mm)
65-1/4”
(1657mm)
71-1/16”
(1805mm)
76-7/8”
(1953mm)
88-1/2”
(2248mm)
100-1/16”
(2542mm)
30º A7-3/8”
(187mm)
9-3/8”
(238mm)
12-3/8”
(314mm)
15-3/8”
(391mm)
21-3/8”
(543mm)
27-3/8”
(695mm)
30-7/8”
(784mm)
32-7/8”
(835mm)
35-7/8”
(911mm)
38-7/8”
(987mm)
44-7/8”
(1140mm)
50-7/8”
(1292mm)
B20-11/16”
(525mm)
24-3/16”
(614mm)
29-3/8”
(746mm)
34-9/16”
(878mm)
44-15/16”
(1141mm)
55-5/16”
(1405mm)
61-3/8”
(1559mm)
64-7/8”
(1648mm)
70-1/16”
(1780mm)
75-1/4”
(1911mm)
35-5/8”
(2175mm)
96”
(2438mm)
Horizontal Offset
Total Height
Offset Dimensions
A
B
NOTE:DIAGRAMS&ILLUSTRATIONSARENOTTOSCALE.
15
*Available from Security Chimneys™

Figure 27
OFFSET CHIMNEY INSTALLATION
*
Chimney AC
Support ACRS
Starter Section
Rain Cap
Collar
Roof Flashing
Offset Support
Insulated Wall
Radiation Shield
Framing
2” x 3”
Figure 28
Straps
Straps
OFFSET CHIMNEY INSTALLATION WITH WALL PENETRATION*
NOTE: In cold areas it is recom-
mended to protect the chimney in
a insulated chase.
NOTE: This illustration is not
to scale. It represents how the
chimney must be supported.
A 30 degree offset only is
allowed in the USA and a 45
degree maximum offset is
allowed in Canada.
ANGLED WALL RADIATION SHIELD*
(RSM+ and RSMI30)
When traversing a combustible wall with the chimney at a 30º or 45º
angle, an angled firestop or wall radiation shield must be installed. Only
one is required.
NOTE: 45º angle for Canada only (RSMI45*)
In cold climate locations (climates where temperatures will fall below 32°
F/0°C),werecommendthatyouusetheinsulatedwallradiationshield
since it will maintain the home’s thermal barrier.
RSM+ and RSMI30
(RSMI45 - Canada Only)
Chimney Model*Angle Hole Size
ASHT+ / HT6103+
(6” dia). Canada only
30º 283 mm x 781 mm (11-1/8” x 30-3/4”)
45º 283 mm x 518 mm (11-1/8” x 20-3/8”)
S-2100+ / HT6000+ /
AC (6” dia).
30º 327 mm x 881 mm (12-7/8” x 34-11/16”)
30º 380 mm x 972 mm (15” x 38-1/4”)
Table 5
Figure 29
Drywall
Insulated Wall
Insulated Wall
Radiation Shield
NOTE:DIAGRAMS&ILLUSTRATIONSARENOTTOSCALE.
16
*Available from Security Chimneys™

If possible, you should choose a location where
the chimney will pass throughthehouse without
cutting floor or roof joists (see fireplace dimen-
sions Page 9).
Usually,noadditionaloorsupportisneeded
for the fireplace. The adequacy of the floor
can be checked by first estimating the weight
of the fireplace system. Weights are given
on Page 23. Note the floor construction and
consult your local building code to determine
if additional support is needed.
The BIS Tradition CE fireplace may be installed
directly on the floor or on a raised base (for
proper guidelines, refer to “Hearth Extension
Requirements”)andaminimumof6’8”(2m)
measured from the base of the appliance to the
ceiling is required.
When selecting the location, the chimney outlet
position and the direction of the wind are impor-
tant factor affecting the chimney performance.
To allow a maximum draft and to reduce wind
turbulence, the chimney must:
• Penetratethehighestpartoftheroof.
• Beinstalledasfaraspossibleofroofoffsets,
trees or any other obstructions that may
cause wind turbulence and back drafts in
the chimney.
• Theleastamountofoffsets(elbows)pos-
sible. NOTE: A maximum of 2 offsets is
allowed.
GLASS CARE
Glass Replacement
TheglassusedfortheBIS®Tradition CE fireplace
isahightemperatureceramicglass(1,400°F/
760° C). If the glass breaks, it must be replaced
with an identical ceramic glass. Tempered glass
or ordinary glass will not withstand the high
temperatures of the BIS Tradition CE fireplace.
Replacement glass should be purchased from a
IHPdealer(see“ReplacementParts”,Page 23).
DO NOT OPERATE THE UNIT WITH CRACKED
OR BROKEN GLASS.
Glass Cleaning
The BIS Tradition CE fireplace is designed to
keep the glass clean under normal operating
conditions. If the BIS Tradition CE fireplace is
operated continuously with the combustion air
controls closed, the glass will tend to get dirty
unless the fuel, firebox and glass are maintained
at hot temperatures (see “Refueling For Best
Performance”).Tocleantheglass,therearea
number of speciallydesignedcleaners. Your IHP
dealer can recommend a suitable cleaner which
is available in your area. Regular household
glass cleaners will not clean creosote. Do not
use abrasives such as steel pads, steel wool
or oven cleaner as they will scratch the glass.
DO NOT USE CHEMICAL GLASS CLEANERS
ON PAINTED SURFACES AS IT MAY CAUSE
THE PAINT TO PEEL.
CAUTION : DO NOTALLOW WINDOW CLEANER
TO GET IN CONTACT WITH DOOR GASKET OR
PAINT ON FACADE OR DOOR. ONCE CLOSED,
CONTACT OF GLASS CLEANER WITH THE
FIREPLACE FACADE CAN PROVOKE PAINT
PEELING OFF.
Gasket Length Dimensions Part No.
Steel Door
Around
Glass
69
(1753)
1x3/16
(25 x 4.8) PR-SR1685D
On Door
Frame
73
(1854)
5/8dia.
(15.9) PR-SR1823G
Cast Door
Around
Glass
69
(1753)
1x5/16
(25 x 4.8) PR-SR1823H
On Door
Frame
73
(1854)
5/8dia.
(15.9) PR-SR1823G
Inches (millimeters)
FIREPLACE INSTALLATION
Locating The BIS Tradition CE Fireplace
The best location to install your fireplace is
determined by considering the location of
windows, doors, and the traffic flow in the room
where the fireplace is located, allowing space
in front of the unit for the hearth extension and
the mantel, and taking into consideration the
location of the hot air ducts (optional), outside
air kit and chimney.
Gasket Replacement
Remove the door from the unit (see Page 6)
and lay it on a clean unabrasive surface. To
replace the gasket, first remove all of the old
gasket and gasket cement. Make sure that the
surface is totally clean before applying new
cement (a high temperature silicone caulking
rated at 500° F [260° C], is suitable) or adhesion
problems may result. Apply gasket cement to
the gasket channel and install the new gasket.
This replacement part is available from your IHP
dealer in the following dimensions:
Marginal Location
Wind Direction
Location
Not
Recommended
Outside Air Intake
Facing the Wind
Location
Not
Recommended
Location Recommended
Figure 6
NOTE:DIAGRAMS&ILLUSTRATIONSARENOTTOSCALE.
17
*Available from Security Chimneys™

CHIMNEY SUPPORT INSTALLATION
Universal Roof Support
When installing a support, slightly lift the chimney system so the weight
will lie on the support, not on the fireplace to reduce expansion noises.
This support has three possible uses:
1. For ASHT+*/HT6103+*and S-2100+*/HT6000+*, it must be used
on a roof to support the chimney.
2. It may be used on a floor, ceiling or roof above an offset to support
the chimney above the offset.
3. It may be used on a floor, ceiling or roof as a supplementary sup-
port.
Table 6 gives maximum height of supported chimney.
NOTE: For the AC chimney*, a support section must be used every forty
(40) feet (12 m) instead of the universal roof support (ST*).
For roof support installation, refer to the instructions provided with the
support.
UNIVERSAL OFFSET SUPPORT INSTALLATION
This support is used to support the chimney above an offset. When
the chimney offset is used to traverse a wall this support may be used
on the wall to support the chimney. The maximum heights are given in
Table 6. For offset support installation, refer to the instructions provided
with the support.
CHIMNEY MODEL*MAXIMUM HEIGHT OF
SUPPORTED CHIMNEY
Offset Support Roof Support
ASHT+ / HT6103+ (6” dia). 28 feet (8.54 m) 29 feet (8.84 m)
S-2100+ / HT6000+ (6” dia). 18 feet (5.49 m) 20 feet (6.1 m)
AC (6” dia). 40 feet (12.19 m) 50 feet (15.20 m)
Table 6
CHIMNEY CHASE AND MULTIPLE TERMINATIONS
For the purpose of this manual, a chimney chase is considered a part of
the chimney system rather than part of a building. The termination must
beplacedaminimumof18”(460mm)abovethechase.
For installations where more than one chimney is located in the same
chase or within the same area, we suggest that their terminations be
separatedbyatleast16”(410mm)horizontally,and18”(460mm)verti-
cally. This separation is to prevent smoke migrating from one chimney
to another (see Figure 30).
Figure 30
CHIMNEY ADAPTOR
*
(S-2100+ / HT6000+) CANADA ONLY
The fireplace is normally supplied with a chimney adaptor suitable for the
ASHT+*/HT6103+*chimney. If you want to install a S-2100+*/HT6000+*
chimney,anadaptorisavailable(6UCA*) (Figure 31). A separate starter
section will also be required if AC chimney is installed.
Figure 31
Chimney Adaptor *-
Canada only
18” (460 mm)
16” (410 mm)
18” (460 mm)
18” (460 mm)
16” (410 mm)
NOTE:DIAGRAMS&ILLUSTRATIONSARENOTTOSCALE.
18
*Available from Security Chimneys™

INSTALLATION INSTRUCTIONS FOR MASONRY APPLICATION
WARNING: Before starting the installation, the masonry chimney
must be inspected by a qualified chimney sweep.
The following requirements must be respected:
1. The chimney must be absolutely clear of any soot residue or creosote.
Check for cracks, loose or missing bricks that could inhibit correct
installation of the liner.
2.Theclearancetocombustiblemustbeaminimumof1”betweenthe
outside of the masonry and any wood framing or loose insulation.
3. The chimney must be built in accordance with the current building
code.
4. No other appliance can be connected to the same chimney.
5.Theclearancestocombustibleforthesereplaceconnectorsare2”
onthesideandbottomand16”atthetop.
6. The connector parts are not necessary if the connection between the
insulated length and the stainless steel liner is done within the masonry
chimney.
Installation:
The chimney must be relined with a stainless steel liner model Tubinox™
*
or Projet
®
SS
*
of the same diameter as the outlet of the fireplace.
Forconnectionata30ºangle,aspecialconnector(BISUMA30
*
) must be
used to connect the liner to the insulated chimney.
* IMPORTANT NOTE - The use of a 45º connector (BISUMA
*
) is ap-
proved for use in Canada ONLY. Installations in the USA must use the
30º connector (BISUMA30
*
).
Follow these steps:
1- Position the fireplace in its location. Temporarily install the ASHT+*
elbow on the top of the fireplace and, using a level, mark with an oval
the location where the flue liner will enter the masonry chimney.
2- In the middle of the oval, drill a hole in the masonry chimney at 30º.
3-Increasethesizeoftheholeuntila30ºTubinox*liner elbow can be
easily slipped through.
4- Slide the liner down from the top of the masonry chimney until you
reach the hole level.
5- Slip through the hole a 30º liner elbow and connect it to the liner.
6- Add a small liner section to the liner elbow which will allow the liner to
extendatleast12”(measuredatthetopoftheliner)fromthemasonry
chimney.
7- Seal the opening around the liner with high temperature refractory
cement.
8- The next steps must be done in the following order:
See typical installation illustrated below.
A. Select the ASHT+*length that will fit between the elbow and the liner
sothatitwillslideatleast2”overthelinersection(Youmayneedto
cut the liner for a better fit).
B.TakethatsectionandtheBISUMA30*cover and slide it over the liner.
Make sure you have enough opening to be able to install the ASHT+*
elbow without difficulty.
C. Install the 30º elbow on the fireplace.
D. Slide the length section back down on the elbow and twist lock the
two together.
E. Pull the cover down over the length and install the insulation pad over
the liner; be careful to cover the liner completely.
F. Slide back the cover over the insulation and fix it in place using the 3
metal screws supplied.
Figure 32
Fireplace
1” Clearance
* Insulated
Elbow* ASHT+ or
HT6103+
3 Screws
Insulation Pad
and Cover
High-Temp.
Cement Firestop
Tubinox*or Projet SS*
Stainless Steel Liner
Insulated
Length
Masonry Chimney,
New or Existing
Tubinox*or Projet SS*
Liner Must Slide at
Least 2” Inside Length
6’ 8”
NOTE:DIAGRAMS&ILLUSTRATIONSARENOTTOSCALE.
19
*Available from Security Chimneys™

Installation Accessories
Description Cat./ Part No.
Facades (Required - Order Separately)
BIS®Tradition CE Facade Black, BTCEFBK BTCEFBK
BIS Tradition CE Facade Gold Plated, BTCEFG BTCEFG
BIS Tradition CE Facade Brushed Nickel, BTCEFBN BTCEFBN
BIS Tradition CE Facade Hammered Steel, BTCEFMC BTCEFMC
Doors (Required - Order Separately)
BIS Tradition CE Door, Steel, Black, BTCECBK BTCECBK
BIS Tradition CE Door, Hammered Steel, BTCECMC BTCECMC
BIS Tradition CE Door, Cast Iron, BTCECBKC BTCECBKC
Outside Air Kit (included with fireplace)
OutsideAirCouplerTo ConnectOutsideAir(UZI)To Fire-
place,UZIAD
UZIAD
OutsideAirDucting-includes4”insulatedexx10’long,UZI UZI
Gravity Kit
Complete double ducting system including: 2 elbows 90º, 2
telescopic lengths, 2 grill supports and 2 black grills
H8947
Gravity Kit Accessories
Elbow90º,8”dia.,7B26ZE90 H8948
Elbow45º,8”dia.,7B26ZE45 H8949
Telescopiclength,8”dia.(15”to26”),7B26ZLA H8950
Adjustablelength8”dia(2”-5”),7B26ZL2A H8951
Length two (2) feet, 8KL2 H8954
Length one (1) feet, 8KL1 H8953
Wallradiationshield,8”I.D.,7B26ZR H8952
OPTIONAL INSTALLATION ACCESSORIES
Fireplace Kits
Description Cat./ Part No.
Rigid firescreen BUCEBWZN
Central Forced Air Kit Accessories u
Central Forced Air Kit, Central forced air kit including: blower
(BISZY), ex adaptor (BISAF), 2 clamps, variable speed
control (VRUW), thermo-disk (VTU), fan to exible pipe
adapter (BISAVF), back draft damper (BISBD), aluminium
tape, BISFWK-1
BISFWK-1
Flexiblepipe5”I.D.x15ft.Long,5FLEX15 5FLEX15
Flexiblepipe5”I.D.x30ft.Long,5FLEX25 5FLEX25
Heating and cooling thermostat, 24V, HCTW HCTW
uNot tested under EPA certification. If installed, this appliance no
longer qualifies for EPA certification.
20
